HARNESS

PG-63

< WIRING DIAGRAM >

C2 B7 —

: Body ground

Chassis harness

B8 W/4

: Front door switch LH

C10 B/2

: Rear wheel sensor LH

G3 B9 Y/22

: Air bag diagnosis sensor unit

C11 GR/2

: Rear wheel sensor RH

G3 B10 Y/2

: Front LH side air bag module

C12 GR/2

: 4WD solenoid

B11 W/4

: Joint connector-B09

C13 B/14

: To B13

B12 W/4

: Joint connector-B10

Front seat LH harness

D4 B13 B/14

: To C13

B200 BR/12

: To B54

B14 Y/2

: Front LH seat belt pre-tensioner

B201 W/16

: To B57

B15 Y/2

: Front side air bag satellite sensor LH

B202 W/24

: Headrest display unit (Driver seat)
(Pre-wire)

B16 W/4

: Joint connector-B11

B203 B/16

: Climate controlled seat control unit
(Driver seat)

B17 W/4

: Joint connector-B12

B204 B/8

: Climate controlled seat control unit
(Driver seat)

D2 B18 W/4

: Rear door switch LH

B205 B/6

: Climate controlled seat control unit
(Driver seat)

B19 —

: Body ground

B206 W/4

: Seat cushion thermal electric device
(Driver seat)

B20 W/4

: Fuel lid door lock actuator

B207 W/6

: Lifting motor LH (Rear)

D2 B22 O/2

: Front LH seat belt pre-tensioner

B208 W/10

: Power seat switch LH

G2 B23 W/24

: To B222

B209 W/32

: Driver seat control unit

B24 W/32

: Video distributor

B210 W/12

: Driver seat control unit

B25 W/24

: Video distributor

B211 GR/5

: Sliding motor LH

C2 B27 —

: Body ground

B212 W/4

: Seat back thermal electric device
(Driver seat)

B28 —

: Body ground

B213 W/5

: Climate controlled seat blower motor
(Driver seat)

G1 B29 W/6

: Fuse block (J/B)

B214 BR/4

: Lumbar support switch

G1 B30 W/8

: Fuse block (J/B)

B215 B/2

: Lumbar support motor

B31 B/2

: EVAP canister vent control valve

B216 W/3

: Front seat heater (Driver seat)

G4 B32 W/32

: To B124

B217 W/6

: Reclining motor LH

B33 B/2

: To B404

B218 W/6

: Lifting motor LH (Front)

B34 W/8

: To B405

B220 W/12

: To B74

C2 B35 W/4

: Sonar buzzer

B221 W/4

: Seat belt buckle switch (Driver seat)

C4 B36 GR/3

: EVAP control system pressure sensor

B222 W/24

: To B23

C1 B38 Y/2

: LH side curtain air bag module

B223 W/24

: Headrest display unit (Driver seat)

G1 B40 W/24

: To E34

Body no. 3 harness

G3 B41 W/32

: To M69

B400 W/32

: To B77

G2 B42 BR/12

: To M74

B401 B/12

: To B452

G1 B43 W/12

: To E33

B402 BR/2

: Back door warning chime

B44 B/2

: To B425

B403 GR/2

: Outside key antenna (Rear bumper)

