1D2-12 COMPRESSOR OVERHAUL FOR TAIWAN 19. Pulley Assembly Using pulley installer and drive handle to install the 20. Cover (If so equipped) Install the snap ring with the inside indented portion 22. Shim(s) Install the drive plate to the compressor drive shaft 24. Drive Plate Bolt Using drive plate holder to prevent the drive plate Tighten: Drive plate bolt to 15 N ⋅m (0.5 kg⋅m / 11 lb⋅ft) N1A0117E N1A0118E N1A0119E N1A0120E |
