GETTING TO KNOW YOUR VEHICLE

(Continued)

1. Place the ignition switch into the ON/RUN

position.

2. Place the garage door opener transmitter

1 to 3 inches (3 to 8 cm) away from the

HomeLink® button you wish to program, while

keeping the HomeLink® indicator light in view.

3. Push and hold the HomeLink® button you

want to program while you push and hold the

garage door opener transmitter button you are

trying to replicate.

4. Continue to hold both buttons and observe the

HomeLink® indicator light. The HomeLink®

indicator light will flash slowly and then rapidly.

Once this happens, release both buttons.

NOTE:

Make sure the garage door opener motor is

plugged in before moving on to the rolling code/

non-rolling code final steps.
Rolling Code Garage Door Opener Final Steps

NOTE:

You have 30 seconds in which to initiate rolling

code final step 2, after completing rolling code

final step 1.
1. At the garage door opener motor (in the

garage), locate the “LEARN” or “TRAIN”

button. This can usually be found where the

hanging antenna wire is attached to the

garage door opener motor. Firmly push and

release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the

programmed HomeLink® button three times

(holding the button for two seconds each

time). If the garage door opener motor

operates, programming is complete.

3. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the final steps for the

rolling code procedure.

Non-Rolling Code Garage Door Opener Final Steps
1. Push and hold the programmed HomeLink®

button and observe the HomeLink® indicator

light. If the HomeLink® indicator light stays

on constantly, programming is complete.

2. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the steps from the

beginning.

ROGRAMMING

OME

INK

® T

ISCELLANEOUS

EVICE

The procedure on how to program HomeLink® to a

miscellaneous device follows the same procedure

as programming to a garage door opener

page 40. Be sure to determine if the device has

a rolling code, or non-rolling code before beginning

the programming process.

NOTE:

Canadian Radio Frequency (RF) laws require trans

mitter signals to time-out (or quit) after several

seconds of transmission, which may not be long

enough for HomeLink® to pick up the signal during

programming. Similar to this Canadian law, some

U.S. gate operators are designed to time-out in the

same manner. The procedure may need to be

performed multiple times to successfully pair the

device to your HomeLink® buttons.

WARNING!



Your motorized door or gate will open and

close while you are programming the universal

transmitter. Do not program the transmitter if

people or pets are in the path of the door or

gate.



Do not run your vehicle in a closed garage or

confined area while programming the trans

mitter. Exhaust gas from your vehicle contains

Carbon Monoxide (CO) which is odorless and

colorless. Carbon Monoxide is poisonous

when inhaled and can cause you and others to

be severely injured or killed.

WARNING!

GETTING TO KNOW YOUR VEHICLE

EPROGRAMMING

A S

INGLE

OME

INK

® B

UTTON

To reprogram a single HomeLink® button that has

been previously trained, without erasing all the

channels, follow the procedure below. Be sure to

determine whether the new device you want to

program the HomeLink® button to has a rolling

code, or non-rolling code.
1. Place the ignition in the ON/RUN position,

without starting the engine.

2. Push and hold the desired HomeLink® button

until the HomeLink® indicator light begins to

flash after 20 seconds. Do not release the

button.

3. Without releasing the button, proceed with

Step 2 in “Programming HomeLink® To A

Garage Door Opener” and follow all remaining

steps.

ANADIAN

ATE

PERATOR

ROGRAMMING

For programming transmitters in Canada/United

States that require the transmitter signals to

“time-out” after several seconds of transmission:
Canadian Radio Frequency (RF) laws require

transmitter signals to time-out (or quit) after

several seconds of transmission, which may not be

long enough for HomeLink® to pick up the signal

during programming. Similar to this Canadian law,

some U.S. gate operators are designed to time-out

in the same manner.
It may be helpful to unplug the device during the

cycling process to prevent possible overheating of

the garage door or gate motor.
1. Place the ignition in the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter ‘n Go™,

place the ignition in the RUN position with the

engine on. Make sure while programming

HomeLink® with the engine on that your vehicle is

outside of your garage, or that the garage door

remains open at all times.
2. Place the hand-held transmitter 1 to 3 inches

(3 to 8 cm) away from the HomeLink® button

you wish to program while keeping the

HomeLink® indicator light in view.

