Mitsubishi ASX (2018 year). Instruction

NOTE

Even  if  the  keyless  operation  key  is  within
70  cm  of  the  driver’s  or  front  passenger’s
door lock/unlock switch, the tailgate LOCK
switch  or  the  tailgate  OPEN  switch,  if  the
key is near to the ground or high up, the sys-
tem may not operate.

If the keyless operation key is within the op-
erating range, even someone not carrying the
key can lock and unlock the doors and tail-
gate by pressing the driver’s or front passen-
ger’s door lock/unlock switch, the tailgate
LOCK switch or the tailgate OPEN switch.

Operating range for starting the
engine and changing the opera-
tion mode

E00306300243

The operating range is the interior of the ve-
hicle.

*: Forward direction

: Operating range

NOTE

Even if it is within the operating range, if the
keyless  operation  key  is  in  a  small  item
holder  such  as  the  glove  box,  on  top  of  the
instrument panel, door pocket or in the lug-
gage  area,  it  may  be  impossible  to  start  the
engine and change the operation mode.

If you are too close to the door or door win-
dow, the engine may start even though the
keyless operation key is outside the vehicle.

To operate using the keyless

operation function

E00305802649

Locking the doors and tailgate

When you are carrying the keyless operation
key, if you press the driver’s or front passen-
ger’s door lock/unlock switch (A), or the tail-
gate LOCK switch (B) within the operating
range, the doors and the tailgate are locked.
The turn-signal lamps will blink once.
Also refer to “Locking and unlocking: Doors,
Central door locks, tailgate” on pages 3-25,
3-26 and 3-30.

Driver’s and front passenger’s door lock/unlock switches

Keyless operation system*

3-10

OGAE18E1

Locking and unlocking

Tailgate switches

NOTE

For vehicles equipped with the mirror retrac-
tor switch, the outside rear-view mirrors au-
tomatically retract when all the doors and
tailgate are locked using the keyless opera-
tion function.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 6-10.

With a vehicle that has a Dead Lock System,
pressing  the  driver’s  or  front  passenger’s
door  lock/unlock  switch  (A),  or  the  tailgate
LOCK  switch  (B)  two  times  in  succession
causes the Dead Lock System to be set. (Re-
fer to “Setting the system” on page 3-27).

The keyless operation function does not op-
erate under the following conditions:

•

The keyless operation key is inside the
vehicle.

•

A door or the tailgate is open or ajar.

•

The operation mode is not in OFF.

NOTE

The tailgate OPEN switch (C) can be used to
confirm that the vehicle is locked properly.
Press the tailgate OPEN switch within ap-
proximately 3 seconds of locking the vehi-
cle.
If the tailgate OPEN switch is pressed 3 sec-
onds or more after the vehicle is locked, the
doors and the tailgate are unlocked.

The time within which locking confirmation
is possible can be adjusted. For further infor-
mation, please contact your MITSUBISHI
MOTORS Authorized Service Point.

Unlocking the doors and tail-

gate

When you are carrying the keyless operation
key, if you press the driver’s or front passen-
ger’s door lock/unlock switch (A), or the tail-
gate  OPEN  switch  (B)  within  the  operating
range,  all  the  doors  and  the  tailgate  are  un-
locked.
If  the  front  room  lamp  switch  is  in  the
“DOOR”  position  or  the  rear  room  lamp
switch (except for vehicles equipped with the
sunshade) is in the middle (•) position at this
time, the room lamp will turn on for 15 sec-
onds. The turn-signal lamps will blink twice.

If the driver’s or front passenger’s door lock/
unlock switch is pressed and any of the doors
or tailgate is not opened within approximate-
ly 30 seconds, relocking will automatically
occur. Also refer to “Locking and unlocking:
Doors, Central door locks, tailgate” on pages
3-25, 3-26 and 3-30.

Driver’s and front passenger’s door lock/unlock switches

Tailgate OPEN switch

Keyless operation system*

3-11

OGAE18E1

Locking and unlocking

NOTE

For vehicles equipped with the mirror retrac-
tor switch, the outside rear-view mirrors au-
tomatically extend when all the doors and
tailgate are unlocked using the keyless oper-
ation function.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 6-10.

Except  for  vehicles  equipped  with  a  Dead
Lock System, the keyless operation function
can be set so that only the driver’s door un-
locks  when  the  driver’s  door  lock/unlock
switch is pressed.
If  the  keyless  operation  function  is  set  to
work  as  described  above,  all  the  doors  and
the  tailgate  unlock  when  the  driver’s  door
lock/unlock  switch  is  pressed  two  times  in
succession.
Refer to “Setting of door and tailgate unlock
function” on page 3-24.

