Mitsubishi Outlander PHEV (2019 year). Instruction

Item

Display

Buzzer

Note (Solution)

Keyless operation key
take-out monitoring sys-
tem

Inner buzzer sounds
once.
Outer buzzer sounds in-
termittently.

When the vehicle is parked with the operation mode in any
mode other than OFF, if you close the door after opening
any of the doors and taking the keyless operation key out of
the vehicle, a warning is issued until the key is detected in
the vehicle.

If you take the keyless operation key out of the vehicle
through a window without opening a door, the keyless oper-
ation key take-out monitoring system does not operate.

It is possible to change the setting to make the keyless oper-
ation  key  take-out  monitoring  system  operate  if  you  take
the  keyless  operation  key  out  from  the  vehicle  through  a
window without opening a door.
For  further  information,  please  contact  a  MITSUBISHI
MOTORS Authorized Service Point.

Even if you have the keyless operation key within the oper-
ating  range  for  starting  the  Plug-in  Hybrid  EV  System,  if
the  keyless  operation  key  and  vehicle  ID  codes  cannot  be
matched,  for  example  due  to  the  ambient  environment  or
electromagnetic conditions, the warning may be activated.

Key lock-in prevention
system

Inner buzzer sounds
once.
Outer buzzer sounds ap-
proximately 3 seconds
intermittently

When  the  operation  mode  is  in  OFF,  if  you  close  all  the
doors and the tailgate with the keyless operation key left in
the  vehicle  and  you  try  to  lock  the  doors  and  tailgate  by
pressing the driver’s or front passenger’s door lock/unlock
switch,  or  the  tailgate  LOCK  switch,  a  warning  is  issued
and you cannot lock the doors and tailgate.

Make sure you have the keyless operation key with you be-
fore locking the doors. Even if you leave the keyless opera-
tion key inside the vehicle, it is possible that the doors will
lock depending on the surrounding environment and wire-
less signal conditions.

Keyless operation system

4-13

OGGE19E1

Locking and unlocking

Item

Display

Buzzer

Note (Solution)

Door ajar prevention
system

Inner buzzer sounds
once.
Outer buzzer sounds ap-
proximately 3 seconds
intermittently

When the operation mode in OFF, if you try to lock the doors
and tailgate by pressing the driver’s or front passenger’s door
lock/unlock switch, or the tailgate LOCK switch with one of the
doors or the tailgate not completely closed, a warning is issued
and you cannot lock the doors and tailgate.

Operation mode OFF re-
minder system

Inner buzzer sounds
once.
Outer buzzer sounds ap-
proximately 3 seconds
intermittently

When the operation mode is in any mode other than OFF, if you
try to lock the doors and tailgate by pressing the driver’s or front
passenger’s door lock/unlock switch, or the tailgate LOCK
switch, a warning is issued and you cannot lock the doors and
tailgate.

To operate without using the

keyless operation function

E00306000019

Emergency key

E00307201725

The  emergency  key  is  built  into  the  keyless
operation  key.  If  the  keyless  operation  func-
tion cannot be used, for example because the
keyless operation key battery has worn out or
the  vehicle  battery  is  flat,  you  can  lock  and
unlock the driver’s door with the emergency
key.
To  use  the  emergency  key  (A),  unlock  the
lock knob (B) and remove it from the keyless
operation key (C).

Refer to “Doors” on page 4-14.

NOTE

Only  use  the  emergency  key  for  emergen-
cies.  If  the  keyless  operation  key  battery
wears  out,  replace  it  as  quickly  as  possible
so  that  you  can  use  the  keyless  operation
key.

After using the emergency key, always re-
turn it into the keyless operation key.

Doors

E00300403719

CAUTION

Make sure the doors are closed: driving with
doors not completely closed is dangerous.

Never leave children in the vehicle unatten-
ded.

Doors

4-14

OGGE19E1

Locking and unlocking

CAUTION

Be careful not to lock the doors while the
key is inside the vehicle.

