(usually in conjunction with increased distance
from the station transmitter), static or flutter can
be heard. This can be reduced by adjusting the
treble control to reduce treble response.

Multipath reception: Because of the reflective
characteristics of FM signals, direct and reflected
signals reach the receiver at the same time. The
signals may cancel each other, resulting in mo-
mentary flutter or loss of sound.

AM RADIO RECEPTION

AM signals, because of their low frequency, can
bend around objects and skip along the ground.
In addition, the signals can be bounced off the
ionosphere and bent back to earth. Because of
these characteristics, AM signals are also sub-
ject to interference as they travel from transmitter
to receiver.

Fading: Occurs while the vehicle is passing
through freeway underpasses or in areas with
many tall buildings. It can also occur for several
seconds during ionospheric turbulence even in
areas where no obstacles exist.

Static: Caused by thunderstorms, electrical
power lines, electric signs and even traffic lights.

SATELLITE RADIO RECEPTION (if so
equipped)

When the satellite radio is used for the first time
or the battery has been replaced, the satellite
radio may not work properly. This is not a mal-
function. Wait more than 10 minutes with satellite
radio ON and the vehicle outside of any metal or
large building for satellite radio to receive all of
the necessary data.

The satellite radio mode will be skipped unless an
optional satellite receiver and antenna are in-
stalled and a SiriusXM® Satellite Radio service
subscription is active. Satellite radio is not avail-
able in Alaska, Hawaii and Guam.

Satellite radio performance may be affected if
cargo carried on the roof blocks the satellite radio
signal.

If possible, do not put cargo over the satellite
antenna.

A build up of ice on the satellite radio antenna can
affect satellite radio performance. Remove the
ice to restore satellite radio reception.

XM® is a registered trademark of SiriusXM®
Satellite Radio, Inc.

AUDIO OPERATION PRECAUTIONS

LHA0099

4-48

Monitor, climate, audio, phone and voice recognition systems

Compact disc (CD) player (models
without Navigation System)

CAUTION

● Do not force a compact disc into the CD

insert slot. This could damage the CD
and/or CD changer/player.

● Trying to load a CD with the CD door

closed could damage the CD and/or CD
changer.

● Only one CD can be loaded into the CD

player at a time.

● Only use high quality 4.7 in (12 cm)

round discs that have the “COMPACT
disc DIGITAL AUDIO” logo on the disc
or packaging.

● During cold weather or rainy days, the

player may malfunction due to the hu-
midity. If this occurs, remove the CD
and dehumidify or ventilate the player
completely.

● The player may skip while driving on

rough roads.

● The CD player sometimes cannot func-

tion when the compartment tempera-
ture

extremely

high

low.

Decrease/increase

the

temperature

before use.

● Do not expose the CD to direct sun-

light.

● CDs that are in poor condition or are

dirty, scratched or covered with finger-
prints may not work properly.

● The following CDs may not work prop-

erly:

● Copy control compact discs (CCCD)
● Recordable compact discs (CD-R)
● Rewritable compact discs (CD-RW)

● Do not use the following CDs as they

may cause the CD player to malfunc-
tion:

● 3.1 in (8 cm) discs with an adapter
● CDs that are not round
● CDs with a paper label
● CDs that are warped, scratched, or

have abnormal edges

● This audio system can only play pre-

recorded CDs. It has no capability to
record or burn CDs.

● If the CD cannot be played, one of the

following messages will be displayed.

CHECK DISC:

● Confirm that the CD is inserted cor-

rectly (the label side is facing up,
etc.).

● Confirm that the CD is not bent or

warped and it is free of scratches.

PRESS EJECT:

This is an error due to excessive tem-
perature inside the player. Remove the
CD by pressing the EJECT button. After
a short time, reinsert the CD. The CD
can be played when the temperature of
the player returns to normal.

UNPLAYABLE:

The file is unplayable in this audio sys-
tem (only MP3 or WMA (if so equipped)
CD).

Monitor, climate, audio, phone and voice recognition systems

4-49

CD/DVD combination player (models
with Navigation System)

● Do not force a disc into the CD/DVD

insert slot. This could damage the
CD/DVD player.

