5-47

OCN7050089N

2. The indicator (4) and (5) operates as

below:

- If the indicator (4) flashes in Orange,

it indicates that the garage door is

“closing”.

- If the indicator (4) is ON

continuously in Green, it indicates

that the garage door is “closed”.

- If the indicator (5) flashes in Orange,

it indicates that the garage door is

“Opening”.

- If the indicator (5) is ON

continuously in Green, it indicates

that the garage door is “Opened”.

- If the indicator (4) or (5) does not

turn to Green, it indicates that the

last status of garage door was not

received properly. The HomeLink

mirror tries to receive the last

known status of the garage door for

a few seconds.

Recalling Garage Door Status

Homelink mirror with two way

communication provides a way to view

the last stored message from the garage

door opener. In order to recall the last

known status of the last activated device,

press the buttons “1 and 2” OR “2 and 3”

simultaneously.

•

If the indicator (4) is ON continuously

in Green, it indicates that the last

activated device was “closed” properly.

•

If the indicator (5) is ON continuously

in Green, it indicates that the last

activated device was “open” properly.

Information

Two way communication range distance

between “vehicle” and “garage door

opener” is 100m.

The range may be reduced or increased

a little due to obstacle conditions around

the garage door opener, such as houses or

trees.

Convenience Features

5-48

Side View Mirrors

OCN7050019

Make sure to adjust the side view mirrors

to your desired position before you begin

driving.
Your vehicle is equipped with both

left-hand and right-hand side view

mirrors. The mirrors can be adjusted

remotely with the remote switch. The

side view mirrors can be folded to help

prevent damage when going through

an automatic car wash or when passing

through a narrow street.

Information

•

The right side view mirror is convex.

Objects seen in the mirror are closer

than they appear.

•

Use the inside rear view mirror or look

back directly to determine the actual

distance of other vehicles prior to

changing lanes.

WARNING

Do not adjust or fold the side view

mirrors while driving. This may cause

loss of vehicle control resulting in an

accident.

NOTICE

•

Do not scrape ice off the mirror face;

this may damage the surface of the

glass.

•

If the mirror is jammed with ice, do

not adjust the mirror by force. Use

an approved de-icer (not radiator

antifreeze) spray, or a sponge or soft

cloth with very warm water, or move

the vehicle to a warm place and

allow the ice to melt.

•

Do not clean the mirror with harsh

abrasives, fuel, or other petroleum

based cleaning products.

5-49

Side View Mirror Adjustment

OCN7H053040N

1. Move the lever (1) to the L (left side)

or R (right side) to select the side view

mirror you want to adjust.

2. Use the mirror adjustment control (2)

to position the selected mirror up,

down, left or right.

3. After adjustment, put the lever into

neutral (center) position to prevent

inadvertent adjustment.

NOTICE

•

The mirrors stop moving when

they reach the maximum adjusting

angles, but the motor continues to

operate while the switch is pressed.

Do not press the switch longer than

necessary, because this can damage

the motor.

•

Do not attempt to adjust the side

view mirrors by hand, because this

can damage the motor.

Folding the side view mirrors

OCN7050022

To fold the side view mirrors, grasp the

housing of the mirror and then fold it

inwards.

5-51

Power Windows

The ignition switch must be in the ON

position to be able to raise or lower

the windows. Each door has a Power

Window switch to control that door’s

window. The driver has a Power Window

Lock switch which can block the

operation of rear passenger windows.

The power windows will operate for

approximately 30 seconds after the

ignition switch is placed in the ACC or

LOCK/OFF position. However, if the front

doors are opened, the Power Windows

will not operate even within the 30

second period.

WARNING

To avoid serious injury or death, do not

extend your head, arms or body outside

the windows while driving.

Information

•

In cold and wet climates, power

windows may not work properly due to

freezing conditions.

•

While driving with the rear windows

down or with the sunroof (if equipped)

opened (or partially opened), your

vehicle may demonstrate a wind

buffeting or pulsation noise. This

noise is normal and can be reduced

or eliminated by taking the following

actions. If the noise occurs with one

or both of the rear windows down,

partially lower both front windows

approximately one inch. If you

experience the noise with the sunroof

open, slightly close the sunroof.

Window opening and closing

OCN7050082

To open:
Press the window switch down to the

first detent position (5). Release the

switch when you want the window to

stop.

To close:
Pull the window switch up to the first

detent position (5). Release the window

switch when you want the window to

stop.

Auto down window (if equipped)

Pressing the power window switch

down momentarily to the second

detent position (6) completely lowers

the window even when the switch is

released. To stop the window at the

desired position while the window is in

operation, pull up or press down and

release the switch.

Auto up/down window (if equipped)

Pressing or pulling up the power window

switch momentarily to the second

detent position (6) completely lowers or

lifts the window even when the switch

is released. To stop the window at the

desired position while the window is in

operation, pull up or press down and

release the switch.

