Lexus CT (2021 year). Manual in english

426

5-7. Setup menu

Select “Change Name” using the “TUNE•SEL” knob.
Select the desired cellular phone name to be changed using the knob.
Select “Record Name” using the knob, and say the new name after the beep.

The name to be registered will be repeated aloud.

Select “Confirm” using the knob.

Select “List Phones” using the “TUNE•SEL” knob. The list of registered cellular
phones will be read aloud.
When listing is complete, the system returns to “Phone Setup”.

Select “Set Passkey” using the “TUNE•SEL” knob.
Select a 4 to 8-digit number using the knob.

The number should be input 1 digit at a time.

When the entire number to be registered as a passkey has been input, press
the knob again.

If the number to be registered has 8 digits, pressing of the knob is not necessary.

Select “Delete Phone” using the “TUNE•SEL” knob.
Select the desired cellular phone to be deleted using the knob.

If the cellular phone to be deleted is paired as a Bluetooth

audio player, the

registration of the audio player can be deleted at the same time.

When “Del Audio?” is displayed, select “Yes” or “No” using the knob.
(Bluetooth

audio player



P. 440)

■

The number of cellular phones that can be registered

Up to 6 cellular phones can be registered in the system.

Changing the registered name of a cellular phone

Listing the registered cellular phones

Changing the passkey

Deleting a registered cellular phone

2
3

427

5-7. Setup menu

Security and system setup

To enter the menu of each setting, follow the steps below.

Press the off-hook switch and select “Setup” using the “TUNE•SEL” knob.
Select “Security” using the knob.
Select one of the following items using the knob:

●

Setting or changing the PIN (Personal Identification Number)
“Set PIN”

●

Locking the phone book
“Phbk Lock”

●

Unlocking the phone book
“Phbk Unlock”

Press the off-hook switch and select “Setup” using the “TUNE•SEL” knob.
Select “System Setup” using the knob.
Select one of the following items using the knob:

●

Setting voice guidance volume
“Guidance Vol”

●

Displaying the Bluetooth

device address and name

“Device Name”

●

Initializing the system
“Initialize”

Security setting items and operation procedures

System setup items and operation procedures

2
3

428

5-7. Setup menu

■

Setting a PIN

Select “Set PIN” using the “TUNE•SEL” knob.
Enter a PIN using the knob.

Input the code 1 digit at a time.

■

Changing the PIN

Select “Set PIN” using the “TUNE•SEL” knob.
Enter the registered PIN using the knob.
Enter a new PIN using the knob.

Input the code 1 digit at a time.

Select “Phbk Lock” or “Phbk Unlock” using the “TUNE•SEL” knob.
Input a PIN by using the knob and select “Confirm” using the knob.

Input the code 1 digit at a time.

Select “Guidance Vol” using the “TUNE•SEL” knob.
Change the voice guidance volume.
To decrease the volume: Turn the knob counterclockwise.
To increase the volume: Turn the knob clockwise.

Select “Device Name” using the “TUNE•SEL” knob.
Turn the knob to display the Bluetooth

device address and name.

Select “Go Back” using the knob to return to “System Setup”.

Select “Initialize” and then “Confirm” using the “TUNE•SEL” knob.
Select “Confirm” again using the knob.

Setting or changing the PIN

Locking or unlocking the phone book

Setting voice guidance volume

Displaying the Bluetooth

device address and name

Initializing the system

2
3

429

5-7. Setup menu

■

Initialization

●

The following data in the system can be initialized:
• Phone book

• Outgoing and incoming call history

• Speed dials

• Registered cellular phone data

• Security code

• Registered Bluetooth

enabled portable player data

• Passkeys for the cellular phones

• Passkey for the Bluetooth

audio players

• Guidance volume

• Receiver volume

• Ring tone volume

●

Once the initialization has been completed, the data cannot be restored to its original

state.

■

When the phone book is locked

The following functions cannot be used:

●

Dialing by inputting a name

●

Speed dialing

●

Dialing a number stored in the call history memory

●

Using the phone book

430

5-7. Setup menu

Using the phone book

To enter the menu of each setting, follow the steps below.

Press the off-hook switch and select “Phonebook” using the “TUNE•SEL”
knob.
Select one of the following items using the knob.

