Mitsubishi ASX (2018 year). Instruction

NOTE

In a vehicle that has a Dead Lock System, it
is not possible to unlock the door by pushing
the lock knob to the unlock side while the
Dead Lock System is set.
(Refer to “Dead Lock System” on page
3-27.)

To lock without using the key

Front passenger’s door, Rear

door

Set the inside lock knob (1) to the locked po-
sition, and close the door (2).

NOTE

The driver’s door cannot be locked using the
inside lock knob while the driver’s door is
opened.

Operation mode ON reminder

system*

E00310100268

For vehicles equipped with the keyless op-
eration system

If the driver’s door is opened with the engine
stopped and the operation mode in any posi-
tion other than OFF, the operation mode ON
reminder buzzer sounds intermittently to re-
mind you to put the operation mode in OFF.
In addition, the warning display will be dis-
played on the information screen in the multi-
information display.

Central door locks

E00300801777

NOTE

Each of the doors can be locked or unlocked
independently by using the inside lock knob.

When locking or unlocking with the key on
the driver’s door, only the driver’s door will
lock or unlock.

NOTE

Repeated continuous operation between lock
and  unlock  could  activate  the  central  door
locking  systems  built-in  protection  circuit
and prevent the system from operating.
If  this  occurs,  wait  approximately  1  minute
before  operating  the  central  door  lock
switch.

When the driver’s door is open, the central
door lock switch cannot be used to lock it.

To lock and unlock the doors

and tailgate

Using the central door lock

switch

Using the central door lock switch on the
driver’s door locks or unlocks all doors and
the tailgate.

LHD

Central door locks

3-26

OGAE18E1

Locking and unlocking

RHD

1- Lock
2- Unlock

To unlock the doors and tail-

gate

E00311301453

You  can  select  the  functions  to  unlock  the
doors  and  tailgate  either  using  the  ignition
switch or the engine switch, or using the se-
lector lever position A/T or CVT).
These  functions  are  not  activated  when  the
vehicle is shipped from the factory. To acti-
vate  or  deactivate  these  functions,  please
contact  a  MITSUBISHI  MOTORS  Author-
ized Service Point.

Using the ignition switch or the

engine switch

All doors and the tailgate will unlock when-
ever the ignition switch is turned to the
“LOCK” position or the operation mode is
put in OFF.

Using the selector lever position

(A/T or CVT)

All doors and the tailgate will unlock when-
ever  the  selector  lever  is  moved  to  the  “P”
(PARK)  position  with  the  ignition  switch  in
the  “ON”  position  or  the  operation  mode  in
ON.

Dead Lock System*

E00305100130

The  Dead  Lock  System  helps  to  prevent
theft.  When  the  keyless  entry  system  or  the
keyless  operation  system  has  been  used  to
lock  all  of  the  doors  and  the  tailgate,  the
Dead  Lock  System  makes  it  impossible  to
unlock the doors using the inside lock knobs.

CAUTION

Do  not  set  the  Dead  Lock  System  when
someone is inside the vehicle. With the Dead
Lock System set, it is not possible to unlock
the doors using the inside lock knobs. If you
erroneously  set  the  Dead  Lock  System,  un-
lock  the  doors  using  the  UNLOCK  switch
on  the  remote  control  switch  or  using  the
keyless operation function.

Setting the system

E00305201369

1. Except for vehicles equipped with the

keyless  operation  system,  remove  the
key from the ignition switch.
For  vehicles  equipped  with  the  keyless
operation  system,  put  the  operation
mode in OFF.

2. Get out of the vehicle. Close all of the

doors and the tailgate.

3. Press the LOCK switch (A) on the re-

mote control switch, the driver’s or front
passenger’s door lock/unlock switch (B),
or the tailgate LOCK switch (C) to lock
all of the doors and the tailgate. The
turn-signal lamps will blink once.

Dead Lock System*

3-27

OGAE18E1

Locking and unlocking

4. Press the switch again within 2 seconds.

The turn-signal lamps will blink three
times to show that the Dead Lock Sys-
tem has been set.

