WARNING

■

Conditions in which the function may not operate correctly

In the following conditions, the wireless charger may not operate correctly

●

The portable device is fully charged

●

There is foreign matter between the charge area and portable device

●

The temperature of the portable device gets higher from charging

●

The charging surface of the portable device is facing up

●

The placement of the portable device is out of alignment with the charge area

●

Near a TV tower, electric power plant, gas station, radio station, large display, airport

or other facility that generates strong radio waves or electrical noise

●

When the electronic key is in contact with, or is covered by the following metallic

objects
• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit radio waves) are being used nearby

In addition, excluding the above-mentioned, when the charger does not perform nor-

mally or the operation indicator light is flashing continuously, it is considered that the

wireless charger is malfunctioning. Contact your Lexus dealer.

■

To prevent failure or damage to data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording media, etc.,

close to the charger while charging, otherwise, data may disappear under the influ-

ence of magnetism. Also, do not bring precision instruments such as wrist watches,

etc., close to the charger, as such objects may break.

●

Do not leave portable devices in the cabin. The temperature inside the cabin may

become high, when under the sun, and cause damage to the device.

■

To prevent battery discharge

When the engine is stopped, do not use the wireless charger for a long time.

451

Inte
rior fe

Fold down the armrest for use.

Armrest

NOTICE

To prevent damage, do not apply too much load on the armrest.

452

Pull the tab of the rear door sunshade
and hook the shade on using the
anchor.

To retract the rear door sunshade,

unhook the shade and retract it slowly.

The coat hooks are provided with the
second seat assist grips.

Rear door sunshades

NOTICE

To ensure normal operation of the rear door sunshade, observe the following precau-

tions.

●

Do not place anything where it may hinder the opening/closing of the sunshade.

●

Do not attach anything to the rear door sunshade.

●

Do not retract the rear door sunshade at an angle.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur-

tain shield airbags deploy, these items may become projectiles, causing death or seri-

ous injury.

453

Inte
rior fe

An assist grip (Type A) can be used to support your body while sitting on the seat.
An assist grip (Type B) can be used when getting in or out of the vehicle and oth-
ers.

Assist grip (Type A)
Assist grip (Type B)

Assist grips

WARNING

Do not use the assist grip (Type A) when getting in or out of the vehicle or rising from

your seat.

NOTICE

To prevent damage, do not hang heavy objects or put a heavy load on the assist grip.

454

Garage door opener

The HomeLink

wireless control system in your vehicle has 3 buttons which can

be programmed to operate 3 different devices. Refer to the programming meth-
ods on the following pages to determine the method which is appropriate for the
device.

HomeLink

indicator light

Garage door operation indicators
HomeLink

icon

Illuminates while HomeLink

is operat-

ing.

Buttons

■

Before programming HomeLink

●

During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or other devices to prevent injury or other
potential harm.

●

It is recommended that a new battery be placed in the remote control
transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be equipped
with rolling code protection. If this is the case, you may need a stepladder
or other sturdy, safe device to reach the “Learn” or “Smart” button on the
garage door opener motor.

The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.

Programming HomeLink

2
3

455

Inte
rior fe

■

Programming the HomeLink

Steps through must be performed within 60 seconds, otherwise the
indicator light will stop flashing and programming will not be able to be com-
pleted.

Press and release the HomeLink

button you want to program and check

that the HomeLink

indicator light flashes (orange).

Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink

buttons.

Keep the HomeLink

indicator light

in view while programming.

Program a device.



Programming a device other
than an entry gate (for U.S.A.
owners)

Press and hold the remote control
transmitter button until the
HomeLink

indicator light

changes from slowly flashing
orange to rapidly flashing green
(rolling code) or continuously lit
green (fixed code), then release
the button.



Programming an entry gate (for U.S.A. owners)/Programming a device
in the Canadian market

Press and release the remote control transmitter button at 2 second inter-
vals, repeatedly, until the HomeLink

indicator light changes from slowly

flashing (orange) to rapidly flashing (green) (rolling code) or continuously
lit (green) (fixed code).
Test the HomeLink

operation by pressing the newly programmed button

and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device has com-
pleted. The garage door or other device should operate when a Home-
Link

button is pressed and released.

