Maintenance

9-10

N

ormal M

ain

tenanc

e Schedule

MAINTENANCE



INTER

VALS

MAINTENANCE ITEM

Number o

f mon

ths or driving dis

tanc

e, whiche

ver c

omes fir

st

M

on

ths

12

24

36

48

60

72

84

96

108

120

132

144

156

168

180

Miles x 1,000

8

16

24

32

40

48

56

64

72

80

88

96

104

112

120

Km x 1,000

13

26

39

52

65

78

91

104

117

130

143

156

169

182

195

Cooling s

ys

tem

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Engine coolan

t / In

vert

er coolan

t

*6



 A

t fir

st, r

eplace a

t 120

,000 miles (200

,000 km

) or 120 mon

ths



Aft

er tha

t, r

eplace e

very 2

4,

000 miles (39

,000 km

) or 2

4 mon

ths

*7

All electrical s

ys

tems

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Dual clut

ch tr

ansmission fluid

*8



N

o check, no service r

equied

Engine clut

ch actua

tor fluid

R

eplace e

very 2

4,

000 miles (39

,000 km

) or 2

4 mon

ths



Inspect e

very 8,

000 miles (13,

000 km

) or 12 mon

ths

Engine clut

ch actua

tor hose and line

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Br

ak

e lines, hoses and connections

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Br

ak

e pedal

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Br

ak

e fluid

Inspect e

very 8,

000 miles (13,

000 km

) or 12 mon

ths,



and r

eplace e

very 48,

000 miles (78,

000 km

) or 48 mon

ths

Br

ak

e discs and pads

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I : Inspect and if necessary

, adjus

t, corr

ect, clean or r

eplace.

R : R

eplace or change.

*6 :



When adding coolan

t, use only deioniz

ed w

at

er or so

ft w

at

er f

or y

our v

ehicle and ne

ver mix har

d w

at

er in the coolan

t filled a

t

the f

act

ory

.

*7 :



For y

our con

venience, it can be r

eplaced prior t

o it’

s in

terv

al when y

ou do main

tenance o

f o

ther it

ems.

*8 :



Dual Clut

ch T

ransmission (DCT) fluid should be changed an

ytime it has been submer

ged in w

at

er

.

09

9-11

N

ormal M

ain

tenanc

e Schedule

MAINTENANCE



INTER

VALS

MAINTENANCE ITEM

Number o

f mon

ths or driving dis

tanc

e, whiche

ver c

omes fir

st

M

on

ths

12

24

36

48

60

72

84

96

108

120

132

144

156

168

180

Miles x 1,000

8

16

24

32

40

48

56

64

72

80

88

96

104

112

120

Km x 1,000

13

26

39

52

65

78

91

104

117

130

143

156

169

182

195

St

eering gear r

ack, link

age and boo

ts

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Driv

esha

ft and boo

ts

I

I

I

I

I

I

I

R

ota

te Tir

es (Includes Tir

e Pr

essur

e and T

read W

ear

Inspection

)

R

ota

te e

very 8,

000 miles (13,

000 km

) or 12 mon

ths

Fr

on

t suspension ball join

ts

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Bolt and nuts on chassis and body

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Air conditioner r

efriger

an

t

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Air conditioner compr

essor

I

I

I

I

I

I

I

I

I

I

I

I

I

I

I

Cabin air filt

er

I

R

I

R

I

R

I

R

I

R

I

R

I

R

I

Exhaus

t s

ys

tem

I

I

I

I

I

I

I

I

I : Inspect and if necessary

, adjus

t, corr

ect, clean or r

eplace.

R : R

eplace or change.

Maintenance

9-12

Maintenance Under Severe Usage Conditions

The following items must be serviced more frequently on cars mainly used under severe

driving conditions. Refer to the chart below for the appropriate maintenance intervals.

R : Replace

I : Inspect and if necessary, adjust, correct, clean or replace

Maintenance item

Maintenance

operation

Maintenance Intervals

Driving

condition

Engine oil and engine oil filter

R

Replace every 3,750

miles (6,000 km)

or 6 months

A, B, C, D, E, F,

G, H, I, J, K, L

Air cleaner filter

R

Replace more

frequently depending

on the condition

C, E

Spark plugs

R

Replace more

frequently depending

on the condition

A, B, F, G, H,

I, K

HSG (Hybrid Starter &

Generator) belt

R

Every 30,000 miles

(48,000 km) or 24

months

B, C, D, E, I, K

I

Every 5,000 miles

(8,000 km) or 6 months

Dual clutch transmission fluid

R

Every 80,000 miles

(120,000 km)

C, D, E, F, G,

H, I, J

09

9-13

Maintenance Under Severe Usage Conditions

Maintenance item

Maintenance

operation

Maintenance Intervals

Driving condition

Steering gear rack,

linkage and boots

I

Inspect more frequently

depending on the

condition

C, D, E, F, G

Front suspension ball

joints

I

Inspect more frequently

depending on the

condition

C, D, E, F, G

Disc brakes and pads,

calipers and rotors

I

Inspect more frequently

depending on the

condition

C, D, E, G, H

Parking brake

I

Inspect more frequently

depending on the

condition

C, D, G, H

Driveshaft and boots

I

Inspect more frequently

depending on the

condition

C, D, E, F, G, H, I, J

Cabin air filter

R

Replace more frequently

depending on the

condition

C, E, G

Severe driving conditions

A.  Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature

or less than 10 miles (16 km) in freezing temperature

B.  Extensive engine idling or low speed driving for long distances
C. Driving on rough, dusty, muddy, unpaved, graveled or salt-spread roads
D. Driving in areas using salt or other corrosive materials or in very cold weather
E.  Driving in heavy dust conditions
F.  Driving in heavy traffic area
G. Driving on uphill, downhill, or mountain roads repeatedly
H. Using for towing or camping, and driving with loading on the roof.
I.  Driving for patrol car, taxi, other commercial use of vehicle towing
J.  Frequently driving under high speed or rapid acceleration.
K.  Frequently driving in stop-and-go conditions
L.  Engine oil usage which is not recommended (Mineral type, Semi-synthetic, Lower

grade spec, etc.)

