6-2. Maintenance

6-2.Maintenance

■

Repair and replacement

It is recommended that genuine Lexus parts

be used for repairs to ensure performance

of each system. If non-Lexus parts are used

in replacement or if a repair shop other than

a Lexus dealer performs repairs, confirm

the warranty coverage.

■

Allow inspection and repairs to be per-

formed by a Lexus dealer

●

Lexus technicians are well-trained spe-

cialists and are kept up to date with the

latest service information. They are well

informed about the operation of all sys-

tems on your vehicle.

●

Keep a copy of the repair order. It proves

that the maintenance that has been per-

formed is under warranty coverage. If any

problem should arise while your vehicle is

under warranty, your Lexus dealer will

promptly take care of it.

General maintenance should be per-
formed on a daily basis. This can be
done by yourself or by a Lexus dealer.

Scheduled maintenance should be
performed at specified intervals
according to the maintenance sched-
ule.

For details about maintenance items and
schedules, refer to the “Warranty and Ser-
vice Guide”, “Owner’s Manual Supple-
ment” or “Scheduled Maintenance”.

■

Resetting the message indicating main-

tenance is required

After the required maintenance is pre-

formed according to the maintenance

schedule, please reset the message.

To reset the message, follow the procedures

described below:

Select

on the center display.

Select “Vehicle customize”.

Select “Utility”.

Select “Scheduled maintenance”.

Select “Reset”.

“The data has been reset” will be displayed

Maintenance requirements

To ensure safe and economical driv-
ing, day-to-day care and regular
maintenance are essential. It is the
owner’s responsibility to perform
regular checks. Lexus recommends
the following maintenance:

WARNING

■

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble death or serious injury.

■

Handling of the 12-volt battery

●

Engine exhaust, some of its constitu-

ents, and a wide variety of automobile

components contain or emit chemicals

known to the State of California to

cause cancer and birth defects and

other reproductive harm. Work in a

well ventilated area.

●

Oils, fuels and fluids contained in vehi-

cles as well as waste produced by

component wear contain or emit

chemicals known to the State of Cali-

fornia to cause cancer and birth

defects or other reproductive harm.

Avoid exposure and wash any affected

area immediately.

●

12-volt battery posts, terminals and

related accessories contain lead and

lead compounds which are known to

cause brain damage. Wash your hands

after handling. (



P.455)

General maintenance

Scheduled maintenance

441

6-2. Maintenance

Mai
nte

e a

are

on the center display when the reset proce-

dure has been completed.

You can perform some maintenance
procedures by yourself.
Please be aware that do-it-yourself
maintenance may affect warranty cov-
erage.

The use of Lexus repair manuals is recom-
mended.
For details about warranty coverage, refer
to the separate “Owner’s Guide”, “War-
ranty and Service Guide”, “Owner’s Man-
ual Supplement” or “Warranty Booklet”.

Do-it-yourself maintenance

General maintenance

Listed below are the general main-
tenance items that should be per-
formed at the intervals specified in
the “Owner’s Warranty Informa-
tion Booklet” or “Owner’s Manual
Supplement/Scheduled Mainte-
nance Guide”. It is recommended
that any problem you notice should
be brought to the attention of your
Lexus dealer or qualified service
shop for advice.

WARNING

■

If the hybrid system is operating

Turn the hybrid system off and ensure

that there is adequate ventilation before

performing maintenance checks.

Engine compartment

Items

Check points

Brake fluid

Is the brake fluid at the
correct level?
(



P.453)

Engine/inter-
cooler/power
control unit cool-
ant

Is the engine/inter-
cooler/power control
unit coolant at the cor-
rect level? (



P.452)

Engine oil

Is the engine oil at the
correct level?
(



P.449)

Exhaust system

There should not be
any fumes or strange
sounds.

442

6-2. Maintenance

Radiator, con-
denser and inter-
cooler radiator

The radiator, con-
denser and inter-
cooler radiator should
be free from foreign
objects. (



P.453)

Washer fluid

Is there sufficient
washer fluid?
(



P.454)

Luggage compartment

Items

Check points

12-volt battery

Check the connec-
tions. (



P.455)

Vehicle interior

Items

Check points

Accelerator
pedal

• The accelerator

pedal should move
smoothly (without
uneven pedal effort
or catching).

Automatic trans-
mission “Park”
mechanism

• When parked on a

slope and the shift
position is in P, is the
vehicle securely
stopped?

Items

Check points

Brake pedal

• Does the brake

pedal move
smoothly?

• Does the brake

pedal have appro-
priate clearance
from the floor?
(



P.537)

• Does the brake

pedal have the cor-
rect amount of free
play? (



P.537)

Brakes

• The vehicle should

not pull to one side
when the brakes are
applied.

• The brakes should

work effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get too
close to the floor
when the brakes are
applied.

Head restraints

• Do the head

restraints move
smoothly and lock
securely?

Indicators/buzz-
ers

• Do the indicators

and buzzers function
properly?

Lights

• Do all the lights

come on?

• Are the headlights

aimed correctly?
(



P.479)

Items

Check points

443

6-2. Maintenance

Mai
nte

e a

are

Parking brake

• Does the parking

brake switch oper-
ate normally?

• When parked on a

slope and the park-
ing brake is on, is the
vehicle securely
stopped?

Seat belts

• Do the seat belts

operate smoothly?

• The seat belts should

not be damaged.

Seats

• Do the seat controls

operate properly?

Steering wheel

• Does the steering

wheel rotate
smoothly?

• Does the steering

wheel have the cor-
rect amount of free
play?

• There should not be

any strange sounds
coming from the
steering wheel.

Vehicle exterior

Items

Check points

Doors

• Do the doors oper-

ate smoothly?

Engine hood

• Does the engine

hood lock system
work properly?

Fluid leaks

• There should not be

any signs of fluid
leakage after the
vehicle has been
parked.

Items

Check points

Tires

• Is the tire inflation

pressure correct?

• The tires should not

be damaged or
excessively worn.

• Have the tires been

rotated according to
the maintenance
schedule?

• The wheel nuts

should not be loose.

Windshield wip-
ers/rear window
wiper

• The wiper blades

should not show any
signs of cracking,
splitting, wear, con-
tamination or defor-
mation.

