GETTING TO KNOW YOUR VEHICLE



The ultrasonic intrusion sensor (motion

detector) actively monitors your vehicle every

time you arm the Vehicle Security system. If you

prefer, you can turn off the ultrasonic intrusion

sensor when arming the security system. To do

so, push the lock button on the key fob four

times within 15 seconds of arming the system

(while the Vehicle Security Light is flashing

rapidly).

The Vehicle Security system is designed to protect

your vehicle; however, you can create conditions

where the system will give you a false alarm. If one

of the previously described arming sequences has

occurred, the Vehicle Security system will arm

regardless of whether you are in the vehicle or not.

If you remain in the vehicle and open a door, the

alarm will sound. If this occurs, disarm the Vehicle

Security system.
If the Vehicle Security system is armed and the

battery becomes disconnected, the Vehicle

Security system will remain armed when the

battery is reconnected; the exterior lights will flash,

the horn will sound. If this occurs, disarm the

Vehicle Security system.

ECURITY

YSTEM

ANUAL

VERRIDE

The Vehicle Security system will not arm if you lock

the doors using the manual door lock, or an

emergency lock lever

page 29.

DOORS

ANUAL

OOR

OCKS

The front doors can be manually unlocked with a

single pull of the inside door handle. The driver’s

door can also be manually locked/unlocked by

inserting the emergency key into the lock cylinder

on the outside door handle.

Driver’s Door Cylinder Lock

The rear doors can be manually unlocked with a

double pull of the inside door handle.
All doors except the driver’s door can be manually

locked by inserting the emergency key into the

emergency lock lever and sliding the lever upward.

The emergency lock lever is located on the door

latch face of each door.

Emergency Lock Lever

NOTE:



The emergency lock lever is only accessible

when the door is open.



Manually locking the vehicle will not arm the

Vehicle Security system.

GETTING TO KNOW YOUR VEHICLE

OWER

OOR

OCKS

The power door lock buttons are located on each

front door panel. Push the lock button to lock all

doors and liftgate, or the unlock button to unlock

all doors and liftgate.
When the doors are locked, an indicator light in the

lock button will illuminate.

Power Door Lock Switches

The driver’s door will unlock automatically if the

keys are detected inside the vehicle when the door

lock button on the front door panel is used to lock

the door. This will occur for two attempts. Upon the

third attempt, the doors will lock even if the key is

inside.

NOTE:

If the key fob is located next to a mobile phone,

laptop, or other electronic device, the wireless

signal may get blocked, and the driver’s door may

not unlock automatically.
If the door lock switch is pushed while the ignition

is in ON/RUN and the driver's door is open, the

doors will not lock.
Rear Passenger Power Door Locks
Power door lock buttons are located on each rear

door trim panel. Push the lock button to lock all

doors and liftgate, and the unlock button to unlock

all doors and liftgate.

OWER

IDE

TEPS

— I

QUIPPED

The Power Side Steps will extend for easier entry

and exit of the vehicle.
When configured for “Auto” mode, the Power Side

Steps will deploy when any of the doors are

opened, and they will retract when the doors are

closed. This mode can be turned on or off in the

Uconnect Settings

page 216.

If the vehicle speed exceeds 5 mph (8 km/h), the

steps will retract.

WARNING!



For personal security and safety in the event

of a collision, lock the vehicle doors before you

drive as well as when you park and leave the

vehicle.



When exiting the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the Keyless Enter ‘n Go™ Ignition in

the ON/RUN position. A child could operate

power windows, other controls, or move the

vehicle.

GETTING TO KNOW YOUR VEHICLE

EYLESS

NTER

‘

™ — P

ASSIVE

NTRY

The Passive Entry system is an enhancement to

the vehicle’s Remote Keyless Entry (RKE) system

and a feature of Keyless Enter ‘n Go™. This feature

allows you to lock and unlock the vehicle’s door(s)

without having to push the key fob lock or unlock

buttons.
If equipped, the rear doors will also have Passive

Entry capabilities.