3. Continue to push and hold the HomeLink®

button while you push and release (cycle) your

hand-held transmitter every two seconds until

HomeLink® has successfully accepted the

frequency signal. The indicator light will flash

slowly and then rapidly when fully trained.

4. Watch for the HomeLink® indicator to change

flash rates. When it changes, it is

programmed. It may take up to 30 seconds or

longer in rare cases. The garage door may

open and close while you are programming.

5. Push and hold the programmed HomeLink®

button and observe the indicator light.

NOTE:



If the indicator light stays on constantly,

programming is complete and the garage

door/device should activate when the

HomeLink® button is pushed.



To program the two remaining HomeLink®

buttons, repeat each step for each

remaining button. DO NOT erase the chan

nels.

If you unplugged the garage door opener/device

for programming, plug it back in at this time.
Reprogramming A Single HomeLink® Button

(Canadian/Gate Operator)
To reprogram a channel that has been previously

trained, follow these steps:
1. Place the ignition in the ON/RUN position.
2. Press and hold the desired HomeLink® button

until the indicator light begins to flash after

20 seconds. Do not release the button.

3. Without releasing the button, proceed with

“Canadian/Gate Operator Programming” Step

2 and follow all remaining steps.

GETTING TO KNOW YOUR VEHICLE

ECURITY

It is advised to erase all channels before you sell or

turn in your vehicle.
To do this, push and hold the two outside buttons

for 20 seconds until the indicator flashes. Note

that all channels will be erased. Individual

channels cannot be erased.
The HomeLink® Universal Transceiver is disabled

when the Vehicle Security system is active.

ROUBLESHOOTING

IPS

If you are having trouble programming

HomeLink®, here are some of the most common

solutions:



Replace the battery in the garage door opener

hand-held transmitter.



Push the LEARN button on the garage door

opener to complete the training for a rolling

code.



Did you unplug the device for programming and

remember to plug it back in?

If you have any problems, or require assistance,

please call toll-free 1-800-355-3515 or, on the

Internet at HomeLink.com for information or

assistance.

EXTERIOR LIGHTS

ULTIFUNCTION

EVER

The multifunction lever controls the operation of

the turn signals, headlight beam selection and

passing lights. The multifunction lever is located on

the left side of the steering column.

Multifunction Lever

WARNING!



Vehicle exhaust contains carbon monoxide, a

dangerous gas. Do not run your vehicle in the

garage while programming the transceiver.

Exhaust gas can cause serious injury or death.



Your motorized door or gate will open and

close while you are programming the universal

transceiver. Do not program the transceiver if

people, pets or other objects are in the path of

the door or gate. Only use this transceiver with

a garage door opener that has a “stop and

reverse” feature as required by Federal safety

standards. This includes most garage door

opener models manufactured after 1982. Do

not use a garage door opener without these

safety features.

GETTING TO KNOW YOUR VEHICLE

EADLIGHT

WITCH

The headlight switch is located on the left side of

the instrument panel. This switch controls the

operation of the headlights, parking lights,

automatic headlights (if equipped), instrument

panel lights, and fog lights (if equipped).

Headlight Switch

Headlight Switch (Vehicles Sold In Canada Only)

NOTE:

Vehicles sold in Canada are equipped with a head

light switch without the OFF position. In order to

turn the exterior lights off, the headlight switch

must be rotated to AUTO position.
Rotate the headlight switch clockwise to the first

detent for parking lights and instrument panel

lights operation. Rotate the headlight switch to the

second detent for headlights, parking lights and

instrument panel lights operation.

NOTE:

For vehicles sold in Canada, rotate the headlight

switch clockwise from the parking lights and

instrument panel lights position to the first detent

to turn the headlight switch to the AUTO position.

Rotate to the second detent to turn on headlights,

parking lights, and instrument panel lights oper

ation.

AYTIME

UNNING

IGHTS

(DRL

) —

QUIPPED

The Daytime Running Lights will turn on when the

engine is started and remain on unless the

headlamps are turned on, the parking brake is

applied, or the ignition is placed in the OFF

position.