• The wiper blades

should clear the
windshield/rear win-
dow without streak-
ing or skipping.

Items

Check points

444

6-2. Maintenance

The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.



When the 12-volt battery is discon-
nected or discharged

Readiness codes that are set during ordi-
nary driving are erased.
Also, depending on your driving habits, the
readiness codes may not be completely
set.



When the fuel tank cap is loose

The malfunction indicator lamp comes on
indicating a temporary malfunction and
your vehicle may not pass the I/M test.

The error code in the OBD system will
not be cleared unless the vehicle is
driven 40 or more times.

Contact your Lexus dealer to prepare
the vehicle for re-testing.

Emission inspection and
maintenance (I/M) pro-
grams

Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.

If the malfunction indicator lamp
comes on

Your vehicle may not pass the
I/M test in the following situa-
tions:

When the malfunction indicator
lamp still remains on after sev-
eral driving trips

If your vehicle does not pass the
I/M test

445

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

6-3.Do-it-yourself maintenance

Do-it-yourself service pre-
cautions

If you perform maintenance by
yourself, be sure to follow the cor-
rect procedure as given in these
sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(



P.455)

• Grease
• Conventional

wrench (for terminal
clamp bolts)

Brake fluid level
(



P.453)

• FMVSS No.116 DOT

3 or SAE J1703
brake fluid
FMVSS No.116 DOT
4 or SAE J1704
brake fluid

• Rag or paper towel
• Funnel (used only for

adding brake fluid)

Engine/inter-
cooler/power
control coolant
level (



P.452)

• “Toyota Super Long

Life Coolant” or a
similar high quality
ethylene gly-
col-based non-sili-
cate, non-amine,
non-nitrite and
non-borate coolant
with long-life hybrid
organic acid tech-
nology
For the U.S.A.:
“Toyota Super Long
Life Coolant” is
pre-mixed with 50%
coolant and 50%
deionized water.
For Canada:
“Toyota Super Long
Life Coolant” is
pre-mixed with 55%
coolant and 45%
deionized water.

• Funnel (used only for

adding coolant)

Engine oil level
(



P.449)

• “Toyota Genuine

Motor Oil” or equiv-
alent

• Rag or paper towel
• Funnel (used only for

adding engine oil)

Fuses (



P.477)

• Fuse with same

amperage rating as
original

Headlight aim
(



P.479)

• Phillips-head screw-

driver

Radiator, con-
denser and inter-
cooler radiator
(



P.453)



Items

Parts and tools

446

6-3. Do-it-yourself maintenance

Tire inflation pres-
sure (



P.467)

• Tire pressure gauge
• Compressed air

source

Washer fluid
(



P.454)

• Water or washer

fluid containing anti-
freeze (for winter
use)

• Funnel (used only for

adding water or
washer fluid)

WARNING

The engine compartment contains many

mechanisms and fluids that may move

suddenly, become hot, or become elec-

trically energized. To avoid death or seri-

ous injury, observe the following

precautions.

■

When working on the engine com-

partment

●

Make sure that the “ACCESSORY” or

“POWER ON” on the multi-informa-

tion display and the “READY” indica-

tor are both off.

●

Keep hands, clothing and tools away

from the moving fan.

●

Be careful not to touch the engine,

power control unit, radiator, exhaust

manifold, etc. right after driving as they

may be hot. Oil and other fluids may

also be hot.

●

Do not leave anything that may burn

easily, such as paper and rags, in the

engine compartment.

■

When working near the electric cool-

ing fan or radiator grille

Be sure the power switch is off.

With the power switch in ON, the elec-

tric cooling fan may automatically start to

run if the air conditioning is on and/or the

coolant temperature is high. (



P.453)

Items

Parts and tools

■

Safety glasses

Wear safety glasses to prevent flying or

falling material, fluid spray, etc. from get-

ting in your eyes.

NOTICE

■

If you remove the air cleaner filter

Driving with the air cleaner filter

removed may cause excessive engine

wear due to dirt in the air.

447

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Pull the hood lock release lever.

The hood will pop up slightly.

Pull up the auxiliary catch lever and
lift the hood.

■

Closing the hood

When closing the hood, make sure to

release it from a slightly high position

(approximately 7.9 in. [20 cm]) to close it.
If the hood is pushed by hand to close it, it

may not lock on both sides.

Hood

Opening the hood

WARNING

■

When the hood is open

Even if the power switch is turned off, the

cooling fan may continue to operate for a

short time. When the cooling fan is rotat-

ing, do not touch or approach the inside

of the engine compartment.

■

Pre-driving check

Check that the hood is fully closed and

locked.

If the hood is not locked properly, it may

open while the vehicle is in motion and

cause an accident, which may result in

death or serious injury.

449

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Fuse boxes (



P.477)

Engine oil filler cap (



P.451)

Brake fluid reservoir (



P.453)

Washer fluid tank (



P.454)

Radiator (



P.453)

Electric cooling fan
Condenser (



P.453)

Engine oil level dipstick (



P.449)

Intercooler radiator (



P.453)

Intercooler/Power control unit coolant reservoir (



P.452)

Engine coolant reservoir (



P.452)

■

12-volt battery



P.455

With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.

Engine compartment

Components

Checking the engine oil

450

6-3. Do-it-yourself maintenance

Park the vehicle on level ground.
After warming up the engine and
turning off the hybrid system, wait
about 5 minutes for the oil to drain
back into the bottom of the engine.

Holding a rag under the end, pull
the dipstick out.

Wipe the dipstick clean.

Reinsert the dipstick fully.

Holding a rag under the end, pull
the dipstick out and check whether
the oil level is above low level mark.

Low level mark

The shape of the dipstick may differ

depending on the type of vehicle or

engine.

Wipe the dipstick and reinsert it
fully.

■

Engine oil consumption

A certain amount of engine oil will be con-

sumed while driving. In the following situa-

tions, oil consumption may increase, and

engine oil may need to be refilled in

between oil maintenance intervals.

