GETTING TO KNOW YOUR VEHICLE

Rolling Code Garage Door Opener Final Steps

NOTE:

You have 30 seconds in which to initiate rolling

code final step 2, after completing rolling code

final step 1.
1. At the garage door opener motor (in the

garage), locate the “LEARN” or “TRAIN”

button. This can usually be found where the

hanging antenna wire is attached to the

garage door opener motor. Firmly push and

release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the

programmed HomeLink® button three times

(holding the button for two seconds each

time). If the garage door opener motor

operates, programming is complete.

3. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the final steps for the

rolling code procedure.

Non-Rolling Code Garage Door Opener Final Steps
1. Push and hold the programmed HomeLink®

button and observe the HomeLink® indicator

light. If the HomeLink® indicator light stays

on constantly, programming is complete.

2. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the steps from the

beginning.

ROGRAMMING

OME

INK

® T

ISCELLANEOUS

EVICE

Refer to “Programming HomeLink® To A Garage

Door Opener” for the procedure on how to program

HomeLink® to a miscellaneous device, as it

follows the same procedure. Be sure to determine

if the device has a rolling code, or non-rolling code

before beginning the programming process.

NOTE:

Canadian Radio Frequency (RF) laws require trans

mitter signals to time-out (or quit) after several

seconds of transmission, which may not be long

enough for HomeLink® to pick up the signal during

programming. Similar to this Canadian law, some

U.S. gate operators are designed to time-out in the

same manner. The procedure may need to be

performed multiple times to successfully pair the

device to your HomeLink® buttons.

EPROGRAMMING

A S

INGLE

OME

INK

® B

UTTON

To reprogram a single HomeLink® button that has

been previously trained, without erasing all the

channels, follow the procedure below. Be sure to

determine whether the new device you want to

program the HomeLink® button to has a rolling

code, or non-rolling code.
1. Place the ignition to the ON/RUN position,

without starting the engine.

2. Push and hold the desired HomeLink® button

until the HomeLink® Indicator light begins to

flash after 20 seconds. Do not release the

button.

3. Without releasing the button, proceed with

Step 2 in “Programming HomeLink® To A

Garage Door Opener” and follow all remaining

steps.

WARNING!



Your motorized door or gate will open and

close while you are programming the

universal transceiver. Do not program the

transceiver if people or pets are in the path of

the door or gate.



Do not run your vehicle in a closed garage or

confined area while programming the trans

ceiver. Exhaust gas from your vehicle contains

Carbon Monoxide (CO) which is odorless and

colorless. Carbon Monoxide is poisonous

when inhaled and can cause you and others to

be severely injured or killed.

GETTING TO KNOW YOUR VEHICLE

ANADIAN

ATE

PERATOR

ROGRAMMING

For programming transmitters in Canada/United

States that require the transmitter signals to

“time-out” after several seconds of transmission:
Canadian Radio Frequency (RF) laws require

transmitter signals to time-out (or quit) after

several seconds of transmission, which may not be

long enough for HomeLink® to pick up the signal

during programming. Similar to this Canadian law,

some U.S. gate operators are designed to time-out

in the same manner.
It may be helpful to unplug the device during the

cycling process to prevent possible overheating of

the garage door or gate motor.
1. Place the ignition in the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter ‘n Go™,

place the ignition in the RUN position. Make sure

while programming HomeLink® with the engine on

that your vehicle is outside of your garage, or that

the garage door remains open at all times.
2. Place the hand-held transmitter 1 to 3 inches

(3 to 8 cm) away from the HomeLink® button

you wish to program while keeping the

HomeLink® indicator light in view.

3. Continue to push and hold the HomeLink®

button while you push and release (cycle) your

hand-held transmitter every two seconds until

HomeLink® has successfully accepted the

frequency signal. The indicator light will flash

slowly and then rapidly when fully trained.

4. Watch for the HomeLink® indicator to change

flash rates. When it changes, it is

programmed. It may take up to 30 seconds or

longer in rare cases. The garage door may

open and close while you are programming.

5. Push and hold the programmed HomeLink®

button and observe the indicator light.

NOTE:



If the indicator light stays on constantly,

programming is complete and the garage

door/device should activate when the

HomeLink® button is pushed.



To program the two remaining HomeLink®

buttons, repeat each step for each remaining

button. DO NOT erase the channels.

