Hyundai Ioniq 5 (2024 year). Manual in english

Instrument Cluster

Additional information display

Vehicle Settings

Drive info

(infotainment System)

Type A

Vehicle Settings in the infotainment

system provides user options for a variety

of settings including door lock/unlock

features, convenience features, driver

assistance settings, etc.

Vehicle Settings menu

• Driver Assistance

• Drive Mode

• EV

• Head-Up Display

ONE1041047N

• Cluster

Drive information is displayed for 4

• Climate

seconds after the vehicle is turned off.

• Seat

Driving assist information

• Lights

• Door

• Convenience

The information provided may differ

depending on which features are

applicable to your vehicle.

WARNING

Do not operate the Vehicle Settings while

driving. This may cause distraction

resulting in an accident.

ONE1041031N

The current operation conditions of

Manual Speed Limit Assist, Cruise

Control, Smart Cruise Control, Lane

Following Assist, Highway Driving Assist,

etc., is displayed.

4-28

5. Convenience Features

Accessing Your Vehicle

5-4

Smart Key

5-4

Immobilizer System

5-11

Hyundai Digital Key

5-12

Door Locks

5-25

Operating Door Unlocks from Outside the Vehicle (Manual type)

5-25

Operating Door Unlocks from Outside the Vehicle (Electric type)

5-25

Operating Door Locks from Outside the Vehicle (Manual type)

5-27

Operating Door Locks from Outside the Vehicle (Electric type)

5-27

Operating Door Lock/Unlock from Inside the Vehicle

5-29

Automatic Door Lock and Unlock Features

5-31

Electronic Child Safety Lock

5-32

Vehicle Auto-Shut Off Function

5-33

Theft-alarm System

5-34

Advanced Rear Occupant Alert (ROA)

5-35

System Setting

5-35

System Operation

5-35

Integrated Memory System

5-36

Storing Memory Positions

5-36

Recalling Memory Positions

5-36

Resetting the System

5-37

Seat Easy Access

5-37

Memory Seat Configurations

5-38

Storing Memory Positions

5-39

Recalling Memory Positions

5-39

Steering Wheel

5-39

Motor Driven Power Steering (MDPS)

5-39

Tilt/Telescopic Steering

5-40

Horn

5-41

Heated Steering Wheel

5-41

Mirrors

5-42

Inside Rearview Mirror

5-42

Side View Mirrors

5-52

Reverse Parking Aid

5-54

Digital Center Mirror (DCM)

5-55

System Component

5-56

How To Change the Mode

5-57

Display Settings (Digital Mirror Mode)

5-57

Windows

5-61

Power Windows

5-62

Vision Roof

5-66

Resetting the Vision Roof

5-67

Exterior Features

5-68

Hood

5-68

Front trunk

5-69

Power Liftgate

5-70

Smart Liftgate

5-76

Electric Charging Door

5-78

Augmented Reality HUD

5-80

Head-up Display Settings

5-80

Head-up Display Information

5-81

Precautions while Using the Head-up Display

5-82

Lighting

5-83

Exterior Lights

5-83

Interior Lights

5-86

High Beam Assist (HBA)

5-89

High Beam Assist Settings

5-90

High Beam Assist Operation

5-90

High Beam Assist Malfunction and Limitations

5-91

Wipers And Washers

5-92

Front Windshield Wipers

5-93

Front Windshield Washers

5-94

Automatic Climate Control System

5-95

Climate

5-96

Automatic Temperature Control Mode

5-96

Manual Temperature Control Mode

5-98

System Operation

5-105

System Maintenance

5-106

Windshield Defrosting And Defogging

5-108

To Defog Inside Windshield

5-108

5. Convenience Features

To Defrost Outside Windshield

5-109

Defogging Logic

5-109

Rear Window Defroster

5-109

Climate Control Additional Features

5-110

A/C Automatic Drying

5-110

Auto Defogging System

5-111

Auto Dehumidify

5-112

Recirculating Air When Washer Fluid Is Used

5-113

Auto. Controls That Use Climate Control Settings (for driver’s seat)

5-113

Smart Ventilation

5-113

Storage Compartment

5-114

Center Console Storage

5-114

Glove Box

5-115

Interior Features

5-116

Cup Holder

5-116

Sunvisor

5-117

Power Outlet

5-117

USB Charger

5-118

Wireless Smart Phone Charging System

5-119

Cluster Fascia Side Panel

5-121

Vehicle to Load (V2L)

5-122

Clock

5-122

Coat Hook

5-122

Floor Mat Anchor(s)

5-123

Rear Side Window Sunshades

5-123

Luggage Net Holder

5-124

Cargo Security Screen

5-124

Infotainment System

5-126

USB Port

5-126

Antenna

5-126

Steering Wheel Remote Controls

5-126

Infotainment System

5-127

Voice Recognition

5-128

Bluetooth® Wireless Technology

5-128

Convenience Features

Type D

Accessing Your Vehicle

Smart Key

Type A

ONE1052035N

Your electric vehicle uses a Smart Key,

which you can use to lock or unlock the

driver and passenger doors, the charging

door or the rear liftgate.

ONE1051259N

(1) Door lock

Type B

(2) Door unlock

(3) Liftgate open/close

(4) Panic

(5) Remote Start

(6) Charging door open/close

(7) Forward / Backward (if equipped)

Locking your vehicle

Manual type

ONE1052034N

Type C

ONE1051004L

To lock your vehicle using the door handle

button or the Smart Key:

ONE1051260N

1. Make sure all doors, the hood and the

liftgate are closed.

2. Press the Door Lock button (1) on the

Smart Key. The hazard warning lights

will blink with an alarm, and the doors

will be locked.

5-4

3. In addition, pushing the button on the

Note that you cannot lock your vehicle

door handle (the engraved part) while

using the door handle touch sensor if any

keeping the smart key will lock all

of the following occur:

doors.

• The Smart Key is in the vehicle.

Electric type (if equipped)

• The Start/Stop button is in ACC or ON

position.

• Any of the doors are open except for

the liftgate.

WARNING

Do not leave the Smart Key in your vehicle

with unsupervised children. Unattended

children could press the Start/ Stop

ONE1051003

button and may operate power windows

or other controls, or even make the

To lock your vehicle using the door handle

vehicle move, which could result in

touch sensor or the Smart Key:

serious injury or death.

1. Make sure all doors, the hood and the

liftgate are closed.

2. Press the Door Lock button (1) on the

Smart key. The hazard warning lights

Information

will blink with an alarm, and the handles

•

To fold/unfold the rearview mirror

will retract back.

simultaneously when the door is

• In addition, touching the touch sensor

locked/unlocked, select Settings >

on the door handle (the engraved part)

Vehicle > Convenience > Welcome

while keeping the smart key will lock all

Mirror > Enable on Door Unlock in the

doors and let the door handle to retract

infotainment screen.

back.

•

The door handle button will only

operate when the smart key is within

Information

28~40 in. (0.7~1 m) from the outside

• The side view mirror will fold if ‘Enable

door handle. Other people can also

on Door Unlock’ is selected from the

open the doors without the smart key in

Settings menu in the infotainment

possession.

system screen. Select:

•

After unlocking the doors, the doors will

- Setup > Vehicle Settings >

lock automatically after 30 seconds

Convenience > Welcome Mirror >

unless a door is opened.

Enable on Door Unlock

•

The infotainment system may change

• The door handle touch sensor will only

after software updates. For more

operate when the smart key is within

information, refer to the user’s manual

28~40 in. (0.7~1 m) from the outside

provided in the infotainment system

door handle.

and the quick reference guide.

• Touching the door handle touch sensor

does not unlock the doors. To unlock

the doors, refer to the following page.

5-5

Convenience Features

Unlocking your vehicle

2. Touch the touch sensor on the door

Manual type

handle(engraved part) or press the

Door Unlock button (2) on the smart

key. All door handles will pop out and

the doors will be unlocked and the

hazard warning lights will blink and the

chime will sound.

3. After unlocking the doors, the doors will

automatically re-lock after 30 seconds

unless a door is opened.

When you set the Two Press Unlock

function

ONE1051004L

1. Make sure you have the smart key in

To unlock your vehicle using the door

your possession.

handle button or the Smart Key:

2. Touch the touch sensor on the door

1. Make sure you have the smart key in

handle(engraved part) or press the

your possession.

Door Unlock button (2) on the smart

2. Pushing the button on the door

key. The driver’s door handle will pop

handle(engraved part) or press the

out and the driver’s door will be

Door Unlock button (2) on the smart

unlocked.

key. All doors handles will be unlocked

3. Touch the touch sensor on the door

and the hazard warning lights will blink

handle(engraved part) or press the

twice.

Door Unlock button (2) on the smart key

3. After unlocking the doors, the doors will

within 4 seconds again. All door

automatically re-lock after 30 seconds

handles will pop out and the doors will

unless a door is opened.

be unlocked and the hazard warning

Electric type (if equipped)

lights will blink twice and the chime will

sound.

4. After unlocking the doors, the doors will

automatically re-lock after 30 seconds

unless a door is opened.

Two Press Unlock Feature

The priority for unlocking the driver door

only, or unlocking all the doors with one

press may be adjusted in the User

Settings menu in the cluster display.

The Two Press Unlock feature, when

ONE1051004

enabled, will require the user to press the

door unlock button once for driver door

When you release the Two Press Unlock

only and twice for unlocking all the doors.

function

Select or Deselect the Two Press Unlock

To unlock your vehicle using the door

Feature in the User Settings menu in the

handle touch sensor or the Smart Key:

cluster display. The option can be found

1. Make sure you have the smart key in

under the following menu:

your possession.

USER SETTINGS > DOOR >TWO PRESS

UNLOCK

5-6

The Two Press Unlock Feature can also be

• The doors may not lock or unlock in the

enabled or disabled by pressing the door

following situations.

lock and unlock buttons simultaneously

- If the touch sensor is touched with

on the Key FOB:

gloves on

Press and hold both the DOOR LOCK

- If the door is suddenly approached

button and the DOOR UNLOCK button

• The infotainment system may change

simultaneously until the hazard warning

after software updates. For more

lights blink.

information, refer to the user`s manual

This will enable or disable the Two Press

provided in the infotainment system

Unlock feature. Repeat this procedure to

and the quick reference guide.

enable/disable the mode again.

Information

• The side view mirror will unfold if

‘Enable on Door Unlock’ is selected

During a car wash or rain, in order to

from the Settings menu in the

minimize unintentional operation of the

infotainment system screen.

touch sensor, the touch sensor may

become insensitive. This is not a

Select:

malfunction.

- Settings > Vehicle Settings >

Convenience> Welcome Mirror >

Enable on Door Unlock

Opening the liftgate

• The door handle touch sensor will only

To open the liftgate:

operate when the smart key is within

1. Make sure you have the smart key in

28~40 in. (0.7~1 m) from the outside

your possession.

door handle.

2. Press the liftgate open/close button (3)

• The doors may lock or unlock if the

on the vehicle or press and hold the

touch sensor of the outer door handle is

Liftgate handle switch on the smart key

recognized while washing your car or

for more than one second. The hazard

due to heavy rain.

warning lights will blink two times and

• To prevent unintentional door lock or

the liftgate will open.

unlock:

Press the lock button on the smart key

Information

and immediately press the unlock

The liftgate open/close button will only

button along with the lock button for

operate when the smart key is within 28

more than 4 seconds. The hazard

in. (0.7 m) from the liftgate.

warning lights will blink four times. At

this time, the doors will not lock or

unlock even though the touch sensor is

touched on the outside door handle.

To deactivate the function, press the

door lock or unlock button on the smart

key.

5-7

Convenience Features

Remotely opening and closing the

Information

charging door

To open charging door remotely:

• The vehicle must be in P (Park) for the

remote start function to start.

Press the Charging Door Open/Close

button (6) for more than one second, or

• The vehicle turns off if you get on the

press the charging door open/close

vehicle without a registered smart key.

button in the vehicle while carrying the

• The vehicle turns off if you do not get on

smart key.

the vehicle within 10 minutes after

To close the charging door:

remotely starting the vehicle.

Press the Charging Door Open/Close

• The Remote Start button (5) may not

button (6) for more than a second while

operate if the smart key is not within 32

the door is open, or press the charging

feet (10 m).

door open/close button in the vehicle

• The vehicle will not remotely start if the

while carrying the smart key when the

vehicle hood or liftgate is opened.

charging door is opened.

Remotely moving vehicle forward or

Remotely initiating electricity

backward

charging

if equipped

To remotely start charging the vehicle:

With the smart key, the driver can move

Press the charging door open/close

the vehicle forward or backward using the

button in the smart key while the charging

Forward or Backward button (7) on the

connector is connected to the vehicle.

smart key.

For more details, refer to “Charging

For more details, refer to “Remote Smart

Electric Vehicle” section in chapter 1.

Parking Assist (RSPA)” section in chapter

Remotely starting vehicle

You can start the vehicle using the

Start-up

Remote Start button (5) on the smart key.

You can start the vehicle without inserting

To start the vehicle remotely:

the key.

1. Press the door lock button on the smart

For more details, refer to the “Start/Stop

key within 32 feet (10 m) from the

Button” section in chapter 6.

vehicle.

2. Press the Remote Start button (5) for

Information

more than 2 seconds within 4 seconds

If the smart key is not moved for some

after pressing the door lock button.

time, the detection function for smart key

3. The hazard warning lights will blink and

operation will pause. Lift the smart key to

the vehicle will start.

activate the detection again.

4. To turn off the remote start function,

press the Remote Start button (5) once.

5-8

Loss of a smart key

NOTICE

A maximum of three Smart Keys can be

To prevent damaging the smart key:

registered to a single vehicle. If you

• Keep the smart key in a cool, dry place

happen to lose your smart key, it is

to avoid damage or malfunction.

recommended that you should

Exposure to moisture or high

immediately take the vehicle and

temperature may cause the internal

remaining keys to your authorized

circuit of the smart key to malfunction

HYUNDAI dealer or tow the vehicle, if

which may not be covered under

necessary.

warranty.

• Avoid dropping or throwing the smart

Smart key precautions

key.

The smart key may not work if any of the

• Protect the smart key from extreme

following occur:

temperatures.

• The smart key is close to a radio

transmitter such as a radio station or an

airport which can interfere with normal

Mechanical key

operation of the transmitter.

If the Smart Key does not operate

• The smart key is near a mobile two way

normally, you can lock or unlock the

radio system or a mobile phone.

driver’s door by using the mechanical key.

• Another vehicle’s smart key is being

To remove the mechanical key from the

operated close to your vehicle.

smart key:

• If your windows are tinted, especially

with metallic window tint, it may cause

frequency interference, reducing the

smart key operating range.

If the smart key does not work correctly,

open and close the door with the

mechanical key. If you have a problem

with the smart key, contact an authorized

HYUNDAI dealer.

If the smart key is in close proximity to

your mobile phone, the signal could be

OFE048007

blocked by your mobile phone’s normal

operational signals. This is specifically

1. Press the mechanical key and remove it

relevant when the phone is active such as

from the smart key.

making and receiving calls, text

2. Move the release lever in the direction

messaging, and/or sending/receiving

of the arrow (1) and then remove the

emails. When possible, avoid keeping the

mechanical key (2). Insert the

smart key and your mobile phone in the

mechanical key into the key hole on the

same location such as pants or jacket

door.

pocket to avoid interference between the

To reinstall the mechanical key, put the

two devices.

key into the hole and push it until a click

sound is heard.

5-9

Convenience Features

Battery replacement

Information

If the Smart Key is not working properly,

Changes or modifications not expressly

try replacing the battery with a new one.

approved by the party responsible for

Battery Type: CR2032

compliance could void the user’s

To replace the battery:

authority to operate the equipment. If the

keyless entry system is inoperative due to

changes or modifications not expressly

approved by the party responsible for

compliance, it will not be covered by your

manufacturer’s vehicle warranty.

Information

This device complies with Part 15 of the

FCC rules.

Operation is subject to the following three

conditions:

OFE048009

1. This device may not cause harmful

If the Smart Key is not working properly,

interference, and

try replacing the battery with a new one.

2. This device must accept any

interference received, including

interference that may cause undesired

operation.

3. Changes or modifications not expressly

approved by the party responsible for

compliance could void the user’s

authority to operate the device.

NOTICE

ODN8059266

Battery Type: CR2032

• Keep the smart key away from

electromagnetic materials that blocks

To replace the battery:

electromagnetic waves to the key

1. Remove the mechanical key.

surface.

2. Use a slim tool to pry open the rear

• Always have the smart key with you

cover of the smart key.

when leaving the vehicle. If the smart

3. Remove the old battery and insert the

key is left near the vehicle, the vehicle

new battery. Make sure the battery

battery may be discharged.

position is correct.

4. Reinstall the rear cover of the smart

key.

If you suspect your smart key might have

sustained some damage, or you feel your

smart key is not working correctly,

contact an authorized HYUNDAI dealer.

5-10

If this occurs, your vehicle may not start.

WARNING

Remove any metal objects or additional

THIS PRODUCT CONTAINS A BUTTON

keys near the smart key before

BATTERY.

attempting to start the vehicle again.

If swallowed, a lithium button battery can

If the system repeatedly does not

cause severe or fatal injuries within 2

recognize the coding of the key, contact

hours. Keep batteries out of reach of

an authorized HYUNDAI dealer.

children.

Do not attempt to alter this system or add

If you think batteries may have been

other devices to it. Electrical problems

swallowed or placed inside any part of the

could result that may make your vehicle

body, seek immediate medical attention.

inoperable.

WARNING

In order to prevent theft of your vehicle,

Information

do not leave spare keys anywhere in your

vehicle. Your immobilizer password is a

customer unique password and should be

kept confidential.

btn_AM-BATT

An inappropriately disposed battery can

be harmful to the environment and

NOTICE

human health. Dispose of the battery

according to your local law(s) or

The transponder in your key is an

regulations.

important part of the immobilizer system.

