LEXUS LX 570 (2019 year). Instruction - part 27

Inte
rior fe

Open (push button)
Unlock with the mechanical key
Lock with the mechanical key

■

Glove box light
The glove box light turns on when the tail lights are on.

■

Removing the separate tray

Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to page 436.

Press the button to open the lid.

Glove box

2
3

Pull out the separate tray while releasing the

clips.

WARNING

Keep the glove box closed while driving.

Injuries may result in the event of sudden braking, sudden swerving or an accident.

Console box (if equipped)

428

Remove the tray.

Press the button.

WARNING

Keep the console box closed while driving.

Injuries may result in the event of sudden braking, sudden swerving or an accident.

Overhead console

WARNING

■

Items unsuitable for storing
Do not store items heavier than 0.4 lb (0.2 kg).

Doing so may cause the overhead console to open and the items inside may fall out,

resulting in an accident.

■

While driving
Do not leave the overhead console open.

Items may fall out and cause injury.

429

Inte
rior fe

Cup holders



Front seats



Second seats

Press down and release the lid.

To open, pull down the armrest, press
the button and release the rear cup
holder on the armrest.



Third seats (if equipped)



Luggage compartment (if
equipped)

WARNING

■

Items unsuitable for the cup holders
Do not place anything other than cups or beverage cans in the cup holders. Even when

the lid is closed, items must not be stored in the cup holders.

Other items may be thrown out of the holders in the event of an accident or sudden

braking, and cause injury. If possible, cover hot drinks to prevent burns.

■

When not in use
Keep the cup holders closed.

Injuries may result in the event of sudden braking, sudden swerving or an accident.

430

NOTICE

■

To prevent damage to the cup holders
Stow the cup holders before stowing the rear armrest.

Bottle holders



Front seats



Second seats

NOTICE

■

Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bottle holders,

or glasses and paper cups containing liquid. The contents may spill and glasses may

break.

Card holder

431

Inte
rior fe

Your vehicle is equipped with either a front auxiliary box type B or wireless char-
ger.
For vehicles with wireless charger, refer to page 441.

■

Front seats



Type A

Press the button to open.



Type B (if equipped)

Press the lid to open.

■

Second seats

Pull down the armrest.

Auxiliary boxes

432

Press the button to release the
lock.

■

Third seats /luggage compartment

WARNING

■

While driving
For the front seats and the second seats: Do not leave the auxiliary box open while driv-

ing.

Items stored in it may fall out and cause death or serious injury in case of an accident or

sudden stop.

433

Inte
rior fe

Luggage compartment features

Raise the hook to use.

The cargo hooks are provided for

securing loose items.

To hang the cargo net, use the cargo
net hooks and rear tie-down hooks.

The cargo net itself is not included as an

original equipment.

Remove the cover.

Cargo hooks

Cargo net hooks

Storage compartment (if equipped)

434

Remove the cover. Hold the warning
reflector with the bands.

The warning reflector itself is not

included as an original equipment.

Remove the cover. Hold the first-aid kit
with a band.

The first-aid kit itself is not included as an

original equipment.

■

Using the luggage cover
Pull out the luggage cover and hook
it on the anchors.

Warning reflector holder

First-aid kit holder

Luggage cover (if equipped)

435

Inte
rior fe

■

Removing the luggage cover
Retract the cover and release both
ends, then lift it out.

After removing the luggage cover,

place it somewhere other than the

passenger compartment.

■

When installing the luggage cover (if equipped)
Keep the “TOP” mark on the luggage cover

ends upward.

WARNING

●

To avoid injury, always return the cargo hooks to their positions when not in use.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an

accident may occur due to an occupant being struck by an open auxiliary box or the

items stored inside.

●

Vehicles with luggage cover: Do not allow children to climb on the luggage cover.

Climbing on the luggage cover could result in damage to the luggage cover, possibly

causing death or serious injury to the child.

NOTICE

■

To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

436

Other interior features

While the engine is running, the cool box, which is cooled by the air conditioning,
can be used.

Press the button to open the lid.

Turns the cool box on/off

When on, the indicator light comes on.

■

While the cool box is on
The front air conditioning system cannot be turned off.

■

When the outside temperature is 32

F (0C) or below

The cool box may not operate.

Cool box (if equipped)

WARNING

Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

NOTICE

To prevent battery discharge, do not leave the cool box on longer than necessary when

the engine is not running.

437

Inte
rior fe



Main sun visor
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.



Sub sun visor

Flip down with the main sun visor in
position

or .

Slide the cover to open.

The light turns on when the cover is

opened.

If the vanity lights remain on when the engine switch is turned off, the lights will go off

automatically after 20 minutes.

Sun visors

Vanity mirrors

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended periods

when the engine is not running.

438

The GPS clock’s time is automatically
adjusted by utilizing GPS time informa-
tion. For details, refer to “NAVIGA-
TION SYSTEM OWNER’S
MANUAL”.

The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W

■

Center of console



Front (12 V DC)

Press the lid to open.

Clock

Power outlets

439

Inte
rior fe



Rear (12 V DC)

■

Luggage compartment (120 V AC)

■

The power outlet can be used when
12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.

440

NOTICE

■

To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.

Foreign objects or liquids that enter the power outlet may cause a short circuit.

■

To prevent the fuse from being blown
12 V DC: Do not use an accessory that uses more than 12 V 10 A.
120 V AC: Do not use a 120 V AC appliance that requires more than 100 W.

If a 120 V AC appliance that consumes more than 100 W is used, the protection circuit

will cut the power supply.

■

To prevent the battery from being discharged
Do not use the power outlet longer than necessary when the engine is not running.

■

Appliances that may not operate properly (120 V AC)
The following 120 V AC appliances may not operate properly even if their power con-

sumption is under 100 W:

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data

●

Other appliances that require an extremely stable power supply

441

Inte
rior fe

A portable device can be charged by just placing Qi standard wireless charge
compatible portable devices according to the Wireless Power Consortium, such
as smart phones and mobile batteries, etc., on the charge area.
This function cannot be used with portable devices that are larger than the
charging area. Also, depending on the portable device, it may not operate as
normal. Please read the operation manual for portable devices to be used.

■

The “Qi” symbol
The “Qi” symbol is a trademark of the Wireless Power Consortium.

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

Wireless charger (if equipped)

2
3

442