NOTE:



For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate

when the front fog lights are turned on.



If allowed by law in the country in which the

vehicle was purchased, the Daytime Running

Lights can be turned on and off using the

Uconnect system

page 150.



On some vehicles, the Daytime Running Lights

may deactivate, or reduce intensity, on one side

of the vehicle (when a turn signal is activated on

that side), or on both sides of the vehicle (when

the hazard warning lights are activated).

1 — Rotate Headlight Control
2 — Push Fog Light Control
3 — Ambient Light Dimmer Control
4 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

IGH

EAM

WITCH

After the low beam headlights are turned on, push

the multifunction lever, located on the left side of

the steering wheel, away from you to switch the

headlights to high beam. Pulling the multifunction

lever back will turn the low beams on.

UTOMATIC

IGH

EAM

EADLAMP

ONTROL

— I

QUIPPED

The Automatic High Beam Headlamp Control

system provides increased forward lighting at night

by automatically controlling the high beams

through the use of a camera mounted on the

windshield. This camera detects vehicle specific

light and automatically switches from high beams

to low beams until the approaching vehicle is out of

view.

NOTE:



The Automatic High Beam Headlamp Control is

enabled through the Uconnect system

page 150.



The multifunction lever must be in the high

beam position and the low beams must be

turned on in order to activate the Automatic

High Beams.



Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will

cause headlights to remain on longer (closer to

the vehicle). Also, dirt, film, and other obstruc

tions on the windshield or camera lens will

cause the system to function improperly.



When set to AUTO, and the low beams are on

and the multifunction lever is in the high beam

position, the system automatically turns the

high beams on or off based on light levels of the

approaching vehicles.



Vehicle speed must be greater than 22 mph

(35 km/h) to activate Automatic High Beams.

Once activated, Automatic High Beams will

remain on until the speed falls below 15 mph

(25 km/h).

LASH

-T

-P

ASS

You can signal another vehicle with your headlights

by lightly pulling the multifunction lever toward you.

This will cause the high beam headlights to turn on,

and remain on, until the lever is released.

UTOMATIC

EADLIGHTS

— I

QUIPPED

This system automatically turns the headlights on

or off according to ambient light levels. To turn the

system on, rotate the headlight switch to the AUTO

position for automatic headlight operation. When

the system is on, the headlight time delay feature

is also on. This means the headlights will stay on

for up to 90 seconds (depending on customer

programmable time of 30, 60, or 90 seconds) after

you place the ignition in the OFF position. To turn

the automatic system off, move the headlight

switch out of the AUTO position.

NOTE:

The engine must be running before the headlights

will come on in the automatic mode.

ARKING

IGHTS

Rotate the headlight switch clockwise to the first

detent for parking lights and instrument panel

lights operation. Rotate the headlight switch to the

second detent for headlights, parking lights and

instrument panel lights operation.

NOTE:

For vehicles sold in Canada, the first headlight

switch position is the parking lights and instrument

panel lights position (instead of the OFF position).

Rotate the headlight switch clockwise to the

second detent to turn on headlights, parking lights,

and instrument panel lights operation.

GETTING TO KNOW YOUR VEHICLE

UTOMATIC

EADLIGHTS

ITH

IPERS

— I

QUIPPED

When this feature is programmed on and the

headlight switch is set to AUTO, the headlights will

turn on after the wipers are turned on. This feature

will also turn the headlights off when the wipers

are turned off.

NOTE:

This feature can be turned on or off using the

Uconnect system

page 150.

EADLIGHT

IME

ELAY

This feature provides the safety of headlight

illumination for up to 90 seconds (programmable)

when leaving your vehicle in an unlit area.
To activate the delay feature, place the ignition in

the OFF position while the headlights are still on.

Then, turn off the headlights within 45 seconds of

placing the ignition in the OFF position. The delay

interval begins when the headlight switch is turned

off.

NOTE:

The headlight delay feature is automatically acti

vated if the customer leaves the headlight switch

in the AUTO position while the ignition is placed in

the OFF position.

