Door Open Warning Light

Drowsiness Detected Warning Light

Electric Power Steering (EPS) Fault Warning Light

Electronic Throttle Control (ETC) Warning Light

Engine Coolant Temperature Warning Light

Hood Open Warning Light

Liftgate Open Warning Light

Night Vision Animal Detected Warning Light

Red Warning Lights

Night Vision Pedestrian Detected Warning Light

Oil Pressure Warning Light

Oil Temperature Warning Light

Rear Seat Belt Reminder Indicator Light

Seat Belt Reminder Warning Light

Transmission Temperature Warning Light

Vehicle Security Warning Light

Red Warning Lights

Yellow Warning Lights

Anti-Lock Brake System (ABS) Warning Light

Electronic Park Brake Warning Light

Electronic Stability Control (ESC) Active Warning Light

Electronic Stability Control (ESC) OFF Warning Light

Service Active Lane Management Warning Light

Active Lane Management Warning Light

Low Fuel Warning Light

Low Washer Fluid Warning Light

Night Vision Animal Detected Warning Light

Night Vision Pedestrian Detected Warning Light

Engine Check/Malfunction Indicator Warning Light (MIL)

Oil Level Sensor Fault Warning Light

Service 4WD Warning Light

Service Adaptive Cruise Control (ACC) Warning Light

Service Forward Collision Warning (FCW) Light

Service Stop/Start System Warning Light

Yellow Warning Lights

Tire Pressure Monitoring System (TPMS) Warning Light

Towing Hook Breakdown Warning Light

Drowsiness Detected System Fault Warning Light

Yellow Indicator Lights

4WD Low Indicator Light

Air Suspension Active Indicator Light

Air Suspension Aerodynamic Height Indicator Light

Air Suspension Entry/Exit Indicator Light

Yellow Warning Lights

Air Suspension Off-Road 1 Indicator Light

Air Suspension Off-Road 2 Indicator Light

Auto HOLD! Fault Indicator Light

Forward Collision Warning (FCW) Off Indicator Light

NEUTRAL Indicator Light

TOW/HAUL Indicator Light

Green Indicator Lights

Adaptive Cruise Control (ACC) Set With Target Light

Yellow Indicator Lights

Adaptive Cruise Control (ACC) Set With No Target Detected

Indicator Light

Auto HOLD Indicator Light

Cruise Control SET Indicator Light

Front Fog Indicator Light

Active Lane Management Indicator Light

Night Vision Active Indicator Light

Rear Seat Belt Fastened Indicator Light

Parking/Headlights On Indicator Light

Green Indicator Lights

Sport Mode Indicator Light

Stop/Start Active Indicator Light

Turn Signal Indicator Lights

White Indicator Lights

Adaptive Cruise Control (ACC) Ready Light

Cruise Control Ready Indicator Light

Hill Descent Control (HDC) Indicator Light

Active Lane Management Indicator Light

Green Indicator Lights

Rear Seat Belt Reminder Indicator Light

Rear Seat Unoccupied Indicator Light

Selec-Speed Control Indicator Light

Blue Indicator Lights

High Beam Indicator Light

Gray Indicator Lights

Night Vision Suppressed Indicator Light

White Indicator Lights

GETTING TO KNOW YOUR VEHICLE

KEYS

Your vehicle is equipped with a key fob which

supports Passive Entry, Remote Keyless Entry

(RKE), Keyless Enter ‘n Go™, Remote Air

Suspension Lowering, and Remote Start. The key

fob allows you to lock or unlock all doors and

liftgate, as well as activate the Panic Alarm from

distances up to approximately 66 ft (20 m). The

key fob does not need to be pointed at the vehicle

to activate the system. The key fob also contains

an emergency key, which is stored in the rear of the

key fob.

NOTE:

In vehicles equipped with Remote Start, the key

fob will operate at distances up to 328 ft (100 m).

NOTE:



The key fob’s wireless signal may be blocked if

the key fob is located next to a mobile phone,

laptop, or other electronic device. This may

result in poor performance.



If your vehicle is equipped with a Wireless

Charging Pad, the key fob may not be detected

if it is placed within 6 inches (15 cm) of the pad

page 88.



With the ignition in the ON position and the

vehicle moving at 2 mph (4 km/h), all RKE

commands are disabled.

