Lexus LX570 (2021 year). Manual in english - page 26

Press the button to release the
lock.

■

Third seats /luggage compartment

WARNING

■

While driving

For the front seats and the second seats: Do not leave the auxiliary box open while driv-

ing.

Items stored in it may fall out and cause death or serious injury in case of an accident or

sudden stop.

435

Inte
rior fe

Luggage compartment features

Raise the hook to use.

The cargo hooks are provided for

securing loose items.

To hang the cargo net, use the cargo
net hooks and rear tie-down hooks.

The cargo net itself is not included as an

original equipment.

Remove the cover.

Cargo hooks

Cargo net hooks

Storage compartment (if equipped)

436

Remove the cover. Hold the warning
reflector with the bands.

The warning reflector itself is not

included as an original equipment.

Remove the cover. Hold the first-aid kit
with a band.

The first-aid kit itself is not included as an

original equipment.

■

Using the luggage cover

Pull out the luggage cover and hook
it on the anchors.

Warning reflector holder

First-aid kit holder

Luggage cover (if equipped)

437

Inte
rior fe

■

Removing the luggage cover

Retract the cover and release both
ends, then lift it out.

After removing the luggage cover,

place it somewhere other than the

passenger compartment.

■

When installing the luggage cover (if equipped)

Keep the “TOP” mark on the luggage cover

ends upward.

WARNING

●

To avoid injury, always return the cargo hooks to their positions when not in use.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an

accident may occur due to an occupant being struck by an open auxiliary box or the

items stored inside.

●

Vehicles with luggage cover: Do not allow children to climb on the luggage cover.

Climbing on the luggage cover could result in damage to the luggage cover, possibly

causing death or serious injury to the child.

NOTICE

■

To prevent damage to the cargo net hooks

Avoid hanging things other than a cargo net on it.

438

Other interior features

While the engine is running, the cool box, which is cooled by the air conditioning,
can be used.

Press the button to open the lid.

Turns the cool box on/off

When on, the indicator light comes on.

■

While the cool box is on

The front air conditioning system cannot be turned off.

■

When the outside temperature is 32



F (0



C) or below

The cool box may not operate.

Cool box (if equipped)

WARNING

Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

NOTICE

To prevent battery discharge, do not leave the cool box on longer than necessary when

the engine is not running.

439

Inte
rior fe



Main sun visor
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.



Sub sun visor

Flip down with the main sun visor in
position

or .

Slide the cover to open.

The light turns on when the cover is

opened.

If the vanity lights remain on when the engine switch is turned off, the lights will go off

automatically after 20 minutes.

Sun visors

Vanity mirrors

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended periods

when the engine is not running.

440

The GPS clock’s time is automatically
adjusted by utilizing GPS time informa-
tion. For details, refer to “NAVIGA-
TION SYSTEM OWNER’S
MANUAL”.

The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W

■

Center of console



Front (12 V DC)

Press the lid to open.

Clock

Power outlets

441

Inte
rior fe



Rear (12 V DC)

■

Luggage compartment (120 V AC)

■

The power outlet can be used when

12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.

■

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery packs.
If such devices are left connected, the engine switch may not be turned off normally.

442

NOTICE

■

To avoid damaging the power outlet

Close the power outlet lid when the power outlet is not in use.

Foreign objects or liquids that enter the power outlet may cause a short circuit.

■

To prevent the fuse from being blown

12 V DC: Do not use an accessory that uses more than 12 V 10 A.
120 V AC: Do not use a 120 V AC appliance that requires more than 100 W.

If a 120 V AC appliance that consumes more than 100 W is used, the protection circuit

will cut the power supply.

■

To prevent the battery from being discharged

Do not use the power outlet longer than necessary when the engine is not running.