● During cold weather or rainy days, the

player may malfunction due to the hu-
midity. If this occurs, remove the
CD/DVD and dehumidify or ventilate
the player completely.

● The player may skip while driving on

rough roads.

● The CD/DVD player sometimes cannot

function when the passenger compart-
ment temperature is extremely high.
Decrease the temperature before use.

● Only use high quality 4.7 in (12 cm)

round discs that have the “COMPACT
disc DIGITAL AUDIO” or “DVD Video”
logo on the disc or packaging.

● Do not expose the CD/DVD to direct

sunlight.

● CDs/DVDs that are of poor quality,

dirty, scratched, covered with finger-
prints, or that have pinholes may not
work properly.

● The following CDs/DVDs are not guar-

anteed to play:

● Copy control compact discs (CCCD)
● Recordable compact discs (CD-R)
● Rewritable compact discs (CD-RW)
● Recordable compact discs (DVD±R,

DVD±R DL)

● Rewritable

compact

discs

(DVD±RW, DVD±RW DL)

● Do not use the following CDs/DVDs as

they may cause the CD/DVD player to
malfunction.

● 3.1 in (8 cm) discs
● CDs/DVDs that are not round
● CDs/DVDs with a paper label
● CDs/DVDs

that

are

warped,

scratched, or have abnormal edges

● This audio system can only play pre-

recorded CDs/DVDs. It has no capa-
bilities to record or burn CDs/DVDs.

● If the CD/DVD cannot be played, one of

the following messages will be dis-
played.

Disc Read Error:

● Confirm that the CD/DVD is inserted

correctly (the label side is facing up,
etc.).

● Confirm that the CD/DVD is not bent

or warped and it is free of scratches.

Please Eject Disc:

This error may be due to the tempera-
ture inside the player getting too high.
Remove the CD/DVD by pushing the
EJECT button, and after a short time
reinsert the CD/DVD. The CD/DVD can
be played when the temperature of the
player returns to normal. If the error
persists, consult your local retailer.

Unplayable File:

● The file may be copy protected.
● The file is not MP3, WMA, AAC, M4A

or DIVX type.

Region Invalid

● The DVD is not for region 1 or all

regions.

4-50

Monitor, climate, audio, phone and voice recognition systems

● Use DVDs with a region code “1”,

“ALL” or “1 included” for your DVD
entertainment system. (The region
code

䊊

is displayed as a small sym-

bol printed on the top of the DVD

䊊

This

vehicle-installed

DVD

player cannot play DVDs with a re-
gion code other than “1” or “ALL”.

Copyright and trademark

● The technology protected by the U.S.

patent and other intellectual property
rights

owned

Macrovision

Corporation and other right holders is
adopted for this system.

● This copyright protected technology

cannot be used without a permit from
Macrovision Corporation. It is limited
to personal use, etc., as long as the
permit from Macrovision Corporation
is not issued.

● Modifying or disassembling is prohib-

ited.

● Dolby digital is manufactured under li-

cense from Dolby Laboratories, Inc.

● Dolby and the double D mark “

”

are trademarks of Dolby Laboratories,
Inc.

● DTS and DTS Digital Surround “

”

are registered trademarks of Digital
Theater Systems, Inc.

USB (Universal Serial Bus)
Connection Port

WARNING

Do not connect, disconnect, or operate the
USB device while driving. Doing so can be
a distraction. If distracted you could lose
control of your vehicle and cause an acci-
dent or serious injury.

LHA0484

Monitor, climate, audio, phone and voice recognition systems

4-51

CAUTION

● Do not force the USB device into the

USB port. Inserting the USB device
tilted or up-side-down into the port may
damage the port. Make sure that the
USB device is connected correctly into
the USB port.

● Do not grab the USB port cover (if so

equipped) when pulling the USB device
out of the port. This could damage the
port and the cover.

● Do not leave the USB cable in a place

where it can be pulled unintentionally.
Pulling the cable may damage the port.

The vehicle is not equipped with a USB device.
USB devices should be purchased separately as
necessary.

This system cannot be used to format USB de-
vices. To format a USB device, use a personal
computer.

