Inte
rior fe

ature

Drive the vehicle at 5 mph
(8 km/h) or less in a circle until a
direction is displayed.

If there is not enough space to drive

in a circle, drive around the block

until a direction is displayed.

■

Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:

●

The vehicle is stopped immediately after turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth’s magnetic field is subject to interference by

artificial magnetic fields (underground car park/parking lot, under a steel tower,

between buildings, roof car park/parking lot, near an intersection, near a large vehicle,

etc.).

●

The vehicle has become magnetized. (There is a magnet or metal object near the inside

rear view mirror.)

●

The 12-volt battery has been disconnected.

●

A door is open.

WARNING

■

While driving the vehicle
Do not adjust the display. Adjust the display only when the vehicle is stopped.

■

When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity. Do not vio-

late any local traffic rules while performing circling calibration.

NOTICE

■

To avoid compass malfunctions
Do not place magnets or any metal objects near the inside rear view mirror.

Doing this may cause the compass sensor to malfunction.

■

To ensure normal operation of the compass

●

Do not perform a circling calibration of the compass in a place where the earth’s

magnetic field is subject to interference by artificial magnetic fields.

●

During calibration, do not operate electric systems (moon roof, power windows, etc.)

as they may interfere with the calibration.

460

LEXUS Enform Safety Connect



Microphone
LED light indicators
“SOS” button



: If equipped

Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, which operates 24 hours per day, 7 days
per week.
Safety Connect service is available by subscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.

System components

2
3

461

Inte
rior fe

ature

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

Helps drivers receive necessary response from emergency service providers.
(

P. 462)

: U.S. Patent No. 7,508,298 B2

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (

P. 462)

●

Emergency Assistance Button (SOS)
Connects drivers to response-center support. (

P. 462)

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance. (

P. 463)

After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call 1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in
your vehicle for further subscription details.

■

Safety Connect Services Information

●

Phone calls using the vehicles Bluetooth

technology will not be possible during Safety

Connect.

●

Contact with the Safety Connect response center is dependent upon the telematics

device being in operative condition, cellular connection availability, and GPS satellite

signal reception, which can limit the ability to reach the response center or receive

emergency service support. Enrollment and Telematics Subscription Service Agree-

ment required. A variety of subscription terms is available; charges vary by subscription

term selected.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location

will function in the United States, including Hawaii and Alaska, and in Canada, and

Enhanced Roadside Assistance will function in the United States (except Hawaii) and in

Canada. No Safety Connect services will function outside of the United States in coun-

tries other than Canada.

●

Safety Connect services are not subject to section 255 of the Telecommunications Act

and the device is not TTY compatible.

■

Languages
The Safety Connect response center will offer support in multiple languages. The Safety

Connect system will offer voice prompts in English and Spanish. Please indicate your lan-

guage of choice when enrolling.

■

When contacting the response center
You may be unable to contact the response center if the network is busy.

Services

Subscription

462

When the power switch is turned to ON mode, the red indicator light comes on
for 2 seconds then turns off. Afterward, the green indicator light comes on, indi-
cating that the service is active.
The following indicator light patterns indicate specific system usage conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)

●

No indicator light (off) = Safety Connect service not active

■

Automatic Collision Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be sent to the location.

■

Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to
assist them in locating and recovering the vehicle. After filing a police report,
call the Safety Connect response center at 1-800-25-LEXUS
(1-800-255-3987) and follow the prompts for Safety Connect to initiate this
service.
In addition to assisting law enforcement with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circum-
stances, be shared with third parties to locate your vehicle. Further informa-
tion is available at Lexus.com.

■

Emergency Assistance Button (“SOS”)
In the event of an emergency on the road, push the “SOS” button to reach the
Safety Connect response center. The answering agent will determine your
vehicle’s location, assess the emergency, and dispatch the necessary assis-
tance required.

If you accidentally press the “SOS” button, tell the response-center agent that you

are not experiencing an emergency.

Safety Connect LED light Indicators

Safety Connect services

463

Inte
rior fe

ature

■

Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GPS data to the already included war-
ranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-
center agent, who can help with a wide range of needs, such as: towing, flat
tire, fuel delivery, etc. For a description of the Roadside Assistance services
and their limitations, please see the Safety Connect Terms and Conditions,
which are available at Lexus.com.