●

When the engine is new, for example

directly after purchasing the vehicle or

after replacing the engine

●

If low quality oil or oil of an inappropriate

viscosity is used

●

When driving at high engine speeds or
with a heavy load, when towing

, or when

driving while accelerating or decelerat-

ing frequently

●

When leaving the engine idling for a long

time, or when driving frequently through

heavy traffic

: Vehicles with towing package

■

Engine oil level rise

If the vehicle is repeatedly driven without

the engine warmed up, moisture caused by

dew condensation inside the engine or fuel

which did not burn mixes into the engine oil,

resulting in a rise in engine oil level. How-

ever, this is not a malfunction.
For example, the engine become difficult to

be warmed up in the following situations.

●

When driving a short distance

●

When driving at a low speed

●

When the outside temperature is low

When checking the engine oil, make sure

that the engine is warmed up. If the engine

oil level exceeds the refill upper limit mark,

contact your Lexus dealer.

NOTICE

■

To prevent serious engine damage

Check the oil level on a regular basis.

451

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

Checking the oil type and prepar-
ing the item needed

Make sure to check the oil type and
prepare the items needed before add-
ing oil.



Engine oil selection



P.534



Oil quantity (Low level mark



Refill upper limit mark)
1.6 qt. (1.5 L, 1.3 Imp. qt.)



Item
Clean funnel

■

Adding engine oil

If the oil level is below or near the low
level mark, add engine oil of the same
type as that already in the engine.

Remove the oil filler cap by turning
it counterclockwise.

Add engine oil slowly, checking the
dipstick.

Make sure that the oil level does not

exceed the refill upper limit mark and is

between the low level mark and refill upper

limit mark.

Low level mark
Refill upper limit mark

The shape of the dipstick may differ
depending on the type of vehicle or
engine.

Install the oil filler cap by turning it
clockwise.

■

After changing the engine oil

After the engine oil has been replaced, the

engine oil maintenance data should be

reset. Perform the following procedures:

Select

on the center display.

Select “Vehicle customize”.

Select “Utility”.

Select “Oil maintenance”.

Select “Reset”.

“The data has been reset” will be displayed

on the center display when the resetproce-

dure has been completed.

Adding engine oil

WARNING

■

Used engine oil

●

Used engine oil contains potentially

harmful contaminants which may

cause skin disorders such as inflamma-

tion and skin cancer, so care should be

taken to avoid prolonged and

repeated contact. To remove used

engine oil from your skin, wash thor-

oughly with soap and water.

452

6-3. Do-it-yourself maintenance

■

Engine coolant reservoir

The coolant level is satisfactory if it is
between the “MAX” and “MIN” lines
on the reservoir when the hybrid sys-
tem is cold.

Reservoir cap
“MAX” line
“MIN” line

If the level is on or below the “MIN” line,
add coolant up to the “MAX” line.
(



P.526)

■

Intercooler/Power control unit
coolant reservoir

The coolant level is satisfactory if it is
between the “MAX” and “MIN” lines
on the reservoir when the hybrid sys-
tem is cold.

Reservoir cap
“MAX” line
“MIN” line

If the level is on or below the “MIN” line,
add coolant up to the “MAX” line.
(



P.526)

■

Coolant selection

Only use “Toyota Super Long Life Coolant”

WARNING

●

Dispose of used oil and filters only in a

safe and acceptable manner. Do not

dispose of used oil and filters in house-

hold trash, in sewers or onto the

ground.

Call your Lexus dealer, service station

or auto parts store for information

concerning recycling or disposal.

●

Do not leave used engine oil within the

reach of children.

NOTICE

■

When replacing the engine oil

●

Be careful not to spill engine oil on the

vehicle components.

●

Avoid overfilling, or the engine could

be damaged.

●

Check the oil level on the dipstick

every time you refill the vehicle.

●

Be sure the engine oil filler cap is prop-

erly tightened.

■

If oil is spilled on the engine cover

To prevent the engine cover from being

damaged, remove any engine oil from

the engine cover as soon as possible

using a neutral detergent. Do not use an

organic solvent such as brake cleaner.

Checking the coolant

453

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

or a similar high quality ethylene glycol

based non-silicate, non-amine, non-nitrite,

and non-borate coolant with long-life

hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is a mix-

ture of 50% coolant and 50% deionized

water. (Minimum temperature: -31°F

[-35°C])
Canada:
“Toyota Super Long Life Coolant” is a mix-

ture of 55% coolant and 45% deionized

water. (Minimum temperature: -44°F

[-42°C])
For more details about coolant, contact

your Lexus dealer.

■

If the coolant level drops within a short

time of replenishing

Visually check the radiator, hoses,

engine/power control unit coolant reservoir

caps, drain cock and water pump.

If you cannot find a leak, have your Lexus

dealer test the cap and check for leaks in

the cooling system.

Check the radiator, condenser and
intercooler radiator and clear away
any foreign objects.
If any of the above parts are extremely
dirty or you are not sure of their condi-
tion, have your vehicle inspected by
your Lexus dealer.

■

Checking fluid level

The brake fluid level should be
between the “MAX” and “MIN” lines
on the tank.

■

Adding fluid

Make sure to check the fluid type and
prepare the necessary item.

WARNING

■

When the hybrid system is hot

Do not remove the engine/inter-

cooler/power control unit coolant reser-

voir caps and radiator cap.

The cooling system may be under pres-

sure and may spray hot coolant if the cap

is removed, causing serious injuries, such

as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct mixture

of water and antifreeze must be used to

provide proper lubrication, corrosion

protection and cooling. Be sure to read

the antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to pre-

vent it from damaging parts or paint.

Checking the radiator, con-
denser and intercooler radiator

WARNING

■

When the hybrid system is hot

Do not touch the radiator, condenser or

intercooler radiator as they may be hot

and cause serious injuries, such as burns.

Checking and adding the brake
fluid

454

6-3. Do-it-yourself maintenance



Fluid type

FMVSS No.116 DOT 3 or SAE J1703
brake fluid
FMVSS No.116 DOT 4 or SAE J1704
brake fluid



Item

Clean funnel

■

Brake fluid can absorb moisture from

the air

Excess moisture in the brake fluid can cause

a dangerous loss of braking efficiency. Use

only newly opened brake fluid.

If any washer does not work or the
warning message appears on the
multi-information display, the washer
tank may be empty. Add washer fluid.

WARNING

■

When filling the reservoir

Take care as brake fluid can harm your

hands and eyes and damage painted sur-

faces.

