C0029

CONNECTOR

DEFENDER 1999 MY

Switch - Brake pedal

Female
NATURAL

Adjacent pedal box

P5564

C0075

C0029

C1264

C0667

C1265

Cav

Col

CCT

1

GP

ALL

CONNECTOR

C0030

DEFENDER 1999 MY

Motor - Wiper - Windscreen

Female
LIGHT GREY

Behind LH side of fascia

Cav

Col

CCT

1

B

ALL

2

NLG

ALL

3

ULG

ALL

4

WG

ALL

5

RLG

ALL

C0031

CONNECTOR

DEFENDER 1999 MY

Switch - Brake fluid level

Female
NATURAL

Adjacent pedal box

P5569

C0026

C0031

Cav

Col

CCT

1

B

3

1

BW

4

CONNECTOR

C0033

DEFENDER 1999 MY

Switch - Door - RH

Female
BLACK

RH ’A’ post

P5640

C0033

Cav

Col

CCT

1

SW

16

1

PU

17

1

PU

19