NOTE

To prevent the key from being locked inside
the vehicle, neither the lock knob on the
driver’s door nor the key can be used to lock
the driver’s door when it is open.

To lock or unlock with the key

1- Lock
2- Unlock

NOTE

When locking or unlocking with the key, on-
ly  the  driver’s  door  will  be  locked  or  un-
locked.
To lock or unlock all doors, the charging lid
and  the  tailgate,  use  the  central  door  lock
switch, the keyless entry system or the key-
less operation function.
Refer to “Central door locks” on page 4-16,
“Keyless  entry  system”  on  page  4-03,  and
“To  operate  using  the  keyless  operation
function” on page 4-09.

The charging lid can be locked or unlocked
at the same time when the driver’s door is
locked or unlocked using the key.
However, the charging lid cannot be un-
locked while the operation mode of the pow-
er switch is in ON.

To lock or unlock from inside

the vehicle

1- Lock

2- Unlock

Pull the inside door handle towards you to
open the door.

NOTE

The driver’s door can be opened without us-
ing the lock knob by pulling on the inside
door handle.

The charging lid can be locked or unlocked
at the same time when the driver’s door is
locked or unlocked using the lock knob.
However, the charging lid cannot be un-
locked while the operation mode of the pow-
er switch is in ON.

To lock without using the key

Front passenger’s door, Rear

door

Doors

4-15

OGGE19E1

Locking and unlocking

Set the inside lock knob (1) to the locked po-
sition, and close the door (2).

Central door locks

E00300803335

NOTE

Repeated continuous operation between lock
and  unlock  could  activate  the  central  door
locking  systems  built-in  protection  circuit
and  prevent  the  system  from  operating.  If
this occurs, wait approximately 1 minute be-
fore operating the central door lock switch.

When the driver’s door is open, the central
door lock switch cannot be used to lock it.

The charging lid is also locked/unlocked,
when the driver’s door is locked/unlocked
using the central door locks.

To lock and unlock the doors

and tailgate

Using the central door lock

switch

Using the central door lock switch on the
driver’s door locks or unlocks all doors and
the tailgate.

LHD

RHD

1- Lock
2- Unlock

NOTE

The charging lid can be locked or unlocked
at  the  same  time  when  the  driver’s  door  is
locked  or  unlocked  using  the  central  door
lock switch.
However,  the  charging  lid  cannot  be  un-
locked while the operation mode of the pow-
er switch is in ON.

To unlock the doors and tail-

gate

E00311301336

You can select the function to unlock the
doors and tailgate using the engine switch.
This function is not activated when the vehi-
cle is shipped from the factory. To activate or
deactivate this function, please contact a
MITSUBISHI MOTORS Authorized Service
Point.

Using the power switch

All doors and the tailgate will unlock when-
ever the operation mode is put in OFF.

Central door locks

4-16

OGGE19E1

Locking and unlocking

Dead Lock System*

E00305100198

The  Dead  Lock  System  helps  prevent  theft.
When the keyless entry system or the keyless
operation system has been used to lock all of
the  doors  and  the  tailgate,  the  Dead  Lock
System  makes  it  impossible  to  unlock  the
doors using the inside lock knobs.

CAUTION

Do  not  set  the  Dead  Lock  System  when
someone is inside the vehicle. With the Dead
Lock System set, it is not possible to unlock
the doors using the inside lock knobs. If you
erroneously  set  the  Dead  Lock  System,  un-
lock  the  doors  using  the  UNLOCK  switch
on  the  remote  control  switch  or  using  the
keyless operation function.

Setting the system

E00305201330

1. Put the operation mode in OFF.
2. Get out of the vehicle. Close all of the

doors and the tailgate.

3. Press the LOCK switch (A) on the re-

mote control switch, the driver’s or front
passenger’s door lock/unlock switch (C),
or the tailgate LOCK switch (D) to lock
all of the doors and the tailgate. The
turn-signal lamps will blink once.