If fluid gets on your hands or in your eyes,

flush the affected area with clean water

immediately.

If you still experience discomfort, see a

doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level to go

down slightly as the brake pads wear out

or when the fluid level in the accumulator

is high.

If the reservoir needs frequent refilling,

there may be a serious problem.

Washer fluid

WARNING

■

When adding washer fluid

Do not add washer fluid when the hybrid

system is hot or operating as washer fluid

contains alcohol and may catch fire if

spilled on the engine, etc.

NOTICE

■

Do not use any fluid other than

washer fluid

Do not use soapy water or engine anti-

freeze instead of washer fluid.

Doing so may cause streaking on the

vehicle’s painted surfaces, as well as

damaging the pump leading to problems

of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as neces-

sary.

Refer to the freezing temperatures listed

on the label of the washer fluid bottle.

455

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

The 12-volt battery is located in the
right-hand side of luggage compart-
ment.

■

Before recharging

When recharging, the 12-volt battery pro-

duces hydrogen gas which is flammable

and explosive. Therefore, observe the fol-

lowing precautions before recharging:

●

If recharging with the 12-volt battery

installed on the vehicle, be sure to discon-

nect the ground cable.

●

Make sure the power switch on the char-

ger is off when connecting and discon-

necting the charger cables to the 12-volt

battery.

■

After recharging/reconnecting the

12-volt battery

●

Unlocking the doors using the smart

access system with push-button start may

not be possible immediately after recon-

necting the 12-volt battery. If this hap-

pens, use the wireless remote control or

the mechanical key to lock/unlock the

doors.

●

Start the hybrid system with the power

switch in ACC. The hybrid system may

not start with the power switch turned off.

However, the hybrid system will operate

normally from the second attempt.

●

The power switch mode is recorded by

the vehicle. If the 12-volt battery is dis-

connected and reconnected, the vehicle

will return the power switch mode to the

status it was in before the 12-volt battery

was disconnected. Make sure to turn off

the power switch before disconnecting

the 12-volt battery. Take extra care when

connecting the 12-volt battery if the

power switch mode prior to the 12-volt

battery being disconnected is unknown.

If the system will not start even after multiple

attempts at all the methods above, contact

your Lexus dealer.

12-volt battery

Location

WARNING

■

Chemicals in the 12-volt battery

The 12-volt battery contains poisonous

and corrosive sulfuric acid and may pro-

duce hydrogen gas which is flammable

and explosive. To reduce the risk of death

or serious injury, take the following pre-

cautions while working on or near the

12-volt battery:

●

Do not cause sparks by touching the

12-volt battery terminals with tools.

●

Do not smoke or light a match near the

12-volt battery.

●

Avoid contact with eyes, skin and

clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when

working near the 12-volt battery.

●

Keep children away from the 12-volt

battery.

■

Where to safely charge the 12-volt

battery

Always charge the 12-volt battery in an

open area. Do not charge the 12-volt bat-

tery in a garage or closed room where

there is insufficient ventilation.

■

How to recharge the 12-volt battery

Only perform a slow charge (5 A or

less). The 12-volt battery may explode if

charged at a quicker rate.

456

6-3. Do-it-yourself maintenance

Open the deck board. (



P.406)

Disengage the 7 claws and pull the
side deck board to remove it.

Disengage the 5 claws and pull the
cover to remove it.

Make sure that the 12-volt battery ter-
minals are not corroded and that there
are no loose connections, cracks, or
loose clamps.

WARNING

■

Emergency measures regarding

electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean water for at

least 15 minutes and get immediate

medical attention. If possible, continue

to apply water with a sponge or cloth

while traveling to the nearest medical

facility.

●

If electrolyte gets on your skin

Wash the affected area thoroughly. If

you feel pain or burning, get medical

attention immediately.

●

If electrolyte gets on your clothes

It can soak through clothing on to your

skin. Immediately take off the clothing

and follow the procedure above if nec-

essary.

●

If you accidentally swallow electrolyte

Drink a large quantity of water or milk.

Get emergency medical attention

immediately.

■

When replacing the 12-volt battery

Use a 12-volt battery designed for this

vehicle. Failure to do so may cause gas

(hydrogen) to enter the passenger com-

partment, causing a fire or explosion.

For replacement of the 12-volt battery,

contact your Lexus dealer.

■

When handling the 12-volt battery



P.525

NOTICE

■

When recharging the 12-volt battery

Never recharge the 12-volt battery while

the hybrid system is operating. Also, be

sure all accessories are turned off.

Removing the 12-volt battery
cover

Exterior

457

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Terminals
Hold-down clamp

Check if the treadwear indicators are
showing on the tires. Also check the
tires for uneven wear, such as excessive
wear on one side of the tread.
Check the spare tire condition and
pressure if not rotated.

New tread
Worn tread
Treadwear indicator

The location of treadwear indicators is
shown by a “TWI” or “

” mark, etc.,

molded into the sidewall of each tire.
Replace the tires if the treadwear indica-
tors are showing on a tire.

Tires

Replace or rotate tires in accor-
dance with maintenance schedules
and treadwear.

Checking tires

458

6-3. Do-it-yourself maintenance

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on

a tire.

●

You have tire damage such as cuts, splits,

cracks deep enough to expose the fabric,

and bulges indicating internal damage.

●

A tire goes flat repeatedly or cannot be

properly repaired due to the size or loca-

tion of a cut or other damage.

If you are not sure, consult with your Lexus

dealer.

■

Tire life

Any tire over 6 years old must be checked

by a qualified technician even if it has sel-

dom or never been used or damage is not

obvious.

■

Maximum load of tire

Check that the number given by dividing

the maximum load by 1.10 of the replace-

ment tire is greater than 1/2 of the Gross

Axle Weight Ratings (GAWR) of either the

front axle or the rear axle, whichever is

greater.
For the GAWR, see the Certification Label.

For the maximum load of the tire, see the

load limit at maximum cold tire inflation

pressure mentioned on the sidewall of the

tire. (



P.541)

■

Tire types

●

Summer tires

Summer tires are high-speed performance
tires best suited to highway driving under
dry conditions. Since summer tires do not
have the same traction performance as
snow tires, summer tires are inadequate for
driving on snow-covered or icy roads. For

driving on snow-covered roads or icy
roads, the use of snow tires is recom-
mended. When installing snow tires, be
sure to replace all four tires.