Maintenance

9-14

Engine Oil and Filter

The engine oil and filter should be

changed at the intervals specified in the

maintenance schedule. If the vehicle

is being driven in severe conditions,

more frequent oil and filter changes are

required.

Drive Belts

Inspect all drive belts for evidence

of cuts, cracks, excessive wear or oil

saturation and replace if necessary. Drive

belts should be checked periodically

for proper tension and adjusted as

necessary.

Fuel Filter

A clogged-up fuel filter may limit the

vehicle driving speed, damage the

emission system, and cause the hard

starting. When a considerable amount

of foreign substances are accumulated

in the fuel tank, the fuel filter should be

replaced.
Upon installing a new fuel filter, operate

the engine for several minutes, and

check the connections for any leakages.

Fuel filters should be installed by an

authorized HYUNDAI dealer.

HSG (Hybrid Starter & Generator)

Belt

The HSG belt should be changed at the

intervals specified in the maintenance

schedule.

Fuel Lines, Fuel Hoses and

Connections

Check the fuel lines, fuel hoses and

connections for leakage and damage.

Have an authorized HYUNDAI dealer

replace any damaged or leaking parts

immediately.

Vapor Hose and Fuel Filler Cap

The vapor hose and fuel filler cap should

be inspected at those intervals specified

in the maintenance schedule. Make sure

a new vapor hose or fuel filler cap is

correctly replaced.

Air Cleaner Filter

A genuine HYUNDAI air cleaner filter

is recommended when the filter is

replaced.

Spark Plugs

Make sure to install new spark plugs of

the correct heat range.
When assembling parts, be sure to

wipe out foreign substances inside

and outside of the boot bottom of the

ignition coil and the insulator of the

spark plug with a soft cloth to prevent

contamination of the spark plug

insulator.

Cooling System

Check cooling system components, such

as radiator, coolant reservoir, hoses and

connections for leakage and damage.

Replace any damaged parts.

EXPLANATION OF SCHEDULED MAINTENANCE ITEMS

09

9-15

Engine Coolant/Inverter Coolant

The coolant should be changed at the

intervals specified in the maintenance

schedule.

Dual Clutch Transmission Fluid

Dual clutch transmission fluid should

not be checked under normal usage

conditions.
Have Intelligent variable transmission

fluid changed by an authorized HYUNDAI

dealer according to the maintenance

schedule.

Brake Hoses and Lines

Visually check for proper installation,

chafing, cracks, deterioration and any

leakage. Replace any deteriorated or

damaged parts immediately.

Brake Fluid

Check the brake fluid level in the brake

fluid reservoir. The level should be

between the MIN and the MAX marks

on the side of the reservoir. Use only

hydraulic brake fluid conforming to DOT

4 specification..

Brake Discs, Pads, Calipers and

Rotors

Check the pads for excessive wear, discs

for run out and wear, and calipers for

fluid leakage.

Suspension Mounting Bolts

Check the suspension connections for

looseness or damage. Retighten to the

specified torque.

Steering Gear Box, Linkage &

Boots/Lower Arm Ball Joint

With the vehicle stopped and the engine

off, check for excessive freeplay in the

steering wheel. Check the linkage for

bends or damage. Check the dust boots

and ball joints for deterioration, cracks,

or damage.
Replace any damaged parts.

Drive Shafts and Boots

Check the drive shafts, boots and clamps

for cracks, deterioration, or damage.

Replace any damaged parts and, if

necessary, repack the grease.

Air Conditioning Refrigerant

Check the air conditioning lines and

connections for leakage and damage.

Maintenance

9-16

Checking the Engine Oil Level

Engine oil is used for lubrication and

cooling, so it is gradually consumed

during driving the vehicle.
Regularly check and manage the oil level

using the following procedure.
1.  Follow all of the oil manufacturer’s

precautions.

2.  Be sure the vehicle is on the level

ground in P (Park) with the parking

brake set. If possible, block the

wheels.

3.  Turn the engine on and allow the

engine to reach normal operating

temperature.

4.  Turn the engine off and wait about 15

minutes (with oil filler cap and dipstick

detached) for the oil to return to the

oil pan.

5.  Pull the dipstick out, wipe it clean, and

re-insert it fully.

OCN7H090003

6.  Pull the dipstick out again and

checkthe level.

OCN7H090004

7.  If the oil level is below L, add

enoughoil to bring the level to F.

Use only the specified engine oil. (refer

to “Recommended Lubricants and

Capacities” in chapter 2).

ENGINE OIL

09

9-17

NOTICE

To prevent damage to your engine:

•

Do not spill engine oil when adding

or changing engine oil. Wipe off

spilled oil immediately.

•

The engine oil consumption may

increase while you break in a new

vehicle and it will be stabilized after

driving 4,000 miles (6,000 km).

•

The engine oil consumption can be

affected by driving habits, climate

conditions, traffic conditions, oil

quality, etc. Therefore, inspect the

engine oil level regularly and refill it

if necessary.

•

The engine oil change interval is

set for the purpose of preventing

oil deterioration, and is not related

the amount of oil consumption; so,

check and refill the amount of the oil

regularly.

Checking the Engine Oil and

Filter

•

Have engine oil and filter changed

by an authorized HYUNDAI dealer

according to the Maintenance

Schedule at the beginning of this

chapter.

