Mitsubishi Outlander PHEV (2019 year). Instruction

The security alarm has four

modes:

System preparation mode (ap-

proximately 20 seconds)

(The buzzer sounds intermittently and the se-
curity indicator (A) blinks.)

The  system  preparation  time  extends  from
the  point  at  which  all  of  the  doors  and  the
tailgate  are  locked  by  pressing  the  LOCK
switch  on  the  remote  control  switch  or  the
keyless  operation  function  to  the  point  at
which  the  system  armed  mode  goes  into  ef-
fect.

During this time, it is possible to temporarily
open a door or the tailgate without using the
keyless entry system or the keyless operation
function and without causing the alarm to
sound (for example, when you forget some-
thing inside the vehicle or realize that a win-
dow is open).

System armed mode

(The  buzzer  stops  and  the  security  indicator
continues  to  blink  with  the  indicator’s  re-
duced lit-up duration time.)
Once the system preparation mode has ended,
the system armed mode starts.
If  an  unlawful  opening  of  any  of  the  doors,
tailgate or bonnet is detected during the sys-
tem armed mode, the alarm will be activated
to  warn  people  around  the  vehicle  of  an  ab-
normal condition.
Also,  for  vehicles  equipped  with  the  interior
alarm sensor, if unlawful moving of the vehi-
cle  is  attempted  or  a  vehicle  intrusion  is  de-
tected, the alarm will be activated.

Alarm activation

Inside alarm (approximately 10 seconds):
The buzzer sounds, warning those inside the
vehicle of an abnormal condition.
(except for vehicles equipped with the interi-
or alarm sensor)
Outside alarm (approximately 30 seconds):

The turn-signal lamps blink and the horn (the
siren for vehicles equipped with the interior
alarm sensor) sounds, warning people around
the vehicle of an abnormal condition.
Refer to “Alarm activation” on page 4-33.

NOTE

The alarm will resume if unlawful actions
are taken again, even if the alarm has stop-
ped.

System cancellation

It  is  possible  to  cancel  the  system  activation
during  the  system  preparation  mode  or  the
system armed mode.
In addition, it is possible to cancel the alarm
once it has been activated.
Refer  to  “Cancelling  the  system”  on  page
4-32, “Cancelling the alarm” on page 4-34.

NOTE

When lending the vehicle to another person
or  allowing  the  vehicle  to  be  driven  by
someone who is unfamiliar with the security
alarm  system,  be  sure  to  give  the  person  a
proper explanation of the security alarm sys-
tem.
If a person who is unfamiliar with the securi-
ty  alarm  system  accidentally  unlocked  the
vehicle,  causing  the  alarm  to  sound,  the
alarm would be a nuisance to people nearby.

Security alarm system*

4-29

OGGE19E1

Locking and unlocking

Changing the security alarm

settings

E00301601365

It is possible to set the security alarm to the
“active” mode or “inactive” mode.
Follow the procedure below.

1. Put the operation mode in OFF.
2. Place the lamp switch in the “OFF” posi-

tion, and leave the driver’s door open.

3. Pull the windscreen wiper and washer

switch towards you and hold it there.
(Since the operation mode in OFF, wash-
er fluid will not be sprayed.)

4. After approximately 10 seconds, the

buzzer  will  make  a  sound.  Keep  the
windscreen  wiper  and  washer  switch
pulled  towards  you.  (If  the  windscreen
wiper  and  washer  switch  was  released,
the  setting  change  mode  would  be  can-
celled. To start over, perform the proce-
dure again from step 3.)

5. When the buzzer stops, with the wind-

screen wiper and washer switch still
pulled towards you, press the UNLOCK
switch (A) on the remote control switch
to select the security alarm settings
mode.

The settings mode can be toggled by
pressing the UNLOCK switch. The
mode can be confirmed from the number
of times the buzzer sounds.

Number of

times the

buzzer
sounds

Security alarm settings

mode

Alarm inactive

Alarm active

6. Any of the following operations can be

used to terminate the system settings
change mode.

