BCS

BCM

BCS-45

< ECU DIAGNOSIS INFORMATION >

[BCM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

105

(LG)

Ground Right front flasher

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

0V

Turn signal switch RH

6.5 V

107
(W)

Ground

Low side start switch
LED

Input

Push-button igni-
tion switch

OFF

0V

NOTE:
When the illumination
brightening/dimming level
is in the neutral position
ON

108

(GR)

Ground

Shift lock solenoid
output

Input

Selector lever

P position

0V

Any position other than P

Battery voltage

109

(R)

Ground Reverse signal

Output

Push-button igni-
tion switch ON

R position

Battery voltage

Any position other than R

0V

111

(P)

Ground ACC LED

Output

Push-button igni-
tion switch

OFF

Battery voltage

ACC or ON

0V

113

(L)

Ground ACC relay output

Output

Push-button igni-
tion switch

OFF

0V

ACC or ON

Battery voltage

114
(W)

Ground

Outside key antenna
(passenger side) A

Output

When the front
door RH request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKID0926E

JSNIA0010GB

JMKIA0062GB

JMKIA0063GB

BCS-46

< ECU DIAGNOSIS INFORMATION >

[BCM]

BCM

115

(BG)

Ground

Outside key antenna
(passenger side) B

Output

When the front
door RH request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

116
(W)

Ground

Inside key antenna
(console) A

Output

Push-button igni-
tion switch OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

117

(SB)

Ground Left front flasher

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

0V

Turn signal switch LH

6.5 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

PKID0926E

BCS

BCM

BCS-47

< ECU DIAGNOSIS INFORMATION >

[BCM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

119

(R)

Ground

Remote keyless entry
receiver signal

Input/

Output

Push-button igni-
tion switch ON

Standby state

When receiving the signal
from the transmitter

121

(G)

Ground

Outside key antenna
(driver side) B

Output

When the front
door LH request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

122

(P)

Ground

Outside key antenna
(driver side) A

Output

When the front
door LH request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

OCC3881D

OCC3880D

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCS-48

< ECU DIAGNOSIS INFORMATION >

[BCM]

BCM

123
(W)

Ground

Inside key antenna
(instrument center) A

Output

Push-button igni-
tion switch OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

124

(G)

Ground

Inside key antenna
(instrument center) B

Output

Push-button igni-
tion switch OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

126

(P)

Ground

NATS antenna amp.
B

Input/

Output

During waiting

Intelligent Key backside is
contacted to push-button
ignition switch, turn ignition
switch ON.

Just after pressing push-button

ignition switch. Pointer of analog

volt meter should move.

127

(BG)

Ground

NATS antenna amp.
A

Input/

Output

During waiting

Intelligent Key backside is
contacted to push-button
ignition switch, turn ignition
switch ON.

Just after pressing push-button

ignition switch. Pointer of analog

volt meter should move.

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB
