The meaning of each symbol on the label are as follows:

■

Customization

Settings (e.g. Exhaust gas sensor sensitivity) can be changed.

(Customizable features:



5-3. Using the air conditioning system and defogger

Caution

Air conditioning system

Air conditioning system lubricant type

Requires registered technician to ser-
vice air conditioning system

Flammable refrigerant

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the engine is

not running.

■

When repairing/replacing parts of the air conditioning system

Have repair/replacement performed by your Lexus dealer. When a part of the air con-

ditioning system, such as the evaporator, is to be replaced, it must be replaced with a

new one.

418

Rear air conditioning system

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan speed.

Press

to turn the fan off.

■

Changing the air flow mode

Press .

The air flow mode switches each time the button is pressed.

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
The rear air conditioning operation switches are on the second seat armrest.
(



P. 451)

419

5-3. Using the air conditioning system and defogger

Inte
rior fe

5-3. Using the air conditioning system and defogger

■

Using the automatic mode

Press the

Adjust the temperature setting.

To stop the operation, press the

■

If the system is operated manually in automatic mode

If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated are maintained.

■

Location of air outlets

The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the position of and opening and closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob fully to the back of
the vehicle to close the vent.

Air conditioning controls

Air outlets

420

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the engine is

not running.

421

5-3. Using the air conditioning system and defogger

Inte
rior fe

5-3. Using the air conditioning system and defogger

Heated steering wheel



/seat heaters/seat

ventilators



: If equipped

Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats. Seat ventilators maintain good airflow by blowing air from
the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories comes in

contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged

• Persons with sensitive skin

• Persons who are fatigued

• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold

remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do not stick

sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is off.

422



Automatic operation

Operates automatically according to
the outside and cabin temperature
when “CLIMATE CONCIERGE”
switch is on. (

P. 406) Automatic

operation can be turned off using the
switch.

The indicator light comes on when the

heated steering wheel is operating.



Manual operation

Turns the heated steering wheel on/off

The indicator light comes on when the heated steering wheel is operating.

■

The heated steering wheel can be used when

The engine switch is in IGNITION ON mode.

■

Timer function

Automatic operation: Operates for a maximum of 30 minutes.

(Turns off according to outside and cabin temperature.)
Manual operation: Turns off after approximately 30 minutes.

■

If the indicator light flashes

Press the switch to turn the heated steering wheel off and then press the switch again. If

the indicator light still flashes, a malfunction may be occurring. Turn the heated steering

wheel off and have the vehicle inspected by your Lexus dealer.

■

Customization

The automatic turning on/off of the heated steering wheel can be customized. (Custom-

izable features



5-3. Using the air conditioning system and defogger

Heated steering wheel (if equipped)

423

Inte
rior fe

5-3. Using the air conditioning system and defogger

Seat heater switches

The indicator light (yellow) on the switch comes on when the seat heater is operating.

Seat ventilator switches (if equipped)

The indicator light (green) on the switch comes on when the seat ventilator is operat-

ing.

Level indicator lights

The seat heater temperature level or the seat ventilator fan speed level (if equipped) is

displayed.

“AUTO” indicator lights

Seat heaters and ventilators (if equipped)



Front seats



Second outboard seats

424

■

Modes and indicators

The mode can be changed by pressing the switch.

: When automatic mode is selected, the level automatically changes depending on the

air conditioning settings.

■

The seat heaters/seat ventilators can be used when

The engine switch is in IGNITION ON mode.

■

Replacing the air filters

Filters are installed in the seat ventilators. For replacement of the filters, contact your

Lexus dealer.

■

Customization

The automatic mode settings for the seat heaters and ventilators can be changed.

(Customizable features:



5-4. Using the interior lights

Mode

“AUTO” indicator light

Level indicator lights

Off

Automatic*

3 to 1, or off

Off

Mid

Off

425

Inte
rior fe

Interior lights list

Rear interior lights (



P. 426)

Rear personal lights (

P. 427)

Inside door handle light
Front interior lights (



P. 426)

Front personal lights (

5-4. Using the interior lights

P. 427)

Shift lever light (when the engine
switch is in ACCESSORY or IGNI-
TION ON mode)

Footwell lights
Scuff lights (if equipped)
Engine switch light
Door courtesy light
Luggage compartment light (if
equipped)
Outer foot lights
Running board lights
Door trim lights

2
3
4
5
6

8
9

12
13
14

426



Front
On/off (touch the light)
Door position on/off



Rear

On/door position on

Interior lights

427

5-4. Using the interior lights

Inte
rior fe

■

Illuminated entry system

The lights automatically turn on/off according to engine switch mode, the presence of the

electronic key, whether the doors are locked/unlocked, and whether the doors are

open/closed.

■

To prevent battery discharge

If the interior lights remain on when the engine switch is turned off, the lights will go off

automatically after 20 minutes:

■

Customization

Settings (e.g. adjust the time elapsed before the interior lights automatically turn off) can

be changed. (Customizable features:



Personal lights



Front



Rear

Turns the lights on/off (touch the lights) Turns the lights on/off

NOTICE

To prevent battery discharge, do not leave the lights on longer than necessary when the

engine is not running.

428

List of storage features

Auxiliary boxes (

P. 433)

Card holder (



Overhead console (

Glove box (

Bottle holders (



P. 432)

Door pockets
Cup holders (



P. 431)

Console box (if equipped)
(

P. 429)

Cool box (if equipped) (



P. 438)

Auxiliary box (if equipped)
(

P. 433)

Wireless charger (if equipped)
(

P. 443)

WARNING

■

Items that should not be left in the storage spaces

Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the

following when cabin temperature becomes high:

●

Glasses may be deformed by heat or cracked if they come into contact with other

stored items.

●

Lighters or spray cans may explode. If they come into contact with other stored items,

the lighter may catch fire or the spray can may release gas, causing a fire hazard.

2
3
4
5
6
7

429

Inte
rior fe

Open (push button)
Unlock with the mechanical key
Lock with the mechanical key

■

Glove box light

The glove box light turns on when the tail lights are on.

■

Removing the separate tray

Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to page 438.

Press the button to open the lid.

Glove box

2
3

Pull out the separate tray while releasing the

clips.

WARNING

Keep the glove box closed while driving.

Injuries may result in the event of sudden braking, sudden swerving or an accident.

Console box (if equipped)

430

Remove the tray.

Press the button.

WARNING

Keep the console box closed while driving.

Injuries may result in the event of sudden braking, sudden swerving or an accident.

Overhead console

WARNING

■

Items unsuitable for storing

Do not store items heavier than 0.4 lb (0.2 kg).

Doing so may cause the overhead console to open and the items inside may fall out,

resulting in an accident.

■

While driving

Do not leave the overhead console open.

Items may fall out and cause injury.

431

Inte
rior fe

Cup holders



Front seats



Second seats

Press down and release the lid.

To open, pull down the armrest, press
the button and release the rear cup
holder on the armrest.



Third seats (if equipped)



Luggage compartment (if
equipped)

WARNING

■

Items unsuitable for the cup holders

Do not place anything other than cups or beverage cans in the cup holders. Even when

the lid is closed, items must not be stored in the cup holders.

Other items may be thrown out of the holders in the event of an accident or sudden

braking, and cause injury. If possible, cover hot drinks to prevent burns.

■

When not in use

Keep the cup holders closed.

Injuries may result in the event of sudden braking, sudden swerving or an accident.