•

If exceeding the maintenance

schedule for replacement of engine

oil, the engine oil performance

may deteriorate and the engine

condition may be affected. Therefore,

the replacement cycle should be

observed.

•

If the maintenance schedule to

replace engine oil is exceeded,

the engine oil performance may

deteriorate, and the engine condition

may be affected. Therefore, replace

the engine oil according to the

maintenance schedule.

•

To keep the engine in optimal

condition, use the recommended

engine oil and filter. If the

recommended engine oil and filter are

not used, replace it according to the

maintenance schedule under severe

usage conditions.

•

The purpose of the maintenance

schedule for engine oil replacement

is to prevent oil deterioration and it is

irrelevant to oil consumption. Check

and refill engine oil regularly.

Maintenance

9-18

 CAUTION

The engine oil is very hot immediately

after the vehicle has been driven and

can cause burns during replacement.

Replace the engine oil after the engine

oil has cooled down.

 WARNING

CALIFORNIA PROPOSITION 65

WARNING
Engine oil contains chemicals known to

the State of California to cause cancer,

birth defects and reproductive harm.

Used engine oil may cause irritation or

cancer of the skin if left in contact with

the skin for prolonged periods of time.

Always protect your skin by washing

your hands thoroughly with soap and

warm water as soon as possible after

handling used oil.

NOTICE

Never add any additives to the engine

oil. Engine oil additives can change the

properties of engine oil and may cause

serious engine failure.

09

9-19

The high-pressure cooling system has a

reservoir filled with year-round antifreeze

coolant. The reservoir is filled at the

factory.
Check the antifreeze protection and

coolant level at least once a year, at

the beginning of the winter season and

before traveling to a colder climate.

NOTICE

•

When the engine overheats by low

level of the engine coolant, suddenly

adding engine coolant may cause

cracks in the engine. To prevent

damage, add engine coolant slowly

in small quantities.

•

Do not drive with no engine coolant.

It may cause water pump failure and

engine seizure, etc.

Checking the Coolant Level

OCN7H090005

„

„

Engine coolant

OCN7H093006

„

„

Inverter coolant

Check the condition and connections

of all cooling system hoses and

heater hoses. Replace any swollen or

deteriorated hoses.
The coolant level should be filled

between the MAX and the MIN marks on

the side of the coolant reservoir when

the engine is cool.
If the coolant level is low, add the

selected anti-freeze according to the

proper coolant mix ratio to bring the level

to the MAX mark, but do not overfill. If

frequent additions are required, see an

authorized HYUNDAI dealer for a cooling

system inspection.

ENGINE COOLANT/INVERTER COOLANT

Maintenance

9-20

 WARNING

OCN7H090007

„

„

Engine coolant cap

OCN7H093008

„

„

Inverter coolant cap

1.  Check if the radiator cap label is

straight In front.

2.  Make sure that the tiny protrusions

inside the radiator cap should be

securely interlocked.

 WARNING

Never remove the engine

coolant cap and/or inverter

coolant cap or the drain plug

while the engine and radiator

are hot. Hot coolant and steam

may blow out under pressure,

causing serious injury.

Turn the vehicle off and wait until

the engine cools down. Use extreme

care when removing the engine

coolant cap and/or inverter coolant

cap. Wrap a thick towel around it,

and turn it counterclockwise slowly

while the pressure is released from

the cooling system. When you are sure

all the pressure has been released,

using a thick towel, continue turning

counterclockwise to remove it.

 Information

The engine coolant and/or inverter coolant

level is influenced by the hybrid system

temperature. Before checking or refilling

the engine coolant and/or inverter coolant,

turn the hybrid vehicle off.

 WARNING

The electric motor for the

cooling fan may continue to

operate or start up when the

engine is not running and can

cause serious injury. Keep

hands, clothing and tools away

from the rotating fan blades of

the cooling fan.

Keep hands, clothing and tools away

from the rotating fan blades of the

cooling fan.
Always turn off the vehicle unless the

vehicle has to be inspected with the

engine on. Be cautious as the cooling

fan may operate until you disconnect

the battery connector.

09

9-21

 WARNING

Make sure the coolant cap is properly

closed after refilling coolant. Otherwise

the engine could be overheated while

driving.

„

„

Engine compartment front view

OOSH089010L

1.  Check if the coolant cap label is

straight In front.

„

„

Engine compartment rear view

OCN7H090009

2.  Make sure that the tiny protrusions

inside the coolant cap are securely

interlocked.

Recommended engine coolant

•

When adding coolant, use only

distilled (deionized) water for your

vehicle and never mix hard water in

the coolant filled at the factory.

•

An improper coolant mixture can

result in severe malfunction or engine

damage.

•

The engine in your vehicle has

aluminum engine parts and must be

protected by an ethylene-glycol with

phosphate based coolant to prevent

corrosion and freezing.

•

Do not use alcohol or methanol

coolant or mix them with the specified

coolant.

•

Do not use a solution that contains

more than 60% antifreeze or less than

35% antifreeze, which would reduce

the effectiveness of the solution.

For mixing percentage, refer to the

following table:

Ambient

Temperature

Mixture Percentage

(volume)

Antifreeze

Water

5°F (-15°C)

35

65

-13°F (-25°C)

40

60

-31°F (-35°C)

50

50

-49°F (-45°C)

60

40

 Information

If in doubt about the mix ratio, a 50%

water and 50% antifreeze mix is the

easiest to mix together as it will be the

same quantity of each. It is suitable to use

for most temperature ranges of - 31°F and

higher.

Maintenance

9-22

 WARNING

The electric motor for the

cooling fan may continue to

operate or start up when the

engine is not running and can

cause serious injury. Keep

hands, clothing and tools away

from the rotating fan blades of

the cooling fan.