In some states/area, the USB device for the front
seats plays only sound without images for regu-
latory reasons, even when the vehicle is parked.

This system supports various USB memory de-
vices, USB hard drives and iPod® players. Some
USB devices may not be supported by this sys-
tem.

● Partitioned USB devices may not play cor-

rectly.

● Some characters used in other languages

(Chinese, Japanese, etc.) may not appear
properly in the display. Using English lan-
guage characters with a USB device is rec-
ommended.

General notes for USB use

● Refer to your device manufacturer’s owner

information regarding the proper use and
care of the device.

Notes for iPod® use

iPod® is a trademark of Apple Inc., registered in
the U.S. and other countries.

● Improperly plugging in the iPod® may cause

a check mark to be displayed on and off
(flickering). Always make sure that the
iPod® is connected properly.

● An iPod® nano (1st Generation) may remain

in fast forward or rewind mode if it is con-
nected during a seek operation. In this case,
please manually reset the iPod®.

● An iPod® nano (2nd Generation) will con-

tinue to fast-forward or rewind if it is discon-
nected during a seek operation.

● An incorrect song title may appear when the

Play Mode is changed while using an iPod®
nano (2nd Generation).

● Audiobooks may not play in the same order

as they appear on an iPod®.

● Large video files cause slow responses in an

iPod®. The vehicle center display may mo-
mentarily black out, but will soon recover.

● If an iPod® automatically selects large video

files while in the shuffle mode, the vehicle
center display may momentarily black out,
but will soon recover.

Bluetooth® streaming audio (if so
equipped)

● Some Bluetooth® audio devices may not be

recognized by the in-vehicle audio system.

● It is necessary to set up the wireless con-

nection between a compatible Bluetooth®
audio device and the in-vehicle Bluetooth®
module before using the Bluetooth® audio.

● Operating procedure of the Bluetooth® au-

dio will vary depending on the devices. Make
sure how to operate your audio device be-
fore using it with this system.

4-52

Monitor, climate, audio, phone and voice recognition systems

● The Bluetooth® audio may be stopped un-

der the following conditions:

● Receiving a call on the Hands-Free

Phone System.

● Checking the connection to the hands-

free phone.

● Do not place the Bluetooth® audio device in

an area surrounded by metal or far away from
the in-vehicle Bluetooth® module to prevent
tone quality degradation and wireless con-
nection disruption.

● While an audio device is connected through

the Bluetooth® wireless connection, the
battery power of the device may discharge
quicker than usual.

● This system supports the Bluetooth® Audio

Distribution Profile (A2DP, AVRCP).

BLUETOOTH® is a
trademark owned by
Bluetooth SIG, Inc.
and licensed to
Clarion Co., Ltd.

CD or USB with Compressed Audio
Files (models without Navigation
System)

The file types supported by this system are MP3
and WMA.

Explanation of terms

● MP3 — MP3 is short for Moving Pictures

Experts Group Audio Layer 3. MP3 is the
most well-known compressed digital audio
file format. This format allows for near “CD
quality” sound, but at a fraction of the size of
normal audio files. MP3 conversion of an
audio track from CD-ROM can reduce the
file size by approximately a 10:1 ratio with
virtually no perceptible loss in quality. MP3
compression removes the redundant and
irrelevant parts of a sound signal that the
human ear doesn’t hear.

● WMA — Windows Media Audio (WMA)* is a

compressed audio format created by Micro-
soft as an alternative to MP3. The WMA
codec offers greater file compression than
the MP3 codec, enabling storage of more
digital audio tracks in the same amount of
space when compared to MP3s at the same
level of quality.

● Bit rate — Bit rate denotes the number of

bits per second used by a digital music file.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

● Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

● Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is called
a multisession.

● ID3/WMA Tag — The ID3/WMA tag is the

part of the encoded MP3 or WMA file that
contains information about the digital music
file such as song title, artist, encoding bit
rate, track time duration, etc. ID3 tag infor-
mation is displayed on the Artist/song title
line on the display.

* Windows®, Windows Media® and Windows
Vista® are registered trademarks and trade-
marks in the United States of America and other
countries of Microsoft Corporation of the USA.