4. Press the switch again within 2 seconds.

The turn-signal lamps will blink three
times to show that the Dead Lock Sys-
tem has been set.

Driver’s and front passenger’s door lock/unlock

switches*

Tailgate switches*

NOTE

Pressing  the  LOCK  switch  (A)  on  the  re-
mote  control  switch  once  while  the  Dead
Lock  System  is  set  causes  the  turn-signal
lamps to blink three times, so it is possible to
confirm that the Dead Lock System is set.

Cancelling the system

E00305301432

When  the  following  operation  is  performed,
the  doors  and  tailgate  will  unlock  and  the
Dead  Lock  System  will  be  simultaneously
cancelled.

The UNLOCK switch (B) on the remote
control switch is pressed.

The drive’s or front passenger’s door
lock/unlock switch (C) or the tailgate
open switch (E) is pressed while you are
carrying the keyless operation key.

Dead Lock System*

4-17

OGGE19E1

Locking and unlocking

NOTE

If  neither  a  door  nor  the  tailgate  is  opened
within  30  seconds  of  unlocking  (except  us-
ing  the  tailgate  open  switch),  the  doors  and
tailgate  are  automatically  relocked  and  the
Dead  Lock  System  is  simultaneously  set
again.

Even when it is not possible to use the key-
less entry system or keyless operation func-
tion to unlock the doors, it is possible to use
the  key  to  unlock  the  driver’s  door.  When
the  key  is  used  to  unlock  the  driver’s  door,
the Dead Lock System is cancelled for only
the driver’s door. If you wish to subsequent-
ly  unlock  all  other  doors,  turn  the  ignition
switch  to  the  “ON”  or  “ACC”  position,  or
put the operation mode in on or ACC.

It  is  possible  to  adjust  the  time  between
pressing the UNLOCK switch (B) on the re-
mote  control  switch  or  the  driver’s  or  front
passenger’s door lock/unlock switch (C) and
automatic  locking.  For  details,  please  con-
tact  a  MITSUBISHI  MOTORS  Authorized
Service Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

NOTE

It  is  possible  to  lock  the  doors  and  tailgate
and  set  the  Dead  Lock  System  at  the  same
time with a single push of the LOCK switch
(A)  on  the  remote  control  switch,  the  driv-
er’s  or  front  passenger’s  door  lock/unlock
switch  (C),  or  the  tailgate  lock  switch  (D).
For  details,  please  contact  a  MITSUBISHI
MOTORS Authorized Service Point.

Testing the system

E00305400159

Open  all  of  the  door  windows,  then  set  the
Dead Lock System.
(Refer to “Setting the system” on page 4-17.)
After  setting  the  Dead  Lock  System,  reach
into  the  vehicle  through  a  window  and  con-
firm  that  you  cannot  unlock  the  doors  using
the lock knobs.

NOTE

If you need advice on how to set the Dead
Lock System, please contact a MITSUBISHI
MOTORS Authorized Service Point.

“Child-protection” rear
doors

E00300901042

1- Lock
2- Unlock

Child protection helps prevent the rear doors
from  being  opened  accidentally  from  the  in-
side.
If  the  lever  is  set  to  the  locked  position,  the
rear  door  cannot  be  opened  using  the  inside
handle, but only with the outside handle.
If  the  lever  is  set  to  the  “Unlock”  position,
the  child  protection  mechanism  does  not
function.

“Child-protection” rear doors

4-18

OGGE19E1

Locking and unlocking

CAUTION

When driving with a child in the rear seat,
please use the child protection to prevent ac-
cidental door opening which may cause an
accident.

Tailgate*

E00301402751

WARNING

It is dangerous to drive with the tailgate
open, since carbon monoxide (CO) gas
can enter the cabin.
You cannot see or smell CO. It can cause
unconsciousness and even death.

When opening and closing the tailgate,
make sure that there are no people nearby
and be careful not to hit your head or
pinch your hands, neck, etc.