Key Fob

1 — LED Indicator
2 — Unlock
3 — Remote Start
4 — Air Suspension Remote Lowering

(If Equipped)
5 — Lock
6 — Power Liftgate
7 — Panic
8 — Emergency Key

GETTING TO KNOW YOUR VEHICLE

In case the ignition switch does not change

positions with the push of a button, the key fob

may have a low or fully depleted battery. A low key

fob battery can be verified by referring to the

instrument cluster, which will display directions to

follow.
For more information on ignition positions, see

page 23.

NOTE:

A low key fob battery condition may be indicated by

a message in the instrument cluster display, or by

the LED light on the key fob. If the LED key fob light

no longer illuminates after a key fob button is

pushed, then the key fob battery requires

replacement

page 413.

To Lock/Unlock The Doors And Liftgate

Push and release the unlock button on the key fob

once to unlock the driver’s door, or twice within five

seconds to unlock all the doors and the liftgate. To

lock all the doors and the liftgate, push the lock

button once.
When the doors are unlocked, the turn signals will

flash and the illuminated entry system will be

activated. When the doors are locked, the turn

signals will flash and the horn will chirp.

NOTE:



If the vehicle is unlocked with the key fob, and

no door is opened within 60 seconds, the

vehicle will relock and the security system will

arm (if equipped).



If one or more doors are open, or the liftgate is

open, the doors will lock. The doors will unlock

again automatically if the key is left inside the

passenger compartment, otherwise the doors

will stay locked.

All doors can be programmed to unlock on the first

push of the unlock button through Uconnect

Settings

page 216.

Key Left Vehicle Feature

If a valid key fob is no longer detected inside the

vehicle while the vehicle’s ignition system is in the

ON/RUN or START position, the message “Key Left

Vehicle” will be shown in the instrument cluster

display along with an interior chime. An exterior

audible and visual alert will also be activated to

warn the driver.
The vehicle’s horn will rapidly chirp three times

along with a single flash of the vehicle’s exterior

lights.

NOTE:



The doors have to be open and then closed in

order for the vehicle to check for the presence of

a key fob; the Key Left Vehicle feature will not

activate until all of the doors are all closed.



These alerts will not be activated in situations

where the vehicle’s engine is left running with

the key fob inside.

Air Suspension (Remote Lowering Of

The Vehicle) — If Equipped

For easy entry and loading, your vehicle

can be lowered to Entry/Exit height by

pushing the key fob air suspension

button two times. When air suspension

lowering is requested using the key fob, the vehicle

will send a series of chirps and flashes to alert the

customer that the operation has begun and will

continue these alerts until it successfully lowers.
The following conditions must be met for the

vehicle to lower remotely:



The vehicle must not already be in Entry/Exit

(Park) ride height.



The vehicle battery must be fully charged.



All doors must be closed.



The key fob must be out of the vehicle.

GETTING TO KNOW YOUR VEHICLE

NOTE:

Ensure the vehicle is clear of all objects, pets, and

people prior to remote lowering.
Canceling Remote Lowering
Vehicle lowering can be cancelled at anytime.

When vehicle lowering is cancelled, the vehicle will

raise up to the next defined level and lock out the

remote lowering feature for five seconds before a

new request can be made.
To cancel vehicle lowering, push the key fob air

suspension button one time during the lowering

process. When vehicle lowering is cancelled, the

horn will chirp two times and the turn signal lamps

will flash four times. Once raising is completed, the

horn will chirp one time.

NOTE:

For more information on Air Suspension, see

page 143.

Replacing The Battery In The Key Fob

The replacement battery model is one CR2450

battery.

NOTE:



Customers are recommended to use a battery

obtained from Mopar®. Aftermarket coin

battery dimensions may not meet the original

OEM coin battery dimensions.



Perchlorate Material — special handling may

apply. See

www.dtsc.ca.gov/hazard

ouswaste/perchlorate

for further information.



Do not touch the battery terminals that are on

the back housing or the printed circuit board.



Do not replace the coin battery if the LED on the

key fob above the top row buttons blinks when

a button is pressed. The coin battery should last

a minimum of three years with normal vehicle

usage.

1. Remove the emergency key by pushing the

emergency key release button (1) on the side

of the key fob, and pulling the emergency key

(2) out with your other hand.

Emergency Key Removal

Emergency Key Removed

2. Hold the key fob with the button side facing

down, and locate the small rectangular gap

on the left side between the housing and the

back cover of the key fob. Use a small

flat-bladed tool to pry open the left side of the

fob cover while applying pressure until the

cover snaps open.