Except for vehicles equipped with the keyless
operation system

Vehicles equipped with the keyless operation system

Driver’s and front passenger’s door lock/unlock
switches*

Tailgate LOCK switch*

NOTE

Pressing  the  LOCK  switch  (A)  on  the  re-
mote  control  switch  once  while  the  Dead
Lock  System  is  set  causes  the  turn-signal
lamps to blink three times, so it is possible to
confirm that the Dead Lock System is set.

Cancelling the system

E00305301416

When  the  following  operation  is  performed,
the  doors  and  tailgate  will  unlock  and  the
Dead  Lock  System  will  be  simultaneously
cancelled.

The UNLOCK switch (D) on the remote
control switch is pressed.

The  driver’s  or  front  passenger’s  door
lock/unlock  switch  (E)  or  the  tailgate
OPEN  switch  (F)  is  pressed  while  you
are carrying the keyless operation key.

Except for vehicles equipped with the keyless
operation system

Dead Lock System*

3-28

OGAE18E1

Locking and unlocking

Vehicles equipped with the keyless operation system

Driver’s and front passenger’s door lock/unlock
switches*

Tailgate OPEN switch

NOTE

If  neither  a  door  nor  the  tailgate  is  opened
within  30  seconds  of  unlocking  (except  us-
ing the tailgate OPEN switch), the doors and
tailgate  are  automatically  relocked  and  the
Dead  Lock  System  is  simultaneously  set
again.

Even when it is not possible to use the key-
less entry system or keyless operation func-
tion to unlock the doors, it is possible to use
the  key  to  unlock  the  driver’s  door.  When
the  key  is  used  to  unlock  the  driver’s  door,
the Dead Lock System is cancelled for only
the driver’s door. If you wish to subsequent-
ly  unlock  all  other  doors,  perform  the  fol-
lowing operation.

•

Except for vehicles equipped with the
keyless operation system, turn the ignition
switch to the “ON” or “ACC” position.

•

For vehicles equipped with the keyless
operation system, put the operation mode
in ON or ACC.

It  is  possible  to  adjust  the  time  between
pressing the UNLOCK switch (D) on the re-
mote  control  switch  or  the  driver’s  or  front
passenger’s door lock/unlock switch (E) and
automatic  locking.  For  details,  please  con-
tact  a  MITSUBISHI  MOTORS  Authorized
Service Point.

NOTE

It  is  possible  to  lock  the  doors  and  tailgate
and  set  the  Dead  Lock  System  at  the  same
time with a single push of the LOCK switch
(A)  on  the  remote  control  switch,  the  driv-
er’s  or  front  passenger’s  door  lock/unlock
switch (B), or the tailgate LOCK switch (C).
For  details,  please  contact  a  MITSUBISHI
MOTORS Authorized Service Point.

Testing the system

E00305400104

Open  all  of  the  door  windows,  then  set  the
Dead  Lock  System.  (Refer  to  “Setting  the
system” on page 3-27.)
After  setting  the  Dead  Lock  System,  reach
into  the  vehicle  through  a  window  and  con-
firm  that  you  cannot  unlock  the  doors  using
the lock knobs.

NOTE

If you need advice on how to set the Dead
Lock System, please contact a MITSUBISHI
MOTORS Authorized Service Point.

Dead Lock System*

3-29

OGAE18E1

Locking and unlocking

“Child-protection” rear
doors

E00300900999

1- Lock
2- Unlock

Child protection helps prevent the rear doors
from  being  opened  accidentally  from  the  in-
side.
If  the  lever  is  set  to  the  locked  position,  the
rear  door  cannot  be  opened  using  the  inside
handle, but only with the outside handle.
If  the  lever  is  set  to  the  “Unlock”  position,
the  child  protection  mechanism  does  not
function.

CAUTION

When driving with a child in the rear seat,
please use the child protection to prevent ac-
cidental door opening which may cause an
accident.