If you unplugged the garage door opener/device

for programming, plug it back in at this time.

Reprogramming A Single HomeLink® Button

(Canadian/Gate Operator)
To reprogram a channel that has been previously

trained, follow these steps:
1. Place the ignition in the ON/RUN position.
2. Press and hold the desired HomeLink® button

until the indicator light begins to flash after 20

seconds. Do not release the button.

3. Without releasing the button, proceed with

“Canadian/Gate Operator Programming” Step

2 and follow all remaining steps.

ECURITY

It is advised to erase all channels before you sell or

turn in your vehicle.
To do this, push and hold the two outside buttons

for 20 seconds until the indicator flashes.

NOTE:

All channels will be erased. Individual channels

cannot be erased.
The HomeLink® Universal Transceiver is disabled

when the Vehicle Security system is active.

GETTING TO KNOW YOUR VEHICLE

ROUBLESHOOTING

IPS

If you are having trouble programming

HomeLink®, here are some of the most common

solutions:



Replace the battery in the garage door opener

hand-held transmitter.



Push the LEARN button on the garage door

opener to complete the training for a rolling

code.



Did you unplug the device for programming and

remember to plug it back in?

If you have any problems, or require assistance,

please call toll-free 1-800-355-3515 or, on the

Internet at

HomeLink.com

for information or

assistance.

EXTERIOR LIGHTS

EADLIGHT

WITCH

The headlight switch is located on the left side of

the instrument panel, next to the steering wheel.

The headlight switch controls the operation of the

headlights, parking lights, instrument panel lights,

and fog lights (if equipped).

Headlight Switch

WARNING!



Vehicle exhaust contains carbon monoxide, a

dangerous gas. Do not run your vehicle in the

garage while programming the transceiver.

Exhaust gas can cause serious injury or death.



Your motorized door or gate will open and

close while you are programming the universal

transceiver. Do not program the transceiver if

people, pets or other objects are in the path of

the door or gate. Only use this transceiver with

a garage door opener that has a “stop and

reverse” feature as required by Federal safety

standards. This includes most garage door

opener models manufactured after 1982. Do

not use a garage door opener without these

safety features. Call toll-free 1-800-355-3515

or, on the Internet at

HomeLink.com

for

safety information or assistance.

1 — Rotate Headlight Control
2 — Push Front Fog Light Control
3 — Ambient Light Dimmer Control
4 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

Headlight Switch (Vehicles Sold In Canada Only)

NOTE:

Vehicles sold in Canada are equipped with a head

light switch without the OFF position. In order to

turn the exterior lights off, the headlight switch

must be rotated to AUTO position.
To turn on the headlights, rotate the headlight

switch clockwise. When the headlight switch is on,

the parking lights, taillights, license plate light and

instrument panel lights are also turned on. To turn

off the headlights, rotate the headlight switch back

to the O (off) position.

For vehicles sold in Canada, rotate the headlight

switch clockwise from the parking lights and

instrument panel lights position to the AUTO

position for automatic headlights. Rotate to the

second detent to turn on headlights, parking lights,

and instrument panel lights operation.

NOTE:



Your vehicle is equipped with plastic headlight

and fog light (if equipped) lenses that are lighter

and less susceptible to stone breakage than

glass lights. Plastic is not as scratch resistant as

glass and therefore different lens cleaning

procedures must be followed.



To minimize the possibility of scratching the

lenses and reducing light output, avoid wiping

with a dry cloth. To remove road dirt, wash with

a mild soap solution followed by rinsing.

ULTIFUNCTION

EVER

The multifunction lever is located on the left side of

the steering column.

Multifunction Lever

AYTIME

UNNING

IGHTS

(DRL

)

The Daytime Running Lights (DRLs) come on

whenever the engine is running, and the low

beams are not on. The lights will remain on until

the ignition is placed in the OFF or ON/RUN

position, or the parking brake is engaged. The

headlight switch must be used for normal

nighttime driving.

NOTE:



For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate

when the front fog lights are turned on.



If allowed by law in the country in which the

vehicle was purchased, the Daytime Running

Lights can be turned on and off using the

Uconnect system

page 216.

1 — Rotate Headlight Control
2 — Push Front Fog Light Control
3 — Ambient Light Dimmer Control
4 — Instrument Panel Dimmer Control

CAUTION!

