Peugeot 107 (2012 year). Instruction - part 8

111

CONFIGURATION

DISPLAY AND LANGUAGE SETTINGS

Select "System" when you want to install an update.

Information can be obtained from a PEUGEOT

dealer.

Select "Language" to modify the display language.

Press MENU then "Confi g.".

Select "Displaying" to activate or deactivate

scrolling text.

Select "Version" for information on the software.

112

SCREEN MENU MAP

MENU

Radio

RDS

TXT

Write freq.

Media

Normal

Random

Random all

Telephone

Call

Repeat

Phone status

Directory

Calls list

Bluetooth

BT management

Missed calls

Dialed calls

Answered calls

Confi g.

Time

Scrolling text

Language

Deutsch

English

Español

Français

Italiano

Nederlands

Português

Version

System

Português-Brasil

Русский

Türkçe

Displaying

113

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Bass, Treble, Ambience,

loudness) can be adapted to the different sound sources, which may

result in audible differences when changing source (radio, CD...).

Check that the audio settings (Bass, Treble,

Ambience, Loudness) are adapted to the sources

listened to. It is advisable to adjust audio settings

Bass, Treble, Front-Rear balance, Left-Right balance)

to the middle position, select the musical ambience

and set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio mode.

When changing the

settings for treble and

bass, the ambience

setting is deselected.
When changing the

ambience setting, treble

and bass are reset to

zero.

Choosing an ambience imposes settings for treble and bass. Modifying

one without the other is only possible with a personalised ambience.

Modify the treble and bass settings or the

ambience setting to obtain the desired sound

quality.

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 MHz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

The following tables contain answers to the most frequently asked questions.

114

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

Traffi c announcement

TA is displayed. I do

not receive any traffi c

information.

The radio station does not broadcast traffi c information.

Tune to a radio station which broadcasts traffi c

information.

The stored stations are

not found (no sound,

87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the SRC/TEL button to return to the

waveband (FM1 or FM2) on which the stations are

stored.

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

Check that the CD is inserted in the player the

right way up.

Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

The audio equipment's CD player does not

play DVDs.

Due to their quality level, certain writeable

CDs will not be played by the audio system.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

The Bluetooth connection

is cut.

The battery of the peripheral may not be suffi ciently charged.

Recharge the battery of the peripheral device.

The message "USB

device error" is displayed

on the screen.

The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick in FAT 16 or FAT 32.

115

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

A telephone connects

automatically,

disconnecting another

telephone.

Automatic connection overrides manual connection.

Modify the telephone settings to remove automatic

connection.

An iPod is not recognised

when connecting to the

USB port.

The iPod is of a generation that is not compatible with the USB.

The hard disk or device

is not recognised when

connecting to the USB

port.

Some hard disks and devices need a power supply greater than is

provided by the audio system.

Connect the device to the 230 V socket, the 12 V

socket or an external power supply.
Caution : ensure that the device does not transmit

a voltage greater than 5 V (risk of destruction of

the system).

When streaming, the

sound cuts momentarily.

Some telephones prioritise connection of the "hands-free" profi le.

Delete the "hands-free" connection profi le to

improve streaming.

In "Random all" play,

not all of the tracks are

played.

In "Random all" play, the system can only take into account up to 999

tracks.

With the engine off, the

audio system switches

off after a few minutes

of use.

When the engine is switched off, the audio system operating time

depends on the battery charge.
The switch-off is normal: the audio system switches to economy mode

and switches off to prevent discharging the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The message "the audio

system is overheated"

appears on the display.

In order to protect the installation if the surrounding temperature is too

high, the audio system switches to an automatic thermal protection mode

leading to a reduction of the volume or stopping of the playing of the CD.

Switch the audio system off for a few minutes to

allow the system to cool.

116

AUDIO SYSTEM

01 First steps

For safety reasons, the driver must only carry out

operations which require prolonged attention while the

vehicle is stationary.

CONTENTS

02 Radio
03 Audio system

p.
p.
p.

117
119
124

117

FIRST STEPS

Volume adjustment

On / Off

Clock adjustment: press for

more than 2 seconds / Access

to the audio settings

Auxiliary socket for

portable equipment

(MP3 player, ...)

Minutes adjustment /

Audio settings

Selection of the source: auxiliary or

CD and CD changer (depending on

equipment)

Hours adjustment /

Audio settings

118

FIRST STEPS

With the ignition key in the accessories position or

with the ignition on, press this button to switch the

audio equipment on or off.

You exit from this mode automatically after a few

seconds without any action.

GENERAL FUNCTIONS

When the parameter is displayed, change the

setting using these two buttons.

Press this button several times in succession to

gain access to the bass (BASS) , treble (TREB) ,

front / rear balance (FAD) and left / right balance

(BAL) settings.

After the engine has been switched off, the audio equipment

can only operate for approximately 30 minutes, to prevent

discharging of the battery.

AUDIO SETTINGS

ON / OFF

Press the upper part of this button several times

in succession to increase the volume of the audio

system or the lower part of this button to decrease it.

VOLUME ADJUSTMENT

The audio system controls enable you to adjust the volume and the

audio settings.
To exit from the AUX source, press AM/FM.
When using an MP3 player: increase the volume of the radio

signifi cantly (between 30 and 60) to obtain a satisfactory playing

volume.

In order to listen to it, connect your equipment then

press this button.

An auxiliary socket "AUX" is provided for the

connection of portable equipment (MP3 player, etc.).

