5-5. Using an external device

●

MP3 file compatibility
• Compatible standards

MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5)

• Compatible sampling frequencies

MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz)

MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz)

MPEG2.5: 8, 11.025, 12 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 AUDIO LAYERII, III: 32-320 (kbps)

MPEG2 AUDIO LAYERII, III: 32-160 (kbps)

MPEG2.5: 32-160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and monaural

●

WMA file compatibility
• Compatible standards

WMA Ver. 9

• Compatible sampling frequencies

HIGH PROFILE 32, 44.1, 48 (kHz)

• Compatible bit rates

HIGH PROFILE 32-320 (kbps, VBR)

●

File names
The only files that can be recognized as MP3/WMA and played are those with the

extension .mp3 or .wma.

●

ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track title, artist

name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags. (The

number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the track title and

artist name in the same way as with ID3 tags.

●

MP3 and WMA playback
• When a device containing MP3 or WMA files is connected, all files in the USB

memory device are checked. Once the file check is finished, the first MP3 or WMA

file is played. To make the file check finish more quickly, we recommend that you do

not include any files other than MP3 or WMA files or create any unnecessary fold-

ers.

• When the USB device is connected and the audio source is changed to USB mem-

ory mode, the USB device will start playing the first file in the first folder. If the same

device is removed and reinserted (and the contents have not been changed), the

USB device will resume play from the same point in which it was last used.

●

Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files,

they will be mistakenly recognized and played as MP3 and WMA files. This may result

in large amounts of interference and damage to the speakers.

411

5-5. Using an external device

●

Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least

128 kbps and a sampling frequency of 44.1 kHz.

• There is a wide variety of freeware and other encoding software for MP3 and WMA

files on the market, and depending on the status of the encoding and the file format,

poor sound quality or noise at the start of playback may result. In some cases, play-

back may not be possible at all.

• Microsoft, Windows, and Windows Media are registered trademarks of Microsoft

Corporation in the U.S.A. and other countries.

WARNING

■

Caution while driving

Do not connect USB memory or operate the controls.

NOTICE

■

To prevent damage to USB memory

●

Do not leave USB memory in the vehicle. The temperature inside the vehicle may

become high, resulting in damage to the player.

●

Do not push down on or apply unnecessary pressure to the USB memory while it is

connected as this may damage the USB memory or its terminal.

●

Do not insert foreign objects into the port as this may damage the USB memory or its

terminal.

412

5-5. Using an external device

Using the AUX port



P. 387

■

Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle’s audio controls. All other adjustments

must be made on the portable audio device itself.

■

When using a portable audio device connected to the power outlet

Noise may occur during playback. Use the power source of the portable audio device.

This port can be used to connect a portable audio device and listen to it
through the vehicle’s speakers. Press the “AUX•USB” button to select “AUX”.

Connecting a portable player

NOTICE

■

To prevent damage to portable audio device

●

Do not leave portable audio devices in the vehicle. The temperature inside the vehicle

may become high, resulting in damage to the device.

●

Do not push down on or apply unnecessary pressure to the portable audio device

while it is connected as this may damage the portable audio device or its terminal.

●

Do not insert foreign objects into the port as this may damage the portable audio

device or its terminal.

413

5-6. Using Bluetooth

devices

Bluetooth

audio/phone

The following can be performed using Bluetooth

wireless communication:

■

Bluetooth

audio

The Bluetooth

audio system enables you to enjoy music played on a porta-

ble digital audio player (portable player) from the vehicle speakers via wire-
less communication.
This audio system supports Bluetooth

, a wireless data system capable of

playing portable audio music without cables. If your portable player does
not support Bluetooth

, the Bluetooth

audio system will not function.

■

Bluetooth

phone (hands-free phone system)

This system supports Bluetooth

, which allows you to make or receive calls

without using cables to connect a cellular phone and the system, and with-
out operating the cellular phone.

414

5-6. Using Bluetooth

devices

Device registration/connection flow

3. Check connection status

(



P. 415)

3. Check connection status

(



P. 415)

4. Use Bluetooth

audio

(



P. 433)

4. Use Bluetooth

phone

(



P. 435)

1. Register the Bluetooth

device to be used with
audio system (



P. 419)

1. Register the Bluetooth

phone to be used with audio
system (



P. 420)

Audio

Hands-free phone

2. Selecting a portable player

to be used (



P. 422)

2. Selecting a cellular phone

to be used (



P. 425)

415

5-6. Using Bluetooth

devices

Display
A message, name, phone number,
etc. is displayed.

Lower-case characters and special

characters cannot be displayed.

Displays information that is too long
to be displayed at one time on the
display (press and hold)
Selects speed dials
Selects items such as menu and number
Turn: Selects an item
Press: Inputs the selected item
Bluetooth

connection condition

If “BT” is not displayed, the hands-free system cannot be used.