Tailgate

E00301402836

WARNING

The  luggage  compartment  was  not  de-
signed  for  people  to  ride  in  it.  Do  not  let
passengers  ride  in  or  let  children  play  in
the luggage compartment. Riding or play-
ing in the luggage compartment could re-
sult in a serious accident.

It  is  dangerous  to  drive  with  the  tailgate
open,  since  carbon  monoxide  (CO)  gas
contained in engine exhaust gases can en-
ter the cabin.
You cannot see or smell CO. It can cause
unconsciousness and even death.
In  addition,  if  the  tailgate  opens  when
driving,  luggage  could  fall  onto  the  road
and cause an accident.

When  opening  and  closing  the  tailgate,
make sure that there are no people near-
by  and  that  there  is  sufficient  space  be-
hind  and  above  the  vehicle.  In  addition,
be  careful  not  to  hit  your  head  or  pinch
your hands, neck, etc.

WARNING

When there is a build up of snow or ice, it
should  be  removed  before  opening  the
tailgate.  If  you  open  the  tailgate  without
removing it, there is a possibility that the
tailgate  may  close  suddenly  due  to  the
weight of that snow or ice.

When  you  open  the  tailgate  make  sure
that  the  tailgate  is  opened  fully  and  re-
mains fully open. If you only open the tail-
gate  halfway  there  is  a  risk  that  the  tail-
gate may drop and slam shut. If you open
the  tailgate  while  your  vehicle  is  parked
on  an  incline  it  is  more  difficult  to  do  so
than on the flat and also it may drop and
slam shut.

CAUTION

Do not stand behind the exhaust pipe when
loading and unloading luggage. The heat
from the exhaust could lead to burns.

To avoid damage to the tailgate, make sure
the area above and behind the tailgate is
clear before opening it.

NOTE

Locking/unlocking with the central door
lock switch, the keyless entry system, or the
keyless operation function also locks/
unlocks the tailgate.

“Child-protection” rear doors

3-30

OGAE18E1

Locking and unlocking

To open

After unlocking, press the tailgate OPEN
switch (A) and lift the tailgate.

NOTE

If you do not open the tailgate immediately
after pressing the tailgate OPEN switch, the
tailgate can not be lifted. If this happens,
press the tailgate OPEN switch again and lift
the tailgate.

The tailgate cannot be opened when the bat-
tery is flat or disconnected.

To close

Pull the tailgate grip (A) downward as illus-
trated.  Gently  push  the  upper  gate  from  the
outside  with  enough  force  so  that  it  is  com-
pletely  closed.  Always  ensure  the  tailgate  is
securely closed.

CAUTION

Do not close the tailgate completely by hold-
ing the tailgate grip (A). Your hand or arm
could be pinched and personal injury could
result.

NOTE

Gas struts (B) are installed to support the
tailgate.

NOTE

To prevent damage or faulty operation.

•

Do not hold the gas struts when closing
the tailgate.

•

Also, do not push or pull the gas struts.

•

Do not attach any plastic material, tape,
etc., to the gas struts.

•

Do not tie string, etc., around the gas
struts.

•

Do not hang any object on the gas struts.

Inside tailgate release

E00303401354

The inside tailgate release is designed to pro-
vide a way to open the tailgate in the case of
a discharged battery.

Inside tailgate release

3-31

OGAE18E1

Locking and unlocking

The tailgate release lever (see illustration) is
mounted on the tailgate.

You and your family should familiarize your-
selves with the location and operation of the
tailgate release lever.

To open

1. Insert a straight blade (or minus) screw-

driver into the notch of the lid (A) and
pry gently to open the lid.

2. Move the lever (B) to open the tailgate.

3. Push out on the tailgate to open it.

WARNING

Always  keep  the  lid  (A)  on  the  tailgate
closed  when  driving  so  that  your  luggage
cannot  accidentally  bump  the  lever  (B)
and open the tailgate.