Convenience Features

5-52

To reset the power windows

If the power windows do not operate

normally, the automatic power window

system must be reset as follows:
1. Place the ignition switch to the ON

position.

2. Close the window and continue

pulling up on the power window

switch for at least one second.

If the power windows do not operate

properly after resetting, have the system

checked by an authorized HYUNDAI

dealer.

WARNING

The automatic reverse feature doesn’t

activate while resetting the power

window system. Make sure body parts

or other objects are safely out of the

way before closing the windows to

avoid injuries or vehicle damage.

Automatic reverse (if equipped)

OCN7050026

If a window senses any obstacle while it

is closing automatically, it will stop and

lower approximately 12 inches (30 cm) to

allow the object to be cleared.
If the window detects the resistance

while the power window switch is

pulled up continuously, the window

will stop upward movement then lower

approximately 1 inch (2.5 cm).
If the power window switch is pulled

up continuously again within 5 seconds

after the window is lowered by the

automatic window reverse feature,

the automatic window reverse will not

operate.

Information

The automatic reverse feature is only

active when the “Auto Up” feature is used

by fully pulling up the switch to the second

detent.

WARNING

Make sure body parts or other objects

are safely out of the way before closing

the windows to avoid injuries or vehicle

damage.
Objects less than 0.16 inch (4 mm) in

diameter caught between the window

glass and the upper window channel

may not be detected by the automatic

reverse window and the window will

not stop and reverse direction.

5-53

NOTICE

Do not install any accessories on the

windows. The automatic reverse

feature may not operate.

Power window lock switch

OCN7050027

The driver can disable the power window

switches on the rear passenger doors by

pressing the power window lock switch.
When the power window lock switch is

pressed:

•

The rear passenger control will not

be able to operate the rear passenger

power window

•

Note that the front passenger control

is still able to operate the front

passenger window, and that the driver

master control can still operate all the

power windows.

NOTICE

•

To prevent possible damage to the

power window system, do not open

or close two windows or more at the

same time. This will also ensure the

longevity of the fuse.

•

Never try to operate the main

switch on the driver’s door and the

individual door window switch in

opposite directions at the same time.

If this is done, the window will stop

and cannot be opened or closed.

WARNING

•

NEVER leave the keys in your vehicle

with unsupervised children, when

the engine is running.

•

NEVER leave any child unattended in

the vehicle. Even very young children

may inadvertently cause the vehicle

to move, entangle themselve s in

the windows, or otherwise injure

themselves or others.

•

Always double check to make

sure arms, hands, head and other

obstructions are safely out of the

way before closing a window.

•

Do not allow children to play with the

power windows. Keep the driver’s

door power window lock switch in

the LOCK position (pressed). Serious

injury can result from unintentional

window operation by the child.

•

Do not extend your head, arms or

body outside the windows while

driving.

Convenience Features

5-54

Remote window opening function (if

equipped)

2C_RemoteWindowOpenButton

Press and hold the Door Unlock (1)

button on the smart key for more than

3 seconds and the front seat windows

move down after the doors are unlocked.

Window movement stops when you

release the door unlock button.

NOTICE

Do not leave the windows down when

leaving the vehicle to prevent theft

or damage from water entering the

vehicle.

Information

The remote window opening function may

abruptly stop, when you move away from

your vehicle during operation. Stay in

close proximity from your vehicle, while

monitoring the window movement.

The doors unlock when the windows are

opened using the remote window opening

function.

5-55

SUNROOF (IF EQUIPPED)

If your vehicle is equipped with a

sunroof, you can slide or tilt your sunroof

with the sunroof switch located on the

overhead console.

OCN7050028

The sunroof can only be operated when

the ignition switch is in the ON or START

position.
The sunroof can be operated for

approximately 3 minutes after the

ignition switch is in the ACC or LOCK/

OFF position. However, if the front door

is open, the sunroof cannot be operated

even within the 3 minute period.

WARNING

•

Adjust the sunroof or sunshade when

your vehicle stops. This could result

in loss of control and an accident

that may cause injury, or property

damage.

•

Do not leave the engine running

and the key in your vehicle with

unsupervised children. Unattended

children could operate the sunroof,

which could result in serious injury.

•

Do not sit on the top of the vehicle. It

may cause injury or vehicle damage.

NOTICE

Do not operate the sunroof when roof

bars are installed on the vehicle or

when there is luggage on the roof.

Sunshade

OCN7050029

Use the sunshade to block direct sunlight

coming through the sunroof glass.
Open or close the sunshade by hand.

Information

The sunshade opens automatically when

the sunroof glass is opened, but the

sunshade does not close automatically

when the sunroof glass is closed. Also, only

the sunshade cannot be closed when the

sunroof glass is opened.

NOTICE

Do not pull the sunshade up or down,

or apply excessive force as such action

may damage the sunshade or cause it

to malfunction.

