395

4-6. Driving tips

4

Dr

iving

WARNING

■

Off-road driving precautions
Always observe the following precautions to minimize the risk of death, serious injury

or damage to your vehicle:

●

Drive carefully when off the road. Do not take unnecessary risks by driving in danger-

ous places.

●

Do not grip the steering wheel spokes when driving off-road. A bad bump could jerk

the wheel and injure your hands. Keep both hands and especially your thumbs on the

outside of the rim.

●

Always check your brakes for effectiveness immediately after driving in sand, mud,

water or snow.

●

After driving through tall grass, mud, rock, sand, rivers, etc., check that there is no

grass, bush, paper, rags, stone, sand, etc. adhering or trapped on the underbody.

Clear off any such matter from the underbody. If the vehicle is used with these materi-

als trapped or adhering to the underbody, a breakdown or fire could occur.

●

When driving off-road or in rugged terrain, do not drive at excessive speeds, jump,

make sharp turns, strike objects, etc. This may cause loss of control or vehicle rollover

causing death or serious injury. You are also risking expensive damage to your vehi-

cle’s suspension and chassis.

396

4-6. Driving tips

NOTICE

■

To prevent the water damage
Take all necessary safety measures to ensure that water damage to the engine or other

components does not occur.

●

Water entering the engine air intake will cause severe engine damage.

●

Water entering the automatic transmission will cause deterioration in shift quality,

locking up of your transmission accompanied by vibration, and ultimately damage.

●

Water can wash the grease from wheel bearings, causing rusting and premature fail-

ure, and may also enter the differentials, transmission and transfer case, reducing the

gear oil’s lubricating qualities.

■

When you drive through water
If driving through water, such as when crossing shallow streams, first check the depth of

the water and the bottom of the riverbed for firmness. Drive slowly and avoid deep

water.

■

Inspection after off-road driving

●

Sand and mud that has accumulated in brake drums and around brake discs may

affect braking efficiency and may damage brake system components.

●

Always perform a maintenance inspection after each day of off-road driving that has

taken you through rough terrain, sand, mud, or water. For scheduled maintenance

information, refer to the “Warranty and Services Guide”, “Owner’s Manual Supple-

ment” or “Scheduled Maintenance”.

397

5

Interior features

5-1. Remote Touch screen

Remote Touch/12.3-inch

display ......................................... 398

5-2. Lexus Climate Concierge

Lexus Climate Concierge..... 404

5-3. Using the air conditioning

system and defogger

Front automatic air

conditioning system .............. 405

Rear air conditioning

system ........................................... 416

Heated steering wheel/seat

heaters/seat ventilators.........419

5-4. Using the interior lights

Interior lights list..........................423

• Interior lights ..........................424
• Personal lights .......................425

5-5. Using the storage features

List of storage features ............426

• Glove box ............................... 427
• Console box........................... 427
• Overhead console ..............428
• Cup holders ...........................429
• Bottle holders ........................430
• Card holder............................430
• Auxiliary boxes ...................... 431

Luggage compartment

features .......................................433

5-6. Using the other interior

features

Other interior features ............436

• Cool box..................................436
• Sun visors ................................ 437
• Vanity mirrors ....................... 437
• Clock ........................................438
• Power outlets.........................438
• Wireless charger ...................441
• Armrest....................................449
• Rear door sunshades .........450
• Coat hooks.............................450
• Assist grips............................... 451

Garage door opener ...............452

398

5-1. Remote Touch screen

Remote Touch/12.3-inch display

“MAP” button

Press this button to display the vehicle’s current position.

“

•” button

Press this button to change map scale and scroll through lists.

Back button

Press this button to display the previous screen.

“MENU” button

Press this button to display the “Menu” screen.

Remote Touch knob

Move in the desired direction to select a function, letter and screen button.
Press the knob to enter the selected function, letter or screen button.

“ENTER” button

Press this button to enter the selected function, letter or screen button.

The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navigation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

Remote Touch operation

1

2

3

4

5

6

399

5-1. Remote Touch screen

5

Inte
rior fe

ature

s

Select: Move the Remote Touch
knob in the desired direction.
Enter: Press the Remote Touch knob
or “ENTER” button.

■

Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed even

if the Remote Touch is operated.

Remote Touch operation

1

2

WARNING

■

When using the Remote Touch

●

Do not allow fingers, fingernails or hair to become caught in the Remote Touch as this

may cause an injury.