• Releasing the windscreen wiper and

washer switch.

• Closing the driver’s door.
• Put the operation mode in ON or

ACC.

Security alarm system*

4-30

OGGE19E1

Locking and unlocking

• Placing the lamp switch in any posi-

tion other than “OFF”.

• Allowing 30 seconds to pass without

making any changes to the settings.

NOTE

If anything with regard to making changes to
the security alarm system settings is hard to
understand,

please

consult

your

MITSUBISHI MOTORS Authorized Serv-
ice Point.

Avoid leaving valuable items inside the ve-
hicle even when the security alarm system
has been set to the “active” mode.

Setting the system

E00301702190

Follow the procedure below to set the system
to the system armed mode.

1. Put the operation mode in OFF.
2. Exit the vehicle and close all of the

doors, tailgate and bonnet.

3. Press the LOCK switch (A) on the re-

mote control switch of the keyless oper-
ation  key,  the  driver’s  or  front  passeng-
er’s  door  lock/unlock  switch  (B),  or  the
tailgate  LOCK  switch  (C)  in  order  to
lock all the doors and the tailgate.

Driver’s and front passenger’s door look/unlock switches*

Tailgate LOCK switch*

By locking the vehicle using the keyless
entry system or the keyless operation
function, the system preparation mode is
activated.
The buzzer makes an intermittent beep-
ing sound and the security indicator (D)
in the centre panel flashes for confirma-
tion.

NOTE

The  system  preparation  mode  is  not  activa-
ted  when  the  doors  and  the  tailgate  have
been  locked  using  a  method  other  than  the
keyless entry system or the keyless operation
function (namely a key, the inside lock knob
or the central door lock switch).

Security alarm system*

4-31

OGGE19E1

Locking and unlocking

NOTE

If  the  bonnet  is  open,  the  security  indicator
illuminates,  and  the  system  does  not  enter
the system preparation mode.
When the bonnet is closed, the system enters
the  system  preparation  mode,  and  after  ap-
proximately  20  seconds  the  system  enters
the system armed mode.

4. After approximately 20 seconds, the

buzzer stops, and when the blinking of
the security indicator starts to slow
down, the system armed mode goes into
effect.
The security indicator continues to blink
during the system armed mode.

NOTE

The security alarm system can be activated
when people are riding inside the vehicle or
when the windows are open. To prevent ac-
cidental activation of the alarm, do not set
the system to the system armed mode while
people are riding in the vehicle.

Avoid leaving valuable items inside the ve-
hicle even when the security alarm system
has been set to the “active” mode.

To deactivate the vehicle incli-
nation detection function and
the interior intrusion detection
function*

E00312101533

The  vehicle  inclination  detection  function
and  the  interior  intrusion  detection  function
can  be  deactivated  when  parking  in  automa-
ted car parks, when leaving pets in the vehi-
cle or when leaving the vehicle with the win-
dows slightly open.

1. Put the operation mode in OFF.
2. Raise and hold the wiper and washer

switch to the “MIST” position for ap-
proximately 3 seconds. The buzzer will
sound twice and the function will be de-
activated.

To activate the function again, raise and hold
the wiper and washer switch to the “MIST”
position for approximately 3 seconds.

The buzzer will sound once and the function
will be activated.

NOTE

The function will be activated again if the
following operation is performed.

•

If the doors and the tailgate are unlocked
using the keyless entry system or the key-
less operation function.

•

If the operation mode is put in ON or
ACC.

Cancelling the system

E00301802234

The following methods can be used to cancel
the system when it is in the system prepara-
tion mode or the system armed mode.

Pressing the UNLOCK switch on the re-
mote control switch.

Putting the operation mode in ON.

Security alarm system*

4-32

OGGE19E1

Locking and unlocking

Opening any one of the doors or the tail-
gate, when the system is in the system
preparation mode.

Holding the keyless operation key and
pressing the driver’s or front passenger’s
door lock/unlock switch, or the tailgate
open switch to unlock the doors and the
tailgate.