Security alarm system*

E00301502329

The security alarm system is for alerting the
surrounding area of suspicious behaviour to
prevent unlawful entry into the vehicle by op-
erating an alarm if a door, the tailgate or the
bonnet is opened when the vehicle has not
been unlocked using the keyless entry system
or the keyless operation function.
Also, the alarm will be activated if any of the
following occur.

Attempt to an unlawful moving of the
vehicle (the vehicle inclination detection
function)

Detection of a motion in the vehicle (the
interior intrusion detection function)

Disconnect the battery terminal.

The security alarm system is set to “active”.
When making changes to the settings, please
follow the procedure listed in the section ti-
tled “Changing the security alarm settings”
on page 3-34.

CAUTION

Do not modify or add parts to the security
alarm system.
Doing so could cause the security alarm to
malfunction.

NOTE

The alarm system will not be activated if the
doors and the tailgate have been locked us-
ing a key, the inside lock knob or the central
door lock switch (instead of the keyless en-
try system or the keyless operation func-
tion).

Security alarm system*

3-32

OGAE18E1

Locking and unlocking

NOTE

If the turn-signal lamps do not blink after the
locking and unlocking operation using the
keyless entry system or the keyless operation
function, the security alarm system may be
malfunctioning.
Have

the

vehicle

inspected

MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
If the confirmation function (blinking of the
turn-signal  lamps  by  locking  and  unlocking
the doors and the tailgate) is deactivated, the
turn-signal lamps do not blink after the lock-
ing and unlocking operation.
For  information  on  the  confirmation  func-
tion, refer to “Keyless entry system” on pa-
ges  3-04,  3-22  and  “To  operate  using  the
keyless operation function” on page 3-10.

The security alarm system could be activated
in the following situations.

•

Using a car wash

•

Taking the vehicle on a ferry

•

Parking in an automated car park

•

Leaving someone or a pet in the vehicle

•

Leaving a window open

•

Leaving an unstable object such as a stuf-
fed toy or accessory in the vehicle

•

Suffering a continuous impact or vibra-
tion by hail, thunder, etc.

According  to  the  situations,  deactivate  the
vehicle  inclination  detection  function  and
the interior intrusion detection function.
Refer  to  “To  deactivate  the  vehicle  inclina-
tion detection function and the interior intru-
sion detection function” on page 3-37.

NOTE

The sensitivity of the interior intrusion de-
tection function can be adjusted. For details,
please contact a MITSUBISHI MOTORS
Authorized Service Point.

The security alarm has four

modes:

System preparation mode (ap-

prox. 20 seconds)

(The buzzer sounds intermittently and the se-
curity indicator (A) blinks.)

The  system  preparation  time  extends  from
the  point  at  which  all  of  the  doors  and  the
tailgate  are  locked  by  pressing  the  LOCK
switch  on  the  remote  control  switch  or  the
keyless  operation  function  to  the  point  at
which  the  system  armed  mode  goes  into  ef-
fect.
During this time, it is possible to temporarily
open a door or the tailgate without using the
keyless entry system or the keyless operation
function  and  without  causing  the  alarm  to
sound  (for  example,  when  you  forget  some-
thing inside the vehicle or realize that a win-
dow is open).

System armed mode

(The  security  indicator  continues  to  blink
with  the  indicator’s  reduced  lit-up  duration
time.)
Once the system preparation mode has ended,
the system armed mode starts.
If  an  unlawful  opening  of  any  of  the  doors,
tailgate or bonnet is detected during the sys-
tem armed mode, the alarm will be activated
to  warn  people  around  the  vehicle  of  an  ab-
normal condition.
Also, if unlawful moving of the vehicle is at-
tempted or a vehicle intrusion is detected, the
alarm will be activated.

Security alarm system*

3-33

OGAE18E1

Locking and unlocking

Alarm activation

The turn-signal lamps blink and the siren
sounds for approximately 30 seconds.
Refer to “Alarm activation” on page 3-38.

NOTE

The alarm will resume if unlawful actions
are taken again, even if the alarm has stop-
ped.

