Freelander 1. Manual - part 34





MAINTENANCE

MAINTENANCE

10-11

Door Locks, Hinges, Check Straps and
Bonnet Catch

Check

1. Check operation of each door, door lock,

bonnet catch and fuel filler flap.

Lubricate Front and Rear Doors

1. Open each door in turn and lubricate door

hinges and check strap using recommended
lubricant.


 +

 CAPACITIES, FLUIDS AND

LUBRICANTS, Lubrication.

2. Lubricate door lock, striker and private lock

using PTFE lubricant.   Remove excessive
lubricant, particularly from door  striker area, to
avoid customer complaint.

3. Check tightness of accessible door lock and

striker fixings.

4. Open and close door to check for smooth,

noise-free operation.  Ensure door closes
securely.

5. Check for smooth operation of private lock.

Lubricate Tail Door

1. Open tail door and lubricate hinges using

recommended lubricant.


 +

 CAPACITIES, FLUIDS AND

LUBRICANTS, Lubrication.

2. Grease tail door check slide.
3. Lubricate rear door lock and striker using PTFE

lubricant.  Remove excessive lubricant to avoid
customer complaint, particularly from door
striker area.

4. Check tightness of accessible tail door lock and

striker fixings.

Lubricate Bonnet

1. With bonnet open, lubricate hinges, striker, lock

and safety catch using a suitable lubricant.


 +

 CAPACITIES, FLUIDS AND

LUBRICANTS, Lubrication.

Sunroof Guide Rails, Slides and Seal

1. With sunroof open, lubricate accessible guide

rails, slides and seals.  Remove any excess
lubricant to avoid contaminating roof lining and
trim.

2. Ensure sunroof closes correctly.

Sunroof Drain Tubes and Channels

1. Remove any debris from sunroof tray.
2. Ensure that all accessible sunroof drain tubes

are clear using a low pressure air line.

MAINTENANCE

10-12

MAINTENANCE

Anti-freeze

Replace

1. Replace anti-freeze.



 +

 COOLING SYSTEM - Td4,

ADJUSTMENTS, Coolant - drain and refill.


 +

 COOLING SYSTEM - K SERIES KV6,

ADJUSTMENTS, Coolant - drain and refill.


 +

 COOLING SYSTEM - K SERIES 1.8,

ADJUSTMENTS, Coolant - drain & refill.

Cooling System and Intercooler

Check

1. Check for any obstructions in the radiator

matrix and remove debris as  necessary.

2. Check condition of all coolant hoses. Check for

any signs of leakage or chafing.

3. Check tightness of accessible hose clips.
4. Check for any obstructions in the intercooler

matrix and remove debris as necessary (diesel
only
).

5. Check intercooler hoses for security and

condition.

6. Check security of radiator and intercooler

mountings.

Coolant Level

1. Check coolant level and top up if necessary.

MAINTENANCE

MAINTENANCE

10-13

Spark Plugs – K1.8

Check & Renew

1. Check spark plugs condition and gap. Renew if

necessary.


 +

 ENGINE MANAGEMENT SYSTEM -

MEMS, REPAIRS, Spark plugs.

Spark Plugs – KV6

Check & Renew

1. Check spark plugs condition and gap. Renew if

necessary.


 +

 ENGINE MANAGEMENT SYSTEM -

SIEMENS, REPAIRS, Spark plugs.

MAINTENANCE

10-14

MAINTENANCE

Air Cleaner – Petrol Models

Replace

1. Replace air cleaner element.



 +

 FUEL DELIVERY SYSTEM -

PETROL, REPAIRS, Element - air cleaner -
KV6.

Clean

1. Clean the drain hole in filter casing.

Ancillary Drive Belt – Td4

Check

1. Check ancillary drive belts for tension, signs of

fraying, damage and for any oil contamination.

Replace

1. Replace ancillary drive belt.



 +

 CHARGING AND STARTING,

REPAIRS, Ancillary drive belt - Td4.