If you turn the headlights or parking lights on, or

place the ignition in ACC or RUN, the system will

cancel the delay.
If you turn the headlights off before the ignition,

they will turn off in the normal manner.

NOTE:



The lights must be turned off within 45 seconds

of placing the ignition in the OFF position to acti

vate this feature.



The headlight delay time is programmable using

the Uconnect system

page 150.

IGHTS

-O

EMINDER

If the headlights or parking lights are on after the

ignition is placed in the OFF position, the vehicle

will chime to alert the driver when the driver's door

is opened.

IGHTS

— I

QUIPPED

The front fog light switch is built into the headlight

switch.

Fog Light Switch

Fog Light Switch (Vehicles Sold In Canada Only)

To activate the front fog lights, turn on the parking

lights or the low beam headlights and push the

headlight switch. To turn off the front fog lights,

either push the headlight switch a second time or

turn off the headlight switch.

GETTING TO KNOW YOUR VEHICLE

An indicator light in the instrument cluster

illuminates when the fog lights are turned on.

NOTE:

The fog lights will operate with the low beam head

lights or parking lights on. However, selecting the

high beam headlights will turn off the fog lights.

URN

IGNALS

Lightly push the multifunction lever up or down to

activate the turn signals. The arrows on each side

of the instrument cluster display will flash to show

proper operation.

NOTE:



If either light remains on and does not flash, or

there is a very fast flash rate, check for a defec

tive LED turn signal. Please see an authorized

dealer for service.



A “Turn Signal On” message will appear in the

instrument cluster display and a continuous

chime will sound if the vehicle is driven more

than 1 mile (1.6 km) with either turn signal on.

ANE

HANGE

SSIST

— I

QUIPPED

Lightly push the multifunction lever up or down,

without moving beyond the detent, and the turn

signal will flash three times then automatically turn

off.

ATTERY

AVER

Timers are set to both the interior and exterior

lights to protect the life of your vehicle’s battery.
After 10 minutes, if the ignition is in the OFF

position and any door is left open or the dimmer

control is rotated all the way up to the dome light

on position, the interior lights will automatically

turn off.

NOTE:

Battery saver mode is canceled if the ignition is

placed in the ON position.
If the headlights remain on while the ignition is

placed in the OFF position, the exterior lights will

automatically turn off after eight minutes. If the

headlights are turned on and left on for eight

minutes while the ignition is OFF, the exterior lights

will automatically turn off.

INTERIOR LIGHTS

The interior lights come on when a door is opened.
To protect the battery, the interior lights will turn off

automatically 10 minutes after the ignition is

placed in the OFF position. This will occur if the

interior lights were turned on manually or are on

because a door is open. The Battery Protection

also includes the glove compartment light and the

cargo light. To restore interior light operation after

automatic battery protection is enabled (lights off),

either place the ignition in the ON/RUN position or

cycle the light switch.

NTERIOR

OURTESY

IGHTS

Front Map/Reading Lights

The front map/reading lights are mounted in the

overhead console. Each light can be turned on by

pushing a switch on either side of the console. To

turn the lights off, push the switch a second time.

These lights also turn on when a door is opened, or

when the unlock button on the key fob is pushed,

or when the dimmer control is turned completely

upward to the second detent.

Front Map/Reading Light Switches

GETTING TO KNOW YOUR VEHICLE

Instrument Panel Dimmer Control

The instrument panel dimmer control is part of the

headlight switch and is located on the driver’s side

of the instrument panel.
With the parking lights or headlights on, rotating

the instrument panel dimmer control upward to

the first detent will increase the brightness of text

displays such as the odometer, instrument cluster

display, and radio.
Rotate the instrument panel dimmer control

completely upward to the second detent to turn on

the interior lights. The interior lights will remain on

when the instrument panel dimmer control is in

this position.

Instrument Panel Dimmer

Instrument Panel Dimmer (Vehicles Sold In Canada Only)

Rotate the instrument panel dimmer control

downward to the O (off) position, and the interior

lights will remain off when the doors are open.

Ambient Light Control — If Equipped

Rotate the ambient dimmer control upward or

downward to increase or decrease the brightness

of the ambient light located in the overhead

console, door handle lights, and door map pocket

lights.

