Mitsubishi Outlander PHEV (2019 year). Instruction - part 5

When discharging from the drive battery

V2H power supply

No energy flow

NOTE

Even when you are not operating the air con-
ditioner, car navigation system, audio equip-
ment, etc., since the on-board computer con-
sumes electricity, arrows may be displayed
from the charger or the drive battery.

NOTE

Energy flow display may change regardless
of the operation of the air conditioner, car
navigation system, audio equipment, etc.

If you change the setting of the air condi-
tioner, it may take time until the display of
the energy flow stabilizes.

How to use an electric device during charging

3-27

OGGE19E1

Charging

Charging troubleshooting guide

E08301501243

Symptom

Possible cause

Possible solution

Charging cannot be
started.

The operation mode of the power
switch is in the “ON” position.

Put the operation mode of the power switch in “OFF” before charging.

The drive battery is already fully
charged.

Charging cannot be performed if the drive battery is already fully charged. Charg-
ing automatically turns off if the drive battery is fully charged.

The temperature of the drive bat-
tery is too high or too low to
charge.

Confirm the drive battery temperature.
Refer to “Cautions and actions to deal with intense heat” on page 2-10 and “Cau-
tions and actions to deal with intense cold” on page 2-10.

The auxiliary battery is dis-
charged.

The drive battery cannot be charged if the vehicle electrical systems cannot be
turned on. If the auxiliary battery is discharged, charge or emergency start the aux-
iliary battery.
Refer to “Emergency starting” on page 9-02.

The vehicle or the charging cable
has a malfunction.

The vehicle or charging cable may have a malfunction. Confirm if the warning
lamp on the meter is illuminated. Confirm if the indicator on the control box is in-
dicating a malfunction. If a warning is displayed, stop charging and contact a
MITSUBISHI MOTORS Authorized Service Point.

Normal charging can-
not be started.

There is no electrical power com-
ing from the outlet.

Confirm that there has not been a power failure. Make sure the breaker is on. If an
outlet with a timer device installed is used, power will only be available at the time
set by the timer.
Confirm if the POWER indicator on the control box is illuminated.

The charge connector is not con-
nected correctly.

Confirm the charge connector is connected correctly.

The charge connector was connec-
ted and disconnected repeatedly in
a short time.

Disconnect the charge connector, wait for a while, then start charging procedure
again from the beginning.

Charging troubleshooting guide

3-28

OGGE19E1

Charging

Symptom

Possible cause

Possible solution

A charging cable for other vehicle
is used.

Use the EV charging cable only for your vehicle.

A normal charger which does not
correspond to your vehicles is
used.

Consult an administrator or a maker of the normal charger that it corresponds to
your vehicle. Also perform normal charging according to the operating procedure
indicated on the body of normal charger.

The reservation of Charging timer
is set up by MITSUBISHI Remote
Control (if so equipped), Smart-
phone Link Display Audio (if so
equipped) or by the MITSUBISHI
Multi-Communication System
(MMCS) (if so equipped).

The normal charging cannot be started when the charging cable is connected, if the
charging timer is set. Cancel all the charging timer settings, if you want to start the
normal charging immediately.
Refer to “MITSUBISHI Remote Control” on page 3-20.
For the MITSUBISHI Multi-Communication System (MMCS) refer to the separate
owner’s manuals.

Normal charging is dis-
continued.

There is no power coming from
the outlet.

There may have been a electrical power failure, or the breaker may have failed.
Charging will resume when the power source is reset.

The EV charging cable has been
disconnected.

Check that the EV charging cable has not been disconnected.

The button on the normal charge
connector has been pressed.

If the charge connector button is pressed for a long period of time, charging will be
stopped. Start the charging procedure again.

The temperature of the drive bat-
tery is too high or too low to
charge.

Confirm the drive battery temperature.
Refer to “Cautions and actions to deal with intense heat” on page 2-10 and “Cau-
tions and actions to deal with intense cold” on page 2-10.

Charging is stopped by the normal
charge timer.

Charging will stop depending on the timer function setting of the normal charge de-
vice. Try it again with cancelling the timer settings.