●

Be careful when selecting the Remote Touch in extreme temperatures as it may

become very hot or cold due to the temperature inside the vehicle.

NOTICE

■

To prevent damage to the Remote Touch

●

Do not allow the Remote Touch to come into contact with food, liquid, stickers or lit

cigarettes as doing so may cause it to change color, emit a strange odor or stop func-

tioning.

●

Do not subject the Remote Touch to excessive pressure or strong impact as the knob

may bend or break off.

●

Do not allow coins, contact lenses or other such items to become caught in the

Remote Touch as this may cause it to stop functioning.

●

Items of clothing may rip if they become caught on the Remote Touch knob.

●

If your hand or any object is on the Remote Touch knob when the engine switch is in

ACCESSORY mode, the Remote Touch knob may not operate properly.

400

5-1. Remote Touch screen

Press the “MENU” button on the Remote Touch to display the “Menu” screen.
The display may differ depending on the type of the system.

When the split-screen display is selected, the “Menu” screen will be displayed on
the main display. (

P. 401)

“Menu” screen

Switch

Function

Select to display the “Destination” screen.

*

Select to display the radio control screen.

*

Select to display the media control screen.

*

Select to display the hands-free operation screen.

*

Select to display the “LEXUS App Suite” screen.

*

Select to display the “Information” screen.

*

Select to display the air conditioning control screen. (

P. 405)

Select to display the “Setup” screen.

*

401

5-1. Remote Touch screen

5

Inte
rior fe

ature

s

*

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Full screen display

The following functions can be displayed full screen:

●

Initial screen

●

“Menu” screen (

P. 400)

●

Map screen

*

*

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

“Display”

Select to adjust the contrast and brightness of the screens, turn the

screen off, etc.

*

12.3-inch display operation

Switch

Function

402

5-1. Remote Touch screen

■

Split-screen display
Different information can be displayed on the left and right of the screen. For
example, air conditioning system or audio screens can be displayed and oper-
ated while the fuel consumption information screen is being displayed. The
large screen on the left of the display is called the main display, and the small
screen to the right is called the side display.

403

5-1. Remote Touch screen

5

Inte
rior fe

ature

s

■

Main Display
For details about the functions and operation of the main display, refer to the
respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Side Display



Basic screens

To change the screen displayed on the side display, use the screen buttons on
the right side of the display.

Navigation system

*

Audio

*

Phone

*

Vehicle information (

P. 110)

Air conditioning system
(

P. 405)



Interruption screens

Each of the following screens is displayed automatically in accordance with
conditions.

• Intuitive parking assist (

P. 293)

• Phone

*

• Destination Assist
• Driving  mode  (

P. 290)

*

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

Split-screen display operation

1

2
3
4
5

404

5-2. Lexus Climate Concierge

Lexus Climate Concierge

“CLIMATE CONCIERGE” switch

When the switch is pressed, the indica-

tor above the switch illuminates and all

of the following systems operate in auto-

matic mode.
If any of the system is operated manually,

the indicator turns off. However, all

other functions continue to operate in

automatic mode.

■

Automatic air conditioning system (

P. 405, 416)

The temperature can be adjusted individually for the driver seat, passenger seat, and

rear seats.

When a passenger is detected in the second seat, the rear air conditioning operates

in automatic mode.

■

Seat heaters and ventilators (if equipped) (

P. 419)

Heating or ventilation is automatically selected according to the set temperature of

the air conditioning system, the outside temperature, etc.

The seat heaters and ventilators of the front passenger seat and second outboard

seats operate in automatic mode if passengers are detected.

■

Heated steering wheel (if equipped) (

P. 419)

Heated steering wheel operates automatically according to the outside temperature

and cabin temperature.

■

Front air conditioning system operation
To improve air conditioning performance in the front seat area, the air outlets on the rear

of the console box may close when there is no passenger in the second seat.

■

Rear air conditioning system operation
The rear air conditioning system may stop automatically when there is no passenger in

the second seat.

■

Seat heater/ventilator operation
When automatic mode is selected using the seat heater/ventilator switch, passenger

detection is not performed.

The seat heaters, seat ventilators and heated steering wheel are each auto-
matically controlled according to the set temperature of the air conditioning
system, the outside and cabin temperature, etc. Lexus Climate Concierge
allows a comfortable condition to be maintained without adjusting each sys-
tem.