Reception level

The vehicle’s built-in microphone is
used when talking on the phone.
The person you are speaking to can be
heard from the front speakers.

To use the hands-free system, you must register your Bluetooth

phone in the

system. (



P. 420)

Audio unit

Microphone

3
4

416

5-6. Using Bluetooth

devices

■

Audio (



P. 421)

■

Phone

Menu list of the Bluetooth

audio/phone

First menu

Second menu

Third menu

Operation detail

“BTA MENU” “BTA Setup”

“Pair Audio”

Registering a portable audio

player

“Select Audio”

Selecting a portable audio

player to be used

“Change Name”

Changing the registered name

of a portable player

“List Audios”

Listing the registered portable

players

“Set Passkey”

Changing the passkey

“Delete Audio”

Deleting a registered portable

player

First menu

Second menu

Third menu

Operation detail

“Callback”

Dialing a number stored in the

incoming call history memory

“Redial”

Dialing a number stored in the out-

going call history memory

“Phonebook”

(



P. 430)

“Add Entry”

Adding a new phone number

“Change

Name”

Changing the registered name in

the phone book

“Delete Entry”

Deleting the registered data

“Del Spd Dial”

Deleting speed dials

“List Names”

Listing the registered data

“Speed Dial”

Setting speed dials

417

5-6. Using Bluetooth

devices

■

Automatic volume adjustment

When vehicle speed reaches 80 km/h (50 mph) or more, the volume automatically

increases. The volume returns to the previous volume setting when vehicle speed drops

to 70 km/h (43 mph) or less.

■

Operations that cannot be performed while driving

●

Operating the system with the “TUNE•SEL” knob

●

Registering a portable player or cellular phone to the system

“Setup”

“Security”

(



P. 427)

“Set PIN”

Setting a PIN code

“Phbk Lock”

Locking the phone book

“Phbk

Unlock”

Unlocking the phone book

“Phone Setup”

(



P. 425)

“Pair Phone”

Registering a cellular phone

“Select

Phone”

Selecting a cellular phone to be

used

“Change

Name”

Changing the registered name of a

cellular phone

“List Phones”

Listing the registered cellular

phones

“Set Passkey”

Changing the passkey

“Delete

Phone”

Deleting a registered cellular

phone

“System

Setup”

(



P. 427)

“Guidance

Vol”

Setting voice guidance volume

“Device

Name”

Displaying the Bluetooth

device

address and name

“Initialize”

Initializing the system

First menu

Second menu

Third menu

Operation detail

418

5-6. Using Bluetooth

devices

Using the steering wheel switches

Volume
The voice guidance volume cannot
be adjusted using this button.
Off-hook switch
Turns the hands-free system on/
starts a call
On-hook switch
Turns the hands-free system off/ends
a call/refuses a call
Talk switch
Turns the voice command system on (press)/turns the voice command system
off (press and hold)

The steering wheel switches can be used to operate a connected cellular
phone, or portable audio player (



P. 386).

Operating Bluetooth

device using the steering wheel switches

419

5-6. Using Bluetooth

devices

Registering a Bluetooth

audio system for the first

time

Press the “AUX•USB” button and select “BTA MENU” using the “TUNE•SEL”
knob.
Press the talk switch or select “BTA Setup” using the knob.

The introductory guidance and portable player name registration instructions
are heard.

Select “Pair Audio Player (Pair Audio)” using a voice command or the knob.
Register a portable player name by either of the following methods:
a. Select “Record Name” using the knob, and say the name to be registered.
b. Press the talk switch and say the name to be registered.

A voice guidance instruction to confirm the input is heard.

Select “Confirm” using a voice command or the knob.

A passkey is displayed and heard, and a voice guidance instruction for inputting
the passkey into the portable player is heard.

Input the passkey into the portable player.

Refer to the manual that comes with the portable player for the operation of the por-

table player.

Guidance for registration completion is heard.
If the portable player has a Bluetooth

phone, the phone can be registered at

the same time. A voice guidance instruction to register a Bluetooth

phone is

heard.

Select “Yes” or “No” using a voice command or the knob.
(Bluetooth

phone



P. 440)

■

Changing the passkey



P. 422

Before using the Bluetooth

audio system, it is necessary to register a

Bluetooth

enabled portable player in the system. Follow the procedure

below to register (pair) a portable player:

3
4

420

5-6. Using Bluetooth

devices

Registering a Bluetooth

phone for the first time

Press the off-hook switch and select “Pair Phone” using the “TUNE•SEL”
knob.
Select “Record Name” using the knob, and say the name to be registered
after the beep.

The name to be registered will be repeated aloud.

Select “Confirm” using the knob.

A passkey will be displayed.