It is designed to give years of trouble-free

service, however you should avoid

exposure to moisture, static electricity

Immobilizer System

and rough handling. Immobilizer system

The immobilizer system helps protect

malfunction could occur.

your vehicle from theft. If an improperly

coded key (or other device) is used, the

vehicle is disabled.

When the Start/Stop button is pressed to

Information

the ON position, the immobilizer system

This device complies with Part 15 of the

indicator should come on briefly, then go

FCC rules.

off. If the indicator starts to blink, the

Operation is subject to the following three

system does not recognize the coding of

conditions:

the key.

1. This device may not cause harmful

Press the Start/Stop button to the OFF

interference.

position, then press the Start/Stop button

to the ON position again.

2. This device must accept any

interference received, including

In some circumstances, the vehicle may

interference that may cause undesired

not recognize your smart key if another

operation.

smart key device is nearby or a metal

object such as a key chain is causing

3. Changes or modifications not expressly

interference with the smart key.

approved by the party responsible for

compliance could void the user’s

authority to operate the device

5-11

Convenience Features

Hyundai Digital Key

Digital key (smartphone) NFC

function

if equipped

You can use the Digital Key NFC (Near

Field Communication) function after turn

Digital Key Application

your smartphone NFC settings on. And

To use Hyundai Digital Key mobile app,

you should unlock & turn on smartphone

you should install Hyundai digital key

screen to use it.

application. Search ‘Hyundai digital key’

* To change the NFC mode of the

in the Google Play Store and download

smartphone, please refer to the

the app. Please refer to the detailed

smartphone manual or contact to the

manual of the digital key app. The option

customer service center of smartphone

can be found under the following app

manufacturers.

menu:

Menu > Application Info > Tutorial

Digital key (smartphone)

Please note the manual before using the

app.

Hyundai Digital Key (Smartphone) Pairing

* This service is only available for Android

1. Turn the vehicle on with the Smart key

smartphones. Please confirm

and make sure to keep the smart key

supported/compatible devices on our

inside the vehicle during digital key

website.

registration.

WARNING

For used vehicle

If any of the digital key (smartphone key

or card key) is already registered when

you press ON button after unlocking the

doors, the message ‘Digital key(s) active’

appears on the cluster display once. If you

buy a used vehicle, you should confirm

the message and delete the registered

smartphone key and card key. In addition,

please notify the Hyundai Customer Care

ONE1051272N

Center.

2. Register your Digital key from the

If the card key does not work properly,

vehicle user setting menu as follows.

please delete the card key and register

From the infotainment screen menu, go

the smartphone key and re-register the

to Setup > Vehicle > Digital Key >

card key.

Smart Phone Key then select the Save

from submenu.

For vehicle maintenance

If you need to have your Digital Key

System repaired or replaced please

ensure your Smartphone Key is still

active. You may have to pair your phone

again.

In the case, re-initialize your Digital Keys

using the Hyundai Digital Key mobile app.

5-12

Hyundai Digital Key (Smartphone Key)

Information

Deletion

The Save button will be disabled if the

1. Turn the vehicle on with the Smart key

digital key (Smartphone key) is already

and make sure to keep the smart key

saved.

inside the vehicle during delete

Please refer to “Digital Key Delete” in

process.

this manual and follow the digital key

delete procedure in your car before

Digital key save.

Please refer to the ‘Tutorial’ on your

Digital key app and delete the previous

saved key in your smartphone before

save.

3. Select the vehicle to save on your

Digital key application and activate the

save mode.

ONE1051272N

* Save mode is available only on the

2. Delete your Digital key from the vehicle

vehicle owner’s Digital key application.

user setting menu as follows.From the

4. Place the backside of smartphone onto

infotainment screen menu, go to Setup

the wireless charging pad(in-vehicle

> Vehicle > Digital Key > Smart Phone

authentication pad). The saving

Key then select the Delete from

process will begin automatically.

submenu.

5. Once the digital key save is complete, a

Information

message will be shown on the

infotainment screen or cluster display.

The Delete button will be disabled if

there is no digital key (Smartphone key)

6.Remove the smartphone from the pad

saved.

and complete the saving process.

3. Once the digital key delete is complete,

a message will be shown on the

infotainment screen or cluster display.

4. Go to Initialize Digital Key menu on the

digital key application and select the

vehicle to delete the digital key

information.

• Open the Hyundai Digital Key app >

Menu > Initialize Digital Key

ONE1051005

* If the saved digital key information in

[A] : Wireless Charging Pad (In-vehicle

your car is deleted due to vehicle

Authentication Pad)

maintenance, the digital key in your

smartphone should be deleted as well.

* For more information, please refer to

the ‘Tutorial’ on your Digital key app.

5-13

Convenience Features

NFC door lock/unlock

CAUTION

•

If the smartphone is removed from the

interior authentication pad during

enrollment, the saving process will be

canceled.

•

If the infotainment or instrument

cluster screen is changed during

enrollment, the saving process will be

canceled.

•

If the vehicle is turned off during

enrollment, the saving process will be

ONE1051006

canceled.

[A] : Door handle authentication pad

•

If the gear is shifted, the saving process

[B] : NFC Antenna in the rear side of smart phone

will be canceled.

You should contact your smartphone’s

NFC antenna(backside of phone) to door

•

If you try to save the smartphone which

handle authentication pad (A) marked

is not logged in with the vehicle owner’s

position near by the lock button) of

ID or if you try to save the Card key, the

driver’s (or front passenger’s) outside

saving process will not begin.

door for 2 seconds to lock or unlock the

•

If the NFC setting on your smartphone

doors. If the Two Press Unlock feature is

is off, the saving process will not begin.

applied (press twice for unlocking),

•

If the smartphone screen is changed to

driver’s seat door will be unlocked by

off or locked status, the saving process

contacting the digital key (smartphone

will be canceled.

key). In this state, if you contact one more

•

If there is no Smart key during the save

time within 4 seconds, all the doors

process, the saving process will not

unlock. Please make sure the doors are

begin.

locked. If you do not open any of the

doors after unlocking, it automatically

re-lock after 30 seconds.

Set up main vehicle

Note that you cannot lock your vehicle

You can manage multiple digital keys

when you contact NFC antenna in the

from the Digital key app. From the list of

smartphone to the door handle pad if any

digital keys you own, select the vehicle

of the following occurs:

you want to make your priority vehicle.

• The Proximity / Smart Key is in the

For more information, please refer to the

vehicle.

‘Tutorial’ on your Digital key app.

• The Start/Stop button is in ACC or ON

position.

• Any of the doors, hood and liftgate is

opened.

If the smartphone digital key does not

work, please remove the smartphone

more than 4 inches (0.1 m) from the door

handle authentication pad and try it

again.

5-14

After unlock the door or start up the

Information

vehicle with digital key, even though the

driver tries to lock the doors by the central

After reconnecting the vehicle battery

door lock switch, the door lock will be

power supply or charging the battery, it

once locked and immediately released at

may take time to operate due to remote

the moment of door closed.

renewal of security information. When

you lock or unlock the door with NFC,

Start-up with Digital Key

please contact and hold your smartphone

1. After placing your registered

on the door handle until it works.

smartphone onto the interior

The solution allows for offline mode

authentication pad (wireless charger),

usage when the mobile data connection

step on the brake and press the

of the smartphone is weak. When you are

Start/Stop button.

in the place where the mobile data

2. After start-up, the digital key data will

connection of your smartphone is

be automatically updated. It takes 5 to

available and place your smartphone on

20 seconds, after that, the smartphone

the interior authentication pad (wireless

can be go into the wireless charging

charger) and start up your vehicle or

mode automatically. Once the vehicle

contact the digital key on the door handle

started, you can remove the

to lock or unlock the door, the remote

smartphone from the pad.

renewal of security information starts

automatically. Even though the motor is

turned on, please wait until the remote

renewal process is completed and

wireless charger is converted to charging

mode.

CAUTION

The motor can be turned on if the

registered smartphone or card key is

placed on the interior authentication pad

ONE1051005

[A] : Wireless Charging Pad (In-vehicle

(wireless charger). Do not leave

Authentication Pad)

unsupervised children or people who are

not aware of the system since it can result

in serious injury or death. Always have the

registered digital key (smartphone) or

card key with you to prevent vehicle theft

when leaving the vehicle.

For more information, refer to the

"Start/Stop Button" in chapter 6.

5-15

Convenience Features

Remote Control with Digital Key

CAUTION

To use the remote control function with

your android smartphone, Bluetooth

•

If metallic window tint was applied to

must be turned on.

your vehicle, it may cause bad

Bluetooth connection or performance

Remote Control Connection with Digital

degradation of the digital key.

Key

•

If multiple users operate the remote

1. Open Hyundai digital key application

control function simultaneously, the

on the smartphone. Select the vehicle

connection between the digital key and

to activate the remote control function

the vehicle might result in failed

as a main vehicle.

commands. Please connect and

2. Approach with the activated

operate the remote control function

smartphone app to your vehicle and

only the necessary user.

you can check whether the connection

•

When using the remote control

is available. If it enables your

operation, the driver (the remote

smartphone to connect, connect with

control user) should leave the vehicle

your vehicle by pressing the connect

after confirming the door lock (the

button. The remote control function is

chime sounds once and the hazard

activated after completing the process.

warning lights blink).

Remote Control Operation with Digital

•

The remote functions of the Digital Key

Key

app enables the vehicle to be

You can execute the remote control

controlled from a set distance. If the

operation including door lock/unlock,

digital key or the vehicle goes beyond

panic on/off, remote start / remote stop

the operable distance, the remote

and liftgate opening. The icon for each

control function might be disconnected

function will be highlighted and

or canceled.

alarm/vibration also provided when the

•

If the digital key (smartphone) is

operation is performed.

connected with the vehicle for the

Note that you cannot lock your vehicle

remote control, the driver with the key

using the Hyundai digital key app if any of

goes far away from the vehicle, the

the following occurs:

function might not work.

• The Start/Stop button is in ACC or ON

•

If the remote control operation is

position.

executed where the mobile connection

is weak, Bluetooth connection is poor

• Any doors are open.

due to several Bluetooth devices or

When the smartphone and the vehicle are

there is an object such as metal or

connected by the Bluetooth function but

concrete, it might be delayed or the

the remote control command cannot be

operable distance might decrease. You

received over 5 minutes, the remote

should not cover the smartphone with

control connection is canceled

your hand or place other devices which

automatically.

can cause frequency interference. It

may result in poor performance.

•

If the remote control function is not

available, please use NFC function to

lock or unlock the doors.

5-16

Remote Start with Digital Key

Smartphone change/App deletion

• When the shift button of your vehicle is

If you change your smartphone or delete

in P (Park) and all of the doors including

the Hyundai Digital Key App, please refer

liftgate and hood is locked and the

to the following to set up your Digital Key:

vehicle is off, press the Door Lock

Smartphone Change/ Reset

button in the Hyundai Digital Key app

then press the Remote Start button

If you change or reset the smartphone,

within 4 seconds.

the registered digital key in your previous

smartphone may not be used. Please

You can confirm the vehicle is on if the

refer to following procedure to use the

hazard warning lights blinks two times

digital key.

and the chime sounds.

1. Install the digital key application and

• If you want to turn off the vehicle, press

Remote Engine Stop. Air Conditioner /

Heating system maintains the same

2. If you are the owner, retry the Digital

status as when you last used the

key save process.

vehicle.

3. If you are the sharer, need to re-share

• Unless you put the registered digital

the key from owner.

key (smartphone) on the interior

App delete & reinstall/ Delete App data

authentication pad (wireless charger)

You can re-download the digital key from

when the remote start function is on,

server in these cases as follow procedure.

the vehicle will turn off.

1. Reinstall the application and log in.

• If you do not get on the vehicle within

10 minutes after the vehicle turns on,

2. Input the PIN number for user

the vehicle will turn off.

verification.

For more information, refer to the

3. If PIN is correct, digital key data will be

"Start/Stop Button" in chapter 6.

re-downloaded to your smartphone

and you can use it without any further

Vehicle information Display

registration or sharing.

The digital key application displays the

Smartphone operability with Digital Key

vehicle information such as driving or

door conditions through the

The digital key application may not be

communication with the vehicle.

available to old type smartphones. Please

check the available smartphone models

• How to check : Select the vehicle what

with your dealer. NFC antenna position on

you want to check and touch the

the smartphone can be confirmed on

vehicle image, then vehicle information

each smartphone’s manual or contact to

display page will be shown.

customer service center of the

• Contents : accumulated odometer,

smartphone manufacture.

latest fuel economy, driving range, fuel

remaining, tire pressure, doors

CAUTION

lock/unlock status and last data

updated time.

• Do not leave the registered digital key

(smartphone) and card key in your

* Displayed vehicle date could be differed

vehicle. Please carry around your keys

from the current vehicle condition.

all the times.

* For more information, please refer to

the ‘Tutorial’ on your Digital key app.

5-17

Convenience Features

•

If you happen to lose your digital key

•

You should be careful not to press the

(smartphone) or card key registered as

remote control button on the digital key

a main user’s key, you should

(smartphone) accidentally.

immediately delete the key on the

•

If the digital key (smartphone) is

vehicle’s key menu. For more

discharged or defective or you cannot

information, refer to the Digital Key

use the digital key since the vehicle

Deletion in this chapter.

battery is discharged, use the inside

•

If you registered your digital key

door lock button to lock all of the doors.

(smartphone) or card key in the vehicle,

a message appears on the instrument

cluster and let you know the key is

CAUTION

registered.

(Message: Digital key(s) active.)

•

Hyundai digital key app on the

smartphone and card key may not work

•

If you buy a used vehicle, you should

if any of the following occurs:

confirm the message and delete the

registered smartphone key and card

Hyundai digital key app on the

key. In this case, you should carry your

smartphone is deleted. (Required to

smart key.

reinstall the app)

•

If you keep place the NFC card of the

Account log in information of

digital key on the interior

Hyundai digital key app is expired.

authentication pad (wireless charger)

(Required to re-log in)

while driving, it may cause a

When you try to log in to another

malfunction of the NFC card.

smartphone instead of the registered

•

You should remove your NFC card of

smartphone with same user account.

the digital key on the interior

Smartphone rooting or app hacking is

authentication pad after turning on the

detected.

vehicle.

Smartphone battery or the vehicle

•

Hyundai digital key app may not work

battery is discharged.

properly when the NFC or Bluetooth

Smartphone’s screen is off or locked.

communication between smartphone

NFC or Bluetooth is turned off on the

and car is not good.

smartphone settings.

•

If the remote control operation is

Smartphone’s mobile network

executed where the mobile connection

setting is off or airplane mode is

is weak, Bluetooth connection is poor

activated.

due to lots of Bluetooth devices or

there is an object such as metal or

A credit card is overlapped in the

concrete, it might be delayed or the

back of your smartphone or metal or

operable distance might decrease.

thick case is used.

Especially, you should not cover the

Use the card key with insert it into the

smartphone with your hand or place

wallet or card holder or overlapping

other devices which can cause

with other cards.

frequency interference. It may result in

If you use a smart phone cover that

poor performance.

uses wireless communication or is

•

If the remote control function is not

made of metal, the digital key NFC

activated, please use NFC function to

function may not work properly.

lock or unlock the doors

Remove the smart phone cover

before using the digital key NFC

function.

5-18

• The vehicle may not be controlled by

Digital key (Card key)

the smartphone if any of the following

occurs:

Digital key (Card key) save

- Basic and necessary functions of the

1. Install Hyundai digital key app in main

smartphone manufacturer are

user’s smartphone and register the

operating. (General call, urgent call,

digital key (smartphone). Please refer

audio or NFC payment)

to the registration method of the digital

key (smartphone).

- Wireless earphone is operating.

(General call, urgent call or audio)

2. Using the Pair Card Key menu on the

digital key application, you can activate

- The digital key app function such as

the Card Key registration mode.

basic setting or app launching is

limited by prior policy according to

* NFC authentication : enter the NFC

the manufacturer while using a

authentication menu and contact the

smartphone produced by domestic

smartphone on the outside door

and foreign manufactures.

handle.

* If you change the smartphone number,

* Bluetooth authentication : enter the

you should modify the user account

Bluetooth authentication menu and

information on the HYUNDAI customer

press the OK button for activation.

web site to use the digital key app.

If you activate the registration mode,

* If the vehicle owner changes the

you should complete the Card saving

smartphone device, the new smartphone

process within 5 minutes.

should be registered in the car after

* If you have not registered the digital

deleting the registered digital

key (smartphone), please register the

key(smartphone).

digital key (card key) with two smart

* If a sharer changes or reset the

keys.

smartphone, the key should be re-shared

from owner.

* Some of the old smartphone may not

work properly. Please check the available

smartphone models with your dealer.

* NFC antenna position on the

smartphone can be confirmed on each

smartphone’s manual or contact to

customer service center of the

smartphone manufacture.

5-19

Convenience Features

3. Register the NFC card key on the User’s

Digital key (Card key) deletion

Settings menu after turning on the

You should have the smart key to delete

vehicle.

the digital key (card key) so please carry

around the key.

1. Get on the vehicle with the smart key.

2. Delete the NFC card key on the User’s

Settings menu after turning on the

vehicle.

ONE1051273N

From the infotainment screen menu, go

to Setup > Vehicle > Digital Key > Card

Key then select the Save from

submenu.

The Save button will be disabled if the

ONE1051273N

digital key (Card key) is already saved.

From the infotainment screen menu, go

Please refer to “Digital Key Delete” in

to Setup > Vehicle > Digital Key > Card

this manual and follow the digital key

Key then select the Delete from

delete procedure in your car before

submenu.

Digital key save.

If there is no saved digital key(card

4. Place the NFC card key onto the interior

key), Delete menu will not be activated.

authentication pad (wireless charger).

• To delete the saved digital key (card

The saving process will begin

key), the smart key must be exist inside

automatically.

the vehicle.

5. If the key is enrolled, the message will

• The deleted digital key (card key) can

be displayed on the infotainment

be re-registered before registering a

screen or cluster display.

new digital key (card key).