Convenience Features

5-56

Tilt Open/Close

OCN7051144

[1] : Tilt open
[2] : Tilt close

•

Push the sunroof switch upward, the

sunroof glass tilts open.

•

Push the sunroof switch forward, the

sunroof glass automatically closes.

To stop the sunroof movement at any

point, push the sunroof switch in any

direction.

Information

The sunroof glass cannot slide open and

tilt open at the same time. You cannot tilt

the sunroof glass open while the sunroof

glass is slide open. Also, you cannot slide

the sunroof glass open while the sunroof

is tilt open. Slide open or tilt open the

sunroof glass when the sunroof glass is

completely closed.

Slide Open/Close

OCN7N051031

•

Push the sunroof switch rearward,

the sunshade and sunroof glass slide

open.
Push the sunroof switch forward, only

the sunroof glass closes.

•

Push the sunroof switch forward or

rearward to the first detent position,

the sunroof glass moves until the

switch is released.

•

Push the sunroof switch forward

or rearward to the second detent

position, the sunroof glass operates

automatically (auto slide feature). To

stop the sunroof movement at any

point, push the sunroof switch in any

direction.

•

The sunroof glass stops halfway

(first detent position) before it is fully

opened. To fully open the sunroof

glass, push the sunroof switch

rearward once more. At this time, the

sunroof glass opens only while the

switch is pushed.

Information

To reduce wind noise while driving,

we recommend that you drive at the

recommended position before the

maximum slide open position.

5-57

Automatic Reversal (if equipped)

ODH043039

If the sunroof glass senses any obstacle

while it is closing automatically, it will

reverse direction then stop at a certain

position.
The auto reverse function may not

work if an object thin or soft is caught

between the sliding sunroof glass and

sunroof sash.

WARNING

•

Make sure heads, hands, arms or

any other body parts or objects are

out of the way before operating the

sunroof. Body parts or objects may

get caught causing injuries or vehicle

damage.

•

Never deliberately use your body

parts to test the automatic reversal

function. The sunroof glass may

reverse direction, but there is a risk

of injury.

NOTICE

•

Do not continue to push the sunroof

switch after the sunroof is fully

opened, closed, or tilted. Damage to

the sunroof motor could occur.

•

Continuous operations such as slide

open/close, tilt open/close, etc. may

cause the motor or sunroof system to

malfunction.

•

Regularly remove any accumulated

dust on the sunroof rail.

•

Dust accumulated between the

sunroof and roof panel can make

noise. Open the sunroof and remove

dust regularly using a clean cloth.

•

Do not try to open the sunroof when

the temperature is below freezing

or when the sunroof is covered

with snow or ice. The sunroof may

not work properly and may break if

opened by force.

•

Do not open or drive with the sunroof

glass open immediately after rain or

washing the vehicle. Water may wet

the interior of the vehicle.

•

Do not extend any luggage outside

the sunroof while driving. Vehicle

damage may occur if the vehicle

suddenly stops.

WARNING

Do not extend your head, arms, body

parts or objects outside the sunroof

while driving. Injuries may occur if the

vehicle suddenly stops.

Convenience Features

5-58

Resetting the Sunroof

OCN7051028L

In some circumstances resetting the

sunroof operation may need to be

performed. Some instances where

resetting the sunroof may be required

include:

•

When the 12 V battery is either

disconnected or discharged

•

When the sunroof fuse is replaced

•

If the sunroof one-touch AUTO OPEN/

CLOSE operation is not functioning

properly

Sunroof resetting procedure:
1. It is recommended to perform the

reset procedure with the vehicle

engine running. Start the vehicle in P

(Park).

2. Make sure the sunroof glass is in the

fully closed position. If the sunroof

glass is open, push the switch forward

until the sunroof glass is fully closed.

3. Release the switch when the sunroof

glass is fully closed.

4. Push the switch forward until the

sunroof glass moves slightly. Then

release the switch.

5. Once again push and hold the sunroof

switch forward until the sunroof glass

slides open and close. Do not release

the switch until the operation is

completed. If you release the switch

during operation, start the procedure

again from step 2.

Information

If the sunroof is not reset when the vehicle

battery connector is disconnected or

discharged, or the sunroof fuse is blown,

the sunroof may not operate normally.

Sunroof Open Warning

(if equipped)

OCN7040018

If the driver turns off the engine when

the sunroof is not fully closed, the

warning chime will sound for several

seconds and the sunroof open warning

will appear on the cluster LCD display.
Close the sunroof securely when leaving

your vehicle.

CAUTION

Make sure the sunroof is closed fully

when leaving your vehicle.
If the sunroof is left open, rain or snow

may wet the interior of the vehicle.

Also, leaving the sunroof open when the

vehicle is unattended may invite theft.

5-59

HOOD

Opening the hood

OCN7050033

1. Park the vehicle and set the parking

brake.

2. Pull the release lever to unlatch the

hood. The hood should pop open

slightly.

