AC0BA–01

AC–84

–

AIR CONDITIONING

ROOM TEMPERATURE SENSOR

1641

1997 LEXUS ES300   (RM511U)

INSTALLATION

Installation is in the reverse order of removal (See page

AC–82

).

N21077

AC0BE–01

–

AIR CONDITIONING

AMBIENT TEMPERATURE SENSOR

AC–85

1642

1997 LEXUS ES300   (RM511U)

AMBIENT TEMPERATURE
SENSOR

REMOVAL

REMOVE AMBIENT TEMPERATURE SENSOR
(a)

Disconnect the connector.

(b)

Pull out the sensor from bumper reinforcement.

AC0BF–01

AC–86

–

AIR CONDITIONING

AMBIENT TEMPERATURE SENSOR

1643

1997 LEXUS ES300   (RM511U)

INSPECTION

INSPECT AMBIENT TEMPERATURE SENSOR CIRCUIT
(See page

DI–540

)

AC0BG–01

–

AIR CONDITIONING

AMBIENT TEMPERATURE SENSOR

AC–87

1644

1997 LEXUS ES300   (RM511U)

INSTALLATION

Installation is in the reverse order of removal (See page

AC–85

).