NOTE:



Passive Entry may be programmed on/off

through Uconnect Settings

page 216.



The key fob may not be detected by the vehicle

Passive Entry system if it is located next to a

mobile phone, laptop or other electronic device;

these devices may block the key fob's wireless

signal and prevent the Passive Entry handle

from locking/unlocking the vehicle.



Passive Entry Unlock initiates illuminated

approach (low beams, license plate lamp,

parking lights, door handle pocket lights [if

equipped]) for whichever time duration is set

between 0, 30, 60 or 90 seconds. Passive Entry

Unlock also initiates two flashes of the turn

signal lamps.



If wearing gloves, or if it has been raining/

snowing on the Passive Entry door handle, the

unlock and lock sensitivity can be affected,

resulting in a slower response time.



The doors may lock and unlock when water is

sprayed on the Passive Entry door handles, if

the key fob is located outside of the vehicle

within 5 ft (1.5 m) of the handle.



Passive Entry lock initiates one horn chirp and

one flash of turn signal lights. These settings

can be programmed on/off within Uconnect

Settings

page 216.



If the vehicle is unlocked by Passive Entry and

no door is opened within 60 seconds, the

vehicle will relock and will arm the Vehicle Secu

rity system (if equipped).

To Unlock From The Driver Or Passenger Side
With a valid Passive Entry key fob within 5 ft

(1.5 m) of the door handle, grab the handle to

unlock the vehicle. Grabbing the driver’s door

handle will unlock the driver door automatically.

Grabbing the front passenger door handle (or a

rear handle when equipped with four-door Passive

Entry) will unlock all doors and the liftgate

automatically.

Grab The Door Handle To Unlock

NOTE:



Either the driver’s door only or all doors will

unlock when you grab hold of the front driver’s

door handle, depending on the selected setting

in the Uconnect system

page 216.



All doors will unlock when the front passenger

(or a rear door when equipped with four door

Passive Entry) door handle is grabbed regard

less of the driver’s door unlock preference

setting.

Frequency Operated Button Integrated Key

(FOBIK-Safe)
To minimize the possibility of unintentionally

locking a Passive Entry key fob inside your vehicle,

the Passive Entry system is equipped with an

automatic door unlock feature which will function if

the ignition switch is in the OFF position.

GETTING TO KNOW YOUR VEHICLE

There are five situations that trigger a FOBIK-Safe

search in any Passive Entry vehicle:



A lock request is made by a valid Passive Entry

key fob while a door is open.



A lock request is made by the Passive Entry door

handle while a door is open.



A lock request is made by the door panel switch

while the door is open.



When the Vehicle Security system is in pre-arm

or armed status and the liftgate transitions from

opened to closed.



When the liftgate transitions from open to

closed and Remote Start is active.

When any of these situations occur, after all open

doors are shut, the FOBIK-Safe search will be

executed. If it detects a Passive Entry key fob

inside the vehicle, the vehicle will unlock and alert

the customer.

NOTE:

The vehicle will only unlock the doors when a valid

Passive Entry key fob is detected inside the

vehicle. The vehicle will not unlock the doors when

any of the following conditions are true:



The doors are manually locked using the emer

gency lock lever.



Three attempts are made to lock the doors

using the door panel switch and then the doors

are closed.



There is a valid Passive Entry key fob outside the

vehicle within 5 ft (1.5 m) of a Passive Entry

door handle.

To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s Passive Entry key fobs

within 5 ft (1.5 m) of a Passive Entry door handle,

touch the lock icon on the door handle to lock all

four doors and liftgate.

Touch The Door Handle Lock Icon To Lock

NOTE:

Do NOT grab the door handle when touching the

lock icon. This could unlock the door(s).

Do NOT Grab The Door Handle When Locking

NOTE:



After touching the door handle lock icon, you

must wait two seconds before you can lock or

unlock the doors using any Passive Entry door

handle. This is done to allow you to check if the

vehicle is locked by pulling the door handle,

without the vehicle unlocking.