The electric motor for the cooling

fan is controlled by engine coolant

temperature, refrigerant pressure and

vehicle speed. As the engine coolant

temperature decreases, the electric

motor will automatically shut off. This is a

normal condition.

Changing Engine Coolant

Have coolant changed by an authorized

HYUNDAI dealer according to the

Maintenance Schedule at the beginning

of this chapter.

 WARNING

Do not use engine coolant or antifreeze

in the washer fluid reservoir.
Engine coolant can severely obscure

visibility when sprayed on the

windshield and may cause loss of

vehicle control resulting in an accident.
Engine coolant may also cause damage

to paint and body trim.

NOTICE

To prevent damage to engine parts, put

a thick towel around the radiator cap

before refilling the coolant to prevent

the coolant from overflowing into

engine parts, such as the alternator.

09

9-23

Checking the Hybrid Starter &

Generator (HSG) Belt

Have the Hybrid Starter & Generator

(HSG) belt inspected or replaced

according to the Maintenance Schedule

in this chapter by an authorized

HYUNDAI dealer.

 CAUTION

When the HSG belt is worn out or

damaged, replace the belt.
Otherwise, it may cause engine

overheating or battery discharge.

 WARNING

•

Turn the vehicle off while you inspect

the engine or Hybrid Starter &

Generator (HSG) belt. Otherwise it

may result in serious injury.

•

Keep hands, clothing etc. away from

the Hybrid Starter & Generator (HSG)

belt.

HYBRID STARTER & GENERATOR (HSG) BELT

Maintenance

9-24

Checking the Brake Fluid Level

OCN7H090010

Check the fluid level in the reservoir

periodically. The fluid level should be

between MAX and MIN marks on the side

of the reservoir.
Before removing the reservoir cap and

adding brake fluid, clean the area around

the reservoir cap thoroughly to prevent

brake fluid contamination.
If the level is low, add fluid to the MAX

level. The level will fall with accumulated

mileage. This is a normal condition

associated with the wear of the brake

linings.
If the fluid level is excessively low, have

the system checked by an authorized

HYUNDAI dealer.

 Information

Use only the specified brake fluid. Refer to

“Recommended lubricants and capacities”

in chapter 2.

 Information

Before removing the brake filler cap, read

the warning on the cap.

 Information

Clean the filler cap before removing. Use

only DOT4 brake fluid from a sealed

container.

 WARNING

Do not let brake fluid enter into your

eyes. If brake fluid gets in your eyes,

flush your eyes with clean water for

at least 15 minutes and get immediate

medical attention.

NOTICE

•

Do not allow brake fluid to contact

the vehicle’s body paint, as it will

result in paint damage.

•

NEVER use brake fluid which has

been exposed to open air for an

extended time, as its quality cannot

be guaranteed.

•

Don’t put in the wrong type of fluid.

A few drops of mineralbased oil such

as engine oil in your brake system

can damage system parts.

•

To maintain the best braking

performance and ABS/ESC

performance, use genuine brake

fluid that conform to specifications.
(Standard : SAE J1704 DOT-4 LV,

ISO4925 CLASS-6 and FMVSS 116

DOT-4)

BRAKE FLUID

09

9-25

Checking the Engine Clutch

Actuator Fluid Level

OCN7H093050N

In normal driving conditions, the

actuator fluid level does not go down

rapidly. However, oil consumption rate

may rise as vehicle mileage increases,

and leak-age in actuator related parts

may result in increased consumption of

the engine clutch actuator oil. Regularly

check and make sure the engine clutch

actuator oil fluid level is between MIN

and MAX marks.
If the oil level is below MIN mark, have

the vehicle checked by an authorized

Hyundai dealer.
If the fluid level is excessively low, have

the system checked by an authorized

Hyundai dealer.
Use only the specified engine clutch

actuator fluid. (Refer to “Recommended

lubricants and capacities” on page 2-12.)
Never mix different types of fluid.

•

Check the fluid level in the engine

clutch actuator fluid reservoir and add

fluid if necessary.

The reservoir is translucent so that you

can check the level with a quick visual

inspection.

 CAUTION

Do not allow the engine clutch actuator

fluid to contact the vehicle’s body paint,

as paint damage will result. The engine

clutch actuator fluid, which has been

exposed to open air for an extended

time should never be used as its quality

cannot be guaranteed. It should be

properly disposed. Don’t put in the

wrong kind of fluid. A few drops of

mineral-based oil, such as engine oil, in

your engine clutch system can damage

engine clutch system parts.

 WARNING

•

In the event the engine clutch system

requires frequent additions of fluid,

have the system inspected by an

authorized Hyundai dealer.

•

When changing and adding the

engine clutch actuator fluid, handle

it carefully. Do not let it come in

contact with your eyes. If engine

clutch actuator fluid should come in

contact with your eyes, immediately

flush them with a large quantity

of fresh tap water. Have your eyes

examined by a doctor as soon as

possible.

ENGINE CLUTCH ACTUATOR FLUID

Maintenance

9-26

Checking the Washer Fluid Level

OCN7080007

Check the fluid level in the washer fluid

reservoir and add fluid if necessary. Plain

water may be used if washer fluid is not

available. However, use washer solvent

with antifreeze characteristics in cold

climates to prevent freezing.

 WARNING

To prevent serious injury or death, take

the following safety precautions when

using washer fluid:

•

Do not use engine coolant or

antifreeze in the washer fluid

reservoir.
Engine coolant can severely obscure

visibility when sprayed on the

windshield and may cause loss

of vehicle control resulting in an

accident or damage to paint and

body trim.