Monitor, climate, audio, phone and voice recognition systems

4-53

Playback order

Music playback order of a CD with MP3 or WMA
files is as illustrated.

● The names of folders not containing MP3 or

WMA files are not shown in the display.

● If there is a file in the top level of the disc,

“Root Folder” is displayed.

● The playback order is the order in which the

files were written by the writing software.
Therefore, the files might not play in the
desired order.

Playback order chart

WHA1078

4-54

Monitor, climate, audio, phone and voice recognition systems

Specification chart

Supported media

CD, CD-R, CD-RW, USB 2.0

Supported file systems

CD, CD-R, CD-RW, ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet
* ISO9660 Level 3 (packet writing) is not supported.
* Files saved using the Live File System component (on a Windows Vista® operating system-based
computer) are not supported.

UDF Bridge (UDF 1.02 + ISO9660), UDF 1.5, UDF 2.0
VDF 1.5/VDF 2.0 (packet writing) is not supported.

USB memory: FAT16, FAT32

Supported
versions

MP3

Version

MPEG1, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR*2

WMA*1

Version

WMA7, WMA8

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR*2

Tag information (Song title and artist name)

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3, VER 2.4 (MP3 only)

WMA tag (WMA only)

Folder levels

Folder levels: 8, Folders: 255 (including root folder), Files: 512 (Max. 255 files for one folder)

Text character number limitation

64 characters

Displayable character codes*3

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 LE), 04: UNICODE (UTF-16 BE), 05: UNI-
CODE (UTF-8)

*1 Protected WMA files (DRM) cannot be played.

*2 When VBR files are played, the playback time may not be displayed correctly.

*3 Available codes depend on what kind of media, versions and information are going to be displayed.

Monitor, climate, audio, phone and voice recognition systems

4-55

Troubleshooting guide

Symptom

Cause and Countermeasure

Cannot play

Check if the CD/USB device is inserted correctly.

Check if the CD is scratched or dirty.

Check if there is condensation inside the player. If there is, wait until the condensation is gone (about 1 hour) before using the player.

If there is a temperature increase error, the player will play correctly after it returns to the normal temperature.

If there is a mixture of music CD files (CD-DA data) and compressed audio files on a CD, only the music CD files (CD-DA data) will be played.

Files with extensions other than “.MP3” or “.WMA” cannot be played. In addition, the character codes and number of characters for folder names and
file names should be in compliance with the specifications.

Check if the disc or file is generated in an irregular format. This may occur depending on the variation or the setting of the compressed audio file writ-
ing application or other text editing applications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the CD/USB device is protected by copyright.

Poor sound quality

Check if the CD is scratched or dirty.

It takes a relatively long time
before the music starts
playing.

If there are many folders or file levels on the CD/USB device, or if it is a multisession disc, some time may be required before the music starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not match the
specifications. Try using the slowest writing speed.

Skipping with high bit rate
files

Skipping may occur with large quantities of data, such as for high bit rate data.

Moves immediately to the
next song when playing

If an unsupported compressed audio file has been given a supported extension like “.MP3”, or when play is prohibited by copyright protection, the
player will skip to the next song.

Songs do not play back in
the desired order

The playback order is the order in which the files were written by the writing software. Therefore, the files might not play in the desired order.

Random/Shuffle may be active on the audio system or on the USB device.

4-56

Monitor, climate, audio, phone and voice recognition systems

CD, DVD or USB with Compressed
Audio Files (models with Navigation
System)

The file types supported by this system are MP3,
WMA, AAC/M4A and ATRAC3.

Explanation of terms

● MP3 — MP3 is short for Moving Pictures

Experts Group Audio Layer 3. MP3 is the
most well known compressed digital audio
file format. This format allows for near “CD
quality” sound, but at a fraction of the size of
normal audio files. MP3 conversion of an
audio track can reduce the file size by ap-
proximately 10:1 ratio (Sampling: 44.1 kHz,
Bit rate: 128 kbps) with virtually no percep-
tible loss in quality. The compression re-
duces certain parts of sound that seem in-
audible to most people.

