.NOTICE

The transponder in your key is an

important part of the immobilizer

system. It is designed to give years

of trouble-free service, however you

should avoid exposure to moisture,

static electricity and rough handling.

Immobilizer system malfunction could

occur.

Information

This device complies with Part 15 of the

FCC rules.

Operation is subject to the following three

conditions:

This device may not cause harmful

interference.

This device must accept any

interference received, including

interference that may cause undesired

operation.

Changes or modifications not expressly

approved by the party responsible

for compliance could void the user’s

authority to operate the device

Convenience Features

5-16

HYUNDAI DIGITAL KEY

Hyundai digital key provides

convenience to the driver, which the

driver can use to lock or unlock the driver

and passenger doors or the trunk and

turn on the vehicle.

Digital Key (Smartphone)

Information

•

Hyundai digital keys are only available

on smartphone that support digital key

functions, and digital key functions

of smartphones are provide by

smartphone manufacturers.

•

Available smartphone models can be

found on smartphone manufactures’

website or HYUNDAI website.

•

Depending on the availability of service

on the vehicle, some functions may not

operated.

Setting your smartphone

To use the digital key (smartphone),

download the Bluelink App and sign up

Hyundai account and service.
For more information about Bluelink,

refer to the infotainment system guide.

Registering your digital key

(smartphone)

1. Turn on the vehicle with a smart key

and have your smart key with you in

the vehicle.

2. After selecting

Digital Key

Set Up

Digital Key

from the My Hyundai App

in the smartphone, register the digital

key according to the guidance in the

smartphone screen.

OCN7053070

[A]: Wireless charging pad

- Place your smartphone on the

vehicle authentication pad (wireless

charging pad) with the screen

facing up. (In case of Apple WATCH,

the watch face must be on the pad).

- When the digital key (smartphone)

is saved, a message appears on the

infotainment system screen.

5-17

Information

2C_SmartPhoneSample

•

The NFC Antenna position on Samsung

device can be found in the following

path: Settings > Connections > NFC

and contactless payments.

•

The NFC Antenna position on Apple

iPhone is located at the top of the rear

and Apple WATCH is located at the

center of the screen.

•

Ensure that the NFC Antenna position

on the smartphone is in contact with

the vehicle authentication pad (wireless

charging pad).

•

The location of the NFC Antenna on the

smartphone may vary by phone model,

so please contact the smartphone

manufacturer for details.

•

NFC communication may not work for

some smartphones depending on the

internal structure of the smartphone.

Move the smartphone to the left or

right of the indoor authentication pad

(wireless charging pad) to operate.

To register the digital key (smartphone)

from the infotainment system

2C_AVNRegisterSmartPhone

If you cannot register the digital key

(smartphone) with the My Hyundai app,

try registering from the infotainment

system.
1. Turn off the vehicle, and then turn on

the vehicle with a smart key and have

your smart key with you in the vehicle.

2. Put the gear in P (Park), from the

infotainment system Settings menu,

select

Settings

Vehicle

Digital key

Smartphone key

and press the

Save

button.

3. Place your smartphone on the vehicle

authentication pad (wireless charging

pad) with the screen facing up. (In

case of Apple WATCH, the watch face

must be on the pad).

•

When the digital key (smartphone)

is saved, a message appears on the

infotainment system screen.

Convenience Features

5-18

Information

•

If you want to register a different

digital key (smartphone), refer

to the “Deleting your digital key

(smartphone)” and delete the digital

key (smartphone) before re-registering.

An active Digital Key can be shared

through the My Hyundai app with a

different smartphone.

•

During the digital key saving process,

the process may cancel when:

The smartphone is removed from the

vehicle authentication pad (wireless

charging pad)

The infotainment system screen is

changed

The engine is turned off

The gear is shifted

•

The registering process does not start if

a smart key is not in the vehicle.

•

Some smartphones may not start

the registering process depending

on the internal structure. Move the

smartphone to the left or right on the

vehicle authentication pad (wireless

charger pad) and try registering the

smartphone.

Using the digital key (smartphone)

The driver can lock or unlock the door by

placing the smartphone on the outside

door handle, and the vehicle can be

started by placing the smartphone on

the vehicle authentication pad (wireless

charging pad).

Samsung smartphone

OCN7053094

[A]: Door handle authentication pad
[B]: NFC Antenna

Information

•

The location of the NFC Antenna on the

smartphone may vary by phone model,

so please contact the smartphone

manufacturer for details.

•

The NFC Antenna position on Samsung

device can be found in the following

path: Setup > Connections > NFC and

contactless payments.

5-19

•

2C_SmartPhoneSample

The NFC Antenna position on Apple

iPhone is located at the top of the rear

[A] and Apple WATCH is located at the

center of the screen [B].

•

Touch the Door handle NFC Antenna

position with the back of your

smartphone. (In case of Apple WATCH,

the watch face must be on the pad).

Locking/Unlocking the doors

•

If the driver places the digital key

(smartphone) NFC antenna to the

driver’s or passenger’s door handle

authentication pad (A) for more than 2

seconds, the door locks or unlocks.

•

After unlocking the doors, the doors

are automatically re-lock after 30

seconds unless a door is opened.

•

If the smartphone digital key does

not operate, try again after moving

the smartphone away from the door

handle authentication pad (more than

4 in. (0.1 m)).

