Mazda 3 (2022 year). Manual in english - page 12





When Driving
i-ACTIVSENSE
NOTE
Strong light is shone at the front of
the vehicle (back light or
In the following cases, the Forward
high-beam light from on-coming
Sensing Camera (FSC) cannot detect
vehicles).
target objects correctly, and each
There are many light emitters on
system may be unable to operate
the vehicle ahead.
normally.
When the vehicle ahead is not
The height of the vehicle ahead is
equipped with taillights or the
low.
taillights are turned off at
You drive your vehicle at the same
nighttime.
speed as the vehicle ahead.
Elongated luggage or cargo is
Headlights are not turned on
loaded onto installed roof rails and
during the night or when going
covers the Forward Sensing
through a tunnel.
Camera (FSC).
In the following cases, the Forward
Exhaust gas from the vehicle in
Sensing Camera (FSC) may not be
front, sand, snow, and water vapor
able to detect target objects
rising from manholes and grating,
correctly.
and water splashed into the air.
When towing a malfunctioning
Under bad weather condition,
vehicle.
such as rain, fog and snow.
The vehicle is driven with tires
The window washer is being used
having significantly different wear.
or the windshield wipers are not
The vehicle is driven on down
used when it's raining.
slopes or bumpy roads.
Ice, fog, snow, frost, rainfall, dirt,
There are water puddles on the
or foreign matter such as a plastic
road.
bag is stuck on the windshield.
The surroundings are dark such as
Trucks with low loading platforms
during the night, early evening, or
and vehicles with an extremely low
early morning, or in a tunnel or
or high profile.
indoor parking lot.
When driving next to walls with no
The illumination brightness of the
patterning (including fences and
headlights is reduced or the
longitudinally striped walls).
headlight illumination is weakened
The taillights of the vehicle ahead
due to dirt or a deviated optical
are turned off.
axis.
A vehicle is outside the
The target object enters the blind
illumination range of the
spot of the Forward Sensing
headlights.
Camera (FSC).
The vehicle is making a sharp turn,
A person or object bursts onto the
or ascending or descending a steep
road from the shoulder or cuts
slope.
right in front of you.
Entering or exiting a tunnel.
You change lanes and approach a
Heavy luggage is loaded causing
vehicle ahead.
the vehicle to tilt.
When driving extremely close to
the target object.
4-214
When Driving
i-ACTIVSENSE
Tire chains or a temporary spare
If the Forward Sensing Camera (FSC)
tire is installed.
detects that the windshield is dirty or
The vehicle ahead has a special
foggy, the system functions related to
shape. For example, a vehicle
the Forward Sensing Camera (FSC)
towing a trailer house or a boat, or
are temporarily stopped and the
a vehicle carrier carrying a vehicle
following warning lights turn on.
with its front pointed rearward.
However, this does not indicate a
If the Forward Sensing Camera (FSC)
problem. Remove the dirt from the
cannot operate normally due to rain,
windshield or press the defroster
backlight, or fog, the system
switch and defog the windshield.
functions related to the Forward
High Beam Control System (HBC)
Sensing Camera (FSC) are
warning indication/warning light
temporarily stopped and the
(amber)
following warning lights turn on.
i-ACTIVSENSE warning indication/
However, this does not indicate a
warning light
malfunction.
If there are recognizable cracks or
High Beam Control System (HBC)
damage caused by flying gravel or
warning indication/warning light
debris on the windshield, always
(amber)
have the windshield replaced.
i-ACTIVSENSE warning indication/
Consult an Authorized Mazda Dealer
warning light
for replacement.
If the Forward Sensing Camera (FSC)
The Forward Sensing Camera (FSC)
cannot operate normally due to high
recognizes pedestrians when all of
temperatures, the system functions
the following conditions are met:
related to the Forward Sensing
The height of a pedestrian is about
Camera (FSC) are temporarily
1 to 2 meters.
stopped and the following warning
An outline such as the head, both
lights turn on. However, this does
shoulders, or the legs can be
not indicate a malfunction. Cool
determined.
down the area around the Forward
In the following cases, the Forward
Sensing Camera (FSC) such as by
Sensing Camera (FSC) may not be
turning on the air conditioner.
able to detect target objects
High Beam Control System (HBC)
correctly:
warning indication/warning light
Multiple pedestrians are walking,
(amber)
or there are groups of people.
i-ACTIVSENSE warning indication/
A pedestrian is close to a separate
warning light
object.
A pedestrian is crouching, lying, or
slouching.
A pedestrian suddenly jumps into
the road right in front of the
vehicle.
A pedestrian opens an umbrella, or
is carrying large baggage or
articles.
4-215
When Driving
i-ACTIVSENSE
A pedestrian is in a dark location
Front Radar Sensor*
such as during the night, or blends
into the background by wearing
Front Radar Sensor
clothes matching the background
color.
Your vehicle is equipped with a front
radar sensor.
The following systems also use the
front radar sensor.
Distance & Speed Alert (DSA)
Mazda Radar Cruise Control
(MRCC)
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
Traffic Jam Assist (TJA)
Smart Brake Support (SBS) forward
drive detection
The front radar sensor functions by
detecting the radio waves reflected off
a vehicle ahead or an obstruction sent
from the radar sensor.