OCN7H053030L

3. Go to the front of the vehicle, raise the

hood slightly, push up the secondary

hood release lever (1) inside of the

hood center and lift the hood (2).

4. Pull out the support rod.

OCN7050035

5. Hold the hood open with the support

rod (3).

WARNING

Support rod

•

After driving, the engine

compartment and support rod will

be hot. Grasp the support rod in the

area wrapped in rubber to prevent

burns.

•

The support rod must be inserted

completely into the hole provided

whenever you inspect the engine

compartment. This will prevent

the hood from falling and possibly

injuring you.

Convenience Features

5-60

Closing the hood

1. Before closing the hood, check the

following:

•

All filler caps in engine

compartment must be correctly

installed.

•

Gloves, rags or any other

combustible material must

be removed from the engine

compartment.

2. Return the support rod to its clip to

prevent it from rattling.

3. Lower the hood halfway (lifted

approximately 11.8 in. (30 cm) from

the closed position) and push down

to securely lock in place. Then double

check to be sure the hood is secure.
If the hood can be raised slightly, it is

not securely locked. Open it again and

close it with more force.

WARNING

•

Before closing the hood, ensure

all obstructions are removed from

around the hood opening.

•

Always double check to be sure that

the hood is firmly latched before

driving away. Check there is no

hood open warning light or message

displayed on the instrument cluster.

Driving with the hood opened may

cause a total loss of visibility, which

might result in an accident.

•

Do not move the vehicle with the

hood in the raised position, as vision

is obstructed, which might result in

an accident, and the hood could fall

or be damaged.

5-61

TRUNK

Opening the Trunk

Opening from outside

OCN7H053015

Make sure the shift lever is in P (Park).
Then do one of the following:

•

Hold down the trunk unlock button

located on your remote key or smart

key for more than 1 second.

•

Additionally, for vehicles equipped

with smart key :

- While all doors are unlocked, press

the switch in the trunk to open the

trunk with or without the smart key

in your possession.

- If any door is locked or all doors are

locked, the switch can still be used

to open the trunk, as long as the

smart key is in your possession.

Opening from inside

OCN7050037

When the trunk is closed, pull the trunk

release lever. The trunk will open.

Closing the trunk

Lower the trunk lid and press down

until it locks. To be sure the trunk lid is

securely fastened, always check by trying

to pull it up again.

WARNING

Always keep the trunk lid completely

closed while the vehicle is in motion. If

it is left open or ajar, poisonous exhaust

gases containing carbon monoxide

(CO) may enter the vehicle and serious

illness or death may result.

Information

To prevent damage to the trunk lift

cylinders and the attached hardware,

always close the trunk before driving.

NOTICE

In cold and wet climates, trunk lock

and trunk mechanisms may not work

properly due to freezing conditions.

Convenience Features

5-62

Emergency Trunk Safety Release

OCN7H053016

Your vehicle is equipped with an

Emergency Trunk Safety Release lever

located inside the trunk. When someone

is inadvertently locked in the trunk, the

trunk can be opened by moving the lever

in the direction of the arrow and pushing

the trunk open.

WARNING

•

You and your passengers must

be aware of the location of the

Emergency Trunk Safety Release

lever in this vehicle and how to open

the trunk in case you are accidentally

locked in the trunk.

•

NEVER allow anyone to occupy the

trunk of the vehicle at any time. If the

trunk is partially or totally latched

and the person is unable to get out,

serious injury or death could occur

due to lack of ventilation, exhaust

fumes and rapid heat build-up, or

because of exposure to cold weather

conditions. The trunk is also a highly

dangerous location in the event of a

crash because it is not a protected

occupant space but is a part of the

vehicle’s crush zone.

•

Your vehicle should be kept locked

and the Smart Key should be kept

out of the reach of children. Parents

should teach their children about the

dangers of playing in trunks.

•

Use the release lever for emergencies

only.

5-63

Smart Trunk with Auto Open

(if equipped)

OCN7H053017

On a vehicle equipped with a smart key,

the trunk can be opened using the Smart

Trunk release system.

How to use the Smart Trunk release

The trunk can be opened with no touch

activation satisfying all the conditions

below.

•

After 15 seconds when all doors are

closed and locked

•

Positioned in the detecting area for

more than 3 seconds

Information

The Smart Trunk release does not operate

when:

•

The smart key is detected within 15

seconds after the doors are closed and

locked, and is continuously detected.

•

The smart key is detected within 15

seconds after the doors are closed

and locked, and 4.9 ft. (1.5 m) from

the front door handles. (for vehicles

equipped with Welcome Light)

•

A door is not locked or closed.

•

The smart key is in the vehicle.

1. Setting
To activate the Smart Trunk release, go

to User Settings Mode and select Smart

Trunk on the cluster display.

For more details, refer to “Cluster

Display” in this chapter. If your vehicle

is equipped with additional navigation,

please refer to the infotainment system

manual separately supplied.