System cancellation

It  is  possible  to  cancel  the  system  activation
during  the  system  preparation  mode  or  the
system armed mode.
In addition, it is possible to cancel the alarm
once it has been activated.
Refer  to  “Cancelling  the  system”  on  page
3-37, “Cancelling the alarm” on page 3-39.

NOTE

When lending the vehicle to another person
or  allowing  the  vehicle  to  be  driven  by
someone who is unfamiliar with the security
alarm  system,  be  sure  to  give  the  person  a
proper explanation of the security alarm sys-
tem.
If a person who is unfamiliar with the securi-
ty  alarm  system  accidentally  unlocked  the
vehicle,  causing  the  alarm  to  sound,  the
alarm would be a nuisance to people nearby.

Changing the security alarm

settings

E00301601440

It is possible to set the security alarm to the
“active” mode or “inactive” mode.
Follow the procedure below.

1. Except for vehicles equipped with the

keyless operation system, remove the
key from the ignition switch. For vehi-
cles equipped with the keyless operation
system, put the operation mode in OFF.

2. Place the lamp switch in the “OFF” posi-

tion, and leave the driver’s door open.

3. Pull the windscreen wiper and washer

switch  towards  you  and  hold  it  there.
(Since  the  ignition  switch  is  in  the
“LOCK” position or the operation mode
is  in  OFF,  washer  fluid  will  not  be
sprayed.)

Security alarm system*

3-34

OGAE18E1

Locking and unlocking

4. After approximately 10 seconds, the

buzzer  will  make  a  sound.  Keep  the
windscreen  wiper  and  washer  switch
pulled  towards  you.  (If  the  windscreen
wiper  and  washer  switch  was  released,
the  setting  change  mode  would  be  can-
celled. To start over, perform the proce-
dure again from step 3.)

5. When the buzzer stops, with the wind-

screen wiper and washer switch still
pulled towards you, press the UNLOCK
switch (A) on the remote control switch
to select the security alarm settings
mode.

Except for vehicles equipped with the keyless
operation system

Vehicles equipped with the keyless operation system

The settings mode can be toggled by
pressing the UNLOCK switch. The
mode can be confirmed from the number
of times the buzzer sounds.

Number of

times the

buzzer
sounds

Security alarm settings

mode

Alarm inactive

Alarm active

6. Any of the following operations can be

used to terminate the system settings
change mode.

• Releasing the windscreen wiper and

washer switch.

• Closing the driver’s door.

• Inserting the key into the ignition

switch (except for vehicles equip-
ped with the keyless operation sys-
tem).

• Putting the operation mode in ON

or ACC. (vehicles equipped with
the keyless operation system)

• Placing the lamp switch in any posi-

tion other than “OFF”.

• Allowing 30 seconds to pass with-

out making any changes to the set-
tings.

NOTE

If anything with regard to making changes to
the security alarm system settings is hard to
understand,

please

consult

your

MITSUBISHI MOTORS Authorized Serv-
ice Point.

Avoid leaving valuable items inside the ve-
hicle even when the security alarm system
has been set to the “active” mode.

Setting the system

E00301702448

Follow the procedure below to set the system
to the system armed mode.

1. Except for vehicles equipped with the

keyless operation system, remove the
key from the ignition switch. For vehi-
cles equipped with the keyless operation
system, put the operation mode in OFF.

Security alarm system*

3-35

OGAE18E1

Locking and unlocking

2. Exit the vehicle and close all of the

doors, tailgate and bonnet.

3. Press the LOCK switch (A) on the re-

mote control switch of the keyless entry
system  or  the  keyless  operation  system,
the  driver’s  or  front  passenger’s  door
lock/unlock  switch  (B),  or  the  tailgate
LOCK switch (C) in order to lock all the
doors and the tailgate.

Except for vehicles equipped with the keyless
operation system

Vehicles equipped with the keyless operation system

Driver’s and front passenger’s door look/unlock switches*

Tailgate LOCK switch*

By locking the vehicle using the keyless
entry system or the keyless operation
function, the system preparation mode is
activated.
The buzzer makes an intermittent beep-
ing sound and the security indicator (D)

in the audio panel blinks for confirma-
tion.