NOTE

If the bonnet is opened during the system
preparation mode, the system preparation
mode is suspended.
The system returns to the system preparation
mode when the bonnet is closed.

If the auxiliary battery terminals are discon-
nected while the system is in the system
preparation mode, the memory will be
erased.

It  is  possible  to  register  up  to  four  remote
control  switches  for  keyless  operation  sys-
tem.
As long as they are registered, any of the re-
mote  control  switches,  other  than  the  one
used  to  activate  the  system,  can  be  used  to
cancel the system.
If  you  want  to  register  additional  remote
control

switches,

please

contact

MITSUBISHI MOTORS Authorized Serv-
ice Point.

NOTE

The activation distance for keyless entry sys-
tem is approximately 4 m.
If it is not possible to lock or unlock the ve-
hicle by pressing the switch at the correct
distance or the security alarm system cannot
be set or cancelled using the switch, the bat-
tery may need to be replaced.
Replace the battery at a MITSUBISHI
MOTORS Authorized Service Point.

If  the  UNLOCK  switch  on  the  remote  con-
trol switch, or the driver’s or front passeng-
er’s  door  lock/unlock  switch  is  pressed  and
no  door  or  the  tailgate  is  opened  within  30
seconds, the doors and the tailgate will auto-
matically  relock.  In  this  case  as  well,  the
system preparation mode will go into effect.

The  time  between  pressing  the  UNLOCK
switch  on  the  remote  control  switch,  or  the
driver’s  or  front  passenger’s  door  lock/
unlock switch and automatic locking can be
adjusted.  Please  consult  a  MITSUBISHI
MOTORS Authorized Service Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

Alarm activation

E00301902408

When  the  system  is  in  the  system  armed
mode, the alarm will be activated as follows
if  the  vehicle  is  unlocked  or  if  any  of  the
doors,  tailgate  or  bonnet  is  opened  using  a
method other than the keyless entry system or
the keyless operation function.

1. The inside alarm will be activated for

approximately 10 seconds. (except for
vehicles equipped with the interior alarm
sensor)

NOTE

If the bonnet is opened during the system
armed mode, the vehicle outside alarm oper-
ates immediately, without the vehicle inside
alarm operating.

The time for the vehicle inside alarm can be
adjusted. Please consult a MITSUBISHI
MOTORS Authorized Service Point.

2. The alarm will be activated for approxi-

mately 30 seconds.
The turn-signal lamps will blink, and the
horn (the siren for vehicles equipped

Security alarm system*

4-33

OGGE19E1

Locking and unlocking

with the interior alarm sensor) will
sound intermittently.

3. The alarm will resume if unlawful ac-

tions are taken again, even if the alarm
has stopped.

Cancelling the alarm

E00302001890

It is possible to halt the activation of an alarm
using the following methods:

Pressing the LOCK or UNLOCK switch
on the remote control switch.
(After pressing the LOCK switch, the
vehicle will lock if all the doors and the
tailgate are closed, after which the sys-
tem preparation mode will once again go
into effect.)

Putting the operation mode in ON.

Holding the keyless operation key and
locking or unlocking the doors and the
tailgate using the keyless operation func-
tion.

NOTE

Even if a door or the tailgate is closed while
the inside alarm is activating, this will not
cancel the alarm activation. (except for vehi-
cles equipped with the interior alarm sensor)

When the operation mode is put in ON, the
buzzer sounds four times. This operation in-
dicates that the alarm was activated while
the vehicle was parked.
Please check the inside of the vehicle to con-
firm that nothing was stolen.

Even if the auxiliary battery is disconnected,
the alarm activation memory will not be
erased.

Electric window control

E00302201632

The electric windows can only be operated
with the operation mode in ON.

Electric window control switch

E00302303507

Each door window opens or closes while the
corresponding switch is operated.