Information

You cannot lock your vehicle using the

digital key (smartphone) if any of the

following occurs:

•

The smart key is in the vehicle.

•

The Engine Start/Stop button is in the

ACC or ON position.

•

Any of the doors are open.

Starting the vehicle

After placing your registered digital

key (smartphone) on the vehicle

authentication pad (wireless charging

pad), depress the brake pedal and press

the Engine Start/Stop button.
After starting the vehicle, the digital key

(smartphone) may be removed from

the vehicle authentication pad (wireless

charging pad).
For more details on the basic way to start

the vehicle, refer to the “Push button

start ignition switch” section in chapter

Information

If a shared digital key (smartphone) is

used for the first time, the activating time

may take longer.

•

Place the shared digital key

(smartphone) on the door handle

authentication pad until the vehicle

door lock/unlock activates.

•

If a shared digital key (smartphone) is

first used on the vehicle authentication

pad (wireless charger pad), the initial

start of the vehicle may fail.

•

If the door lock/unlock is activated

once with the shared digital key

(smartphone) or the vehicle is started

with the digital key (smartphone) on

the vehicle authentication pad, the

digital key (smartphone) is registered in

the vehicle.

WARNING

The vehicle can be started when the

registered smartphone is placed on the

vehicle authentication pad (wireless

charging pad). Therefore, do not leave

unsupervised children or people who

are not aware of the system since it

can result in serious injury or death. In

addition, always have the registered

smartphone with you to prevent vehicle

theft when leaving the vehicle.

Convenience Features

5-20

Deleting your digital key

(smartphone)

Turn on the vehicle with a smart key.

Have your smart key with you in the

vehicle.

2C_AVNDeleteDegitalKey

Deleting all registered digital key

(smartphone)

To delete all the registered digital key

(smartphone), from the Settings menu

select

Setup

Vehicle

Digital Keys

Smartphone key

Delete

all in the

infotainment system.

•

The “

Delete all

” button is disabled

if there is no registered digital key

(smartphone).

2C_AVNDeleteMySmartPhone

Deleting my registered digital key

(smartphone)

To delete only my registered digital key

(smartphone), from the Settings menu

select

Setup

Vehicle

Digital Keys

Smartphone key

My Smartphone Key

Delete

in the infotainment system.

•

If a shared digital key (smartphone) is

registered, it cannot be deleted.

•

A new smartphone can be registered

after deleting the existing digital key

(smartphone) from “

My Smartphone

Key

” menu.

Information

•

If the registered digital key

(smartphone) is deleted, the digital key

saved in the smartphone is also deleted.

•

If the digital key is deleted from

the smartphone, the digital key

(smartphone) registered in the vehicle

is also deleted.

•

The shared digital key registered in the

vehicle cannot be deleted individually.

•

Even though the Blue Link® App

is deleted from the smartphone, the

digital key saved in the smartphone is

not deleted.

•

Management of the digital key saved

in the smartphone is available from

the Digital Key App provided by the

smartphone manufacturer.

5-21

Digital Key (Card Key)

How to register digital key (Card

Key)

To use the card key as a digital key,

follow the following procedure.

2C_AVNRegisterCardKey

OCN7053070

[A]: Vehicle authentication pad

(Wireless charging pad)

1. Have both of your smart keys with you

in the vehicle.

2. Select

Setup

Vehicle

Digital Keys

NFC Card Key

from the Settings

menu, and check whether “

Use

” is

selected in the infotainment system.

3. Place your card key on the vehicle

authentication pad (wireless charging

pad) while the engine is on.

4. Register your card key by selecting

Setup

Vehicle

Digital Keys

NFC

Card Key

Save

from the Settings

menu in the infotainment system.

Information

•

Only one digital key (card key) can be

registered to the vehicle. If it must be

replaced, delete the existing card key

before registering the new card key.

•

To register a digital key (card key),

both of your smart keys must be in the

vehicle.

•

Once a digital key (card key) is

registered, it cannot be registered in

another vehicle. It is possible to re-

register it to the original vehicle.

Using the digital key (card key)

The driver can lock or unlock the door by

placing the card key on the outside door

handle, and the vehicle can be started

by placing the card key on the vehicle

authentication pad (wireless charging

pad).

Locking/Unlocking the doors

OCN7053097

[A]: Door handle authentication pad
[B]: Card key NFC Antenna

If the driver places the digital key (card

key) to the driver’s or passenger’s

door handle authentication pad (A) for

more than 2 seconds, the door locks or

unlocks.
After unlocking the doors, the doors are

automatically re-locked after 30 seconds

unless a door is opened.

Convenience Features

5-22

Information

You cannot lock your vehicle using

the digital key (card key) if any of the

following occurs:

•

The smart key is in the vehicle.

•

The Engine Start/Stop button is in the

ACC or ON position.

•

Any of the doors are open.

Starting the vehicle

After placing your registered digital key

(card key) on the vehicle authentication

pad (wireless charging pad), depress the

brake pedal and press the Engine Start/

Stop button.
For more information on the basic way

to start the vehicle, refer to the “Push

button start ignition switch” section in

chapter 6.

WARNING

The vehicle can be started when the

registered card key is placed on the

vehicle authentication pad (wireless

charging pad). Therefore, do not leave

unsupervised children or people who

are not aware of the system since it

can result in serious injury or death. In

addition, always have the registered

card key with you to prevent vehicle

theft when leaving the vehicle.