OCN7H053031N

2. Detect and Alert
If you are positioned in the detecting

area (20~40 in. (50~100 cm) behind the

vehicle) carrying a smart key, the hazard

warning lights will blink and chime will

sound to alert you the smart key has

been detected and the trunk will open.

Information

Do not approach the detecting area if you

do not want the trunk to open. If you have

unintentionally entered the detecting area

and the hazard warning lights and chime

starts to operate, leave the detecting area

with the smart key. The trunk will stay

closed.

Convenience Features

5-64

OCN7H053018

3. Automatic opening
The hazard warning lights will blink and

chime will sound 6 times and then the

trunk will open.

WARNING

•

Make sure you close the trunk before

driving your vehicle.

•

Make sure there are no people or

objects around the trunk before

opening or closing the trunk.

•

Make sure objects in the trunk do not

come out when opening the trunk on

a slope. It may cause serious injury.

•

Make sure to deactivate the Smart

Trunk when washing your vehicle.

Otherwise, the trunk may open

inadvertently.

•

The key should be kept out of

reach of children. Children may

inadvertently open the Smart Trunk

release while playing around the rear

area of the vehicle.

How to deactivate the Smart Trunk

release function using the smart key

Type A

OCN7053005

Type B

OCN7053004

1.  Door lock
2.  Door unlock
3.  Trunk open
4.  Panic
5.  Remote Start (if equipped)

If you press any button of the smart key

during the Detect and Alert stage, the

Smart Trunk release function will be

deactivated.
Make sure to be aware of how to

deactivate the Smart Trunk release

function for emergency situations.

5-65

Information

•

If you press the door unlock button

(2), the Smart Trunk release function

will be deactivated temporarily. But,

if you do not open any door for 30

seconds, the smart trunk function will

be activated again.

•

If you press the trunk open button

(3) for more than 1 second, the trunk

opens.

•

If you press the door lock button (1) or

trunk open button (3) when the Smart

Trunk release function is not in the

Detect and Alert stage, the smart trunk

function will not be deactivated.

•

In case you have deactivated the Smart

Trunk function by pressing the smart

key button and opened a door, the

Smart Trunk release function can be

activated again by closing and locking

all doors.

Detecting area

OCN7H053031N

•

The Smart Trunk release operates

with a welcome alert if the smart key

is detected within 20~40 in. (50~100

cm) from the trunk.

•

The alert stops at once if the smart

key is positioned outside the

detecting area during the Detect and

Alert stage.

Information

•

The Smart Trunk release function will

not work if any of the following occurs:

The smart key is close to a radio

transmitter such as a radio station or

an airport which can interfere with

normal operation of the transmitter.

The smart key is near a mobile two

way radio system or a cellular phone.

Another vehicle’s smart key is being

operated close to your vehicle.

•

The detecting range may decrease or

increase when :

One side of the tire is raised to

replace a tire or to inspect the

vehicle.

The vehicle is slantingly parked on a

slope or unpaved road, etc.

Convenience Features

5-66

FUEL FILLER DOOR

Opening the Fuel Filler Door

OCN7050042

The fuel filler door must be opened from

inside the vehicle by pulling up the fuel

filler door opener.
1. Turn the engine off.
2. Pull up the fuel filler door opener.

OCN7H053046N

3. Pull the fuel filler door (1) out to fully

open.

4. To remove the fuel tank cap (2), turn

it counterclockwise. You may hear a

hissing noise as the pressure inside

the tank equalizes.

5. Place the cap on the fuel filler door.

Information

Open and close the reservoir cap by using

the handle on the cap cover for safety.

Information

If the fuel filler door does not open

because ice has formed around it, tap

lightly or push on the door to break the

ice and release the door. Do not pry on the

door. If necessary, spray around the door

with an approved de-icer fluid (do not use

radiator anti-freeze) or move the vehicle to

a warm place and allow the ice to melt.

5-67

Closing the Fuel Filler Door

1. To install the fuel tank cap, turn it

clockwise until it “Clicks”.

2. Close the fuel filler door until it is

latched securely.

NOTICE

There may be an intermittent noise

near the refueling hole while the engine

is idling if the fuel cap is not closed

securely. This occurs normally with the

OBD system.

NOTICE

When refueling on unlevel ground,

the fuel gauge may not point to the F

position.
It is not a malfunction. If you move your

vehicle to a level ground, the fuel gauge

will move to the full position.

WARNING

Gasoline is highly flammable and

explosive. Failure to follow these

guidelines may result in SERIOUS

INJURY or DEATH:

•

Read and follow all warnings posted

at the gas station.

•

Before refueling, note the location of

the Emergency Gasoline Shut-Off, if

available, at the gas station.

•

Before touching the fuel nozzle, you

should eliminate the potential build-

up of static electricity by touching

a metal part of the vehicle, a safe

distance away from the fuel filler

neck, nozzle, or other gas source,

with your bare hand.

