427

6-1. Using the air conditioning system and defogger

6

Inte
rior fe

ature

s

■

When the outside temperature is low
The dehumidification function may not operate even when “A/C” is pressed.

■

Operation of the air conditioning system in Eco drive mode

●

In the Eco drive mode, the air conditioning system is controlled as follows to prioritize

fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations
• Adjust the fan speed

• Turn off Eco drive mode

• Customize the air conditioning control of Eco drive mode. (

P. 603)

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

Air conditioning filter
P. 507

■

Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.

(Customizable features:

P. 598)

428

6-1. Using the air conditioning system and defogger

WARNING

■

To prevent the windshield from fogging up

●

Do not use

 during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)

NOTICE

■

To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the hybrid sys-

tem is off.

●

Do not place anything on the instrument

panel which may cover the air outlets. Other-

wise, air flow may be obstructed, preventing

the windshield defoggers from defogging.

429

6-1. Using the air conditioning system and defogger

6

Inte
rior fe

ature

s

Heated steering wheel



/seat heaters





: If equipped

Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats, respectively.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories comes in

contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged

• Persons with sensitive skin

• Persons who are fatigued

• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold

remedies, etc.)

●

Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do not stick

sharp objects (needles, nails, etc.) into the seat.

●

To prevent 12-volt battery discharge, do not use the functions when the hybrid system

is off.

430

6-1. Using the air conditioning system and defogger

Turns the heated steering wheel on/off

The indicator light comes on when the

heated steering wheel is operating.

●

The heated steering wheel can be used when the power switch is in ON mode.

●

The heated steering wheel will automatically turn off after about 30 minutes.

Pops the knob out
Turns the seat heater on

The indicator light comes on.

Adjusts the seat temperature

The further you turn the knob clockwise,

the warmer the seat becomes.

●

The seat heaters can be used when the power switch is in ON mode.

●

When not in use, turn the knob fully counterclockwise. The indicator light goes off.

Press the knob into the recessed position.

Heated steering wheel

Seat heaters

1

2

3

431

6-2. Using the interior lights

6

Inte
rior fe

ature

s

Interior lights list

Outer foot lights
Cup holder light (when the power switch is in ACCESSORY or ON mode)
Front personal/interior lights (

P. 432)

Rear interior light (

P. 432)

Footwell lights

When the instrument panel light control dial is turned fully down, the cup holder light

and the footwell lights will turn off. (

P. 87)

Turns the lights off
Turns the door position on
Turns the lights on

Personal/interior light main switch

1

2
3
4
5

1

2
3

432

6-2. Using the interior lights

Turns the lights on/off

Turns the light on
Turns the door position on

*

*

: When the personal/interior light main

switch is in the off position, the rear inte-
rior light will not turn on even if the door
is opened with the rear interior light
switch in door position.

●

Illuminated entry system: The lights automatically turn on/off according to power switch

mode, the presence of the electronic key, whether the doors are locked/unlocked, and

whether the doors are opened/closed.

●

If the interior lights remain on when the power switch is turned off, the lights will go off

automatically after 20 minutes.

●

Settings (e.g. the time elapsed before the lights turn off) can be changed.

(Customizable features:

P. 598)

Front personal/interior lights

Rear interior light

1

2

NOTICE

To prevent 12-volt battery discharge, do not leave the lights on longer than necessary

when the hybrid system is off.

433

6-3. Using the storage features

6

Inte
rior fe

ature

s

List of storage features

Auxiliary boxes (

P. 436)

Glove box (

P. 434)

Bottle holders/door pockets
(

P. 435)

Console box (

P. 434)

Cup holders (

P. 434)

1

2
3

4
5

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause

the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other

stored items.

• Lighters or spray cans may explode. If they come into contact with other stored

items, the lighter may catch fire or the spray can may release gas, causing a fire

hazard.

●

When driving or when the storage compartments are not in use, keep the lids closed.

In the event of sudden braking or sudden swerving, an accident may occur due to an

occupant being struck by an open lid or the items stored inside.

434

6-3. Using the storage features

Open (press the button)
Lock with the mechanical key
Unlock with the mechanical key

Lift the lid while pushing the knob to
release the lock.

■

Cup holders

Glove box

1

2
3

Console box

The tray slides forward/backward and can be

removed.

Cup holders/bottle holders/door pockets

435

6-3. Using the storage features

6

Inte
rior fe

ature

s

■

Bottle holders/door pockets

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

●

The partition in the cup holder can also be

used to store a small cup or can.

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.

Other items may be thrown out of the holders in the event of an accident or sudden

braking, causing injury. If possible, cover hot drinks to prevent burns.

NOTICE

Put the cap on before stowing a bottle. Do not place open bottles or glass and paper

cups containing liquid in the bottle holders.
The contents may spill and glasses may break.

436

6-3. Using the storage features

Auxiliary boxes



Type A



Type B

Press in the lid.

This box is useful for temporarily storing

sunglasses and similar small items.



Type C (if equipped)



Type D (if equipped)

437

6-3. Using the storage features

6

Inte
rior fe

ature

s

■

Auxiliary box (type D) (if equipped)
If an object has fallen down the back of the lid,

the fallen object can be retrieved by removing

the cover inside the auxiliary box.

Remove the mat.

Remove the cover using a flathead screw-

driver protected with tape etc.

WARNING

Do not store items heavier than 0.44 lb. (200 g).

Doing so may cause the auxiliary box to open and the items inside may fall out, result-

ing in an accident. (type A)

NOTICE

Do not leave items in the auxiliary box or on the dashboard for long periods of time

when the vehicle is in the sun.

The inside of the auxiliary box and the dashboard will become extremely hot compared

to other parts of the vehicle, and the items could be deformed or damaged. (type D)

1

2

438

6-3. Using the storage features

Luggage compartment features

Raise the hook to use.

The cargo hooks are provided for

securing loose items.

Secure the first-aid kit.

To loosen
To tighten

Cargo hooks

First-aid kit storage belt (if equipped)

1

2

439

6-3. Using the storage features

6

Inte
rior fe

ature

s

Auxiliary boxes



Center



Right side

Lift the center deck board.

Lift the right side deck board.



Left side (if equipped)

Lift the left side deck board.

440

6-3. Using the storage features

■

Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.

■

Removing the luggage cover
Retract the cover and release both
ends, then lift it out.

Luggage cover

441

6-3. Using the storage features

6

Inte
rior fe

ature

s

■

Stowing the luggage cover

Remove the side deck boards and
open the center auxiliary box.

Adjust the cover so that the infor-
mation label is facing up.

Fold the rear edge of the cover
over, replace the side deck
boards and close the center auxil-
iary box.

1

2

3

A part of the center auxiliary box can be used as

an Owner’s Manual holder.

442

6-3. Using the storage features

WARNING

●

To avoid injury, always return the cargo hooks to their stowed positions when not in

use.

●

If the deck boards are removed, return them to their original positions before driving.

In the event of sudden braking, an accident may occur due to an occupant being

struck by the deck boards or the items stored in the auxiliary box.

●

Do not allow children to climb on the luggage cover. Climbing on the luggage cover

could result in damage to the luggage cover, possibly causing death or serious injury

to the child.