Ambient Light/Door Handle Light Dimmer

(Vehicles Sold In Canada Only)

GETTING TO KNOW YOUR VEHICLE

LLUMINATED

NTRY

The courtesy lights will turn on when you use the

key fob to unlock the doors or open any door.
The lights will fade to off after approximately

30 seconds, or they will immediately fade to off

once the ignition switch is placed in the ON/RUN

position from the OFF position.
The courtesy lights will not turn off if the instrument

panel dimmer control is rotated upward to the

second detent. The courtesy lights will turn off after

10 minutes when the ignition is placed in the OFF

position to protect the battery.
The illuminated entry system will not operate if the

instrument panel dimmer control is rotated all the

way down to the O (off) position.

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer controls are located

on the windshield wiper/washer lever on the right

side of the steering column. The front wipers are

operated by rotating a switch, located on the end of

the lever.

INDSHIELD

IPER

PERATION

Rotate the end of the lever to one of the first four

detent positions for intermittent settings, the fifth

detent for low wiper operation and the sixth detent

for high wiper operation.

Windshield Wiper Operation

NOTE:

Do not operate the windshield wipers with the

blades lifted from the windshield.

Intermittent Wipers
Use one of the four intermittent wiper settings

when weather conditions make a single wiping

cycle, with a variable delay between cycles,

desirable. At driving speeds above 10 mph

(16 km/h), the delay can be regulated from a

maximum of approximately 18 seconds between

cycles (first detent), to a cycle every one second

(fourth detent). If the vehicle is moving less than

10 mph (16 km/h), delay times will be doubled.
Windshield Washers
To use the washer, pull the lever rearward toward

you and hold. If the lever is pulled while in the

intermittent setting, the wipers will turn on and

operate for several wipe cycles after the lever is

released, and then resume the intermittent

interval previously selected.
If the lever is pulled while the wipers are in the off

position, the wipers will operate for several wipe

cycles, then turn off.

1 — Push Forward For Rear Washer
2 — Rotate For Front Wiper Operation
3 — Pull For Front Washer
4 — Rotate For Rear Wiper Operation
5 — Push Up For Mist

CAUTION!

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the “park” position. If the windshield

wiper switch is turned off, and the blades cannot

return to the “park” position, damage to the

wiper motor may occur.

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

Mist
Push the lever upward to the MIST position and

release for a single wiping cycle.

NOTE:

The mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page 260.

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snowfall on the

windshield and automatically activates the wipers.

Rotate the end of the multifunction lever to one of

four detent positions to activate this feature.
The sensitivity of the system can be adjusted with

the multifunction lever. Wiper delay detent one is

the least sensitive, and wiper delay position four is

the most sensitive.
Setting three is preferred by the average driver

during normal rain conditions.

NOTE:



The Rain Sensing feature will not operate when

wiper switch is in the low or high-speed position.



The Rain Sensing feature may not function prop

erly when ice or dried salt water is present on

the windshield.



Use of Rain-X or products containing wax or sili

cone may reduce Rain Sensing performance.



The Rain Sensing feature can be turned on and

off using the Uconnect system

page 150.

The Rain Sensing system has protection features

for the wiper blades and arms, and will not operate

under the following conditions:



Low Ambient Temperature — When the ignition

is first placed in the ON position, the Rain

Sensing system will not operate until the wiper

switch is moved, vehicle speed is greater than

3 mph (5 km/h) or the outside temperature is

greater than 32°F (0°C).



Transmission In NEUTRAL Position — When the

ignition is ON, and the transmission is in

NEUTRAL, the Rain Sensing system will not

operate until the wiper switch is moved, vehicle

speed is greater than 3 mph (5 km/h) or the

gear selector is moved out of the NEUTRAL posi

tion.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode.

EAR

INDOW

IPER

ASHER

The rear wiper/washer controls are located on the

windshield wiper/washer lever on the right side of

the steering column. The rear wiper/washer is

operated by rotating a switch, located at the

middle of the lever.