●

All season tires

All season tires are designed to provide
better traction in snow and to be adequate
for driving in most winter conditions as well
as for use year-round. All season tires,
however, do not have adequate traction
performance compared with snow tires in
heavy or loose snow. Also, all season tires
fall short in acceleration and handling per-
formance compared with summer tires in
highway driving.

●

Snow tires

For driving on snow-covered roads or icy
roads, we recommend using snow tires. If
you need snow tires, select tires of the
same size, construction and load capacity
as the originally installed tires. Since your
vehicle has radial tires as original equip-
ment, make sure your snow tires also have
radial construction. Do not install studded
tires without first checking local regula-
tions for possible restrictions. Snow tires
should be installed on all wheels. (



P.374)

■

If the tread on snow tires wears down

below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is

lost.

■

Checking the tire valves

When replacing the tires, check the tire

valves for deformation, cracks, and other

damage.

459

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Rotate the tires in the order shown.

To equalize tire wear and extend tire life,
Lexus recommends that tire rotation is car-
ried out at the same interval as tire inspec-
tion.
Make sure to perform wheel position reg-
istration procedure after rotating the tires.
(



P.461)

Your vehicle is equipped with a tire
pressure warning system that uses tire
pressure warning valves and transmit-
ters to detect low tire inflation pressure
before serious problems arise.
The tire pressure warning system of
this vehicle adopts a 2-type warning
system. (



P.492)



When “Adjust Pressure” is dis-
played on the multi-information dis-
play (Normal Warning)

A warning with the tire pressure warning
light and warning buzzer when there is an
unknown level of low tire pressure with the
appearance of the tire due to natural air
leakage as well as the pressure lowering
due to changes in the pressure according
to the outside temperature.

WARNING

■

When inspecting or replacing tires

Observe the following precautions to

prevent accidents.

Failure to do so may cause damage to

parts of the drive train as well as danger-

ous handling characteristics, which may

lead to an accident resulting in death or

serious injury.

●

Do not mix tires of different makes,

models or tread patterns.

Also, do not mix tires of remarkably

different treadwear.

●

Do not use tire sizes other than those

recommended by Lexus.

●

Do not mix differently constructed

tires (radial, bias-belted or bias-ply

tires).

●

Do not mix summer, all season and

snow tires.

●

Do not use tires that have been used

on another vehicle.

Do not use tires if you do not know

how they were used previously.

●

Do not tow if your vehicle has a spare

tire installed.

NOTICE

■

Driving on rough roads

Take particular care when driving on

roads with loose surfaces or potholes.

These conditions may cause losses in tire

inflation pressure, reducing the cushion-

ing ability of the tires. In addition, driving

on rough roads may cause damage to

the tires themselves, as well as the vehi-

cle’s wheels and body.

■

If tire inflation pressure of each tire

becomes low while driving

Do not continue driving, or your tires

and/or wheels may be ruined.

Tire rotation

Tire pressure warning system

460

6-3. Do-it-yourself maintenance



When “Immediately Check tire
when Safe” is displayed on the
multi-information display (Emer-
gency Warning)

A warning with the tire pressure warning
light and warning buzzer when there is a
known level of low tire pressure with the
appearance of the tire due to pressure sud-
denly lowering. (Ways of coping:



P.492

505)

However, the system may not be able to
detect sudden tire ruptures (bursting, etc.).



The tire pressure detected by the
tire pressure warning system can be
displayed on the center display.
(



P.96)



Multi-information display



Center display

■

Routine tire inflation pressure checks

The tire pressure warning system does not

replace routine tire inflation pressure

checks. Make sure to check tire inflation

pressure as part of your routine of daily

vehicle checks.

■

Tire inflation pressure

●

It may take a few minutes to display the

tire inflation pressure after the power

switch is turned to ON. It may also take a

few minutes to display the tire inflation

pressure after inflation pressure has been

adjusted.

●

Tire inflation pressure changes with tem-

perature. The displayed values may also

be different from the values measured

using a tire pressure gauge.

■

Situations in which the tire pressure

warning system may not operate prop-

erly

●

In the following cases, the tire pressure

warning system may not operate prop-

erly.

• If non-genuine Lexus wheels are used.

• A tire has been replaced with a tire that is

not an OE (Original Equipment) tire.

• A tire has been replaced with a tire that is

not of the specified size.

• Tire chains, etc. are equipped.

• If a window tint that affects the radio wave

signals is installed.

• If there is a lot of snow or ice on the vehi-

cle, particularly around the wheels or

wheel housings.

• If the tire inflation pressure is extremely

higher than the specified level.

• If tires not equipped with tire pressure

warning valves and transmitters are used.

• If the ID code on the tire pressure warn-

ing valves and transmitters is not regis-

tered in the tire pressure warning

computer.

●

Performance may be affected in the fol-

lowing situations.

• Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

• When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

●

If tire position information is not correctly

displayed due to the radio wave condi-

tions, the display may be corrected by

changing the location of the vehicle as

the radio wave conditions may change.

461

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

●

When the vehicle is parked, the time

taken for the warning to start or go off

could be extended.

●

When tire inflation pressure declines rap-

idly for example when a tire has burst, the

warning may not operate.

When replacing tires or wheels, tire
pressure warning valves and transmit-
ters must also be installed.
When new tire pressure warning
valves and transmitters are installed,
new ID codes must be registered in the
tire pressure warning computer.
(



P.464)

■

Replacing tires and wheels

If the ID code of the tire pressure warning

valve and transmitter is not registered, the

tire pressure warning system will not work

properly. In this case, after driving for about

20 minutes, the tire pressure warning light

blinks for 1 minute and stays on to indicate a

system malfunction.

■

When to register the position of
each wheel

It is necessary to register the position
of each wheel after performing a tire
rotation.
Wheel position registration can be
performed by oneself. Wheel position
registration is performed by driving
forward with moderate left and right
turns. However, depending on the driv-
ing conditions and driving environ-
ment, registration may take some time
to complete.

■

Registering the position of each
wheel

Park the vehicle in a safe place, turn
the power switch off and wait 15
minutes or more.

Start the hybrid system.