Do not use abrasive cleaning components,

solvents, steel wool or other abrasive materials

to clean the lenses.

GETTING TO KNOW YOUR VEHICLE



On some vehicles, the Daytime Running Lights

may deactivate, or reduce intensity, on one side

of the vehicle (when a turn signal is activated on

that side), or on both sides of the vehicle (when

the hazard warning lights are activated).

IGH

EAM

WITCH

Push the multifunction lever toward the instrument

panel to switch the headlights to high beams.

Pulling the multifunction lever back toward the

steering wheel will turn the low beams back on, or

shut the high beams off.

UTOMATIC

IGH

EAMS

—

QUIPPED

The Automatic High Beam Headlight system

provides increased forward lighting at night by

automating high beam control through the use of a

digital camera mounted on the inside rearview

mirror. This camera detects vehicle specific light

and automatically switches from high beams to low

beams until the approaching vehicle is out of view.

NOTE:



The Automatic High Beam Headlight system can

be turned on or off by selecting or deselecting

“Auto High Beam” within Uconnect Settings

page 216.



The headlight switch must also be turned to the

AUTO position after Automatic High Beams is

enabled within Uconnect Settings for the

feature to activate.



Automatic High Beams will only activate when

the vehicle speed is above 22 mph (35 km/h).



Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will

cause headlights to remain on longer (closer to

the vehicle). Also, dirt, film, and other obstruc

tions on the windshield or camera lens will

cause the system to function improperly.

If the windshield or Automatic High Beam

Headlight Control mirror is replaced, the mirror

must be re-aimed to ensure proper performance.

See a local authorized dealer.

LASH

-T

-P

ASS

You can signal another vehicle with your headlights

by lightly pulling the multifunction lever toward you.

This will cause the high beam headlights to turn on,

and remain on, until the lever is released.

UTOMATIC

EADLIGHTS

This system automatically turns the headlights on

or off according to ambient light levels. To turn the

system on, rotate the headlight switch

counterclockwise to the AUTO position. When the

system is on, the headlight time delay feature is

also on. This means the headlights will stay on for

up to 90 seconds after you place the ignition into

the OFF position. The headlight time delay can be

programmed 0/30/60/90 seconds

page 216.

To turn the automatic system off, move the

headlight switch out of the AUTO position.

NOTE:

The engine must be running before the headlights

will come on in the automatic mode.

ARKING

IGHTS

ANEL

IGHTS

To turn on the parking lights and instrument panel

lights, rotate the headlight switch clockwise. To

turn off the parking lights, rotate the headlight

switch back to the O (off) position.

NOTE:

For vehicles sold in Canada, rotate the headlight

switch to the AUTO position to turn off the parking

lights.

EADLIGHTS

UTOMATICALLY

ITH

IPERS

If your vehicle is equipped with Automatic

Headlights, it also has this

customer-programmable feature. When your

headlights are in the automatic mode and the

engine is running, they will automatically turn on

when the wiper system is on. This feature is

programmable through the Uconnect system

page 216.

GETTING TO KNOW YOUR VEHICLE

NOTE:

When your headlights come on during the daytime,

the vehicle will monitor outside brightness and

decide if the instrument panel needs to be dimmed

or not

page 68.

EADLIGHT

LLUMINATION

PPROACH

When enabled, the headlights, exterior door

handle pocket lights (if equipped), and interior

lights will illuminate when the unlock button on the

key fob is pushed as the operator is approaching

the vehicle. This feature can be turned on/off, and

the length of time the headlights stay on can be

programmed for up to 90 seconds within Uconnect

Settings

page 216.

Proximity Wake-Up — If Equipped
This feature is enabled/disabled within the

Uconnect system, and is activated when the

operator approaches the driver’s door,

passenger’s door, or liftgate with a valid key fob on

their person. Some exterior and interior lights will

illuminate in order to provide an increased sense

of welcome and security as the operator

approaches the vehicle in the dark. “Headlight

Illumination On Approach” must be selected and

set to a time value other than zero within Uconnect

Settings for Proximity Wake-Up to activate.

The doors may be locked or unlocked for this

feature to activate, as long as the ignition is in the

OFF position, or during a Remote Start event. It will

not activate if the doors are locked and the ignition

was placed in the ON/RUN position.

