Nissan Pathfinder. Manual - part 213





BCS

BCM

BCS-41

< ECU DIAGNOSIS INFORMATION >

[BCM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

79

(W)

Ground

Combination switch
output 1

Output

Combination
switch
(Wiper intermit-
tent dial 4)

OFF

7.0 – 8.0V

FR WASHER

1.2V

FR WIPER LOW

TURN LH

TURN RH

80

(R)

Ground

Back door open
switch

Output Back door

Open (back door actuator
is activated)

Battery voltage

Close (back door actuator
is not activated)

0V

81

(L)

Ground

Rear wiper battery
fuse

Input

Push-button ignition switch OFF

Battery voltage

82

(W)

Ground Left rear door switch

Input

Rear door LH
switch

OFF (when rear door LH
closes)

11.8V

ON (when rear door LH
opens)

0V

83

(BG)

Ground

Back door request
switch

Input

Back door re-
quest switch

ON (pressed)

0V

OFF (not pressed)

Battery voltage

84

(BR)

Ground

Rear wiper autostop
switch

Input

Push-button igni-
tion switch ON

Rear wiper stop position

Battery voltage

Any position other than
rear wiper stop position

0V

86

(R)

Ground

Left rear trailer flash-
er

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

Battery voltage

Turn signal switch LH

6.0 - 7.0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKIB4960J

PKIB4958J

JPMIA0011GB

PKIC6370E

BCS-42

< ECU DIAGNOSIS INFORMATION >

[BCM]

BCM

87

(P)

Ground

Right rear trailer
flasher

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

Battery voltage

Turn signal switch RH

6.0 - 7.0 V

91

(BR)

Ground

Back door open out
signal

Output

Back door opener
switch

OFF

0V

ON

Battery voltage

92

(R)

Ground Right rear flasher

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

0V

Turn signal switch RH

6.5 V

93

(R)

Ground

Right rear door
switch

Input

Rear door RH
switch

OFF (when rear door RH
closes)

11.8V

ON (when rear door RH
opens)

0V

94

(G)

Ground

Passenger door
switch

Input

Front door RH
switch

OFF (when front door RH
closes)

11.8 V

ON (when front door RH
opens)

0V

95

(V)

Ground Rear wiper output

Output Rear wiper

OFF (stopped)

0V

ON (activated)

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKIC6370E

PKID0926E

JPMIA0011GB

JPMIA0011GB

BCS

BCM

BCS-43

< ECU DIAGNOSIS INFORMATION >

[BCM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

96

(BG)

Ground Driver door switch

Input

Front door LH
switch

OFF (front door LH
CLOSE)

11.8V

ON (front door LH OPEN)

0V

97

(W)

Ground Back door switch

Input

Back door switch

OFF (back door is closed)

11.8V

ON (back door is open)

0V

99

(P)

Ground

Inside key antenna
(luggage room) B

Output

Push-button igni-
tion switch OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

100
(W)

Ground

Inside key antenna
(luggage room) A

Output

Push-button igni-
tion switch OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0011GB

JPMIA0011GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCS-44

< ECU DIAGNOSIS INFORMATION >

[BCM]

BCM

101

(R)

Ground

Outside key antenna
(rear bumper) B

Output

When the back
door request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

102

(G)

Ground

Outside key antenna
(rear bumper) A

Output

When the back
door request
switch is operat-
ed with push-but-
ton ignition switch
OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

103

(BG)

Ground Left rear flasher

Output

Push-button igni-
tion switch ON

Turn signal switch OFF

0V

Turn signal switch LH

6.5 V

104

(LG)

Ground Reverse lamp output

Output

Push-button igni-
tion switch ON

R position

6.5V

Any position other than R

0V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

PKID0926E

PKID0926E