•

Do not use cellular phones while

refueling. Electric current and/or

electronic interference from cellular

phones can potentially ignite fuel

vapors and cause a fire.

•

Do not get back into a vehicle

once you have begun refueling.

You can generate a build-up of

static electricity by touching,

rubbing or sliding against any item

or fabric capable of producing

static electricity. Static electricity

discharge can ignite fuel vapors

causing a fire. If you must re-enter

the vehicle, you should once again

eliminate potentially dangerous

static electricity discharge by

touching a metal part of the vehicle,

away from the fuel filler neck, nozzle

or other gasoline source, with your

bare hand.

Convenience Features

5-68

•

When refueling, always move the

shift lever to the P (Park) position,

set the parking brake, and place the

ignition switch to the LOCK/OFF

position.
Sparks produced by electrical

components related to the engine

can ignite fuel vapors causing a fire.

•

When using an approved portable

fuel container, be sure to place the

container on the ground prior to

refueling. Static electricity discharge

from the container can ignite fuel

vapors causing a fire. Once refueling

has begun, contact between your

bare hand and the vehicle should

be maintained until the filling is

complete.

•

Use only approved portable plastic

fuel containers designed to carry and

store gasoline.

•

Do not use matches or a lighter and

do not smoke or leave a lit cigarette

in your vehicle while at a gas station,

especially during refueling.

•

Do not over-fill or top-off your

vehicle tank, which can cause

gasoline spillage.

•

If a fire breaks out during refueling,

leave the vicinity of the vehicle, and

immediately contact the manager

of the gas station and then contact

the local fire department. Follow any

safety instructions they provide.

•

If pressurized fuel sprays out, it can

cover your clothes or skin and thus

subject you to the risk of fire and

burns. Always remove the fuel cap

carefully and slowly. If the cap is

venting fuel or if you hear a hissing

sound, wait until the condition stops

before completely removing the cap.

•

Always check that the fuel cap is

installed securely to prevent fuel

spillage in the event of an accident.

Information

Make sure to refuel your vehicle according

to the “Fuel Requirements” suggested in

the Introduction chapter.

NOTICE

•

Do not spill fuel on the exterior

surfaces of the vehicle. Any type of

fuel spilled on painted surfaces may

damage the paint.

•

If the fuel filler cap requires

replacement, use only a genuine

HYUNDAI cap or the equivalent

specified for your vehicle. An

incorrect fuel filler cap can result

in a serious malfunction of the fuel

system or emission control system.

5-69

EXTERIOR LIGHTS

Lighting Control

To operate the lights, turn the knob at

the end of the control lever to one of the

following positions:

ODN8A059200

1.  OFF
2.  AUTO headlight
3.  Parking light
4.  Headlight

OCN7050055

AUTO headlight

The parking light and headlight will

be turned ON or OFF automatically

depending on the amount of daylight as

measured by the ambient light sensor on

the center dash (1).
Even with the AUTO headlight feature

in operation, it is recommended to

manually turn ON the headlights when

driving at night or in a fog, driving in the

rain, or when you enter dark areas, such

as tunnels and parking facilities.

NOTICE

•

Do not cover or spill anything on

the sensor (1) located in front of the

instrument panel.

•

Do not clean the sensor using

a window cleaner, the cleanser

may leave a light film which could

interfere with sensor operation.

•

If your vehicle has window tint or

other types of metallic coating on the

front windshield, the AUTO headlight

system may not work properly.

Convenience Features

5-70

ODN8A059202

Parking light (

)

The parking light, license plate light and

instrument panel light are turned ON.

ODN8A059203

Headlight (

)

The headlight, parking light, license

plate light and instrument panel light are

turned ON.

Information

The ignition switch must be in the ON

position to turn on the headlight.

High Beam Operation

ODN8A059205

To turn on the high beam headlight, push

the lever away from you. The lever will

return to its original position.
The high beam indicator will light when

the headlight high beams are switched

on.
To turn off the high beam headlight, pull

the lever towards you. The low beams

will turn on.

WARNING

Do not use high beam when there are

other vehicles approaching you. Using

high beam could obstruct the other

driver’s vision.

ODN8A059204

To flash the high beam headlight, pull the

lever towards you, then release the lever.

The high beams will remain ON as long

as you hold the lever towards you.

5-71

Turn Signals and Lane Change

Signals

ODN8A059207

To signal a turn, push down on the lever

for a left turn or up for a right turn in

position (A). To signal a lane change,

move the turn signal lever slightly and

hold it in position (B). The lever will

return to the OFF position when released

or when the turn is completed.
If an indicator stays on and does not flash

or if it flashes abnormally, one of the turn

signal bulbs may be burned out and will

require replacement.

One touch turn signal function

To activate a one-touch turn signal

function, move the turn signal lever

slightly and then release it. The lane

change signals will blink 3, 5 or 7 times.
You can enable the One Touch Turn

Signal function or choose the number of

blinks from the User Settings Mode on

the cluster display.
For more details, refer to “Cluster display

modes” in chapter 4. If your vehicle is

equipped with additional navigation,

please refer to the infotainment system

manual separately supplied.