NOTE:

Proximity Wake-Up may not activate under the

following conditions:



After numerous consecutive activations, in

order to conserve the vehicle’s battery



After the vehicle’s engine has been off for

several days

Headlight Animation — If Equipped
When “Headlight Illumination On Approach” is

turned on, and set to a time value above zero, the

exterior lights illuminate in a theatrical manner

during approach to the vehicle. This feature is

activated in the following situations:



Proximity Wake-Up (if equipped) is activated



Remote Start is activated



The unlock button on the key fob is pushed

NOTE:

For Headlight Animation to activate with Remote

Start or with the push of the unlock button,

“Greeting Lights” must also be selected within the

Uconnect system.

EADLIGHT

ELAY

To aid in your exit, your vehicle is equipped with a

headlight delay that will leave the headlights on for

approximately 90 seconds. This delay is initiated

when the ignition is placed in the OFF position

while the headlight switch is on, and then the

headlight switch is cycled off. Headlight delay can

be canceled by either turning the headlight switch

on then off, or by placing the ignition in the ON

position.

NOTE:

The headlight delay time is programmable through

Uconnect Settings

page 216.

IGHTS

-O

EMINDER

If the headlights or parking lights are left on after

the ignition is placed in the OFF position, a chime

will sound when the driver’s door is opened.

GETTING TO KNOW YOUR VEHICLE

IGHTS

To activate the front fog lights, turn on the parking

lights or the low beam headlights, and push the fog

light button on the headlight switch.

Fog Light Button

Fog Light Button (Vehicles Sold In Canada Only)

The fog lights will operate only when the parking

lights are on, or when the vehicle headlights are on

low beam. An indicator light located in the

instrument cluster display will illuminate when the

fog lights are on. The fog lights will turn off when

the button is pushed a second time, when the

headlight switch is rotated to the off position, or

the high beam is selected.
Cornering Lights
The cornering lights are a feature to improve

visibility at night while turning the vehicle. When

activated, a light incorporated in the front fog light

will illuminate on the side of the vehicle the

steering wheel is rotated or the turn signal

indicator is on. It can be activated through the

Uconnect system

page 216.

URN

IGNALS

Move the multifunction lever up or down and the

arrows on each side of the instrument cluster will

flash to show proper operation of the front and rear

turn signal lights.

NOTE:

If either light remains on and does not flash, or

there is a very fast flash rate, check for a defective

outside light bulb.

ANE

HANGE

SSIST

— I

QUIPPED

Tap the multifunction lever up or down once,

without moving beyond the detent, and the turn

signal (right or left) will flash three times then

automatically turn off.

ATTERY

AVER

To protect the life of your vehicle’s battery, load

shedding is provided for both the interior and

exterior lights.
If the ignition is placed in the OFF position and any

door is left ajar for 10 minutes or if the overhead

console Dome ON switch is pressed, and the

interior lights are on for 10 minutes, the interior

lights will automatically turn off.

NOTE:

Battery saver mode is canceled if the ignition is in

the ON position.
If the headlights remain on while the ignition is

placed in the OFF position, the exterior lights will

automatically turn off after eight minutes. If the

headlights are turned on and left on for eight

minutes while the ignition is in the OFF position,

the exterior lights will automatically turn off.

GETTING TO KNOW YOUR VEHICLE

INTERIOR LIGHTS

OURTESY

IGHTS

Courtesy and dome lights are turned on when the

front doors are opened or the Dome ON button is

pushed on the overhead console. If your vehicle is

equipped with Remote Keyless Entry and the

unlock button is pushed on the key fob, the

courtesy and dome lights will turn on. When a door

is open and the interior lights are on, pressing the

Dome Defeat button on the overhead console will

cause all of the interior lights to turn off. This allows

the doors to stay open for extended periods of time

without discharging the vehicle’s battery.

Front Map/Reading Lights

The overhead console lights can also be operated

individually as reading lights by pushing the

corresponding buttons.

Courtesy Lights

Rear Courtesy/Reading Lights

Located above the rear passenger seating in both

second and third rows, along the trim, are

courtesy/reading lights. The courtesy lights turn on

when a door or the liftgate is opened. The lights will

also turn on when the unlock button on the key fob

is pushed.
The courtesy lights also function as reading lights.