Pry Apart Key Fob Halves

1 — Emergency Key Release Button
2 — Emergency Key

GETTING TO KNOW YOUR VEHICLE

3. Next, locate the gap on the right side of the key

fob, which is positioned further to the edge

than the left side gap. Pry open the right side,

and remove the back cover.

4. Remove the battery by using your thumb to

slide the battery downward and back toward

the key ring.

Key Fob Battery Location

NOTE:

You can also insert a screwdriver or similar tool into

the battery removal pocket to pry the battery out.

Battery Removal Pocket

NOTE:

When replacing the battery, ensure the (+) sign on

the battery is facing upward. Avoid touching the

new battery with your fingers. Skin oils may cause

battery deterioration. If you touch a battery, clean

it with rubbing alcohol.
5. Replace the battery by using your thumb to

push down and slide the battery under the

small lip on the top edge of the opening.

Key Fob Battery Replacement

6. To assemble the key fob case, line up the top

edge of the back cover with the top of the fob,

and press the edges into the interlocking

hinges until all edges snap together with no

large visual gaps.

7. Reinsert the emergency key until it locks into

place.

NOTE:

The key fob battery should only be replaced by

qualified technicians. If the battery requires

replacement, see an authorized dealer.

GETTING TO KNOW YOUR VEHICLE

Programming And Requesting Additional

Key Fobs

Programming the key fob may be performed by an

authorized dealer.

NOTE:



Once a key fob is programmed to a vehicle, it

cannot be repurposed and reprogrammed to

another vehicle.



Only key fobs that are programmed to the

vehicle electronics can be used to start and

operate the vehicle. Once a key fob is

programmed to a vehicle, it cannot be

programmed to any other vehicle.

Duplication of key fobs may be performed at an

authorized dealer. This procedure consists of

programming a blank key fob to the vehicle

electronics. A blank key fob is one that has never

been programmed.

NOTE:

When having the Sentry Key Immobilizer system

serviced, bring all vehicle keys with you to an

authorized dealer.

SENTRY KEY

The Sentry Key Immobilizer system prevents

unauthorized vehicle operation by disabling the

engine. The system does not need to be armed or

activated. Operation is automatic, regardless of

whether the vehicle is locked or unlocked.
The system uses a key fob, keyless push button

ignition and a Radio Frequency (RF) receiver to

prevent unauthorized vehicle operation. Therefore,

only key fobs that are programmed to the vehicle

can be used to start and operate the vehicle. The

system cannot reprogram a key fob obtained from

another vehicle.
After placing the ignition in the ON/RUN position,

the Vehicle Security Light will turn on for three

seconds for a bulb check. If the light remains on

after the bulb check, it indicates that there is a

problem with the electronics. In addition, if the light

begins to flash after the bulb check, it indicates

that someone attempted to start the engine with

an invalid key fob. In the event that a valid key fob

is used to start the engine but there is an issue

with the vehicle electronics, the engine will start

and shut off after two seconds.
If the Vehicle Security Light turns on during normal

vehicle operation (vehicle running for longer than

10 seconds), it indicates that there is a fault in the

electronics. Should this occur, have the vehicle

serviced as soon as possible by an authorized

dealer.

All of the key fobs provided with your new vehicle

have been programmed to the vehicle electronics

page 413.

WARNING!



The integrated key fob contains a coin cell

battery. Do not ingest the battery; there is a

chemical burn hazard. If the coin cell battery is

swallowed, it can cause severe internal burns

in just two hours and can lead to death.



If you think a battery may have been swal

lowed or placed inside any part of the body,

seek immediate medical attention.



Keep new and used batteries away from chil

dren. If the battery compartment does not

close securely, stop using the product and

keep it away from children.

WARNING!



Always remove the key fobs from the vehicle

and lock all doors when leaving the vehicle

unattended.



Always remember to place the ignition in the

OFF position.

CAUTION!

The Sentry Key Immobilizer system is not

compatible with some aftermarket remote

starting systems. Use of these systems may

result in vehicle starting problems and loss of

security protection.

GETTING TO KNOW YOUR VEHICLE

(Continued)

IGNITION SWITCH

EYLESS

NTER

‘

™ I

GNITION

This feature allows the driver to operate the

ignition switch with the push of a button as long as

the key fob is in the passenger compartment.
The START/STOP ignition button has several

operating modes that are labeled and will

illuminate when in position. These modes are OFF,

ON/RUN, and START.