The keyless operation function does not op-
erate under the following conditions:

•

The keyless operation key is inside the
vehicle.

•

A door or the tailgate is open or ajar.

•

The operation mode is not in OFF.

The doors and the tailgate cannot be un-
locked by using the tailgate OPEN switch
for about 3 seconds after locking.

The time within which locking confirmation
is possible can be adjusted. For further infor-
mation, please contact your MITSUBISHI
MOTORS Authorized Service Point.

NOTE

The  time  between  unlocking  and  automatic
locking  can  be  adjusted.  Consult  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

Operation confirmation when locking and
unlocking
Operation can be confirmed as shown below.
However, the room lamp will only illuminate
if the front room lamp switch is in the
“DOOR” position or the rear room lamp
switch (except for vehicles equipped with the
sunshade) is in the middle (•) position.

When lock-
ing:

The turn-signal lamps will
blink once.

When un-
locking:

The room lamp illuminates
for approximately 15 sec-
onds, the turn-signal lamps
blink twice.

NOTE

Functions can be modified as stated below.
For further information, please contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.

•

Set the confirmation function (blinking of
the turn-signal lamps) to operate only
when the vehicle is locked or only when
the vehicle is unlocked.

NOTE

•

Disable the operation confirmation func-
tion (blinking of the turn-signal lamps).

•

Change the number of blinks for the oper-
ation confirmation function (blinks of the
turn-signal lamps).

Operation of the Dead Lock

System

With a vehicle that has a Dead Lock System,
it is possible to set the Dead Lock System us-
ing  the  driver’s  or  front  passenger’s  door
lock/unlock  switch,  or  the  tailgate  LOCK
switch.
(Refer  to  “Dead  Lock  System”  on  page
3-27.)

Electronic immobilizer (Anti-

theft starting system)

E00306401603

The  electronic  immobilizer  has  been  de-
signed  to  significantly  reduce  the  possibility
of vehicle theft. The purpose of the system is
to immobilize the vehicle if an invalid start is
attempted.  A  valid  start  attempt  can  only  be
achieved (subject to certain conditions) using
a keyless operation system “registered” to the
immobilizer system.
All of the keys provided with your new vehi-
cle have been programmed into the vehicle’s
electronics. Refer to “Engine switch” on page
3-13.

Keyless operation system*

3-12

OGAE18E1

Locking and unlocking

NOTE

If the engine does not start, contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.

If  you  lose  one  of  the  keyless  operation
keys,  contact  a  MITSUBISHI  MOTORS
Authorized  Service  Point  as  soon  as  possi-
ble.
To obtain a replacement or extra spare key,
take  your  vehicle  and  all  remaining  keys  to
your  MITSUBISHI  MOTORS  Authorized
Service Point. All the keys have to be re-reg-
istered  in  the  immobilizer  computer  unit.
The immobilizer can register up to 4 differ-
ent keys.

Engine switch

E00306500753

In order to prevent theft, the engine will not
start unless a preregistered keyless operation
key is used. (Engine immobilizer function)
If you are carrying the keyless operation key,
you can start the engine.

Also refer to “Starting and driving: Starting
the engine” on pages 6-14 and 6-15.

CAUTION

The  indication  lamp  (A)  will  flash  orange
when  there  is  a  problem  or  malfunction  in
the keyless operation system. Never drive if
the  indication  lamp  on  the  engine  switch  is
flashing  orange.  Immediately  contact  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

If the engine switch operation is not smooth
and feels like it is sticking, do not operate
the

switch.

Immediately

contact

MITSUBISHI MOTORS Authorized Serv-
ice Point.

NOTE

When operating the engine switch, press the
switch  all  the  way  in.  If  the  switch  is  not
fully pressed, the engine may not start or the
operation  mode  may  not  change.  If  the  en-
gine  switch  is  pressed  correctly,  there  is  no
need to hold the engine switch down.

Operation mode of the engine

switch and its function

OFF
The indication lamp on the engine switch
turns off. The operation mode cannot be put
in OFF when the selector lever is in any posi-
tion other than the “P” (PARK) position (A/T
or CVT).

ACC
The audio system and other electric devices
can be operated.
The indication lamp on the engine switch il-
luminates orange.

ON
All electric devices can be operated.
The indication lamp on the engine switch il-
luminates green.
The indication lamp turns off when the en-
gine is running.