456

●

Indicator light flashes rapidly: The garage door opener motor or other
device is equipped with a rolling code. To complete programming, firmly
press and hold the HomeLink

button for 2 seconds then release it.

●

If the garage door or other device does not operate, proceed to “Pro-
gramming a rolling code system”.

Repeat the steps above to program another device for any of the remaining
HomeLink

buttons.

■

Programming a rolling code system

2 or more people may be necessary to complete rolling code programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by man-

ufacturer. Refer to the owner’s man-

ual supplied with the garage door

opener motor for details.

Press and release the “Learn” or
“Smart” button.
Perform within 30 seconds
after performing .

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this sequence
(press/hold/release) up to 3
times to complete programming.
If the garage door opener motor
operates when the HomeLink

button is pressed, the garage
door opener motor recognizes
the HomeLink

signal.

457

Inte
rior fe

■

Enabling 2-way communication with a garage door (only available for com-
patible devices)

When enabled, 2-way communication allows you to check the status of the
opening and closing of a garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used
is a compatible device. (To check device compatibility, refer to www.Home-
Link.com.)

Within 5 seconds after programming the garage door opener has been
completed, if the garage door opener motor is trained to HomeLink

both garage door operation indicators will flash rapidly (green) and the
light on the garage door opener motor will blink twice, indicating that 2-
way communication is enabled.

If the indicators do not flash, perform and within the first 10 presses of
the HomeLink

button after programming has been completed.

Press a programmed HomeLink

button to operate a garage door.

Within 1 minute of pressing the HomeLink

button, after the garage door

operation has stopped, press the “Learn” or “Smart” button on the garage
door opener motor. Within 5 seconds of the establishment of 2-way com-
munication with the garage door opener, both garage door operation indi-
cators in the vehicle will flash rapidly (green) and the light on the garage
door opener motor will blink twice, indicating that 2-way communication is
enabled.

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already have
devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing (orange), continue to hold

the HomeLink

button and perform “Programming HomeLink

”

(it

takes 20 seconds for the HomeLink

indicator to start flashing).

Press the appropriate HomeLink

button. The HomeLink

indicator light

should turn on.

Operating HomeLink

2
3

458

The status of the opening and closing of
a garage door is shown by the indica-
tors.

Opening
Closing

This function is only available if the

garage door opener motor used is a

compatible device. (To check device

compatibility, refer to www.Home-

Link.com.)

The indicators can operate within approximately 820 ft. (250 m) of the
garage door. However, if there are obstructions between the garage door and
the vehicle, such as houses and trees, feedback signals from the garage door
may not be received.
To recall the previous door operation status, press and release either Home-

Link

buttons

and

simultaneously. The

last recorded status will be displayed for 3 seconds.

Press and hold the 2 outside buttons for
10 seconds until the HomeLink

indi-

cator light changes from continuously
lit (orange) to rapidly flashing (green).

If you sell your vehicle, be sure to erase

the programs stored in the HomeLink

memory.

Garage door operation indicators

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

Erasing the entire HomeLink

memory (all three codes)

459

Inte
rior fe

■

Codes stored in the HomeLink

memory

●

The registered codes are not erased even if the battery cable is disconnected.

●

If learning failed when registering a different code to a HomeLink

button that already

has a code registered to it, the already registered code will not be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the HomeLink

■

Certification for the garage door opener

■

When support is necessary

Visit on the web at www.homelink.com/lexus or call 1-800-355-3515.

460

WARNING

■

When programming a garage door or other remote control device

The garage door or other device may operate, so ensure people and objects are out of

danger to prevent potential harm.

■

Conforming to federal safety standards

Do not use the HomeLink

compatible transceiver with any garage door opener or

device that lacks safety stop and reverse features as required by federal safety stan-

dards.

This includes any garage door that cannot detect an interfering object. A door or

device without these features increases the risk of death or serious injury.

■

When operating or programming HomeLink

Never allow a child to operate or play with the HomeLink

buttons.