The front radar sensor is mounted
behind the front emblem.
1. Front radar sensor
If “Safety and Driver Support Systems
Temporarily Disabled. Front Radar
Obscured. Drive Safely” is displayed on
the multi-information display of the
instrument cluster, clean the area
around the front radar sensor.
4-216 *Some models.
When Driving
i-ACTIVSENSE
¾ Do not modify the suspensions. If
CAUTION
the suspensions are modified, the
Heed the following precautions to
vehicle's posture could change and
assure correct operation of each
the front radar sensor may not be
system.
able to correctly detect a vehicle
ahead or an obstruction.
¾ Do not adhere stickers (including
transparent stickers) to the surface of
NOTE
the radiator grille and front emblem
in and around the front radar sensor,
When the vehicle is driven on roads
and do not replace the radiator grille
in which there is an elevated road on
and front emblem with any product
one side, the front radar sensor
that is not a genuine product
function may be restricted
designed for use with the front radar
temporarily.
sensor.
Under the following conditions, the
¾ The front radar sensor includes a
front radar sensor may not be able to
function for detecting soiling of the
detect vehicles ahead or obstructions
radar sensor's front surface and
correctly and each system may not
informing the driver, however,
operate normally.
depending on the conditions, it may
The rear surface of a vehicle ahead
require time to detect or it may not
does not reflect radio waves
detect plastic shopping bags, ice or
effectively, such as an unloaded
snow. If this occurs, the system may
trailer or an automobile with a
not operate correctly, therefore
loading platform covered by a soft
always keep the front radar sensor
top, vehicles with a hard plastic
clean.
tailgate, and round-shaped
¾ Do not install a grille guard.
vehicles.
¾ If the front part of the vehicle has
Vehicles ahead with low vehicle
been damaged in a vehicle accident,
height and thus less area for
the position of the front radar sensor
reflecting radio waves.
may have moved. Stop the system
Visibility is reduced due to a
immediately and always have the
vehicle ahead casting off water,
vehicle inspected at an Authorized
snow, or sand from its tires and
Mazda Dealer.
onto your windshield.
¾ Do not use the front bumper to push
The trunk/luggage compartment is
other vehicles or obstructions such
loaded with heavy objects or the
as when pulling out of a parking
rear passenger seats are occupied.
space. Otherwise, the front radar
Ice, snow, or soiling is on the front
sensor could be hit and its position
surface of the front emblem.
deviated.
During inclement weather such as
¾ Do not remove, disassemble, or
rain, snow, or sand storms.
modify the front radar sensor.
When driving near facilities or
¾ For repairs, replacement or paint
objects emitting strong radio
work around the front radar sensor,
waves.
consult an Authorized Mazda Dealer.
4-217
When Driving
i-ACTIVSENSE
Under the following conditions, the
The radar sensors are regulated by
front radar sensor may not be able to
the relevant radio wave laws of the
detect vehicles ahead or
country in which the vehicle is
obstructions.
driven. If the vehicle is driven
abroad, authorization from the
The beginning and end of a curve.
country in which the vehicle is driven
Roads with continuous curves.
may be required.
Narrow lane roads due to road
construction or lane closures.
The vehicle ahead enters the radar
sensor's blind spot.
The vehicle ahead is running
abnormally due to accident or
vehicle damage.
Roads with repeated up and down
slopes
Driving on poor roads or unpaved
roads.
The distance between your vehicle
and the vehicle ahead is extremely
short.
A vehicle suddenly comes close,
such as by cutting into your lane.
To prevent incorrect operation of the
system, use tires of the same
specified size, manufacturer, brand,
and tread pattern on all four wheels.
In addition, do not use tires with
significantly different wear patterns
or tire pressures on the same vehicle
(Including the temporary spare tire).
If the battery power is weak, the
system may not operate correctly.
When driving on roads with little
traffic and few vehicles ahead or
obstructions for the front radar
sensor to detect, “Safety and Driver
Support Systems Temporarily
Disabled. Front Radar Obscured.
Drive Safely” may be temporarily
displayed, however, this does not
indicate a problem.
4-218
When Driving
i-ACTIVSENSE
NOTE
Front Side Radar Sensor*
The detection ability of the front side
Front Side Radar Sensor
radar sensor has limitations. In the
following cases, the detection ability
Your vehicle is equipped with front
may lower and the system may not
side radar sensor. The following
operate normally.
systems also use the front side radar
sensor.
The front bumper near the front
side radar sensor has become
Front Cross Traffic Alert (FCTA)
deformed.
The front side radar sensor function by
Snow, ice or mud adheres to the
detecting the radio waves reflected off
front side radar sensor on the front
a vehicle approaching from the front or
bumper.
an obstruction sent from the radar
Under bad weather conditions
sensor.
such as rain, snow and fog.
Under the following conditions, the
front side radar sensor cannot detect
target objects or it may be difficult to
detect them.
Small motorcycles, bicycles,
pedestrians, animals, shopping
carts, and stationary objects on a
road or a road side.