START/STOP Ignition Button

The push button ignition can be placed in the

following modes:
OFF



The engine is stopped



Some electrical devices (e.g. power locks,

alarm, etc.) are still available

ON/RUN



Driving position



All electrical devices are available (e.g. climate

controls, heated seats, etc.)

START



The engine will start (when foot is on the brake

pedal)

NOTE:



If the ignition position does not change with a

push of the ignition button, and the instrument

cluster displays a message such as “Key Fob

Not Detected”, the key fob may have a low or

depleted battery. In this situation, a back up

method can be used to operate the ignition

switch. Put the nose side of the key fob (side

opposite of the emergency key) against the

START/STOP ignition button and push to

operate the ignition switch.



Replacement of the key fob battery is recom

mended.

Depleted Key Fob Battery Procedure

1 — OFF
2 — ON/RUN

WARNING!



When exiting the vehicle, always remove the

key fob from the vehicle and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle.



Allowing children to be in a vehicle unattended

is dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.

GETTING TO KNOW YOUR VEHICLE

NOTE:



The key fob may not be detected by the vehicle

Keyless Enter ‘n Go™ system if it is located next

to a mobile phone, laptop or other electronic

device; these devices may block the key fob’s

wireless signal and prevent the Keyless Enter ‘n

Go™ system from starting the vehicle.



For more information on the engine starting

procedure, see

page 128.



When opening the driver's door and the ignition

is in the ON/RUN position (engine not running),

a chime will sound to remind you to place the

ignition in the OFF position. In addition to the

chime, the message “Ignition ON” will display in

the cluster.

REMOTE START

This system uses the key fob to start the

engine conveniently from outside the

vehicle while still maintaining security.

The system has a range of

approximately 328 ft (100 m).
Remote Start is used to defrost windows in cold

weather, and to reach a comfortable climate in all

ambient conditions before the driver enters the

vehicle.

NOTE:

Obstructions between the vehicle and key fob may

reduce this range

page 413.

EMOTE

TART

Push and release the Remote Start button on the

key fob twice within five seconds. The vehicle

doors will lock, the parking lights will flash, and the

horn will chirp twice (if programmed). Then, the

engine will start, and the vehicle will remain in the

Remote Start mode for a 15 minute cycle. Pushing

the Remote Start button a third time shuts the

engine off.



Do not leave the key fob in or near the

vehicle, or in a location accessible to chil

dren, and do not leave the Keyless Enter ‘n

Go™ Ignition in the ON/RUN position. A child

could operate power windows, other controls,

or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat buildup

may cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves.

Always remove key fob from the vehicle and lock

all doors when leaving the vehicle unattended.

WARNING!



Do not start or run an engine in a closed

garage or confined area. Exhaust gas

contains Carbon Monoxide (CO) which is

odorless and colorless. Carbon Monoxide is

poisonous and can cause serious injury or

death when inhaled.



Keep key fobs away from children. Operation

of the Remote Start system, windows, door

locks or other controls could cause serious

injury or death.

GETTING TO KNOW YOUR VEHICLE

NOTE:



With Remote Start, the engine will only run for

15 minutes.



Remote Start can only be used twice.



If an engine fault is present or fuel level is low,

the vehicle will start and then shut down in 10

seconds.



The parking lights will turn on and remain on

during Remote Start mode.



Headlight animation (if equipped) will occur

when Remote Start is activated, if “Headlight

Illumination On Approach” is enabled within

Uconnect Settings.



For security, power window and power sunroof

operation (if equipped) are disabled when the

vehicle is in the Remote Start mode.



The ignition must be placed in the ON/RUN

position before the Remote Start sequence

can be repeated for a third cycle.

All of the following conditions must be met before

the engine will remote start:



Gear selector in PARK



Doors closed



Hood closed



Liftgate closed



Hazard switch off



Brake switch inactive (brake pedal not pressed)



Battery at an acceptable charge level



System not disabled from previous Remote

Start event



Vehicle Security Light flashing



Ignition in OFF position



PANIC button is not pushed



Fuel level meets minimum requirement



Vehicle Security system is not signaling an

intrusion



Malfunction Indicator Light (MIL) is not

illuminated

XIT

EMOTE

TART

ODE

To drive the vehicle after starting the Remote Start

system, either push and release the unlock button

on the key fob to unlock the doors, or unlock the

vehicle using Keyless Enter ‘n Go™ — Passive Entry

via the door handles, and disarm the Vehicle

Security system (if equipped). Then, prior to the

end of the 15 minute cycle, push and release the

START/STOP ignition button.
The Remote Start system will turn the engine off if

the Remote Start button on the key fob is pushed

again, or if the engine is allowed to run for the

entire 15 minute cycle. Once the ignition is placed

in the ON/RUN position, the climate controls will

resume previously set operations (temperature,

blower control, etc.).