• Once the card key registration mode is

• If you try to register a new digital key

activated, the process should be

(card key), the previously registered

completed within 5 minutes. After then,

digital key (card key) cannot be used

you should reactivate once again for

again.

registration.

• For the digital key(card key) saving, the

smart key(fob) must be exist inside of

vehicle.

• Once a Card key is registered, it cannot

be reuse onto another vehicle.

5-20

NFC door lock/unlock

After unlock the door or start up the

vehicle with digital key, even though the

driver tries to lock the doors by the central

door lock switch, the door lock will be

once locked and immediately released at

the moment of door closed.

Start-up with Card key

After placing your registered card key

onto the interior authentication pad

(wireless charger), step on the brake and

press the Start/Stop button.

ONE1051008

For more information, refer to the

[A] : Door handle authentication pad

"Start/Stop Button" in chapter 6.

[B] : NFC Antenna of the card key

You should contact digital key (card key)

NOTICE

to door handle authentication pad (1,

marked position near by the lock button)

•

The digital key (card key) may not work

of driver’s (or front passenger’s) outside

under the following conditions:

door for 2 seconds to lock or unlock the

- The digital key (card key) is not

doors. If the Two Press Unlock feature is

placed on the door handle

applied (press twice for unlocking),

authentication pad or vehicle

driver’s seat door will be unlocked by

authentication pad (wireless

contacting the digital key (card key). In

charging pad) correctly.

this state, if you contact one more time

- The digital key (card key) is near

within 4 seconds, all the doors unlock.

NFC-enabled cards such as credit

Inoperable condition

cards or smart phones.

If you do not contact the digital key (card

If the digital key (card key) does not

key) to the center of the door handle

work, try again after moving the

authentication pad accurately., it may not

digital key (card key) away from the

work. In addition, if you overlap and use

door handle authentication pad

the key with NFC-enabled cards such as

(more than 4 in. (0.1 m)).

transportation card or credit card, it does

•

The digital key (card key) can be

not work.

damaged by impacts. If the digital key

Note that if you try to lock your vehicle

(card key) is damaged, replace the

with digital key (card key) in following

digital key (card key) with a new one

cases, the doors will not be locked and

and register it again.

chime will sound for 3 seconds.

•

Long-time exposure to high

• The Smart Key is in the vehicle.

temperature may cause the digital key

• The Start/Stop button is in ACC or ON

(card key) to malfunction. Be careful

position.

not to expose the digital key (card key)

to direct sunlight or high temperature.

• Any of the doors, hood and liftgate are

open

5-21

Convenience Features

• Leaving the digital key (card key) on the

CAUTION

in-vehicle authentication pad (wireless

charging pad) while driving may cause

If you uncheck Enable digital keys, it is

the digital key (card key) to

impossible to lock or unlock the doors or

malfunction. Remove the digital key

start up the vehicle with digital keys such

(card key) from the in-vehicle

as smartphone and card key. If you check

authentication pad (wireless charging

Enable digital keys again, the registered

pad) after starting the vehicle.

digital keys(smartphone and card key) are

• Remove the digital key (card key) from

available. Even though you stop the

the smartphone before charging the

digital key function, the registered keys

smartphone. If the digital key (card key)

(smartphone and card key) are not

is placed between the smartphone and

deleted.

the in-vehicle authentication pad

(wireless charging pad) while the

smartphone is being charged, the

Personalized profile and vehicle

digital key (card key) may malfunction.

settings

For example, when charging

Connect the registered digital key with

smartphone while the digital key (card

personalized profile. Then in case you

key) is attached to the back of the

lock or unlock the door with the digital

smartphone case.

key NFC function or unlock the door

remotely by digital key application

Bluetooth connection, the vehicle will

Digital key application/cancellation

play the personalized user profile

If you do not want to use the digital key

settings. Profile connection and

(smartphone and card key), you can

personalization are available for Driver 1

disable the function temporarily. You

and Driver 2.

should have the smart key when you

change the settings.

Profile link/unlinked

From the infotainment screen menu, go

Profile link

to Setup > Vehicle > Digital Key > Enable

1. Select Setup > User Profile > Profile

Digital Keys (deselect)

Settings > Link Digital Key

(Smartphone) on the infotainment

Information

system menu.

For the digital key disable, the smart key

2. Unlock and place your smartphone on

must be exist inside the car. For the digital

the wireless charger according to a

key enable, the smart key is not needed.

message and it automatically starts to

interwork.

3. It begins the profile link with a

message.

4. If you select Link, the registered phone

number’s digital key and the user’s

profile are linked.

5. The interconnection process is

completed with a message.

5-22

• If you remove the smart phone from the

Information

wireless charger before completing the

The infotainment system may change

profile link, it does not work.

after software updates. For more

• To unlink the profile, the smart phone

information, refer to the user's manual

does not need to be on the wireless

provided in the infotainment system and

charger.

the quick reference guide.

Vehicle personalization operation

The personalization function linked with

Profile unlink

digital key works as following conditions:

1. Select Digital Key information on

• Contact the driver’s door handle with

infotainment Vehicle Settings menu. It

the profile linked smart phone to lock or

is possible to unlink only if the profile is

unlock the doors (Personalization does

interconnected.

not operate when locking or unlocking

2. Profile unlink is completed with a

the front passenger door.)

message.

• Remote door unlock with the profile

linked smartphone digital key app.

Information

The profile linked with digital key can be

If you connect both Driver 1 and Driver 2

changed manually in the infotainment

with a single smartphone, the

system setup screen.

smartphone digital key always works as

Driver 1.

Precaution for digital key profile link and

If you unlink the Driver 1, personalization

unlink

function will operate as Driver 2.

Profile operation according to door

lock/unlock system is as follows.

PRECAUTION for vehicle profile link and

Personalization

Item

unlink

Operation

When you link or unlink the profile of

Initial value

Guest

digital key, you should be careful of the

following.

Profile linked

• Profile link is possible to use with the

smart phone

Linked profile

digital key. (Infotainment Vehicle

key

Settings Mode > Digital Key > Enable

Digital Keys)

Profile

unlinked smart

• Profile link information remains even

phone key

Recently activated

when you set the digital key function

profile

disable.

NFC card key

• Only the smart phone with digital key

Smart key

app enables you to link your profile.

(Impossible to link with NFC card)

• The personalization function using the

• Profile link works only when the smart

digital key can be operated after linking

phone and the digital key are registered

the digital key on the infotainment

to the vehicle. The smart phone with

system profile menu.

another vehicle’s digital key cannot link

• You should use the personalization

profile.

function during stopping your vehicle

safely.

5-23

Convenience Features

Vehicle personalization with digital key

The available personalization function in the vehicle is as follows.

System

Personalization Item

Display mode, Display control, AR matching

HUD

adjustment, Content selection

Lamp

Blink number of one-touch signal lamps

Information display on the instrument cluster, Voice

Cluster

volume, Welcome sound, Theme selection

Seat/Mirror

USM

Door

Automatic door lock/unlock, Two Press Unlock

Temperature unit, shut off outside air (interlocked

Air conditioning

with washer fluid), Automatic ventilation, Auto

defogging on/off

Convenience

Wireless charging system on/off

Digital key on/off, Smartphone Key Paring/Deletion,

NFC

Card key Save/Delete

Preferred volume of the navigation system, Recent

Navigation

destination

AVN

User preset

Radio preset

Phone

Bluetooth preferential connect CarPlay/Android

connectivity

Auto/MirrorLink On/Off

Latest operation setup of the following

Operating

functions:Temperature, AUTO, air flow direction, air

Air conditioning

condition

volume, air conditioner, air intake control, SYNC,

Front windshield defroster, OFF

Driving

Smart mode

Information

The infotainment system may change after software updates. For more information,

refer to the user's manual provided in the infotainment system and the quick reference

guide.

CAUTION

If you leave the digital key after locking or unlocking the doors or starting up the vehicle

with the smart key, the doors can be locked by the central door lock. Please carry around

the digital key all the time.

5-24

Door Locks

Operating Door Unlocks from

Outside the Vehicle (Electric

type)

Operating Door Unlocks from

if equipped

Outside the Vehicle (Manual

type)

Smart key

Approach unlock system

The outside door handle will slide out and

the doors will unlock when the driver

approaches the vehicle possessing the

smart key.

The driver can activate/deactivate the

“Approach unlock” system on the

infotainment screen.

To activate Approach unlock system for

only the driver’s seat, select Settings >

Vehicle > Door > Remote power door

open > Unlock all doors in the

ONE1051004L

infotainment system screen.

To activate Approach unlock system,

select Settings > Vehicle > Door >

activate approach unlock in the

infotainment system. The outside door

handle will slide out and the door will

unlock when the driver approaches the

vehicle possessing the smart key. If

Approaching unlock system is

deactivated, the door handle will not slide

out even when the driver approaches to

the vehicle with the smart key. To unlock

ONE1051010L

doors when Approach unlock system is

Push the button on the front outside door

deactivated, touch the lock/unlock

handle (the engraved part) while carrying

sensor(engraved part) on the handle.

the Smart Key with you, all doors will

unlock.

Information

The hazard warning lights will blink twice

The infotainment system may change

and chime also sounds twice.

after software updates. For more

Once the doors are unlocked, when press

information, refer to the user’s manual

the front of the door handle (1) then rear

provided in the infotainment system and

of the door handle will pop out (2).

the quick reference guide.

Pull the outside door handle to open the

door.

5-25

Convenience Features

ONE1051276

ONE1051004

ONE1051010

• When the “Approach unlock” is

activated :

deactivated : The handle does not slide

out even when you approach with the

- If you approach (within 1 m) the driver

smart key in possession. The doors are

or front passenger’s door handle

unlocked if you press the outside

possessing the smart key, the outside

handle as the handles slide out.

door handles slide out and the doors

are unlocked. In this case, Hazard

• The doors will lock automatically and

Warning Flasher blinks twice and

the handles will slide in after 30

chime also sounds twice.

seconds unless a door is opened.

- After first approach, the vehicle tries

detecting the smart key every 5

Information

seconds and if the key is not

In emergency situations, such as battery

detected, the doors will lock

is dead, the outside electric door handle

automatically and the handles will

can still be operated in a way that the

slide in.

outside manual door handle operate.

5-26

Operating Door Locks from

Outside the Vehicle (Manual

Outside the Vehicle (Electric

type)

if equipped

Smart key

ONE1051004L

Push the button on the front outside door

ONE1051012

handle (the engraved part) while carrying

the Smart Key with you, all doors will lock.

The hazard warning lights will blink and

chime also sounds once.

Push the door to close.

ONE1051013

When all doors are closed, touch the

touch sensor on the front outside door

handle (the engraved part) while carrying

the Smart Key with you, outside door

handle will return and doors will be

locked.

The hazard warning lights will blink and

chime also sounds once.

5-27

Convenience Features

- Auto car wash

NOTICE

Keep the door locked with the

•

If the door is locked/unlocked multiple

outside door handle closed.

times in rapid succession with the

If the Smart Key is not in the vehicle,

smart key, door lock button or door lock

turn off the vehicle and stay the

switch, the system may stop operating

Smart Key away at least 2 m (78 in.)

temporarily in order to protect the

from the vehicle to prevent the

circuit. Also, the “Approach unlock”

outside door handle operates.

system may not operate. Try operation

after a sufficient time in case the

system does not operate due to

Digital key

multiple operations.

if equipped

•

“Approach unlock” system is not

Refer to ‘Hyundai Digital Key’ of this

operated continuously. Retry after a

chapter to lock or unlock the door from

certain period of time when all the

outside vehicle with digital key.

doors are closed.

Pull the outside door handle to open the

door after unlocking the door. Push the

door to close.

Information

•

In cold and wet climates, door lock and

door mechanisms may not work

properly due to freezing conditions.

•

If the door is locked/unlocked multiple

times in rapid succession with either

the vehicle key or door lock switch, the

system may stop operating temporarily

in order to protect the circuit and

prevent damage to system

components.

•

When washing the vehicle

- Self car wash

Keep the door locked with the

outside door handle closed.

To keep the door unlocked, push

back the outside door handle by

hand. This function prevents the door

handle from being damaged, and the

door handle pops out again when the

unlock button is pressed.

5-28

Mechanical key

Operating Door Lock/Unlock

from Inside the Vehicle

With the door handle

ONE1051015

Press the front part (1) of the door handle

to pull out the rear part of the door

handle. While keep pressing the front part

of the door handle, insert the mechanical

ONE1051016

key to the lock.

Front door

To lock the door, turn the key toward the

If the inner door handle is pulled when the

front (left side) of the vehicle. To unlock,

door is locked, the door will unlock and

turn the key toward the rear (right side) of

open.

the vehicle.

NOTICE

Rear door

If the inner door handle is pulled once

Do not apply excessive force on the door

when the door is locked, the door will

and door handle. It may damage the door

unlock. If the inner door handle is pulled

and door handle.

once more, the door will open.

The mechanical key only locks/unlocks

If any door is opened, the doors will not

the driver’s door handle. For more detail,

lock even though the central door lock

refer to ‘In case of an emergency’ in this

switch is pressed.

chapter.

Information

If a power door lock ever fails to function

Information

while you are in the vehicle try one or

more of the following techniques to exit:

When the door handle or the keyhole

freeze and do not open, lightly tap or

• Operate the door unlock feature

indirectly warm (for example, hand

repeatedly (both electronic and

temperature) the keyhole.

manual) while simultaneously pulling

on the door handle.

• Operate the other door locks and

handles, front and rear.

• Lower a front window and use the

mechanical key to unlock the door from

outside.

5-29

Convenience Features

With the central door lock switch

In case of an emergency

ONE1051017

ONE1051019K

In case of emergency such as when the

Driver’s and front passenger’s door

battery is discharged, the only way to lock

The driver’s and front passenger’s door

the door(s) is with the mechanical key

armrest is equipped with a central door

from the outside key hole.

lock switch. The lock switch is indicated

Doors without an outside key hole can be

by a symbol. The unlock switch is

locked as follows:

indicated by a symbol.

1. Open the door.

When the lock switch (1) is pressed (door

2. Insert the key into the emergency door

indicator light ON), all the vehicle doors

lock hole and turn the key to the lock

will lock.

position.

When the unlock switch (2) is pressed, all

3. Close the door securely.

the vehicle doors will unlock.

If any door is opened, the doors will not

Information

lock even though the central door lock

If the electrical power door lock switch

switch (1) is pressed.

does not operate (ex. dead car battery)

and the liftgate is closed, you will not be

NOTICE

able to open the liftgate until power is

If the smart key is in the vehicle and the

restored.

front door is opened, the central door lock

button (1) cannot lock the doors.

WARNING

• The doors should always be fully closed

and locked while the vehicle is in

motion. If the doors are unlocked, the

risk of being thrown from the vehicle in

a crash is increased.

• Do not pull the inner door handle of the

driver’s or passenger’s door while the

vehicle is moving.

5-30

Automatic Door Lock and

WARNING

Unlock Features

Do not leave the elderly, children or

Your vehicle is equipped with features

animals unattended in your vehicle. An

that will automatically lock or unlock your

enclosed vehicle can become extremely

vehicle based on settings you select in the

hot, causing death or serious injury to the

infotainment system screen.

elderly, unattended children or animals

who cannot escape from the vehicle.

Children might operate features of the

Auto LOCK Enable on speed

vehicle that could injure them, or they

When this feature is set in the

could encounter other harm, possibly

infotainment system screen, all the doors

from someone gaining entry to the

will be locked automatically when the

vehicle.

vehicle exceeds 9 mph (15 km/h).

Auto LOCK Enable on shift

WARNING

When this feature is set in the

Always secure your vehicle.

infotainment system screen, all the doors

will be locked automatically when the

Leaving your vehicle unlocked increases

vehicle is shifted out of P (Park) while the

the potential risk to you or others from

vehicle is running.

someone hiding in your vehicle.

To secure your vehicle, while depressing

the brake, shift the gear to the P (Park)

Auto UNLOCK On Shift to P

position, engage the parking brake, and

When this feature is set in the

press the Start/Stop button to the OFF

infotainment system screen, all the doors

position, close all windows, lock all doors,

will be unlocked automatically when the

and always take the key with you.

vehicle is shifted back into P (Park) while

the vehicle is running.

CAUTION

Auto UNLOCK Vehicle off

Opening a door when something is

When this feature is set in the

approaching may cause damage or injury.

infotainment system screen, all the doors

Be careful when opening doors and

will be unlocked automatically when the

watch for vehicles, motorcycles, bicycles

vehicle is turned off.

or pedestrians approaching the vehicle in

the path of the door.

Information

For more information, refer to the user’s

manual provided in the infotainment

system and the quick reference guide.

WARNING

If you stay in the vehicle for a long time

while the weather is very hot or cold,

Additional unlock safety feature air

there are risks of injuries or danger to life.

bag deployment

Do not lock the vehicle from the outside

As an additional safety feature, all doors

when someone is in the vehicle.

will be automatically unlocked when an

impact causes the air bags to deploy.

5-31

Convenience Features

Electronic Child Safety Lock

• If the airbag is activated while the

electronic child safety lock button is in

the LOCK position (indicator light ON),

the rear doors will unlock

automatically.

• Vehicles equipped with the electronic

child safety lock feature is not provided

with a manual child safety lock.

WARNING

If children accidentally opens the rear

door while the vehicle is in motion, they

ONE1051020

could fall out of the vehicle. Electronic

When the electronic child safety lock

child safety lock should always be used

button is pressed and the indicator light

whenever children are in the vehicle.

on the button illuminates, the rear doors

cannot be opened from inside the vehicle.

•

The rear door window cannot be

NOTICE

opened or closed while the electronic

child safety lock button is in the LOCK

Child safety lock failure

position (indicator light ON).

For more details, refer to “Windows”

section in this chapter.

•

Electronic child safety lock does not

automatically turn on unless the driver

presses the electronic child safety lock

button.