Driver’s switch RHD

Driver’s switch LHD

1- Driver’s door window
2- Front passenger’s door window
3- Rear left door window
4- Rear right door window
5- Lock switch

WARNING

Before operating the electric window con-
trol, make sure that nothing can get trap-
ped (head, hand, finger, etc.).

Never leave the vehicle without removing
the key.

Never leave a child (or other person who
might not be capable of safe operation of
the electric window control) in the vehicle
alone.

Electric window control

4-34

OGGE19E1

Locking and unlocking

Driver’s switches

The driver’s switches can be used to operate
all door windows. A window can be opened
or  closed  by  operating  the  corresponding
switch.
Press  the  switch  down  to  open  the  window,
and pull up the switch to close it.
If the switch for the driver’s window is fully
pressed down/pulled up, the door window au-
tomatically opens/closes completely.
If  you  want  to  stop  the  window  movement,
operate the switch lightly in the reverse direc-
tion.

NOTE

When the door window does not close auto-
matically even if the switch is fully pulled
up, pull up the door window switch until the
window has been fully closed.
You should now be able to operate the door
window in the normal fashion.

Passenger’s switches

The passenger’s switches can be used to op-
erate the corresponding passenger’s door
windows.

Press the switch down for opening the win-
dow, and pull up the switch for closing it.

NOTE

Repeated operation with the Plug-in Hybrid
EV System stopped will run down the auxil-
iary battery. Operate the window switches
only while the Plug-in Hybrid EV System is
operating.

The rear door windows only open halfway.

Lock switch

E00303101263

When this switch is operated, the passenger’s
switches cannot be used to open or close the
door windows and the driver’s switch cannot
open or close any door windows other than
the driver’s door window.

To unlock, press it once again.

1- Lock
2- Unlock

WARNING

A child may tamper with the switch at the
risk of its hands or head being trapped in
the window. When driving with a child in
the vehicle, please press the window lock
switch to disable the passenger’s switches.

Timer function

E00302402051

The door windows can be opened or closed
for 30 seconds after putting the operation
mode in OFF or ACC from ON.
However, once the driver’s door or the front
passenger’s door is opened, the windows can-
not be operated.

Electric window control

4-35

OGGE19E1

Locking and unlocking

Safety mechanism

E00302502384

If  a  hand  or  head  is  trapped  in  the  closing
window, it will lower automatically.
Nonetheless,  make  sure  that  nobody  puts
their  head  or  hand  out  of  the  window  when
closing a window.
The lowered window will become operation-
al after a few seconds.

WARNING

If the auxiliary battery terminals are dis-
connected or the fuse for electric window
is replaced, the safety mechanism will be
cancelled.
If a hand or head got trapped, a serious
injury could result.

CAUTION

The safety mechanism is cancelled just be-
fore the window is fully closed. This allows
the window to close completely. Therefore
be especially careful that no fingers are trap-
ped in the window.

CAUTION

The safety mechanism is deactivated while
the switch is pulled up. Therefore be espe-
cially careful that fingers are not trapped in
the door window opening.

NOTE

The safety mechanism can be activated if the
driving conditions or other circumstances
cause the door windows to be subjected to a
physical shock similar to that caused by a
trapped hand or head.

If  the  following  operation  is  performed,  the
safety  mechanism  will  be  cancelled  and  the
door  window  will  not  automatically  open/
close completely.

•

When the auxiliary battery terminals are
disconnected.

•

When the fuse for power window is re-
placed.

•

When the safety mechanism is activated
five or more times consecutively.

In  such  a  case,  the  following  procedure
should  be  implemented  to  rectify  this  situa-
tion.
If  the  window  is  open,  repeatedly  raise  the
appropriate  window  switch  until  that  win-
dow  has  been  fully  closed.  Following  this,
release  the  switch,  raise  the  switch  once
again and hold it in this condition for at least
1 second, then release it. You should now be
able to operate the door window in the nor-
mal fashion.

Sunroof*

E00302702445

The sunroof can only be operated with the
operation mode in “ON”.

To open

The sunroof automatically opens if the switch
(1) is pressed.
To stop the moving sunroof, press switch (2)
or (3).