Push the lens button to turn these lights on while

inside the vehicle. Push the lens button a second

time to turn each light off.

Dimmer Controls

The dimmer controls are inboard and adjacent to

the headlight switch located on the left side of the

instrument panel.
With the parking lights or headlights on, rotating

the right dimmer control upward will increase the

brightness of the instrument cluster lights.

Rotating the left dimmer control will adjust the

interior light levels of the ambient lighting on the

instrument panel and doors. The ambient lighting

may be color customizable

page 69.

Dimmer Controls

1 — Reading Light On/Off Buttons
2 — Dome Defeat Button
3 — Ambient Light
4 — Dome ON Button

1 — Ambient Light Dimmer Control
2 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

Dimmer Controls (Vehicles Sold In Canada Only)

NOTE:



Ambient lighting in the second and third row

seating areas may not be equipped in the

vehicle.



The dimming of the touchscreen is program

mable through the Uconnect system

page 216.

Multicolor Ambient Lighting — If Equipped

The color of certain ambient lighting inside of the

vehicle can be selected within the Apps menu on

the radio screen, or within Uconnect Settings

page 216. Brightness is adjusted using the

ambient light dimmer control on the headlight

switch.

Five colors can be selected for the following two

zones inside of the vehicle:



Zone 1:



Instrument panel decorative ambient lights



Door panel decorative ambient lights



Zone 2:



Front seat footwell areas below the instru

ment panel



Lighting below the second row seats



Map pocket lighting on all four door panels

These areas can be set to different colors, or if the

SYNC button is selected within the settings menu,

all colored lights will be set to the same color

automatically.

NOTE:

All other ambient lighting inside of the vehicle will

remain white, and the ambient light dimmer

control switch will adjust all ambient lighting at the

same time.

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer lever is located on

the right side of the steering column. The front

wipers are operated by rotating a switch, located

on the end of the lever.

Windshield Wiper Operation

INDSHIELD

IPER

PERATION

The wipers and washers are operated by a switch

within the wiper lever. Rotate the switch at the end

of the lever upward, to the first detent past the

intermittent settings for low-speed wiper

operation. Rotate the switch at the end of the lever

upward to the second detent past the intermittent

settings for high-speed wiper operation. To turn the

windshield wipers off, rotate the switch within the

lever all the way down to OFF.

1 — Ambient Light Dimmer Control
2 — Instrument Panel Dimmer Control

1 — Pull For Front Washer
2 — Rotate For Rear Wiper Operation
3 — Rotate For Front Wiper Operation
4 — Push Forward For Rear Washer
5 — Push Up For Mist

GETTING TO KNOW YOUR VEHICLE

Intermittent Wiper System

Use the intermittent wiper when weather

conditions make a single wiping cycle with a

variable pause between cycles desirable. Rotate

the switch at the end of the wiper lever to the first

detent position, and then turn the switch at the end

of the lever to select the desired delay interval.

There are four delay settings, which allow you to

regulate the wipe interval from a minimum of one

cycle every second to a maximum of approximately

36 seconds between cycles. The delay intervals

will double in duration when the vehicle speed is

10 mph (16 km/h) or less.

NOTE:

If the vehicle is moving less than 10 mph (16 km/h),

delay times will be doubled.

Windshield Washer Operation

To use the washer, pull the lever rearward toward

you and hold. If the lever is pulled while on the

intermittent setting, the wipers will turn on and

operate for several wipe cycles after the lever is

released, and then resume the intermittent

interval previously selected. If the lever is pulled

while the wipers are in the off position, the wipers

will operate several cycles, then turn off.

NOTE:



As a protective measure, the pump will stop if

the switch is held for more than 20 seconds.

Once the switch is released the pump will

resume normal operation.



If the front window washer feature is activated,

all of the front cameras (if equipped) on the

vehicle will be washed as well.

Mist

Use the Mist feature when weather conditions

make occasional usage of the wipers necessary.

Push the lever upward to the MIST position and

release for a single wiping cycle.

NOTE:

The Mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page 353.

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snowfall on the

windshield and automatically activates the wipers.

Rotate the end of the windshield wiper lever to one

of the four detent positions to activate this feature.
The sensitivity of the system is adjustable from the

windshield wiper lever. Wiper sensitivity position 1

is the least sensitive, and wiper sensitivity position

4 is the most sensitive.