•

Do not allow sparks or flames to

contact the washer fluid or the

washer fluid reservoir. Washer fluid

may contain alcohol and can be

flammable.

•

Do not drink washer fluid and avoid

contact with skin. Washer fluid is

harmful to humans and animals.

•

Keep washer fluid away from

children and animals.

WASHER FLUID

Filter Replacement

OCN7H093011

The air cleaner filter can be cleaned for

inspection using compressed air. Do not

attempt to wash or to rinse it, as water

will damage the filter. If soiled, the air

cleaner filter must be replaced.

OCN7H090012

1.  Loosen the air cleaner cover attaching

clip (1) and open the cover.

AIR CLEANER

09

9-27

OCN7H090013

OCN7H090023

2.  Replace the air cleaner filter. Insert (2)

completely into (3).

OCN7H090022

OCN7H090021

3.  Insert the air cleaner cover in the

hinge (4) and engage the clip (5) after

closing the cover.

4.  Check that the cover is firmly

installed.

 Information

If the vehicle is operated in extremely

dusty or sandy areas, replace the element

more often than the usual recommended

intervals (refer to “Maintenance Under

Severe Usage Conditions” in this chapter).

NOTICE

•

Do not drive with the air cleaner filter

removed. This will result in excessive

engine wear.

•

When removing the air cleaner filter,

be careful that dust or dirt does not

enter the air intake, or damage may

result.

•

Use HYUNDAI genuine parts. Use of

non-genuine parts could damage the

engine.

Maintenance

9-28

Filter Inspection

The cabin air filter should be replaced

according to the Maintenance Schedule.

If the vehicle is operated in severely

air-polluted cities or on dusty rough

roads for a long period, it should be

inspected more frequently and replaced

earlier. When you replace the cabin air

filter, replace it performing the following

procedure, and be careful to avoid

damaging other components.

Filter Replacement

OCN7080013

1.  Push in both sides of the glove box as

shown. This will ensure that the glove

box stopper pins will get released

from its holding location allowing the

glove box to hang.

OCN7080014

2.  Remove the cabin air filter case while

pressing the lock on the right side of

the cover.

OIK077021

3.  Replace the cabin air filter.
4.  Reassemble in the reverse order of

disassembly.

NOTICE

Install a new cabin air filter in the correct

direction with the arrow symbol (↓)

facing downwards, otherwise, it may be

noisy and the effectiveness of the filter

may be reduced.

CABIN AIR FILTER

09

9-29

Blade Inspection

Contamination of either the windshield

or the wiper blades with foreign matter

can reduce the effectiveness of the

windshield wiper functionality. Common

sources of contamination are insects,

tree sap, and hot wax treatments used

by some commercial car washes. If the

blades are not wiping properly, clean

both the window and the blades with a

clean cloth dampened with washer fluid.

NOTICE

To prevent damage to the wiper blades,

arms or other components, do not:

•

Use gasoline, kerosene, paint

thinner, or other solvents on or near

them.

•

Attempt to move the wipers

manually.

•

Use non-specified wiper blades.

 Information

Commercial hot waxes applied by

automatic car washes have been known to

make the windshield difficult to clean.

Blade Replacement

When the wipers no longer clean

adequately, the blades may be worn or

cracked, and require replacement.

NOTICE

•

In order to prevent damage to the

hood and the wiper arms, the wiper

arms should only be lifted when in

the top wiping position.

•

Always return the wiper arms to the

windshield before driving.

NOTICE

The use of a non-specified wiper blade

could result in wiper malfunction and

failure.

WIPER BLADES

Maintenance

9-30

Front windshield wiper service

positions

OCN7080015

This vehicle has a “hidden” wiper design

which means that the wipers cannot

be lifted when they are in their bottom

resting position.
1.  Within 20 seconds of turning off the

engine, lift and hold the wiper lever

up to the MIST position for about 2

seconds until the wipers move to the

top wipe position.

2.  At this time you can lift the wipers off

the windshield.

3.  Gently put the wipers back down onto

the windshield.

4.  Turn the wipers to any ON position

to return the wipers to the bottom

resting position.

OGSR076067

1.  Raise the wiper arm.

OGSR076066

2.  Lift up the wiper blade clip. Then pull

down the blade assembly and remove

it.

OGSR076068

3.  Install the new blade assembly.
4.  Return the wiper arm on the

windshield.

09

9-31

12 V auxiliary battery

The 12 V auxiliary battery of the vehicle

is integrated within the high-voltage

battery. The high-voltage battery is

located under the seat cushion.
For battery related servicing, contact an

authorized HYUNDAI dealer.

12 V auxiliary battery connector

OCN7H092032

Disconnect the 12 V auxiliary battery

connector located inside the engine

room compartment to shut down the

power of the 12 V auxiliary battery.
Connect the 12 V auxiliary battery

connector again after the battery related

maintenance is finished.

 CAUTION

•

The efficiency of the battery

decreases during low temperature.

If the vehicle is not used for the

extended period of time, park the

vehicle indoors if possible.

•

Always keep the battery charged to

the full capacity. The battery case

may damage due to freezing if the

battery capacity is low.

•

Do not install unauthorized electrical

devices (for example, lamps,

dashcam, etc.) to a vehicle. It may

discharge the battery.

BATTERY

Maintenance

9-32

 WARNING

Tire failure may cause loss of

vehicle control resulting in an

accident. To reduce risk of SERIOUS

INJURY or DEATH, take the

following precautions:

•

Inspect your tires monthly for

proper inflation as well as wear

and damage.

•

The recommended cold tire

pressure for your vehicle can be

found in this manual and on the

tire label located on the driver’s

side center pillar. Always use a

tire pressure gauge to measure

tire pressure. Tires with too

much or too little pressure wear

unevenly causing poor handling.