When there is a build up of snow or ice, it
should  be  removed  before  opening  the
tailgate.  If  you  open  the  tailgate  without
removing it, there is a possibility that the
tailgate  may  close  suddenly  due  to  the
weight of that snow or ice.

WARNING

When  you  open  the  tailgate  make  sure
that  the  tailgate  is  opened  fully  and  re-
mains fully open. If you only open the tail-
gate  halfway  there  is  a  risk  that  the  tail-
gate may drop and slam shut. If you open
the  tailgate  whilst  your  vehicle  is  parked
on  an  incline  it  is  more  difficult  to  do  so
than on the flat and also it may drop and
slam shut.

CAUTION

To avoid damage to the tailgate, make sure
the area above and behind the tailgate is
clear before opening it.

To lock/unlock

The tailgate can be locked or unlocked by us-
ing the central door lock switch (driver side).

LHD

RHD

1- Lock

2- Unlock

NOTE

Repeated continuous operating between lock
and  unlock  could  cause  the  central  door
locks’  built-in  protection  circuit  to  prevent
the  system  from  operating.  If  this  occurs,
wait  approximately  1  minute  before  operat-
ing the central door lock switch.

To open

After unlocking the tailgate, push the tailgate
open switch (A) and pull up the tailgate.

Tailgate*

4-19

OGGE19E1

Locking and unlocking

NOTE

The tailgate cannot be opened when the aux-
iliary battery is flat or disconnected.
If you want to open the tailgate, it can be
opened by using the inside tailgate release.
Refer to “Inside tailgate release” on page
4-27.

To close

Pull the tailgate grip (B) downward as illus-
trated. Gently shut the tailgate from the out-
side so that it is completely closed. Always
ensure the tailgate is securely closed.

CAUTION

When closing the tailgate, always ensure
your or other person’s fingers cannot be
caught by the tailgate.

NOTE

Gas struts (C) are installed to support the
tailgate.
To prevent damage or faulty operation.

•

Do not hold the gas struts when closing
the tailgate.

•

Also, do not push or pull the gas struts.

•

Do not attach any plastic material, tape,
etc., to the gas struts.

•

Do not tie string, etc., around the gas
struts.

•

Do not hang any object on the gas struts.

Electric tailgate*

E00312801035

Before operating the electric tailgate, unlock
the tailgate by using the keyless entry system,
keyless operation system, or the central door
locks.

Refer to “Keyless entry system” on page
4-03, “Keyless operation system” on page
4-06, or “Central door locks” on page 4-16.

Operating the electric tailgate

E00312901124

WARNING

The  luggage  area  was  not  designed  for
people  to  ride  in  it.  Do  not  let  your  chil-
dren  ride  in  or  play  in  the  luggage  area.
Riding  or  playing  in  the  luggage  area
could result in a serious accident.

Before driving, make sure the electric tail-
gate is securely closed.
If you drive with the tailgate open, there is
a danger of exhaust gas entering the vehi-
cle and causing carbon monoxide poison-
ing.

For safety’s sake, the electric tailgate
should be operated by adults and not chil-
dren.

When  opening  and  closing  the  tailgate,
make sure that there are no people nearby
and  be  careful  not  to  hit  your  head  or
pinch your hands, neck, etc.
Make  sure  the  electric  tailgate  is  com-
pletely open before loading and unloading
luggage.

Electric tailgate*

4-20

OGGE19E1

Locking and unlocking

CAUTION

Do not stand behind the exhaust pipe when
loading and unloading luggage.
The heat from the exhaust could cause
burns.

To avoid damage to the tailgate, make sure
the area above and behind the tailgate is
clear before opening it.

Before driving, make sure the electric tail-
gate is closed properly. If the tailgate opens
when driving, luggage could fall onto the
road and cause an accident.