Charging troubleshooting guide

3-29

OGGE19E1

Charging

Symptom

Possible cause

Possible solution

The Charging timer was set up by
the MITSUBISHI Remote Control
(if so equipped), Smartphone Link
Display Audio (if so equipped) or
the MITSUBISHI Multi-Commu-
nication System (MMCS) (if so
equipped) after starting of normal
charging.

Cancel all the charging timer settings. Charging is automatically restarted if you
cancel the charging timer.
Refer to “MITSUBISHI Remote Control” on page 3-20.
For the MITSUBISHI Multi-Communication System (MMCS) refer to the separate
owner’s manuals.

Quick charging cannot
be started.

The charge connector is not con-
nected correctly and/or not locked.

Check that the charge connector is connected correctly and that it is locked.

The self-diagnostic function of the
quick charge device returns a neg-
ative result.

There is a possibility that the vehicle has a malfunction. Stop charging and contact
a MITSUBISHI MOTORS Authorized Service Point.

The power switch of the quick
charger is off.

Check the power switch of the quick charger.
Consult an administrator or a maker of the quick charger.

Quick charge is discon-
tinued.

Charging is stopped by the quick
charge timer.

Charging will stop depending on the timer function setting of the quick charge de-
vice. If you need to charge the drive battery more, start the charging procedure
again.

Charging stops at 80 % capacity.

Charging is designed to stop when the drive battery capacity reaches 80 %. If you
need to charge the drive battery more than 80 %, start the charging procedure
again.

The power supply for the quick
charger is off.

Check whether the power supply for the quick charger is off.
Consult an administrator or a maker of the quick charger.

Charging troubleshooting guide

3-30

OGGE19E1

Charging

Symptom

Possible cause

Possible solution

The charging indicator
is continuously blink-
ing even if the quick
charge connector is
not connected into the
quick charge port
when you start the
plug-in hybrid EV sys-
tem after quick charg-
ing.

Quick charging has not finished
normally.

Perform quick charging again and finish it normally or contact a MITSUBISHI
MOTORS Authorized Service Point.

Plug-in Hybrid EV
System does not start
after quick charging.

The vehicle has a malfunction.

There is a possibility that the vehicle has a malfunction. After turning the operation
mode of the power switch to “ON” and putting the select position to “N”, ask the
support of the fellow passenger or people nearby to move the vehicle by pushing it
into safety.
After moving, contact a MITSUBISHI MOTORS Authorized Service Point.

Charging troubleshooting guide

3-31

OGGE19E1

Charging

Keys

E00300104540

The key fits all locks.
without MITSUBISHI Remote Control

with MITSUBISHI Remote Control

1- Keyless operation key

2- Keyless operation key (with electric tail-

gate switch)

3- Emergency key

WARNING

When taking a key on flights, do not press
any  switches  on  the  key  while  on  the
plane. If a switch is pressed on the plane,
the  key  emits  electromagnetic  waves,
which  could  adversely  affect  the  plane’s
flight operation.
When carrying a key in a bag, be careful
that  no  switches  on  the  key  can  be  easily
pressed by mistake.

NOTE

The key (except for the emergency key) is a
precision electronic part with a built-in sig-
nal transmitter. Please observe the following
in order to prevent a malfunction.

•

Do not leave in a place that is exposed to
direct sunlight, for example on the dash-
board.

•

Do not disassemble or modify.

•

Do not excessively bend the key or sub-
ject it to strong impacts.

•

Do not expose to water.

•

Keep away from magnetic key rings.

•

Keep away from audio systems, personal
computers, TVs, and other equipment that
generates a magnetic field.

NOTE

•

Keep away from devices that emit strong
electromagnetic waves, such as cellular
phones, wireless devices and high fre-
quency equipment (including medical de-
vices).

•

Do not clean with ultrasonic cleaners or
similar equipment.

•

Do not leave the key where it may be ex-
posed to high temperature or high humidi-
ty.

The plug-in hybrid EV system is designed so
that it will not start if the ID code registered
in  the  immobilizer  computer  and  the  key’s
ID  code  do  not  match.  Refer  to  the  “Elec-
tronic  immobilizer”  section  for  details  and
key usage.