•

If 3 minutes passes after the Start/Stop

button is pressed to the OFF or ACC, the

indicator on the button turns off, and

the driver cannot turn off electronic

ONE1051205L

child safety lock by pressing the button.

When electronic child safety lock does

To turn off the function, press the

not work even though the button is

Start/Stop button to the ON position,

pressed, the message will be displayed

and then press the electronic child

and an alarm will sound. If this occurs,

safety lock button.

have the vehicle inspected by an

•

If the power is supplied again after

authorized HYUNDAI dealer.

removing the battery or battery is

discharged while the electronic child

safety lock button is in the LOCK

position, press the button once more to

match the state of the indicator on the

electronic child safety lock button and

actual status of the electronic child

safety lock function.

5-32

Safe Exit Assist (if equipped with

electronic child safety lock)

Safe Exit Assist helps prevent the rear

occupant from opening the rear door.

When an approaching vehicle from the

rear area is detected after the vehicle

stops, the rear doors will not unlock even

when the driver tries to unlock the rear

doors using the electronic child safety

lock button.

For more details, refer to “Safe Exit Assist

(SEA)” section in chapter 7.

ODN8A059340

• Head unit is not updating

• Outside of vehicle charging connector

Vehicle Auto-Shut Off

engaged or outside V2L used

Function

• If you want to deactivate auto-shut off

If you forget to turn off the vehicle that EV

function during inside V2L, use the

Drivable for a period of time, Vehicle

Utility mode

Shuts Off automatically to prevent waste

electric power.

System Operation

If the system is satisfied operating

Operating Conditions

conditions after 90 minutes, vehicle shut

Vehicle Auto-Shut Off timer activates

off automatically.

when the following conditions are met

• Not Auto-Shut Off timer reset condition

- Vehicle is not EV ready state(Only

Ignition On) or the utility mode on

- Gear Shift Other than P

- Stepped on the brake pedal of the

accelerator pedal

- Fastened driver’s seat belt and

passenger’s seat belt

- Passenger’s seat is occupied

- The vehicle moves(vehicle speed is

above 2 mph (3 km/h))

- When Auto-Shut Off timer is left

10minutes, the user setting mode

pops up in the instrument cluster.

And you can check the time left. If

you push the ‘OK’ button, Auto-Shut

off timer is reset.

5-33

Convenience Features

Theft-alarm System

Information

This system helps to protect your vehicle

•

Do not lock the doors until all

and valuables. The horn will sound and

passengers have left the vehicle. If the

the hazard warning lights will blink

remaining passenger leaves the vehicle

continuously if any of the following occur:

when the system is armed, the alarm

• A door is opened without using the

will be activated.

smart key.

•

If the vehicle is not disarmed with the

• The liftgate is opened without using the

smart key, open the doors by using the

smart key.

mechanical key and start the vehicle by

directly pressing the Start/Stop button

• The vehicle hood is opened.

with the smart key.

The alarm continues for 30 seconds, then

•

If the system is disarmed by unlocking

the system resets. To turn off the alarm,

the vehicle, but neither a door or the

unlock the doors with the smart key.

liftgate is opened within 30 seconds,

The Theft Alarm System automatically

the doors will relock and the system will

sets 30 seconds after you lock the doors

rearm automatically.

and the liftgate. For the system to

activate, you must lock the doors and the

liftgate from outside the vehicle with the

smart key or by touching the touch sensor

or pressing the button on the outside

door handle with the smart key in your

possession.

The hazard warning lights will blink and

the chime will sound once to indicate the

system is armed.

Once the security system is set, opening

any door, the liftgate, or the hood without

using the smart key will cause the alarm

to activate.

The Theft Alarm System will not set if the

hood, the liftgate, or any door is not fully

closed. If the system will not set, check

the hood, the liftgate, or the doors are

fully closed.

Do not attempt to alter this system or add

other devices to it.

5-34

Advanced Rear Occupant

System Operation

• First alert

Alert (ROA)

When you turn off the vehicle and open

if equipped

the driver’s door after opening and

Advanced Rear Occupant Alert is

closing the rear door or liftgate, the

provided to help prevent a driver from

‘Check rear seats’ warning message

leaving a vehicle with the rear passenger

appears on the cluster display.

left in the vehicle.

WARNING

Even if your vehicle is equipped with

System Setting

Advanced Rear Occupant Alert (ROA),

To use Rear Occupant Alert, it must be

always make sure to check the rear seat

enabled from the Settings menu in the

before you leave the vehicle.

infotainment system screen.

Advanced Rear Occupant Alert (ROA)

Select:

may not operate when:

• Setup > Vehicle Settings >

• Movement does not continue for a

Convenience > Rear Occupant Alert

certain period of time or the movement

(ROA)

is small.

• A child is not seated in a child restraint

Information

system.

The infotainment system may change

• Movement is detected in areas other

after software updates. For more

than the rear seats.

information, refer to the user's manual

• The rear passenger is covered with a

provided in the infotainment system and

fabric containing metallic substance

the quick reference guide.

such as a blanket.

• An object in the vehicle blocks the

sensor.

• The sensor is contaminated by foreign

material.

• An animal at the rear seat or luggage

compartment is not large enough to be

detected by the sensor or there is

hardly any movement.

• Attaching objects or modifying the

interior ceiling, or the interior ceiling is

deformed or damaged.

• There are electronic interference

around the vehicle.

• Other environmental reasons that may

affect the system.

5-35

Convenience Features

Integrated Memory

Storing Memory Positions

1. Shift to P (Park) while the Start/Stop

System

button is in the ON position.

if equipped

2. Adjust the driver’s seat position, side

view mirror position, and head-up

display height to the desired position.

3. Hold the button (1 or 2). The system will

beep once and notify you ‘Driver 1 (or 2)

settings saved’ will appear on the

infotainment screen.

Recalling Memory Positions

1. Shift to P (Park) while the Start/Stop

button is in the ON position.

ONE1051023

2. Press the desired memory button (1 or

Integrated Memory System for the

2). The system will beep once, and then

driver’s seat is provided to store and recall

the driver’s seat position, side view

the following memory settings with a

mirror position, and head-up display

simple button operation.

height will automatically adjust to the

• Driver’s seat position

stored positions.

• Side view mirror position

3. ‘Driver 1 (or 2) settings applied’ will

• Head-Up Display (HUD) : display mode,

appear on the infotainment screen.

position, AR matching adjustment (if

equipped)

Information

• In order to adjust the memory button

WARNING

(2) while adjusting the memory button

Never attempt to operate the integrated

(1), press the memory button (1) to

memory system while the vehicle is

pause the adjustment of (1), then press

moving.

memory button (2).

This could result in loss of control, and an

• If you adjust the seat, side view mirror,

accident causing death, serious injury, or

head-up display while recalling the

property damage.

stored positions, the manually adjusted

settings will be applied.

Information

• If the battery is disconnected, the

memory settings will be erased.

• If integrated memory system does not

operate normally, have the system

inspected by an authorized HYUNDAI

dealer.

5-36

Resetting the System

NOTICE

Take the following procedures to reset

• While integrated memory system is

integrated memory system, when it does

being reset, if the resetting and

not operate properly.

notification sound stops incompletely,

restart the resetting procedure again.

Resetting integrated memory

• Make sure that there is no objects

system

around the driver’s seat in advance of

1. Stop the vehicle and open the driver’s

resetting the integrated memory

door with the Start/Stop button in the

system.

ON position and the vehicle shifted to P

• After resetting the integrated memory

(Park).

system, the adjustment for the driver

2. Adjust the driver’s seat and seatback to

seat must be stored again to recall the

the foremost position.

memory position.

3. Press the memory button 1 (or 2) and

push forward the driver’s seat switch

simultaneously (about two seconds).

Seat Easy Access

4. Release the memory button and the

Seat easy access will move the driver’s

driver's seat switch when a beep

seat and steering wheel automatically as

sounds.

follows:

• Exiting the vehicle:

While resetting integrated memory

The driver’s seat will move as follows

system

when the Start/Stop button is in the

1. Resetting starts with a notification

OFF position with the gear in P (Park)

sound.

and the driver’s door open.

2. The driver’s seat and seatback is

- Driver seat: Moves rearward

adjusted to the rearward position with

depending on the distance selected

the notification sound.

from the Settings menu in the

infotainment system.

3. The driver’s seat and seatback is

re-adjusted to the default position

However, the driver’s seat may not

(central position) with the notification

move rearward if there is not enough

sound.

space between the driver’s seat and the

rear seats.

However, in the following cases, the

resetting procedure and the notification

• Entering the vehicle:

sound may stop.

The driver’s seat will move as follows

• The memory button is pressed.

when the Start/Stop button is pressed

to the ACC, ON or START position or

• The seat control switch is operated.

while carrying the smart key, the

• The gear is shifted out of P (Park).

driver’s door is closed with the

• The driving speed exceeds 2 mph (3

Start/Stop button in the OFF position.

km/h).

- Driver seat: Moves back to its original

• The driver’s door is closed.

position.

5-37

Convenience Features

• You can set the Seat Easy Access

Memory Seat

function from the Settings menu in the

infotainment system screen.

Configurations

Select:

if equipped

- Driver seat

Memory seat configurations for the seats

Setup > Vehicle Settings > Seat >

are provided to store and recall the

Seating Easy Access > Driver Seat

following memory settings with a simple

Easy Access >

operation on the infotainment system.

Normal/Extended/Off

WARNING

Information

Never attempt to operate the integrated

The infotainment system may change

memory system while the vehicle is

after software updates. For more

moving.

information, refer to the user's manual

This could result in loss of control, and an

provided in the infotainment system and

accident causing death, serious injury, or

the quick reference guide.

property damage.

CAUTION

The function requires a large amount of

electrical power. To prevent the battery

from discharging, refrain from using it

when the vehicle start switch is off.

• If the battery is disconnected, the

memory settings will be erased.

• If integrated memory system does not

operate normally, have the system

inspected by an authorized HYUNDAI

dealer.

5-38

Storing Memory Positions

Steering Wheel

Motor Driven Power Steering

(MDPS)

The system assists you with steering the

vehicle. If the vehicle is turned off or if the

power steering system becomes

inoperative, you may still steer the

vehicle, but it will require increased

steering effort.

Should you notice any change in the

ONE1051250L

effort required to steer during normal

You can save the position of each seat on

vehicle operation, have the system

the Infotainment system screen as below.

checked by an authorized HYUNDAI

1. Shift to P (Park) while the Start/Stop

dealer.

button is in the ON position.

2. Touch the Memory seat configuration

CAUTION

icon in the infotainment home screen.

If Motor Driven Power Steering does not

3. Adjust the each seat position with

operate normally, the

warning light

arrow icons to the desired position on

and the message ‘Check motor driven

the infotainment screen.

power steering’ will illuminate on the

4. To save the each seat that desired

instrument cluster. You may steer the

position, touch the ‘Save’ icon.

vehicle, but it will require increased

steering efforts. Take the vehicle to an

5. Select the one of the mode on the

authorized HYUNDAI dealer and have the

infotainment screen. The mode that

system checked as soon as possible.

selected will be saved.

Recalling Memory Positions

Information

1. Shift to P (Park) while the Start/Stop

button is in the ON position.

The following symptoms may occur

during normal vehicle operation:

2. Touch the desired memory mode icon

(1,2 or 3) and touch ‘Apply’ icon on the

• The steering effort may be high

infotainment screen.

immediately after pressing the

Start/Stop button to the ON position.

3. The seats will automatically adjust to

the stored positions.

This happens as the system performs

the MDPS system diagnostics. When

4. To stop working while recalling the

the diagnostics are completed, the

saved mode, touch ‘Stop’ icon on the

steering wheel effort will return to its

infotainment screen.

normal condition.

• When the battery voltage is low, you

might have to put more steering effort.

However, it is a temporary condition so

that it will return to normal condition

after charging the battery.

5-39

Convenience Features

• A click noise may be heard from the

Manual adjustment

MDPS relay after the Start/Stop button

is in the ON or OFF position.

• Motor noise may be heard when the

vehicle is at a stop or at a low driving

speed.

• When you operate the steering wheel in

low temperatures, abnormal noise may

occur. If the temperature rises, the

noise will disappear. This is a normal

condition.

• When an error is detected from MDPS,

ONE1051024

the steering effort assist function will

To adjust the steering wheel angle and

not be activated in order to prevent

height:

fatal accidents. Instrument cluster

warning lights may be on or the

1. Pull down the lock-release lever (1).

steering effort may be high. If these

2. Adjust the steering wheel to the desired

symptoms occur, drive the vehicle to a

angle (2) and distance forward/back

safe area as soon as it is safe to do so.

(3).

Have the system checked by an

3. Pull up the lock-release lever to lock the

authorized HYUNDAI dealer as soon as

steering wheel in place.

possible.

Information

Tilt/Telescopic Steering

Sometimes the lock release lever may not

engage completely. This may occur when

When adjusting the steering wheel to a

the gears of the locking mechanism do

comfortable position, adjust the steering

not completely mesh. If this occurs, pull

wheel so that it points toward your chest,

down on the lock-release lever, readjust

not toward your face. Make sure you can

the steering wheel again, and then pull

see the instrument cluster warning lights

back up on the release lever to lock the

and gauges. After adjusting, push the

steering wheel in place.

steering wheel both up and down to be

certain it is locked in position.

Always adjust the position of the steering

wheel before driving.

WARNING

NEVER adjust the steering wheel while

driving. This may cause loss of vehicle

control resulting in an accident.

NOTICE

While adjusting the steering wheel

height, please do not push or pull it hard

since the fixture can be damaged.

5-40

Climate control panel

Horn

ONE1031081

ONE1051025

Press WARMER in the front climate

To sound the horn, press the area

control panel.

indicated by the horn symbol on your

steering wheel (see illustration). The horn

will operate only when this area is

pressed.

NOTICE

Do not strike the horn severely to operate

it, or hit it with your fist. Do not press on

the horn with a sharp-pointed object.

Heated Steering Wheel

ONE1051216L

if equipped

While the vehicle is running, touch the

Infotainment system

heated steering wheel icon to warm the

steering wheel.

• To warm the steering wheel, touch the

heated steering wheel icon in the

Heating/Ventilation seats.

• Auto. Controls That Use Climate

Control Settings (for driver’s seat)

The heated steering wheel

automatically controls the steering

wheel temperature depending on the

ambient temperature when the vehicle

is running.

ONE1031085L

While the vehicle is running, touch

To use this function, it must be enabled

Heating/Ventilation icon in the

from the Settings menu in the

infotainment home screen.

infotainment system screen.

Select:

- Setup > Vehicle Settings > Seat >

Heated/Ventilated Features > Auto.

Controls That Use Climate Control

Settings > Heated steering wheel

5-41

Convenience Features

• The heated steering wheel defaults to

Mirrors

the OFF position whenever the

Start/Stop button is pressed to the ON

position. However, if the Auto. Controls

Inside Rearview Mirror

That Use Climate Control Settings

function is ON, the heated steering

Before driving your vehicle, check to see

wheel will turn on and off depending on

that your inside rearview mirror is

the outside temperature.

properly positioned. Adjust the rearview

mirror so that the view through the rear

Information

window is properly centered.

The infotainment system may change

WARNING

after software updates. For more

information, refer to the user's manual

Make sure your line of sight is not

provided in the infotainment system and

obstructed. Do not place objects in the

the quick reference guide.

rear seat, cargo area, or behind the rear

head restraints which could interfere with

your vision through the rear window.

NOTICE

Do not install any cover or accessory on

WARNING

the steering wheel. The cover or

accessory could cause damage to the

To prevent serious injury during an

heated steering wheel system.

accident or deployment of the air bag, do

not modify the rearview mirror and do not

install a wide mirror.

WARNING

NEVER adjust the mirror while driving.

This may cause loss of vehicle control

resulting in an accident.

NOTICE

When cleaning the mirror, use a paper

towel or similar material dampened with

glass cleaner. Do not spray glass cleaner

directly on the mirror as this may cause

the liquid cleaner to enter the mirror

housing.

5-42

Day/night rearview mirror

When the vehicle is running, the glare is

if equipped

automatically controlled by the sensor

mounted in the rearview mirror. The

sensor detects the light level around the

vehicle, and automatically adjusts to

control the headlight glare from vehicles

behind you.

Whenever the the gear is shifted to R

(Reverse), the mirror will automatically go

to the brightest setting in order to

improve the driver’s view behind the

vehicle.

ONE1051026

Electrochromic mirror (ECM) with

Make this adjustment before you start

HomeLink® system

driving and while the day/night lever is in

if equipped

the day position.

Your vehicle may be equipped with a

Pull the day/night lever towards you to

Gentex Automatic-Dimming Mirror with

reduce glare from the headlights of the

an Integrated HomeLink® Wireless

vehicles behind you during night driving.

Control System.

Remember that you lose some rearview

During nighttime driving, this feature will

clarity in the night position.

automatically detect and reduce rearview

mirror glare. The HomeLink® Universal

Transceiver allows you to activate your

Electric Chromic Mirror (ECM)

garage door(s), electric gate, home

if equipped

lighting, etc.

ONE1051226

ONE1051261N

[A] : Indicator

(1) HomeLink Channel 1

Some vehicles come equipped with an

(2) HomeLink Channel 2

electrochromic mirror that helps control

(3) HomeLink Channel 3

glare while driving at night or under low

(4) Garage Door Opener Status Indicator :

light driving conditions.

Closing or Closed

(5) HomeLink Operation Indicator

(6) Garage Door Opener Status Indicator :

Opening or Opened

(7) HomeLink User Interface Indicator

5-43

Convenience Features

Automatic-Dimming Night Vision Safety™

WARNING

(NVS^®) Mirror

if equipped

Before programming HomeLink® to a

garage door opener or gate operator,

The NVS® Mirror automatically reduces

make sure people and objects are out of

glare by monitoring light levels in the

the way of the device to prevent potential

front and the rear of the vehicle. Any

harm or damage. Do not use the

object that obstructs either light sensor

HomeLink® with any garage door opener

will degrade the automatic dimming

that lacks the safety stop and reverse

control feature.

features required by U.S. federal safety

For more information regarding NVS®

standards (this includes any garage door

mirrors and other applications, please

opener model manufactured before April

refer to the Gentex website:

1, 1982). A garage door that cannot detect

www.gentex.com

an object - signaling the door to stop and

Your mirror will automatically dim upon

reverse - does not meet current U.S.

detecting glare from the vehicles

federal safety standards. Using a garage

traveling behind you.

door opener without these features

increases the risk of serious injury or

The mirror defaults to the ON position

death.

each time the vehicle is started.