Do  not  install  accessories  other  than
MITSUBISHI  MOTORS  GENUINE  parts
on  the  electric  tailgate.  Some  accessories
could be too heavy, causing the drop preven-
tion mechanism to operate.

When closing the electric tailgate, make sure
there is no foreign matter around the striker
(A).
If foreign matter gets into the striker it could
prevent the electric tailgate from closing
normally.

NOTE

When opening and closing the electric tail-
gate, do not place your hands near the arm
(B).

Gas struts (C) are installed in the locations
shown below in order to support the electric
tailgate.

Make sure not to bump your head in the area
near the arm of the electric tailgate when
loading and unloading luggage.

NOTE

Please observe the following in order to pre-
vent damage or faulty operation.

•

Do not pull on the gas struts when closing
the electric tailgate or otherwise push or
pull them.

•

Do not attach any plastic material, tape,
etc., to the gas struts.

NOTE

•

Do not tie string, etc., around the gas
struts.

•

Do not hang anything from the gas struts.

Automatic operation

E00313001177

The electric tailgate can be operated using the
remote control switch on the keyless opera-
tion key, or the close switch on the tailgate
when the electric tailgate power switch (A) is
on.

Electric tailgate*

4-21

OGGE19E1

Locking and unlocking

WARNING

Turn off the electric tailgate power switch
when not operating the electric tailgate.
If the switch is left on, someone’s hand or
head could get caught if the electric tail-
gate switch or close switch is accidentally
operated, or children play with the con-
trols.

If  the  electric  tailgate  power  switch  is
turned  off  while  the  tailgate  is  operating,
it  will  stop  moving  and  switch  to  manual
operation.
At  this  time,  the  electric  tailgate  could
open  or  close  suddenly,  depending  on  its
position.

CAUTION

Do not apply excessive force on the electric
tailgate when opening or closing it. Doing so
could cause a breakdown.

Do  not  start  the  Plug-in  Hybrid  EV  System
while  the  tailgate  is  operating.  The  sudden
operation prevention mechanism could oper-
ate,  making  the  electric  tailgate  stop  inter-
mittently while it moves.

NOTE

The electric tailgate cannot be opened when
the auxiliary battery is flat or disconnected.
If you want to open the electric tailgate, it
can be opened by using the inside tailgate re-
lease.
Refer to “Inside tailgate release” on page
4-27.

If the keyless entry system or close switch is
operated when the electric tailgate power
switch is off, the warning buzzer sounds four
times to notify the driver that the electric
tailgate cannot be operated.

The electric tailgate does not operate nor-
mally under the following conditions:

•

When parked on an incline

•

In strong winds

•

When the electric tailgate is covered with
snow

Repeated continuous operation between
opening and closing the electric tailgate will
activate the built-in protection circuit and
switch the tailgate to manual operation.

If the electric tailgate handle is operated
while the tailgate is operating or immediate-
ly after it is closed, the tailgate will move in
the direction opposite to the one in which it
was operating.

If  the  battery  or  fuse  is  replaced  while  the
electric  tailgate  is  open,  it  cannot  be  closed
automatically.
In  this  case  close  the  electric  tailgate  man-
ually.

Operating conditions

E00313101224

The electric tailgate can be opened automati-
cally when all of the following conditions are
met.
<Using the keyless operation key>

The operation mode is in OFF.

The electric tailgate is completely
closed.

The electric tailgate is unlocked.

The operation mode is in ON with the
electrical parking switch is pressed.

The electric tailgate is completely
closed.

The electric tailgate is unlocked.

The electric tailgate can be closed automati-
cally when all of the following conditions are
met.
<Using the keyless operation key>

The operation mode is in OFF.

The electric tailgate is completely open.

People, luggage, etc., are not touching
the sensors.

The operation mode is in ON with the
electrical parking switch is pressed.

Electric tailgate*

4-22

OGGE19E1

Locking and unlocking

The electric tailgate is completely open.

People, luggage, etc., are not touching
the sensors.