Information

•

The digital key (card key) may not

work under the following conditions:

The digital key (card key) is

not placed on the door handle

authentication pad or vehicle

authentication pad (wireless charging

pad) correctly.

The digital key (card key) is near

NFC-enabled cards such as credit

cards or smartphones.

If the digital key (card key) does not

work, try again after moving the

digital key (card key) away from

the door handle authentication pad

(more than (4 in. (0.1 m)).

•

The digital key (card key) can be

damaged by impacts. If the digital key

(card key) is damaged, replace the

digital key (card key) with a new one

and register it again.

•

Long-time exposure to high

temperature may cause the digital key

(card key) to malfunction. Be careful

not to expose the digital key (card key)

to direct sunlight or high temperature.

•

Leaving the digital key (card key)

on the in-vehicle authentication pad

(wireless charging pad) while driving

may cause the digital key (card key)

to malfunction. Remove the digital

key (card key) from the in-vehicle

authentication pad (wireless charging

pad) after starting the vehicle.

•

Keep the digital key (card key) away

from the smartphone when charging

the smartphone. If the digital key

(card key) is placed between the

smartphone and the in-vehicle

authentication pad (wireless charging

pad) while the smartphone is being

charged, the digital key (card key)

may malfunction. For example, when

charging smartphone while the digital

key (card key) is attached to the back of

the smartphone case.

5-23

Deleting your digital key (card key)

2C_AVNDeleteCardKey

1. Turn on the engine with a smart key.

Have your smart key with you in the

vehicle.

2. From the infotainment system settings

menu, select

Setup

Vehicle

Digital

Keys

NFC Card Key

Delete

•

The “

Delete

” button is disabled

if there is no digital key (card key)

registered.

Personalized profile and vehicle

settings

You can set the registered digital key

(smartphone) profiles for Driver 1 and

Driver 2. When you use the digital key

(smartphone), the vehicle can be set to

the user-defined personalized profile

(includes items such as vehicle settings

and audio preferences).

Linking/Unlinking profile

How to link user profile

1. Select

Setup

User Profile

Profile Settings

Link Digital Key

(Smartphone)

from the Settings menu

in the infotainment system.

2. Select “

Link

” to connect the

registered smartphone’s digital key

and the user’s profile.

3. Follow the instructions according

to the message on the infotainment

system screen.

How to unlink user profile

Select

Setup

User Profile

Profile

Settings

, and then deselect “

Link Digital

Key (Smartphone)

”

from Settings menu

in the infotainment system.

•

Unlinking is possible only when user

profile is linked.

Information

•

User profile cannot be linked to

both Driver 1 and Driver 2 that are

connected to single smartphone.

Personalization operates with the

recently linked user profile, and the

previously linked user profile will be

automatically canceled.

•

User profile link works only when the

digital key is registered to the vehicle.

•

Digital key (card key) cannot be linked

with a user profile.

•

If the user profile linked digital key

in the smartphone is deleted, the

digital key should be re-registered and

personalized by linking the user profile

again.

Convenience Features

5-24

Vehicle personalization operation

•

The personalization function linked with digital key works when the profile linked

smartphone is placed on the outside door handle authentication pad to lock or

unlock the doors.

•

The profile set by the digital key can be changed manually from the infotainment

system.

•

The personalization function using the digital key can be operated after linking the

digital key in the infotainment system profile menu.

•

The personalization function works only when the vehicle is OFF or when the

vehicle is started remotely. If the vehicle is not started remotely, the personalization

function does not work with the digital key.

Information

User profile operation according to door lock/unlock system is as follows:

Item

Personalization Operation

Initial value

Guest

Profile linked smartphone key

Linked profile

Profile unlinked smartphone key

Recently activated profile

NFC card key
Smart key

5-25

Vehicle personalization with digital key

The available personalization function in the vehicle is as follows:

System

Personalization Item

Infotainment

system vehicle

settings

Lamp

Blink number of one-touch signal lamps

Cluster

Information display on the cluster, Voice volume,

Welcome sound

Seat

Seat position

Door

Automatic door lock/unlock, Two Press Unlock

Climate

Temperature Unit, Automatic ventilation

Infotainment

system

Navigation

Preferred volume of the navigation system, Recent

destination

User preset

My menu list settings, Radio preset

Phone connectivity Bluetooth preferential connect CarPlay/Android

Auto On/Off

Air

conditioning

Operating condition

Latest operation setup of the following functions:

Temperature, AUTO, air flow direction, air volume,

air conditioner, air intake control, SYNC, Front

windshield defroster, OFF

CAUTION

If you leave the digital key after locking or unlocking the doors or starting up the

vehicle with the smart key, the doors can be locked by the central door lock. Please

carry around the digital key all the time.

Information

The infotainment system may change after software updates. For more information, refer

to the user’s manual provided in the infotainment system and the quick reference guide.

Convenience Features

5-26

Used Vehicle/Digital Key

Maintenance

Purchasing used vehicle

If any of the digital key devices

(smartphone key, card key) are

registered in the vehicle, the “

Digital

key registered

” message appears once

on the infotainment system screen or

instrument cluster when the Engine

Start/Stop button is in the ON position

after unlocking the doors. When

purchasing a used vehicle, make sure

to check the message and delete the

smartphone key and card key registered

by the previous user and inform the

purchase of a used vehicle through

Hyundai Customer Care Center.
If the card key comes with the vehicle,

check whether it operates properly.