[For vehicles equipped with the security
alarm system]
Pay attention to the following if the security
alarm is set to “Active”.
Refer to “Security alarm system” on page
4-27.

•

If  the  security  alarm  is  in  the  system
armed  mode,  the  alarm  will  sound  if  the
doors  are  opened  after  being  unlocked
with  the  key,  the  inside  lock  knob  or  the
central door lock switch.

•

Even if the security alarm is set to “Ac-
tive”, the system preparation mode is not
entered if the keyless entry system or the
keyless operation function was not used to
lock the vehicle.

Keys

4-02

OGGE19E1

Locking and unlocking

Key number tag

The key number is stamped on the tag as in-
dicated in the illustration.
Make  a  record  of  the  key  number  and  store
the  key  and  key  number  tag  in  separate  pla-
ces,  so  that  you  can  order  a  key  from  your
MITSUBISHI MOTORS Authorized Service
Point in the event the original keys are lost.

Electronic immobilizer
(Anti-theft starting system)

E00300203791

The  electronic  immobilizer  has  been  de-
signed  to  significantly  reduce  the  possibility
of vehicle theft. The purpose of the system is
to immobilize the vehicle if an invalid start is
attempted.  A  valid  start  attempt  can  only  be
achieved  by  using  a  key  “registered”  to  the
immobilizer system.

CAUTION

Do not modify or add parts to the immobiliz-
er system. Doing so could cause the immo-
bilizer to malfunction.

NOTE

If  the  plug-in  hybrid  EV  system  does  not
start,  we  recommend  you  to  contact  your
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

If  you  lose  one  of  keyless  operation  keys,
contact  your  MITSUBISHI  MOTORS  Au-
thorized  Service  Point  as  soon  as  possible.
To  obtain  a  replacement  or  extra  spare  key,
take  your  vehicle  and  all  remaining  keys  to
your  MITSUBISHI  MOTORS  Authorized
Service Point. All the keys have to be re-reg-
istered  in  the  immobilizer  computer  unit.
The immobilizer can register as follows.

•

Keyless operation key: up to 4 different
keys

Keyless entry system

E00300304861

Press the remote control switch, and all doors
and the tailgate will be locked or unlocked as
desired. It is also possible to operate the out-
side rear-view mirrors.

1- LOCK switch
2- UNLOCK switch
3- Electric tailgate switch*
4- Indication lamp
5- Charging timer cancel switch*

NOTE

The charging lid is also locked/unlocked,
when the driver’s door is locked/unlocked.

Electronic immobilizer (Anti-theft starting system)

4-03

OGGE19E1

Locking and unlocking

To lock

Press the LOCK switch (1). All the doors and
the tailgate will be locked. The turn-signal
lamps will blink once when the doors and the
tailgate are locked.

To unlock

Press the UNLOCK switch (2). All the doors
and the tailgate will be unlocked. If the doors
and tailgate are unlocked when the front
room lamp switch is in the “DOOR” position
or the rear room lamp switch is in the middle
(•) position, the room lamp will illuminate for
approximately 15 seconds and the turn-signal
lamps will blink twice.
The position and tail lamps can also be set to
turn on for approximately 30 seconds. Refer
to “Instruments and controls: Welcome light”
on page 6-65.

NOTE

For the operation of the Electric tailgate
switch (3), refer to “Electric tailgate” on
page 4-20.

For the operation of the Charging timer can-
cel switch (5), refer to “MITSUBISHI Re-
mote Control” on page 3-20.

NOTE

The door and tailgate unlock function can be
set  so  that  only  the  driver’s  door  unlocks
when  the  UNLOCK  switch  (2)  is  pressed
once.
If the door and tailgate unlock function is set
to work as described above, all the doors and
the  tailgate  unlock  when  the  UNLOCK
switch is pressed two times in succession.
Refer to “Setting of door and tailgate unlock
function” on page 4-05.

If the UNLOCK switch (2) is pressed and no
door or tailgate is opened within approxi-
mately 30 seconds, relocking will automati-
cally occur.

If either of the following problems occurs,
the battery may be exhausted.

•

The remote control switch is operated at
the correct distance from the vehicle, but
the doors and tailgate are not locked/
unlocked in response.