•

Check the pressure of the

spare every time you check the

pressure of the other tires on

your vehicle.

•

Replace tires that are worn, show

uneven wear, or are damaged.

Worn tires can cause loss of

braking effectiveness, steering

control, or traction.

•

ALWAYS replace tires with

the same type, size, brand,

construction and tread pattern

as each tire that was originally

supplied with this vehicle. Using

tires and wheels other than the

recommended sizes could cause

unusual handling characteristics,

poor vehicle control, or

negatively affect your vehicle’s

Anti-Lock Brake System (ABS)

resulting in a serious accident.

Tire Care

For proper maintenance, safety, and

maximum fuel economy, you must

always maintain recommended

tire inflation pressures and stay

within the load limits and weight

distribution recommended for your

vehicle.

OCN7010009L

All specifications (sizes and

pressures) can be found on a label

attached to the driver’s side center

pillar.

Recommended Cold Tire

Inflation Pressures

All tire pressures (including the

spare) should be checked when the

tires are cold. “Cold tires” means the

vehicle has not been driven for at

least three hours or has been driven

for less than one mile (1.6 km).
Warm tires normally exceed

recommended cold tire pressures

by 4 to 6 psi (28 to 41 kPa). Do not

release air from warm tires to adjust

the pressure or the tires will be

under-inflated. For recommended

inflation pressure, refer to “Tire and

Wheels” in chapter 2.

TIRES AND WHEELS

09

9-33

 WARNING

Recommended pressures must be

maintained for the best ride, vehicle

handling, and minimum tire wear.
Over-inflation or under-inflation

can reduce tire life, adversely

affect vehicle handling, and lead to

sudden tire failure that could result

in loss of vehicle control resulting in

an accident.
Severe under-inflation can lead

to severe heat build-up, causing

blowouts, tread separation and

other tire failures that can result in

the loss of vehicle control resulting

in an accident. This risk is much

higher on hot days and when

driving for long periods at high

speeds.

 CAUTION

•

Under-inflation results in

excessive wear, poor handling

and reduced fuel economy.

Wheel deformation is also

possible. Keep your tire pressures

at the proper levels. If a tire

frequently needs refilling, have

it checked by an authorized

HYUNDAI dealer.

•

Over-inflation produces a harsh

ride, excessive wear at the center

of the tire tread, and a greater

possibility of damage from road

hazards.

Check Tire Inflation Pressure

Check your tires, including the spare

tire, once a month or more.

How to check

Use a good quality tire pressure

gauge to check tire pressure. You

can not tell if your tires are properly

inflated simply by looking at them.

Radial tires may look properly

inflated when they are under-

inflated.
Remove the valve cap from the tire

valve stem. Press the tire gauge

firmly onto the valve to get a

pressure measurement. If the cold

tire inflation pressure matches the

recommended pressure on the tire

label located on the driver’s side

center pillar or in this manual. No

further adjustment is necessary. If

the pressure is low, add air until you

reach the recommended pressure.

Make sure to put the valve caps

back on the valve stems. Without

the valve cap, dirt or moisture could

get into the valve core and cause

air leakage. If a valve cap is missing,

install a new one as soon as possible.
If you overfill the tire, release air by

pushing on the metal stem in the

center of the tire valve. Recheck the

tire pressure with the tire gauge. Be

sure to put the valve caps back on

the valve stems. Without the valve

cap, dirt or moisture could get into

the valve core and cause air leakage.

If a valve cap is missing, install a new

one as soon as possible.
A cold tire means the vehicle has

been sitting for 3 hours and driven

for less than 1 mile (1.6 km) in that 3

hour period.
Allow the tire to cool before

measuring the inflation pressure.

Always be sure the tire is cold before

inflating to the recommended

pressure.

Maintenance

9-34

Tire Rotation

To equalize tread wear, HYUNDAI

recommends that the tires

be rotated according to the

maintenance schedule or sooner if

irregular wear develops.
During rotation, check the tires for

correct balance.
When rotating tires, check for

uneven wear and damage. Abnormal

wear is usually caused by incorrect

tire pressure, improper wheel

alignment, out-of-balance wheels,

severe braking or severe cornering.

Look for bumps or bulges in the

tread or side of the tire. Replace

the tire if you find any of these

conditions. Replace the tire if fabric

or cord is visible. After rotation, be

sure to bring the front and rear tire

pressures to specification and check

lug nut tightness (proper torque is

79~94 lbf·ft [11~13 kgf·m]).

OHI078078

Disc brake pads should be inspected

for wear whenever tires are rotated.

 Information

Tires that are asymmetrical or

directional can only be installed

on the wheel in one direction.

The outside and inside of an

asymmetrical tire is not easily

distinguishable. Pay careful

attention to the markings on the

sidewalls of the tires, noting the

“outside” marking and also the

rotating direction before installing

them on the vehicle.

 WARNING

•

Do not use the compact spare

tire for tire rotation.

•

Do not mix bias ply and radial ply

tires under any circumstances.

This may cause unusual handling

characteristics that may cause

loss of vehicle control resulting in

an accident.

09

9-35

Wheel Alignment and Tire

Balance

The wheels on your vehicle were

aligned and balanced carefully at the

factory to give you the longest tire

life and best overall performance.
In most cases, you will not need to

have your wheels aligned again.

However, if you notice unusual tire

wear or your vehicle pulling one way

or the other, the alignment may need

to be reset.
If you notice your vehicle vibrating

when driving on a smooth road, your

wheels may need to be rebalanced.

NOTICE

Improper wheel weights can

damage your vehicle’s aluminum

wheels. Use only approved wheel

weights.

