TIRE ROTATION
Tires should be rotated every 8,000 km (5,000miles). If you notice that tires are
wearing unevenly between rotations, have the car checked by a JAC dealer so
the cause may be corrected.
After rotating, adjust the tire pressure and be sure to check wheel nut tight鄄
ness.
NOTE:
荫
Do not mix biss-ply and radial-ply under any circumstances.
荫
In ace double rear wheel, the difference of outer diameter between outer
wheel and Inner wheel Is less than 12mm.
DOUBLE REAR AXLE
1. Front tire
2. Rear front tire
3. Rear reartire
Spare tire
174
OWNER爷S MANUAL
JAC HEAVY DUTY TRUCK
PRECAUTIONS BEFORE HIGH SPEED OPERATION
The higher the vehicle speed, the more heat the tires generate, and eventually
there is a danger or a burst.
The heat generated by the tires varies greatly with the tire pattern, tire inflation
pressure, load and speed. Pay attention to the following points.
荫
Keep the tires inflated at normal pressure.
荫
Avoid overloading.
The lug type pattem tires are not suited for high speed operation, as they tend
to skid. If your vehicle is equipped with the lug type tires, care should be tak鄄
en not to operate it at very high speed.
Exercise special car when controlling the steering wheel or applying brakes on
a wet road surface.
175