•

The indication lamp (4) is dim or does not
come on.
For further information, please consult
your MITSUBISHI MOTORS Authorized
Service Point.
If you replace the battery yourself, refer to
“Procedure for replacing the remote con-
trol switch battery” on page 4-05.

It is possible to modify functions as follows:
For further information, please contact your
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI

NOTE

Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

•

The time for automatic relocking can be
changed.

•

The confirmation function (flashing of the
turn-signal lamps) can be set to operate
only when the doors and backdoor are
locked or only when the doors and back-
door are unlocked.

•

The confirmation function (this indicates
locking or unlocking of the doors and tail-
gate with the blink of the turn-signal
lamps) can be deactivated.

•

The number of times the turn-signal
lamps are flashed by the confirmation
function can be changed.

The outside rear-view mirrors automatically
retract or extend when the doors and tailgate
are locked or unlocked using the remote
control switches of the keyless entry system.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 7-09.

The keyless entry system does not operate in
the following conditions:

•

The operation mode is not in OFF.

•

The LOCK switch (1) is pressed while a
door or the tailgate is open.

Keyless entry system

4-04

OGGE19E1

Locking and unlocking

NOTE

The remote control switch will operate with-
in  approximately  4  m  from  the  vehicle.
However, the operating range of the remote
control  switch  may  change  if  the  vehicle  is
located  near  a  power  station,  or  radio/TV
broadcasting station.

If your remote control switch is lost or dam-
aged, please contact your MITSUBISHI
MOTORS Authorized Service Point for a re-
placement remote control switch.

If you wish to add a remote control switch,
we recommend you to contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.
The below remote control switches are avail-
able for your vehicle.

•

Keyless operation key: up to 4 remote
control switches

Setting of door and tailgate un-

lock function

E00310301531

The door and tailgate unlock function can be
set to the following two conditions.
Each time the door and tailgate unlock func-
tion is set, a chime will sound to tell you the
condition of the door and tailgate unlock
function.

Number of

chimes

Condition

One chime [Fac-
tory setting]

When  the  UNLOCK
switch,  driver’s  or  front
passenger’s  door  lock/
unlock switch, or tailgate
open  switch  is  pressed
one  time,  all  doors  and
the tailgate unlock.

Two chimes

When  the  UNLOCK
switch  or  the  driver’s
door  lock/unlock  switch
is pressed one time, only
the  driver’s  door  un-
locks.  When  the  UN-
LOCK  switch  or  the
driver’s

door

lock/

unlock switch is pressed
two times in succession,
all doors and the tailgate
unlock.

1. Put the operation mode in OFF.
2. Place the combination headlamps and

dipper switch in the “OFF” position, and
leave the driver’s door open.

3. Press the LOCK switch (1) for 4 to 10

seconds and press the UNLOCK switch
(2) during this time.

4. Release in sequence the LOCK and UN-

LOCK switches within 10 seconds of
pressing the LOCK switch in step 3.

NOTE

The charging lid is also unlocked, when the
driver’s door is unlocked.

On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

Procedure for replacing the re-

mote control switch battery

E00309502022

Before replacing the battery, remove static
electricity from your body by touching a met-
al grounded object.

WARNING

Danger of explosion if battery is incor-
rectly replaced.
Replace only with the same battery or an
equivalent type.

CAUTION

When  the  remote  control  switch  case  is
opened,  be  careful  to  keep  water,  dust,  etc.
out.  Also,  do  not  touch  the  internal  compo-
nents.

Keyless entry system

4-05

OGGE19E1

Locking and unlocking

NOTE

You may purchase a replacement battery at
an electric appliance store.

A MITSUBISHI MOTORS Authorized
Service Point can replace the battery for you
if you prefer.

1. Remove the emergency key from the

key.
Refer to “Emergency key” on page
4-14.

2. With the MITSUBISHI mark facing you,

insert  the  cloth  covered  tip  of  a  straight
blade  (or  minus)  screwdriver  into  the
notch  in  the  remote  control  switch  case
and use it to open the case.