●

Adding a new phone number
“Add Entry”

●

Changing the registered name in the phone book
“Change Name”

●

Listing the registered data
“List Names”

●

Setting speed dials
“Speed Dial”

●

Deleting the registered data
“Delete Entry”

●

Deleting speed dials
“Del Spd Dial”

The following methods can be used to add a new phone number:

●

Transferring data from the cellular phone

●

Inputting a phone number using the “TUNE•SEL” knob

●

Selecting a phone number from outgoing or incoming call history

■

Adding procedure

Select “Add Entry” using the “TUNE•SEL” knob.
Use one of the following methods to input a telephone number:

Transferring data from the cellular phone:

STEP2-1 Select “By Phone” and then “Confirm” using the knob.
STEP2-2 When “Transfer” appears in the display, transfer the data from

the cellular phone.

Refer to the manual that comes with the cellular phone for the details

of transferring data.

STEP2-3 Select the desired data using the knob.

Adding a new phone number

431

5-7. Setup menu

Inputting a phone number using the knob:

STEP2-1 Select “Manual Input” using the knob.
STEP2-2 Input a phone number using the knob, and press the knob

again.

Input the phone number 1 digit at a time.

Selecting a phone number from outgoing or incoming call history:

STEP2-1  Select “Call History” using the knob.
STEP2-2  Select “Outgoing” or “Incoming” using the knob.
STEP2-3  Select the desired data using the knob.
Select “Record Name” using the knob, and say the desired name after the
beep.

The name to be registered will be repeated aloud.

Select “Confirm” using the knob.
Select “Confirm” again using the knob.

In step

, selecting “Speed Dial” instead of “Confirm” registers the newly added

phone number as a speed dial.

Select “Change Name” using the “TUNE•SEL” knob
Select the desired name to be changed using the knob.
Select “Record Name” using the knob, and say the new name after the beep.

The name to be registered will be repeated aloud.

Select “Confirm” using the knob.

Selecting “List Names” using the “TUNE•SEL” knob. The list of the registered
data will be read aloud.
When listing is complete, the system returns to “Phonebook”.
Pressing the off-hook switch while an entry is being read aloud selects the entry,
and calls the registered phone number.

Changing the registered name in the phone book

Listing the registered data

4
5

2
3

432

5-7. Setup menu

Select “Speed Dial” using the “TUNE•SEL” knob
Select the desired data using the knob.
Select the desired preset button, and register the data into speed dial by
either of the following methods:
a. Press the desired preset button, and select “Confirm” using the knob.
b. Press and hold the desired preset button.

Select “Delete Entry” using the “TUNE•SEL” knob
Select the desired data to be deleted using the knob.

Select “Del Spd Dial” using the “TUNE•SEL” knob.
Press the preset button to which the desired speed dial is registered after the
beep.

The name to be deleted will be heard.

Select “Confirm” using the knob.

■

Adding an entry to the phonebook

Up to 20 names can be stored.

■

Limitation of number of digits

A phone number that exceeds 24 digits cannot be registered.

Setting speed dials

Deleting the registered data

Deleting speed dials

2
3

433

5-8. Bluetooth

Audio

Operating a Bluetooth

enabled portable player

To select the desired album, press the “5” button or the “6” button.

Press “



”



or “



” on the “SEEK•TRACK” button to select the desired track.

Control panel

Displaying text message
Repeat play
Playback/pause
Album selection
“TUNE•SEL” knob
BT•A menu
Playback

Track selection
Random play
Power/volume knob
Press: Turning the audio system on
or off
Turn: Adjusting the volume

2
3
4
5

8
9

Selecting an album

Selecting tracks

434

5-8. Bluetooth

Audio

To play or pause a track, press the “3” button.

To fast-forward or rewind, press and hold “



”



or “



” on the “SEEK•TRACK” but-

ton until you hear a beep.

Press the “1” button.

To cancel, press

the button again.

Press the “2” button.

To cancel, press

the button again.

Press the “TEXT” button.

Each time the button is pressed, the display changes in the following order:

Elapsed time



Album title



Track title



Artist name

■

Bluetooth

audio system functions

Depending on the portable player that is connected to the system, certain functions may

not be available.

■

Display



P. 396

■

Error messages

“Memory Error”: This indicates a problem in the system.

Playing and pausing tracks

Fast-forwarding and rewinding tracks

Random play

Repeat play

Switching the display

435

5-9. Bluetooth

Phone

Making a phone call

◆

Making a phone call

●

Dialing by inputting a name
“Dial by name”

●

Speed dialing

●

Dialing a number stored in the outgoing history memory
“Redial”

●

Dialing a number stored in the incoming history memory
“Call back”

◆

Using the call history memory

●

Dialing

●

Storing data in the phone book

●

Deleting

Press the talk switch and say a registered name.

The desired name or number is displayed.