NOTE

The sunroof automatically stops just before
reaching the fully open position.
Press the switch again to fully open it.

To close

The sunroof automatically closes while the
switch (3) is pressed.

Sunroof*

4-36

OGGE19E1

Locking and unlocking

To stop the moving sunroof, press switch (1)
or (2).

To tilt up

When the switch (2) is pressed, the rear edge
of the sunroof rises for ventilation.

To tilt down

Press the switch (3).

Safety mechanism

E00303801521

If  a  hand  or  head  is  trapped  in  the  closing
sunroof, it will re-open automatically.
Nonetheless,  make  sure  that  nobody  puts
their  head  or  hand  out  of  the  sunroof  when
opening or closing.
The opened sunroof will become operational
after a few seconds.

CAUTION

The safety mechanism is cancelled just be-
fore the sunroof is fully closed. This allows
the sunroof to close completely.
Therefore be especially careful that no fin-
gers are trapped in the sunroof.

NOTE

The safety mechanism can be activated if the
driving conditions or other circumstances
cause the sunroof to be subjected to a physi-
cal shock similar to that caused by a trapped
hand or head.

If the safety mechanism should be activated 5
or  more  times  consecutively,  normal  closing
of the sunroof will be aborted.
As an emergency measure, the sunroof can be
closed  bit  by  bit  until  the  sunroof  is  com-
pletely  closed  by  repeatedly  pressing  switch
(2).
After  that,  the  sunroof  can  be  set  the  initial-
ized state in the following procedure.

1. Move the sunroof in slide open position.
2. Press the tilt up switch (2) continually in

10 seconds.

3. The sunroof will be moved to tilt up po-

sition automatically bit by bit.

4. The initialize is completed when the

sunroof is stopped at tilt up position.

If the sunroof does not return to normal, con-
sult a MITSUBISHI MOTORS Authorized
Service Point.

WARNING

Before operating the sunroof, make sure
that nothing is capable of being trapped
(head, hand, finger, etc.).

WARNING

Do not put head, hands or anything else
out of the sunroof opening while driving
the vehicle.

Never leave the vehicle without removing
the key.

Never leave a child (or other person who
might not be capable of safe operation of
the sunroof switch) in the vehicle alone.

NOTE

The  sunroof  stops  just  before  reaching  the
fully open position.
If  the  vehicle  is  driven  with  the  sunroof  in
this  position,  wind  buffeting  is  lower  than
with the sunroof fully open.

When leaving the vehicle unattended, make
sure you close the sunroof.

Do not try to operate the sunroof if it is fro-
zen closed (after snow fall or during extreme
cold).

Do not sit or place heavy luggage on the
sunroof or roof opening edge.

Release the switch as soon as the sunroof
reaches the fully open or fully closed posi-
tion.

If  the  sunroof  does  not  operate  when  the
sunroof  switch  is  operated,  release  the
switch and check whether something is trap-
ped  by  the  sunroof.  If  nothing  is  trapped,
have the sunroof checked at a MITSUBISHI
MOTORS Authorized Service Point.

Sunroof*

4-37

OGGE19E1

Locking and unlocking

NOTE

Depending on the models of ski carriers or
roof carriers, the sunroof may touch the car-
rier when the sunroof is tilted up. Be careful
when tilting up the sunroof if such a ski car-
rier or a roof carrier is installed.

Be sure to close the sunroof completely
when washing the vehicle or when leaving
the vehicle.

Be careful, not to put any wax on the weath-
erstrip  (black  rubber)  around  the  sunroof
opening.  If  stained  with  wax,  the  weather-
strip  cannot  maintain  a  weatherproof  seal
with the sunroof.

After washing the vehicle or after it has
rained, wipe off any water that is on the sun-
roof before operating it.

Sunshade

E00307901227

Slide the sunshade manually to open and
close it.

CAUTION

Be careful that hands are not trapped when
closing the sunshade.