Operating the electric tailgate

using the keyless operation key

or the driver’s side electric tail-

gate switch

After  unlocking  the  doors  and  the  electric
tailgate,  the  electric  tailgate  can  be  operated
by pressing the switch (A) of the keyless op-
eration  key  or  the  driver’s  side  electric  tail-
gate switch (B).

<Using the keyless operation key>
If the electric tailgate switch is pressed twice
in a row, the electric tailgate operates after
the warning buzzer sounds and the hazard
warning flasher blinks.
The electric tailgate operates as follows:

•While
closed:

The warning buzzer sounds
and the tailgate completely
opens.

•While
open:

The warning buzzer sounds
and the tailgate completely
closes.

If the electric tailgate switch is pressed once
while the tailgate is operating, the warning
buzzer sounds and it moves in the direction
opposite to the one in which it was operating.

NOTE

If the electric tailgate switch is pressed three
or more times in a row, the tailgate may not
operate normally.
If this occurs, wait a short time before again
pressing the electric tailgate switch twice.

<Using  the  driver’s  side  electric  tailgate
switch>
If  the  driver’s  side  electric  tailgate  switch  is
pressed  for  more  than  approximately  1  sec-
ond,  the  electric  tailgate  operates  after  the
buzzer sounds and the hazard warning flasher
blinks.
The electric tailgate operates as follows.

•While
closed:

The warning buzzer sounds
and the tailgate completely
opens.

•While
open:

The warning buzzer sounds
and the tailgate completely
closes.

If  the  driver’s  side  electric  tailgate  switch  is
pressed  once  while  the  tailgate  is  operating,
the  warning  buzzer  sounds  and  it  moves  in
the  direction  opposite  to  the  one  in  which  it
was operating.

WARNING

When  operating  the  electric  tailgate,  en-
sure  the  safety  of  the  surrounding  area,
make sure there is sufficient space behind
and above the vehicle, and be careful not
to  bump  your  head  or  catch  your  hands
or fingers.

Electric tailgate*

4-23

OGGE19E1

Locking and unlocking

Opening the electric tailgate us-

ing the open switch

The electric tailgate can be opened by press-
ing the open switch (C).

If the open switch is pressed with the tailgate
and all doors are unlocked, the electric tail-
gate opens after the warning buzzer sounds.
When the tailgate and all doors are locked,
the warning buzzer will not sound.

NOTE

When the keyless operation key is within the
operation range, the electric tailgate can be
opened by pressing the open switch even if
the tailgate is locked.

Closing the electric tailgate us-

ing the close switch

The electric tailgate can be closed by press-
ing the close switch (D) on the inside of the
electric tailgate.

If the close switch on the inside of the elec-
tric tailgate is pressed, the electric tailgate
closes after the warning buzzer sounds and
the hazard warning flasher blinks.
If the close switch is pressed once while the
tailgate is closing, the warning buzzer sounds
and the electric tailgate opens.

NOTE

If the close switch is again pressed once
while the electric tailgate is operating in the
opening direction, the warning buzzer
sounds once and the electric tailgate closes.

Safety mechanism

E00313201036

The safety mechanism is activated if the elec-
tric tailgate should trap a person or an object
during  automatic  operation,  or  if  the  sensors
(A)  on  either  side  of  the  electric  tailgate  are
hit. The warning buzzer sounds once for safe-
ty  and  the  electric  tailgate  automatically
moves in the direction opposite to the one in
which it was operating.

CAUTION

The  safety  mechanism  will  sometimes  not
operate  depending  on  the  condition  of  the
trapped  object  or  how  it  is  trapped.  There-
fore, be especially careful not to trap a hand,
part of your body or an object at this time.

Electric tailgate*

4-24

OGGE19E1

Locking and unlocking

CAUTION

The safety mechanism is cancelled just be-
fore the electric tailgate is fully closed to al-
low it to close completely. Therefore be es-
pecially careful not to trap a hand or finger
at this time.