Vehicle shapes which do not
1. Front side radar sensor
reflect radar waves well such as
empty trailers with a low vehicle
The front side radar sensors are
height and sports cars.
installed inside the front bumper, one
Vehicles are shipped with the
on each side.
direction of the front side radar
Always keep the surface of the front
sensor adjusted for each vehicle to a
bumper near the front side radar
loaded vehicle condition so that the
sensors clean so that they operate
front side radar sensor detect
normally. Also, do not apply items such
approaching vehicles correctly. If the
as stickers.
direction of the front side radar
Refer to Exterior Care on page 6-47.
sensor has deviated for some reason,
have the vehicle inspected at an
CAUTION
Authorized Mazda Dealer.
For repairs or replacement of the
If the front bumper receives a severe
front side radar sensor, or bumper
impact, the system may no longer
repairs, paintwork, and replacement
operate normally. Stop the system
near the radar sensors, consult an
immediately and have the vehicle
Authorized Mazda Dealer.
inspected at an Authorized Mazda
Dealer.
*Some models.
4-219
When Driving
i-ACTIVSENSE
The radar sensors are regulated by
Rear Side Radar Sensor*
the relevant radio wave laws of the
country in which the vehicle is
Rear Side Radar Sensor
driven. If the vehicle is driven
abroad, authorization from the
Your vehicle is equipped with rear side
country in which the vehicle is driven
radar sensor. The following systems
may be required.
also use the rear side radar sensor.
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
Smart Brake Support (SBS) reverse
drive detection
The rear side radar sensors emit radio
waves and detect the radio waves
reflected off a vehicle approaching
from the rear or an obstruction.
4-Door
1. Rear side radar sensor
5-Door
1. Rear side radar sensor
The rear side radar sensors are installed
inside the rear bumper, one on each
side.
4-220 *Some models.
When Driving
i-ACTIVSENSE
Always keep the surface of the rear
Vehicles are shipped with the
bumper near the rear side radar
direction of the rear side radar
sensors clean so that they operate
sensor adjusted for each vehicle to a
normally. Also, do not apply items such
loaded vehicle condition so that the
as stickers.
rear side radar sensor detect
Refer to Exterior Care on page 6-47.
approaching vehicles correctly. If the
direction of the rear side radar
CAUTION
sensor has deviated for some reason,
have the vehicle inspected at an
If the rear bumper receives a severe
Authorized Mazda Dealer.
impact, the system may no longer
For repairs or replacement of the rear
operate normally. Stop the system
side radar sensor, or bumper repairs,
immediately and have the vehicle
paintwork, and replacement near the
inspected at an Authorized Mazda
radar sensors, consult an Authorized
Dealer.
Mazda Dealer.
The radar sensors are regulated by
NOTE
the relevant radio wave laws of the
The detection ability of the rear side
country in which the vehicle is
radar sensor has limitations. In the
driven. If the vehicle is driven
following cases, the detection ability
abroad, authorization from the
may lower and the system may not
country in which the vehicle is driven
operate normally.
may be required.
The rear bumper near the rear side
radar sensor has become
deformed.
Snow, ice or mud adheres to the
rear side radar sensor on the rear
bumper.
Under bad weather conditions
such as rain, snow and fog.
Under the following conditions, the
rear side radar sensor cannot detect
target objects or it may be difficult to
detect them.
Small motorcycles, bicycles,
pedestrians, animals, shopping
carts, and stationary objects on a
road or a road side.
Vehicle shapes which do not
reflect radar waves well such as
empty trailers with a low vehicle
height and sports cars.
4-221
When Driving
i-ACTIVSENSE
Rear/Rear Corner
Front Camera/Side
Ultrasonic Sensor*
Cameras/Rear Camera*
Rear/Rear Corner Ultrasonic
Front Camera/Side Cameras/Rear
Sensor
Camera
The ultrasonic sensors function by
Your vehicle is equipped with a front
emitting ultrasonic waves which are
camera, side cameras, and a rear
reflected off obstructions at the rear
camera. The 360°View Monitor uses
and the returning ultrasonic waves are
each camera.
picked up by the ultrasonic sensors.
Refer to 360°View Monitor on page
4-178.
The front camera, side cameras, and
rear camera shoot images of the area
surrounding the vehicle.
Each camera is installed to the
following positions.
4-Door
The ultrasonic sensors are mounted in
the rear bumper.
1. Side cameras
2. Front camera
3. Rear camera
4-222 *Some models.
When Driving
i-ACTIVSENSE
5-Door
Driver Monitoring
Camera*
Driver Monitoring Camera
The driver monitoring camera detects
changes in the driver's facial features
and estimates the amount of
accumulated fatigue and sleepiness of
the driver.
1. Driver monitoring camera
NOTE
1.
Side cameras
2.
Front camera
Driver Monitoring (DM) and the
3.
Rear camera
earlier collision warning may not
operate normally under the following
conditions.
The driver monitoring camera is
covered with something.
You are driving the vehicle while
leaning on the steering wheel.
You are wearing glasses or
sunglasses.
A cap or hat you are wearing
partially blocks the driver
monitoring camera's view of your
eyes, you have long bangs partially
covering your eyes, or a part of
your face is invisible due to a face
mask.
The lighting conditions change
significantly (such as backlight,
light from the side, or direct light
from the setting sun, and the
headlights of on-coming vehicles).
*Some models.