If Passive Entry is disabled using the Uconnect

Settings, the key protection described in

"Frequency Operated Button Integrated Key

(FOBIK-Safe)" remains active/functional.



The Passive Entry system will not operate if the

key fob battery is depleted.

GETTING TO KNOW YOUR VEHICLE

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built

into the electronic liftgate release button. With a

valid Passive Entry key fob within 5 ft (1.5 m) of the

liftgate, push the electronic liftgate release handle

for a power open on vehicles equipped with Power

Liftgate. Push the electronic liftgate button and lift

for Manual Liftgate vehicles.

Electronic Liftgate Handle

To Lock The Liftgate
With a valid Passive Entry key fob within 5 ft

(1.5 m) of the liftgate, push the Passive Entry lock

button located on the outside liftgate door handle.

NOTE:

The liftgate Passive Entry lock button will lock all

doors and the liftgate

page 413.

UTOMATIC

NLOCK

OORS

XIT

The doors will unlock automatically on vehicles

with power door locks after the following sequence

of actions:
1. The Automatic Unlock Doors On Exit feature is

enabled within Uconnect Settings

page 216.

2. All doors are closed.
3. The gear selector was not in PARK, then is

placed in PARK.

4. Any door is opened.

UTOMATIC

OOR

OCKS

—

QUIPPED

The auto door lock feature default condition is

enabled. When enabled, the door locks will lock

automatically when the vehicle's speed exceeds

15 mph (24 km/h). The auto door lock feature is

enabled or disabled by an authorized dealer per

written request of the customer. Please see an

authorized dealer for service.

HILD

-P

ROTECTION

OOR

OCK

YSTEM

— R

EAR

OORS

To provide a safer environment for small children

riding in the rear seats, the rear doors are

equipped with a Child-Protection Door Lock

system.
To use the system, open each rear door, use a flat

blade screwdriver (or emergency key) and rotate

the dial to the lock or unlock position. When the

system on a door is engaged, that door can only be

opened by using the outside door handle even if

the inside door lock is in the unlocked position.

Child-Protection Door Lock Function

1 — Lock Button Location
2 — Electronic Liftgate Release Handle

GETTING TO KNOW YOUR VEHICLE

NOTE:



When the Child-Protection Door Lock system is

engaged, the door can be opened only by using

the outside door handle even though the inside

door lock is in the unlocked position.



After disengaging the Child-Protection Door

Lock system, always test the door from the

inside to make certain it is in the unlocked posi

tion.



After engaging the Child-Protection Door Lock

system, always test the door from the inside to

make certain it is in the locked position.

NOTE:

Always use this device when carrying children.

After engaging the child lock on both rear doors,

check for effective engagement by trying to open a

door with the internal handle. Once the

Child-Protection Door Lock system is engaged, it is

impossible to open the doors from inside the

vehicle. Before getting out of the vehicle, be sure to

check that there is no one left inside.

STEERING WHEEL

OWER

ILT

ELESCOPING

TEERING

OLUMN

This feature allows you to tilt the steering column

upward or downward. It also allows you to lengthen

or shorten the steering column. The power tilt/

telescoping steering column control is located

below the multifunction lever on the steering

column.

Power Tilt/Telescoping Steering Control Location

Use the four-way control to adjust the steering

column.

NOTE:

For vehicles equipped with Driver Memory

Settings, you can use your key fob or the memory

switch on the driver's door trim panel to return the

tilt/telescopic steering column to saved positions

page 35.

EATED

TEERING

HEEL

The steering wheel contains a heating

element that helps warm your hands in

cold weather. The heated steering wheel

has three temperature settings. Once

the heated steering wheel has been turned on, it

will stay on until the operator turns it off. The

heated steering wheel may not turn on when it is

already warm.

WARNING!

Avoid trapping anyone in a vehicle in a collision.

Remember that the rear doors can only be

opened from the outside with the

Child-Protection locks engaged (locked).

WARNING!

Do not adjust the steering column while driving.