The safety mechanism is deactivated when
the electric tailgate is closed manually.
Therefore be especially careful not to trap a
hand or finger at this time.

If the safety mechanism is repeatedly operat-
ed, the tailgate could be switched to manual
operation. Be careful at this time, as the
electric tailgate could open or close sudden-
ly, depending on its position.
Once the electric tailgate is completely open
or closed, normal automatic operation is
again possible.

NOTE

If the environment or usage conditions sub-
ject the sensors to the same kind of force as
that of trapping a person or object, the safety
mechanism could be activated.

Do not damage the sensors when loading or
unloading luggage, or when cleaning the
rear window. Doing so could prevent the
tailgate from closing automatically.

Drop prevention mechanism

After the electric tailgate is opened automati-
cally, if it is detected that the tailgate is drop-
ping due to factors such as accumulated
snow, the electric tailgate is closed automati-
cally.
A warning buzzer sounds continuously while
the drop prevention mechanism operates.

NOTE

If snow has accumulated on the electric tail-
gate, remove it before operation.

Do  not  install  accessories  other  than
MITSUBISHI  MOTORS  GENUINE  parts
on  the  electric  tailgate.  Some  accessories
could be too heavy, causing the drop preven-
tion mechanism to operate.

The  drop  prevention  mechanism  could  be
activated  if  manual  operation  is  attempted
immediately  after  the  electric  tailgate  is
completely opened automatically.

Sudden operation prevention

mechanism

If  the  Plug-in  Hybrid  EV  System  is  started
while  the  electric  tailgate  is  operating  auto-
matically, it may switch to manual operation
due  to  insufficient  auxiliary  battery  voltage,
making the electric tailgate stop intermittent-
ly while it moves. This is to stop the electric
tailgate  from  operating  suddenly.  When  the
tailgate is completely closed or opened, auto-
matic  operation  is  again  possible  after  ap-
proximately 10 seconds.

CAUTION

The safety mechanism is deactivated while
the sudden operation prevention mechanism
is operating. Therefore be especially careful
not to trap a hand or finger at this time.

Manual operation

E00313401083

If the electric tailgate power switch is off, the
electric tailgate can be operated by manual
operation.

Electric tailgate*

4-25

OGGE19E1

Locking and unlocking

After unlocking the electric tailgate, push the
tailgate open switch (A) and pull up the tail-
gate.

CAUTION

Make sure there is no one around the electric
tailgate when opening it.

NOTE

If it does not open immediately after pushing
the tailgate open switch, the electric tailgate
cannot be lifted.
If this occurs, push the tailgate open switch
again and pull up the electric tailgate.

The electric tailgate cannot be opened when
the auxiliary battery is flat or disconnected.

To close the tailgate, pull the tailgate grip (B)
downward and release it before the tailgate is
completely closed, and then gently slam the
electric tailgate from the outside.

CAUTION

Do not fully close the electric tailgate with
your hand still on the tailgate grip. Doing so
could trap and injure your hand or arm.

The safety mechanism is deactivated when
the electric tailgate is closed manually.
Therefore be especially careful not to trap a
hand or finger at this time.

Tailgate easy closer

E00313300069

The tailgate easy closer is a mechanism for
assisting the closing of the electric tailgate.
If the electric tailgate is closed to a position
where it is detected as being ajar, it closes au-
tomatically.

WARNING

Be careful not to catch your hands or fin-
gers when the electric tailgate closes auto-
matically from the door ajar position. If
you think your hands or fingers could be
caught during the operation of the tailgate
easy closer, pull the handle of the electric
tailgate. The electric tailgate will return to
the door ajar position.

CAUTION

Do not touch the latch (A) on the inside of
the electric tailgate. The tailgate easy closer
could operate and catch your fingers.

NOTE

The tailgate easy closer operates even when
the electric tailgate power switch is OFF.