B45 W/16

: To B426

B404 B/2

: To B33

B46 W/24

: To D501

B405 W/8

: To B34

B47 GR/8

: To D502

B406 GR/3

: Rear combination lamp LH

G1 B48 GR/1

: To E35

B407 GR/3

: Rear combination lamp RH

B49 W/16

: To B140

B408 GR/2

: Rear combination lamp LH

B51 W/12

: To D201

B409 GR/2

: Rear combination lamp RH

B52 W/2

: Condenser-2

B410 GR/6

: To B450

PG-64

< WIRING DIAGRAM >

HARNESS

B54 BR/12

: To B200

B411 B/2

: To B451

C3 B55 B/24

: Automatic back door control module

B412 W/2

: Rear combination lamp LH

B56 GR/14 : Automatic back door control module

B413 W/2

: Rear combination lamp RH

G2 B57 W/16

: To B201

B425 B/2

: To B44

B61 W/4

: Joint connector-B18

Trailer relay sub harness

B62 W/4

: Joint connector-B19

B426 W/16

: To B45

B63 W/33

: Joint connector-B01

B427 L/4

: Trailer tow relay 1

B67 W/16

: 4WD control unit

B428 BR/6

: Trailer tow relay 2

G1 B69 SMJ

: To M40

B431 L/4

: Trailer back-up relay

B70 B/10

: Spindle unit LH

Body no. 3 sub harness

C3 B71 Y/2

: Rear side air bag satellite sensor LH

B450 GR/6

: To B410

B72 GR/6

: Fuel level sensor and fuel pump

B451 B/2

: To B411

B73 GR/6

: Subwoofer

B452 B/12

: To B401

G3 B74 W/12

: To B220

B453 B/7

: Trailer

D3 B75 W/16

: To B145

B454 B/7

: Trailer receptacle

C4 B76 GR/2

: Inside key antenna (Luggage room)

B455 B/3

: Rear sonar sensor LH outer

B77 W/32

: To B400

B456 B/3

: Rear sonar sensor RH outer

B79 W/6

: 2nd row seat heater LH

B457 B/3

: Rear sonar sensor LH inner

G2 B80 W/4

: Joint connector-B15

B458 B/3

: Rear sonar sensor RH inner

HARNESS

PG-65

< WIRING DIAGRAM >

BODY NO. 2 HARNESS

ABMIA4917ZZ

D1 B101 W/32

: To M84

B157 W/12

: To B300

B105 W/6

: 2nd row seat heater RH

B158 —

: Body ground

D1 B106 GR/1

: To M8

B161 W/16

: To M157

C1 B107 W/24

: To M9

B162 B/10

: Spindle unit RH

B108 W/4

: Front door switch RH

B169 W/4

: Joint connector-B04

PG-66

< WIRING DIAGRAM >

HARNESS

C1 B111 BR/16

: To M10

B170 Y/2

: Rear side air bag satellite sensor RH

B113 Y/22

: Air bag diagnosis sensor unit

Front seat RH harness

B114 Y/2

: Front side air bag satellite sensor RH

B300 W/12

: To B157

B116 W/4

: Rear door switch RH

B301 W/24

: To B138

B117 —

: Body ground

B302 W/24

: Headrest display unit (Passenger seat)
(Pre-wire)

B119 O/2

: Front RH seat belt pre-tensioner

B303 W/4

: Seat belt buckle switch (Passenger seat)

D2 B123 W/4

: To B350

B304 B/6

: Climate controlled seat control unit
(Passenger seat)

B124 W/32

: To B32

B305 B/8

: Climate controlled seat control unit
(Passenger seat)

C2 B126 Y/2

: Front RH side air bag module

B306 B/16

: Climate controlled seat control unit
(Passenger seat)

B127 Y/2

: Front RH seat belt pre-tensioner

B307 W/5

: Climate controlled seat blower motor
(Passenger seat)

B128 Y/2

: RH side curtain air bag module

B308 W/4

: Seat cushion thermal electric device
(Passenger seat)

D4 B129 BR/14

: BOSE speaker amp.

B309 W/4

: Seat back thermal electric device
(Passenger seat)

D4 B130 BR/23

: BOSE speaker amp.

B311 W/6

: Reclining motor RH

B132 —

: Body ground

B313 W/10

: Power seat switch RH

B133 W/4

: Rear blower motor resistor 2

B314 W/5

: Sliding motor RH

G4 B134 W/2

: Rear blower motor 2

B315 W/3

: Front seat heater (Passenger seat)

C1 B136 W/40

: To M36

B316 W/24

: To B137

C3 B137 W/24

: To B316

B317 W/24

: Headrest display unit (Passenger seat)

C2 B138 W/24

: To B301

ODS sub harness

B139 W/12

: To D301

B350 W/4

: To B123

B140 W/16

: To B49

B351 P/3

: Occupant classification system sensor FL

D4 B145 W/16

: To B75

B352 P/3

: Occupant classification system sensor FR

B152 —

: Body ground

B356 B/20

: Occupant classification system control
unit

B153 BR/2

: Rear side speaker RH
