Peugeot 107 (2012 year). Instruction

RADIO

Press SRC/TEL repeatedly and select

the FM1, FM2 or AM waveband.

Press a button to listen to the

corresponding preset station.

Select the desired radio station and

confi rm by pressing "OK".

RADIO

Press LIST to display the list of stations

received in alphabetical order.

The exterior environment (hills, buildings, tunnel, car park, below ground...) may prevent reception, even in RDS station tracking (alternative

frequencies) mode. This phenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.

A long press on LIST builds or updates

the list of stations; audio reception is

cut momentarily.

Make a long press on one of the buttons

to preset the station being listened to.

The name of the station is displayed and

an audible signal confi rms the preset.

A press changes to the next or previous

letter (e.g. A, B, D, F, G, J, K, ...).

MANAGE THE LIST

PRESETTING AND SELECTING A STATION

When recalling a preset station, of the reception of the station is

poor, the radio will try to fi nd a frequency transmitting the same

programme and a message appears in the screen.

RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the country as radio stations do not cover

100 % of the territory. This explains the loss of reception of the

station during a journey.

RADIO

RDS

With source FM1 or FM2, press MENU

then select "Radio".

Select or deselect "RDS" to activate or

deactivate RDS then confi rm with "OK"

to save the setting.

ENTER A FREQUENCY MANUALLY

Press MENU , select "Radio" , then

select "Write freq." .

Press + or - to select the desired

frequency and confi rm with "OK".

RADIO

Radio text is information transmitted by the radio station related to

the current programme or song.

With the radio displayed on the screen,

press MENU then select "Radio".

Select or deselect "TXT" to activate or

deactivate the display of Radio Text.

DISPLAY RADIO TEXT

RECEIVING TA MESSAGES

The TA (Traffi c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffi c

report is transmitted, the current audio source (Radio, CD,

USB, ...) is interrupted automatically to play the TA message.

Normal playback of the audio source resumes at the end of the

transmission of the message.

Press MENU, select "Radio".

Select or deselect "TA" to activate

or deactivate the reception of traffi c

messages.

AUDIO

AUDIO CD

Insert 12 cm diameter circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no refl ection on the

quality of the original player.
Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

To play a disc which has already been

inserted, press the SRC/TEL button

several times until CD play is displayed.

Press one of the buttons to select a

track on the CD.
Press and hold one of the buttons for

fast forward or backward.

PLAYING A CD

AUDIO

CD, USB

INFORMATION AND ADVICE

On a single disc, the CD player can read up to 255 MP3 fi les spread

over 8 folder levels with a maximum of 192 folders. However, it is

recommended that this be kept to 2 levels so as to limit the time taken

to access and play the CD.
During play, the folder structure is not observed.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select standards ISO 9660 level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is

recommended.

Do not connect a hard disk or USB device other than audio players to

the USB port. This may cause damage to your installation.

The audio system will only play fi les with ".mp3", ".wma" and ".wav" on

a CD and can play fi les with ".ogg" extension only on USB.

A high compression rate can adversely affect sound quality.

The playlists accepted on CD, MP3, iPod and USB connection are

types ".m3u" and ".wpl".
The number of fi les recognised is limited to 5 000 in 500 folders on a

maximum of 8 levels.

VOL

SRC/

LIST

ESC

SEEK

MP3

100

CD, USB

AUDIO

PLAYING A COMPILATION

Insert an MP3 compilation in the CD player or

connect a memory stick to the USB port.

The system creates playlists (temporary memory) the creation time

for which can take from a few seconds to several minutes.
The playlists are updated every time the ignition is switched off or a

USB memory stick is connected.
Play starts automatically after a period which depends on the

capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.

When connecting again, the order previously chosen is

retained.

To play a disc or memory stick which has

already been inserted, press SRC/TEL

several times in succession and select "CD"

or "USB".

Press one of the buttons to select the

next or previous track.

Press one of the buttons to select the

next or previous folder in the order

chosen.

Press and hold one of the buttons for

fast forwards or backwards.

101

Select a line in the list.

Jump a page.

Press MENU, select "Media" then

select or deselect "TA" to activate

or deactivate reception of traffi c

messages.

Up a level in the menu.

AUDIO

Return to the top level of the folder structure to select the type of

tracks.
-

By Folders (CD or USB): all folders containing audio fi les

recognised on the peripheral device, in alphabetical order without

following the folder structure.

By Artist (USB only): all of the artist names defi ned in the ID3

Tags, in alphabetical order.

By Genre (USB only): all of the genres defi ned in the ID3 Tags.

By Playlist (CD or USB): if playlists have been saved.

Press LIST to display the structure of

the folders in the compilation.

Select the play mode: "Normal" ,

"Random" , "Random all" or

"Repeat" .

102

AUDIO

APPLE

PLAYERS or MOBILE PLAYER

Do not connect a device to both the USB port and the JACK

socket at the same time.

Connect the portable device (MP3 player...) to the

USB port or the JACK socket using a suitable cable

(not supplied).

The Apple

player software must be updated regularly for the

best connection.

The playlists are those defi ned in the Apple

player.

* Check your player's manual.

The auxiliary input, USB or JACK, allows the connection of a

portable device (MP3 player...).