Digital key maintenance

If you need to repaired or replaced your

Digital Key system, make sure your

smartphone key is still active. You may

have to pair your phone again using the

HYUNDAI Digital Key app.

Limitations of the System

•

HYUNDAI Digital Key app on the

smartphone and card key may not

work if:

- Smartphone battery or the vehicle

battery is discharged.

- NFC or Bluetooth is turned off on

the smartphone settings.

- The card key is in a wallet or card

holder, or overlapped with other

cards.

- If you use a smartphone cover

that uses wireless communication

or is made of metal, remove the

smartphone cover.

•

The vehicle may not be controlled by

the smartphone if any of the following

occurs:

- Other smartphone functions (calls,

urgent call, audio or NFC payment),

apps, or wireless earphones are

operating.

- The digital key app function such

as basic setting or app launching is

limited by the prior policy according

to the manufacturer.

5-27

DOOR LOCKS

Operating Door Locks from

Outside the Vehicle

Mechanical key

OCN7053009

1. Press the lever located under the

cover with mechanical key. (1)

2. While pushing the lever so that the

mechanical key does not fall out of

the cover hole, slowly push it towards

the rear of the vehicle and remove the

cover. (2)

3. After removing the cover, only driver’s

door can be locked or unlocked by

using mechanical key.

4. Turn the key toward the rear of the

vehicle to lock and toward the front of

the vehicle to unlock. (3)

If you lock/unlock the driver’s door with

a key, the driver’s door will lock/ unlock

automatically.
Once the door is unlocked, it may be

opened by pulling the door handle.
Make sure that doors are closed securely.

Information

Be careful when locking the door by

mechanical key operation, only the

driver’s door can be locked/unlocked.

Refer to Chapter 5 “Operating door locks

from inside the vehicle” to lock from

inside the vehicle.

Information

When removing the cover, be careful not

to lose cover and any scratches.

When the key cover freezes and does not

open, lightly tap or indirectly warm(hand

temperature, etc.) it.

Do not apply excessive force to the door

and door handle. It may be damaged.

Convenience Features

5-28

Remote key

ODN8059279L

To lock the doors, press the Door Lock

button (1) on the remote key.
To unlock the doors, press the Door

Unlock button (2) on the remote key.
Once the doors are unlocked, they may

be opened by pulling the door handle.
When closing the door, push the door by

hand. Make sure that doors are closed

securely.

Smart key

OCN7050078

To lock the doors, press the button on

the outside door handle while carrying

the smart key with you or press the door

lock button on the smart key.
To unlock the doors, press the button on

the outside door handle while carrying

the smart key with you or press the door

unlock button on the smart key.
Once the doors are unlocked, they may

be opened by pulling the door handle.
When closing the door, push the door by

hand. Make sure that doors are closed

securely.

Information

•

In cold and wet climates, door lock

and door mechanisms may not work

properly due to freezing conditions.

•

If the door is locked/unlocked multiple

times in rapid succession with either

the vehicle key or door lock switch, the

system may stop operating temporarily

in order to protect the circuit and

prevent damage to system components.

•

Two press unlock setting can be

changed in the User Settings mode on

the cluster.

5-29

Operating Door Locks from

Inside the Vehicle

With the door handle

OCN7050010

Front door

If the inner door handle is pulled when

the door is locked, the door will unlock

and open.

Rear door

If the inner door handle is pulled once

when the door is locked, the door will

unlock. If the inner door handle is pulled

once more, the door will open.

If any door is opened, the doors will not

lock even though the central door lock

switch is pressed.

Information

If a power door lock ever fails to function

while you are in the vehicle try one or

more of the following techniques to exit:

•

Operate the door unlock feature

repeatedly (both electronic and

manual) while simultaneously pulling

on the door handle.

•

Operate the other door locks and

handles, front and rear.

•

Lower a front window and use the

mechanical key to unlock the door from

outside.

With the central door lock switch

Driver’s door

OCN7053011

Front passenger’s door

OCN7050083N

•

When pressing the ( ) portion (1) of

the switch, all vehicle doors will lock.

- If any door is opened, the doors will

not lock even though the central

door lock switch (1) is pressed.

•

When pressing the ( ) portion (2)

of the switch, all vehicle doors will

unlock.

•

Doors indicating light (3)
When all vehicle doors are locked, the

indicating lights on the driver’s door

and passenger’s door will turn off. If

any door is unlocked, it would go on.

Convenience Features

5-30

WARNING

•

The doors should always be fully

closed and locked while the

vehicle is in motion. If the doors

are unlocked, the risk of being

thrown from the vehicle in a crash is

increased.

•

Do not pull the inner door handle of

the driver’s or passenger’s door while

the vehicle is moving.

WARNING

Do not leave the elderly, children or

animals unattended in your vehicle. An

enclosed vehicle can become extremely

hot, causing death or serious injury

to the elderly, unattended children

or animals who cannot escape from

the vehicle. Children might operate

features of the vehicle that could injure

them, or they could encounter other

harm, possibly from someone gaining

entry to the vehicle.