For more information, contact

HomeLink® at www.homelink.com, or call

Integrated HomeLink^® Wireless Control

Home-Link customer support at

System

1-800-355-3515.

The HomeLink® Wireless Control System

It is also recommended that a new battery

provides a convenient way to replace up

be replaced in the handheld transmitter

to three hand held radio-frequency

of the device being trained to HomeLink®

transmitters used to activate compatible

for quicker training and accurate

devices such as gate operators, garage

transmission of the radio frequency.

door openers, entry door locks, security

systems, and home lighting.

NOTICE

1. Programming HomeLink^®

The following steps show how to program

HomeLink® operates while the ignition

HomeLink. If you have any questions or

switch is in the ACC or ON position for

are having difficulty programming your

safety reasons. It is to prevent

HomeLink buttons, refer to the HomeLink

unintentional security problems from

website or call the HomeLink customer

happening when the vehicle is parked

support toll-free number. Do this, before

outside the garage.

going back to the dealer who sold you the

car.

• Visit the HomeLink website at:

www.homelink.com. Then at the top of

the page, choose your vehicle make.

Then watch the You Tube video, and/or

access additional website information.

5-44

• If you choose to access the website via

2) Programming a New HomeLink®

your cell phone, scan the QR code.

ODL3A040519

• Or, call HomeLink customer support at

1-800-355-3515 (Please have the

vehicle make/model AND the opener

device make/model readily available.)

1) Programming Preparation

ONE1051263N

1. Press and release the HomeLink button

(1), (2) or (3), you would like to program.

The HomeLink indicator light (7) will

flash orange slowly (if not, perform the

steps of “Erasing HomeLink Buttons”

section, and start over).

ONE1051262N

1. When programming a garage door

opener, it is advised to park the vehicle

outside of the garage.

2. It is recommended that a new battery

be placed in the handheld transmitter

of the device being programmed to

ONE1051264N

HomeLink for quicker training and

2. Position the garage door opener

accurate transmission of the

remote 1 - 3 inches (2 - 8cm) away from

radio-frequency signal.

the HomeLink buttons.

3. Place the ignition switch to the ACC

3. While the HomeLink indicator light (7) is

(Accessory) position for programming

flashing orange, press and hold the

of HomeLink.

hand-held remote button. Continue

pressing the handheld remote button

until the HomeLink indicator light (7)

light changes from orange to green.

You may now release the handheld

remote button.

4. Wait until your garage door comes to a

complete stop, regardless of position,

before proceeding to the next steps.

5-45

Convenience Features

5. Press and release the HomeLink button

8. Return to the vehicle and firmly press,

you are programming and observe the

hold for two seconds and release, the

indicator light.

HomeLink button up to three times in a

row slowly. Do not press the HomeLink

• If the indicator light remains solid

button rapidly. As soon as you see the

green, your device should operate

garage door start to move, stop

when the HomeLink button is

pressing any buttons until a few

pressed. At this point, if your device

seconds after the garage door has

operates, programming is complete.

come to a complete stop, regardless of

• If the indicator light rapidly flashes

position. At this point, programming is

green, firmly press, hold for two

complete and your device should

seconds and release the HomeLink

operate when the HomeLink button is

button up to three times in a row

pressed and released.

slowly to complete the programming

process. Do not press the HomeLink

3) Two-Way Communication

button rapidly. At this point if your

Programming (For select garage door

device operates, programming is

openers)

complete. If the device does not

If your garage door opener has the ‘myQ’

operate, continue with step 6.

logo on its side, your opener likely has

6.At the garage door opener motor,

Two-Way Communication capability.

(security gate motor, etc.) locate the

HomeLink has the capability to establish

“Learn”, “Smart”, “Set” or “Program”

Two-Way Communication with your

button. This can usually be found where

garage door opener. HomeLink can

the hanging antenna wire is attached to

receive and display “closing” or

the motor-head unit (see the device’s

“opening” status messages from

manual to identify this button). The

compatible garage door openers. At any

name and color of the button may vary

time, Home-Link can also recall and

by manufacturer.

display the last recorded status

communicated by the garage door

opener to indicate your garage door

being “closed” or “opened”.

To check if your garage door opener is

compatible with this feature, refer to

www.homelink.com/compatible/Two-w

ay-Communication. If your garage door

opener has this functionality, AND the

Two-Way Communication indicators (4),

(6) in the mirror appear while the garage

door is opening/closing, then no further

steps are needed. Two-Way

Communication Programming is already

ODL3A040504

complete. However, if your garage door

* A ladder and/or second person may

opener has this functionality, AND the

simplify the following steps.

Two-Way Communication indicators (4),

7. Firmly press and release the “Learn”,

(6) in the mirror DO NOT appear while the

“Smart”, “Set” or “Program” button.

garage door is opening/closing, use the

You now have up to 30 seconds in

following instructions to enable this

which to complete the next step.

functionality.

5-46

1. In your vehicle, press and hold the

Information

programmed HomeLink button for 2

seconds, then release. Confirm that the

If your garage door opener has Two-Way

garage door is moving. AFTER it stops,

Communication functionality, it is

you will have one minute to complete

possible for HomeLink to stop functioning

the following steps:

the garage door shortly after initial

* A ladder and/or second person may

programming, IF the Two-Way

simplify the following steps.

Communication Programming wasn’t

properly completed. This usually happens

2. On your garage door opener in your

after the first 10 times a programmed

garage, locate the “Learn” button

HomeLink button is pressed. If you

(usually near where the hanging

experience this, completing the

antenna wire is attached to the garage

“Programming a New HomeLink Button”

door opener). If there is difficulty

and “Two-Way Communication

locating this button, reference the

Programming” will restore door

device’s owner’s manual.

operation.

3. Press and release the “Learn” button.

4. A light on your garage door opener may

flash, and your Two-Way

4) Canadian Programming

Communication indicators (4), (6) in

Canadian radio-frequency laws require

your vehicle may flash, confirming

transmitter remote signals to “time-out”

completion of the process.

(or quit) after a couple seconds of

5. Return to the vehicle and firmly press

transmission, which may not be long

and release the programmed

enough for HomeLink to pick up the

HomeLink button to activate your

signal during programming.

garage door. The Two-Way

If you live in Canada or you are having

Communication indicators (4), (6) flash

difficulties programming a gate operator

in orange when the door is moving. Do

or garage door opener by using the

not make any additional button presses

programming procedures, replace

until AFTER the garage door has come

“Programming a New HomeLink Button”

to a complete stop.

step 3 with the following:

6.Your Two-Way Communication

While the HomeLink indicator light (7) is

programming is now complete.

flashing orange, press and release

(“cycle”) your device’s handheld remote

every two seconds until the HomeLink

indicator light (7) changes from orange to

green. You may now release the

hand-held remote button. Then proceed

with “Programming a New HomeLink

Button” step 4.

5-47

Convenience Features

2. Operating HomeLink^®

2) Two-Way Communication Display

Behavior

1) Operating HomeLink®

ONE1051265N

ONE1051263N

1. Press and release one of the

1. Press and release the desired

programmed HomeLink buttons (1, 2 or

programmed HomeLink button (1, 2 or

3).

Information

The HomeLink indicator (7) should light

green, solid or flashing, and your

programmed device should operate.

If your device does not operate, the

HomeLink programming was not

successful, and you’ll need to reprogram

the button.

ONE1051266N

2. The indicator (4) and (6) operates as

below, if your garage door opener has

Two-Way Communication

functionality.

• If the indicator (4) flashes in Orange,

it indicates that the garage door is

“Closing”.

• The indicator (4) turns solid green

once the garage door has closed.

• If the indicator (6) flashes in Orange,

it indicates that the garage door is

“Opening”.

• The indicator (6) turns solid green

once the garage door has fully

opened.

5-48

• If the indicator (4) or (6) does not turn

2) The following instructions will erase

to green, it indicates that the last

ALL HomeLink® programming from ALL

status of garage door was not

buttons:

received properly. The HomeLink

mirror tries to receive the last known

status of the garage door for a few

seconds.

3) Recalling Garage Door Status

HomeLink mirror with Two-Way

Communication provides a way to view

the last stored message from the garage

door opener. In order to recall the last

known status of the last activated device,

press the buttons “1 and 2” OR “2 and 3”

ONE1051267N

simultaneously.

1. Press and hold the buttons (1) and (3)

• If the indicator (4) appears solid Green,

simultaneously

it indicates that the last activated

2. The HomeLink indicator light (7) will

device was “closed” properly.

illuminate solid Orange for about 10

• If the indicator (6) appears solid Green,

seconds

it indicates that the last activated

3. Release the buttons once the

device was “open” properly.

HomeLink indicator light (7) changes to

Green and flashes rapidly

3. Erasing HomeLink^® Buttons

4. Now all three HomeLink buttons (1), (2)

1) Erasing and Reprogramming a Single

and (3) are cleared of any programming

HomeLink® Button:

1. Press and hold the desired HomeLink

Information

button you want to re-program. DO

HomeLink^® and the HomeLink^® House

NOT release the button.

logo are registered trademarks of Gentex

2. The HomeLink indicator light (7) will

Corporation.

illuminate solid green. Release the

The myQ logo is a registered trademark of

button as soon as the HomeLink

The Chamberlain Group, Inc.

indicator light (7) begins to flash

orange, usually about 20 seconds.

3. Proceed with the steps in the

“Programming a New HomeLink

Button” section.

Information

If you do not complete the

re-programming of a new device to the

button, it will revert to the previously

stored programming.

5-49

Convenience Features

FCC (USA) and ISED (Canada)

MISE EN GARDE : L’émetteur a subi des

tests et est conforme aux règlements de

This device complies with FCC rules part

la FCC et d’ISDE. Les changements ou

15 and Innovation, Science, and

modifications non approuvés

Economic Development Canada RSS-210.

explicitement par la partie responsable de

Operation is subject to the following two

la conformité pourraient rendre caduque

conditions: (1) This device may not cause

l’autorisation de l’utilisateur de se servir

harmful interference, and (2) This device

du dispositif.

must accept any interference that may be

received including interference that may

Cet appareil est conforme aux limites

cause undesired operation. WARNING:

d’exposition aux radiations de la FCC et

The transmitter has been tested and

d’ISDE établies pour un environnement

complies with FCC and ISED rules.

non contrôlé. Les utilisateurs finaux

Changes or modifications not expressly

doivent respecter les instructions

approved by the party responsible for

d’utilisation spécifiques pour satisfaire

compliance could void the user’s

aux exigences de conformité aux

authority to operate the device.

expositions de RF. L’émetteur doit se

trouver à 20 cm au minimum de

This equipment complies with FCC and

l’utilisateur et ne doit pas être situé au

ISED radiation exposure limits set forth

même endroit que tout autre émetteur ou

for an uncontrolled environment. End

antenne ni fonctionner avec un autre

Users must follow the specific operating

émetteur ou antenne.

instructions for satisfying RF exposure

compliance. This transmitter must be at

least 20cm from the user and must not be

co-located or operating in conjunction

with any other antenna or transmitter.

Cet appareil est conforme aux règlements

de la FCC, section 15, et au CNR-210

d’Innovation, Sciences et

Dhveloppement économique Canada. Le

fonctionnement est assujetti aux deux

conditions suivantes : (1) cet appareil ne

doit pas causer d’interférences nuisibles

et (2) cet appareil doit accepter toute

interférence reçue, y compris celle qui

pourrait entraîner un dysfonctionnement.

5-50

Convenience Features

Side View Mirrors

NOTICE

• Do not scrape ice off the mirror face;

this may damage the surface of the

glass.

• If the mirror is jammed with ice, do not

adjust the mirror by force. Use an

approved de-icer (not radiator

antifreeze) spray, or a sponge or soft

cloth with very warm water, or move

the vehicle to a warm place and allow

the ice to melt.

ONE1051027

• Do not clean the mirror with harsh

Your vehicle is equipped with both

abrasives, fuel or other petroleum

left-hand and right-hand sideview

based cleaning products.

mirrors. The mirrors can be adjusted

remotely with the mirror adjustment

control switch. The sideview mirrors can

Adjusting the side view mirrors

be folded to help prevent damage when

going through an automatic car wash or

when passing through a narrow street.

The right sideview mirror is convex.

Objects seen in the mirror are closer than

they appear.

Use the inside side view mirror or look

back directly to determine the actual

distance of other vehicles prior to

changing lanes.

Make sure to adjust the sideview mirrors

ONE1051028

to your desired position before you begin

driving.

Adjusting the side view mirrors:

1. When the Start/Stop button is in the

WARNING

ACC, ON or START position, move

either the L (Left side) or R (Right side)

Do not adjust or fold the sideview mirrors

lever (1) to select the side view mirror

while driving. This may cause loss of

you would like to adjust.

vehicle control resulting in an accident.

2. Use the mirror adjustment control

switch (2) to position the selected

mirror up, down, left or right.

3. After adjustment, move the lever (1) to

the middle to prevent inadvertent

adjustment.

5-52

• Enable on driver approach

NOTICE

If Setup> Vehicle Settings >

• The mirrors stop moving when they

Convenience > Welcome Mirror >

reach the maximum adjusting angles,

Enable on Driver Approach is selected

but the motor continues to operate

from the Settings menu in the

while the switch is pressed. Do not

infotainment system screen, the mirror

press the switch longer than necessary,

will unfold when the vehicle is

because this can damage the motor.

approached with the smart key in

• Do not attempt to adjust the side view

possession.

mirrors by hand, because this can

damage the motor.

Information

• For your safety, the side view mirrors

cannot be folded automatically when

Folding the side view mirrors

driving at a speed of 9 mph (15 km/h) or

faster.

• The infotainment system may change

after software updates. For more

information, refer to the user’s manual

provided in the infotainment system

and the quick reference guide.

NOTICE

The electric type side view mirror

ONE1051029

operates even though the Start/Stop

button is in the OFF position. However, to

Folding button

prevent unnecessary battery discharge,

The side view mirrors can be folded or

do not adjust the mirrors longer than

unfolded by pressing the button.

necessary while the vehicle is not

running.

Infotainment system setting

• Enable on door unlock

If Setup > Vehicle Settings > Welcome

NOTICE

Mirror > Enable on Door Unlock is

Do not fold the electric type side view

selected from the Settings menu in the

mirror by hand. It could cause motor

infotainment system screen,

failure.

- The mirror will fold or unfold when

the door is locked or unlocked by the

smart key.

- The mirror will fold or unfold when

the door is locked or unlocked by the

touch sensor or button on the outside

door handle.

5-53

Convenience Features

Reverse Parking Aid

Reverse parking aid user settings

mode

if equipped

You may change the angle of the side

view mirror if it is difficult to see the rear

view with the basic downward mirror

angle provided when reversing.

When the vehicle is first delivered, the set

downward angle of the left and right side

view mirror are different to ensure driver

visibility.

1. Make sure the vehicle is stopped.

2. Depress the brake pedal and shift the

gear to R (Reverse). When L (Left) or R

ONE1051030

(Right) button is selected, both side

When the gear is shifted to the R

view mirror angle will move downward

(Reverse) position, the side view lever(s)

to the basic set position.

will rotate downwards to aid with driving

3. Move either L or R lever to select the

in reverse.

side view mirror you would like to

The state of the side view mirror lever (1)

adjust. Then press “

” switch

determines whether or not the mirrors

to adjust the side view mirror to the

will move:

desired angle.

How it works

4. After adjusting the angle to save the

• Left/Right : When either the L (Left) or R

adjusted side view mirror angle, shift

(Right) lever is selected, both side view

the gear to another position other than

mirrors will move.

R (Reverse), or change the L and R lever

to the neutral position (L and R levers

• Neutral : When neither switch is

are not selected).

selected, the side view mirrors will not

move.

5. Set the other side view mirror following

the above procedure 1 to 4.

The side view mirrors will automatically

revert to their original positions if any of

Resetting reverse parking aid user settings

the following occur:

mode

• The Start/Stop button is pressed to

To change the side view mirror angle back

either the OFF position or the ACC

to the basic angle, shift the gear to R

position.

(Reverse), and adjust the mirror angle

• The gear is shifted to any position

higher than when the gear is in P (Park), N

except R (Reverse).

(Neutral) and D (Drive).

• The side view mirror adjustment button

is not selected.

NOTICE

When changing the angle of both side

view mirrors, it is recommended to

change the angle one side at a time

following the procedure 1 to 4.

5-54

• Be sure to adjust the Digital Center

Digital Center Mirror

Mirror before driving.

(DCM)

- Switch the system to the

if equipped

conventional rearview mirror mode

and be properly seated on the

The Digital Center Mirror is a system that

driver’s seat. Then adjust the mirror

uses the camera on the rear of the vehicle

so as to see the rear window properly.

and displays its image on the screen of

- Push the lever all the way to change

the Digital Center Mirror. The Digital

to digital mirror mode and adjust the

Center Mirror allows the driver to see the

display settings. Driving without

rear view despite obstructions, such as

adjusting the mirror may cause

the head restraint or luggage, ensuring

difficulty in watching the display at

rear visibility.

the Digital Mirror mode (camera view

WARNING

mode) due to the reflection from the

surface of the mirror.

• Failure to follow the warnings and

- As the range of the image display by

instructions for proper use of the Digital

the Digital Center Mirror is different

Center Mirror could result in serious

from that of the optical mirror, make

accident.

sure to check this difference before

The Digital Center Mirror is a

driving.

convenience feature but it is not a

• If the Digital Center Mirror

substitute for proper vehicle

malfunctions, immediately switch the

operation. The system has areas

system to the conventional rearview

where objects cannot be viewed.

mirror mode.

