LEXUS CT200H (2017 year). Instruction - part 28

443

Other interior features

To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.

Slide the cover to open.

The light turns on when the cover is

opened.

If the vanity light remain on when the power switch is turned off, the light will go off auto-

matically after 20 minutes.

Sun visors

Vanity mirrors

NOTICE

To prevent 12-volt battery discharge, do not leave the vanity lights on for extended peri-

ods while the hybrid system is off.

444

6-4. Using the other interior features



Vehicles with a navigation system

Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.



Vehicles without navigation system

The clock can be adjusted by pressing the buttons.

Adjusts the hours
Adjusts the minutes
Rounds to the nearest hour

: e.g. 1:00 to 1:29

1:00

1:30 to 1:59

2:00

The clock is displayed when the power switch is in ACCESSORY or ON mode.

Please use a power supply for electronic goods that use less than 12 VDC /10 A
(power consumption of 120 W).
When using electronic goods, make sure that the power consumption of all the
connected power outlets is less than 120 W.



Center console
Press down and release the lid.

Clock

2
3

Power outlet

445

6-4. Using the other interior features

Inte
rior fe

ature

Open the cover.



Auxiliary box (if equipped)
Press the button.

Open the cover.

●

The power outlet can be used when the power switch is in ACCESSORY or ON mode.

●

The gap in the lid allows power cables to be

passed through even when the lid is closed.

(auxiliary box)

446

6-4. Using the other interior features

An assist grip installed on the ceiling
can be used to support your body while
sitting on the seat.

NOTICE

●

To avoid damaging the power outlet, close the power outlet lid when the power outlet

is not in use.

Foreign objects or liquids that enter the power outlet may cause a short circuit.

●

To prevent 12-volt battery discharge, do not use the power outlet longer than neces-

sary when the hybrid system is off.

Assist grips

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from your seat.

NOTICE

To prevent damage to the assist grip, do not hang any heavy object or put a heavy load

on the assist grip.

447

6-4. Using the other interior features

Inte
rior fe

ature

Garage door opener



The garage door opener (HomeLink

Universal Transceiver) is manufactured

under license from HomeLink

The HomeLink

compatible transceiver in your vehicle has 3 buttons which can

be programmed to operate 3 different devices. Refer to the programming
method below appropriate for the device.

Garage door operation indicators
HomeLink

indicator light

Buttons



: If equipped

The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.

Programming the HomeLink

2
3

448

6-4. Using the other interior features

■

Before programming HomeLink

●

During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or other devices to prevent injury or other
potential harm.

●

It is recommended that a new battery be placed in the remote control
transmitter for more accurate programming.

●

Garage door openers manufactured after 1995 may be equipped with
rolling code protection. If this is the case, you will need a stepladder or
other sturdy, safe device to reach the “learn” or “smart” button on the
garage door opener motor.

●

In order to conserve electricity after the power switch is turned off and 20
minutes after the doors have been opened or closed, registration proce-
dures may not be possible and the garage door opener may not operate.
Perform the registration procedures with the power switch in ON mode.

■

Programming HomeLink

Point the remote control transmit-
ter for the device 1 to 3 in. (25 to
75 mm) from the HomeLink

buttons.

Keep the HomeLink

indicator light

in view while programming.



For U.S.A. owners
Press and hold the HomeLink

button you want to program and
the remote control transmitter
button simultaneously. When the
HomeLink

indicator light

changes from slowly flashing
orange to rapidly flashing green
(rolling code) or continuously lit
green (fixed code), release both
buttons.

449

6-4. Using the other interior features

Inte
rior fe

ature



Programming an entry gate (for U.S.A. owners)/Programming a device in
the Canadian market
With one hand, press and hold the HomeLink

button you want to pro-

gram. With your other hand, press and release the remote control transmit-
ter every 2 seconds and repeat this cycle until the HomeLink

indicator

light starts to flash rapidly. Then, release the buttons.
Test the HomeLink

operation by pressing the newly programmed button

and observing the indicator light:

●

If the indicator light is solid/continuous, programming has been com-
pleted and your device should activate when the HomeLink

button is

pressed and released.

●

If the indicator light blinks rapidly for 2 seconds and then turns into a
solid/continuous light, proceed to the heading “Programming a Rolling
Code System”.

Repeat the steps above to program another device for any of the remaining
HomeLink

buttons.

■

Programming a Rolling Code System

Locate the “learn” or “smart” but-
ton on the garage door opener
motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by man-

ufacturer. Please refer to the

Owner’s manual supplied with the

garage door opener motor for

details.

Press and release the “learn” or
“smart” button.
Perform step within 30 sec-
onds after performing step .

450

6-4. Using the other interior features

Press and hold the programmed
HomeLink

button (located

inside the vehicle) for 2 seconds
and release it. Repeat this
sequence (press/hold/release)
up to 3 times to complete pro-
gramming.

If the garage door opener motor

activates when the HomeLink

but-

ton is pressed, the garage door

opener motor recognizes the

HomeLink

signal.

■

Enabling 2-way communication with a garage door (only available for com-
patible devices)
When enabled, 2-way communication allows you to check the status of the
opening and closing of the garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used
is a compatible device. (To check device compatibility, refer to the Owner’s
manual supplied with the garage door opener motor.)