NOTE

The  system  preparation  mode  is  not  activa-
ted  when  the  doors  and  the  tailgate  have
been  locked  using  a  method  other  than  the
keyless entry system or the keyless operation
function (namely a key, the inside lock knob
or the central door lock switch).

If  the  bonnet  is  open,  the  security  indicator
illuminates,  and  the  system  does  not  enter
the system preparation mode.
When the bonnet is closed, the system enters
the  system  preparation  mode,  and  after  ap-
proximately  20  seconds  the  system  enters
the system armed mode.

Security alarm system*

3-36

OGAE18E1

Locking and unlocking

4. After approximately 20 seconds, the

buzzer stops, and when the blinking of
the security indicator starts to slow
down, the system armed mode goes into
effect.
The security indicator continues to blink
during the system armed mode.

NOTE

The security alarm system can be activated
when people are riding inside the vehicle or
when the windows are open. To prevent ac-
cidental activation of the alarm, do not set
the system to the system armed mode while
people are riding in the vehicle.

Avoid leaving valuable items inside the ve-
hicle even when the security alarm system
has been set to the “active” mode.

To deactivate the vehicle incli-
nation detection function and
the interior intrusion detection
function

E00312101487

The  vehicle  inclination  detection  function
and  the  interior  intrusion  detection  function
can  be  deactivated  when  parking  in  automa-
ted car parks, when leaving pets in the vehi-
cle or when leaving the vehicle with the win-
dows slightly open.

1. Except for vehicles equipped with the

keyless operation system, remove the
key from the ignition switch. For vehi-
cles equipped with the keyless operation
system, put the operation mode in OFF.

2. Raise and hold the wiper and washer

switch to the “MIST” position for ap-
proximately 3 seconds. The buzzer will
sound twice and the function will be de-
activated.

To activate the function again, raise and hold
the wiper and washer switch to the “MIST”
position for approximately 3 seconds.
The buzzer will sound once and the function
will be activated.

NOTE

The function will be activated again if the
following operation is performed.

•

If the doors and the tailgate are unlocked
using the keyless entry system or the key-
less operation function.

•

If the ignition switch is turned to the
“ON” or “ACC” position (except for vehi-
cles equipped with the keyless operation
system).

•

If the operation mode is put in ON or
ACC (vehicles with the keyless operation
system).

Cancelling the system

E00301802003

The following methods can be used to cancel
the system when it is in the system prepara-
tion mode or the system armed mode.

Pressing the UNLOCK switch on the re-
mote control switch.

Turning the ignition switch to the “ON”
position (except for vehicles equipped
with the keyless operation system).

Putting the operation mode in ON (vehi-
cles equipped with the keyless operation
system).

Opening any one of the doors or the tail-
gate, or inserting the key into the igni-
tion switch (except for vehicles equipped
with the keyless operation system) when
the system is in the system preparation
mode.

Security alarm system*

3-37

OGAE18E1

Locking and unlocking

Holding  the  keyless  operation  key  and
pressing the driver’s or front passenger’s
door  lock/unlock  switch,  or  the  tailgate
OPEN  switch  to  unlock  the  doors  and
the  tailgate  (vehicles  equipped  with  the
keyless operation system).

NOTE

If the bonnet is opened during the system
preparation mode, the system preparation
condition is suspended.
The system returns to the system preparation
mode when the bonnet is closed.

If the battery terminals are disconnected
while the system is in the system preparation
mode, the memory will be erased.

It is possible to register up to 8 remote con-
trol  switches  for  the  keyless  entry  system
and  4  remote  control  switches  for  the  key-
less operation system.
As long as they are registered, any of the re-
mote  control  switches,  other  than  the  one
used  to  activate  the  system,  can  be  used  to
cancel the system.
If  you  want  to  register  additional  remote
control

switches,

please

contact

MITSUBISHI MOTORS Authorized Serv-
ice Point.

