6-1. Maintenance and care

■

Caring for leather areas

Lexus recommends cleaning the interior of the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.

■

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a sponge or brush to

apply the foam. Rub in overlapping circles. Do not use water. The excellent results are

obtained when keeping the carpet as dry as possible.

■

Seat belts

Clean with mild soap and lukewarm water using a cloth or sponge. Also check the belts

periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.

Doing so may cause electrical components etc. to malfunction or catch fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet. (



P. 40)

An electrical malfunction may cause the airbags to deploy or not function properly,

resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use polish wax or polish cleaner. The instrument panel may reflect off the wind-

shield, obstructing the driver’s view and leading to an accident, resulting in death or

serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehicle interior

or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkaline or

acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other interior part’s

painted surface may be damaged.

467

6-1. Maintenance and care

6

Main

tenance an

d care

NOTICE

■

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of leather

surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time. Park the

vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they

may stick to the leather surface if the vehicle interior heats up significantly.

■

When cleaning the inside of the windshield (vehicles with Lexus Safety System +)

Do not allow glass cleaner to contact the lens. Also, do not touch the lens. (



P. 252)

■

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio system may be damaged if water comes into contact

with electrical components such as the audio system above or under the floor of the

vehicle. Water may also cause the body to rust.

■

Cleaning the inside of the rear quarter windows and rear window

●

Do not use glass cleaner to clean the rear quarter windows and rear window, as this

may cause damage to the rear window defogger heater wires or antenna. Use a cloth

dampened with lukewarm water to gently wipe the window clean. Wipe the window

in strokes running parallel to the heater wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

468

6-2. Maintenance

Maintenance requirements

General maintenance should be performed on a daily basis. This can be done by
yourself or by a Lexus dealer.

Scheduled maintenance should be performed at specified intervals according to
the maintenance schedule.
For details about maintenance items and schedules, refer to the “Warranty and
Service Guide”, “Owner’s Manual Supplement” or “Scheduled Maintenance”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty coverage.

The use of Lexus repair manuals is recommended.
For details about warranty coverage, refer to the separate “Owner’s Guide”, “War-

ranty and Service Guide”, “Owner’s Manual Supplement” or “Warranty Booklet”.

To ensure safe and economical driving, day-to-day care and regular mainte-
nance are essential. It is the owner’s responsibility to perform regular checks.
Lexus recommends the following maintenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

469

6-2. Maintenance

6

Main

tenance an

d care

■

Repair and replacement

It is recommended that genuine Lexus parts be used for repairs to ensure performance

of each system. If non-Lexus parts are used in replacement or if a repair shop other than

a Lexus dealer performs repairs, confirm the warranty coverage.

■

Resetting the message indicating maintenance is required (U.S.A. only)

After the required maintenance is performed according to the maintenance schedule,

please reset the message.

To reset the message, follow the procedures described below:

Press

 or

 of the meter control switches, select

.

Press

 or

 of the meter control switches, select “Scheduled Maintenance” and

then press

.

Select the “Yes” and press

.

A message is displayed on the multi-information display.

■

Allow inspection and repairs to be performed by a Lexus dealer

●

Lexus technicians are well-trained specialists and are kept up to date with the latest ser-

vice information. They are well informed about the operation of all systems on your

vehicle.

●

Keep  a  copy  of  the  repair  order.  It  proves  that  the  maintenance  that  has  been  per-

formed is under warranty coverage. If any problem should arise while your vehicle is

under warranty, your Lexus dealer will promptly take care of it.

WARNING

■

If your vehicle is not properly maintained

Improper maintenance could result in serious damage to the vehicle and possible seri-

ous injury or death.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile compo-

nents contain or emit chemicals known to the State of California to cause cancer and

birth defects and other reproductive harm. Work in a well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by component

wear contain or emit chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm. Avoid exposure and wash any affected area

immediately.

●

Battery posts, terminals and related accessories contain lead and lead compounds

which are known to cause brain damage. Wash your hands after handling. (



P. 486)

1

2

3
4

470

6-2. Maintenance

General maintenance

Listed below are the general maintenance items that should be performed at
the intervals specified in the “Warranty and Service Guide” or “Owner’s
Manual Supplement”. It is recommended that any problem you notice should
be brought to the attention of your Lexus dealer or qualified service shop for
advice.

Engine compartment

Items

Check points

Battery

Check the connections.

(



P. 486)

Brake fluid

Is the brake fluid at the correct level?

(



P. 483)

Engine coolant

Is the engine coolant at the correct level? (



P. 482)

Engine oil

Is the engine oil at the correct level?

(



P. 479)

Exhaust system

There should not be any fumes or strange sounds.

Power steering fluid

Is the power steering fluid at the correct level?

(



P. 485)

Radiator/condenser

The radiator and condenser should be free from

foreign objects.