AUXILIARY SOCKET

119

RADIO

Automatic search for a

higher frequency: double

press / Successive tuning

in to the stations

Selection of the AM /

FM (FM1, FM2, FM3)

wavebands

Manual search for a higher /

lower frequency

Selection of the stored

station / Storing of a station:

press for more than 2 seconds

AF function on/off:

alternative frequencies

Autostore: automatic storing of

6 stations on AM and FM3

TA function on/off: traffi c

information priority

Selection of the type of radio

programme: News, Sports,

Talk, Pop, Classics

120

RADIO

STATIONS

When the radio receives a station broadcasting in stereo it

automatically plays in stereo and the screen displays "ST". If the

reception conditions deteriorate, the radio changes to mono and

"ST" is no longer displayed.

STEREO RECEPTION

Press this button.

SELECTION OF THE RADIO SOURCE

Press the button successively to select the

wavebands FM1, FM2, FM3 and AM.

SELECTION OF A WAVEBAND

Press this button twice to select the next station.
Press this button briefl y to listen to each station

available on the FM waveband for three seconds.

To stop the station scan, press this button again.

AUTOMATIC STATION SEARCH

If the traffi c information programme TA is selected, only stations

which broadcast this type of programme are selected.

Press one of these two buttons briefl y to increase or

decrease the frequency displayed respectively.
If you maintain the pressure on the button in the

chosen direction, the frequency will be scanned

continuously.
The scan stops when you release the button.

MANUAL STATION SEARCH

121

Select the required station.
Press one of the buttons "1" to "6" for more than 2 seconds.
An audible signal confi rms that the station has been preset.

MANUAL STATION PRESETTING

Press this button.
Your audio equipment automatically presets the

six strongest stations received on AM and FM in

your current location. These stations are stored on

the AM and FM3 wavebands. The end of the search

is signalled by two audible signals.

AUTOMATIC PRESETTING OF FM STATIONS

(AUTOSTORE)

RADIO

If it was not possible to fi nd six stations the remaining memories

remain empty: three dashes are displayed on the audio system

screen for each empty memory.

RECALLING PRESET STATIONS

On each waveband, a brief press on one of the buttons "1" to "6"

recalls the corresponding preset station.

RADIO RECEPTION

Your audio system will be subjected to phenomena which do not

affect domestic radio sets. Both MW/LW and FM reception are

subject to various forms of interference. This is no refl ection on the

quality of the system but is due to the nature of the signals and the

way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high

voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from

the transmitter, defl ection of the signal by obstacles (mountains,

hills, buildings, etc) or of being in an area which is not covered by a

transmitter.

122

This enables you to listen to stations which broadcast a type of

programme which has a theme (NEWS, SPORTS, TALK, POP,

CLASSICS).

SEARCH BY TYPE OF PROGRAMME (PTY)

When FM is selected, press this button:
-

"no pty" is displayed,

then press the button briefl y to select a

programme.

After a few seconds without any action, your

selection is stored.

RADIO

RDS SYSTEM

The RDS (Radio Data System) enables you to continue listening

to the same station irrespective of the frequency that it uses in your

current location. The radio continuously searches for the transmitter

which provides the best reception.

USING THE AF (ALTERNATIVE FREQUENCIES)

FUNCTION ON THE FM WAVEBAND

Some stations, organised in a network, broadcast regional

programmes in the various regions which they serve. The regional

mode enables you to continue listening to the same programme.

REGIONAL MODE (REG)

Press this button successively to activate or

deactivate the function.
The screen will indicate:
-

"AF" if the function is activated,

"AF REG" if the function is activated at regional

level,

"AF" fl ashing if the function is not available.

123

Press this button successively to activate or

deactivate the function.
On FM, the multifunction display will indicate:
-

"TP" or "TP EON": the radio transmits a

programme while awaiting the broadcasting of

traffi c information.

"TA" or "TA EON": the programme transmitted

by the radio is put on standby while awaiting

the broadcasting of traffi c information.

TRAFFIC INFORMATION PROGRAMME (TA)

RADIO

If you wish to interrupt the transmission of a message, press this

button again.

EON SYSTEM

The volume of the traffi c information is independent of the volume of

normal radio listening.
You can adjust it using the volume button, when the TA programme

is being transmitted.
The setting will be stored and will be used during subsequent

message transmissions.

This system links stations which belong to the same network. It

permits the transmission of traffi c information broadcast by a station

which belongs to the same network as the station to which you are

listening.
In order to benefi t from this, select the traffi c information programme TA.

124

AUDIO

Play the start of each

track on the CD: brief

press

CD eject

CD: repeat the current track /

CD changer (depending on

equipment), press for more

than 2 seconds: repeat the

current CD

CD changer (depending on

equipment):

: selection of the previous CD

: selection of the next CD

Random play of the tracks on

the CD currently being played

Selection of the source: auxiliary or

CD and CD changer (depending on

equipment)

Selection of the

previous / next track

: fast forwards play

: fast backwards

play

125

AUDIO

Press this button to select the next track.

CD AND CD CHANGER (depending on equipment)

SELECTION OF A TRACK ON A CD

Press and hold one of these buttons for fast

forwards or backwards play respectively.
The fast play stops when the button is released.

FAST PLAY

Press this button to return to the start of the current

track or to select the previous track.

Press this button to listen to the start of each track

on the current CD.

INTROSCAN (SCAN)

126

When a CD is inserted, printed face uppermost,

play begins automatically.
If there is a CD in the player already, press this

button.

SELECTION OF THE CD SOURCE

The tracks on the CD will be played in a random order. Press the

button again to return to normal play.
The random play mode is deactivated when the audio system is

switched off.

When the CD player is selected, press this button.

RANDOM PLAY OF THE CD (RAND)

Press this button to eject the CD from the player.

CD EJECT

The use of copied CDs may cause faults.
Insert circular CDs only.

If you wish to listen to the current track again, press

this button. To cancel the repetition, press the

button again.

REPEAT OF A TRACK ON THE CD (RPT)

AUDIO

Content .. 6 7 8 9 ..