Keyless operation system*

3-13

OGAE18E1

Locking and unlocking

NOTE

Your vehicle is equipped with an electronic
immobilizer. To start the engine, the ID code
transmitted by the transponder inside the key
must match the code registered in the immo-
bilizer computer.
(Refer to “Electronic immobilizer (Anti-theft
starting system)” on page 3-12.)

Changing the operation mode

E00312200133

If you press the engine switch without de-
pressing the brake pedal (A/T or CVT) or the
clutch pedal (M/T), you can change the oper-
ation mode in the order of OFF, ACC, ON,
OFF.

CAUTION

When the engine is not running, put the op-
eration mode in OFF. Leaving the operation
mode in ON or ACC for a long time when
the engine is not running may cause the bat-
tery to be discharged, making it impossible
to start the engine, lock and unlock the steer-
ing wheel.

When  the  battery  is  disconnected,  the  cur-
rent operation mode is memorized. After re-
connecting the battery, the memorized mode
is selected automatically. Before disconnect-
ing  the  battery  for  repair  or  replacement,
make sure to put the operation mode in OFF.
Be  careful  if  you  are  not  sure  which  opera-
tion mode the vehicle is in when the battery
is run down.

The operation mode cannot be changed from
OFF to ACC or ON if the keyless operation
key is not detected to be in the vehicle. Refer
to “Keyless operation system: Operating
range for starting the engine and changing
the operation mode” on page 3-10.

ACC power auto-cutout func-
tion

E00312300088

After  approximately  30  minutes  has  elapsed
with  the  operation  mode  in  ACC,  the  func-
tion automatically cuts out the power for the
audio  system  and  other  electric  devices  that
can be operated with that mode.

When the engine switch is pressed while the
operation mode is in ACC, the power is sup-
plied again to those devices.

NOTE

It is possible to modify functions as follows:

•

The time until the power cuts out can be
changed to approximately 60 minutes.

•

The ACC power auto-cutout function can
be deactivated.

For details, consult a MITSUBISHI
MOTORS Authorized Service Point.

Warning activation

E00305900486

In  order  to  prevent  vehicle  theft  or  the  acci-
dental operation of the keyless operation sys-
tem, the buzzer and the display on the infor-
mation  screen  in  the  multi-information  dis-
play are used to alert the driver.
If  a  warning  is  activated,  always  check  the
vehicle  and  the  keyless  operation  key.  The
warning is also displayed if there is a fault in
the keyless operation system.
If  any  of  the  following  warnings  are  activa-
ted,  please  contact  a  MITSUBISHI
MOTORS Authorized Service Point.

There is a fault in the keyless
operation system.

Keyless operation system*

3-14

OGAE18E1

Locking and unlocking

The battery in the keyless opera-
tion system key has worn out.

Put  the  operation  mode  in  OFF
and then start the engine again.
If  the  warning  is  not  cancelled,
there  is  a  fault  in  the  electronic
immobilizer  (Anti-theft  starting
system).
Please  contact  a  MITSUBISHI
MOTORS  Authorized  Service
Point.

In the following cases, a warning is activated,
but it can be cancelled if the correct actions
are followed.

The ID codes for the keyless operation
key and vehicle do not match.

You could be carrying another
keyless operation key with a dif-
ferent code, or the keyless oper-
ation key could be outside the
operating range.

Refer to “Keyless operation key
take-out monitoring system” on
page 3-15.

Even though you press the driver’s or
front passenger’s door lock/unlock
switch, or the tailgate LOCK switch, the
doors and tailgate are not locked.

Refer to “Key lock-in preven-
tion system” on page 3-15.

Refer to “Door ajar prevention
system” on page 3-16.

Refer to “Operation mode OFF
reminder system” on page
3-16.

Keyless operation key take-out
monitoring system

E00308000420

When  the  vehicle  is  parked  with  the  opera-
tion  mode  in  any  mode  other  than  OFF,  if
you  close  the  door  after  opening  any  of  the
doors  and  taking  the  keyless  operation  key
out of the vehicle, a warning displays and the
buzzer sounds 4 times.

NOTE

If you take the keyless operation key out of
the vehicle through a window without open-
ing a door, the keyless operation key take-
out monitoring system does not operate.

NOTE

It  is  possible  to  change  the  setting  to  make
the  keyless  operation  key  take-out  monitor-
ing  system  operate  if  you  take  the  keyless
operation key out from the vehicle through a
window without opening a door. For further
information,

please

contact

your

MITSUBISHI MOTORS Authorized Serv-
ice Point.