4-223
When Driving
i-ACTIVSENSE
You are driving the vehicle with
your head excessively tilted to one
side or the other.
You are moving around extensively.
Your face or your eyes frequently
turn in direction other than straight
ahead (direction of travel).
Your line of sight moves or directly
after it has moved.
There is a large difference between
your line of sight and the direction
your face is pointed.
You are driving the vehicle with
your head largely tilted to one side.
Free/open source software
information
This product includes free/open
sources. Information about the
licensing and source code is
available at the following URL.
/RTOS/License/oss/DMS_0201/
4-224
When Driving
Cruise Control
NOTE
Cruise Control*
If your Mazda has the following
steering switch, your Mazda is
Cruise Control
equipped with the Mazda Radar
Cruise Control (MRCC) system, the
With cruise control, you can set and
Mazda Radar Cruise Control with Stop
automatically maintain any speed of
& Go function (MRCC with Stop & Go
more than about 30 km/h (19 mph).
function) system.
WARNING
Do not use the cruise control under
the following conditions:
Using the cruise control under the
following conditions is dangerous and
could result in loss of vehicle control.
Refer to Mazda Radar Cruise Control
(MRCC) on page 4-131.
¾ Hilly terrain
Refer to Mazda Radar Cruise Control
¾ Steep inclines
with Stop & Go function (MRCC with
¾ Heavy or unsteady traffic
Stop & Go function) on page 4-140.
¾ Slippery or winding roads
If the Mazda Radar Cruise Control
¾ Similar restrictions that require
(MRCC) or Mazda Radar Cruise
inconsistent speed
Control with Stop & Go function
¾ The vehicle speed may exceed the
(MRCC with Stop & Go function) is set
set speed during sudden acceleration
to inoperable using the personalization
or on steep down slopes.
feature, the system switches to the
In this case, depress the brake pedal
cruise control function. In this case, the
to adjust the vehicle speed.
MRCC functions as the cruise switch.
In addition, this personalization
Cruise Control Switch
feature setting is initialized by
switching the ignition OFF, and it turns
back on when the ignition is switched
ON the next time.
Cruise Standby Indication
(White)/Cruise Set Indication
(Green)
1. CANCEL switch
Cruise standby Indication (White)
2. RES switch
The indication turns on (white) when
3. Cruise switch
the cruise control system is activated.
*Some models.
4-225
When Driving
Cruise Control
Cruise Set Indication (Green)
To Set Speed
The indication turns on (green) when a
1. Activate the cruise control system
cruising speed has been set.
by pressing the cruise switch. The
cruise standby indication (white)
turns on.
2. Accelerate to the desired speed,
which must be more than 25 km/h
(16 mph).
Activation/Deactivation
3. Adjust the system to the desired
vehicle speed using the accelerator
pedal. Press the RES switch up (SET
WARNING
+) or down (SET-) to start cruise
control. The cruise control
Always turn off the cruise control
indication (green) in the instrument
system when it is not in use:
cluster turns on at the same time.
Leaving the cruise control system in an
Quickly release the switch when the
activation-ready state while the cruise
cruise control indication (green)
control is not in use is dangerous as the
turns on.
cruise control could unexpectedly
activate if the activation button is
NOTE
accidentally pressed, and result in loss
If the RES switch is operated up (SET
of vehicle control and an accident.
+) or down (SET-) while the vehicle
speed is between 25 and 30 km/h
If the headway control function is
(16 to 19 mph), the set speed is set
disabled using a Mazda Connect
to 30 km/h (19 mph).
setting, the system switches to cruise
The cruise control speed setting
control.
cannot be performed under the
Activation
following conditions:
To activate the system, press the cruise
Any of the doors is opened.
switch. The cruise standby indication
The driver's seat belt is unfastened.
(white) turns on.
The brake pedal is depressed.
The parking brake is applied.
Deactivation
(Automatic transmission)
To deactivate the system, press the
The selector lever is in the P, N, or
cruise switch again.
R position.
The cruise standby indication (white)
(Manual transmission)
turns off.
The shift lever is in the neutral
position.
On a steep grade, the vehicle may
momentarily slow down while
ascending or speed up while
descending.
4-226
When Driving
Cruise Control
The cruise control will cancel if the
Changing the Set Vehicle Speed
vehicle speed decreases below 20
Follow either of these procedures.
km/h (12 mph) when the cruise
control is activated, such as when
To increase/decrease speed using
climbing a steep grade.
cruise control switch
The vehicle speed preset using the
When the RES switch is pressed up
cruise control is displayed in the
(SET+), the vehicle accelerates and
instrument cluster and the active
when the RES switch is pressed down
driving display (vehicles with active
(SET-), it decelerates.
driving display).
Press and release immediately: 1
Instrument cluster (Basic display)
km/h (1 mph)
Press and hold: 10 km/h (5 mph)
NOTE
Even after releasing the RES switch, the
cruise control accelerates/decelerates
continuously until the set speed
displayed in the instrument cluster and
on the active driving display is reached.
If you want to stop accelerating/
decelerating, change the set speed or
cancel the system (such as by
depressing the brake pedal).