NOTE

The activation distance for the keyless entry
system is approximately 4 m.
If it is not possible to lock or unlock the ve-
hicle  by  pressing  the  switch  at  the  correct
distance or the security alarm system cannot
be set or cancelled using the switch, the bat-
tery may need to be replaced.
For  further  information,  please  consult  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.
If  you  replace  the  battery  yourself,  refer  to
“Procedure  for  replacing  the  remote  control
switch battery” on pages 3-06, 3-24.

If  the  UNLOCK  switch  on  the  remote  con-
trol  switch,  or  the  driver’s  or  front  passen-
ger’s door lock/unlock switch is pressed and
no  door  or  the  tailgate  is  opened  within  30
seconds, the doors and the tailgate will auto-
matically  relock.  In  this  case  as  well,  the
system preparation mode will go into effect.

The  time  between  pressing  the  UNLOCK
switch  on  the  remote  control  switch,  or  the
driver’s  or  front  passenger’s  door  lock/
unlock switch and automatic locking can be
adjusted.  Please  consult  a  MITSUBISHI
MOTORS Authorized Service Point.

Alarm activation

E00301902310

When  the  system  is  in  the  system  armed
mode, the alarm will be activated as follows
if  the  vehicle  is  unlocked  or  if  any  of  the
doors,  tailgate  or  bonnet  is  opened  using  a
method other than the keyless entry system or
the keyless operation function.

1. The alarm will be activated for approxi-

mately 30 seconds.
The turn-signal lamps will blink, and the
siren will sound intermittently.

2. The alarm will resume if unlawful ac-

tions are taken again, even if the alarm
has stopped.

Security alarm system*

3-38

OGAE18E1

Locking and unlocking

NOTE

During an alarm operation, the alarm is dis-
played on the information screen in the mul-
ti-information display.
Type 1

Type 2

Cancelling the alarm

E00302000428

It is possible to halt the activation of an alarm
using the following methods:

Pressing the LOCK or UNLOCK switch
on the remote control switch.
(After pressing the LOCK switch, the
vehicle will lock if all the doors and the
tailgate are closed, after which the sys-
tem preparation mode will once again go
into effect.)

Turning the ignition switch to the “ON”
position (except for vehicles equipped
with the keyless operation system).

Putting the operation mode in ON (vehi-
cles equipped with the keyless operation
system).

Holding the keyless operation key and
locking and unlocking the doors and the
tailgate using the keyless operation func-
tion (vehicles equipped with the keyless
operation system).

NOTE

When the ignition switch is turned to the
“ON” position or the operation mode is put
in ON, the buzzer sounds 4 times. This oper-
ation indicates that the alarm was activated
while the vehicle was parked.
Please check the inside of the vehicle to con-
firm that nothing was stolen.

Even if the battery is disconnected, the alarm
activation memory will not be erased.

Electric window control

E00302200521

The electric windows can only be operated
with the ignition switch in the “ON” position
or the operation mode in ON.

WARNING

Before operating the electric window con-
trol, make sure that nothing can get trap-
ped (head, hand, finger, etc.).

Never leave the vehicle without removing
the key.

Never leave a child (or other person who
might not be capable of safe operation of
the electric window control) in the vehicle
alone.

The child may tamper with the switch at
the risk of its hands or head being trap-
ped in the window.

Electric window control switch

E00302303435

Each door window opens or closes while the
corresponding switch is operated.

Driver’s switches (LHD)

Electric window control

3-39

OGAE18E1

Locking and unlocking

Driver’s switches (RHD)

1- Driver’s door window
2- Front passenger’s door window
3- Rear left door window
4- Rear right door window
5- Lock switch

Driver’s switches

The switches can be used to operate all door
windows. A window can be opened or closed
by operating the corresponding switch.
Press the switch down to open the window,
and pull up the switch to close it.
If the switch for the driver’s window is fully
pressed down/pulled up, the door window au-
tomatically opens/closes completely.
If you want to stop the window movement,
operate the switch lightly in the reverse direc-
tion.