Tire Replacement

Tread wear indicator

Tread wear indicator

OLMB073027

If the tire is worn evenly, a tread wear

indicator will appear as a solid band

across the tread. This shows there is

less than 1/16 inch (1.6 mm) of tread

left on the tire. Replace the tire when

this happens.
Do not wait for the tread surface to

become level with the tread wear

indicators before replacing the tire.

Maintenance

9-36

 WARNING

To reduce the risk of DEATH or

SERIOUS INJURY:

•

Replace tires that are worn, show

uneven wear, or are damaged.

Worn tires can cause loss of

braking effectiveness, steering

control, and traction.

•

Always replace tires with the

same size as each tire that was

originally supplied with this

vehicle. Using tires and wheels

other than the recommended

sizes could cause unusual

handling characteristics, poor

vehicle control, or negatively

affect your vehicle’s Anti-Lock

Brake System (ABS) resulting in a

serious accident.

•

Tires degrade over time, even

when they are not being used.

Regardless of the remaining

tread, HYUNDAI recommends

that tires be replaced after six (6)

years of normal service.

•

When replacing tires, it is

recommended to replace the

two front or two rear tires as a

pair. Replacing just one tire can

seriously affect your vehicle’s

handling. If only replacing one

pair of tires, it is recommended

to install the pair of new tires on

the rear axle.

•

Heat caused by hot climates or

frequent high loading conditions

can accelerate the aging process.

Failure to follow this warning

may cause sudden tire failure,

which could lead to a loss of

vehicle control resulting in an

accident.

Compact spare tire replacement

A compact spare tire has a shorter

tread life than a regular size tire.

Replace it when you can see the

tread wear indicator bars on the tire.

The replacement compact spare tire

should be the same size and design

tire as the one provided with your

new vehicle and should be mounted

on the same compact spare tire

wheel. The compact spare tire is

not designed to be mounted on a

regular size wheel, and the compact

spare tire wheel is not designed for

mounting a regular size tire.

 WARNING

The original tire should be repaired

or replaced as soon as possible to

avoid failure of the spare and loss

of vehicle control resulting in an

accident. The compact spare tire

is for emergency use only. Do not

operate your vehicle over 50 mph

(80 km/h) when using the compact

spare tire.

09

9-37

Wheel Replacement

When replacing the metal wheels

for any reason, make sure the new

wheels are equivalent to the original

factory units in diameter, rim width

and offset.

Tire Traction

Tire traction can be reduced if you

drive on worn tires, tires that are

improperly inflated or on slippery

road surfaces. Tires should be

replaced when the tread depth is at

least 2/32 inch (1.6 mm). To reduce

the possibility of losing control, slow

down whenever there is rain, snow

or ice on the road.

Tire Maintenance

In addition to proper inflation,

correct wheel alignment helps to

decrease tire wear. If you find a tire

is worn unevenly, have your dealer

check the wheel alignment.
When you have new tires installed,

make sure they are balanced. This

will increase vehicle ride comfort

and tire life. Additionally, a tire

should always be rebalanced if it is

removed from the wheel.

Tire Sidewall Labeling

This information identifies and

describes the fundamental

characteristics of the tire and also

provides the tire identification

number (TIN) for safety standard

certification. The TIN can be used to

identify the tire in case of a recall.

B0464EU01

1.  Manufacturer or brand name

Manufacturer or brand name is

shown.

2.  Tire size designation

A tire’s sidewall is marked with a

tire size designation. You will need

this information when selecting

replacement tires for your car.

The following explains what the

letters and numbers in the tire size

designation mean.
Example tire size designation:
(These numbers are provided as

an example only; your tire size

designator could vary depending on

your vehicle.)

205/55R16 91H

205 -Tire width in millimeters.
55 - Aspect ratio. The tire’s section

height as a percentage of its

width.

R - Tire construction code (Radial).
16 - Rim diameter in inches.
91 - Load Index, a numerical code

associated with the maximum

load the tire can carry.

H - Speed Rating Symbol. See the

speed rating chart in this section

for additional information.

Maintenance

9-38

Wheel size designation

Wheels are also marked with

important information that you need

if you ever have to replace one. The

following explains what the letters

and numbers in the wheel size

designation mean.
Example wheel size designation:

6.5J X 16

6.5 - Rim width in inches.
J - Rim contour designation.
16 - Rim diameter in inches.

Tire speed ratings

The chart below lists many of the

different speed ratings currently

being used for passenger vehicle

tires. The speed rating is part of the

tire size designation on the sidewall

of the tire. This symbol corresponds

to that tire’s designed maximum safe

operating speed.

Speed

Rating

Symbol

Maximum Speed

S

112 mph (180 km/h)

T

118 mph (190 km/h)

H

130 mph (210 km/h)

V

149 mph (240 km/h)

W

168 mph (270 km/h)

Y

186 mph (300 km/h)

3.  Checking tire life (TIN : Tire

Identification Number)

Any tires that are over six years old,

based on the manufacturing date,

(including the spare tire) should be

replaced by new tires. You can find

the manufacturing date on the tire

sidewall (possibly on the inside of

the wheel), displaying the DOT Code.

The DOT Code is a series of numbers

on a tire consisting of numbers and

English letters. The manufacturing

date is designated by the last four

digits (characters) of the DOT code.

DOT : XXXX XXXX OOOO

The front part of the DOT shows a

plant code number, tire size and

tread pattern and the last four

numbers indicate week and year

manufactured.
For example:
DOT XXXX XXXX 1423 represents that

the tire was produced in the 14th

week of 2023.

4. Tire ply composition and material

The number of layers or plies of

rubber-coated fabric in the tire. Tire

manufacturers also must indicate the

materials in the tire, which include

steel, nylon, polyester, and others.