Even  if  you  have  the  keyless  operation  key
within the engine start operating range, if the
keyless  operation  key  and  vehicle  ID  codes
cannot  be  matched,  for  example  due  to  the
ambient  environment  or  electromagnetic
conditions, the warning may be activated.

Key lock-in prevention system

E00308100391

Keyless operation system*

3-15

OGAE18E1

Locking and unlocking

When  the  operation  mode  is  in  OFF,  if  you
close  all  the  doors  and  the  tailgate  with  the
keyless  operation  key  left  in  the  vehicle  and
you  try  to  lock  the  doors  and  tailgate  by
pressing  the  driver’s  or  front  passenger’s
door  lock/unlock  switch,  or  the  tailgate
LOCK  switch,  a  warning  is  issued  with  the
warning  display  and  the  buzzer  buzzing  for
approximately 3 seconds and you cannot lock
the doors and tailgate.

NOTE

Make sure you have the keyless operation
key with you before locking the doors. Even
if you leave the keyless operation key inside
the vehicle, it is possible that the doors will
lock depending on the surrounding environ-
ment and wireless signal conditions.

Door ajar prevention system

E00308200347

When  the  operation  mode  is  in  OFF,  if  you
try to lock the doors and tailgate by pressing
the  driver’s  or  front  passenger’s  door  lock/
unlock  switch,  or  the  tailgate  LOCK  switch
with one of the doors or the tailgate not com-
pletely  closed,  a  warning  is  issued  with  the
warning  display  and  the  buzzer  buzzing  for
approximately 3 seconds and you cannot lock
the doors and tailgate.

Operation mode OFF reminder
system

E00308300348

When the operation mode is in any mode oth-
er than OFF, if you close all the doors and the
tailgate then try to lock the doors and tailgate
by  pressing  the  driver’s  or  front  passenger’s
door  lock/unlock  switch,  or  the  tailgate
LOCK  switch,  a  warning  is  issued  with  the
warning  display  and  the  buzzer  buzzing  for
approximately 3 seconds and you cannot lock
the doors and tailgate.

Steering wheel lock

E00306801346

To lock

After pressing the engine switch and opera-
tion mode in OFF, when driver’s door is
opened, the steering wheel is locked.

CAUTION

If the engine is stopped while driving, do not
open  a  door  or  press  the  LOCK  switch  on
the  remote  control  switch  until  the  vehicle
stops  in  a  safe  place.  This  could  cause  the
steering wheel to lock, making it impossible
to operate the vehicle.

NOTE

When the following operation is performed
with the operation mode in OFF and the se-
lector lever in the “P” (PARK) position, the
steering wheel is locked.

•

Open or close one of the doors (except the
tailgate).

•

Lock all doors and the tailgate with the
keyless entry system or the keyless opera-
tion function.

Keyless operation system*

3-16

OGAE18E1

Locking and unlocking

NOTE

When the driver’s door is opened while the
steering wheel does not lock, a warning dis-
play will appear and the buzzer sounds to
alert the steering wheel is unlocked.

To unlock

The following methods can be used to unlock
the steering wheel.

Put the operation mode in ACC.

Start the engine.

CAUTION

Carry the key with you when leaving the ve-
hicle.

If your vehicle needs to be towed, perform
the following operation to unlock the steer-
ing wheel.

•

On vehicles with M/T, put the operation
mode in ACC or ON.

•

On vehicles with A/T or CVT, put the op-
eration mode in ON.

NOTE

When  the  steering  wheel  does  not  unlock,
the  warning  will  be  displayed  on  the  infor-
mation  screen  in  the  multi-information  dis-
play.  Press  the  engine  switch  again  while
moving the steering wheel slightly.

When  the  steering  wheel  lock  is  abnormal,
the  warning  display  will  appear  and  the  in-
ner  buzzer  will  sounds.  Put  the  operation
mode in OFF and then press the lock switch
of  the  keyless  operation  key.  After  that,
press  the  engine  switch.  If  the  warning  is
then  not  cancelled,  have  your  vehicle
checked  by  a  MITSUBISHI  MOTORS  Au-
thorized Service Point.

NOTE

If there is a fault in the steering wheel lock,
the warning display will appear and the in-
ner buzzer will sound. Immediately stop the
vehicle in a safe place and contact the near-
est MITSUBISHI MOTORS Authorized
Service Point.