Rotate the center portion of the lever

upward to the first detent for intermittent

operation and to the second detent for

continuous rear wiper operation.
To use the washer, push the lever

forward and hold while spray is desired. If

the lever is pushed while in the

intermittent setting, the wiper will turn on

and operate for several wipe cycles after the end of

the lever is released, and then resume the

intermittent interval previously selected.
If the lever is pushed while the wiper is in the off

position, the wiper will operate for several wipe

cycles, then turn off.

NOTE:

As a protective measure, the pump will stop if the

switch is held for more than 20 seconds. Once the

lever is released the pump will resume normal

operation.
If the rear wiper is operating when the ignition is

placed in the OFF position, the wiper will

automatically return to the “park” position.

GETTING TO KNOW YOUR VEHICLE

INDSHIELD

IPER

-I

CER

—

QUIPPED

Your vehicle may be equipped with a Windshield

Wiper De-Icer feature that may be activated under

the following conditions:



Activation By Front Defrost — The Windshield

Wiper De-Icer shall be activated automatically in

the case of a cold weather manual start with full

front defrost, and when the ambient tempera

ture is below 33°F (0.6°C).



Activation By Rear Defrost — The Windshield

Wiper De-Icer shall be activated automatically

when the rear defrost is turned on and when the

ambient temperature is below 33°F (0.6°C).



Activation By Remote Start Operation — When

Remote Start is active and the outside ambient

temperature is less than 33°F (0.6°C), the

Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation.

If the Windshield Wiper De-Icer was active, the

timer and operation will continue.

CLIMATE CONTROLS

The Climate Control system allows you to regulate

the temperature, air flow, and direction of air

circulating throughout the vehicle. The controls are

located on the touchscreen (if equipped) and on

the instrument panel below the radio.

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 4C/4C NAV With 8.4-inch Display With

Automatic Temperature Controls

MAX A/C Button

Press and release the MAX A/C button on

the touchscreen to change the current

setting to the coldest output of air. The

MAX A/C indicator illuminates when MAX

A/C is on. Pressing the button again will cause the

MAX A/C operation to exit. In MAX A/C, the blower

level and mode position can be adjusted to the

desired user settings. Pressing other settings will

cancel MAX A/C.

NOTE:

The MAX A/C button is only available on the touch

screen.

A/C Button

Press and release this button on the

touchscreen, or push the button on the

faceplate to change the current setting.

The A/C indicator illuminates when A/C is

on. When the A/C system is on, cool, dehumidified

air will flow through the outlets into the cabin.

Recirculation Button

Press and release this button on the

touchscreen, or push the button on the

faceplate, to change the system between

Recirculation mode and outside air

mode. The Recirculation indicator and the A/C

indicator illuminate when the Recirculation button

is pressed. Recirculation can be used when

outside conditions, such as smoke, odors, dust, or

high humidity are present. Recirculation can be

used in all modes. Recirculation may be

unavailable (button on the touchscreen greyed

out) if conditions exist that could create fogging on

the inside of the windshield. The A/C can be

deselected manually without disturbing the mode

control selection. Continuous use of the

Recirculation mode may make the inside air stuffy

and window fogging may occur. Extended use of

this mode is not recommended. Recirculation

mode may automatically adjust to optimize

customer experience for warming, cooling,

dehumidification, etc.

GETTING TO KNOW YOUR VEHICLE

(Continued)

In cold weather, use of Recirculation mode may

lead to excessive window fogging. The

Recirculation feature may be unavailable if

conditions exist that could create fogging on the

inside of the windshield.

Auto Button

Set your desired temperature and press

AUTO. AUTO will achieve and maintain

your desired temperature by

automatically adjusting the blower speed

and air distribution. Air Conditioning (A/C) may be

active during AUTO operation to improve

performance. AUTO mode is highly recommended

for efficiency.
You can turn AUTO on in one of two ways:



Press and release this button on the touch

screen.



Push the button on the faceplate.

Toggling this function will cause the system to

switch between manual mode and automatic

mode

page 56.

Front Defrost Button

Press and release the Front Defrost

button on the touchscreen, or push and

release the button on the faceplate, to

change the current airflow setting to

Defrost mode. The Front Defrost indicator

illuminates when Front Defrost is on. Air comes

from the windshield and side window demist

outlets. When the defrost button is selected, the

blower level may increase. Use Defrost mode with

maximum temperature settings for best

windshield and side window defrosting and

defogging. When toggling the front defrost mode

button, the climate system will return to the

previous setting.