The wheel position registration procedure

cannot be performed while the vehicle is

moving.

Select

on the center display.

Installing tire pressure warning
valves and transmitters

NOTICE

■

Repairing or replacing tires, wheels,

tire pressure warning valves, trans-

mitters and tire valve caps

●

When removing or fitting the wheels,

tires or the tire pressure warning

valves and transmitters, contact your

Lexus dealer as the tire pressure warn-

ing valves and transmitters may be

damaged if not handled correctly.

●

Make sure to install the tire valve caps.

If the tire valve caps are not installed,

water could enter the tire pressure

warning valves, corrode the valve, and

cause sticking and air leaks.

●

When replacing tire valve caps, do not

use tire valve caps other than those

specified. The cap may become stuck.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact your Lexus

dealer or other qualified service shop as

soon as possible. Make sure to replace

the tire pressure warning valve and trans-

mitter when replacing the tire. (



P.461)

Registering the position of each
wheel

462

6-3. Do-it-yourself maintenance

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Tire rotation”.

Select “Continue”.

A message indicating that wheel position

registration is being performed will be dis-

played on the multi-information display.

“---” will be displayed for the tire inflation

pressure of each tire and wheel position

registration will begin.

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

When wheel position registration is com-

plete, a message indicating that registra-

tion has been completed and the inflation

pressure of each tire will be displayed on

the multi-information display.
Even if it is not possible to drive continu-

ously at approximately 25 mph (40 km/h)

or more, registration can be completed by

driving for a long time. However, if registra-

tion does not complete after driving for 1

hour or more, park the vehicle in a safe

place and leave it with the power switch in

ON for approximately 15 minutes or more,

and then perform the driving procedure

again.

■

When performing wheel position regis-

tration

●

Normally, wheel position registration can

be completed within approximately 30

minutes.

●

Wheel position registration is performed

while driving at a vehicle speed of

approximately 25 mph (40 km/h) or

more.

■

Wheel position registration procedure

●

If the power switch is turned off while reg-

istering the wheel position, the next time

the power switch is turned to ON, the

wheel position registration will resume

and it will not be necessary to restart the

procedure.

●

While the position of each wheel is being

determined and the inflation pressures

are not being displayed, if the inflation

pressure of a tire drops, the tire pressure

warning light will come on.

■

If the wheel position cannot be regis-

tered easily

●

In the following situations, wheel position

registration may take longer than usual to

be completed or may not be possible.

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads

●

If wheel position registration does not

complete after driving for 1 hour or more,

park the vehicle in a safe place for

approximately 15 minutes and then drive

the vehicle again.

●

If the vehicle is reversed during wheel

position registration, all data collected

until then will be cleared. Perform driving

again.

■

When you need to setting the tire
pressure

In the following situations, it will be nec-
essary to perform the tire inflation
pressure setting procedure of the tire
pressure warning system.



When the specified tire inflation
pressure has changed, such as due
to carried load, etc.



When the tire inflation pressure is
changed such as when the tire size
is changed.

If the tire inflation pressure has been
adjusted to the specified level, perform
the tire inflation setting procedure by
selecting specified inflation pressure
on the center display. (



P.463)

When the tire inflation pressure is to be

Setting the tire pressure

463

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

other than specified, such as when tires
other than the specified size are used,
etc., set the tire inflation pressure using
the current pressure. Make sure to
adjust the tire inflation pressure of each
tire to the appropriate level before per-
forming tire pressure setting. The tire
pressure warning system operates
based on this tire inflation pressure.
(



P.463)

■

Setting by selecting a specified tire
inflation pressure

Park the vehicle in a safe place and
then start the hybrid system.

The tire inflation pressure cannot be set

while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Set indicated air pressure”
and then select the desired front
and rear tire pressures. (



P.467)

Select “OK”.

The tire pressure warning light will slowly

blink 3 times.
After setting the tire inflation pressure, a

message indicating that setting has been

completed will be displayed on the

multi-information display.

■

Setting using the current tire infla-
tion pressure

Adjust the tire inflation pressure of
each tire to the appropriate level.

Make sure to adjust the tire inflation pres-

sure with the tires cold.

Start the hybrid system.

The tire inflation pressure cannot be set

while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Set current air pressure”.

Select “Continue”.

The tire pressure warning light will slowly

blink 3 times and a message indicating that

tire inflation pressure is being set will be

displayed on the multi-information display.
After setting the tire inflation pressure, a

message indicating that setting has been

completed will be displayed on the

multi-information display.

■

Warning performance of the tire pres-

sure warning system (Setting using the

current tire inflation pressure)

●

When performing the tire pressure set-

ting using the current tire inflation pres-

sure, the warning timing of the tire

pressure warning system will vary

according to the conditions under which

tire pressure setting was performed.

Therefore, a warning may be output even

if the tire inflation pressure drops slightly

464

6-3. Do-it-yourself maintenance

or if the tire inflation pressure increases

above that when the tire inflation pres-

sure was set.

●

Make sure to perform the tire pressure

setting procedure after adjusting the tire

inflation pressure. Also, make sure the

tires are cold before performing the tire

pressure setting procedure or adjusting

the tire inflation pressure.

■

Tire inflation pressure setting proce-

dure (Setting using the current tire infla-

tion pressure)

●

If the power switch is turned off while set-

ting the tire inflation pressure, the next

time the power switch is turned to ON,

the setting procedure will resume and it

will not be necessary to restart the proce-

dure.

●

If the tire inflation pressure setting proce-

dure is started unnecessarily, adjust the

tire inflation pressure to the specified

level with the tires cold and then perform

setting by selecting a specified tire infla-

tion pressure, or perform the tire inflation

pressure setting procedure with the cur-

rent tire inflation pressure.

■

If the tire inflation pressure cannot be

set easily

●

Normally, it takes approximately 3 min-

utes to complete the setting procedure to

the current tire inflation pressure.

●

If the tire pressure warning light does not

blink 3 times when starting the tire infla-

tion pressure setting procedure, the pro-

cedure may not have started. Perform the

procedure again from the beginning.

●

If tire inflation pressure setting procedure

cannot be completed after performing

the above procedure, contact your Lexus

dealer.