Adjusting the steering column while driving or

driving with the steering column unlocked, could

cause the driver to lose control of the vehicle.

Failure to follow this warning may result in

serious injury or death.

GETTING TO KNOW YOUR VEHICLE

The heated steering wheel control button is

located on the side of the radio screen or within the

Uconnect system. You can gain access to the

control button through the controls screen of the

touchscreen. If your vehicle is not equipped with

the button on the side of the radio, you can also

access the control button through the climate

screen.



Push the heated steering wheel button once to

turn the HI setting on.



Push the heated steering wheel button a second

time to turn the MED setting on.



Push the heated steering wheel button a third

time to turn the LO setting on.



Push the heated steering wheel button a fourth

time to turn the heating elements off.

NOTE:

The engine must be running for the heated

steering wheel to operate.
For information on use with the Remote Start

system, see

page 26.

DRIVER AND PASSENGER MEMORY

SETTINGS — IF EQUIPPED

This feature allows the driver, and if equipped, also

the front passenger to save up to two different

memory profiles for easy recall through a memory

switch. Each memory profile saves desired position

settings for the following features:

Driver’s Side



Seat position



Easy entry/exit seat (if equipped)



Side mirrors



Power tilt and telescopic steering column

(if equipped)



Power adjustable pedals (if equipped)



A set of desired radio station presets

Passenger’s Side (If Equipped)



Seat position

The memory settings switches are located on the

front door panels, next to the door handle, and

consists of two or three buttons, depending on trim

level:



The (1) and (2) buttons which are used to recall

either of two saved memory profiles



The set (S) button (Wagoneer models only),

which is used to activate the memory save

function

WARNING!



Persons who are unable to feel pain to the

skin because of advanced age, chronic illness,

diabetes, spinal cord injury, medication,

alcohol use, exhaustion, or other physical

conditions must exercise care when using the

steering wheel heater. It may cause burns

even at low temperatures, especially if used

for long periods.



Do not place anything on the steering wheel

that insulates against heat, such as a blanket

or steering wheel covers of any type and mate

rial. This may cause the steering wheel heater

to overheat.

GETTING TO KNOW YOUR VEHICLE

Wagoneer Memory Settings Buttons

Grand Wagoneer Memory Settings Buttons

NOTE:



Your vehicle is equipped with two key fobs, each

can be linked to either driver’s side memory

position 1 or 2.



Front passenger memory settings cannot be

linked to a key fob.

ROGRAMMING

EMORY

EATURE

To create a new memory profile, perform the

following:

NOTE:

Saving a new memory profile will erase the

selected profile from memory.
Wagoneer
1. Place the vehicle’s ignition in the ON/RUN

position (do not start the engine).

2. Adjust all memory profile settings to desired

preferences (i.e., seat, side mirror, power tilt

and telescopic steering column [if equipped],

and radio station presets).

3. Push and release the set (S) button on the

memory switch.

4. Within five seconds, push and release either of

the memory buttons (1) or (2). The instrument

cluster display will display which memory

position has been set.

Grand Wagoneer
1. Place the vehicle’s ignition in the ON/RUN

position (do not start the engine).

2. Adjust all memory profile settings to desired

preferences (i.e., seat, side mirror, power tilt

and telescopic steering column [if equipped],

and radio station presets).

3. Press memory button (1) or (2) for two or more

seconds. The instrument cluster display will

display which memory position has been set.

NOTE:

Memory profiles can be set without the vehicle in

PARK, but the vehicle must be below 5 mph

(8 km/h) to recall a memory profile.

INKING

NLINKING

EMORY

Your key fobs can be programmed to recall one of

two saved driver’s side memory profiles.

NOTE:

Before programming your key fobs you must select

the “Personal Settings Linked To Key Fob” feature

through the Uconnect Settings

page 216.

To program your key fobs, perform the following:
Wagoneer
1. Place the vehicle’s ignition in the OFF

position.

2. Select a desired driver’s side memory profile,

1 or 2.