WARNING

Always secure your vehicle.
Leaving your vehicle unlocked increases

the potential risk to you or others from

someone hiding in your vehicle.
To secure your vehicle, while depressing

the brake, move the shift lever to the

P (Park) position, engage the parking

brake, and place the ignition switch

in the LOCK/OFF position, close all

windows, lock all doors, and always

take the key with you.

WARNING

If you stay in the vehicle for a long time

while the weather is very hot or cold,

there are risks of injuries or danger to

life. Do not lock the vehicle from the

outside when someone is in the vehicle.

WARNING

Opening a door when something is

approaching may cause damage or

injury. Be careful when opening doors

and watch for vehicles, motorcycles,

bicycles or pedestrians approaching the

vehicle in the path of the door.

5-31

Automatic Door Lock and Unlock

Features

Your vehicle is equipped with features

that automatically locks or unlocks your

vehicle based on settings you select in

the infotainment system.

Automatically Lock Enable on speed

When this feature is set in the

infotainment system, all the doors are

locked automatically when the vehicle

exceeds 9 mph (15 km/h).

Automatically Lock Enable on speed

or shift

When this feature is set in the

infotainment system, all the doors are

locked automatically when the vehicle

exceeds 9 mph (15 km/h) or when the

vehicle is shifted out of P (Park) while the

vehicle is running.

Automatically Unlock Enable on

Shift to P

When this feature is set in the

infotainment system, all the doors are

unlocked automatically when the vehicle

is shifted back to P (Park) while the

vehicle is running.

Automatically Unlock On vehicle off

When this feature is set in the

infotainment system, all the doors are

unlocked automatically when the vehicle

is turned off.
For detailed information, refer to the

separately supplied infotainment system

manual.

Additional unlock safety feature

airbag deployment

As an additional safety feature, all doors

are automatically unlocked when an

impact causes the airbags to deploy.

Child-Protector Rear Door Locks

OCN7053215

The child safety lock is provided to help

prevent children seated in the rear from

accidentally opening the rear doors.
The rear door safety locks should be used

whenever children are in the vehicle.
The child safety lock is located on the

edge of each rear door. When the child

safety lock is in the lock position, the

rear door will not open if the inner door

handle is pulled.
To lock the child safety lock, insert

a small flat blade tool (for example,

screwdriver or similar) into the slot and

turn it to the lock position as shown.
To allow a rear door to be opened from

inside the vehicle, unlock the child safety

lock.

WARNING

If children accidently open the rear

doors while the vehicle is in motion,

they could fall out of the vehicle. The

rear door safety locks should always

be used whenever children are in the

vehicle.

Convenience Features

5-32

REAR OCCUPANT ALERT (ROA)

Rear Occupant Alert helps prevent the

driver from leaving a passenger in the

rear seats.

Rear Occupant Alert Operation

OCN7H053028L

When the driver turns off the engine and

opens the driver’s door after opening and

closing a rear door, a warning message

“Check rear seat for passengers and

belongings” appears on the cluster.

WARNING

Rear Occupant Alert provides

information to the driver to check

the rear seats but it does not detect

whether there is an object or passenger.

Always check the rear seats when

leaving the vehicle.

Information

The open and close history of the rear

door is initialized if the driver turns off the

engine and lock vehicle doors.However,

the alarm may sound again whenever the

driver’s door is opened if the previous

history of the rear door is not initialized.

5-33

THEFT-ALARM SYSTEM

This system helps to protect your vehicle

and valuables. The horn will sound and

the hazard warning lights will blink

continuously if any of the following

occur:

- A door is opened without using the

remote key or smart key.

- The trunk is opened without using the

remote key or smart key.

- The engine hood is opened.
The alarm continues for 30 seconds, then

the system resets. To turn off the alarm,

unlock the doors with the remote key or

smart key.
The Theft Alarm System automatically

sets 30 seconds after you lock the doors

and the trunk. For the system to activate,

you must lock the doors and the trunk

from outside the vehicle with the remote

key or smart key or by pressing the

button on the outside of the door handle

with the smart key in your possession.
The hazard warning lights will blink and

the chime will sound once to indicate the

system is armed.
Once the security system is set, opening

any door, the trunk, or the hood without

using the remote key or smart key will

cause the alarm to activate.
The Theft Alarm System will not set if the

hood, the trunk, or any door is not fully

closed. If the system will not set, check

the hood, the trunk, or the doors are fully

closed.
Do not attempt to alter this system or

add other devices to it.

Information

•

Do not lock the doors until all

passengers have left the vehicle. If the

remaining passenger leaves the vehicle

when the system is armed, the alarm

will be activated.

•

If the vehicle is not disarmed with the

remote key or smart key, open the

doors by using the mechanical key and

place the ignition switch in the ON

position (for remote key) or start the

engine (for smart key) and wait for 30

seconds.

•

When the system is disarmed but a

door or trunk is not opened within 30

seconds, the system will be rearmed.

Convenience Features

5-34

OCN7050012

The Driver Position Memory System is

provided to store and recall the following

memory settings with a simple button

operation.

- Driver’s seat position

WARNING

Never attempt to operate the driver

position memory system while the

vehicle is moving.
This could result in loss of control, and

an accident causing death, serious

injury, or property damage.

Information

•

If the battery connector is disconnected,

the memory settings will be erased.