NOTE

Be  sure  to  perform  the  procedure  with  the
MITSUBISHI  mark  facing  you.  If  the
MITSUBISHI  mark  is  not  facing  you  when
you open the remote control switch case, the
transmitter may come out.

3. Remove the old battery.
4. Install a new battery with the + side (A)

up.

+ side

- side

Coin type battery

CR2032

5. Close the case firmly.
6. Install the emergency key removed in

step 1.

7. Check the keyless operation function to

see that it works.

Keyless operation system

E00305602432

The  keyless  operation  system  allows  you  to
lock  and  unlock  the  doors  and  tailgate  and
start  the  Plug-in  Hybrid  EV  System  simply
by  carrying  the  keyless  operation  key  with
you.
The keyless operation key can also be used as
the  keyless  entry  system  remote  control
switch.
Refer  to  “Keyless  entry  system”  on  page
4-03.
The  driver  should  always  carry  the  keyless
operation key. This key is necessary for lock-
ing  and  unlocking  the  doors  and  tailgate,
starting  the  Plug-in  Hybrid  EV  System  and
otherwise  operating  the  vehicle,  so  before
locking  and  leaving  the  vehicle,  be  sure  to
check  that  you  have  the  keyless  operation
key.

WARNING

People  with  implantable  cardiac  pace-
makers or implantable cardiovascular-de-
fibrillators should not go near the exterior
transmitters  (A)  or  the  interior  transmit-
ters (B). The radio waves used by the key-
less  operation  system  could  adversely  af-
fect  implantable  cardiac  pacemakers  or
implantable cardiovascular-defibrillators.

Keyless operation system

4-06

OGGE19E1

Locking and unlocking

WARNING

When using electro-medical devices other
than  implantable  cardiac  pacemakers  or
implantable  cardiovascular-defibrillators,
contact  the  electromedical  device  manu-
facturer  ahead  of  time  to  determine  the
affects of radio waves on the devices. Elec-
tromedical device operations could be ad-
versely effected by radio waves.

You can limit the possible operations of
the  keyless  operation  system  in  the  fol-
lowing  ways.  (The  keyless  operation
system  can  be  used  as  a  keyless  entry
system.)  Please  consult  a  MITSUBISHI
MOTORS Authorized Service Point.

• You can limit operations to locking

and unlocking the doors and tailgate.

• You can limit operations to starting

the Plug-in Hybrid EV System.

• The keyless operation system can be

disabled.

NOTE

The keyless operation key uses an ultra-
weak electromagnetic wave. In the following
cases, the keyless operation system may not
operate properly or may be unstable.

•

When there is equipment nearby that
emits strong radio waves, such as: a pow-
er station, a radio/TV broadcasting station
or an airport.

•

The  keyless  operation  system  is  carried
together  with  a  communications  device
such  as  a  cellular  phone  or  radio  set,  or
with  an  electronic  device  such  as  a  per-
sonal computer.

•

The keyless operation key is touching or
covered by a metal object.

•

A keyless entry system is being used
nearby.

•

When the keyless operation key battery is
worn out.

•

When the keyless operation key is placed
in  an  area  with  strong  radio  waves  or
noise.
In such cases, use the emergency key.
Refer  to  “To  operate  without  using  the
keyless  operation  function”  on  page
4-14.

NOTE

Because  the  keyless  operation  key  receives
signals  in  order  to  communicate  with  the
transmitters  in  the  vehicle,  the  battery  con-
tinually  wears  down  regardless  of  keyless
operation key use. The battery life is 1 to 3
years, depending on usage conditions. When
the battery wears out, replace the battery ac-
cording  to  the  description  in  this  manual  or
have  it  replaced  at  your  MITSUBISHI
MOTORS Authorized Service Point.
Refer to “Procedure for replacing the remote
control switch battery” on page 4-05.

Because the keyless operation key continual-
ly receives signals, strong radio wave recep-
tion could affect battery wear. Do not leave
the key near a TV, personal computer, or
other electronic device.

Operating range of the keyless

operation system

E00305701830

If you are carrying the keyless operation key,
enter the operating range of the keyless oper-
ation system, and press the driver’s or front
passenger’s door lock/unlock switch, the tail-
gate LOCK switch or the tailgate open
switch, the ID code for your key is verified.