3. Once the profile has been recalled, push and

release the set (S) button on the memory

switch.

GETTING TO KNOW YOUR VEHICLE

(Continued)

4. Within five seconds, push and release button

(1) or (2) accordingly. “Memory Profile Set”

(1 or 2) will display in the instrument cluster.

5. Push and release the lock button on the key

fob within 10 seconds.

NOTE:

Your key fobs can be unlinked from your driver’s

side memory settings by pushing the set (S) button,

and within 10 seconds, pushing the unlock button

on the key fob.
Grand Wagoneer
1. Place the vehicle’s ignition in the OFF

position.

2. Recall the desired memory profile (1 or 2).
3. Press the memory button (1) or (2) (according

to the previous selection) for two seconds or

more, and release.

4. Push and hold the lock button on the key fob

within 10 seconds.

NOTE:

Your key fobs can be unlinked from your driver’s

side memory settings by pushing the memory

button (1) or (2) for two seconds or more and

releasing, and then within 10 seconds, pushing

and holding the unlock button on the key fob.

EMORY

OSITION

ECALL

NOTE:

Memory Recall is available when not in PARK, if the

vehicle speed is below 5 mph (8 km/h).



To recall a memory settings using the memory

switches, push memory button (1) or (2) on the

memory switch.



To recall the driver’s side memory settings using

the key fob, push the unlock button on the key

fob linked to memory position 1 or 2.

A recall can be canceled by pushing any of the

memory buttons during a recall, or by pushing any

of the seat adjustment switches. When a recall is

canceled, the seat and power tilt/telescopic

steering column will stop moving. A delay of one

second will occur before another recall can be

selected.

SEATS

Seats are a part of the Occupant Restraint system

of the vehicle.

ANUAL

DJUSTMENT

EAR

EATS

)

NOTE:

You may experience deformation in the seat

cushion from the seat belt buckles if the seats are

left folded for an extended period of time. This is

normal and by simply unfolding the seats to the

open position, over time the seat cushion will

return to its normal shape.

WARNING!



It is dangerous to ride in a cargo area, inside

or outside of a vehicle. In a collision, people

riding in these areas are more likely to be seri

ously injured or killed.



Do not allow people to ride in any area of your

vehicle that is not equipped with seats and

seat belts. In a collision, people riding in

these areas are more likely to be seriously

injured or killed.



Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

WARNING!

Do not pile luggage or cargo higher than the top

of the seatback. This could impair visibility or

become a dangerous projectile in a sudden stop

or collision.

WARNING!

GETTING TO KNOW YOUR VEHICLE

Second Row Bench Seat — If Equipped

SECOND ROW BENCH SEAT FORWARD/REAR

WARD ADJUSTMENT

Lift up on the adjusting bar located at the front of

the seat near the floor and release it when the seat

is at the desired position. Then, using body

pressure, move forward and rearward on the seat

to be sure that the seat adjusters have latched.

Rear Seat Adjustment Bar

SECOND ROW BENCH SEAT RECLINE

ADJUSTMENT

To recline, lean forward slightly and lift the lever

located on the outboard side of the seat. Then,

push the seat rearward to the desired position and

release the lever. To return the seatback to its

normal position, lean forward and lift the lever. To

ensure the seatback is latched, use body pressure

to lean forward and rearward.

Rear Seat Recline Lever

To recline the center seat, pull the recline strap

located on the seatback, and move forward or

backward as desired. Release the strap when the

desired seat position has been reached.

Center Seat Recline Strap

SECOND ROW BENCH FOLD FLAT SEAT

To provide additional storage area, each rear seat

can be folded flat. This allows for extended cargo

space and still maintains some rear seating room.

NOTE:

Prior to folding the rear seat, it may be necessary

to position the front seat to its mid-track position

especially if the seat is equipped with Rear Seat

Entertainment. Also, be sure that the front seats

are fully upright and positioned forward. This will

allow the rear seat to fold down easily.
To lower the seatback, pull upward on the recline

lever located on the outboard side of the seat, and

let the seatback fold forward automatically.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

GETTING TO KNOW YOUR VEHICLE

Second Row Bench Seat Folded Flat

To lower the center seatback, pull the recline strap,

located on the left side of the seatback, and let the

seatback fold forward automatically.

