7B-64 Automatic Transmission (Smoother) 27. Install the heat protector bracket (1) and heat protector (2). Tighten: 45 N ⋅m (4.6 kg⋅m / 33.2 lb⋅ft) Protector 23 N ⋅m (2.3 kg⋅m / 17 lb⋅ft) 28. Apply engine oil to the O-ring, and then install the drain plug and O-ring. Tighten: ⋅m (4.0 kg⋅m / 28.8 lb⋅ft) 29. Apply 5W-30 engine oil to the O-ring, and then install the filler plug and O-ring. Tighten: ⋅m (4.0 kg⋅m / 28.8 lb⋅ft) 30. Install the parking brake assembly. • Refer to “Parking Brake”. 31. Apply engine oil to the O-ring, and then install the coupling driver and O-ring. 32. Using a new lock nut, use the flange holder (5- 8840-2043-0) to tighten the lock nut. Tighten: ⋅m (29.5 kg⋅m / 213.2 lb⋅ft) • After tightening the lock nut to the specified torque, stake it (2 points) securely using a × 60 degrees) so the lock nut lip gap is aligned Caution: N7A1084E N7A1083E N7A0294E |
