LEXUS LX 570 (2019 year). Instruction - part 26

411

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Switching between outside air and recirculated air modes

Press

on the control panel.

The mode switches among

(recirculated air mode), “AUTO” and

(outside air mode) each time

is pressed.

When the system is switched to automatic mode, it operates automatically.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side windows.

Press

on the control panel.

Set the outside/recirculated air mode button to outside air mode if the recirculated

air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.
To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press

on the control panel.

Press

again to turn the defogger off.

■

Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.

Select

on the option control screen.

In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.

■

Windshield wiper de-icer
This feature is used to prevent ice from building up on the windshield and
wiper blades.
Select

on the option control screen.

When the windshield wiper de-icer is on, the indicator turns on.
The windshield wiper de-icer will automatically turn off after a period of time.

Other functions

412

5-3. Using the air conditioning system and defogger

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the air flow direction and opening/closing the air outlets

Direct air flow to the left or right, up or down
Turn the knob to open or close the vent

Air outlets



Front side



Front center



Rear

413

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the

is pressed or

on the control screen is selected.

■

Operation of the air conditioning system in Eco drive mode

●

In the Eco drive mode, the air conditioning system is controlled as follows to prioritize

fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations
• Adjust the fan speed

• Turn off Eco mode

■

Using the voice command system
Air conditioning system can be operated using voice commands. For details, refer to the

“NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Selecting

will dehumidify the air from the outlets and defog the windshield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set the outside/recircu-

lated air mode button to the recirculated air mode. This is effective in preventing out-

side air from entering the vehicle interior. During cooling operation, setting the

recirculated air mode will also cool the vehicle interior effectively.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

■

When the outside temperature exceeds 75

F (24C) and the air conditioning system

is on

●

In order to reduce the air conditioning power consumption, the air conditioning system

may switch to recirculated air mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch is turned to

IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

Automatic mode for air intake control
In automatic mode, the system detects exhaust gas and other pollutants and automati-

cally switches between outside air and recirculated air modes.
When the dehumidification function is off, and the fan is operating, turning automatic

mode on will activate the dehumidification function.

414

5-3. Using the air conditioning system and defogger

■

When the outside temperature is low
The dehumidification function may not operate even when

is selected.

■

Micro dust and pollen filter

●

In order to prevent the windows from fogging up when the outside air is cold, the fol-

lowing may occur.
• Outside air mode does not switch to recirculated air mode.

• The air conditioning system operates automatically.

• The operation cancels after 1 minute.

●

In rainy weather, the windows may fog up. Press

■

The rear window defogger, outside rear view mirror defogger and windshield wiper de-

icer can be operated when
The engine switch is in IGNITION ON mode.

■

When the windshield wiper de-icer is on
The windshield wiper de-icer will automatically turn off after approximately 15 minutes.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

While the cool box is on (if equipped)
The front air conditioning system cannot be turned off.

■

Air conditioning filter
P. 503

■

Customization
Settings (e.g. Exhaust gas sensor sensitivity) can be changed.

(Customizable features:

P. 584)

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on.

415

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is

not running.

416

5-3. Using the air conditioning system and defogger

Rear air conditioning system

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan speed.

Press

to turn the fan off.

■

Changing the air flow mode

Press .

The air flow mode switches each time the button is pressed.

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
The rear air conditioning operation switches are on the second seat armrest.
(

P. 449)

417

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Using the automatic mode

Press the

Adjust the temperature setting.

To stop the operation, press the

■

If the system is operated manually in automatic mode
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated are maintained.

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the position of and opening and closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob fully to the back of
the vehicle to close the vent.

Air conditioning controls

Air outlets

418

5-3. Using the air conditioning system and defogger

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is

not running.

419

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

Heated steering wheel



/seat heaters/seat

ventilators



: If equipped

Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats. Seat ventilators maintain good airflow by blowing air from
the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories comes in

contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged

• Persons with sensitive skin

• Persons who are fatigued

• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold

remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do not stick

sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is off.

420

5-3. Using the air conditioning system and defogger



Automatic operation

Operates automatically according to
the outside and cabin temperature
when “CLIMATE CONCIERGE”
switch is on. (

P. 404) Automatic

operation can be turned off using the
switch.

The indicator light comes on when the

heated steering wheel is operating.



Manual operation

Turns the heated steering wheel on/off

The indicator light comes on when the heated steering wheel is operating.

■

The heated steering wheel can be used when
The engine switch is in IGNITION ON mode.

■

Timer function
Automatic operation: Operates for a maximum of 30 minutes.

(Turns off according to outside and cabin temperature.)
Manual operation: Turns off after approximately 30 minutes.

■

If the indicator light flashes
Press the switch to turn the heated steering wheel off and then press the switch again. If

the indicator light still flashes, a malfunction may be occurring. Turn the heated steering

wheel off and have the vehicle inspected by your Lexus dealer.

■

Customization
The automatic turning on/off of the heated steering wheel can be customized. (Custom-

izable features

P. 584)

Heated steering wheel (if equipped)

421

5-3. Using the air conditioning system and defogger

Inte
rior fe

ature

Seat heater switches

The indicator light (yellow) on the switch comes on when the seat heater is operating.

Seat ventilator switches (if equipped)

The indicator light (green) on the switch comes on when the seat ventilator is operat-

ing.

Level indicator lights

The seat heater temperature level or the seat ventilator fan speed level (if equipped) is

displayed.

“AUTO” indicator lights

Seat heaters and ventilators (if equipped)



Front seats



Second outboard seats

422

5-3. Using the air conditioning system and defogger

■

Modes and indicators
The mode can be changed by pressing the switch.

: When automatic mode is selected, the level automatically changes depending on the

air conditioning settings.

■

The seat heaters/seat ventilators can be used when
The engine switch is in IGNITION ON mode.

■

Replacing the air filters
Filters are installed in the seat ventilators. For replacement of the filters, contact your

Lexus dealer.

■

Customization
The automatic mode settings for the seat heaters and ventilators can be changed.

(Customizable features:

P. 584)

Mode

“AUTO” indicator light

Level indicator lights

Off

Automatic*

3 to 1, or off

Off

Mid

Off

423

5-4. Using the interior lights

Inte
rior fe

ature

Interior lights list

Rear interior lights (

P. 424)

Rear personal lights (

P. 425)

Inside door handle light
Front interior lights (

P. 424)

Front personal lights (

P. 425)

Shift lever light (when the engine
switch is in ACCESSORY or IGNI-
TION ON mode)

Footwell lights
Scuff lights (if equipped)
Engine switch light
Door courtesy light
Luggage compartment light (if
equipped)
Outer foot lights
Running board lights
Door trim lights

2
3
4
5
6

8
9

12
13
14