■

When to register ID codes

The tire pressure warning valve and
transmitter is equipped with a unique
ID code. When new tire pressure
warning valves and transmitters are
installed, new ID codes must be regis-
tered in the tire pressure warning com-
puter.

■

How to registration ID code

Before performing ID code registra-
tion, make sure that no wheels with tire
pressure warning valve and transmit-
ters installed are near the vehicle.

Park the vehicle in a safe place, turn
the power switch off and wait 15
minutes or more.

Start the hybrid system.

The ID code registration procedure cannot

be performed while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Check if the desired wheel set (“Set
1” or “Set 2”) is displayed.

ID codes will be registered to the displayed

WARNING

■

When setting using the current tire

inflation pressure

Make sure to adjust the tire inflation

pressure of each tire to the appropriate

level before performing tire pressure set-

ting. Otherwise, the tire pressure warn-

ing light may not illuminate even if the tire

inflation pressure drops or may illuminate

even though the tire inflation pressure is

normal.

Registering ID codes

465

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

wheel set.
To change the wheel set to be registered,

select the displayed set, and then select the

wheel set you wish to register.
If ID codes have already been registered

for that wheel set, the tire pressure warning

light will slowly blink 3 times, and a mes-

sage indicating that change is occurring

will be displayed on the multi-information

display.

Select “New tire registration”.

Select “Continue”.

The tire pressure warning light will slowly

blink 3 times and a message indicating that

ID code registration is being performed

will be displayed on the multi-information

display. Wheel set changing will be can-

celed and registration will begin.
When registration is being performed, the

tire pressure warning light will blink for

approximately 1 minute then illuminate and

“---” will be displayed for the inflation pres-

sure of each tire on the multi-information

display.

Drive straight (with occasional left
and right turns) at approximately

25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

When registration is complete, the tire

pressure warning light will turn off and a

message indicating that registration has

been completed will be displayed on the

multi-information display.
Registration may take longer than normal

to complete if the vehicle speed cannot be

maintained at approximately 25 mph (40

km/h) or more. If registration cannot be

completed after driving for 1 hour or more,

perform the registration procedure again

from the beginning.

If the tire inflation pressure of the
wheel set installed differs from that
of the previous set, it will be neces-
sary to perform the tire inflation
pressure setting procedure of the
tire pressure warning system.
(



P.462)

If the specified tire inflation pressure is the

same, it will not be necessary to perform

the tire inflation pressure setting proce-

dure.

■

When registering ID codes

●

Normally, wheel position registration can

be completed within approximately 30

minutes.

●

ID code registration is performed while

driving at a vehicle speed of approxi-

mately 25 mph (40 km/h) or more.

●

ID codes can be registered by yourself,

but depending on the driving conditions

and driving environment, registration

may take some time to complete.

●

When using a wheel set which all of the

ID codes have already been registered,

the wheel set can be changed in a short

amount of time. (



P.466)

■

If ID codes are not registered easily

●

In the following situations, ID code regis-

tration may take longer than usual to be

completed or may not be possible.

• When the vehicle has not been parked

466

6-3. Do-it-yourself maintenance

for approximately 15 minutes or more

before being driven

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads

• Vehicle is driven near other vehicles and

system cannot recognize tire pressure

warning valve and transmitters of your

vehicle over those of other vehicles

• Wheel with tire pressure warning valve

and transmitter installed is inside or near

the vehicle

●

If the vehicle is reversed during registra-

tion, all data collected until then will be

cleared. Perform driving again.

●

If registration does not complete after

driving for 1 hour or more, perform the ID

code registration procedure again from

the beginning.

●

If the tire pressure warning light does not

blink 3 times when starting ID code reg-

istration procedure, the procedure may

not have started. Perform the procedure

again from the beginning.

●

If the ID codes cannot be registered even

when performing the above procedure,

contact your Lexus dealer.

■

Canceling ID code registration

To cancel ID code registration after it has

been started, select “New tire registration”

again on the center display.
If ID code registration has been canceled,

the tire pressure warning light will turn off.
If the warning light does not turn off, ID
code registration may not have been can-
celled correctly. To cancel registration,
select “New tire registration” again on the
center display.

Your vehicle is equipped with a tire
pressure warning system with a func-
tion to register two sets of ID codes.
This allows for registration of a second
wheel set, for example a winter set.



The wheel set can be changed only
if a second wheel set has been regis-
tered to the system. If a second
wheel set has not been registered,
“Set 2 (Unregistered)” will be dis-
played and it will not be possible to
change to the selected wheel set.

ID codes can be registered by yourself.
(



P.464)



Only a change between both regis-
tered wheel set is possible, mixing
between these wheel sets is not sup-
ported.



While registering ID codes, it may
not be possible to change between
wheel sets normally. Cancel regis-
tration before changing between
wheel sets.

■

Changing ID codes between dif-
ferent wheel sets

Install the desired wheel set.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select the wheel set (“Set 1” or “Set
2”) displayed for the set selection
setting.

Select the wheel set you wish to
register, and then select “OK”.

The tire pressure warning light will slowly

blink 3 times, a message indicating that

change is occurring will be displayed, and

the wheel set change will begin.
Wheel set change will begin and the tire

pressure warning light will blink for 1 min-

ute and then illuminate. Also, while the

change is being performed, “---” will be

displayed for the tire inflation pressure of

each tire on the multi-information display.

Selecting wheel set

467

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

After approximately 2 minutes, the wheel

set change will complete, the tire pressure

warning light will turn off, and a completion

message will be displayed on the

multi-information display.
If changing does not complete after

approximately 4 minutes, a message indi-

cating that the change could not be com-

pleted will be displayed.
Check which wheel set is installed and per-

form the change procedure again from the

beginning.

If the specified tire inflation pres-
sure of the wheel set installed dif-
fers from that of the previous set, it
will be necessary to perform the
tire inflation pressure setting proce-
dure of the tire pressure warning
system. (



P.462)

If the specified tire inflation pressure is the

same, it will not be necessary to perform

the tire inflation pressure setting proce-

dure.



P.461)

■

If “Tire Set Switching Incomplete Try

Tire Set Registration Again See

Owner's Manual” is displayed

The wheel set change could not be com-

pleted.
Check which wheel set is installed and per-

form the change procedure again from the

beginning.

The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
(



P.537)

Tire valve
Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure
gauge onto the tire valve.