Instrument cluster (i-ACTIVSENSE
display)
To increase speed using accelerator
pedal
Depress the accelerator pedal and
press the RES switch up (SET+) or
down (SET-) at the desired speed. If
the switch is not operated, the system
returns to the set speed after you
release your foot from the accelerator
pedal.
NOTE
Accelerate if you want to speed up
temporarily when the cruise control is
Active driving display
on. Greater speed will not interfere
with or change the set speed. Take
your foot off the accelerator to return
to the set speed.
4-227
When Driving
Cruise Control
To Resume Cruising Speed at More
NOTE
Than 30 km/h (19 mph)
If any of the following conditions
If the cruise control system is
occur, the cruise control system is
temporarily canceled (such as by
temporarily canceled.
applying the brake pedal) and the
Even when the brake pedal is
system is still activated, the most
slightly depressed.
recent set speed will automatically
The DSC is operating.
resume when the RES switch is
There is a problem in the system.
pressed.
Any of the doors is opened.
If vehicle speed is below 30 km/h (19
The driver's seat belt is unfastened.
mph), increase the vehicle speed up to
The parking brake is applied.
30 km/h (19 mph) or more and press
(Automatic transmission)
the RES switch.
The selector lever is in the P, N, or
R position.
To Temporarily Cancel
(Manual transmission)
To temporarily cancel the system, use
The shift lever is in the neutral
one of these methods:
position.
When the cruise control system is
Slightly depress the brake pedal.
temporarily canceled by even one of
Press the CANCEL switch.
the applicable cancel conditions, the
(Manual transmission)
speed cannot be re-set.
Depress the clutch pedal.
(Automatic transmission)
If the RES switch is pressed when the
The cruise control cannot be
vehicle speed is 30 km/h (19 mph) or
canceled while driving in manual
higher, the system reverts to the
mode (selector lever shifted from D
previously set speed.
to M position). Therefore, engine
braking will not be applied even if
the transmission is shifted down to a
lower gear. If deceleration is
required, lower the set speed or
depress the brake pedal.
To Deactivate
Press the cruise switch again.
4-228
When Driving
Tire Pressure Monitoring System (TPMS)
Before driving, visually inspect the
Tire Pressure Monitoring
tires for abnormalities. Additionally,
System (TPMS)
inspect the tire pressures monthly. A
digital type air pressure gauge is
Tire Pressure Monitoring System
recommended for inspecting the tire
(TPMS)
pressures.
The TPMS monitors the air pressure of
The TPMS is not a substitute for your
each tire and if it decreases below the
own periodic inspection of the tires.
specified value, the system notifies the
Always inspect the tires yourself
driver by turning on the TPMS warning
periodically.
light in the instrument cluster and
indicating a message on the
CAUTION
multi-information display.
For the TPMS, the air pressure data
¾ Each tire, including the spare (if
sent from the tire pressure sensors
provided), should be checked
installed on each wheel via radio signal
monthly when cold and inflated to
is received by the receiver unit in the
the inflation pressure recommended
vehicle to monitor the tire pressures.
by the vehicle manufacturer on the
vehicle placard or tire inflation
pressure label. (If your vehicle has
tires of a different size than the size
indicated on the vehicle placard or
tire inflation pressure label, you
should determine the proper tire
inflation pressure for those tires.)
As an added safety feature, your
vehicle has been equipped with a
1. Tire pressure sensors
tire pressure monitoring system
(TPMS) that illuminates a low tire
In addition, the current tire pressures
pressure telltale when one or more
can be checked using the center
of your tires is significantly
display.
under-inflated. Accordingly, when
Refer to the Vehicle Status Monitor
the low tire pressure telltale
section in the Mazda Connect
illuminates, you should stop and
Owner's Manual.
check your tires as soon as possible,
NOTE
and inflate them to the proper
pressure. Driving on a significantly
When the ambient temperature is
under-inflated tire causes the tire to
low, the tire temperatures also
overheat and can lead to tire failure.
decrease. If the tire temperatures
Under-inflation also reduces fuel
decrease, the air pressure in the tires
efficiency and tire tread life, and may
will also decrease which could turn
affect the vehicle's handling and
on the TPMS warning light.
stopping ability.
4-229
When Driving
Tire Pressure Monitoring System (TPMS)
Please note that the TPMS is not a
If there is a problem with the Tire
substitute for proper tire
Pressure Monitoring System
maintenance, and it is the driver's
(TPMS)
responsibility to maintain correct tire
If the TPMS warning light flashes, there
pressure, even if under-inflation has
may be a problem with the system.
not reached the level to trigger
Consult an Authorized Mazda Dealer
illumination of the TPMS low tire
to have the system inspected.
pressure telltale.
Refer to Tire Pressure Monitoring
Your vehicle has also been equipped
System (TPMS) Warning Indication/
with a TPMS malfunction indicator to
Warning Light (Flashing) on page
indicate when the system is not
7-33.
operating properly.