Keyless operation system

4-07

OGGE19E1

Locking and unlocking

You can lock and unlock the doors and tail-
gate and start the Plug-in Hybrid EV System
only if the ID codes of your keyless operation
key and the vehicle match.

NOTE

If the keyless operation key battery is wear-
ing out or there are strong electromagnetic
waves or noise present, the operating range
may become smaller and operation may be-
come unstable.

Operating range for locking
and unlocking the doors and
tailgate

E00306201858

The operating range is approximately 70 cm
from the driver’s door lock/unlock switch,
front passenger’s door lock/unlock switch,
and tailgate lock/unlock switch.

*: Forward direction

: Operating range

NOTE

Locking and unlocking operate only when
you press a door or tailgate switch that de-
tects the keyless operation key.

Operation may not be possible if you are too
close to the front door, door window, or tail-
gate.

NOTE

Even  if  the  keyless  operation  key  is  within
70  cm  of  the  driver’s  door  lock/unlock
switch,  front  passenger’s  door  lock/unlock
switch, or tailgate lock/unlock switch, if the
key is near to the ground or high up, the sys-
tem may not operate.

If the keyless operation key is within the op-
erating range, even someone not carrying the
key can lock and unlock the doors and tail-
gate by pressing the driver’s or front pas-
senger’s door lock/unlock switch, the tail-
gate lock switch or the tailgate open switch.

Operating range for starting the
Plug-in Hybrid EV System and
changing the operation mode

E00306301530

The operating range is the interior of the ve-
hicle.

Keyless operation system

4-08

OGGE19E1

Locking and unlocking

*: Forward direction

: Operating range

NOTE

Even if it is within the operating range, if the
keyless  operation  key  is  in  a  small  item
holder  such  as  the  glove  box,  on  top  of  the
instrument panel, door pocket or in the lug-
gage  area,  it  may  be  impossible  to  start  the
Plug-in Hybrid EV System.

If a keyless operation key is too close to the
door or door window, it may be possible to
start the Plug-in Hybrid EV System or
change the operation mode even when the
key is outside the vehicles.

To operate using the keyless

operation function

E00305802870

NOTE

The charging lid is also locked/unlocked,
when the driver’s door is locked/unlocked.

Locking the doors and tailgate

When you are carrying the keyless operation
key,  if  you  press  the  driver’s  or  front  pas-
senger’s  door  lock/unlock  switch  (A),  or  the
tailgate LOCK switch (B) within the operat-
ing  range,  the  doors  and  the  tailgate  are
locked.
The turn-signal lamps will blink once.
Also refer to “Locking and unlocking: Doors,
Central  door  locks,  Tailgate”  on  pages  4-14,
4-16 and 4-19.

Driver’s or front passenger’s door
lock/unlock switches

Tailgate switches

NOTE

For vehicles equipped with the mirror retrac-
tor switch, the outside rear-view mirrors au-
tomatically retract when all the doors and
tailgate are locked using the keyless opera-
tion function.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 7-09.

The keyless operation function does not op-
erate under the following conditions:

•

The keyless operation key is inside the
vehicle.

•

The operation mode of the power switch
is not in OFF.

•

A door or the tailgate is open or ajar.

The tailgate open switch (C) can be used to
check that the vehicle is locked properly.
Press the tailgate open switch within approx-
imately 3 seconds of locking the vehicle. If
you wait longer than 3 seconds and press the
tailgate open switch, the doors and tailgate
will be unlocked.

Keyless operation system

4-09

OGGE19E1

Locking and unlocking

NOTE

The time allowed for checking that the vehi-
cle is locked can be adjusted. For further in-
formation,

please

contact

your

MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

Unlocking the doors and tail-

gate

When you are carrying the keyless operation
key,  if  you  press  the  driver’s  or  front  pas-
senger’s  door  lock/unlock  switch  (A),  or  the
tailgate open switch (B) within the operating
range,  all  the  doors  and  the  tailgate  are  un-
locked.
If  the  front  room  lamp  switch  is  in  the
“DOOR”  position  or  the  rear  room  lamp
switch  is  in  the  middle  ( )  position  at  this
time, the room lamp will turn on for 15 sec-
onds. The turn-signal lamps will blink twice.
If the driver’s or front passenger’s door lock/
unlock switch is pressed and any of the doors
or tailgate is not opened within approximate-
ly  30  seconds,  relocking  will  automatically
occur.