Starting and stopping the en-

gine

E00306901523

Tips for starting

The operation mode can be in any mode
to start the engine.

Keyless operation system*

3-17

OGAE18E1

Locking and unlocking

The starter motor will be turning for up
to  approximately  15  seconds  if  the  en-
gine switch is released at once. Pressing
the engine switch again while the starter
motor is still turning will stop the starter
motor. The starter motor will be turning
for  up  to  approximately  30  seconds
while the engine switch is pressed.
If  the  engine  does  not  start,  wait  for  a
while  and  then  attempt  to  start  the  en-
gine  again.  Trying  repeatedly  with  the
starter  motor  still  running  will  damage
the starter mechanism.

WARNING

Never run the engine in a closed or poorly
ventilated area any longer than is needed
to move your vehicle in or out of the area.
Carbon monoxide gases are odourless and
can be fatal.

CAUTION

Never attempt to start the engine by pushing
or pulling the vehicle.

Do not run the engine at high rpm or drive
the vehicle at high speed until the engine has
had a chance to warm up.

Starting the engine (petrol-pow-
ered vehicles)

E00307002111

The starting procedure is as follows:

1. Fasten the seat belt.
2. Make sure the parking brake is applied.
3. Press and hold the brake pedal down

firmly with your right foot.

NOTE

After the engine has not started for a while,
the brake pedal effort needed to start the en-
gine may become greater.
If this occurs, depress the brake pedal more
firmly than usual.

4. Fully depress the clutch pedal (M/T).
5. On vehicles equipped with M/T, place

the  gearshift  lever  in  the  “N”  (Neutral)
position.
On  vehicles  equipped  with  CVT,  make
sure  the  selector  lever  is  in  the  “P”
(PARK) position.

Vehicles with CVT

Vehicles with M/T

NOTE

The engine can only be started when the se-
lector  lever  is  in  the  “P”  (PARK)  or  “N”
(NEUTRAL) position (CVT).
For safety reasons, the engine should be star-
ted  when  the  selector  lever  is  in  the  “P”
(PARK)  position  in  which  the  driving
wheels lock.

6. Press the engine switch.
7. Make sure that all warning lamps are

functioning properly.

NOTE

Minor noises may be heard on engine start-
up. These will disappear as the engine
warms up.

When it is difficult to start the engine
After several attempts, you may experience
that the engine still does not start.

1. Make sure that all electric devices, such

as lamps, air conditioning blower and
rear window demister, are turned off.

2. While depressing the brake pedal (CVT)

or the clutch pedal (M/T), press the ac-
celerator pedal halfway and hold it there,
then crank the engine. Release the accel-
erator pedal, immediately after the en-
gine starts.

Keyless operation system*

3-18

OGAE18E1

Locking and unlocking

3. If the engine still will not start, the en-

gine  could  be  flooded  with  too  much
petrol. While depressing the brake pedal
(CVT)  or  the  clutch  pedal  (M/T),  push
the  accelerator  pedal  all  the  way  down
and  hold  it  there,  then  press  the  engine
switch to crank the engine. If the engine
does not start after 5 to 6 seconds, push
the  engine  switch  to  stop  cranking  the
engine, and release the accelerator pedal.
Put  the  operation  mode  in  OFF.  Wait  a
few  seconds,  and  then  press  the  engine
switch  to  crank  the  engine  again  while
depressing the brake pedal (CVT) or the
clutch pedal (M/T), but do not push the
accelerator  pedal.  If  the  engine  fails  to
start,  repeat  these  procedures.  If  the  en-
gine  still  will  not  start,  we  recommend
you to have the vehicle checked.

Starting the engine (diesel-pow-
ered vehicles)

E00308601146

1. Fasten the seat belt.
2. Make sure the parking brake is applied.
3. Press and hold the brake pedal down

firmly with your right foot.

NOTE

After the engine has not started for a while,
the brake pedal effort needed to start the en-
gine may become greater.
If this occurs, depress the brake pedal more
firmly than usual.

4. Fully depress and hold the clutch pedal

(M/T).

5. On vehicles equipped with M/T, place

the  gearshift  lever  in  the  “N”  (Neutral)
position.
On  vehicles  equipped  with  A/T,  make
sure  the  selector  lever  is  in  the  “P”
(Park) position.

Vehicles with M/T

Vehicles with A/T

6. Press the engine switch.

The diesel preheat indication lamp will
first illuminate, and then after a short
time go out, indicating that preheating is
completed. The engine will start.