Center Seat Recline Strap

To raise the seatback, fold the seatback up into its

original position and lock it into place.

SECOND ROW BENCH SEAT EASY ACCESS FOR

THIRD ROW

The second row bench seats can slide forward to

allow passengers to easily access the third row

seats.
Press the easy entry button located on the

outboard side of the seatback. Once pressed, the

seat will pitch forward, allowing the seat to slide

forward.

Bench Seat Easy Entry Button

To return the seat to a sitting position, push the

seatback rearward until the seat locks.
Emergency Straps
In the event that the vehicle loses power, the Easy

Entry buttons will not function. There are

emergency straps located on the back of the

second row outboard seats to allow the third row

occupants to manually fold the seats flat to exit the

vehicle.

Emergency Straps

Pull the emergency straps to fold the second row

seat flat.

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

GETTING TO KNOW YOUR VEHICLE

Second Row Captain’s Chairs —

If Equipped

SECOND ROW CAPTAIN’S CHAIRS FORWARD/

REARWARD ADJUSTMENT

Lift up on the adjusting bar located at the front of

the seat near the floor and release it when the seat

is at the desired position. Then, using body

pressure, move forward and rearward on the seat

to be sure that the seat adjusters have latched.

Rear Seat Adjustment Bar

SECOND ROW CAPTAIN’S CHAIRS RECLINE

ADJUSTMENT

To recline, lean forward slightly and lift the lever

located on the outboard side of the seat. Then,

push the seat rearward to the desired position and

release the lever. To return the seatback to its

normal position, lean forward and lift the lever. To

ensure the seatback is latched, use body pressure

to lean forward and rearward.

Rear Seat Recline Lever

SECOND ROW CAPTAIN’S CHAIRS FOLD FLAT

SEATS

The second row seatbacks can be folded flat to

carry cargo.

NOTE:

Prior to folding the rear seat, it may be necessary

to position the front seat to its mid-track position

especially if the seat is equipped with Rear Seat

Entertainment. Also, be sure that the front seats

are fully upright and positioned forward. This will

allow the rear seat to fold down easily.
Pull upward on the recline lever located on the

outboard side of each second row seat, and let the

seatback fold forward automatically.

Second Row Captain’s Chair Folded Flat

To Raise The Rear Seats
Fold the seatbacks upward to their original

position, and lock them into place.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

GETTING TO KNOW YOUR VEHICLE

SECOND ROW CAPTAIN’S CHAIR EASY ACCESS

FOR THIRD ROW

The second row captain’s chairs can slide forward

to allow passengers to easily access the third row

seats.
Press the easy entry button located on the

outboard side of the seatback. Once pressed, the

entire seat will pitch forward, allowing the seat to

slide forward.

Captain’s Chair Easy Entry Button

To return the seat to a sitting position, push the

seatback rearward until the seat locks.
Emergency Straps
In the event that the vehicle loses power, the Easy

Entry buttons will not function. There are

emergency straps located on the back of the

second row outboard seats to allow the third row

occupants to manually fold the seats flat to exit the

vehicle.

Emergency Straps

Pull the emergency straps to fold the second row

seat flat.

Folding Third Row

Both third row seats can be folded flat to increase

the cargo area. To lower either seat, pull on the

release straps located on both sides of the rear

cargo area, near the bottom of the seat.

NOTE:

The second row seats must be in their full upright

position or folded flat when folding the third row

seats.

Release Straps

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

GETTING TO KNOW YOUR VEHICLE

Third Row Folded

To raise the seat, pull the seatback up and push

back to lock it into place. You can also use the

return straps in the rear cargo area, on the back of

the seat.

Return Straps

To recline the seat, pull the recline straps, located

on the sides of the seat.