In the following cases, the system
The TPMS malfunction indicator is
cannot recognize the tire pressures
combined with the low tire pressure
correctly and the TPMS warning light
telltale. When the system detects a
may flash.
malfunction, the telltale will flash for
approximately one minute and then
There is equipment or a device
remain continuously illuminated.
nearby emitting radio signals the
This sequence will continue upon
same as a tire pressure sensor.
subsequent vehicle start-ups as long
A metallic object such as a
as the malfunction exists. When the
non-genuine electronic device is
malfunction indicator is illuminated,
installed near the center of the
the system may not be able to detect
dashboard (obstructs the radio
or signal low tire pressure as
signals from the tire pressure sensors
intended. TPMS malfunctions may
to the receiver).
occur for a variety of reasons,
A device such as one of the following
including the installation of
is used in the cabin.
replacement or alternate tires or
Electronic devices such as a
wheels on the vehicle that prevent
computer.
the TPMS from functioning properly.
Converter devices such as a
Always check the TPMS malfunction
DC-AC converter.
telltale after replacing one or more
There is a large accumulation of
tires or wheels on your vehicle to
snow or ice around the vehicle tires.
ensure that the replacement or
The battery in a tire pressure sensor
alternate tires and wheels allow the
is dead.
TPMS to continue to function
A wheel not equipped with a tire
properly.
pressure sensor is used.
¾ To avoid false readings, the system
Tires employing steel in the sidewall
samples for a little while before
of the tire are installed.
indicating a problem. As a result it
Tire chains are used.
will not instantaneously register a
rapid tire deflation or blow out.
4-230
When Driving
Tire Pressure Monitoring System (TPMS)
When a tire pressure decreases
2. After more than 19 minutes have
passed, drive the vehicle at a speed
If the TPMS warning light turns on, a
of about 25 km/h (16 mph) or
tire pressure may be low. Inspect the
faster for 3 minutes or longer. While
tire pressures and adjust them to the
driving, the ID signal codes of the
correct inflation pressure.
tire pressure sensors are
Refer to Tire Pressure Monitoring
automatically registered.
System (TPMS) Warning Indication/
Warning Light (Turns on) on page
NOTE
7-37.
If you drive the vehicle within 19
minutes of changing a tire or wheel,
Tires and Wheels
the TPMS warning light will flash
because the ID signal codes for the tire
pressure sensors were not registered.
CAUTION
In this case, stop the vehicle and
When inspecting/adjusting the tire
register the ID signal codes of the tire
pressures, do not apply excessive force
pressure sensors following the
to the air valve of the tire pressure
procedure.
sensor. Otherwise, the tire pressure
When replacing tires and wheels
sensor could be damaged.
When changing tires and wheels
CAUTION
When changing the tires or wheels
(such as installing winter tires), it will
¾ When replacing the tires and wheels,
be necessary to register the ID signal
consult an Authorized Mazda Dealer
code of the tire pressure sensor to the
Otherwise, the tire pressure sensors
TPMS.
could be damaged when replacing
Have an Authorized Mazda Dealer do
them.
the registration or register the ID signal
¾ Do not install non-genuine wheels. If
codes of the tire pressure sensors using
wheels other than genuine ones are
the following procedure.
installed, it may not be possible to
install the tire pressure sensors.
NOTE
The tire pressure sensors on each
When replacing a tire or wheel, always
wheel have a unique ID signal code.
install the tire pressure sensor. The
For the TPMS to operate correctly, the
following combinations of tires,
ID signal codes of the tire pressure
wheels, or tires and wheels are
sensors need to be registered to the
possible.
system.
The tire pressure sensor from the old
wheel is removed and it is installed
1. Wait more than 19 minutes after
changing a tire or wheel.
to the new wheel.
Only a tire is replaced without
replacing the tire pressure sensor and
wheel.
A new tire pressure sensor is installed
to a new wheel.
4-231
When Driving
Tire Pressure Monitoring System (TPMS)
NOTE
When installing a new tire pressure
sensor, the ID signal code for the tire
pressure sensor needs to be registered.
For details on purchasing a tire
pressure sensor and registering the ID
signal of the tire pressure sensor,
consult an Authorized Mazda Dealer.
4-232
When Driving
Rear View Monitor
¾ Do not apply excessive force to the
Rear View Monitor*
camera. The camera position and
angle may deviate.
Rear View Monitor
¾ Do not disassemble, modify, or
The rear view monitor provides visual
remove it as it may no longer be
images of the rear of the vehicle when
waterproof.
reversing.
¾ The camera cover is made of plastic.
Do not apply degreasing agents,
WARNING
organic solvents, wax, or glass
coating agents to the camera cover.
Always drive carefully confirming the
If any are spilled on the cover, wipe
safety of the rear and the surrounding
off with a soft cloth immediately.
conditions by looking directly with
¾ Do not rub the camera cover
your eyes:
forcefully with an abrasive or hard
Reversing the vehicle by only looking at
brush. The camera cover or lens may
the screen is dangerous as it may cause
be scratched which might affect the
an accident or a collision with an
images.
object. The rear view monitor is only a
¾ If a camera lens is severely damaged
visual assist device when reversing the
by flying gravel, have the camera
vehicle. The images on the screen may
replaced. For camera replacement,
be different from the actual conditions.
consult an Authorized Mazda Dealer.
NOTE
CAUTION
If water, snow, or mud is stuck on
¾ Do not use the rear view monitor
the camera lens, wipe it off using a
under the following conditions:
soft cloth. If it cannot be wiped off,
Using the rear view monitor under
use a mild detergent.
the following conditions is
If the camera temperature changes
dangerous and could result in injury
rapidly (Hot to cold, cold to hot), the
or vehicle damage or both.
rear view monitor may not operate
¾ Icy or snow-covered roads.
correctly.