NOTE

If the engine is cold, the diesel preheat indi-
cation lamp is on for a longer time.

Putting the operation mode in ON will also
start preheating the engine. When the engine
has not been started within about 5 seconds
after the diesel preheat indication lamp went
out, put the operation mode in OFF. Then,
attempt the engine start procedure to preheat
the engine again.

Minor noises may be heard on engine start-
up. These will disappear as the engine
warms up.

Stopping the engine

E00312601118

WARNING

Do  not  operate  the  engine  switch  while
driving except in an emergency. If the en-
gine  is  stopped  while  driving,  the  brake
servomechanism  will  cease  to  function
and  braking  efficiency  will  deteriorate.
Also,  the  power  steering  system  will  not
function  and  it  will  require  greater  man-
ual  effort  to  operate  the  steering.  This
could result in a serious accident.

Keyless operation system*

3-19

OGAE18E1

Locking and unlocking

NOTE

If you have to bring the engine to an emer-
gency stop while driving, press and hold the
engine switch for 3 seconds or more, or
press it quickly 3 times or more. The engine
will stop and the operation mode will go to
ACC.

Do not stop the engine with the selector lev-
er in any position other than the “P” (PARK)
position (A/T or CVT). If the engine is stop-
ped  with  the  selector  lever  in  any  position
other than the “P” (PARK) position, the op-
eration  mode  will  go  to  ACC  rather  than
OFF.
Put the operation mode in OFF after placing
the  selector  lever  in  the  “P”  (PARK)  posi-
tion.

1. Stop the vehicle.
2. Fully engage the parking brake while de-

pressing the brake pedal.

3. On vehicles with M/T, press the engine

switch to stop the engine, move the gear-
shift lever to the 1

(on an uphill) or “R”

(Reverse) (on a downhill) position.
On vehicles with A/T or CVT, move the
selector lever to the “P” (PARK) posi-
tion, press the engine switch to stop the
engine.

NOTE

For diesel-powered vehicles, if the tempera-
ture  inside  the  engine  compartment  is  high,
the cooling fans (A) will continue to operate
for some time even if the engine is stopped.
Therefore,  the  operation  sound  of  the  cool-
ing fans may be heard even after the engine
is  stopped.  This  sound  is  normal  and  does
not indicate a malfunction.
After  operating  for  a  period  of  time,  the
cooling fans will stop automatically.

*: Front of the vehicle

If the keyless operation key is

not operating properly

E00312501162

Insert the keyless operation key into the key
slot in the glove box. Starting the engine and
changing the operation mode should now be
possible.

Remove the keyless operation key from the
key slot after starting the engine or changing
the operation mode.

NOTE

Do not insert into the key slot anything other
than the keyless operation key. This could
cause damage or a malfunction.

Remove  the  object  or  additional  key  from
the  the  keyless  operation  key  before  insert-
ing  the  key  into  the  key  slot.  The  vehicle
may not be able to receive the registered ID
code from the registered key. Therefore, the
engine may not start and the operation mode
may not change.

The keyless operation key is fixed in the key
slot when inserted in the illustrated direc-
tion. Simply pull out the key to remove it
from the key slot.

Keyless operation system*

3-20

OGAE18E1

Locking and unlocking

Keyless operation key reminder

If the operation mode is in OFF and the driv-
er’s door is opened with the keyless operation
key in the key slot, a warning is issued with
the warning display and the buzzer buzzing
for approximately 3 seconds to remind you to
remove the key.

To operate without using the

keyless operation function

E00306000123

Emergency key

E00307200278

The  emergency  key  is  built  into  the  keyless
operation  key.  If  the  keyless  operation  func-
tion cannot be used, for example because the
keyless operation key battery has worn out or
the  vehicle  battery  is  flat,  you  can  lock  and
unlock the driver’s door with the emergency
key.  To  use  the  emergency  key  (A),  unlock
the  lock  knob  (B)  and  remove  it  from  the
keyless operation key (C).

NOTE

Only  use  the  emergency  key  for  emergen-
cies.  If  the  keyless  operation  key  battery
wears  out,  replace  it  as  quickly  as  possible
so  that  you  can  use  the  keyless  operation
key.

NOTE

After using the emergency key, always re-
turn it into the keyless operation key.

Locking and unlocking the driver’s door
Turning the emergency key in the forward di-
rection locks the door, and turning it in the
rear direction unlocks the door. Also refer to
“Locking and unlocking: Doors” on page
3-25.