NOTE:



The Rain Sensing feature will not operate when

the wiper switch is in the low or high position.



The Rain Sensing feature may not function prop

erly when ice or dried saltwater is present on the

windshield.



Use of Rain-X or products containing wax or sili

cone may reduce rain sensor performance.



The Rain Sensing feature can be turned on and

off through the Uconnect system

page 216.

CAUTION!

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the “park” position. If the windshield

wiper switch is turned off, and the blades cannot

return to the “park” position, damage to the

wiper motor may occur.

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

The Rain Sensing system has protective features

for the wiper blades and arms. It will not operate

under the following conditions:



Low Temperature Wipe Inhibit — The Rain

Sensing feature will not operate when the igni

tion is first placed in the ON position, when the

vehicle is stationary and the outside tempera

ture is below 32°F (0°C), unless the wiper

control on the windshield wiper lever is moved,

the vehicle speed becomes greater than 3 mph

(5 km/h) or the outside temperature rises

above freezing.



Neutral Wipe Inhibit — The Rain Sensing feature

will not operate when the ignition is ON, when

the transmission gear selector is in the

NEUTRAL position and the vehicle speed is less

than 3 mph (5 km/h), unless the wiper control

on the windshield wiper lever is moved, the

vehicle speed is greater than 3 mph (5 km/h) or

the gear selector is moved out of the NEUTRAL

position.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode. Once the

operator is in the vehicle and has placed the

ignition switch in the ON/RUN position, rain

sensing wiper operation can resume, if it has

been selected, and no other inhibit conditions

(mentioned previously) exist.

EAR

IPER

ASHER

The rear wiper/washer is operated by rotating a

switch, located at the middle of the lever.

Rotate the center portion of the lever

upward to the first detent for

intermittent operation and to the

second detent for continuous rear wiper

operation.
Rear Window Washer Operation

Pushing the windshield wiper lever

forward activates the rear window

washer. If the lever is pushed while on

the intermittent setting, the wipers will

turn on and operate for several wipe cycles after

the lever is released, and then resume the

intermittent interval previously selected. If the

lever is pushed while the wipers are in the off

position, the wipers will operate several wipe

cycles, then turn off.

NOTE:

When the rear window washer is activated, the rear

backup camera and digital rearview mirror (if

equipped) cameras are also washed.

INDSHIELD

IPER

-I

CER

—

QUIPPED

Your vehicle may be equipped with a Windshield

Wiper De-Icer feature that may be activated under

the following conditions:



Activation By Front Defrost — The Windshield

Wiper De-Icer shall be activated automatically in

the case of a cold weather manual start with full

front defrost, and when the ambient tempera

ture is below 33°F (0.6°C).



Activation By Rear Defrost — The Windshield

Wiper De-Icer shall be activated automatically

when the rear defrost is turned on and when the

ambient temperature is below 33°F (0.6°C).



Activation By Remote Start Operation — When

Remote Start is active and the outside ambient

temperature is less than 33°F (0.6°C), the

Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation.

If the Windshield Wiper De-Icer was active, the

timer and operation will continue.

GETTING TO KNOW YOUR VEHICLE

CLIMATE CONTROLS

The Climate Control system allows you to regulate

the temperature, air flow, and direction of air

circulating throughout the vehicle. The controls are

located on the touchscreen and on the instrument

panel below the radio.

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 5 With 10.1-inch Or 12-inch Display

Temperature Controls

Front Comfort And Convenience Display —

If Equipped

The Front Comfort And Convenience Display is a

retractable screen located below the main

Uconnect display that controls the front and rear

climate settings just as the “Controls” menu would

within the Uconnect system.
Other front seat functions can also be adjusted

from this screen, such as:



Power Massage Seat

page 47



Power Lumbar

page 44



Power Bolster

page 44

Front Comfort And Convenience Display Location

NOTE:

The Front Comfort And Convenience Display can

only be used if the vehicle is in the ON/RUN

position.
To stow this display and access the power outlet,

USB ports, and wireless charging pad, push the

screen open/close hard button below the display,

in front of the gear selector. Pushing the button

again will lower the screen for use.