•

If the Driver Position Memory System

does not operate normally, have the

system checked by an authorized

HYUNDAI dealer.

Storing Memory Positions

1. Shift to P (Park) while the ignition

switch is in the ON position.

2. Adjust the driver’s seat position and

instrument panel illumination intensity

to the desired position.

3. Press the SET button. The system

will beep once and notify you ‘Press

button to save settings’ on the cluster

display.

4. Press one of the memory buttons (1 or

2) within 4 seconds. The system will

beep twice when successfully stored.

Recalling Memory Positions

1. The ignition switch is in the ON

position.

2. Press the desired memory button

(1 or 2). The system will beep once,

and then the driver’s position will

automatically adjust to the stored

positions.

3. ‘Settings 1 (or 2) applied’ appears on

the cluster display.

Information

If your vehicle is equipped with

additional navigation, please refer to the

infotainment system manual separately

supplied.

DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)

5-35

Information

•

To recall the settings of memory button

2 while the settings of memory button

1 is being recalled, press the SET

button or memory button 1 to stop the

adjustment, and then press memory

button 2.

•

While recalling the stored positions,

pressing one of the control buttons

for the driver’s seat will cause the

movement of that component to stop

and move in the direction that the

control button is pressed.

Resetting Integrated Memory

System

If the Driver position memory system

does not work properly, initialize the

system as follows.

How to initialize:
1. Stop the vehicle and open the driver’s

door with the ignition switch in the

ON position and the vehicle shifted to

P (Park).

2. Pull the driver’s seat forward as far

as possible and have the seatback

upright as much as possible using

the driver’s seat forward/backward

adjustment and seatback angle

(recline) switches.

3. Push the SET button and seat forward

movement switch for 2 seconds

simultaneously.

While Resetting the Integrated

Memory System

A notification sound is heard and the seat

is adjusted to the most reward position.
Then the seat and seatback move to the

default center position.
The resetting procedure and the

notification sound may stop if:

•

The memory button is pressed.

•

The seat control switch is operated.

•

The gear is shifted out of P (Park).

•

The driving speed exceeds 2 mph (3

km/h).

•

The driver’s door is closed.

NOTICE

•

If the seat movement or notification

sound stops before the process

is complete, restart the resetting

procedure.

•

Before resetting the IMS, make sure

there are no objects on or around the

driver’s seat.

•

After resetting the IMS, the driver’s

seat must be adjusted and stored

again to recall the memory position.

Convenience Features

5-36

Seat Easy Access Operation (if

equipped)

Seat easy access moves the driver’s seat

automatically as follows:

•

Without smart key system

- It will move the driver’s seat

rearward when the ignition key is

removed and the driver’s door is

opened.

- It will move the driver’s seat forward

when the ignition switch is in the

ACC or ON position.

•

With smart key system

- It will move the driver’s seat

rearward when the ignition switch

is in the LOCK/OFF is in the OFF

position and the driver’s door is

opened.

- It will move the driver’s seat

rearward when the ignition switch

is in the LOCK/OFF position and the

driver’s door is opened.

You can activate or deactivate the

Easy Access Function from the User

Settings Mode on the cluster display.
For more details, refer to “Cluster

display (Type A)” in chapter 4

Information

If your vehicle is equipped with additional

infotainment system, you can set the

system in the infotainment system.

5-37

STEERING WHEEL

Motor Driven Power Steering

(MDPS)

The system assists you with steering the

vehicle. If the vehicle is turned off or

if the power steering system becomes

inoperative, you may still steer the

vehicle, but it will require increased

steering effort.
Also, the steering effort becomes heavier

as the vehicle’s speed increases and

becomes lighter as the vehicle’s speed

decreases for better control of the

steering wheel.
Should you notice any change in the

effort required to steer during normal

vehicle operation, have the system

checked by an authorized HYUNDAI

dealer.

CAUTION

•

If the Motor Driven Power Steering

System does not operate normally,

the warning light (

) will illuminate

on the instrument cluster. You may

steer the vehicle, but it will require

increased steering efforts. Take your

vehicle to an authorized HYUNDAI

dealer and have the system checked

as soon as possible.

•

When an abnormality is detected

in the Motor Driven Power Steering

system, to prevent an accident, the

steering assist function may become

inoperative. At this time, the warning

light turns on or blinks on the cluster.

The steering wheel may become

difficult to control or operate. Have

your vehicle checked immediately,

after moving the vehicle to a safe

area.

Information

The following symptoms may occur during

normal vehicle operation:

•

The steering effort may be high

immediately after placing the ignition

switch in the ON position.

This happens as the system performs

the MDPS system diagnostics. When

the diagnostics are completed, the

steering wheel effort will return to its

normal condition.

•

When the battery voltage is low, you

may have to put more steering effort.

However, it is a temporary condition so

that it will return to normal condition

after charging the battery.

•

A click noise may be heard from the

MDPS relay after the ignition switch is

in the ON or LOCK/OFF position.

•

Motor noise may be heard when the

vehicle is at a stop or at a low driving

speed.

•

When you operate the steering wheel

in low temperatures, abnormal noise

may occur. If the temperature rises, the

noise will disappear. This is a normal

condition.

•

When an error is detected from the

MDPS, the steering effort assist

function may become inoperative

in order to prevent fatal accidents.