Press a programmed HomeLink

button to operate a garage door.

Within 1 minute of pressing the HomeLink

button, after the garage door

operation has stopped, press the “learn” or “smart” button on the garage
door opener motor. Within 5 seconds of the establishment of 2-way com-
munication with the garage door opener, both garage door operation indi-
cators in the vehicle will flash rapidly (green).

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already have
devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing, continue to hold the

HomeLink

button and perform “Programming HomeLink

” from step

(it takes 20 seconds for the HomeLink

indicator to start flashing).

451

6-4. Using the other interior features

Inte
rior fe

ature

Press the appropriate HomeLink

button. The HomeLink

indicator light

should turn on.

The status of the opening and closing of
a garage door is shown by the indica-
tors.

Opening
Closing

This function is only available if the

garage door opener motor used is a

compatible device. (To check device

compatibility, refer to the Owner’s man-

ual supplied with the garage door

opener motor.)

The indicators can operate within approximately 820 ft. (250 m) of the garage
door. However, if there are obstacles between the garage door and the vehicle,
such as houses and trees, feedback signals from the garage door may not be
received.
To recall the previous door operation status, press and release either
HomeLink

buttons “1” and “2” or “2” and “3” simultaneously for 2 seconds. The

last recorded status will be displayed for 5 seconds.

Press and hold the 2 outside buttons for
10 seconds until the HomeLink

indi-

cator light changes from continuously
lit (orange) to rapidly flashing (green).

If you sell your vehicle, be sure to erase

the programs stored in the HomeLink

memory.

Operating HomeLink

Garage door operation indicators

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

Erasing the entire HomeLink

memory (all three programs)

452

6-4. Using the other interior features

■

Programs stored in the HomeLink

memory

●

The registered codes are not erased even if the 12-volt battery cable is disconnected.

●

If learning failed when registering a different code to a HomeLink

button that already

has a code registered to it, the already registered code is not erased.

■

Certification for the garage door opener



For vehicles sold in the U.S.A., Hawaii, Guam, Puerto Rico and NATO Germany



For vehicles sold in Canada

■

For additional programming assistance with your HomeLink

Universal Transceiver

Visit on the web at www.homelink.com or call 1-800-355-3515.

453

6-4. Using the other interior features

Inte
rior fe

ature

WARNING

■

When programming a garage door or other remote control device
The garage door or other device may operate, so ensure people and objects are out of

danger to prevent potential harm.

■

Conforming to federal safety standards
Do not use the HomeLink

compatible transceiver with any garage door opener or

device that lacks safety stop and reverse features as required by federal safety stan-

dards.

This includes any garage door that cannot detect an interfering object. A door or

device without these features increases the risk of death or serious injury.

■

When operating or programming HomeLink

Never allow a child to operate or play with the HomeLink

buttons.

454

6-4. Using the other interior features

Compass





Vehicles without garage door opener



Vehicles with garage door opener

To turn the compass on or off, press the
button.



: If equipped

The compass on the inside rear view mirror indicates the direction in which
the vehicle is heading.

Operation

Type A:

Type B:

To turn the compass on or off, press the
“AUTO” button for more than 3 sec-
onds.

To turn the compass on or off, press
the “AUTO” button for more than 3
seconds.

455

6-4. Using the other interior features

Inte
rior fe

ature

Displays and directions

Display

Direction

“N”

North

“NE”

Northeast

“E”

East

“SE”

Southeast

“S”

South

“SW”

Southwest

“W”

West

“NW”

Northwest

456

6-4. Using the other interior features

The direction display deviates from the true direction determined by the earth’s
magnetic field. The amount of deviation varies depending on the geographic
position of the vehicle.

If you cross over one of the map boundaries shown in illustration, the compass will

deviate.

To obtain higher precision or perfect calibration, refer to “Deviation calibration”.

Calibrating the compass

457

6-4. Using the other interior features

Inte
rior fe

ature

■

Deviation calibration



Vehicles without garage door opener
Stop the vehicle.
Press and hold the “AUTO” button for 6 seconds. A number (1 to 15)
appears on the compass display.

Referring to the map above, press the “AUTO” button to select the number
of the zone you are in.

If the direction is displayed several seconds after adjustment, the calibration is

complete.



Vehicles with garage door opener
Stop the vehicle.
Press and hold the button for 3
seconds. A number (1 to 15)
appears on the compass display.

Referring to the map above, press the button to select the number of the
zone you are in.

If the direction is displayed several seconds after adjustment, the calibration is

complete.

Type A:

Type B:

458

6-4. Using the other interior features

■

Circling calibration



Vehicles without garage door opener
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold the “AUTO” button for 9 seconds.

“C” appears on the compass display.

Drive the vehicle at 5 mph
(8 km/h) or less in a circle until a
direction is displayed.

If there is not enough space to drive

in a circle, drive around the block

until a direction is displayed.



Vehicles with garage door opener
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold the button for 6
seconds.

“C” appears on the compass display.

Type A:

Type B:

Content .. 26 27 28 29 ..