Screen Open/Close Button

NOTE:

When the open/close button is pushed to stow the

Comfort And Convenience display screen, the

screen will turn off and save the menu it was on

prior to being stowed.

GETTING TO KNOW YOUR VEHICLE

Max A/C Button

Press and release the MAX A/C button

on the touchscreen to automatically

turn the air conditioning on to the

coldest temperature setting and the

highest blower speed. The MAX A/C indicator

illuminates when MAX A/C is ON. Performing this

function again will cause the MAX A/C operation to

switch into manual mode and the MAX A/C

indicator will turn off. Pressing other setting

buttons will also cause the MAX A/C to turn off.
MAX A/C sets the control for maximum cooling

performance.

NOTE:

The MAX A/C button is only available on the touch

screen.

A/C Button

Press and release the A/C button on the

touchscreen, or push and release the

button on the faceplate, to turn the air

conditioning on. The A/C indicator

illuminates when A/C is on.

Recirculation Button

Press and release the Recirculation

button on the touchscreen, or push and

release the button on the faceplate, to

change the system between

recirculation mode and outside air mode.

Recirculation can be used when outside conditions

such as smoke, odors, dust, or high humidity are

present. Recirculation can be used in all modes.

Recirculation may be unavailable if conditions

exist that could create fogging on the inside of the

windshield. The A/C can be deselected manually

without disturbing the mode control selection.

Continuous use of Recirculation mode may make

the inside air stuffy and window fogging may occur.

Extended use of this mode if not recommended.
In cold weather, use of Recirculation mode may

lead to excessive window fogging. The

Recirculation feature may be unavailable if

conditions exist that could create fogging on the

inside of the windshield.

AUTO Button

Press the AUTO button on the

touchscreen, or push and release the

button on the faceplate to automatically

control the front driver and passenger

area’s temperature by adjusting distribution and

amount of airflow. Performing this function will

cause the system to switch between manual mode

and automatic modes

page 78. AUTO mode is

highly recommended for efficiency.

MAX Defrost Button

Press the MAX Defrost button on the

touchscreen, or push and release the

button on the faceplate, to change the

current airflow setting to Defrost mode.

The indicator illuminates when this feature is on.

Performing this function will cause the automatic

climate controls to change to manual mode.
When MAX Defrost mode is selected:



The blower speed increases to full (all LEDs on)



Air conditioning compressor is turned on (LED on)



Both driver and passenger temperature controls

are set to HI



Defrost mode is selected (LED on)



Rear defroster is turned on (LED on)



Air recirculation is turned off (LED off)

If MAX Defrost mode is turned off, the Climate

Control system will return to the previous setting.

Rear Defrost Button

Press and release the button on the

touchscreen, or push and release the

button on the faceplate, to turn on the

rear window defroster and the heated

outside mirrors (if equipped). The Rear Defrost

indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 10 minutes.

GETTING TO KNOW YOUR VEHICLE

Driver And Passenger Temperature

Switches

These switches provide the driver and passenger

with independent temperature control.

Push the driver’s or passenger’s side

toggle switch on the faceplate upward,

or press and slide the temperature bar

towards the red arrow button on the

touchscreen for warmer temperature settings.

Push the driver’s or passenger’s side

toggle switch on the faceplate

downward, or press and slide the

temperature bar towards the blue arrow button on

the touchscreen for cooler temperature settings.

SYNC Button

Press the SYNC button on the

touchscreen to turn the SYNC feature

on/off. The SYNC indicator illuminates

when SYNC is on. SYNC is used to

synchronize the front passenger temperature and

rear passenger temperature, mode, and blower

settings with the driver temperature, mode, and

blower settings. Changing the front passenger

temperature or rear passenger temperature,

mode, and blower settings while in SYNC will

automatically exit this feature.

NOTE:

The SYNC setting is only available on the touch

screen.

Blower Control

Blower Control is used to regulate the

amount of air forced through the

Climate Control system. There are

several blower speeds available. The

speeds can be selected using the blower control

buttons on the touchscreen.
Use the small blower icon to reduce the blower

setting and the large blower icon to increase the

blower setting. Blower speed can also be selected

by pressing the numbered blower speed on the bar

area between the blower icons.

NOTE:

You can also adjust the blower speed by pushing

the blower control button on the faceplate. Push

down to decrease speed and up to increase speed.