Instrument cluster warning lights may

be on or the steering effort may be

high. If these symptoms occur, drive

the vehicle to a safe area as soon as it is

safe to do so. Have the system checked

by an authorized HYUNDAI dealer as

soon as possible.

Convenience Features

5-38

Tilt Steering / Telescope Steering

When adjusting the steering wheel to a

comfortable position, adjust the steering

wheel so that it points toward your chest,

not toward your face. Make sure you can

see the instrument cluster warning lights

and gauges. After locking the lever, push

the steering wheel both up and down to

be certain it is locked in position. Always

adjust the position of the steering wheel

before driving.

WARNING

NEVER adjust the steering wheel while

driving. This may cause loss of vehicle

control resulting in an accident.

OCN7050013

To adjust the steering wheel angle and

height:
1. Pull down the lock-release lever (1).
2. Adjust the steering wheel to the

desired angle (2) and distance

forward/back (3).

3. Pull up the lock-release lever to lock

the steering wheel in place.

Information

Sometimes the lock release lever may not

engage completely. This may occur when

the gears of the locking mechanism do not

completely mesh. If this occurs, pull down

on the lock release lever, readjust the

steering wheel again, and then pull back

up on the release lever to lock the steering

wheel in place.

CAUTION

While adjusting the steering wheel

height, please do not push or pull it

hard since the fixture can be damaged.

5-39

Horn

OCN7050016

To sound the horn, press the area

indicated by the horn symbol on your

steering wheel (see illustration). The

horn will operate only when this area is

pressed.

NOTICE

Do not strike the horn severely to

operate it, or hit it with your fist. Do not

press on the horn with a sharp-pointed

object.

NOTICE

Do not clean the steering wheel surface

with the following products:

•

Organic solvents such as thinner,

alcohol and gasoline

•

Chemical products such as leather

cleaner, coating agent, and wax

Convenience Features

5-40

MIRRORS

Inside Rearview Mirror

Before driving your vehicle, check to

see that your inside rearview mirror is

properly positioned. Adjust the rearview

mirror so that the view through the rear

window is properly centered.

WARNING

Make sure your line of sight is not

obstructed. Do not place objects in the

rear seat, cargo area, or behind the rear

head restraints which could interfere

with your vision through the rear

window.

WARNING

To prevent serious injury during an

accident or deployment of the air bag,

do not modify the rearview mirror and

do not install a wide mirror.

WARNING

NEVER adjust the mirror while driving.

This may cause loss of vehicle control

resulting in an accident.

NOTICE

When cleaning the mirror, use a paper

towel or similar material dampened

with glass cleaner. Do not spray glass

cleaner directly on the mirror as this

may cause the liquid cleaner to enter

the mirror housing.

Day/night rearview mirror

(if equipped)

OCN7053017

[A] : Lever, [B] : Day, [C] : Night

Make this adjustment before you start

driving and while the day/night lever is in

the day position.
Pull the day/night lever towards you to

reduce glare from the headlights of the

vehicles behind you during night driving.

Remember that you lose some rearview

clarity in the night position.

5-41

Electrochromic mirror (ECM) with

HomeLink® system (if equipped)

OCN7050084N

Your vehicle may be equipped with

a Gentex Automatic-Dimming Mirror

with an Integrated HomeLink® Wireless

Control System.
During nighttime driving, this feature will

automatically detect and help reduce

rearview mirror glare. The HomeLink®

Universal Transceiver allows you to

activate your garage door(s), electric

gate, home lighting, etc.
(1) HomeLink Channel 1
(2) HomeLink Channel 2
(3) HomeLink Channel 3
(4) Garage Door Opener Status Indicator :

Closing or Closed

(5) HomeLink Operation Indicator
(6) Garage Door Opener Status Indicator :

Opening or Opened

(7) HomeLink User Interface Indicator

Automatic-Dimming Night Vision Safety™

(NVS

) Mirror (if equipped)

The NVS® Mirror automatically helps

reduce glare by monitoring light levels in

the front and the rear of the vehicle. Any

object that obstructs either light sensor

will degrade the automatic dimming

control feature.

For more information regarding NVS®

mirrors and other applications, please

refer to the Gentex website:
www.gentex.com

Your mirror will automatically dim

upon detecting glare from the vehicles

traveling behind you.
The mirror defaults to the ON position

each time the vehicle is started.

Integrated HomeLink

Wireless Control

System

The HomeLink® Wireless Control System

can replace up to three hand-held

radio-frequency (RF) transmitters with

a single built-in device. This innovative

feature will learn the radio frequency

codes of most current transmitters to

operate devices such as gate operators,

garage door openers, entry door locks,

security systems, even home lighting.

Both standard and rolling code-equipped

transmitters can be programed by

following the outlined procedures.
Additional HomeLink® information can

be found at: www.homelink.com, www.

youtube.com/HomeLinkGentex or by

calling 1-800-355-3515.
Retain the original transmitter of the

RF device you are programing for use

in other vehicles as well as for future

HomeLink® programing. It is also

suggested that upon the sale of the

vehicle, the programed HomeLink®

buttons be erased for security purposes.

Convenience Features

5-42

WARNING

Before programing HomeLink® to a

garage door opener or gate operator,

make sure people and objects are out

of the way of the device to prevent

potential harm or damage. Do not

use the HomeLink® with any garage

door opener that lacks the safety

stop and reverse features required

by U.S. federal safety standards (this

includes any garage door opener model

manufactured before April 1, 1982).