Input the passkey into the cellular phone.

Refer to the manual that comes with the cellular phone for the operation of the phone.

If the cellular phone has a Bluetooth

audio player, the audio player can be reg-

istered at the same time.

When “Pair Audio?” is displayed, select “Yes” or “No” using the knob.
(Bluetooth

audio player



P. 440)

■

Changing the passkey



P. 426

Before using the hands-free phone system, it is necessary to register a cellular
phone in the system. The system will enter phone registration mode automati-
cally when starting the system with no cellular phone registered. Follow the
procedure below to register (pair) a cellular phone:

421

5-7. Setup menu

Setting up a Bluetooth

enabled portable player

To enter the menu for each function, follow the steps below.

Press the “AUX•USB” button and select “BTA MENU” using the “TUNE•SEL”
knob or press the off-hook switch (



P. 418) and select “Setup” using the

knob.
Select “BTA Setup” using the knob.
Select one of the following items using the knob:

●

Registering a portable player
“Pair Audio”

●

Selecting a portable player to be used
“Select Audio”

●

Changing the registered name of a portable player
“Change Name”

●

Listing the registered portable players
“List Audios”

●

Changing the passkey
“Set Passkey”

●

Deleting a registered portable player
“Delete Audio”

Registering a portable audio player in the Bluetooth

audio system allows the

system to function. The following functions can be used for registered porta-
ble players:

Functions and operation procedures

2
3

422

5-7. Setup menu

Select “Pair Audio” using the “TUNE•SEL” knob, and perform the procedure for
registering a portable player. (



P. 419)

Select “Select Audio” using the “TUNE•SEL” knob.
Select the portable player to be used using the knob.
Select “From Car” or “From Audio” using the knob.

If “From Car” is selected, the portable player will be automatically connected when-

ever:
The power switch is in ACCESSORY or ON mode.

Select “Change Name” using the “TUNE•SEL” knob.
Select the desired portable player name to be changed using the knob.
Select “Record Name” using the knob, and say the new name after the beep.

The name to be registered will be repeated aloud.

Select “Confirm” using the knob.

Select “List Audios” using the “TUNE•SEL” knob. The list of registered portable
players will be read aloud.
When listing is complete, the system returns to “BTA Setup”.

Select “Set Passkey” using the “TUNE•SEL” knob.
Select a 4 to 8-digit number using the knob.

The number should be input 1 digit at a time.

When the entire number to be registered as a passkey has been input, press
the knob again.

If the number to be registered has 8 digits, pressing of the knob is not necessary.

Registering a portable player

Selecting a portable player to be used

Changing the registered name of a portable player

Listing the registered portable players

Changing the passkey

2
3

423

5-7. Setup menu

Select “Delete Audio” using the “TUNE•SEL” knob
Select the desired portable player to be deleted using the knob.

If the portable player to be deleted is paired as a Bluetooth

phone, the registra-

tion of the cellular phone can be deleted at the same time.

When “Del Phone?” is displayed, select “Yes” or “No” using the knob.
(Bluetooth

phone



P. 440)

■

The number of portable players that can be registered

Up to 2 portable players can be registered in the system.

Deleting a registered portable player

424

5-7. Setup menu

Bluetooth

audio system setup

To enter the menu of each setting, follow the steps below.

Press the off-hook switch (



P. 418) and select “Setup” using the

“TUNE•SEL” knob
Select “System Setup” using the knob.
Select one of the following items using the knob:

●

Setting voice guidance volume
“Guidance Vol” (



P. 428)

●

Displaying the Bluetooth

device address and name

“Device Name” (



P. 428)

●

Initializing the system
“Initialize” (



P. 428)

System setup items and operation procedures

2
3

425

5-7. Setup menu

Setting a cellular phone

To enter menu for each function, follow the steps below.

Press the off-hook switch and select “Setup” using the “TUNE•SEL” knob
Select “Phone Setup” using the knob.
Select one of the following items using the knob:

●

Registering a cellular phone
“Pair Phone”

●

Selecting a cellular phone to be used
“Select Phone”

●

Changing the registered name of a cellular phone
“Change Name”

●

Listing the registered cellular phones
“List Phones”

●

Changing the passkey
“Set Passkey”

●

Deleting a registered cellular phone
“Delete Phone”

Select “Pair Phone” using the “TUNE•SEL” knob, and perform the procedure for
registering a cellular phone. (



P. 420)

Select “Select Phone” using the “TUNE•SEL” knob.
Select the cellular phone to be used using the knob.

Registering a cellular phone in the hands-free phone system allows the system
to function. The following function can be used for registered cellular phones:

Functions and operation procedures

Registering a cellular phone

Selecting a cellular phone to be used

2
3

Lexus CT (2021 year). Manual in english - page 18