(



P. 483)

Washer fluid

Is there sufficient washer fluid?

(



P. 489)

471

6-2. Maintenance

6

Main

tenance an

d care

Vehicle interior

Items

Check points

Accelerator pedal

• The accelerator pedal should move smoothly

(without uneven pedal effort or catching).

Automatic transmission

“Park” mechanism

• When parked on a slope and the shift lever is in P, is

the vehicle securely stopped?

Brake pedal

• Does the brake pedal move smoothly?

• Does the brake pedal have appropriate clearance

from the floor?

(



P. 568)

• Does the brake pedal have the correct amount of

free play?

(



P. 568)

Brakes

• The vehicle should not pull to one side when the

brakes are applied.

• The brakes should work effectively.

• The brake pedal should not feel spongy.

• The brake pedal should not get too close to the floor

when the brakes are applied.

Head restraints

• Do the head restraints move smoothly and lock

securely?

Indicators/buzzers

• Do the indicators and buzzers function properly?

Lights

• Do all the lights come on?

Seat belts

• Do the seat belts operate smoothly?

• The seat belts should not be damaged.

Seats

• Do the seat controls operate properly?

Steering wheel

• Does the steering wheel rotate smoothly?

• Does the steering wheel have the correct amount of

free play?

• There should not be any strange sounds coming

from the steering wheel.

472

6-2. Maintenance

Vehicle exterior

Items

Check points

Doors

• Do the doors operate smoothly?

Engine hood

• Does the engine hood lock system work properly?

Fluid leaks

• There should not be any signs of fluid leakage after

the vehicle has been parked.

Tires

• Is the tire inflation pressure correct?

• The tires should not be damaged or excessively

worn.

• Have the tires been rotated according to the mainte-

nance schedule?

• The wheel nuts should not be loose.

Windshield wipers/rear

window wiper

• The  wiper  blades  should  not show any signs of crack-

ing, splitting, wear, contamination or deformation.

• The wiper blades should clear the windshield/rear

window without streaking or skipping.

WARNING

■

If the engine is running

Turn off the engine and ensure that there is adequate ventilation before performing

maintenance checks.

473

6-2. Maintenance

6

Main

tenance an

d care

Emission inspection and maintenance (I/M) programs

The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pass the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.

●

When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not be com-
pletely set.

●

When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.

The error code in the OBD system will not be cleared unless the vehicle is driven
40 or more times.

Contact your Lexus dealer to prepare the vehicle for re-testing.

Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.

If the malfunction indicator lamp comes on

Your vehicle may not pass the I/M test in the following situations:

When the malfunction indicator lamp still remains on after several driv-
ing trips

If your vehicle does not pass the I/M test

474

6-3. Do-it-yourself maintenance

Do-it-yourself service precautions

If you perform maintenance yourself, be sure to follow the correct procedures
as given in these sections.

Items

Parts and tools

Battery condition

(



P. 486)

• Warm  water

• Baking soda

• Grease

• Conventional wrench (for terminal clamp bolts)

Brake fluid level

(



P. 483)

• FMVSS No.116 DOT 3 or SAE J1703 brake fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)

Engine coolant level

(



P. 482)

• “Toyota Super Long Life Coolant” or similar high quality eth-

ylene glycol-based non-silicate, non-amine, non-nitrite and

non-borate coolant with long-life hybrid organic acid tech-

nology.
For the U.S.A.:

“Toyota Super Long Life Coolant” is pre-mixed with 50 %

coolant and 50 % deionized water.
For Canada:

“Toyota Super Long Life Coolant” is pre-mixed with 55 %

coolant and 45 % deionized water.

• Funnel (used only for adding coolant)

Engine oil level

(



P. 479)

• “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)

Fuses (



P. 509)

• Fuse with same amperage rating as original

Power steering fluid

level (



P. 485)

• Automatic transmission fluid DEXRON

®

 II or III

• Rag or paper towel
• Funnel (used only for adding power steering fluid)

Radiator and

condenser

(



P. 483)



Tire inflation

pressure (



P. 499) • Tire pressure gauge

• Compressed air source

Washer fluid

(



P. 489)

• Water or washer fluid containing antifreeze (for winter use)
• Funnel (used only for adding water or washer fluid)

475

6-3. Do-it-yourself maintenance

6

Main

tenance an

d care

WARNING

The engine compartment contains many mechanisms and fluids that may move suddenly,

become hot, or become electrically energized. To avoid death or serious injury, observe

the following precautions:

■

When working on the engine compartment

●

Keep hands, clothing and tools away from the moving fan and engine drive belt.

●

Be careful not to touch the engine, radiator, exhaust manifold, etc. right after driving

as they may be hot. Oil and other fluids may also be hot.

●

Do not leave anything that may burn easily, such as paper or rags, in the engine com-

partment.

●

Do not smoke, cause sparks or expose an open flame to fuel or the battery. Fuel and

battery fumes are flammable.