¾ Tire chains or a temporary spare
When replacing the tires, consult an
tire is installed.
Authorized Mazda Dealer. Replacing
¾ The vehicle is on a road incline.
the tires could result in deviation of
¾ Bumpy roads.
the guide lines which appear on the
¾ When the display is cold, images
display.
may course across the monitor or the
If the vehicle's front, side, or rear has
screen and may be dimmer than
been involved in a collision, the
usual, which could cause difficulty in
alignment of the rear view parking
confirming the surrounding
camera (location, installation angle)
conditions of the vehicle. Always
may have deviated. Always consult
drive carefully confirming the safety
an Authorized Mazda Dealer to have
of the rear and the surrounding
the vehicle inspected.
conditions by looking directly with
your eyes.
*Some models.
4-233
When Driving
Rear View Monitor
If “No camera signal.” is indicated in
Rear View Parking Camera
the display, there could be a
Location
problem with the camera. Have your
4-Door
vehicle inspected at an Authorized
Mazda Dealer.
(Predicted vehicle path assist lines
display type)
If force is applied to the steering
wheel, the guide lines may not
display. Loosen your grip on the
steering wheel to allow the guide
lines to display.
1. Rear view parking camera
5-Door
1. Rear view parking camera
4-234
When Driving
Rear View Monitor
Switching to the Rear View Monitor Display
Shift the shift lever (manual transmission) or the selector lever (automatic
transmission) to reverse (R) position with the ignition switched ON to switch the
display to the rear view monitor display.
NOTE
When the shift lever (manual transmission) or the selector lever (automatic
transmission) is shifted from reverse (R) position to another shift lever (manual
transmission) or the selector lever (automatic transmission) position, the screen
returns to the previous display.
Displayable Range on the Screen
The images on the screen may be different from the actual conditions.
1.
(Screen display)
2.
(Actual view)
3. Bumper
4.
“Check surroundings for safety.” message is displayed
5. Object
NOTE
The displayable range varies depending on the vehicle and road conditions.
If the camera lens is touched or there is any dirt on it, it could affect the screen
image. Wipe the lens using a soft cloth.
The displayable range is limited. Objects under the bumper or around the bumper
ends cannot be displayed.
4-235
When Driving
Rear View Monitor
The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a specific lens.
Images displayed on the monitor from the rear view parking camera are reversed
images (mirror images).
Some optionally installed vehicle accessories may be picked up by the camera. Do
not install any optional parts that can interfere with the camera view, such as
illuminating parts or parts made of reflective material.
It may be difficult to see the display under the following conditions, however, it
does not indicate a malfunction.
In darkened areas.
When the temperature around the lens is high/low.
When the camera is wet such as on a rainy day or during periods of high
humidity.
When foreign material such as mud is stuck around the camera.
When the camera lens reflects sunlight or headlight beams.
The surroundings are illuminated by vehicle lights, fluorescent lights, or LED
lights (display may flicker).
Extremely small dark or white dots appear on the screen (dots may flicker).
An object is close to a camera.
Image display may be delayed if the temperature around the camera is low.
Viewing the Display
Predicted vehicle path assist lines display type
The projected path guidance mode displays the predicted path of the vehicle after
you turn the steering wheel.
Use this mode for parking your vehicle in a parking space or garage.
a) Projected vehicle path (yellow)
These lines are displayed as a reference for the projected path of the vehicle.
The lines displaying the projected vehicle path change after you turn the steering
wheel.
b) Extended vehicle width lines (blue)
These lines indicate the vehicle's extended width.
4-236
When Driving
Rear View Monitor
These lines are not displayed when the vehicle's wheels are in the straight-ahead
position.
c) Distance guide lines (red)
These lines indicate the approximate distance to a point measured from the
vehicle's rear (from the end of the bumper).
The blue line indicates the point about 0.5 m (19 in) from the rear bumper.
The red and yellow lines, which change position after you turn the steering wheel,
indicate the points about 0.5 m (19 in) for the red line and 1.0 m (39 in) and 2.0
m (78 in) for the yellow lines from the rear bumper (at the center point of each of
the lines).
A degree of error occurs when the wheels are not in the straight-ahead position.
In the above illustration, the right side of the vehicle is in a position closer to the
actual distance displayed by the distance guide lines (red: about 0.5 m (19 in)
point, yellow: about 1.0 m (39 in), and yellow: about 2.0 m (78 in) point behind
the rear bumper), whereas the left side is in a position farther away.
CAUTION
The indicated position of the guide lines on the display changes depending on the
vehicle conditions (such as the number of occupants/cargo load) and the road
conditions (such as a steep gradient to the rear of the vehicle).
Always check the area to the vehicle's rear and the surrounding area directly with
your eyes while backing up.
Fixed assist lines display type
Guide lines which indicate the width of the vehicle are displayed on the screen as a
reference to the approximate width of the vehicle in comparison to the width of the
parking space you are about to back into.