Important! Read this information before using Safety Connect.

■

Exposure to radio frequency signals
The Safety Connect system installed in your vehicle is a low-power radio
transmitter and receiver. It receives and also sends out radio frequency (RF)
signals.
In August 1996, the Federal Communications Commission (FCC) adopted
RF exposure guidelines with safety levels for mobile wireless phones. Those
guidelines are consistent with the safety standards previously set by the fol-
lowing U.S. and international standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measurement)
Report 86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]

Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. Over 120 scientists, engineers, and physi-
cians from universities, and government health agencies and industries
reviewed the available body of research to develop the ANSI Standard
(C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.

Safety information for Safety Connect

465

Maintenance and care

7-1. Maintenance and care

Cleaning and protecting the

vehicle exterior ........................466

Cleaning and protecting the

vehicle interior .........................469

7-2. Maintenance

Maintenance

requirements..............................472

General maintenance...............474
Emission inspection and

maintenance (I/M)
programs.....................................477

7-3. Do-it-yourself maintenance

Do-it-yourself service

precautions................................ 478

Hood .............................................. 480
Positioning a floor jack.............482
Engine compartment ...............483
12-volt battery............................... 491
Tires..................................................495
Tire inflation pressure ...............502
Wheels .......................................... 505
Air conditioning filter ...............507
Electronic key battery..............509
Checking and replacing

fuses.................................................511

Light bulbs...................................... 514

466

Cleaning and protecting the vehicle exterior

●

Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly with
water.

●

Wipe away any water.

●

Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle body is cool.

■

Self-restoring coat
The vehicle body has a self-restoring coating that is resistant to small surface scratches

caused in a car wash etc.

●

The coating lasts for 5 to 8 years from when the vehicle is delivered from the plant.

●

The restoration time differs depending on the depth of the scratch and outside temper-

ature. The restoration time may become shorter when the coating is warmed by apply-

ing warm water.

●

Deep scratches caused by keys, coins, etc. cannot be restored.

●

Do not use wax that contain abrasives.

■

Automatic car washes

●

Fold the mirrors before washing the vehicle. Start washing from the front of the vehicle.

Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface and harm your

vehicle’s paint.

●

Rear spoiler may not be washable in some automatic car washes. There may also be an

increased risk of damage to vehicle.

■

High pressure car washes

●

Do not allow the nozzles of the car wash to come within close proximity of the windows.

●

Before using the car wash, check that the fuel filler door on your vehicle is closed prop-

erly.

■

Note for a smart access system with push-button start
If the door handle becomes wet while the electronic key is within the effective range, the

door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more sep-

arate from the vehicle while the vehicle is being washed. (Take care to ensure that the key

is not stolen.)

Perform the following to protect the vehicle and maintain it in prime condi-
tion:

467

Main

■

Aluminum wheels

●

Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or

abrasive cleaners. Do not use strong or harsh chemical cleaners.

Use the same mild detergent and wax as used on the paint.

●

Do not use detergent on the wheels when they are hot, for example after driving for

long distance in the hot weather.

●

Wash detergent from the wheels immediately after use.

■

Bumpers
Do not scrub with abrasive cleaners.

■

Front side windows water-repellent coating

●

The following precautions can extend the effectiveness of the water-repellent coating.
• Remove any dirt, etc. from the front side windows regularly.

• Do not allow dirt and dust to accumulate on the windows for a long period.

Clean the windows with a soft, damp cloth as soon as possible.

• Do not use wax or glass cleaners that contain abrasives when cleaning the windows.

• Do not use any metallic objects to remove condensation build up.

●

When the water-repellent performance has become insufficient, the coating can be

repaired. Contact your Lexus dealer.

WARNING

■

When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may cause the

electrical components etc. to catch fire.

■

When cleaning the windshield (vehicles with rain-sensing windshield wipers)

●

When the upper part of the windshield where the raindrop sensor is located is

touched by hand

●

When a wet rag or similar is held close to the raindrop sensor

●

If something bumps against the windshield

●

If you directly touch the raindrop sensor body or if something bumps into the raindrop

sensor

■

Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-

ciently, as touching a hot exhaust pipe can cause burns.

Set the wiper switch to off.

If the switch is in “AUTO”, the wipers may oper-

ate unexpectedly in the following situations,

and may result in hands being caught or other

serious injuries and cause damage to the wiper

blades.