A garage door that cannot detect an

object - signaling the door to stop and

reverse - does not meet current U.S.

federal safety standards. Using a garage

door opener without these features

increases the risk of serious injury or

death.

Programing HomeLink

Please note the following:

•

When programing a garage door

opener, it is advised to park the

vehicle outside of the garage.

•

It is recommended that a new battery

be placed in the hand-held transmitter

of the device being programed to

HomeLink® for quicker training and

accurate transmission of the radio-

frequency signal.

•

Some vehicles may require the

ignition switch to be in the ACC

(or “Accessories”) position for

programing and/or operation of

HomeLink®.

•

In the event that there are still

programing difficulties or questions

after following the programing steps

listed below, contact HomeLink® at:

www.homelink.com, www.youtube.

com/HomeLinkGentex or by calling

1-800-355-3515.

Programing

To program most devices, follow these

instructions:

OCN7050085N

1. Press and release (1), (2) or (3) button.

•

If the indicator (4) is turned ON in

Orange, go to Step 3) since it is a

new programing.

•

If the indicator (4) is continuously

turned ON or flashes in Green

rapidly several times, go to Step 2)

since it is a programed button.

2. Press and hold the button you wish

to program for approximately 15-

25 seconds until the LED flashes in

Orange for several times.

3. Hold the Garage Door Opener Original

Transmitter near the HomeLink Mirror.

5-43

OCN7050086N

4. Press the Original Transmitter

button until the indicator (4) is

turned continuously ON or flashes in

Green for approximately 10 seconds

and it indicates the programing is

completed.

5. However, the indicator (4) flashes

in Green continuously, but if the

garage door opener does not operate,

please continue to follow the step

6 and 7 (“Rolling Code Programing”

procedures).

6. Firmly press and release the “Learn,”

“Smart,” or “Program” button while

the indicator (4) flashes in Green.

Once the button is pressed, you have

approximately 30 seconds to initiate

the next step.

Information

At the garage door opener motor, (security

gate motor, etc.) locate the “Learn,”

“Smart,” or “Program” button. This

can usually be found where the hanging

antenna wire is attached to the motor-head

unit (see the device’s manual to identify

this button). The name and color of the

button may vary by manufacturer. A

ladder and/or second person may simplify

the following steps.

7. Return to the vehicle and firmly press,

hold for two seconds and release the

HomeLink button up to three times.

Do not press the HomeLink button

rapidly. At this point programing is

complete and your device should

operate when the HomeLink button is

pressed and released.

Information

•

Some garage door openers require to

press the programed button on the

mirror up to three times right after

the programing is just completed to

operate the garage door.

•

The indicator (4) is turned ON in

Orange and flashes for about 60

seconds, during the programing mode

and if a programing is not succeeded

within the 60 seconds, the programing

mode will be abort.

HomeLink® should now activate your

rolling code equipped device.

Convenience Features

5-44

Gate operator & Canadian programing

During programing, your handheld

transmitter may automatically stop

transmitting. Continue to press the

Integrated HomeLink® Wireless Control

System button while you press and re-

press (“cycle”) your handheld transmitter

every two seconds until the frequency

signal has been learned. The indicator

light will flash slowly and then rapidly

after several seconds upon successful

training.

OCN7050085N

Operating HomeLink®

1. Press and release one of the

HomeLink buttons (1, 2 or 3) that

programed.

2. The HomeLink indicator (4) will

operate as below:

- Indicates Green and is continuously

ON (Fixed Code Garage Door

Opener)

- Flashes in Green rapidly (Rolling

Code Garage Door Opener)

OCN7050087N

Erasing HomeLink® buttons

1. Press and hold the button (1) and (3)

simultaneously.

2. The indicator (4) is turned

continuously ON in orange for about

10 seconds.

3. Then the indicator (4) color changes

to Green and flashes rapidly.
Release the buttons once the green

indicator flashes.

4. Now HomeLink button (1), (2) and (4)

memories are all cleared.

NVS® is a registered trademark and

Z-Nav™ is a trademark of the Gentex

Corporation, Zeeland, Michigan.

HomeLink® is a registered trademark

owned by Johnson Controls,

Incorporated, Milwaukee, Wisconsin.

FCC ID: NZLUAHL5A
IC: 4112A-UAHL5A

5-45

Information

This device complies with Part 15 of the

FCC Rules.

Operation is subject to the following three

conditions:

1. This device may not cause harmful

interference, and

2. This device must accept any

interference received, including

interference that may cause undesired

operation.

3. The transceiver has been tested

and complies with FCC and

Industry Canada rules. Changes or

modifications not expressly approved

by the party responsible for compliance

could void the user’s authority to

operate the device.

Two Way Communication Programing

1. Complete the HomeLink

“Programing” first.

2. Before the first 10 times HomeLink

button is pressed after the

programing, the following steps

MUST occur to program two way

communication. (only for some older

garage doors)

OCN7050088N

3. Press and release the programed

HomeLink button to activate the

garage door.

4. Once the garage door is stopped,

press and release the “Learn” or

“Smart” button on the Garage door

opener within 1 minute from the time

of pressing the programed HomeLink

button on mirror.

Hyundai Elantra Hybrid (2024 year). Manual in english - page 6