Use this display view for parking your vehicle in a parking space or garage.
a) Vehicle width guide lines
Guide lines serve as a reference to the approximate width of the vehicle.
b) Distance guide lines
These guide lines indicate the approximate distance to a point measured from the
vehicle's rear (from the end of the bumper).
The red line indicates the point about 0.5 m (19 in) from the rear bumper.
4-237
When Driving
Rear View Monitor
The yellow lines indicate the points about 1.0 m (39 in) and 2.0 m (78 in) from
the rear bumper.
CAUTION
The guide lines on the screen are fixed lines. They are not synced to the driver's
turning of the steering wheel. Always be careful and check the area to the vehicle's
rear and the surrounding area directly with your eyes while backing up.
Rear View Monitor Operation
The operation of the rear view monitor when reversing the vehicle varies depending
on the traffic, road, and vehicle conditions. The amount of steering and the timing
also varies depending on conditions, so confirm the surrounding conditions directly
with your eyes and steer the vehicle in accordance with the conditions.
Be well aware of the above cautions prior to using the rear view monitor.
Predicted vehicle path assist lines display type
NOTE
The following shows an example of vehicle parking in which the steering wheel is
turned to the right when backing up the vehicle. The operation is reversed when
backing up the vehicle from the opposite direction.
1. Shift the shift lever (manual transmission) or the selector lever (automatic
transmission) to reverse (R) position to switch the display to the rear view
monitor display.
4-238
When Driving
Rear View Monitor
2. Before backing the vehicle into the parking space, turn the steering wheel while
referring to the projected vehicle path display so that the vehicle enters the
center of the parking space.
1.
(Display condition)
2.
(Vehicle condition)
4-239
When Driving
Rear View Monitor
3. After your vehicle begins entering the parking space, continue backing up slowly
so that the distance between the vehicle width lines and the sides of the parking
space on the left and right are roughly equal.
1.
(Display condition)
2.
(Vehicle condition)
4. Continue to adjust the steering wheel until the vehicle width guide lines are
parallel to the left and right sides of the parking space.
4-240
When Driving
Rear View Monitor
5. Once they are parallel, straighten the wheels and back your vehicle slowly into
the parking space. Continue checking the vehicle's surroundings and then stop
the vehicle in the best possible position. (If the parking space has division lines,
check whether the vehicle width guide lines are parallel to them.)
1.
(Display condition)
2.
(Vehicle condition)
6. When the shift lever (manual transmission) or the selector lever (automatic
transmission) is shifted from reverse (R) position to another shift lever (manual
transmission) or the selector lever (automatic transmission) position, the screen
returns to the previous display.
NOTE
Because there may be a difference between the displayed image, such as indicated
below, and the actual conditions when parking, always verify the safety at the rear of
the vehicle and the surrounding area directly with your eyes.
In the image of the parking space (or garage) displayed on the screen, the back
end and distance guide lines may appear aligned in the monitor, but they may not
actually be aligned on the ground.
4-241
When Driving
Rear View Monitor
When parking in a space with a division line on only one side of the parking space,
the division line and the vehicle width guide line appear aligned in the monitor,
but they may not actually be aligned on the ground.
Fixed assist lines display type
NOTE
Images displayed on the monitor from the rear view parking camera are reversed
images (mirror images).
1. Shift the shift lever (manual transmission) or the selector lever (automatic
transmission) to reverse (R) position to switch the display to the rear view
monitor display.
2. Confirming the surrounding conditions, reverse the vehicle.
4-242
When Driving
Rear View Monitor
3. After your vehicle begins entering the parking space, continue backing up slowly
so that the distance between the vehicle width lines and the sides of the parking
space on the left and right are roughly equal.
1.
(Display condition)
2.
(Vehicle condition)
4. Continue to adjust the steering wheel until the vehicle width guide lines are
parallel to the left and right sides of the parking space.
4-243
When Driving
Rear View Monitor
5. Once they are parallel, straighten the wheels and back your vehicle slowly into
the parking space. Continue checking the vehicle's surroundings and then stop
the vehicle in the best possible position. (If the parking space has division lines,
check whether the vehicle width guide lines are parallel to them.)
1.
(Display condition)
2.
(Vehicle condition)
6. When the shift lever (manual transmission) or the selector lever (automatic
transmission) is shifted from reverse (R) position to another shift lever (manual
transmission) or the selector lever (automatic transmission) position, the screen
returns to the previous display.
NOTE
Because there may be a difference between the displayed image, such as indicated
below, and the actual conditions when parking, always verify the safety at the rear of
the vehicle and the surrounding area directly with your eyes.
In the image of the parking space (or garage) displayed on the screen, the back
end and distance guide lines may appear aligned in the monitor, but they may not
actually be aligned on the ground.
4-244
When Driving
Rear View Monitor
When parking in a space with a division line on only one side of the parking space,
the division line and the vehicle width guide line appear aligned in the monitor,
but they may not actually be aligned on the ground.
Variance Between Actual Road Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Such
variance in distance perspective could lead to an accident. Note the following
conditions that may cause a variance in distance perspective.
When the vehicle is tilted due to the weight of passengers and load
When the vehicle rear is lowered, the object displayed on the screen appears farther
than the actual distance.
1. Object
2. Variance
3. Object on screen
4-245















Content      ..     10      11      12      13     ..