Tri-Mode Climate

Three airflow distribution modes can be selected

on/off individually by pressing the icons on the

touchscreen for up to seven combinations of

airflow. The icons on the screen will illuminate

when selected, and turn off when deselected.
The three airflow modes are:

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

Windshield (Front Defrost outlets)

Face (instrument panel outlets)

Feet (floor outlets)

GETTING TO KNOW YOUR VEHICLE

Mode Control Button On The Instrument Panel

The airflow distribution mode can also

be selected by pushing the hard button

on the instrument panel, below the radio

screen. Pushing this button will cycle

through the seven mode combinations in order:

Face, Face/Feet, Feet, Windshield/Feet,

Windshield, Windshield/Face, and Windshield/

Face/Feet. The cycle will repeat if the button is

continually pushed.

NOTE:

The distribution modes on the climate control

screen will also illuminate when a selection is

made using the button on the instrument panel.

Climate Control OFF Button

Press and release the OFF button on the

touchscreen, or push the blower control

button on the faceplate and release

when the OFF setting has been reached,

to turn the Climate Control system on/off.

Controlling The Rear Climate Controls

From The Front Climate Screen

Four-Zone Rear Climate Controls From Front Climate

Screen

The Three-Zone and Four-Zone Climate Control

system allows for adjustment of the rear climate

controls from the front screen. This can be done

through either the main Uconnect display, or the

Front Comfort And Convenience Display (if equipped).

NOTE:

If equipped with a Four-Zone Climate Control

system, the temperature of left and right sides of

the rear passenger zones can be adjusted sepa

rately from the front or rear climate screens.

To change to the rear climate control screen:



Press the “Rear” icon on the touchscreen to

display the rear climate controls. The control

functions now operate the rear system.



Press the “Front” icon on the touchscreen to

return to the front climate controls.

LOCK REAR CLIMATE

Press and release the “Lock Rear

Climate” icon to lock out manual control

of the rear temperature and blower

settings made from the rear climate

control display. The “Lock Rear Climate” icon will

illuminate and the text will update to “Unlock Rear

Climate” when this feature is selected. When the

feature is deselected, the text will change back to

“Lock Rear Climate” and will no longer be

illuminated.

REAR AUTO BUTTON

Press and release “Auto” on the rear

climate control screen to control the

selected rear passenger temperature by

automatically adjusting airflow

distribution and amount. The “Auto” icon will

illuminate when this feature is selected, and will

turn off when deselected. Pressing any other

climate control function for the rear system will

cause the rear system to switch between manual

mode and automatic modes

page 78.

GETTING TO KNOW YOUR VEHICLE

SYNC BUTTON

Press the SYNC icon on the rear climate

control screen to turn the SYNC feature

on/off. SYNC is used to synchronize the

rear passenger temperature, mode, and

blower settings with the driver’s temperature,

mode, and blower settings. The SYNC indicator will

illuminate when SYNC is on. Changing the front

driver climate settings will adjust the passenger

(front and rear) settings automatically. If the front

passenger or rear climate settings are adjusted

while SYNC is on, SYNC will automatically exit.

REAR BLOWER CONTROL

Rear Blower Control is used to regulate

the amount of air forced through the

rear climate system. There are several

blower speeds available. The speeds

can be selected using the buttons on the

touchscreen. Use the small blower icon (or blower

icon with the downward arrow) to reduce the

blower setting, and the large blower icon (or blower

icon with the upward arrow) to increase the blower

setting. Blower can also be selected by pressing

the blower bar area between the icons.

REAR MODE CONTROL

Two airflow distribution modes for the rear seat

passengers can be selected on/off from the front

climate screen by individually by pressing the icons

on the touchscreen for up to three combinations of

airflow. The icons on the screen will illuminate

when selected, and turn off when deselected.
The two airflow modes are:

NOTE:

If Auto is selected, these icons will no longer be

available and the current mode selection will be

overwritten.

REAR CLIMATE CONTROL OFF

To turn the rear climate controls off,

press the OFF button on the

touchscreen, near the blower buttons.

Rear Climate Control Description And

Functions

Rear Climate Touchscreen (If Equipped)

Rear Climate Buttons (If Equipped)

Face (panel outlets)

Feet (floor outlets)

Jeep Wagoneer (2022 year). Manual in english - page 4
