Defender Electric Diagrams. Manual - part 121





C0036

CONNECTOR

DEFENDER 1999 MY

Switch - Direction indicator

Female
NATURAL

Behind steering column
cowl LH side

Cav

Col

CCT

1

U

ALL

2

GW

ALL

3

LGN

ALL

4

GR

ALL

5

UW

ALL

6

UR

ALL

7

NP

ALL

8

PB

ALL

CONNECTOR

C0041

DEFENDER 1999 MY

Switch - Lighting

Female
NATURAL

Behind steering column
cowl LH side

Cav

Col

CCT

1

NU

ALL

2

R

ALL

4

U

ALL

C0044

CONNECTOR

DEFENDER 1999 MY

Relay - Heated rear screen

Female
BLACK

Behind centre of fascia

P5660

C0068

C0730

C0151

C0731

C0044

C0282

Cav

Col

CCT

2

WB

ALL

4

WG

ALL

6

B

ALL

8

NP

ALL

CONNECTOR

C0049

DEFENDER 1999 MY

Passive coil

Female
BLACK

Behind steering column
cowl LH side

P5768

C0049

Cav

Col

CCT

1

OG

ALL

2

OP

ALL