● WMA — Windows Media Audio (WMA) is a

● AAC/M4A — Advanced Audio Coding

(AAC) is a lossy audio compression format.
Audio files that have been encoded with
AAC are generally smaller in size and deliver
a higher quality of sound than MP3.

● ATRAC3, ATRAC3 Plus — Adaptive Trans-

form Acoustic Coding (ATRAC) is a lossy
audio compression format developed by
Sony.

● Bit rate — Bit rate denotes the number of

bits per second used by a digital music file.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

● Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

● Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is called
a multisession.

● ID3/WMA Tag — The ID3/WMA tag is the

part of the encoded MP3 or WMA file that
contains information about the digital music
file such as song title, artist, album title,
encoding bit rate, track time duration, etc.
ID3 tag information is displayed on the
Album/Artist/Track title line on the display.

* Windows®, Windows Media® and Windows
Vista® are registered trademarks or trademarks
of Microsoft Corporation in the United States of
America and/or other countries.

Monitor, climate, audio, phone and voice recognition systems

4-57

Playback order

Music playback order of a CD, DVD or USB
device with compressed audio files is as illus-
trated.

● The folder names of folders not containing

compressed audio files are not shown in the
display.

● If there is a file in the top level of the

disc/USB, “Root Folder” is displayed.

● The playback order is the order in which the

files were written by the writing software, so
the files might not play in the desired order.

Playback order chart

WHA1374

4-58

Monitor, climate, audio, phone and voice recognition systems

Specification chart

Supported media

CD, CD-R, CD-RW, DVD-ROM, DVD±R, DVD±RW, DVD±R DL, USB 2.0

Supported file systems

CD, CD-R, CD-RW, DVD-ROM, DVD±R, DVD±RW, DVD±R DL, ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet
* ISO9660 Level 3 (packet writing) is not supported.
* Files saved using the Live File System component (on a Windows Vista® operating system-based computer) are not supported.

UDF Bridge (UDF 1.02 + ISO9660), UDF 1.5, UDF 2.0
* VDF 1.5/VDF 2.0 (packet writing) is not supported.

USB memory: FAT16, FAT32

Supported
versions*1

MP3

Version

MPEG1, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR*4

WMA*2

Version

WMA7, WMA8, WMA9

Sampling frequency

32 kHz - 48 kHz

Bit rate

32 kbps - 192 kbps, VBR*4

AAC

Sampling frequency

8 kHz - 96 kHz

Bit rate

16 kbps - 320 kbps, VBR*4

ATRAC

Version

ATRAC3, ATRAC3 Plus

Tag information (Song title and artist name)

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3, VER 2.4 (MP3 only)

WMA tag (WMA only)

Folder levels

Folder levels: 8, Folders: 255 (including root folder), Files: 512 (Max. 255 files for one folder)

Text character number limitation

128 characters

Displayable character codes*3

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 BOM Big Endian), 04: UNICODE (UTF-16 Non-BOM Big Endian), 05: UNI-
CODE (UTF-8), 06: UNICODE (Non-UTF 16 BOM Little Endian), 07: SHIFT-JIS

*1 Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.

*2 Protected WMA files (DRM) cannot be played.

*3 Available codes depend on what kind of media, versions and information are going to be displayed.

*4 When VBR files are played, the playback time may not be displayed correctly.

Monitor, climate, audio, phone and voice recognition systems

4-59

Troubleshooting guide

Symptom

Cause and Countermeasure

Cannot play

Check if the CD/DVD/USB device was inserted correctly.

Check if the CD/DVD is scratched or dirty.

Check if there is condensation inside the player. If there is, wait until the condensation is gone (about 1 hour) before using the player.

If there is a temperature increase error, the player will play correctly after it returns to the normal temperature.

If there is a mixture of music CD files (CD-DA data) and compressed audio files on a CD, only the music CD files (CD-DA data) will be played.

Files with extensions other than “.MP3”, “.WMA”, “.AAC”, “.M4A” or “.AA3” cannot be played. In addition, the character codes and number of charac-
ters for folder names and file names should be in compliance with the specifications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the CD/DVD/USB device is protected by copyright.