Electric tailgate*

4-26

OGGE19E1

Locking and unlocking

NOTE

Repeated continuous operation of the handle
could activate the protection circuit and tem-
porarily prevent the tailgate easy closer from
operating.
If this occurs, wait about 1 minute before
operating the tailgate easy closer again.

Inside tailgate release

E00303401370

The inside tailgate release is designed to pro-
vide a way to open the tailgate in the case of
a discharged auxiliary battery.
The tailgate release (see illustration) is moun-
ted on the tailgate.

You and your family should familiarise your-
selves with the location and operation of the
tailgate release.

To open

1. Open the lid (A) inside of the tailgate.

2. Move the lever (B) to open the tailgate.

Vehicles without
electric tailgate

Vehicles with
electrictailgate

3. Push out on the tailgate to open it.

CAUTION

Always keep the release lever lid on the tail-
gate closed when driving so that your lug-
gage cannot accidentally bump against the
lever and open the tailgate.

Security alarm system*

E00301502172

The security alarm system is for alerting the
surrounding  area  of  suspicious  behaviour  to
prevent unlawful entry into the vehicle by op-
erating an alarm if a door, the tailgate or the
bonnet  is  opened  when  the  vehicle  has  not
been unlocked using the keyless entry system
or the keyless operation function.
Also,  for  vehicles  equipped  with  the  interior
alarm  sensor,  the  alarm  will  be  activated  if
any of the following occurs:

attempt to an unlawful moving of the ve-
hicle (the vehicle inclination detection
function)

detection of a motion in the vehicle (the
interior intrusion detection function)

disconnection of the battery terminal

The security alarm system is set to “active”.
When making changes to the settings, please
follow the procedure listed in the section ti-
tled “Changing the security alarm settings”
on page 4-30.

Inside tailgate release

4-27

OGGE19E1

Locking and unlocking

On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen operations can be used to make the ad-
justment. Refer to the separate owner’s man-
ual for details.

CAUTION

Do not modify or add parts to the security
alarm system.
Doing so could cause the security alarm to
malfunction.

NOTE

The alarm system will not be activated if the
doors and the tailgate have been locked us-
ing a key, the inside lock knob or the central
door lock switch (instead of the keyless en-
try system or the keyless operation func-
tion).

NOTE

For vehicles equipped with the interior alarm
sensor, if the turn-signal lamps do not blink
after the locking and unlocking operation us-
ing the keyless entry system or the keyless
operation function, the security alarm system
may be malfunctioning.
Have

the

vehicle

inspected

MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
If the confirmation function (blinking of the
turn-signal  lamps  by  locking  and  unlocking
the doors and the tailgate) is deactivated, the
turn-signal lamps do not blink after the lock-
ing and unlocking operation.
For  information  on  the  confirmation  func-
tion, refer to “Keyless entry system” on page
4-03 and “To operate using the keyless oper-
ation function” on page 4-09.

For vehicles equipped with the interior alarm
sensor, the security alarm system could be
activated in the following situations.

•

Using a car wash

•

Taking the vehicle on a ferry

•

Parking in an automated car park

•

Leaving someone or a pet in the vehicle

•

Leaving a window or the sunroof open

•

Leaving an unstable object such as a stuf-
fed toy or accessory in the vehicle

•

Suffering a continuous impact or vibra-
tion by hail, thunder, etc.

NOTE

•

Air flows by the Remote Climate Control.
According to the situations, please deacti-
vate  the  vehicle  inclination  detection
function  and  the  interior  intrusion  detec-
tion function.
Refer  to  “To  deactivate  the  vehicle  incli-
nation  detection  function  and  the  interior
intrusion  detection  function”  on  page
4-32.

For vehicles equipped with the interior alarm
sensor, the sensitivity of the interior intru-
sion detection function can be adjusted. For
details, please contact a MITSUBISHI
MOTORS Authorized Service Point.

Security alarm system*

4-28

OGGE19E1

Locking and unlocking

Mitsubishi Outlander PHEV (2019 year). Instruction - part 6
