Front scuff plate trim panel
6
—
Cowl side trim panel
7
—
B-pillar upper trim panel
8
—
B-pillar lower trim panel
9
—
Rear scuff plate trim panel
10
—
Lower C-pillar trim panel
11
—
Upper C-pillar trim panel
12
—
Parcel shelf
13
—
Folding Tray
14
Headliner
This section covers removal and installation of the interior mouldings and trim panels. In
many instances, one component overlaps another component. If this condition is found, it will
be necessary to loosen or remove the overlapping component before removal, to prevent
damage to either component. The pillar trims and the headliner are safety critical assemblies
as they mount the occupant sensors and interface with the side airbag curtains (to make sure
correct deployment is achieved), and as such, correct alignment and installation are necessary
for safety reasons.
The headliner is a one-piece design covering the entire interior of the roof and is made of a
moulded composite with cloth covering. Finger depressions give pull-down access for the sun
visors and passenger assist handles are provided.
There is an interior lamp fitted into the front of the overhead console.