461

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting

the vehicle exterior ................462

Cleaning and protecting

the vehicle interior..................465

6-2. Maintenance

Maintenance

requirements ............................468

General maintenance..............470
Emission inspection and

maintenance (I/M)
programs.................................... 473

6-3. Do-it-yourself maintenance

Do-it-yourself service

precautions................................ 474

Hood ............................................... 476
Engine compartment ............... 477
Tires .................................................490
Tire inflation pressure...............499
Wheels ...........................................503
Air conditioning filter .............. 505
Electronic key battery..............507
Checking and replacing

fuses..............................................509

Light bulbs...................................... 512

462

Cleaning and protecting the vehicle exterior

●

Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly with
water.

●

Wipe away any water.

●

Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle body is cool.

■

Automatic car washes

●

Fold the mirrors back before washing the vehicle. Start washing from the front of the

vehicle. Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface, parts (wheel,

etc.) and harm your vehicle’s paint.

●

Rear spoiler may not be washable in some automatic car washes. There may also be an

increased risk of damage to vehicle.

■

High pressure car washes

As water may enter the cabin, do not bring the nozzle tip near the gaps around the doors

or perimeter of the windows, or spray these areas continuously.

■

Wheels and wheel ornaments

●

Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or

abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild

detergent and wax as used on the paint.

●

Do not use detergent on the wheels when they are hot, for example after driving for

long distance in the hot weather.

●

Wash detergent from the wheels immediately after use.

■

Bumpers

Do not scrub with abrasive cleaners.

Perform the following to protect the vehicle and maintain it in prime condi-
tion:

463

Main

tenance an

d care

■

Notes for a smart access system with push-button start

●

If the door handle becomes wet while the electronic key is within the effective range,

the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more

separate from the vehicle while the vehicle is being washed. (Take care to ensure that

the key is not stolen.)

●

If the electronic key is inside the vehicle and a door handle becomes wet during a car

wash, a message may be shown on the multi-information display and a buzzer will

sound outside the vehicle. To turn off the alarm, lock all the doors.

■

Plated portions

If dirt cannot be removed, clean the parts as follows:

●

Use a soft cloth dampened with an approximately 5% solution of neutral detergent and

water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

●

To remove oily deposits, use alcohol wet wipes or a similar product.

WARNING

■

When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may cause the

electrical components etc. to catch fire.

■

When cleaning the windshield

●

When the upper part of the windshield where the raindrop sensor is located is

touched by hand

●

When a wet rag or similar is held close to the raindrop sensor

●

If something bumps against the windshield

●

If you directly touch the raindrop sensor body or if something bumps into the raindrop

sensor

■

Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-

ciently, as touching a hot exhaust pipe can cause burns.

■

Precautions regarding the Blind Spot Monitor (if equipped)

If the paint of the rear bumper is chipped or scratched, the system may malfunction.

If this occurs, consult your Lexus dealer.

Set the wiper switch to off.

If the wiper switch is in “AUTO”, the wipers may

operate unexpectedly in the following situa-

tions, and may result in hands being caught or

other serious injuries and cause damage to the

wiper blades.

OFF

AUTO

464

NOTICE

■

To prevent paint deterioration and corrosion on the body and components (aluminum

wheels etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present on the paint surface

• If you see dead insects, insect droppings or bird droppings on the paint

• After driving in an area contaminated with soot, oily smoke, mine dust, iron pow-

der or chemical substances

• If the vehicle becomes heavily soiled in dust or mud

• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place with low

humidity when storing wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.

This may damage the surfaces of the lights.

●

Do not apply wax on the surfaces of the lights.

Wax may cause damage to the lenses.

■

When using an automatic car wash

Set the wiper switch to the off position.

If the wiper switch is in “AUTO”, the wipers may operate and the wiper blades may be

damaged.

■

When using a high pressure car wash

●

Do not bring the nozzle tip close to boots (rubber or resin manufactured cover), con-

nectors or the following parts. The parts may be damaged if they come into contact

with high-pressure water.
• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

●

Keep the cleaning nozzle at least 11.9 in. (30 cm) away from the vehicle body. Other-

wise resin section, such as moldings and bumpers, may be deformed and damaged.

Also, do not continuously hold the nozzle in the same place.

●

Do not spray the lower part of the windshield continuously. If water enters the air con-

ditioning system intake located near the lower part of the windshield, the air condi-

tioning system may not operate correctly.

●

Do not wash the underside of the vehicle using a high pressure car washer.

465