Also refer to “Locking and unlocking: Doors,
Central door locks, Tailgate” on page 4-14,
“Central door locks” on page 4-16 and
“Tailgate*” on page 4-19.

Driver’s and front passenger’s door lock/unlock switches

Tailgate open switch

NOTE

The outside rear-view mirrors automatically
extend when all the doors and tailgate are
unlocked using the keyless operation func-
tion.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 7-09.

The keyless operation function can be set so
that only the driver’s door unlocks when the
driver’s door lock/unlock switch is pressed.
If  the  keyless  operation  function  is  set  to
work  as  described  above,  all  the  doors  and
the  tailgate  unlock  when  the  driver’s  door
lock/unlock  switch  is  pressed  two  times  in
succession.
Refer to “Setting of door and tailgate unlock
function” on page 4-05.

The keyless operation function does not op-
erate when the operation mode of the power
switch is not in OFF.

In order to make it possible to check that the
doors and tailgate are locked, you cannot un-
lock them by using the tailgate open switch
for 3 seconds after locking them.

The time allowed for checking that the vehi-
cle is locked can be adjusted. For further in-
formation,

please

contact

your

Keyless operation system

4-10

OGGE19E1

Locking and unlocking

NOTE

The  time  between  unlocking  and  automatic
locking  can  be  adjusted.  Please  consult  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

Operation confirmation when locking and
unlocking
Operation can be confirmed as shown below.
However, the room lamp will only illuminate
if the front room lamp switch is in the
“DOOR” position or the rear room lamp
switch is in the middle (•) position.

When locking:

The turn-signal
lamps will blink
once.

When unlocking:

The room lamp illu-
minates for approxi-
mately 15 seconds,
the turn-signal lamps
blink twice.

NOTE

Functions  can  be  modified  as  stated  below.
For further information, please contact your
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

•

Set the confirmation function (blinking of
the turn-signal lamps) to operate only
when the vehicle is locked or only when
the vehicle is unlocked.

•

Disable the operation confirmation func-
tion (blinking of the turn-signal lamps).

•

Change the number of blinks for the oper-
ation confirmation function (blinks of the
turn-signal lamps).

Keyless operation system

4-11

OGGE19E1

Locking and unlocking

Warning activation

E00305902464

In order to prevent vehicle theft or the accidental operation of the keyless operation system, the buzzer and the display on the information screen
in the multi-information display are used to alert the driver.
If a warning is activated, always check the vehicle and the keyless operation key. The warning is also displayed if there is a fault in the keyless
operation system.

Item

Display

Buzzer

Note (Solution)

Detection of failure

Inner buzzer sounds
once.

There is a fault in the keyless operation system.

Fall of battery voltage

Inner buzzer sounds
once.

The battery starts to run out, the warning is activated. (The
warning is not activated if the battery is completely dead.)

Key not detected

Inner buzzer sounds
once.

When the operation mode of the power switch is put in ACC or
ON from OFF or when the Plug-in Hybrid EV System is started,
the warning is activated, if any of the following conditions is oc-
curred.

Carrying another keyless operation key with a different
code, or the keyless operation key could be outside the op-
erating range.

The battery of the keyless operation key is dead.

Communication is blocked by electric wave environment.

Keyless operation key
reminder

Inner buzzer sounds ap-
proximately 1 minute
Outer buzzer sounds ap-
proximately 3 seconds
intermittently

If the operation mode is in OFF and the driver’s door is opened
with the keyless operation key in the key slot, a warning is is-
sued and the outer buzzer sounds for approximately 3 seconds
and the inner buzzer sounds for approximately 1 minute to re-
mind you to remove the key. If the key removed from key slot,
the buzzer is stopped.

Keyless operation system

4-12

OGGE19E1

Locking and unlocking

Content .. 3 4 5 6 ..