Dial by one of the following methods:
a. Press the off-hook switch.
b. Select “Dial” using the “TUNE•SEL” knob.

In step

, if the pronounced name cannot be recognized, select the desired name

using the knob.

Press the off-hook switch.
Press the preset button in which the desired number is registered.
Press the off-hook switch.

Dialing by inputting a name

Speed dialing

2
3

436

5-9. Bluetooth

Phone

Follow the procedure below to use number stored in call history memory:

Press the off-hook switch and select “Redial” (when using a number stored in
the outgoing call history memory) or “Call back” (when using a number
stored in the incoming call history memory) using the “TUNE•SEL” knob.
Select the desired number using the knob.
The following operations can be performed:
Dialing: Press the off-hook switch or select “Dial” using the knob.
Storing the number in the phone book: Select “Store” and then “Confirm”
using the knob.
Deleting: Select “Delete” and then “Confirm” using the knob.

■

Call history

Up to 5 numbers can be stored in each of the outgoing and incoming call history memo-

ries.

Using a call history memory

2
3

437

5-9. Bluetooth

Phone

Receiving a phone call

Press the off-hook switch.

Press the on-hook switch.

Answering the phone

Refusing the call

438

5-9. Bluetooth

Phone

Speaking on the phone

A call can be transferred between the cellular phone and system while dialing,
receiving a call, or during a call. Use one of the following methods:
a. Operate the cellular phone.

Refer to the manual that comes with the cellular phone for the operation of the phone.

b. Press the off-hook switch

: This operation can be performed only when transferring a call from the cellular phone

to the system during a call.

■

When talking on the phone

●

Do not talk simultaneously with the other party.

●

Keep the volume of the received voice down. Otherwise, voice echo will increase.

Transferring a call

439

5-10. Bluetooth

Bluetooth

■

Conditions under which the system will not operate

●

If using a cellular phone that does not support Bluetooth

●

If the cellular phone is switched off.

●

If you are outside service range.

●

If the cellular phone is not connected.

●

If the cellular phone’s battery is low.

●

If the cellular phone is behind the seat or in the glove box or console box

●

If metal is covering or touching the portable player/phone

■

Signal status

This display may not correspond exactly with the cellular phone itself.

■

When using the hands-free system

●

The audio system and voice guidance are muted when making a call.

●

If both parties speak at the same time, it may be difficult to hear.

●

If the incoming call volume is overly loud, an echo may be heard.

●

Try to face toward the microphone as much as possible when speaking.

●

In the following circumstances, it may be difficult to hear the other party:
• When driving on unpaved roads

• When driving at high speeds

• When a window is open

• When the air conditioning is blowing directly on the microphone

• When the air conditioning is set to high

●

This system is not guaranteed to operate with all Bluetooth

devices.

■

When transferring ownership of the vehicle

Be sure to initialize the system to prevent personal data from being improperly accessed.

(



P. 428)

■

About Bluetooth

Bluetooth is a registered trademark of

Bluetooth SIG, Inc.

440

5-10. Bluetooth

■

Compatible models

Portable players must correspond to the following specifications:

●

Bluetooth

specifications:

Ver. 1.2, or higher (Recommended: Ver. 2.0+EDR or higher)

●

Following Profiles:
• A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher

• AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher (Ver. 1.3 or higher

recommended)

However, please note that some functions may be limited depending on the type of por-

table player.
This system supports the following service.
Compatible with HFP (Hands Free Profile) Ver. 1.5 and OPP (Object Push Profile) Ver.

1.1.
If your cellular phone does not support HFP, you cannot enter the Bluetooth

phone. If

your cellular phone supports OPP alone, you cannot use the Bluetooth

phone.

445

5-10. Bluetooth

WARNING

■

Caution while driving

Do not use a cellular phone or connect the Bluetooth

phone.

■

Caution regarding interference with electronic devices

●

An antenna for the Bluetooth

connection is built in the instrument panel. People

with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemak-

ers or implantable cardioverter defibrillators should maintain a reasonable distance

between themselves and the Bluetooth

antennas. The radio waves may affect the

operation of such devices.

●

Before using cellular phones, users of any electrical medical device other than

implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or

implantable cardioverter defibrillators should consult the manufacturer of the device

for information about its operation under the influence of radio waves. Radio waves

could have unexpected effects on the operation of such medical devices.

NOTICE

■

To prevent damage to cellular phones

Do not leave cellular phones in the vehicle. The temperature inside the vehicle may

become high, resulting in damage to the phone.

Lexus CT (2021 year). Manual in english - page 19