Battery Saver Function

The purpose of this feature is to

help prevent the battery from being

discharged. The system automatically

turns off the parking light when the

driver turns the vehicle off and opens the

driver-side door.
With this feature, the parking lights will

turn off automatically if the driver parks

on the side of road at night.
However, the position lights stay ON

even when the driver-side door is opened

if the headlight switch is turned to the

position light (O) or AUTO (if equipped)

position after the engine is turned off.
If necessary, to keep the lights on turn

the position lights OFF and ON again

using the headlight switch on the

steering column after the engine is

turned off.

Convenience Features

5-72

Headlight Delay Function

(if equipped)

If you place the ignition switch in the

ACC or LOCK/OFF position with the

headlights ON, the headlights (and/

or parking lights) remain on for about 5

minutes. However, with the engine off if

the driver’s door is opened and closed,

the headlights (and/or parking lights) are

turned off after 15 seconds.
The headlights (and/or parking lights)

can be turned off by pressing the lock

button on the remote key or smart key

twice or turning the light switch to the

OFF or AUTO position. However, if you

turn the light switch to the AUTO position

when it is dark outside, the headlights

will not be turned off.
You can enable the headlight delay

function from the User Settings Mode in

the cluster display.
For more details, refer to “Cluster display

modes” in chapter 4. If your vehicle is

equipped with additional navigation,

please refer to the infotainment system

manual separately supplied.

NOTICE

If the driver exits the vehicle through

another door besides the driver

door, the battery saver function

does not operate and the headlight

delay function does not turn OFF

automatically.
This may cause the battery to

discharge. To avoid battery discharge,

turn OFF the headlights manually from

the headlight switch before exiting the

vehicle.

Daytime Running Light (DRL)

The Daytime Running Lights (DRL) can

make it easier for others to see the front

of your vehicle during the day, especially

after dawn and before sunset.

The DRL system will turn the dedicated

light OFF when:

•

The headlights are ON.

•

The parking lights are ON.

•

The vehicle is turned off.

•

The parking brake is engaged.

5-73

HIGH BEAM ASSIST (HBA) (IF EQUIPPED)

OCN7050141N

Hight Beam Assist automatically

switches between high beam and

low beam depending on the detected

brightness from the lights of oncoming

vehicles or vehicles in front.

Detecting sensor

OCN7H053033L

[1] : Front view camera

The front view camera is used as a

detecting sensor to help detect ambient

light and brightness while driving.
Refer to the picture above for the

detailed location of the detecting sensor.

NOTICE

•

Always keep the front view camera in

good condition to maintain optimal

performance of High Beam Assist.

•

For more details on the precautions

of the front view camera, refer to

“Forward Collision-Avoidance Assist

(FCA)” section in chapter 7.

High Beam Assist Settings

OCN7073239L

With the ignition switch ON, go to the

User Settings menu to turn on High

Beam Assist and deselect to turn off the

function in the instrument cluster.
Select:

User Settings

Lights

High Beam

Assist

(for cluster type)

WARNING

Only change the settings after parking

your vehicle at a safe location.

Convenience Features

5-74

High Beam Assist Operation

•

After selecting

High Beam Assist

from

the Settings menu to operate High

Beam Assist:

- Place the headlight switch in

the AUTO position and push

the headlight lever towards the

instrument cluster. The High Beam

Assist ( ) indicator light illuminates.

- When High Beam Assist is enabled,

high beams turn on when the

vehicle speed is above 20 mph (30

km/h) and the High Beam (

)

indicator illuminates. When the

vehicle speed is below 12 mph (20

km), high beams turn off and the

indicator light illuminates in white.

•

When High Beam Assist is operating:

- If the turn signal lever is pulled

toward you when the high beams

are off, the high beams turn on.

When you let go of the turn signal

lever, High Beam Assist operates

again.

- If the turn signal lever is pulled

toward you when the high beams

are on by High Beam Assist, the

low beams turn on and High Beam

Assist turns off.

- If the turn signal lever is pushed

away from you, the high beams turn

on and High Beam Assist turns off.

- If the headlight switch is moved

from AUTO to another position

(headlight/position/off(O)), the

corresponding light turns on and

High Beam Assist turns off.

•

When High Beam Assist is operating,

high beam switches to low beam if:

- The headlights of an oncoming

vehicle are detected.

- The tail lights of a front vehicle are

detected.

- The headlight or tail light of a

motorcycle or a bicycle is detected.

- The surrounding ambient light is

bright enough so high beams are

not required.

- Streetlights or other lights are

detected.

- The vehicle speed drops below the

threshold.

Information

The images and colors in the cluster may

differ depending on the cluster type or

theme selected from the cluster.