Poor sound quality

Check if the CD/DVD is scratched or dirty.

It takes a relatively long time
before the music starts
playing.

If there are many folders or file levels on the CD/DVD/USB device, or if it is a multisession disc, some time may be required before the music starts
playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not match the
specifications. Try using the slowest writing speed.

Skipping with high bit rate
files

Skipping may occur with large quantities of data, such as for high bit rate data.

Moves immediately to the
next song when playing

If an unsupported compressed audio file has been given a supported extension like “.MP3”, or when play is prohibited by copyright protection, the
player will skip to the next song.

Songs do not play back in
the desired order

The playback order is the order in which the files were written by the writing software. Therefore, the files might not play in the desired order.

Random/Shuffle may be active on the audio system or on the USB device.

4-60

Monitor, climate, audio, phone and voice recognition systems

Compressed Video Files (models with
Navigation System)

Explanation of terms

● DivX – DivX refers to the DivX® codec

owned by Div, Inc. used for a lossy compres-
sion of video based on MPEG-4.

● AVI – AVI stands for Audio Video Interleave.

It is standard file format originated by Micro-
soft Corporation. A .divx encoded file can be
saved into the .avi file format for playback on
this system if it meets the requirements
stated in the table in this section. However,
all .avi files are not playable on this system
since different encodings can be used other
than the DivX® codec.

● ASF – ASF stands for Advanced Systems

Format. It is a file format owned by Microsoft
Corporation. Note: Only .asf files that meet
the requirements stated in the table in this
section can be played.

● Bit rate — Bit rate denotes the number of

bits per second used by a digital video files.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

Monitor, climate, audio, phone and voice recognition systems

4-61

Requirements for Supporting Video Playback

Media

CD, CD-R, CD-RW, DVD, DVD±R, DVD±RW, DVD±RW DL, USB 2.0 Memory

File Systems

CD, CD-R, CD-RW, DVD,
DVD±R, DVD±RW, DVD±RW
DL

ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet, UDF Bridge (UDF1.02+ISO9660), UDF1.5, UDF2.0
* ISO9660 Level 3 (packet writing) is not supported.
* Files saved using the Live File System component (on a Windows Vista-based computer) are not supported.
* VDF1.5/VDF2.0 (packet writing) is not supported.

USB Memory

FAT16, FAT32

File Types

.divx, .avi

Video Codecs

DivX3, DivX4, DivX5, DivX6

Audio Codecs

MP3, MPEG2.5 Audio Layer3, AC3, LPCM

.asf

Video Codec

ISO-MPEG4

Audio Codec

G.726

Bit Rates

.divx, .avi

Maximum Average

4 Mbps

Maximum Peak

8 Mbps

Resolution

.divx, .avi

Minimum

32 x 32

Maximum

720 x 480

.asf

Minimum

32 x 32

Maximum

720 x 576

4-62

Monitor, climate, audio, phone and voice recognition systems

FM/AM/SAT RADIO WITH
COMPACT DISC (CD) PLAYER (if so
equipped)

CD eject button

2. ON-OFF control knob/VOL (volume) control

knob

3. Station select (1–6) buttons

4. AUDIO button/TUNE/FOLDER control knob

5. AUX button*

TRACK button

SEEK/CAT button

8. DISC button

9. RPT (repeat)/RDM (random) button

10. SCAN button

11. AM-FM button

*No satellite radio reception is available when the
AUX button is pressed to access satellite radio
stations unless optional satellite receiver and an-
tenna are installed and a SiriusXM® Satellite
Radio service subscription is active. Satellite ra-
dio is not available in Alaska, Hawaii and Guam.

For all operation precautions, refer to

⬙Audio op-

eration precautions

⬙ in this section.

Audio main operation

VOL/ON·OFF control

Place the ignition switch in the ACC or ON
position and push the VOL/ON·OFF control knob
while the system is off to call up the mode that
was playing immediately before the system was
turned off.

To turn the system off, press the VOL/ON·OFF
control knob.

LHA3181

Monitor, climate, audio, phone and voice recognition systems

4-63

Content .. 15 16 17 18 ..