NOTE:



To avoid unintentional shutdowns, the system

will disable for two seconds after receiving a

valid Remote Start request.



For vehicles equipped with the Keyless

Enter ‘n Go™ — Passive Entry feature, the

message “Remote Start Active — Push Start

Button” will display in the instrument cluster

display until you push the START/STOP ignition

button.

WARNING!



Do not start or run an engine in a closed

garage or confined area. Exhaust gas

contains Carbon Monoxide (CO) which is

odorless and colorless. Carbon Monoxide is

poisonous and can cause serious injury or

death when inhaled.



Keep key fobs away from children. Operation

of the Remote Start system, windows, door

locks or other controls could cause serious

injury or death.

GETTING TO KNOW YOUR VEHICLE

EMOTE

TART

RONT

EFROST

CTIVATION

— I

QUIPPED

When Remote Start is active, and the outside

ambient temperature is 40°F (4.5°C) or below, the

system will automatically activate front defrost for

15 minutes or less. The time is dependent on the

ambient temperature. Once the timer expires, the

system will automatically adjust the settings

depending on ambient conditions. See “Remote

Start Comfort Systems — If Equipped” in the next

section for detailed operation.

EMOTE

TART

OMFORT

YSTEMS

—

QUIPPED

When Remote Start is activated, the front and rear

defrost will automatically turn on in cold weather.

The heated steering wheel and driver heated seat

feature will turn on if selected in the comfort menu

screen within Uconnect Settings

page 216. In

warm weather, the driver vented seat feature will

automatically turn on when Remote Start is

activated, if programmed in the comfort menu

screen. The vehicle will adjust the climate control

settings depending on the outside ambient

temperature.

Automatic Temperature Control (ATC) —

If Equipped
The climate controls will automatically adjust to

the optimal temperature and mode settings

depending on the outside ambient temperature.

This will occur until the ignition is placed in the ON/

RUN position where the climate controls will

resume their previous settings.
For more information on ATC and climate control

settings, see

page 72.

NOTE:

These features will stay on through the duration of

Remote Start until the ignition is placed in the ON/

RUN position. The climate control setting will

change, and exit automatic operation, if manually

adjusted by the driver while the vehicle is in

Remote Start mode. This includes the OFF button

on the climate controls, which will turn the system

off.

EMOTE

TART

INDSHIELD

IPER

–I

CER

CTIVATION

— I

QUIPPED

When Remote Start is active and the outside

ambient temperature is less than 33°F (0.6°C),

the Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation. If

the Windshield Wiper De-Icer was active, the timer

and operation will continue.

EMOTE

TART

BORT

ESSAGE

The following messages will display in the

instrument cluster display if the vehicle fails to

remote start or exits Remote Start prematurely:



Remote Start Cancelled — Door Open



Remote Start Cancelled — Hood Open



Remote Start Cancelled — Liftgate Open



Remote Start Cancelled — Fuel Low



Remote Start Cancelled — System Fault



Remote Start Disabled — Start Vehicle to Reset

The instrument cluster display message stays

active until the ignition is placed in the ON/RUN

position.

VEHICLE SECURITY SYSTEM — IF EQUIPPED

The Vehicle Security system monitors the vehicle

doors, hood, liftgate, and the Keyless Enter ‘n Go™

Ignition for unauthorized operation. While the

Vehicle Security system is armed, interior switches

for door locks and liftgate release handle are

disabled. If something triggers the alarm, the

Vehicle Security system will provide the following

audible and visible signals:



The horn will pulse



The turn signals will flash



The Vehicle Security Light in the instrument

cluster will flash

GETTING TO KNOW YOUR VEHICLE

YSTEM

Follow these steps to arm the Vehicle Security

system:
1. Make sure the vehicle’s ignition is placed in

the OFF position.



For vehicles equipped with Keyless Entry,

make sure the vehicle’s keyless ignition

system is OFF.

2. Perform one of the following methods to lock

the vehicle:



Push lock on the interior power door lock

switch with the driver and/or passenger

door open.