1- Lock
2- Unlock

Keyless operation system*

3-21

OGAE18E1

Locking and unlocking

Keyless entry system

E00307700967

Press the remote control switch, and all doors
and the tailgate will be locked or unlocked as
desired. It is also possible to operate the out-
side rear-view mirrors (Vehicles equipped
with the mirror retractor switch).

1- LOCK ( ) switch
2- UNLOCK ( ) switch
3- Indication lamp

To lock

Press the LOCK switch (1). All the doors and
the tailgate will be locked. The turn-signal
lamps will blink once when the doors and the
tailgate are locked.

NOTE

With a vehicle that has a Dead Lock System,
pressing the LOCK switch (1) two times in
succession causes the Dead Lock System to
be set. (Refer to “Setting the system” on
page 3-27.)

To unlock

Press the UNLOCK switch (2). All the doors
and the tailgate will be unlocked. If the front
room lamp switch is in the “DOOR” position
or the rear room lamp switch (except for ve-
hicles  equipped  with  the  sunshade)  is  in  the
middle  (•)  position  at  this  time,  the  room
lamp will come on for approximately 15 sec-
onds  and  the  turn-signal  lamps  will  blink
twice.
Depending on the vehicle model, the position
and  tail  lamps  can  also  be  set  to  turn  on  for
approximately 30 seconds.
Refer to “Instruments and controls: Welcome
light” on page 5-54.

NOTE

The remote control switch does not operate
when one of the doors or the tailgate is open
or ajar. (Only the unlock function operates.)

NOTE

Except  for  vehicles  equipped  with  a  Dead
Lock  System,  the  door  and  tailgate  unlock
function can be set so that only the driver’s
door unlocks when the UNLOCK switch (2)
is pressed once.
If the door and tailgate unlock function is set
to work as described above, all the doors and
the  tailgate  unlock  when  the  UNLOCK
switch is pressed two times in succession.
Refer to “Setting of door and tailgate unlock
function” on page 3-24.

The indication lamp (3) comes on each time
a switch is pressed.

If the UNLOCK switch (2) is pressed and no
door or tailgate is opened within approxi-
mately 30 seconds, relocking will automati-
cally occur.

Keyless operation system*

3-22

OGAE18E1

Locking and unlocking

NOTE

It is possible to modify functions as follows:
For further information, please contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.

•

The time from pressing the UNLOCK
switch (2) to the moment of automatic
locking can be changed.

•

The confirmation function (flashing of the
turn-signal lamps) can be set to operate
only when the doors and backdoor are
locked or only when the doors and back-
door are unlocked.

•

The confirmation function (this indicates
locking or unlocking of the doors and tail-
gate with the flash of the turn-signal
lamps) can be deactivated.

•

The number of times the turn-signal
lamps are flashed by the confirmation
function can be changed.

Operation of the Dead Lock

System

In a vehicle that has a Dead Lock System, it
is possible to set the Dead Lock System using
the remote controller.
(Refer to “Dead Lock System” on page
3-27.)

Operation of the outside rear-
view mirrors (Vehicles equip-
ped with mirror retractor
switch)

E00311200325

To fold
Within 30 seconds of locking the doors and
tailgate using the LOCK switch (1), press the
LOCK switch twice rapidly to fold the out-
side rear-view mirrors.

To extend
Within  30  seconds  of  unlocking  the  doors
and  tailgate  using  the  UNLOCK  switch  (2),
press  the  UNLOCK  switch  twice  rapidly  to
return  the  outside  rear-view  mirrors  to  their
extended positions.

The  outside  rear-view  mirrors  are  not  ini-
tially set to work as described above. If you
want them to work as described above, you
need to set them so that they do not retract/
extend  when  the  doors  and  tailgate  are
locked/unlocked using the keyless entry sys-
tem or keyless operation system.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 6-10.
For  details,  please  consult  a  MITSUBISHI
MOTORS Authorized Service Point.

NOTE

The outside rear-view mirrors cannot be fol-
ded or extended using the remote control
switch when one of the doors or the tailgate
is open or ajar.

For vehicles equipped with the mirror retrac-
tor switch, the outside rear-view mirrors au-
tomatically retract or extend when all the
doors and tailgate are locked or unlocked us-
ing the remote control switches of the key-
less entry system.
Refer to “Starting and driving: Outside rear-
view mirrors” on page 6-10.

The remote control switch will operate with-
in  approximately  4  m  from  the  vehicle.
However, the operating range of the remote
control  switch  may  change  if  the  vehicle  is
located  near  a  power  station,  or  radio/TV
broadcasting station.