Off

468

NOTICE

■

To prevent paint deterioration and corrosion on the body and components (aluminum

wheels etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present on the paint surface

• If dead insects, insect droppings or bird droppings are present on the paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust, iron pow-

der or chemical substances

• If the vehicle becomes heavily soiled with dust or mud

• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place with low

humidity when storing the wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.

This may damage the surfaces of the lights.

●

Do not apply wax to the surfaces of the lights.

Wax may cause damage to the lenses.

■

When using an automatic car wash (vehicles with rain-sensing windshield wipers)
Set the wiper switch to the off position.

If the wiper switch is in “AUTO”, the wipers may operate and the wiper blades may be

damaged.

■

When using a high pressure car wash

●

When washing the vehicle, do not let water from the high-pressure washer directly hit

the camera or the area around the camera. Due to the shock from high-pressure

water, it is possible that the device may not operate normally.

●

Do not bring the nozzle tip close to boots (rubber or resin manufactured cover), con-

nectors or the following parts. The parts may be damaged if they come into contact

with high-pressure water.
• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

469

Main

Cleaning and protecting the vehicle interior

●

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth
dampened with lukewarm water.

●

If dirt cannot be removed, wipe it off with a soft cloth dampened with neutral
detergent diluted to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off remaining
traces of detergent and water.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe off any excess dirt and dust with a soft cloth dampened with diluted
detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

●

Wring out any excess water from the cloth and thoroughly wipe off all remain-
ing traces of detergent.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.
Allow the leather to dry in a shaded and ventilated area.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe it off with a soft cloth dampened with neutral detergent diluted to
approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off remaining
traces of detergent and water.

The following procedures will help protect your vehicle’s interior and keep it
in top condition:

Protecting the vehicle interior

Cleaning the leather areas

Cleaning the synthetic leather areas

470

■

Caring for leather areas
Lexus recommends cleaning the interior of the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.

■

Shampooing the carpets
There are several commercial foaming-type cleaners available. Use a sponge or brush to

apply the foam. Rub in overlapping circles. Do not use water. Wipe dirty surfaces and let

them dry. Excellent results are obtained by keeping the carpet as dry as possible.

■

Seat belts
Clean with mild soap and lukewarm water using a cloth or sponge. Also check the belts

periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle, such as on the floor, in the hybrid battery

(traction battery) air vents, and in the luggage compartment.

Doing so may cause the hybrid battery, electrical components, etc. to malfunction or

catch fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.

(

P. 41)

An electrical malfunction may cause the airbags to deploy or not function properly,

resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)
Do not use polish wax or polish cleaner. The instrument panel may reflect off the wind-

shield, obstructing the driver’s view and leading to an accident, resulting in death or

serious injury.

471

Main

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehicle interior

or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkaline or

acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other interior part’s

painted surface may be damaged.

■

Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of leather

surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time. Park the

vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they

may stick to the leather surface if the vehicle interior heats up significantly.

■

Water on the floor
Do not wash the vehicle floor with water.

Vehicle systems such as the audio system may be damaged if water comes into contact

with electrical components such as the audio system above or under the floor of the

vehicle. Water may also cause the body to rust.

■

Cleaning the inside of the rear window

●

Do not use glass cleaner to clean the rear window, as this may cause damage to the

rear window defogger heater wires or antenna. Use a cloth dampened with luke-

warm water to gently wipe the window clean. Wipe the window in strokes running

parallel to the heater wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

472

7-2. Maintenance

Maintenance requirements

General maintenance should be performed on a daily basis. This can be done by
yourself or by a Lexus dealer.

Scheduled maintenance should be performed at specified intervals according to
the maintenance schedule.

For details about maintenance items and schedules, refer to the “Warranty and Ser-

vice Guide”, “Owner’s Manual Supplement” or “Scheduled Maintenance”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty coverage.

The use of Lexus repair manuals is recommended.
For details about warranty coverage, refer to the separate “Owner’s Guide”, “War-

ranty and Service Guide”, “Owner’s Manual Supplement” or “Warranty Booklet”.

To ensure safe and economical driving, day-to-day care and regular mainte-
nance are essential. It is the owner’s responsibility to perform regular checks.
Lexus recommends the following maintenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

473

7-2. Maintenance

Main