■

Appliances that may not operate properly (120 V AC)

The following 120 V AC appliances may not operate properly even if their power con-

sumption is under 100 W:

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data

●

Other appliances that require an extremely stable power supply

443

Inte
rior fe

A portable device can be charged by just placing Qi standard wireless charge
compatible portable devices according to the Wireless Power Consortium, such
as smart phones and mobile batteries, etc., on the charge area.
This function cannot be used with portable devices that are larger than the
charging area. Also, depending on the portable device, it may not operate as
normal. Please read the operation manual for portable devices to be used.

■

The “Qi” symbol

The “Qi” symbol is a trademark of the Wireless Power Consortium.

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

Wireless charger (if equipped)

2
3

444

■

Using the wireless charger

Press the lid to open.

Press the power supply switch of
the wireless charger.

Switches on and off with each press

of the power supply switch.
When turned on, the operation indi-

cator light (green) comes on.
Even with the engine off, the on/off

state of the power supply switch is

memorized.

Place the charging side of the
portable device down.

When charging, the operation indi-

cator light (orange) comes on.
If charging is not occurring, try plac-

ing the portable device as close to

the center of the charging area as

possible.
When charging is complete, the

operation indicator light (green)

comes on.

●

Recharging function

• When charging is complete and after a fixed time in the charge suspen-

sion state, charging restarts.

• When the portable device is moved, charging is stopped for a moment

and then it restarts.

445

Inte
rior fe

■

Lighting conditions of operation indicator light

: Depending on the portable device, there are cases where the operation indicator

light will continue being lit up orange even after the charging is complete.

●

When the operation indicator light flashes
When an error occurs, the operation indicator light flashes an orange color.
Handle the error based on the following table.

■

The wireless charger can be operated when

The engine switch is in ACCESSORY or IGNITION ON mode.

■

Usable portable devices

Qi standard wireless charge standard can be used on compatible devices.

However, not all Qi standard devices and compatibility are guaranteed.
Starting with mobile phones and smart phones, it is aimed for low power electrically sup-

plied portable devices of no more than 5W.

Operation indicator light

Conditions

Turning off

When the Wireless charger power supply is off

Green (comes on)

On Standby (charging possible state)

When charging is complete

Orange (comes on)

When placing the portable device on the charging

area (detecting the portable device)

Charging

Operation indicator light

Suspected causes

Handling method

Flashing repeatedly once

every second (Orange)

Vehicle to charger commu-

nication failure.

Contact your Lexus dealer.

Repeatedly flashes

3 times continuously

(Orange)

A foreign substance is

between the portable device

and charge area.

Remove the foreign sub-

stance from between por-

table device and the

charge area.

The portable device is out of

sync due to the device being

shifted from its position.

Place the portable device

near the center of the

charge area.

Repeatedly flashes

4 times continuously

(Orange)

Temperature rising within

the wireless charger.

Stop charging at once and

start charging again after

for a while.

446

■

When covers and accessories are attached to portable devices

Do not charge in situations where cover and accessories not able to handle Qi are

attached to the portable device. Depending on the type of cover and accessory, it may

not be possible to charge. When charging is not performed even with the portable

device placed on the charge area, remove the cover and accessories.

■

While charging, noise enters the AM radio

Turn off the wireless charger and confirm that the noise has decreased. If the noise

decreases, continuously pushing the power supply switch of the wireless charger for 2

seconds, the frequency of the charger can be changed and the noise can be reduced.

Also, on that occasion, the operation indicator light will flash orange 2 times.

■

Important points of the wireless charger

●

If the electronic key cannot be detected within the vehicle interior, charging cannot be

done. When the door is opened and closed, charging may be temporarily suspended.

●

When charging, the wireless charging device and portable device will get warmer,

however this is not a malfunction.

When a portable device gets warm while charging, charging may stop due to the pro-

tection function on the portable device side. In this case, when the temperature of the

portable device drops significantly, charge again.

■

Operation sounds

When the power supply is turned on, while searching for the portable device a sound will

be produced, however this is not a malfunction.

447

Inte
rior fe

■

Certification for the wireless charger

449

Inte
rior fe