If either of the following problems occurs,
the battery may be exhausted.

•

The remote control switch is operated at
the correct distance from the vehicle, but
the doors and tailgate are not locked/
unlocked in response.

•

The indication lamp (3) is dim or does not
come on.

For further information, please contact
your MITSUBISHI MOTORS Authorized
Service Point.
If you replace the battery yourself, refer to
“Procedure for replacing the remote con-
trol switch battery” on page 3-24.

Keyless operation system*

3-23

OGAE18E1

Locking and unlocking

NOTE

If your remote control switch is lost or dam-
aged, please contact your MITSUBISHI
MOTORS Authorized Service Point for a re-
placement remote control switch.

If you wish to add a remote control switch,
please

contact

your

MITSUBISHI

MOTORS Authorized Service Point. A max-
imum of 4 remote control switches are avail-
able for your vehicle.

Setting of door and tailgate un-
lock function (Except for vehi-
cles equipped with a Dead Lock
System)

E00310400304

The door and tailgate unlock function can be
set to the following two conditions.
Each time the door and tailgate unlock func-
tion is set, a chime will sound to tell you the
condition of the door and tailgate unlock
function.

Number of

chimes

Condition

One chime

All doors and the tailgate un-
lock

Two chimes

Driver’s door unlock only

1. Put the operation mode in OFF.

2. Place the combination headlamps and

dipper switch in the “OFF” position, and
leave the driver’s door open.

3. Press and hold the LOCK switch (1) for

4 to 10 seconds and then also press the
UNLOCK switch (2) during this time.

4. Release in sequence the LOCK and UN-

LOCK switches within 10 seconds of
pressing the LOCK switch in step 3.

Procedure for replacing the re-
mote control switch battery

E00309601114

1. Before replacing the battery, remove

static electricity from your body by
touching a metal part such as doorknob
of the room.

WARNING

Danger of explosion if battery is incor-
rectly replaced.
Replace only with the same battery or an
equivalent type.

CAUTION

When  the  remote  control  switch  case  is
opened,  be  careful  to  keep  water,  dust,  etc.
out.  Also,  do  not  touch  the  internal  compo-
nents.

NOTE

You may purchase a replacement battery at
an electric appliance store.

A MITSUBISHI MOTORS Authorized
Service Point can replace the battery for you
if you prefer.

2. With the MITSUBISHI mark facing

you, insert the cloth covered tip of a
straight blade (or minus) screwdriver in-
to the notch in the remote control switch
case and use it to open the case.

NOTE

Be  sure  to  perform  the  procedure  with  the
MITSUBISHI  mark  facing  you.  If  the
MITSUBISHI  mark  is  not  facing  you  when
you open the remote control switch case, the
transmitter may come out.

3. Remove the old battery.

Keyless operation system*

3-24

OGAE18E1

Locking and unlocking

4. Install a new battery with the + side (A)

up.

+ side

- side

Coin type battery

CR2032

5. Close the case firmly.
6. Check the keyless operation function to

see that it works.

Doors

E00300402060

CAUTION

Make sure the doors are closed: driving with
doors not completely closed is dangerous.

Never leave children in the vehicle unatten-
ded.

Be careful not to lock the doors while the
key is inside the vehicle.

NOTE

To prevent the key from being locked inside
the vehicle, neither the lock knob on the
driver’s door nor the key can be used to lock
the driver’s door when it is open.

To lock or unlock with the key

1- Lock
2- Unlock

NOTE

When locking or unlocking with the key, on-
ly  the  driver’s  door  will  be  locked  or  un-
locked.
To lock or unlock all doors and the tailgate,
use the central door lock switch, the keyless
entry  system  or  the  keyless  operation  func-
tion.
Refer  to  “Central  door  locks”  on  pages
3-26, “Keyless entry system” on pages 3-04,
3-22, and “To operate using the keyless op-
eration function” on page 3-10.

NOTE

If the vehicle is equipped with the keyless
operation system, the driver’s door can be
locked or unlocked with the emergency key.
Refer to “Emergency key” on page 3-21.

To lock or unlock from inside

the vehicle

1- Lock
2- Unlock

Pull the inside door handle towards you to
open the door.

NOTE

The driver’s door can be opened without us-
ing the lock knob by pulling on the inside
door handle.

Doors

3-25

OGAE18E1

Locking and unlocking

Mitsubishi ASX (2018 year). Instruction - part 3