Rear Defrost Button

Press and release the Rear Defrost

button on the touchscreen, or push and

release the button on the faceplate, to

turn on the rear window defroster and the

heated outside mirrors (if equipped). The Rear

Defrost indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 10 minutes.

Driver And Passenger Temperature Up And

Down Buttons

These buttons provide the driver and

passenger with independent

temperature control.
Push the red button on the faceplate or

touchscreen or press and slide the

temperature bar towards the red arrow

button on the touchscreen for warmer

temperature settings.

Push the blue button on the faceplate or

touchscreen or press and slide the

temperature bar towards the blue arrow

button on the touchscreen for cooler

temperature settings.

NOTE:

The numbers within the temperature display will

only appear if the system is equipped with an auto

matic climate control system.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

CAUTION!

GETTING TO KNOW YOUR VEHICLE

SYNC Button

Press the SYNC button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator illuminates

when SYNC is on. SYNC synchronizes the

passenger temperature setting with the driver

temperature setting. Changing the passenger’s

temperature setting while in SYNC will

automatically exit this feature.

NOTE:

The SYNC button is only available on the touch

screen.

Blower Control

Blower Control regulates the amount of

air forced through the climate control

system. There are seven blower speeds

available. Adjusting the blower will cause

automatic mode to switch to manual operation.

The speeds can be selected using either the

blower control knob on the faceplate or the

buttons on the touchscreen.
Faceplate
The blower speed increases as you turn the blower

control knob clockwise from the lowest blower

setting. The blower speed decreases as you turn

the blower control knob counterclockwise.

Touchscreen
Use the small blower icon to reduce the blower

setting and the large blower icon to increase the

blower setting. Blower can also be selected by

pressing the blower bar area between the icons.

Mode Control

Select Mode by pressing one of the Mode

buttons on the touchscreen to change

the airflow distribution mode. The airflow

distribution mode can be adjusted so air

comes from the instrument panel outlets, floor

outlets, defrost outlets, and demist outlets.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Climate Control OFF Button

Press and release the OFF button on the

touchscreen, or push the OFF button on

the faceplate to turn the Climate Control

ON/OFF.

GETTING TO KNOW YOUR VEHICLE

ANUAL

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 4C/4C NAV With 8.4-inch Display With Manual

Temperature Controls

MAX A/C Button

Press and release the MAX A/C button on

the touchscreen to change the current

setting to the coldest output of air. The

MAX A/C indicator illuminates when MAX

A/C is on. Pressing the button again will cause the

MAX A/C operation to exit.

NOTE:

The MAX A/C button is only available on the touch

screen.

A/C Button

Press and release this button on the

touchscreen, or push the button on the

faceplate to change the current setting. The A/C

indicator illuminates when A/C is on.

NOTE:



For Manual Climate Controls, if the system is in

Mix, Floor or Defrost Mode, the A/C can be

turned off, but the A/C system shall remain

active to prevent fogging of the windows.



If fog or mist appears on the windshield or side

glass, select Defrost mode, and increase blower

speed if needed.



If your air conditioning performance seems

lower than expected, check the front of the A/C

condenser (located in front of the radiator), for

an accumulation of dirt or insects. Clean with a

gentle water spray from the front of the radiator

and through the condenser.

Recirculation Button

Press and release this button on the

touchscreen, or push the button on the

faceplate, to change the system between

Recirculation mode and outside air

mode. The Recirculation indicator and the A/C

indicator illuminate when the Recirculation button

is pressed. Recirculation can be used when

outside conditions, such as smoke, odors, dust, or

high humidity are present. Recirculation can be

used in all modes except Defrost. Recirculation

may be unavailable (button on the touchscreen

greyed out) if conditions exist that could create

fogging on the inside of the windshield. The A/C

can be deselected manually without disturbing the

mode control selection. Continuous use of the

Recirculation mode may make the inside air stuffy

and window fogging may occur. Extended use of

this mode is not recommended.
On systems with Manual Climate Controls, if

equipped, the Recirculation mode is not allowed in

Defrost mode to improve window clearing

operation. Recirculation is disabled automatically

if this mode is selected. Attempting to use

Recirculation while in this mode causes the LED in

the control button to blink and then turns off.