Check the blind spot of the Digital

Center Mirror before vehicle

• When strong light (for example,

operation. The driver is always

sunlight or high beams from following

responsible for safe driving.

vehicles) enters the camera, a light

beam or a glaring light may appear on

Do not operate the Digital Center

the monitor screen of the Digital Center

Mirror while driving. Doing so can not

Mirror. In that case, switch the system

be a distraction and it could lose

to the conventional rearview mirror

control of your vehicle and cause an

mode appropriately.

accident or serious injury.

Do not disassemble or modify the

Digital Center Mirror, the camera unit

or wirings. If you do, it may result in

accidents or fire. In case you notice

smoke or smell coming from the

Digital Center Mirror, stop using the

system immediately. See an

authorized HYUNDAI dealer for

servicing.

ONE1052294N

• If the camera lens (1) is dirty, the

displayed image may not be clear. In

this case, clean it with a soft cloth

dampened with water or a swab.

5-55

How To Change the Mode

Display Settings (Digital

Mirror Mode)

Settings of the display in the digital mirror

mode.

The mode can be switched when the

switch is in the ON position.

1. Pull the mode select lever all the way to

ONE1053298N

switch to the Digital Center Mirror

1. Press the menu button (1). You can

mode (camera view mode).

adjust the brightness and the vertical

* Displays an image of the area behind

angle of the display.

the vehicle. In this mode, camera

indicator (6) is shown.

Icons

Settings

2. Push the mode select lever all the way

display

to switch to the optical inside rearview

Select to adjust the

mirror mode

brightness of the display.

* Turns off the display of the Digital

Center Mirror allows it to be used as an

Select to adjust the display.

optical mirror.

2. Press the menu button repeatedly and

select the item you want to adjust.

Adjusting the mirror height

3. Press the button (2) or button (3) to

change the setting.

The icons will disappear if the button is

not operated for approximately 5

seconds or more.

* If the brightness of the Digital Center

Mirror is set too high, it may cause eye

strain.

Adjust the Digital Center Mirror to and

appropriate brightness. If your eyes

become tired, change to optical mirror

ONE1053297N

mode.

The height of the rearview mirror can be

adjusted to suit your driving posture.

Change to optical mirror mode, adjusting

the rearview mirror angle by moving it up

and down.

5-57

Convenience Features

To prevent the light sensors from

When using the Digital Center Mirror

malfunctioning

in digital mirror mode

• When the liftgate is open, the Digital

Center Mirror image may not display

properly. Before driving, make sure the

liftgate is closed.

• If the display is difficult to see due to

reflected light, close the sunshade for

the sunroof (if equipped).

• Any of the following conditions may

occur when driving in the dark, such as

at night. None of them indicates that

the malfunction has occurred.

ONE1053299N

- Colors of objects in the displayed

To prevent the light sensors from

image may differ their actual color.

malfunctioning, do not touch or cover

them.

- Depending on your physical

condition or age, it may take longer

than usual to focus on the displayed

Digital mirror mode operating

image. In this case, change to optical

condition

mirror mode.

The Start/Stop button is in the ON

- Do not let passengers stare at the

position.

displayed image when the vehicle is

When the Start/Stop button is changed

being driven, as doing so may cause

from ON position to OFF or ACC position,

motion sickness.

the image will be disappeared.

5-58

When the system malfunctions

•

Do not subject the camera to a strong

impact as this could cause a

malfunction. If this happens, have the

vehicle inspected by an authorized

HYUNDAI dealer as soon as possible.

•

Operating the system at the ON

position while the vehicle is not running

would cause discharging of the battery.

•

Do not attach an antenna of wireless

device near the Digital Center Mirror.

Electric wave from wireless device may

cause disturbed image in Digital Center

ONE1052300N

Mirror.

If the symbol shown in the illustration is

•

Do not push buttons excessively or

displayed when using the Digital Center

operating the lever roughly may cause

Mirror in digital mirror mode, the system

a system failure or the Digital Center

may be malfunctioning. The symbol will

Mirror itself to drop.

disappear in a few seconds. Operate the

•

Never rotate the body of Digital Center

lever, change to optical mirror mode and

Mirror by 90° or more. It may damage

have the vehicle inspected by an

the Digital Center Mirror. Do not apply

authorized HYUNDAI dealer.

strong shocks to the body of Digital

Center Mirror. It may cause a system

CAUTION

failure.

To prevent the Digital Center Mirror from

•

If it is difficult to see the Digital Center

malfunctioning

Mirror display screen because of a

• Do not use detergents, such as thinner,

strong external light, switch the mode

benzene, and alcohol to clean the

to the conventional rearview mirror

mirror. They may dis color, deteriorate

mode for better use.

or damage the mirror surface.

• Do not remove, disassemble or modify

the mirror and camera.

• Do not allow an organic solvent, vehicle

wax, window cleaner or glass coating to

adhere to the camera. If this happens,

wipe it off as soon as possible.

• When cleaning the camera lens, wipe

the camera lens with a damp soft cloth.

• Do not strongly rub the camera lens, as

it may be scratched and will not be able

to transmit a clear image.

5-59

Convenience Features

Digital Center Mirror error icon and solution

Symptom

Likely cause

Solution

The Digital Center

If the high temp

Mirror is extremely

Reducing the cabin temperature is

icon is

hot. (The display will

recommended to reduce the temperature of

displayed on

gradually become

the mirror. (The icon will disappear when the

the display right

more dim. If the

mirror becomes cool.)

side.

temperature continues

If the icon does not disappear even though the

to increase, the Digital

mirror is cool, have the vehicle inspected by an

Center Mirror will turn

authorized HYUNDAI dealer.

off.)

If the display

icon

has

Change to optical mirror mode and have the

been switched

The system may be

vehicle inspected by an authorized HYUNDAI

which is

malfunctioning.

dealer.

the display error

icon.

5-60

Convenience Features

Power Windows

Auto up/down window

The Start/Stop button must be in the ON

Pressing the power window switch

position to be able to raise or lower the

momentarily to the second detent

windows. Each door has a Power Window

position (6) completely lowers or lifts the

switch to control that door’s window. The

window even when the switch is released.

driver has a Power Window Lock button

To stop the window at the desired

which can block the operation of rear

position while the window is in operation,

passenger windows. The power windows

pull up or press down and release the

will operate for approximately 3 minutes

switch.

after the Start/Stop button is in the ACC

WARNING

or OFF position. However, if the front

doors are opened, the Power Windows

• Do not leave the vehicle running and

will not operate even within the 3 minute

the key in your vehicle with

period.

unsupervised children. Unattended

children could operate the window,

Window opening and closing

which could result in serious injury.

• Do not extend your head, arms or any

other body parts or objects outside the

window while driving to avoid serious

injury.

Resetting the power windows

If the power windows do not operate

normally, the automatic power window

system must be reset as follows:

1. Press the Start/Stop button to the ON

ONE1051033

position.

To open:

2. Close the window and continue pulling

Press the window switch down to the first

up on the power window switch for at

detent position (5). Release the switch

least one second.

when you want the window to stop.

If the power windows do not operate

To close:

properly after resetting, have the system

inspected by an authorized HYUNDAI

Pull the window switch up to the first

dealer.

detent position (5). Release the window

switch when you want the window to

WARNING

stop.

The automatic reverse feature doesn’t

activate while resetting the power

window system.Make sure body parts or

other objects are safely out of the way

before closing the windows to avoid

injuries or vehicle damage.

5-62

Automatic reverse

WARNING

Make sure body parts or other objects are

safely out of the way before closing the

windows to avoid injuries or vehicle

damage.

Objects less than 0.16 in. (4 mm) in

diameter caught between the window

glass and the upper window channel may

not be detected by the automatic reverse

window and the window will not stop and

reverse direction.

OLF044032

Power window lock button

If a window senses any obstacle while it is

closing automatically, it will stop and

lower approximately 12 in. (30 cm) to

allow the object to be cleared.

If the window detects the resistance

while the power window switch is pulled

up continuously, the window will stop

upward movement then lower

approximately 1 in. (2.5 cm).

If the power window switch is pulled up

continuously again within 5 seconds after

the window is lowered by the automatic

ONE1051020

window reverse feature, the automatic

The driver can disable the power window

window reverse will not operate.

switches on the rear passenger doors by

pressing the power window lock button.

Information

When the power window lock button is

The automatic reverse feature is only

pressed:

active when the “Auto Up” feature is used

• The rear passenger control will not be

by fully pulling up the switch to the

able to operate the rear passenger

second detent.

power window.

• Note that the front passenger control is

still able to operate the front passenger

window, and that the driver master

control can still operate all the power

windows.

5-63

Convenience Features

Remote window opening function

WARNING

if equipped

Do not allow children to play with the

Type A

power windows. Keep the driver’s door

power window lock button in the LOCK

position. Serious injury or death can result

from unintentional window operation by

a child.

NOTICE

• To prevent possible damage to the

power window system, do not open or

close two windows or more at the same

time. This will also ensure the longevity

Type B

of the fuse.

• Never try to operate the main switch on

the driver’s door and the individual

door window switch in opposite

directions at the same time. If this is

done, the window will stop and cannot

be opened or closed.

Type C

ONE1053308N

5-64

Type D

• One of the windows may stop operating

when the window is interrupted by

certain force. However, the other

windows will keep operating. Thus, you

should make sure that all windows are

opened.

• Please be aware that the doors unlock

when the windows are opened using

the remote window opening function.

ONE1053309N

You can still control the window

movement with the engine turned off.

Press the Door Unlock button (1) for more

than 3 seconds. The window moves down

after the doors are unlocked, as long as

you press the door unlock button. The

window movement stops, when you

release the door unlock button.

WARNING

If you stay on the function after operating

the Remote window opening function, it

is likely to cause a theft. In addition,

please use caution there might be a

malfunction due to the inflow of water

while raining.

Information

• The remote window opening function

will be operated only with the Safety

Power Windows equipped.

• The remote window opening function

may abruptly stop when you move

away from your vehicle during

operation. Stay in close proximity from

your vehicle, while monitoring the

window movement.

5-65

Convenience Features

The power sunshade can only be

Vision Roof

operated when the Start/Stop button is in

if equipped

the ON or START position.

• Push the switch rearward, the power

sunshade automatically slides open.

• Push the vision roof switch forward, the

power sunshade automatically closes.

To stop the power sunshade at any point,

push the switch in any direction.

Information

• The power sunshade can be operated

for approximately 3 minutes after the

ONE1051036

Start/Stop button is in the ACC or OFF

If your vehicle is equipped with a vision

position. However, if the front door is

roof, you can slide open the power

open, the power sunshade cannot be

sunshade and an all-glass roof appears.

operated even within the 3 minute

period.

Power sunshade

• Wrinkles formed on the power

sunshade are normal due to material

Use the power sunshade to block direct

characteristic.

sunlight coming through the vision roof

glass.

WARNING

• Adjust the power sunshade when your

vehicle stops. This could result in loss of

control and an accident that may cause

injury, or property damage.

• Do not leave the vehicle running and

the key in your vehicle with

unsupervised children. Unattended

children could operate the power

sunshade, which could result in injury.

ONE1051037

• Do not sit on the top of the vehicle. It

may cause injury or vehicle damage.

NOTICE

Do not pull or push the power sunshade

by hand as such action may damage the

power sunshade or cause it to

malfunction.

ONE1051038

5-66

Automatic reversal

Resetting the Vision Roof

ONE1051039

ONE1051037

If the power sunshade senses any

In some circumstances resetting the

obstacle while it is closing automatically,

power sunshade operation may need to

it will reverse direction then stop at a

be performed. Some instances where

certain position.

resetting the power sunshade may be

The auto reverse function may not work if

required include:

an object thin or soft is caught between

• When the 12 V battery is either

the sliding power sunshade and vision

disconnected or discharged

roof sash.

• When the power sunshade fuse is

replaced

WARNING

• If the power sunshade one-touch AUTO

• Make sure heads, hands, arms or any

OPEN/CLOSE operation is not

other body parts or objects are out of

functioning properly

the way before operating the power

Vision roof resetting procedure:

sunshade . Body parts or objects may

get caught causing injuries or vehicle

1. It is recommended to perform the reset

damage.

procedure with the vehicle in the ready

mode. Start the vehicle in P (Park).

• Never deliberately use your body parts

to test the automatic reversal function.

2. Make sure the power sunshade is in the

The power sunshade may reverse

fully closed position. If the power

direction, but there is a risk of injury.

sunshade is open, push the switch

forward until the power sunshade and

is fully closed.

3. Release the switch when the power

NOTICE

sunshade is fully closed.

Do not continue to push the switch after

4. Push the switch forward until the power

the power sunshade is fully opened or

sunshade moves slightly. Then release

closed. Damage to the power sunshade

the switch.

motor could occur.

5-67

Convenience Features

5. Once again push and hold the switch

Exterior Features

forward until the power sunshade

slides open and close. Do not release

the switch until the operation is

Hood

completed.

If you release the switch during

Opening the hood

operation, start the procedure again

from step 2.

Information

If the power sunshade is not reset when

the vehicle battery is disconnected or

discharged, or the power sunshade fuse is

blown, the power sunshade may not

operate normally.

ONE1051041

1. Park the vehicle and set the parking

brake.

2. Pull the release lever to unlatch the

hood. The hood should pop open

slightly.

ONE1051042

3. Go to the front of the vehicle, raise the

hood slightly, push to the left the

secondary hood release lever (1) inside

of the hood center and lift the hood (2).

5-68

Closing the hood

Front trunk

1. Before closing the hood, check in and

around the motor compartment to

Opening the Front Trunk

ensure the following:

• Any tools or other loose objects are

removed from the motor room area

or hood opening area

• All glove, rags, or other combustible

material is removed from the motor

compartment

• All filler caps are tightly and correctly

installed

2. Lower the hood halfway (lifted

approximately 12 in. (30 cm) from the

ONE1051213

closed position) and push down to

securely lock in place. Then double

• Open the hood

check to be sure the hood is secure. If

• Lift up the front trunk cover while

the hood can be raised slightly, it is not

depressing the front trunk lever (1).

securely locked. Open it again and

close it with more force.

Closing the Front Trunk

WARNING

Push down the front trunk cover to the

right position.

•

Before closing the hood, ensure all

obstructions are removed from around

Information

the hood opening. The hood will rise up

or move down automatically if the

Available front trunk weight

height is not firmly adjusted. Be aware

• 2WD : 55 lbs. (25 kg)

of the damage caused by the

• AWD : 25 lbs. (10 kg)

unintended hood movements.

Available front trunk weight depends on

•

Always double check to be sure that the

the specifications.

hood is firmly latched before driving

away. Check there is no hood open

warning light or message displayed on

the instrument cluster. Driving with the

WARNING

hood opened may cause a total loss of

• NEVER make an attempt to get inside

visibility, which might result in an

the front trunk. It will cause a fatal

accident.

injury.

•

Do not move the vehicle with the hood

in the raised position, as vision is

• Before closing the hood, ensure all

obstructed, which might result in an

obstructions are removed from around

accident, and the hood could fall or be

the hood opening. The hood will rise up

damaged.

or move down automatically if the

height is not firmly adjusted. Be aware

of the damage caused by the

unintended hood movements.

5-69

Convenience Features

•

Never store cigarette lighters, propane

NOTICE

cylinders, or other

flammable/explosive materials in the

To avoid possible theft, do not leave

vehicle. These items may catch fire

valuables in the storage compartments.

and/or explode if the vehicle is exposed

to hot temperatures for extended

periods.

Power Liftgate

if equipped

CAUTION

Power liftgate operating conditions

•

Do not exceed the luggage volume

The power liftgate operates when the

capacity of the front trunk. The

gear is in P (Park) with the vehicle

overweighted front trunk can be

running. However, the power liftgate will

severely damaged.

operate regardless of the gear position

•

Do not store the fragile objects in the

when the vehicle is off. Also, the liftgate

front trunk.

can be opened only when vehicle speed is

below 1.8 mph (3 km/h).

•

ALWAYS keep the front trunk cover

closed securely while driving. Items

For safety, before attempting to open or

inside your vehicle are moving as fast

close the liftgate, make sure the vehicle is

as the vehicle. If you have to stop or

in P (Park).

turn quickly, or if there is a crash, the

items can be damaged.

WARNING

•

Do not spray water in the front trunk.

• Never leave children or animals

Vehicle driving system may get

unattended in your vehicle. Children

damaged since the front trunk is

may operate the power liftgate. Doing

located at the center of motor

so can result in injury to themselves or

compartment.

others and can damage the vehicle.

•

Be careful when you store any liquid in

the front trunk. If liquid leak outside the

front trunk, it will cause a damage to

the electric devices in the motor

compartment.

•

Do not press the front trunk cover or

place the objects on the front trunk

cover. It may be deformed or damaged.

•

When closing the front trunk cover, be

careful not to touch objects inside the

trunk. Loaded objects or the front trunk

ONE1051286L

may be deformed or damaged and the

• Make sure that there are no people or

front trunk cover may be opened during

objects in the path of the power liftgate

driving due to poor closing, resulting in

or smart liftgate prior to use. Serious

joints and damage.

injury, damage to the vehicle or

damage to surrounding objects (for

example, walls, ceilings, vehicles, etc.)

may result if contact with the liftgate

occurs.

5-70

• The tailgate may not open or may close

unintentionally injuring people around

the tailgate under the following

situation:

- There is a lot of snow on the tailgate.

- There is a heavy object on the tailgate

such as a bicycle carrier, ladder, etc.

Do not open the tailgate before

removing snow or heavy object on the

tailgate.

ONE1051206N

• Do not grab or hold on to the liftgate

NOTICE

support struts at any time. Damage to

the liftgate support struts could result.