USB PORT OR JACK SOCKET (DEPENDING ON VERSION)

Management of the device is via the audio system controls;

refer to the "CD, USB" section.

The audio fi les on a Mass Storage portable player * can be

heard through the vehicle's speakers by connecting it to the

USB port or JACK socket (cable not supplied).

The Apple

player must be generation 3 or later.

103

AUDIO

STREAMING - PLAYING AUDIO FILES VIA BLUETOOTH

DEPENDING ON THE COMPATIBILITY OF THE PHONE

Connect the telephone: see the "USING THE

TELEPHONE" section.

Streaming allows music fi les on a telephone to be heard via the

vehicle's speakers.
The telephone must support the appropriate Bluetooth

profi les

(profi les A2DP / AVRCP).

Activate the streaming source by

pressing SRC/TEL . Control of playback

is via the audio system. The contextual

information can be displayed in the

screen.

In certain cases, playing of the audio fi les must be initiated from

the telephone.

The audio quality depends on the quality of the transmission from

the telephone.

104

USING THE TELEPHONE

PAIRING A TELEPHONE / FIRST CONNECTION

The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.
Consult your telephone's manual and your operator to fi nd out which services are available to you.

Activate the telephone's Bluetooth function and

ensure that it is set as visible to all (refer to the

telephone instructions).

Press MENU then select "Bluetooth".

A window is displayed with " Searching device".

Select the telephone to be paired from

the list and confi rm with "OK". Only

one telephone can be paired at a time.

Select " Search".

For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile

telephone with the Bluetooth hands-free system of your audio system must be carried out with the vehicle stationary and the ignition on.

It is not possible to pair more that 5 telephones. Press MENU and

select "Bluetooth" . Select "BT management" . If 5 telephones are

already paired, select the telephone to be deleted by pressing "OK"

and select "Delete" (refer to "Managing connections").

Visit www.peugeot.co.uk for more information (compatibility, more help, ...).

105

USING THE TELEPHONE

A virtual keypad is displayed on the screen: choose

a 4 digit code then confi rm with OK .

A message is displayed on the screen of the

telephone: enter the same code and confi rm.

A message appears in the screen to confi rm the result of the

connection.

Pairing can also be initiated from the telephone by searching for

detected Bluetooth devices.

Accept the connection to the telephone.

If pairing fails, try again; the number of attempts is not limited.

The directory and the calls list can be accessed after the

synchronisation period (if the telephone is compatible).
Automatic connection must be confi gured in the telephone to allow

the connection each time the vehicle is started.

In some cases, the Bluetooth address of the telephone may appear

instead of the name of the telephone.

106

USING THE TELEPHONE

Press MENU then select "Bluetooth" .

Select "BT management" and confi rm. The list of

paired telephones is displayed.

Indicates connection of the audio profi le.

MANAGING CONNECTIONS

Select a telephone and confi rm "OK".

Indicates connection of the hands-free profi le.

Then select or deselect:
-

"Tel." : hands-free connection

"Audio" : play audio fi les

"OK" to confi rm the choice.
Select "Delete" to delete the

pairing.

107

USING THE TELEPHONE

Make along press on SRC/TEL to

display the calls list.

In the list of calls, select the number and choose

"Missed calls", "Dialed calls" or "Answered

calls".

Previous or next page in the calls list.

"OK" starts the call.

MAKING A CALL - RECENTLY CALLED NUMBERS *

Navigation in the calls list.

The calls list includes the calls sent from and by from the vehicle via

the connected telephone.
It is possible to make a call directly from the telephone; stop the

vehicle as a safety measure.

* Depending on the compatibility of the telephone.

For access to the calls list, it is also possible to press MENU, select

"Telephone" , then select "Call" , and fi nally select "Calls list".

108

USING THE TELEPHONE

Press MENU , select "Telephone".

Select Call then "Directory" .

An incoming call is announced by a ring and a superimposed display

in the screen.

Select the desired number and confi rm.
"OK" to start the call.

Press SRC/TEL or select "YES " to

accept the call,
or
select "NO" to reject the call.

MAKING A CALL -

FROM THE DIRECTORY

RECEIVING A CALL

A long press on ESC or on SRC/TEL

also rejects an incoming call.

109

USING THE TELEPHONE

HANG UP

In the contextual menu:
-

select "Combined mode" to

transfer the call to the telephone.

select "Combined mode" to

transfer the call to the vehicle.

In the contextual menu:
-

select " Micro OFF " to switch off the

microphone.

select " Micro OFF " to switch the

microphone on again.

In certain cases, the combined mode has to activated from the

telephone.
The Bluetooth connection will be restored automatically if the ignition

has been switched off, then on again (depending on the compatibility

of the telephone).

MANAGING CALLS

A long press on SRC/TEL also ends

the call.

In the contextual menu, select "Hang

up" to end the call.

SECRET - MUTE
(so that the caller cannot hear)

COMBINED MODE
(to leave the vehicle without ending the call)

110

Press to display the audio settings

menu.
Press to go to the next setting.

The settings available are:
- AMBIANCE:

BASS, TREBLE and LOUDNESS.

- BALANCE (left/right balance).

The AMBIANCE, TREBLE and BASS audio settings are different

and independent for each sound source.

AUDIO SETTINGS

Peugeot 107 (2012 year). Instruction - part 7