Front Defrost Button

Press and release the Front Defrost

button on the touchscreen, or push and

release the button on the faceplate, to

change the current airflow setting to

Defrost mode. The Front Defrost indicator

illuminates when Front Defrost is on. Air comes

from the windshield and side window demist

outlets. When the defrost button is selected, the

blower level may increase. Use Defrost mode with

maximum temperature settings for best

windshield and side window defrosting and

defogging. When toggling the front defrost mode

button, the climate system will return to the

previous setting.

GETTING TO KNOW YOUR VEHICLE

Rear Defrost Button

Press and release the Rear Defrost

button on the touchscreen, or push and

release the button on the faceplate, to

turn on the rear window defroster and the

heated outside mirrors (if equipped). The Rear

Defrost indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 10 minutes.

Driver And Passenger Temperature

Control Buttons

These buttons provide the driver and

passenger with independent

temperature control.
Push the red button on the faceplate or

touchscreen or press and slide the

temperature bar towards the red arrow

button on the touchscreen for warmer

temperature settings.

Push the blue button on the faceplate or

touchscreen or press and slide the

temperature bar towards the blue arrow

button on the touchscreen for cooler

temperature settings.

NOTE:

The numbers within the temperature display will

only appear if the system is equipped with an auto

matic climate control system.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator illuminates

when SYNC is on. SYNC synchronizes the

passenger temperature setting with the driver

temperature setting. Changing the passenger’s

temperature setting while in SYNC will

automatically exit this feature.

NOTE:

The SYNC button is only available on the touch

screen.

Blower Control

Blower Control regulates the amount of

air forced through the climate control

system. There are seven blower speeds

available. Adjusting the blower will cause

automatic mode to switch to manual operation.

The speeds can be selected using either the

blower control knob on the faceplate or the

buttons on the touchscreen.
Faceplate
The blower speed increases as you turn the blower

control knob clockwise from the lowest blower

setting. The blower speed decreases as you turn

the blower control knob counterclockwise.
Touchscreen
Use the small blower icon to reduce the blower

setting and the large blower icon to increase the

blower setting. Blower can also be selected by

pressing the blower bar area between the icons.

Mode Control

Select Mode by pressing one of the Mode

buttons on the touchscreen to change

the airflow distribution mode. The airflow

distribution mode can be adjusted so air

comes from the instrument panel outlets, floor

outlets, defrost outlets, and demist outlets.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Climate Control OFF Button

Press and release the OFF button on the

touchscreen, or push the OFF button on

the faceplate to turn the Climate Control

ON/OFF.

UTOMATIC

EMPERATURE

ONTROL

(ATC) — I

QUIPPED

Automatic Operation

1. Push the AUTO button on the faceplate, or the

AUTO button on the touchscreen on the

Automatic Temperature Control (ATC) Panel.

2. Next, adjust the temperature that you would

like the system to maintain by adjusting the

driver and passenger temperature control

buttons. Once the desired temperature is

displayed, the system will achieve and

automatically maintain that comfort level.

3. When the system is set up for your comfort

level, it is not necessary to change the

settings. You will experience the greatest

efficiency by simply allowing the system to

function automatically.

NOTE:



It is not necessary to move the temperature

settings for cold or hot vehicles. The system

automatically adjusts the temperature, mode,

and blower speed to provide comfort as quickly

as possible.



The temperature can be displayed in U.S. or

Metric units by selecting the US/Metric

customer-programmable feature within the

Uconnect system

page 150.

To provide you with maximum comfort in the

Automatic mode during cold start-ups, the blower

fan will remain on low until the engine warms up.

The blower will increase in speed and transition

into Auto mode.

Manual Operation Override

This system offers a full complement of manual

override features. The AUTO symbol in the front

ATC display will be turned off when the system is

being used in the manual mode.

Jeep Cherokee (2022 year). Manual in english - page 3