• Do not close or open the liftgate

Deformation of the liftgate support

manually. This may cause damage to

struts may cause vehicle damage and

the power liftgate. If it is necessary to

personal injury may occur.

close or open the liftgate manually

when the battery is discharged or

• Do not modify or repair any part of the

disconnected, do not apply excessive

power liftgate by yourself. This must be

force.

done by an authorized HYUNDAI

dealer.

• Do not operate the power liftgate more

than 10 times continuously when the

• Do not operate the power liftgate under

vehicle is not running. Use the power

the following conditions. The power

liftgate with the vehicle running when

liftgate may not operate properly.

the power liftgate is used repeatedly to

- One side of the vehicle is lifted to

prevent battery discharge.

inspect the vehicle or change a tire

• Do not leave the power liftgate open for

- Parking on an uneven road such as a

a long period of time. This may drain the

slope, etc.

battery.

• Close the liftgate completely and lock

• Do not apply excessive force when the

all doors and liftgate using the central

power liftgate is operating. Doing so

door lock button before using an

could result in vehicle damage.

automatic car wash.

• Do not spray high pressure water

directly on the power liftgate outside

open/close button. The liftgate may

open unintentionally.

5-71

Convenience Features

Operating the power liftgate

Information

•

If the liftgate is not fully closed and

Power liftgate open/close button (Smart

vehicle speed is at or above 1.8 mph (3

key, Instrument panel)

km/h), a warning will sound 10 times.

Type A

Immediately park the vehicle at a safe

place, close the liftgate, and check that

the liftgate open warning on the

instrument cluster is turned off.

•

In cold and wet climates, the outside

power liftgate open/close button may

not work properly due to freezing

conditions. If this occurs, remove the

ice before using the outside power

liftgate open/close button or use the

power liftgate open/close button on

ONE1051043

the smart key or the instrument panel.

Type B

•

Operating the power liftgate more than

5 times continuously could cause

damage to the operating motor. If this

occurs, the power liftgate will not

operate to prevent the motor from

overheating. If any of the power liftgate

buttons are pressed to try to open the

liftgate, the chime will sound 3 times,

but the liftgate will remain closed.

Allow the power liftgate system to cool

for about 1 minute before operating the

system again.

ONE1051044

ONE1051045

When the liftgate is closed, press the

power liftgate open/close button for 1

second. The power liftgate opens with a

warning sound.

While the liftgate is opening, press the

button to stop liftgate operation.

5-72

When the power liftgate is opened, press

Power liftgate open/close button (Inside the

and hold the power liftgate open/close

power liftgate)

button to close the liftgate. If you release

the button while the liftgate is closing,

power liftgate operation will stop with a

warning sound for 5 seconds.

Also, if the smart key is not within

operation range (approximately 394 in.(10

m)) from the vehicle, power liftgate

operation will stop with a warning sound

for 5 seconds.

Power liftgate open/close button (Outside

the power liftgate)

ONE1051047

Press the power liftgate open/close

button. The liftgate opens or closes

automatically.

Automatic reverse

During power liftgate operation if the

power liftgate senses any obstacle, the

liftgate will stop or will fully open. The

automatic reverse feature may not

operate properly, or it may operate

unexpectedly under the following

ONE1051046L

When the liftgate is closed, press the

circumstances:

power liftgate open/close button (1) to

• The automatic reverse feature may not

open the liftgate.

detect the resistance if the detected

If the vehicle is locked, press the power

resistance is below a certain level, or if

liftgate open/close button (1) with the

the liftgate is almost fully closed near

smart key in your possession.

the latched position.

If the liftgate is unlocked, the liftgate will

• The automatic reverse feature may

open or close with a warning sound when

operate if a strong impact is applied

the power liftgate open/close button (1) is

with no obstructions placed.

pressed without carrying the smart key.

WARNING

Never intentionally place any object or

part of your body in the path of the power

liftgate to make sure the automatic

reverse feature operates. Serious injury,

or damage to the vehicle or object may

occur.

5-73

Convenience Features

User height setting

Information

1. Position the liftgate manually to the

The power liftgate may stop operating if

height you prefer.

the automatic reverse feature operates

2. Press the power liftgate open/close

more than two times while attempting to

button located inside the liftgate for

open or close the liftgate. If this occurs,

more than 3 seconds. If ‘User Height

carefully open or close the liftgate

Setting’ is selected for the power

manually, and then after 30 seconds try to

liftgate opening height, the power

operate the power liftgate automatically

liftgate will automatically open to the

again.

height manually set by you.

Information

Setting the power liftgate

•

If the power liftgate opening height has

To use each feature, you must select the

not been manually set, the power

opening speed or opening height from

liftgate will fully open when ‘User

the settings menu. Deselect the settings

Height Setting’ from the infotainment

when you do not want to use the feature.

system is selected.

Power liftgate opening speed

•

If one of the height setting (Full

Open/Level 3/Level 2/Level 1) is

To adjust the power liftgate speed, select

selected from the settings menu in the

Setup > Vehicle Settings > Door/liftgate

infotainment system, and then ‘User

> Power liftgate Opening Speed >

Height Setting’ is selected, the liftgate

Fast/Slow in the infotainment system.

will open to the height manually set by

(Default setting is ‘Fast’.)

you.

Power liftgate opening height

•

The power liftgate opening speed and

opening height settings change

To adjust the power liftgate opening

according to the linked User Profile. If

height, select Setup > Vehicle Settings >

the User Profile is changed, power

Door/liftgate > Power liftgate Opening

liftgate opening speed and opening

Height > Full Open/Level 3/Level 2/Level

height settings will change accordingly.

1/User Height Setting in the infotainment

system.

Information

The infotainment system may change

after software updates. For more

information, refer to the user’s manual

provided in the infotainment system and

the quick reference guide.

5-74

Resetting the power liftgate

Emergency liftgate safety release

In some circumstances resetting the

power liftgate operation may need to be

performed. Some instances where

resetting the power liftgate may be

required include:

• When the 12 V battery is recharged

• When the 12 V battery is reinstalled

after removal or replacement

• When the related fuse is reinstalled

after removal or replacement

ONE1051049N

To unlock and open the liftgate manually

from inside the luggage compartment,

perform the following procedure:

1. Insert a long, flat object, such as a key

into the opening at the bottom of the

liftgate.

2. Slide the latch in the direction of the

arrow to unlock the liftgate.

3. Push the liftgate to open.

ONE1051047

1. With the vehicle off or running, put the

WARNING

gear in P (Park).

• For emergencies, be fully aware of the

2. Press the power liftgate open/close

location of the emergency liftgate

inner button simultaneously until a

safety release latch in the vehicle and

chime sounds.

how to open the liftgate if you are

accidentally locked in the luggage

3. Slowly close the liftgate manually.

compartment.

4. Press the power liftgate open/close

• No one, including animals, should be

outer button. The power liftgate will

allowed to occupy the luggage

open with a chime sound. Wait until the

compartment of the vehicle at any

liftgate fully opens to complete

time. The luggage compartment is a

resetting. If the liftgate stops before it is

very dangerous location in the event of

fully open, resetting cannot be

an accident.

completed.

• Use the release latch for emergencies

Information

only. Use extreme caution, especially

while the vehicle is in motion.

If the power liftgate does not operate

properly after the above procedure, have

the system inspected by an authorized

HYUNDAI dealer.

5-75

Convenience Features

Smart Liftgate

• The smart key is detected within 15

seconds after the doors are closed and

if equipped

locked, and within 60 in. (1.5 m) from

the front door handles. (for vehicles

equipped with Welcome Mirror).

• The smart key is in the vehicle.

• The vehicle is on charge.

1. Settings

To use smart liftgate, it must be

enabled from the Settings menu in the

infotainment system screen.

ONE1051050N

Select:

On a vehicle equipped with a smart key,

• Setup > Vehicle Settings >

the liftgate can be opened with

Door/Liftgate > Smart Liftgate

hands-free activation using the smart

liftgate system.

Information

The infotainment system may change

Using smart liftgate

after software updates. For more

The hands-free smart liftgate system can

information, refer to the user’s manual

be opened automatically when the

provided in the infotainment system

following conditions are met:

and the quick reference guide.

• The smart liftgate option is enabled in

the Settings menu in the infotainment

system screen.

2. Detect and Alert

• The smart liftgate is activated and

The smart liftgate detecting area

ready 15 seconds after all the doors are

extends approximately 20-40 in.

closed and locked.

(50-100 cm) behind the vehicle. If you

are positioned in the detecting area and

• The smart liftgate will open when the

are carrying the smart key, the hazard

smart key is detected in the area behind

warning lights will blink and the chime

the vehicle for 3 seconds.

will sound to alert you that the smart

• When disconnecting the charging

liftgate will open.

connector, the smart liftgate is

activated.

Information

Do not approach the detecting area if

Information

you do not want the liftgate to open. If

The smart liftgate will NOT operate when:

you have unintentionally entered the

• A door is not locked or closed.

detecting area and the hazard warning

lights and chime starts to operate,

• The smart key is detected within 15

move away from the area behind the

seconds from when the doors were

vehicle with the smart key. The liftgate

closed and locked.

will remain closed.

5-76

3. Automatic opening

• If you press the liftgate open button (3)

for more than 1 second, the liftgate

After the hazard warning lights blink

opens.

and the chime sounds 6 times, the

smart liftgate will open.

• The smart liftgate will still be activated

if you press the door lock button (1) or

liftgate open/close button (3) on the

Deactivating smart liftgate

smart key as long as the smart liftgate is

Type A

not already in the Detect and Alert

stage.

• In case you have deactivated the smart

liftgate by pressing the smart key

button and opened a door, the smart

liftgate can be activated again by

closing and locking all doors.

Detecting area

ONE1051051

Type B

ONE1051053R

• The smart liftgate detecting area

extends approximately 20-40 in.

(50-100 cm) behind the vehicle. If you

ONE1051052

are positioned in the detecting area and

(1) Door lock

are carrying the smart key, the hazard

(2) Door unlock

warning lights will blink and the chime

(3) Liftgate open/close

will sound for about 3 seconds to alert

(4) Panic

you that the liftgate will open.

If you press any button on the smart key

• The alert stops once the smart key is

during the Detect and Alert stage, the

moved outside of the detecting area

smart liftgate will be deactivated.

within the 3 second period.

Make sure to be aware of how to

deactivate the smart liftgate for

emergency situations.

• If you press the door unlock button (2),

the smart liftgate will be deactivated

temporarily. But, if you do not open any

door for 30 seconds, the smart liftgate

will be activated again.

5-77

Convenience Features

Electric Charging Door

Information

•

Smart liftgate may not operate properly

if any of the following occur:

- The smart key is close to a radio

transmitter such as a radio station or

an airport which can interfere with

normal operation of the transmitter.

- The smart key is near a mobile two

way radio system or a mobile phone.

- Another vehicle’s smart key is being

operated close to your vehicle.

•

Smart liftgate detecting area may

ONE1Q011040

change when:

The driver can open and close the

charging door with the following

- The vehicle is parked on an incline or

methods:

slope.

• When the shift gear is in P (Park), push

- One side of the vehicle is raised or

the charging door to open/close

lowered relative to the opposite side.

• Push the Close button located inner

part of the charging door

• Press the charging door button in the

smart key

• Use the Voice Recognition

NOTICE

• If the charging door does not open

because ice has formed around it, tap

lightly or push on the door to break the

ice and release the door. If necessary,

use hand temperature to melt down the

ice or move the vehicle to a warm place

and allow the ice to melt. Do not pry on

the charging door or use unauthorized

tools to open the charging door.

• After closing the charging door, push

the door again to ensure that the

charging door is completely closed.

• Make sure that the charging door is

closed before driving the vehicle. If the

charging door is opened, mechanical

parts of the charging door can be

damaged.

• After closed the charging door, be sure

to check the warning light is off.

5-78

•

After charging the vehicle, close the

Information

charging inlet by the charging inlet

cover properly. If the charging inlet

• The charging door automatically closes

cover is closed improperly, the

when:

charging inlet and the charging door

- The charging connector is

can be damaged.

disconnected

•

Do not pry on the charging door while

- The door is opened and the charging

the charging door is opening. The

connector is not connected for a

charging door may stop moving. Also,

certain period of time

the electrical mechanism of the

charging door and its related parts can

- The gear is not in P (Park)

be severely damaged.

• After replacing battery (12 V), open and

close the charging door once to check

•

While washing the vehicle, do not spray

that the charging door automatic

a high pressure water to the charging

opening mechanism is functioning

door directly. The high pressure can

properly.

damage the charging door.

For more details, refer to “Charging

CAUTION

Electric Vehicle” section in chapter 1.

•

The charging door opens upwards.

Check the surrounding while the

charging door is open or close. Be

aware of your head or limbs from being

hit or stuck to the charging door.

•

Do not hold the hinge to prevent

damaging the charging door and

causing other accidents.

5-79

Convenience Features

Augmented Reality HUD

Head-up Display Settings

if equipped

ONE1041053L

• Head-up display can be enabled from

ONE1051214R

the Settings menu in the infotainment

The Head-Up Display is an optional

system screen. Select either

feature that allows the driver to view

Augmented Reality (AR) mode or

information projected onto a transparent

Standard mode from:

screen while still keeping your eyes safely

- Setup > Vehicle > Head-Up Display >

on the road ahead while driving.

Display mode > Augmented reality

mode / Standard mode

• After turning on the head-up display,

you can change the settings of ‘Display

control’, ‘AR Matching Adjustment’

(When AR mode is selected) and

‘Content selection’ of the Head-up

display.

Information

• Standard mode is the basic setting for

Head-up display.

• The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system

and the quick reference guide.

5-80

Head-up Display Information

(14)Leading Vehicle Departure Alert (AR)

(15)Highway Lane Change Assist

information (AR)

AR mode display information

Standard mode display information

ONE1051217E

ONE1051244N

(1) Turn by Turn (TBT) navigation

information

(2) Traffic information

(3) Speedometer information

(4) SCC set speed information

(5) SCC vehicle distance information

(6) Lane Following Assist information

(7) Lane Safety information

(8) Blind-Spot Safety information

ONE1051218E

(9) Highway Auto Speed Change

(1) Turn by Turn (TBT) navigation

information

(10)Highway Driving Assist information

(2) Traffic signs or speed limit

(11) Surrounding vehicle information

information

(3) Speedometer information

Information

(4) SCC set speed information

(5) SCC vehicle distance information

Standard Head-up display information

(6) Lane Following Assist information

may not be consistent based on the

different system settings menu.

(7) Lane Safety information

(8) Blind-Spot Safety information

(9) Highway Auto Speed Change

information

(10)Highway Driving Assist information

(11) Turn by turn (TBT) navigation

information (AR)

(12)Lane Safety Information (AR)

(13)Front Vehicle indicator (AR) (if

Highway Lane Change Assist function

equipped)

5-81

Convenience Features

Precautions while Using the

• For your safety, make sure to stop the

vehicle before adjusting the settings.

Head-up Display

• Do not tint the front windshield glass or

•

It may sometimes be difficult to read

add other types of metallic coating.

information on the Head-Up Display in

Otherwise, the Head-Up Display image

the following situations.

may be invisible.

- The driver is improperly positioned in

• Do not place any accessories on the

the driver’s seat

crash pad or attach any objects on the

- The driver wears polarizing-filter

windshield glass.

sunglasses

• When replacing the front windshield

- An object is located above the

glass, replace it with a windshield glass

head-up display cover

designed for Head-Up Display

- The vehicle is driven on a wet road

operation. Otherwise, duplicated

images may be displayed on the

- Any improper lighting accessory is

windshield glass.

installed inside the vehicle, or there is

incoming light from outside of the

WARNING

vehicle

- The driver wears glasses

• The warning information of Blind-Spot

Safety on the Head-Up Display are

- The driver wears contact lenses

supplemental. Do not solely depend on

When it is difficult to read the Head-up

them to change lanes. Always take a

display information, adjust the image

look around before changing lanes.

position, brightness level or AR

The driving route guidance display in

matching information from the Settings

the augmented reality mode is an

menu in the infotainment system

auxiliary function. Be sure to check the

screen.

navigation screen together.

•

The AR mode display information may

• ALWAYS pay attention on the road

be difficult to recognize when the

while driving when the Head-Up

vehicle is driven under severe weather

Display is on.

condition, such as heavy rain, heavy

snow, low visibility, etc.

•

Since the information displayed on the

head-up display partially overlaps with

Information

the road ahead, you may feel fatigue

Head-Up Display includes GPL, LGPL,

and discomfort while driving. If you feel

MPL and other open source license

tired or uncomfortable, adjust the

softwares. All license notices including

image, and if the symptoms persist,

related source code are provided at

turn off the head-up display before

http://www.mobis.co.kr/opensource/list.

driving.

do.

•

When the direct flash light or sunlight

If the driver requests on-board software

hits the front windshield, a warning

open source code via

message will appear. If the temperature

MOBIS_OSSrequest@mobis.co.kr within

of the front windshield keep rises,

3 years after buying this product, a

Head-up display will be deactivated

CD-ROM or other storage device will be

temporarily to protect Head-up display

sent with the minimum cost covering

from the high temperature. When the

storage device cost and delivery cost.

temperature drops, Head-up display

will be reactivated.

5-82

AUTO headlight

Lighting

Exterior Lights

Lighting control

To operate the lights, turn the knob at the

end of the control lever to one of the

following positions:

ONE1051057

The parking lamp and headlight will be

turned ON or OFF automatically

depending on the amount of daylight as

measured by the ambient light sensor (1)

at the upper end of the windshield glass.

Even with the AUTO headlight feature in

operation, it is recommended to manually

turn ON the headlights when driving at

ONE1051056

night or in a fog, driving in the rain, or

(1) OFF

when you enter dark areas, such as

(2) AUTO headlight

tunnels and parking facilities.