405

5-3. Using the air conditioning system and defogger

5

Inte
rior fe

ature

s

Front automatic air conditioning system

■

Adjusting the temperature setting

Press

 to increase the temperature and

 to decrease the tem-

perature.

If the

 indicator is turned off, the system will blow ambient temperature air

or heated air.

■

Adjusting the fan speed setting

Press

 to increase the fan speed and

 to decrease the fan

speed.

Press

 to turn the fan off.

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
Select the “MENU” button on the Remote Touch, then select

 to display

the air conditioning control screen. (

P. 400)

The air conditioning system can be displayed and operated on the side display.
(

P. 402)

Control panel

406

5-3. Using the air conditioning system and defogger

■

Change the airflow mode

To change the air outlets, press

.

The air outlets used are switched
each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates

■

Other functions

●

Switching between outside air and recirculated air modes (

P. 411)

●

Defogging the windshield (

P. 411)

●

Defogging the rear window and outside rear view mirrors (

P. 411)

1

2

3
4

407

5-3. Using the air conditioning system and defogger

5

Inte
rior fe

ature

s

■

Main display

Left-hand front seat side temperature control
Left-hand front seat side air outlet selector
Air flows to the feet and the windshield defogger operates
Fan speed control
Right-hand front seat side air outlet selector
Option control screen
Right-hand front seat side temperature control
Rear air conditioning operation screen
Eco mode
Adjust the temperature for driver, passenger and rear seats separately
(“4-ZONE” mode)
Cooling and dehumidification function on/off
Automatic mode

Control screen

1

2
3
4
5
6
7
8
9

10

11

12

408

5-3. Using the air conditioning system and defogger

■

Changing the air flow mode
To adjust settings, select the screen button.



 Air flows to the upper body.



 Air flows to the upper body and feet.



 Air flows to the feet.



 Air flows to the feet and the windshield defogger operates.

■

Side display

Select the left-hand front seat
side air flow mode
Adjust the left-hand side tem-
perature setting
Adjust the fan speed setting
Select the right-hand front seat
side air flow mode
Adjust the right-hand side tem-
perature setting
Adjust the temperature for driver
and passenger seats separately
(“4-ZONE” mode)
Select to set cooling and dehumidification function on/off
Select to set auto mode on

■

Option control screen

Select

 on the main display to display the option control screen. The func-

tions can be switched on and off.

Prevent ice from building up on
the windshield and wiper blades
(

P. 411)

Micro dust and pollen filter
(

P. 411)

1

2

3
4

5

6

7

8

1

2

409

5-3. Using the air conditioning system and defogger

5

Inte
rior fe

ature

s

■

Using the automatic mode

Press

 or select

 on the control screen.

The air conditioning system will begin to operate. Air outlets and fan speed
are automatically adjusted according to the temperature setting.

Press

 to switch to automatic air intake mode.

The air conditioning system automatically switches between outside air
and recirculated air modes.

Press

 or select

 to increase the temperature and press

or select

 to decrease the temperature.

The temperature for the driver’s and front passenger’s seats can be set separately.

To stop the operation, press

.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated is maintained.

The air conditioning system switches between individual and simultaneous
modes each time

 on the control screen is selected.

Individual mode (the indicator is on.): The temperature for the driver’s, front pas-
senger’s and rear seats (

P. 416) can be adjusted separately. Operating the

passenger’s side or rear temperature control will enter individual mode.

In the simultaneous mode, only

 (increase) or

 (decrease) on the

driver’s side can be used to adjust the temperature for all seats.

Air conditioning controls

Adjusting the temperature for driver and passenger seats separately
(“4-ZONE” mode)

1

2

3

4

410

5-3. Using the air conditioning system and defogger

■

Using the automatic mode

Select

 on the main display.

Select .

Select

 to increase the tem-

perature and

 to decrease the

temperature.

■

Adjusting the temperature setting

Select

 on the main display.

Select

 to increase the tem-

perature and

 to decrease the

temperature.

Operating the switch will enter indi-

vidual mode.

Left-hand rear seat
Right-hand rear seat

■

Adjusting the fan speed setting

Select

 on the main display.

Select

 to increase the fan speed and

 to decrease the fan speed.

Select

 to turn the fan off.

Changing the rear seat settings

1

2

3

1

2

1

2

1

2

3