The letter “R” means radial ply

construction; the letter “D” means

diagonal or bias ply construction;

and the letter “B” means belted-bias

ply construction.

09

9-39

5.  Maximum permissible inflation

pressure

This number is the greatest amount

of air pressure that should be put in

the tire. Do not exceed the maximum

permissible inflation pressure. Refer

to the Tire and Loading Information

label for recommended inflation

pressure.

6. Maximum load rating

This number indicates the maximum

load in kilograms and pounds that

can be carried by the tire. When

replacing the tires on the vehicle,

always use a tire that has the same

load rating as the factory installed

tire.

7.  Uniform tire quality grading

Quality grades can be found where

applicable on the tire sidewall

between tread shoulder and

maximum section width.
For example:
TREAD WEAR 200
TRACTION AA
TEMPERATURE A

Tread wear

The tread wear grade is a

comparative rating based on the

wear rate of the tire when tested

under controlled conditions on a

specified government test course.

For example, a tire graded 150 would

wear one-and-a-half times (1½) as

well on the government course as a

tire graded 100.
The relative performance of tires

depends upon the actual conditions

of their use, however, and may

depart significantly from the norm

due to variations in driving habits,

service practices and differences in

road characteristics and climate.
These grades are molded on the

sidewalls of passenger vehicle tires.

The tires available as standard or

optional equipment on your vehicle

may vary with respect to grade.

Traction AA, A, B & C

The traction grades, from highest

to lowest, are AA, A, B and C. Those

grades represent the tire’s ability to

stop on wet pavement as measured

under controlled conditions on

specified government test surfaces

of asphalt and concrete. A tire

marked C may have poor traction

performance.

 WARNING

The traction grade assigned to this

tire is based on straight-ahead

braking traction tests, and does not

include acceleration, cornering,

hydroplaning, or peak traction

characteristics.

Maintenance

9-40

Temperature A, B & C

The temperature grades are A (the

highest), B and C representing the

tire’s resistance to the generation

of heat and its ability to dissipate

heat when tested under controlled

conditions on a specified indoor

laboratory test wheel.
Sustained high temperature can

cause the material of the tire to

degenerate and reduce tire life, and

excessive temperature can lead to

sudden tire failure. Grade C responds

to a level of performance which

all passenger car tires must meet

under the Federal Motor Vehicle

Safety Standard No. 109. Grades

B and A represent higher levels of

performance on the laboratory test

wheel than the minimum required

by law.

 WARNING

The temperature grade for this

tire is established for a tire that

is properly inflated and not

overloaded. Excessive speed,

under-inflation, over-inflation, or

excessive loading, either separately

or in combination, can cause heat

build-up and possible sudden

tire failure. This may cause loss

of vehicle control resulting in an

accident.

Tire Terminology and Definitions

Air Pressure

The amount of air inside the tire

pressing outward on the tire. Air

pressure is expressed in pounds per

square inch (psi) or kilopascal (kPa).

Accessory Weight

This means the combined weight

of optional accessories. Some

examples of optional accessories

are automatic transmission, power

seats, and air conditioning.

Aspect Ratio

The relationship of a tire’s height to

its width.

Belt

A rubber coated layer of cords that

is located between the plies and the

tread. Cords may be made from steel

or other reinforcing materials.

Bead

The tire bead contains steel wires

wrapped by steel cords that hold the

tire onto the rim.

Bias Ply Tire

A pneumatic tire in which the plies

are laid at alternate angles less than

90 degrees to the centerline of the

tread.

Cold Tire Pressure

The amount of air pressure in a tire,

measured in pounds per square inch

(psi) or kilopascals (kPa) before a tire

has built up heat from driving.

09

9-41

Curb Weight

This means the weight of a motor

vehicle with standard and optional

equipment including the maximum

capacity of fuel, oil and coolant, but

without passengers and cargo.

DOT Markings

A code molded into the sidewall

of a tire signifying that the tire

is in compliance with the U.S.

Department of Transportation motor

vehicle safety standards. The DOT

code includes the Tire Identification

Number (TIN), an alphanumeric

designator which can also identify

the tire manufacturer, production

plant, brand and date of production.

GVWR

Gross Vehicle Weight Rating

GAWR FRT

Gross Axle Weight Rating for the

Front Axle.

GAWR RR

Gross Axle Weight Rating for the

Rear axle.

Intended Outboard Sidewall

The side of an asymmetrical tire,

that must always face outward when

mounted on a vehicle.

Kilopascal (kPa)

The metric unit for air pressure.

Light truck (LT) tire

A tire designated by its manufacturer

as primarily intended for use on

lightweight trucks or multipurpose

passenger vehicles.

Load ratings

The maximum load that a tire is rated

to carry for a given inflation pressure.

Load Index

An assigned number ranging from 1

to 279 that corresponds to the load

carrying capacity of a tire.

Maximum Inflation Pressure

The maximum air pressure to which

a cold tire may be inflated. The

maximum air pressure is molded

onto the sidewall.

Maximum Load Rating

The load rating for a tire at the

maximum permissible inflation

pressure for that tire.

Maximum Loaded Vehicle Weight

The sum of curb weight; accessory

weight; vehicle capacity weight; and

production options weight.

Normal Occupant Weight

The number of occupants a vehicle

is designed to seat multiplied by 150

pounds (68 kg).

Occupant Distribution

Designated seating positions.

Outward Facing Sidewall

An asymmetrical tire has a particular

side that faces outward when

mounted on a vehicle. The outward

facing sidewall bears white lettering

or bears manufacturer, brand, and/or

model name molding that is higher

or deeper than the same moldings

on the inner facing sidewall.

Passenger (P-Metric) tire

A tire used on passenger cars

and some light duty trucks and

multipurpose vehicles.