Tire inflation pressure

Checking the specified tire infla-
tion pressure

Inspection and adjustment pro-
cedure

468

6-3. Do-it-yourself maintenance

Read the pressure using the gauge
gradations.

If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.

After completing the tire inflation
pressure measurement and adjust-
ment, apply soapy water to the
valve and check for leakage.

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure

every two weeks, or at least once a month.

Do not forget to check the spare.

■

Effects of incorrect tire inflation pres-

sure

Driving with incorrect tire inflation pressure

may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor han-

dling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating, have it

checked by your Lexus dealer.

■

Instructions for checking tire inflation

pressure

When checking tire inflation pressure,

observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at

least 3 hours or has not been driven for

more than 1 mile or 1.5 km, you will get an

accurate cold tire inflation pressure read-

ing.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly

inflated based only on its appearance.

●

It is normal for the tire inflation pressure

to be higher after driving as heat is gen-

erated in the tire. Do not reduce tire infla-

tion pressure after driving.

●

Never exceed the vehicle capacity

weight.

Passengers and luggage weight should

be placed so that the vehicle is balanced.

WARNING

■

Proper inflation is critical to save tire

performance

Keep your tires properly inflated.

If the tires are not properly inflated, the

following conditions may occur which

could lead to an accident resulting in

death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from

overheated tires

●

Air leaking from between tire and

wheel

●

Wheel deformation and/or tire dam-

age

●

Greater possibility of tire damage

while driving (due to road hazards,

expansion joints, sharp edges in the

road, etc.)

NOTICE

■

When inspecting and adjusting tire

inflation pressure

Be sure to put the tire valve caps back on.

If a valve cap is not installed, dirt or mois-

ture may get into the valve and cause an

air leak, resulting in decreased tire infla-

tion pressure.

469

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

When replacing wheels, care should
be taken to ensure that they are equiv-
alent to those removed in load capac-
ity, diameter, rim width and inset

Replacement wheels are available at
your Lexus dealer.

: Conventionally referred to as offset.

Lexus does not recommend using the
following:



Wheels of different sizes or types



Used wheels



Bent wheels that have been straight-
ened

■

When replacing wheels

The wheels of your vehicle are equipped

with tire pressure warning valves and trans-

mitters that allow the tire pressure warning

system to provide advance warning in the

event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pres-

sure warning valves and transmitters must

be installed. (



P.461)

Wheels

If a wheel is bent, cracked or heavily
corroded, it should be replaced.
Otherwise, the tire may separate
from the wheel or cause a loss of
handling control.

Wheel selection

WARNING

■

When replacing wheels

●

Do not use wheels that are a different

size from those recommended in the

Owner’s Manual, as this may result in a

loss of handling control.

●

Never use an inner tube in a leaking

wheel which is designed for a tubeless

tire.

Doing so may result in an accident,

causing death or serious injury.

■

When installing the wheel nuts

Never use oil or grease on the wheel

bolts or wheel nuts.

Oil and grease may cause the wheel nuts

to be excessively tightened, leading to

bolt or disc wheel damage. In addition,

the oil or grease can cause the wheel

nuts to loosen and the wheel may fall off,

causing an accident and resulting in

death or serious injury. Remove any oil or

grease from the wheel bolts or wheel

nuts.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.

Doing so could cause the tire to leak air

during driving, possibly causing an acci-

dent.

NOTICE

■

Replacing tire pressure warning

valves and transmitters

●

Because tire repair or replacement

may affect the tire pressure warning

valves and transmitters, make sure to

have tires serviced by your Lexus

dealer or other qualified service shop.

In addition, make sure to purchase

your tire pressure warning valves and

transmitters at your Lexus dealer.

470

6-3. Do-it-yourself maintenance



Use only Lexus wheel nuts and
wrenches designed for use with
your aluminum wheels.



When rotating, repairing or chang-
ing your tires, check that the wheel
nuts are still tight after driving 1000
miles (1600 km).



Be careful not to damage the alumi-
num wheels when using tire chains.



Use only Lexus genuine balance
weights or equivalent and a plastic
or rubber hammer when balancing
your wheels.

Turn the power switch off.

Open the glove box. Slide off the
damper.

Push in each side of the glove box
to disconnect the claws. Then pull
out the glove box and disconnect
the lower claws.

NOTICE

●

Ensure that only genuine Lexus wheels

are used on your vehicle.

Tire pressure warning valves and trans-

mitters may not work properly with

non-genuine wheels.

Aluminum wheel precautions

Air conditioning filter

The air conditioning filter must be
changed regularly to maintain air
conditioning efficiency.

WARNING

Do not use the Remote Air Conditioning

System. Doing so may result in the air

conditioning system operating during the

procedure, possibly resulting in injury.

Removing the air conditioning
filter

471

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Unlock the filter cover ( ), pull the
filter cover out of the claws ( ),
and remove the filter cover.

Remove the filter case.

There may be foreign objects on top of the

air conditioning filter.

Remove the air conditioning filter
from the filter case and replace it
with a new one.

The “

UP” marks shown on the filter

and the filter case should be pointing up.

■

Checking interval

Inspect and replace the air conditioning fil-

ter according to the maintenance schedule.

In dusty areas or areas with heavy traffic

flow, early replacement may be required.

(For scheduled maintenance information,

please refer to the “Owner’s Manual Sup-

plement” or “Scheduled Maintenance”.)

■

If air flow from the vents decreases dra-

matically

The filter may be clogged. Check the filter

and replace if necessary.

■

Air conditioning filter with deodorizing

function

When fragrances are placed in your vehi-

cle, the deodorizing effect may become

significantly weakened in a short period.

When an air conditioning odor comes out

continuously, replace the air conditioning

filter.

NOTICE

■

When using the air conditioning sys-

tem

●

Make sure that a filter is always

installed. Using the air conditioning

system without a filter may cause dam-

age to the system.

●

The filter is replaceable. When clean-

ing the filter, do not clean with water or

an air gun.

■

To prevent damage to the filter cover

When moving the filter cover in the

direction of arrow to release the fitting,

pay attention not to apply excessive force

to the claws. Otherwise, the claws may

be damaged.

Lexus TX500H (2024 year). Manual in english - page 14