(3) Parking lamp

NOTICE

(4) Headlight

• Do not cover or spill anything on the

Daytime Running Light (DRL)

sensor (1) located at the upper end of

The Daytime Running Lights (DRL) can

the windshield glass.

make it easier for others to see the front

• Do not clean the sensor using a window

of your vehicle during the day, especially

cleaner, the cleanser may leave a light

after dawn and before sunset.

film which could interfere with sensor

The DRL system will turn the dedicated

operation.

lamp OFF when :

• If your vehicle has window tint or other

• The headlights are ON.

types of metallic coating on the front

windshield, the AUTO headlight system

• The parking brake is applied.

may not work properly.

• The vehicle is turned off.

5-83

Convenience Features

Parking lamp (

)

High beam operation

ONE1051058

ONE1051061

The parking lamp, license plate lamp and

To turn on the high beam headlight, push

instrument panel lamp are turned ON.

the lever away from you. The lever will

return to its original position.

Headlight (

)

The high beam indicator will light when

the headlight high beams are switched

on.

To turn off the high beam headlight, pull

the lever towards you. The low beams will

turn on.

ONE1051059

The headlight, parking lamp, license plate

lamp and instrument panel lamp are

turned ON.

Information

ONE1051060

The Start/Stop button must be in the ON

To flash the high beam headlight, pull the

position to turn on the headlight.

lever towards you, then release the lever.

The high beams will remain ON as long as

you hold the lever towards you.

5-84

Turn signals and lane change signals

Battery saver function

The purpose of this feature is to prevent

the battery from being discharged. The

system automatically turns off the

Parking lamp when the driver turns the

vehicle off and opens the driver-side

door.

With this feature, the Parking lamps will

turn off automatically if the driver parks

on the side of road at night.

However, the Parking lamps stay ON even

when the driver-side door is opened if the

ONE1051062

light headlight switch is turned to the

To signal a turn, push down on the lever

Parking lamp or AUTO (if equipped)

for a left turn or up for a right turn in

position after the vehicle is turned off.

position (A).

If necessary, to keep the lamps on turn

If an indicator stays on and does not flash

the Parking lamps OFF and ON again

or if it flashes abnormally, one of the turn

using the headlight switch on the steering

signal bulbs may be burned out and will

column after the vehicle is turned off.

require replacement.

One touch turn signal

Headlight delay function

To use One Touch Turn Signal push the

If the Start/Stop button is in the ACC

turn signal lever up or down to position

position or the OFF position with the

(B) and then release it.

headlights ON, the headlights (and/or

Parking lamps) remain on for about 5

The lane change signals will blink 3, 5 or 7

minutes. However, if the driver’s door is

times.

opened and closed, the headlights are

You can enable the One Touch Turn

turned off after 15 seconds. Also, with the

Signal function or choose the number of

vehicle off if the driver’s door is opened

blinking by selecting Setup > Vehicle

and closed, the headlights (and/or

Settings > Lights> One Touch Turn

Parking lamps) are turned off after 15

Signal (or One-touch indicator) > 3

seconds.

flashes/5 flashes/7 flashes/Off in the

The headlights (and/or Parking lamps)

infotainment system screen.

can be turned off by pressing the lock

button on the smart key twice or turning

Information

the headlight switch to the OFF or AUTO

The infotainment system may change

position.

after software updates. For more

You can enable the headlight delay

information, refer to the user's manual

function by selecting Setup > Vehicle

provided in the infotainment system and

Settings > Lights > Headlight Delay (or

the quick reference guide.

Headlight time-out) in the infotainment

system screen.

5-85

Convenience Features

Front lamps

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

NOTICE

If the driver exits the vehicle through

another door besides the driver door, the

ONE1051065

battery saver function does not operate

and the headlight delay function does not

Front map lamp (

turn OFF automatically.

Touch either icons to turn the map lamp

This may cause the battery to discharge.

on or off. This light produces a spot beam

To avoid battery discharge, turn OFF the

for convenient use as a map lamp at night

headlights manually from the headlight

or as a personal lamp for the driver and

switch before exiting the vehicle.

the front passenger.

Door lamp (

Interior Lights

The front or rear room lamps come on

when the front or rear doors are opened.

WARNING

When doors are unlocked by the smart

Do not use the interior lights when driving

key, the front and rear lamps come on for

in the dark. The interior lights may

approximately 30 seconds as long as any

obscure your view and cause an accident.

door is not opened. The front and rear

room lamps go out gradually after

approximately 30 seconds when the door

is closed. However, if the Start/Stop

NOTICE

button is in the ON position or all doors

Do not use the interior lights for extended

are locked, the front and rear lamps will

periods when the vehicle is turned off or

turn off. If a door is opened with the

the battery will discharge.

Start/Stop button in the ACC position or

the OFF position, the front and rear lamps

will stay on for about 5 minutes.

Interior lamp AUTO cut

The interior lamps will automatically go

Room lamp (

)

off approximately 20 minutes after the

Press the button to turn ON the room

vehicle is turned off and the doors are

lamp for the front/rear seats.

closed. If a door is opened, the lamp will

go off 25 minutes after the vehicle is

Mood lamp (

)

turned off. If the doors are locked by the

if equipped

smart key and the vehicle enters the

armed stage of the theft alarm system,

Press the button to turn On the mood

the lamps will go off five seconds later.

lamp. Press again to turn the lamp off.

5-86

Rear lamps

Vanity mirror lamp

Room lamp (without vision roof)

OTM050200

ONE1051066

Push the switch to turn the light on or off.

Personal lamp (with vision roof)

•

The lamp will turn on if this button is

pressed.

•

The lamp will turn off if this button is

pressed.

NOTICE

Always have the switch in the off position

when the vanity mirror lamp is not in use.

ONE1051067

If the sunvisor is closed without the lamp

•

(Room lamp):

off, it may discharge the battery or

(Personal lamp):

damage the sunvisor.

Press the button to turn the lamp on or

off.

Glove box lamp

ONE1051068N

The glove box lamp turns on for about 20

minutes when the glove box is opened.

5-87

Convenience Features

Door mood lamp

Information

if equipped

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

Luggage compartment lamp

ONE1091026

•

Door mood lamp

To set the brightness and the color of

the door mood lamp, select Setup >

Vehicle Settings > Lights > Interior

mood lamp’

•

When driving at night or under low light

driving conditions, the sensors detect

ONE1051069

the light level around the vehicle and

The lamp turns on when the liftgate is

automatically adjust the brightness of

opened.

the mood lamp.

To set the automatic brightness

Headlight and Parking lamp

adjustment turn On/Off, select Setup >

Vehicle Settings > Lights > Interior

When the light switch is ON, and all the

Mood Lamp > Brightness control

doors (and liftgate) are closed and locked,

the headlight and Parking lamp will turn

•

There are different colors for different

on for approximately 15 seconds if the

drive modes.

door unlock button is pressed on the

To set the colors for the different drive

smart key.

modes, select Setup > Vehicle Settings

Select Setup > Lights > Headlight Delay

> Lights > Interior Mood Lamp > Colors

from the Settings menu to turn on this

for the drive modes

function.

•

The color of the mood lamp turns red

when the vehicle speed exceeds the

Information

speed limit in the speed control section.

The infotainment system may change

To set the color change function, select

after software updates. For more

Setup > Vehicle Settings > Lights >

information, refer to the user's manual

Interior Mood Lamp > Speed limit

provided in the infotainment system and

warning)

the quick reference guide.

5-88

Interior lamp

High Beam Assist (HBA)

When the interior lamp switch is in the

if equipped

position and all doors (and liftgate) are

closed and locked, the room lamp will

come on for 30 seconds if any of the

below is performed.

• When the door unlock button is pressed

on the smart key.

• When you touch the touch sensor on

the door handle while carrying the

smart key.

At this time, if you press the door lock or

unlock button on the smart key the lamps

will turn off immediately.

ONE1051064

High Beam Assist will automatically

adjust the headlight range (switches

between high beam and low beam)

depending on the brightness of detected

vehicles and certain road conditions.

Detecting sensor

ONE1071262

(1)

: front view camera

The front view camera is used as a

detecting sensor to detect ambient light

and brightness while driving.

Refer to the picture above for the detailed

location of the detecting sensor.

5-89

Convenience Features

NOTICE

High Beam Assist Operation

• Always keep the front view camera in

Display and control

good condition to maintain optimal

performance of High Beam Assist.

• After selecting ‘High Beam Assist’ in the

Settings menu, High Beam Assist will

• For more details on the precautions of

operate by following the procedure

the front view camera, refer to

below.

“Forward Collision-Avoidance Assist

(FCA)” section in chapter 7.

- Place the headlight switch in the

AUTO position and push the

headlight lever towards the

instrument cluster. The High Beam

High Beam Assist Settings

Assist (

) indicator light will

illuminate on the instrument cluster

Setting features

and High Beam Assist will be

enabled.

- When High Beam Assist is enabled,

high beams turn on when the vehicle

speed is above 20 mph (30 km/h).

The High Beam (

) indicator light

illuminates on the instrument cluster.

When the vehicle speed is below 12

mph (20 km/h), high beams do not

turn on and the high beam (

)

indicator light illuminates in white.

• When High Beam Assist is operating, if

ONE1051248L

the headlight lever or switch is used,

With the Start/Stop button in the ON

High Beam Assist operates as follow:

position, select Lights > High Beam

Assist from the Settings menu to turn on

- If the headlight lever is pulled

High Beam Assist and deselect to turn off

towards you when the high beam is

the function.

off, the high beam will turn on

without High Beam Assist canceled.

WARNING

When you let go of the headlight

lever, the lever will move to the

For your safety, change the Settings after

middle and the high beam will turn

parking the vehicle at a safe location.

off.

- If the headlight lever is pulled

towards you when the high beam is

on by High Beam Assist, low beam

will turn on and the function will turn

off.

- If the headlight switch is placed from

AUTO to another position

(headlight/position/off), High Beam

Assist will turn off and the

corresponding lamp will turn on.

5-90

• When High Beam Assist is operating,

Limitations of High Beam Assist

high beam switches to low beam if any

High Beam Assist may not work properly

of the following conditions occur:

in the following situations:

- When the headlight of an oncoming

•

Light from an oncoming or front vehicle

vehicle is detected.

is not detected because of lamp

- When the tail lamp of a vehicle in

damage, or because it is hidden from

front is detected.

sight, etc.

- When the headlight or tail lamp of a

•

Headlight of an oncoming or front

motorcycle or a bicycle is detected.

vehicle is covered with dust, snow or

water.

- When the surrounding ambient light

is bright enough that high beams are

•

A front vehicle’s headlights are off, but

not required.

the fog lamps are on, etc.

- When streetlights or other lights are

•

There is a lamp that has a similar shape

detected.

as a vehicle’s lamp.

•

Headlights have been damaged or not

Information

repaired properly.

The images or colors may be displayed

•

Headlights are not aimed properly.

differently depending on the

•

Driving on a narrow curved road, rough

specifications of the instrument panel or

road, uphill or downhill.

theme.

•

Vehicle in front is partially visible on a

crossroad or curved road.

High Beam Assist Malfunction

•

There is a traffic light, reflecting sign,

flashing sign or mirror ahead.

and Limitations

•

There is a temporary reflector or flash

ahead (construction area).

High Beam Assist malfunction

•

The road conditions are bad such as

being wet, iced or covered with snow.

•

A vehicle suddenly appears from a

curve.

•

The vehicle is tilted from a flat tire or is

being towed.

•

Light from an oncoming or front vehicle

is not detected due to obstacles in the

air such as exhaust fume, smoke, fog,

snow, or water spay or blizzard on the

road, or fogging in the lamp, etc.

OJK050059L

When High Beam Assist is not working

Information

properly, the ‘Check High Beam Assist

For more details on the limitations of the

(HBA) system’ warning message will

Front View Camera, refer to “Forward

appear and warning light will

Collision-Avoidance Assist (FCA)” section

illuminate on the instrument cluster. Have

in chapter 7.

the function inspected by an authorized

HYUNDAI dealer.

5-91

Convenience Features

Wipers And Washers

WARNING

• At times, High Beam Assist may not

work properly. High Beam Assist is for

your convenience only. It is the

responsibility of the driver for safe

driving practices and always check the

road conditions for your safety.

• When High Beam Assist does not

operate properly, change the headlight

position manually between high beam

and low beam.

ONE1051070E

A. Wiper speed control

• MIST - Single wipe

• OFF - Off

• INT - Intermittent wipe

AUTO* - Auto control wipe

• LO - Low wiper speed

• HI - High wiper speed

B. Intermittent wipe time

adjustment/Auto control wipe time

adjustment*

C. Wash with brief wipes

* : if equipped

5-92

Front Windshield Wipers

AUTO (Automatic) control

Operates as follows when the Start/Stop

button is in the ON position.

MIST : For a single wiping cycle, push the

lever upward (or downward) and release.

The wipers will operate continuously if

the lever is held in this position.

OFF : Wiper is not in operation.

INT : Wiper operates intermittently at the

same wiping intervals. To vary the speed

setting, turn the speed control knob (B).

AUTO : The rain sensor located on the

ONE1051072

upper end of the windshield glass senses

The rain sensor located on the upper end

the amount of rainfall and controls the

of the windshield glass senses the

wiping cycle for the proper interval. The

amount of rainfall and controls the wiping

more it rains, the faster the wiper

cycle for the proper interval.

operates. When the rain stops, the wiper

The wiper operation time will be

stops. To vary the speed setting, turn the

automatically controlled depends on

speed control knob.

rainfall.

LO : The wiper runs at a lower speed.

When the rain stops, the wiper stops.

HI : The wiper runs at a higher speed.

To vary the sensitivity setting, turn the

sensitivity control knob.

Information

If the wiper switch is set in AUTO mode

If there is heavy accumulation of snow or

when the Start/Stop button is in the ON

ice on the windshield, defrost the

position, the wiper will operate once to

windshield for about 10 minutes, or until

perform a self-check of the system. Set

the snow and/or ice is removed before

the wiper to the OFF position when the

using the windshield wipers to ensure

wiper is not in use.

proper operation.

WARNING

If you do not remove the snow and/or ice

before using the wiper and washer, it may

To avoid personal injury from the

damage the wiper and washer system.

windshield wipers, when the vehicle is

running and the windshield wiper switch

is placed in the AUTO mode:

• Do not touch the upper end of the

windshield glass facing the rain sensor.

• Do not wipe the upper end of the

windshield glass with a damp or wet

cloth.

• Do not put pressure on the windshield

glass.

5-93

Convenience Features

Recirculating air when washer fluid

NOTICE

is used

• When washing the vehicle, set the

When washer fluid is used, in order to

wiper switch in the OFF position to stop

reduce any objectionable scent of the

the auto wiper operation. The wiper

washer fluid from entering the cabin,

may operate and be damaged if the

recirculation mode and air conditioning

switch is set in the AUTO mode while

are automatically activated depending on

washing the vehicle.

the outside temperature. If you select

• Do not remove the sensor cover

fresh mode while the function is

located on the upper end of the

operating, the function will resume after a

passenger side windshield glass.

certain amount of time. It may not work in

Damage to system components could

some conditions such as cold weather or

occur and may not be covered by your

vehicle OFF.

vehicle warranty.

For more details, refer to “Climate Control

• Because of using a photo sensor,

Additional Features” section in this

temporary malfunction could occur

chapter.

according to sudden ambient light

change made by stone and dust while

WARNING

driving.

When the outside temperature is below

freezing, ALWAYS warm the windshield

using the defroster to help prevent the

Front Windshield Washers

washer fluid from freezing on the

windshield and obscuring your vision

which could result in an accident and

serious injury or death.

NOTICE

• To prevent possible damage to the

washer pump, do not operate the

washer when the fluid reservoir is

empty.

ONE1051073

• To prevent possible damage to the

In the OFF position, pull the lever gently

wipers or windshield, do not operate

toward you to spray washer fluid on the

the wipers when the windshield is dry.

windshield and to run the wipers 1-3

• To prevent damage to the wiper arms

cycles. The spray and wiper operation will

and other components, do not attempt

continue until you release the lever. If the

to move the wipers manually.

washer does not work, you may need to

• To prevent possible damage to the

add washer fluid to the washer fluid

wipers and washer system, use

reservoir.

anti-freezing washer fluids in the winter

season or cold weather.

5-94

Automatic Climate Control System

Climate control panel

ONE1051127L

Infotainment System (Climate)

ONE1051115N

The actual shape may differ from the illustration.

(1) Driver’s temperature control

(10)Rear windshield defroster

(2) Passenger’s temperature control

(11) Air intake control

(3) Display the air flow direction

(12)Driver only mode

(4) View climate infotainment screen

(13)A/C (air conditioning) ON/OFF

(5) AUTO (automatic control)

(14)Heating ON/OFF

(6) Mode selection button

(15)SYNC

(7) Fan speed up

(16)Ambient temperature display

(8) Fan speed down / OFF

(17)Seat warmer/air ventilation

(9) Front windshield defroster

infotainment screen

Information

Use a clean soft microfiber cloth to gently wipe any finger prints off the touch screen.

5-95

Fan

AUTO

Climate

Information

Level

Speed

Indicator

Information

level

LOW

1~4

1. Press AUTO icon or touch the AUTO

icon in the infotainment screen to

ONE1051074

select the fan speed (level1~3)

• Never place anything near the ambient

2. Adjust the temperature with the

light/solar sensor to ensure better

temperature control icon.

control of the heating and cooling

system.

The fan speed level only can be changed

manually.

• The infotainment system may change

after software updates. For more

The following systems can be

information, refer to the user's manual

respectively adjusted while the AUTO

provided in the infotainment system

climate control is On. When those

and the quick reference guide.

systems are adjusted, AUTO indicator

lights will turn off.

• Fan speed level

• A/C (Air condition)

• Mode selection

• Front windshield defroster (When

defroster is turned off, AUTO indicator

light will illuminate)

For your convenience and to improve the

efficiency of the climate control, use the

AUTO button and set the temperature to

72°F (22°C).

To change the temperature unit from °C

to °F or °F to °C:

Select Setup > General Settings > Unit >

Temperature Unit > °C/°F from the

Settings menu in the infotainment system

screen.

5-97

Hyundai Ioniq 5 (2024 year). Manual in english - page 3