Passenger’s switches

The passenger’s switches can be used to op-
erate the corresponding passenger’s door
windows. Press the switch down for opening
the window, and pull up the switch for clos-
ing it.

NOTE

Repeated operation with the engine stopped
will run down the battery. Operate the elec-
tric window switches only while the engine
is running.

The rear door windows only open halfway.

Lock switch

E00303101032

When this switch is operated, the passenger’s
switches cannot be used to open or close the
door windows and the driver’s switch cannot
open or close any door windows other than
the driver’s window.

To unlock, press it once again.

1- Lock
2- Unlock

WARNING

A child may tamper with the switch at the
risk of its hands or head being trapped in
the window. When driving with a child in
the vehicle, please press the window lock
switch to disable the passenger’s switches.

Timer function

E00302400800

The door windows can be opened or closed
for 30 seconds after the engine is stopped.
However, once the driver’s door or the front
passenger’s door is opened, the windows can-
not be operated.

Electric window control

3-40

OGAE18E1

Locking and unlocking

Safety mechanism (driver’s

door window only)

E00302501895

If  a  hand  or  head  is  trapped  in  the  closing
window, it will lower automatically.
Nonetheless,  make  sure  that  nobody  puts
their  head  or  hand  out  of  the  window  when
closing the driver’s door window.
The lowered window will become operation-
al after a few seconds.

WARNING

If the battery terminals are disconnected
or the fuse for electric window is replaced,
the safety mechanism will be cancelled.
If a hand or head got trapped, a serious
injury could result.

CAUTION

The safety mechanism is cancelled just be-
fore the window is fully closed. This allows
the window to close completely. Therefore
be especially careful that no fingers are trap-
ped in the window.

The safety mechanism is deactivated while
the switch is pulled up. Therefore be espe-
cially careful that fingers are not trapped in
the door window opening.

NOTE

The safety mechanism can be activated if the
driving conditions or other circumstances
cause the driver’s door window to be subjec-
ted to a physical shock similar to that caused
by a trapped hand or head.

If  the  battery  terminals  are  disconnected  or
the fuse for electric window is replaced, the
safety  mechanism  will  be  cancelled  and  the
door  window  will  not  automatically  open/
close completely.
If  the  window  is  open,  repeatedly  raise  the
driver’s  door  window  switch  until  the  win-
dow has been fully closed.
Following  this,  release  the  switch,  raise  the
switch once again and hold it in this condi-
tion  for  at  least  1  second,  then  release  it.
You should now be able to operate the driv-
er’s door window in the normal fashion.

Sunshade*

E00302801407

WARNING

Before operating the sunshade, make sure
that nothing can get trapped (head, hand,
finger, etc.).

Never leave the vehicle without removing
the key.

Never leave a child (or other person who
might not be capable of safe operation of
the sunshade switch) in the vehicle alone.

WARNING

Do not bring your head, hand, finger, etc.
near the opening edge of the sunshade re-
ceptacle while the vehicle is in motion.
It may cause injury to your head, hand,
finger, etc. in the event of sudden braking.

CAUTION

Do not place heavy luggage on the panoram-
ic glass roof. Doing so could damage the
glass roof.

Do  not  hang  heavy  luggage  from,  allow  a
person  to  hang  onto,  or  apply  any  other
strong  force  to  the  opening  of  the  sunshade
receptacle  or  the  parts  between  the  ceiling
and the sunshade opening on either side. Do-
ing so could damage the sunshade.

NOTE

Release the switch as soon as the sunshade
reaches the fully open or fully closed posi-
tion.

If  the  sunshade  does  not  operate  when  the
sunshade  switch  is  operated,  release  the
switch and check whether something is trap-
ped  by  the  sunshade.  If  nothing  is  trapped,
we  recommend  you  to  have  the  sunshade
checked.

Operating the sunshade repeatedly with the
engine stationary will run down the battery.
Operate the sunshade while the engine is
running.

Sunshade*

3-41

OGAE18E1

Locking and unlocking

Mitsubishi ASX (2018 year). Instruction - part 4
