AC0B6–01

AC–80

–

AIR CONDITIONING

SOLAR SENSOR

1637

1997 LEXUS ES300   (RM511U)

INSPECTION

INSPECT SOLAR SENSOR CIRCUIT
(See page

DI–549

)

AC0B7–01

–

AIR CONDITIONING

SOLAR SENSOR

AC–81

1638

1997 LEXUS ES300   (RM511U)

INSTALLATION

Installation is in the reverse order of removal (See page

AC–79

).

N21090

AC0B8–02

AC–82

–

AIR CONDITIONING

ROOM TEMPERATURE SENSOR

1639

1997 LEXUS ES300   (RM511U)

ROOM TEMPERATURE SENSOR

REMOVAL

REMOVE ROOM TEMP. SENSOR
(a)

Remove the No. 1 instrument lower panel set screws.

(b)

Disconnect the aspirator hose.

(c)

Disconnect the connector.

(d)

Release the 2 claws and pull out the sensor from No. 1
instrument lower panel.

AC0B9–01

–

AIR CONDITIONING

ROOM TEMPERATURE SENSOR

AC–83

1640

1997 LEXUS ES300   (RM511U)

INSPECTION

INSPECT ROOM TEMP. SENSOR CIRCUIT
(See page

DI–537

)