●

Be extremely cautious when working on the battery. It contains poisonous and corro-

sive sulfuric acid.

■

When working near the electric cooling fans or radiator grille

Be sure the engine switch is off. With the engine switch in IGNITION ON mode, the

electric cooling fans may automatically start to run if the air conditioning is on and/or

the coolant temperature is high. (



P. 483)

■

When working on or under the vehicle

Do not get under the vehicle with just the jack supporting it.

Always use automotive jack stands or other solid supports.

■

Safety glasses

Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting in

your eyes.

NOTICE

■

If you remove the air cleaner filter

Driving with the air cleaner filter removed may cause excessive engine wear due to dirt

in the air.

476

6-3. Do-it-yourself maintenance

Hood

Pull the hood lock release lever.

The hood will pop up slightly.

Lift the hood catch and lift the hood.

Release the lock from the inside of the vehicle to open the hood.

1

2

WARNING

■

Pre-driving check

Check that the hood is fully closed and locked.

If the hood is not locked properly, it may open while the vehicle is in motion and cause

an accident, which may result in death or serious injury.

477

6-3. Do-it-yourself maintenance

6

Main

tenance an

d care

Engine compartment

Power steering fluid reservoir

(



P. 485)

Engine oil level dipstick

(



P. 479)

Engine coolant reservoir

(



P. 482)

Engine oil filler cap

(



P. 480)

Brake fluid reservoir  (



P. 483)

Fuse box

(



P. 509)

Washer fluid tank

(



P. 489)

Battery

(



P. 486)

Cooling fans
Condenser

(



P. 483)

Radiator

(



P. 483)

1

2

3

4

5
6
7
8
9

10

11

478

6-3. Do-it-yourself maintenance

■

Removing the engine compartment cover

■

Installing the clips

Push up center portion
Insert
Press

Engine compartment cover

1

2
3

NOTICE

■

After installing an engine compartment cover

Make sure the cover is securely installed in its original position.

479

6-3. Do-it-yourself maintenance

6

Main

tenance an

d care

With the engine at operating temperature and turned off, check the oil level on
the dipstick.

■

Checking the engine oil

Park the vehicle on level ground. After warming up the engine and turning
it off, wait more than 5 minutes for the oil to drain back into the bottom of
the engine.
Holding a rag under the end, pull
the dipstick out.

Wipe the dipstick clean.
Reinsert the dipstick fully.
Holding a rag under the end, pull the dipstick out and check the oil level.

Low
Normal
Excessive

The shape of the dipstick may dif-

fer depending on the type of vehi-

cle or engine.

Wipe the dipstick and reinsert it fully.

Engine oil

1

2

3
4
5

1

2
3

6

480

6-3. Do-it-yourself maintenance

■

Adding engine oil

If the oil level is below or near the
low level mark, add engine oil of the
same type as already in the engine.

Make sure to check the oil type and prepare the items needed before adding
oil.

Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.

■

Engine oil consumption

A certain amount of engine oil will be consumed while driving. In the following situations,

oil consumption may increase, and engine oil may need to be refilled in between oil

maintenance intervals.

●

When the engine is new, for example directly after purchasing the vehicle or after

replacing the engine

●

If low quality oil or oil of an inappropriate viscosity is used

●

When driving at high engine speeds or with a heavy load, when towing, or when driving

while accelerating or decelerating frequently

●

When leaving the engine idling for a long time, or when driving frequently through

heavy traffic

■

After changing the engine oil

The engine oil maintenance data should be reset. Perform the following procedures:

Press

 or

 of the meter control switches, select

.

Press

 or

 of the meter control switches, select “Oil Maintenance” and then

press .
Select the “Yes” and press

.

A message is displayed on the multi-information display.

Engine oil selection



P. 564

Oil quantity (Low



 Full)

1.6 qt. (1.5 L, 1.3 Imp.qt.)

Items

Clean funnel

1

2
3

1

2

3
4

481

6-3. Do-it-yourself maintenance

6

Main

tenance an

d care

WARNING

■

Used engine oil

●

Used engine oil contains potentially harmful contaminants which may cause skin dis-

orders such as inflammation or skin cancer, so care should be taken to avoid pro-

longed and repeated contact. To remove used engine oil from your skin, wash

thoroughly with soap and water.

●

Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of

used oil and filters in household trash, in sewers or onto the ground. Call your Lexus

dealer, service station or auto parts store for information concerning recycling or dis-

posal.

●

Do not leave used engine oil within the reach of children.

NOTICE

■

To prevent serious engine damage

Check the oil level on regular basis.

■

When replacing the engine oil

●

Be careful not to spill engine oil on the vehicle components.

●

Avoid overfilling, or the engine could be damaged.

●

Check the oil level on the dipstick every time you refill the vehicle.

●

Be sure the engine oil filler cap is properly tightened.