High Beam Assist Malfunction

and Limitations

High Beam Assist malfunction

OCN7H043028L

When High Beam Assist is not working

properly, the “

Check High Beam Assist

(HBA) system

” warning message may

appear, and the warning light may

illuminate on the instrument cluster.

Contact an authorized HYUNDAI dealer.

5-75

Limitations of High Beam Assist

High Beam Assist may not work properly

in the following situations if:

•

The headlights from an oncoming or

front vehicle is damaged or out of the

detection range.

•

The headlights from an oncoming or

front vehicle are covered with dust,

snow, or water.

•

An oncoming or front vehicle’s

headlights are off but the fog lights

are on.

•

There are lights that have a similar

shape as a vehicle’s light ahead.

•

The headlights are not repaired or

replaced properly.

•

The headlights are not aimed properly.

•

You are driving on a narrow curved

road, rough road, uphill, or downhill.

•

A front vehicle is partially visible at a

crossroad or on a curved road.

•

There is a temporary reflector or flash

ahead (construction area).

•

There is a traffic light, reflecting sign,

LED sign, or reflectors ahead.

•

The road is wet or covered with snow

or ice.

•

A vehicle suddenly appears from a

curve.

•

The vehicle is tilted due to a flat tire or

being towed.

•

The headlights from an oncoming or

front vehicle is not detected because

of exhaust fumes, smoke, fog, snow,

blizzard, water spray on the road, or

windshield condensation, etc.

Information

For more details on the limitations of the

front view camera, refer to “Forward

Collision-Avoidance Assist (FCA)” section

in chapter 7.

WARNING

•

Always check road conditions,

and if necessary, take appropriate

actions to drive safely. It is your

responsibility to operate your vehicle

in a safe manner.

•

If High Beam Assist does not operate

properly, use the turn signal lever to

switch between high beam and low

beam.

•

High Beam Assist may not operate

for 15 seconds right after your vehicle

is started or when the front view

camera is initialized.

Convenience Features

5-76

WARNING

Do not use the interior lights when

driving in the dark. The interior lights

may obscure your view and cause an

accident.

NOTICE

Do not use the interior lights for

extended periods when the vehicle is

turned off or the battery will discharge.

Interior Lights Auto Off

The interior lamps will automatically go

off approximately 20 minutes after the

engine is turned off and the doors are

closed. If a door is opened, the lamp

will go off 40 minutes after the engine is

turned off. If the doors are locked by the

remote key or smart key and the vehicle

enters the armed stage of the theft

alarm system, the lamps will go off five

seconds later.

Front Lamps

OCN7053056N

(1)  Front Map Lamp
(2)  Front Door Lamp
(3)  Front Room Lamp ON
(4)  Front Room Lamp OFF

Front map lamp:

Press either of these lens to turn the map

lamp on or off. This light produces a spot

beam for convenient use as a map lamp

at night or as a personal lamp for the

driver and the front passenger.

Front Door Lamp (

The front or rear room lamps come on

when the front or rear doors are opened

if the engine is running or not. When

doors are unlocked by the remote key or

smart key, the front and rear lamps come

on for approximately 30 seconds as long

as any door is not opened. The front and

rear room lamps go out gradually after

approximately 30 seconds if the door is

closed. However, if the ignition switch is

in the ON position or all doors are locked,

the front and rear lamps will turn off. If a

door is opened with the ignition switch in

the ACC position or the ON/OFF position,

the front and rear lamps stay on for

about 20 minutes.

INTERIOR LIGHTS

5-77

Front room lamp

•

Press the button to turn ON the room

lamp for the front/rear seats.

•

Press the button to turn OFF the room

lamp for the front/rear seats.

Mood lamp (if equipped)

OCN7C052041

The lamp turns on when ‘User settings →

Lights → Ambient Light’ is selected from

the infotainment system.

Information

The infotainment system may change after

software updates. For more information,

refer to the user’s manual provided in

the infotainment system and the quick

reference guide.

Room Lamp

OCN7050057

Rear Room Lamp (

Press this switch to turn the rear room

lamp on and off.

NOTICE

Do not leave the lamp switches on for

an extended period of time when the

engine is turned off.

Convenience Features

5-78

Luggage Compartment Lamp

OCN7H053019

The luggage compartment lamp comes

on when the trunk is opened.

NOTICE

The luggage compartment lamp comes

on as long as the trunk is open. To

prevent unnecessary battery system

drain, close the trunk securely after

using the luggage compartment.

Vanity Mirror Lamp (if equipped)

OCN7050058

Push the switch to turn the light on or off.

•

: The lamp will turn on if this

button is pressed.

•

: The lamp will turn off if this

button is pressed.

NOTICE

Always have the switch in the off

position when the vanity mirror lamp

is not in use. If the sunvisor is closed

without the lamp off, it may discharge

the battery or damage the sunvisor.

Hyundai Elantra Hybrid (2024 year). Manual in english - page 7