Touch the lock button on the exterior

Passive Entry door handle with a valid key

fob available in the same exterior zone



Push the lock button on the key fob.

3. If any doors are open, close them.

When the Vehicle Security system is armed, the

Vehicle Security Light (located in the lower right

portion of the instrument cluster display) will begin

to flash every two seconds until it is disarmed.

NOTE:

If the system is armed by pushing the lock button

on the interior door panel, the Vehicle Security

Light will flash rapidly for about 15 seconds once

the door is closed, then slow down to every two

seconds.

ISARM

YSTEM

The Vehicle Security system can be disarmed using

any of the following methods:



Push the unlock button on the key fob.



Grab the Passive Entry door handle to unlock

the door



Cycle the ignition out of the OFF position to

disarm the system.

NOTE:



The driver's door key cylinder cannot arm or

disarm the Vehicle Security system. Use of the

door key cylinder when the alarm is armed will

sound the alarm when the door is opened.



The Vehicle Security system remains armed

when the power liftgate is opened using the lift

gate button on the key fob. If someone enters

the vehicle through the liftgate and opens any

door from the inside, the alarm will sound.



If Passive Entry (if equipped) is used to unlock

the liftgate, the Vehicle Security system is

disarmed and the rest of the vehicle doors will

remain locked unless all doors are set to unlock

on first press within Uconnect Settings.



When the Vehicle Security system is armed, the

interior power door lock switches will not unlock

the doors.

The Vehicle Security system is designed to protect

your vehicle. However, you can create conditions

where the system will give you a false alarm. If one

of the previously described arming sequences has

occurred, the Vehicle Security system will arm

regardless of whether you are in the vehicle or not.

If you remain in the vehicle and open a door, the

alarm will sound. If this occurs, disarm the Vehicle

Security system.
If the Vehicle Security system is armed and the

battery becomes disconnected, the Vehicle

Security system will remain armed when the

battery is reconnected; the exterior lights will flash,

and the horn will sound. If this occurs, disarm the

Vehicle Security system.

EARMING

YSTEM

If something triggers the alarm and no action is

taken to disarm it, the Vehicle Security system will

turn the horn off after a 29 second cycle (with five

seconds between cycles and up to eight cycles if

the trigger remains active) and then rearm itself.

GETTING TO KNOW YOUR VEHICLE

ECURITY

YSTEM

ANUAL

VERRIDE

The Vehicle Security system will not arm if you lock

the doors using the manual door lock, or an

emergency lock lever

page 29.

AMPER

LERT

If something has triggered the Vehicle Security

system in your absence, the horn will sound three

times and the exterior lights will blink three times

when you disarm the Vehicle Security system.

DELUXE VEHICLE SECURITY SYSTEM —

IF EQUIPPED

The Deluxe Vehicle Security system monitors the

doors, hood latch, and liftgate for unauthorized

entry and the ignition switch for unauthorized

operation. The system also includes a dual

function intrusion sensor and vehicle tilt sensor.

The intrusion sensor monitors the vehicle interior

for motion. The vehicle tilt sensor monitors the

vehicle for any tilting actions (tow away, tire

removal, ferry transport, etc.).
If a perimeter violation triggers the security system,

the horn will sound for 29 seconds and the exterior

lights will flash followed by approximately five

seconds of no activity. This will continue for eight

cycles if no action is taken to disarm the system.

YSTEM

Follow these steps to arm the security system:
1. Make sure the vehicle ignition system is OFF.
2. Perform one of the following methods to lock

the vehicle:



Push the lock button on the interior power

door lock switch with the driver and/or

passenger door open.



Touch the lock button on the exterior

Passive Entry door handle with a key fob

available in the same exterior zone



Push the lock button on the key fob.

3. If any doors are open, close them.

NOTE:



Once the security system is armed, it remains in

that state until you disarm it by following either

of the disarming procedures described. If a

power loss occurs after arming the system, you

must disarm the system after restoring power to

prevent alarm activation.



The ultrasonic intrusion sensor (motion

detector) actively monitors your vehicle every

time you arm the Vehicle Security system. If you

prefer, you can turn off the ultrasonic intrusion

sensor when arming the Vehicle Security

system. To do so, push the lock button on the

key fob four times within 15 seconds of arming

the system (while the Vehicle Security Light is

flashing rapidly).

ISARM

YSTEM

The Vehicle Security system can be disarmed using

any of the following methods:



Push the unlock button on the key fob.



Grab the Passive Entry door handle to unlock

the door