NOTE

The sunshade cannot be closed with the sun-
roof opened. Do not attempt to close the
sunshade when the sunroof is opened.

Sunroof*

4-38

OGGE19E1

Locking and unlocking

Seat arrangement

E00400201886

By operating the front or rear seat, select the desired seat arrangement.

Normal usage

Flat seat

® p. 5-08

Making a luggage area

Folding the rear seats

® p. 5-06

Seat adjustment

E00400302057

Adjust the driver’s seat so that you are com-
fortable and that you can reach the pedals,
steering wheel, switches etc. while retaining
a clear field of vision.

Seat arrangement

5-02

OGGE19E1

Seats and seat belts

WARNING

Do  not  attempt  to  adjust  the  seat  while
driving. This can cause loss of vehicle con-
trol  and  result  in  an  accident.  After  ad-
justments are made, ensure the seating is
locked  in  position  by  attempting  to  move
the  seat  forward  and  rearward  without
using the adjusting mechanism.

Do not allow people or children to ride in
any area of your vehicle that is not equip-
ped with seats and seat belts, and make
sure that everyone travelling in your vehi-
cle is in a seat and wearing a seat belt, or
in the case of a child is strapped in a child
restraint.

To minimize the risk of personal injury in
the event of a collision or sudden braking,
the  seatbacks  should  always  be  in  the  al-
most  upright  position  while  the  vehicle  is
in motion. The protection provided by the
seat  belts  may  be  reduced  significantly
when  the  seatback  is  reclined.  There  is
greater  risk  that  the  passenger  will  slide
under the seat belt, resulting in serious in-
jury, when the seatback is reclined.

Do not place objects under the seats. This
could prevent the seat from locking se-
curely, and it could lead to an accident. It
may also cause damage to the seat or oth-
er parts.

CAUTION

Make sure the seat is adjusted by an adult or
with adult supervision for correct and safe
operation.

Do not place a cushion or the like between
your back and the seatback while driving.
The effectiveness of the head restraints will
be reduced in the event of an accident.

The  reclining  mechanism  of  the  front  seat’s
seatback is spring loaded, causing it to return
to the vertical position when the lock lever is
operated.  When  using  the  lever,  sit  close  to
the  seatback  or  hold  it  with  your  hand  to
control its return motion.

When sliding the seats, be careful not to
catch your hand or foot.

When adjusting the front seat while the rear
seat is folded, be careful not to apply strong
force to the flipped rear seat cushion.
Doing so could cause damage to the cover of
the front seat and the fitting of the rear seat
cushion.

Front seats

E00400401253

Manual type

1- To adjust forward or backward

Lift the handle and adjust the seat to the
desired position, and release the handle.

2- To recline the seatback

Pull the lever up and then lean backward
to the desired position, and release the
lever.

3- To adjust seat height (driver’s side only)

Repeatedly operate the lever and adjust
the seat height to the desired position.

Front seats

5-03

OGGE19E1

Seats and seat belts

Power type*

1- To adjust forward or backward

Operate the switch as indicated by the
arrows and adjust the seat to the desired
position.

2- To recline the seatback

Operate the switch as indicated by the
arrows and adjust the seatback angle to
the desired position.

3- To adjust seat height

Operate the switch as indicated by the
arrows and adjust the seat height to the
desired position.
If the entire switch is operated, then the
entire seat moves.

Heated seats*

E00401102371

The heated seats can be operated with the op-
eration mode of the power switch in ON. Op-
erate the switch as indicated by arrows.

The indication lamp (A) will illuminate while
the heater is on.

1 (HI)

- Heater high (for quick heating).

2 (neu-
tral po-
sition)

- Heater off.

3 (LO)

- Heater low (to keep the seat

warm).

CAUTION

Operate in the high position for quick heat-
ing. Once the seat is warm, set the heater to
low to keep it warm. Slight variations in seat
temperature may be felt while using the
heated seats. This is caused by the operation
of the heater’s internal thermostat and does
not indicate a malfunction.