Recline Straps

OWER

DJUSTMENT

RONT

EATS

) —

QUIPPED

Wagoneer models will be equipped with 8-way

power driver and front passenger seats. The power

seat switches are located on the outboard side of

the seat. There are two switches that control the

movement of the seat cushion and the seatback.

Wagoneer Power Seat Switches

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

1 — Seat Switch
2 — Seatback Switch

GETTING TO KNOW YOUR VEHICLE

Grand Wagoneer models will be equipped with

20-way power driver and front passenger seats.

The power seat switches are located on the driver

and front passenger door panels near the door

handles. These switches control the movement of

the seat cushion and the seatback.

Grand Wagoneer Power Seat Switches

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and

rearward. Push the seat switch forward or

rearward. The seat will move in the direction of the

switch. Release the switch when the desired

position has been reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or

down. Pull upward or push downward on the rear of

seat switch, the seat will move in the direction of

the switch. Release the switch when the desired

position has been reached.

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted in

two directions. Pull upward or push downward on

the front of the seat switch, the front of the seat

cushion will move in the direction of the switch.

Release the switch when the desired position has

been reached.

Reclining The Seatback

The angle of the seatback can be adjusted forward

or rearward. Push the seatback recline switch

forward or rearward, the seat will move in the

direction of the switch. Release the switch when

the desired position is reached.

For Grand Wagoneer models, the angle of the

upper seatback can also be adjusted forward or

rearward. Push the upper seatback switch forward

or rearward, and the seat will move in the direction

of the switch. Release the switch when the desired

position is reached.

1 — Front Headrest Adjustment Switch
2 — Power Massage Switch
3 — Decrease Back/Thigh Bolster & Lumbar

Switch
4 — Increase Back/Thigh Bolster & Lumbar

Switch
5 — Upper Seatback Switch
6 — Seatback Recline Switch
7 — Seat Switch (Multiple Functions)
8 — Cushion Extender Switch

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious

injury or death.

CAUTION!

Do not place any article under a power seat or

impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

GETTING TO KNOW YOUR VEHICLE

Power Seat Bolster Adjustment —

If Equipped

In Grand Wagoneer models, the front driver and

passenger seatback and seat cushion bolsters can

be extended outward, or retracted inward by using

the (+) and (–) adjustment switches on the door

panel. The bolsters can also be adjusted directly in

the Front Comfort And Convenience Display or the

Uconnect display.
Push the (+) switch to extend the bolsters, or push

the (–) switch to retract the bolsters.

Seat Bolster Adjustment Switches

When either the (+) or the (–) switch is pushed, the

Front Comfort And Convenience Display

page 72 will change to the Seat menu. The last

selected seat item of lumbar in/out, lumbar up/

down, back bolster, or thigh bolster will be

retained. Select the desired adjustment type, and

then press the (+) or (–) switch to adjust.

NOTE:

If the Front Comfort And Convenience Display is in

the stowed position, the Seat menu will appear in

the main Uconnect display.

Cushion Extender — If Equipped

In Grand Wagoneer models, the cushion can be

extended forward a couple inches (centimeters) to

increase thigh support. Push the cushion extender

switch forward or rearward to extend or retract the

cushion. Release the switch when the desired

position has been reached.

Power Lumbar — If Equipped

The front driver and passenger seats may be

equipped with power lumbar adjustment.
The Wagoneer power lumbar switch is located on

the outboard side of the power seat. Push the

switch forward to increase the lumbar support.

Push the switch rearward to decrease the lumbar

support. Pushing upward or downward on the

switch will raise and lower the position of the

support.

Wagoneer Power Lumbar Adjustment Switch

The Grand Wagoneer power lumbar adjustment

switches are located on the door trim. The (+) and

(–) switches can be used to adjust lumbar support

in/out and up/down. The power lumbar can also

be adjusted directly in the Front Comfort And

Convenience Display or the Uconnect display.

Grand Wagoneer Power Lumbar Adjustment Switches

Jeep Wagoneer (2022 year). Manual in english - page 2