CAUTION

If  the  following  types  of  persons  use  the
heated  seats,  they  might  become  too  hot  or
receive  minor  burns  (red  skin,  heat  blisters,
etc.):

•

Children, elderly or ill people

•

People with sensitive skin

•

Excessively tired people

•

People under the influence of alcohol or
sleep inducing medication (cold medicine,
etc.)

Do not place heavy objects on the seat or
stick pins, needles, or other pointed objects
into it.

Do not use a blanket, cushion, or other mate-
rial with high heat insulation properties on
the seat while using the heater; this might
cause the heater element to overheat.

Do not use benzine, kerosene, petrol, alcohol
or other organic solvents when cleaning the
seats. Doing so could damage not only the
seat cover, but also the heater element.

If water or any other liquid is spilled on the
seat, allow it to dry thoroughly before at-
tempting to use the heater. Turn the heater
off immediately if it appears to be malfunc-
tioning during use.

Front seats

5-04

OGGE19E1

Seats and seat belts

Rear seats

E00401301549

To adjust the seatback, pull the lever up and
adjust the seatback by hand to the desired po-
sition, and release the lever.

Armrest

E00401701732

To use the armrest, fold it down.

To return to the original position, push it
backward level with the seat.

NOTE

Do not climb or sit on the armrest.
Doing so could damage the armrest.

The top surface of the armrest contains a cup
holder for rear seat occupants.
Refer to “Cup holder” on page 8-84.

Head restraints

E00403302654

WARNING

Driving  without  the  head  restraints  in
place  can  cause  you  and  your  passengers
serious injury or death in an accident. To
reduce  the  risk  of  injury  in  an  accident,
always  make  sure  the  head  restraints  are
installed  and  properly  positioned  when
the seat is occupied.

WARNING

Never place a cushion or similar device on
the seatback. This can adversely affect
head restraint performance by increasing
the distance between your head and the
restraint.

When a person sits in the rear seats, pull
up the head restraint to a height at which
it locks in position. Be sure to make this
adjustment before starting to drive. Seri-
ous injuries could otherwise be suffered as
the result of an impact.

To adjust height

Adjust the head restraint height so that the
centre of the head restraint is as close as pos-
sible to ear level to reduce the chances of in-
jury in the event of collision. Any person too
tall for the head restraint to reach their seated
ear level, should adjust the restraint as high
as possible.

Rear seats

5-05

OGGE19E1

Seats and seat belts

To  raise  the  head  restraint,  move  it  upward.
To  lower  the  restraint,  move  it  downward
while  pushing  the  height  adjusting  knob  (A)
in  the  direction  of  the  arrow.  After  adjust-
ment,  push  the  head  restraint  downward  and
make sure that it is locked.

To remove

Lift the head restraint with the height adjust-
ing knob (A) pushed in.

To install

Confirm  that  the  head  restraint  is  facing  the
correct  direction,  and  then  insert  it  into  the
seatback  while  pressing  the  height  adjusting
knob (A) in the direction indicated by the ar-
row.
The  head  restraint  stalk  with  the  adjustment
notches (B) must be installed in the hole with
the adjusting knob (A).

CAUTION

Confirm  that  the  height  adjusting  knob  (A)
is correctly adjusted as shown in the illustra-
tion,  and  also  lift  the  head  restraints  to  en-
sure  that  they  do  not  come  out  of  the  seat-
back.

CAUTION

The shape and size of the head restraint dif-
fers  according  to  the  seat.  Always  use  the
correct  head  restraint  provided  for  the  seat
and  do  not  install  the  head  restraint  in  the
wrong direction.

Making a luggage area

E00403401502

To create luggage space, you can fold the rear
seats.

CAUTION

Do not stack luggage above the seatback
height. Secure the luggage firmly.
Serious accidents could result due to unre-
strained objects entering the passenger com-
partment during sudden braking.

Making a luggage area

5-06

OGGE19E1

Seats and seat belts

Mitsubishi Outlander PHEV (2019 year). Instruction - part 7
