Hyundai Palisade (2024 year). Manual in english

5-79

if equipped

Power Liftgate

Power Liftgate Operating

Conditions

The power liftgate operates when the

gear is in P (Park) with the engine running.

However, the power liftgate will operate

regardless of the gear position when the

engine is off. Also, the liftgate can be

opened only when vehicle speed is below

1.8 mph (3 km/h).
For safety, before attempting to open or

close the liftgate, make sure the vehicle is

in P (Park).

WARNING

• Never leave children or animals

unattended in your vehicle. Children

may operate the power liftgate. Doing

so can result in injury to themselves or

others and can damage the vehicle.

• Make sure that there are no people or

objects in the path of the power liftgate

or smart liftgate prior to use. Serious

injury, damage to the vehicle or

damage to surrounding objects (for

example, walls, ceilings, vehicles, etc.)

may result if contact with the liftgate

occurs.

B0911KO01

NOTICE

• Do not close or open the liftgate

manually. This may cause damage to

the power liftgate. If it is necessary to

close or open the liftgate manually

when the battery is discharged or

disconnected, do not apply excessive

force.

• Do not operate the power liftgate more

than 10 times continuously when the

engine is not running. Use the power

liftgate with the engine running when

the power liftgate is used repeatedly to

prevent battery discharge.

• Do not leave the power liftgate open for

a long period of time. This may drain the

battery.

• Do not apply excessive force when the

power liftgate is operating. Doing so

could result in vehicle damage.

• Do not grab or hold on to the liftgate

support struts at any time. Damage to

the liftgate support struts could result.

Deformation of the liftgate support

struts may cause vehicle damage and

personal injury may occur.

B0911KO02

• Do not modify or repair any part of the

power liftgate by yourself. This must be

done by an authorized HYUNDAI

dealer.

CarManuals2.com

Convenience Features

5-80

• Do not operate the power liftgate under

the following conditions. The power

liftgate may not operate properly.
- Parking on an uneven road such as a

slope, etc.

- One side of the vehicle is lifted to

inspect the vehicle or change a tire

• Close the liftgate completely and lock

all doors and liftgate using the central

door lock button before using an

automatic car wash.

• Do not spray high pressure water

directly on the power liftgate outside

open/close button. The liftgate may

open unintentionally.

Information

• If the liftgate is not fully closed and

vehicle speed is at or above 1.8 mph (3

km/h), a warning will sound 10 times.

Immediately park the vehicle at a safe

place, close the liftgate, and check that

the liftgate open warning on the

instrument cluster is turned off.

• In cold and wet climates, the outside

power liftgate open/close button may

not work properly due to freezing

conditions. If this occurs, remove the

ice before using the outside power

liftgate open/close button or use the

power liftgate open/close button on

the smart key or the instrument panel.

• Operating the power liftgate more than

5 times continuously could cause

damage to the operating motor. If this

occurs, the power liftgate will not

operate to prevent the motor from

overheating. If any of the power liftgate

buttons are pressed to try to open the

liftgate, the chime will sound 3 times,

but the liftgate will remain closed.

Allow the power liftgate system to cool

for about 1 minute before operating the

system again.

Operating the Power Liftgate

Power liftgate open/close button

(Smart key, Instrument panel)

B0912KO01

B0912KO02

When the liftgate is closed, press the

power liftgate open/close button for 1

second. The power liftgate opens with a

warning sound.
When the power liftgate is opened, press

the power liftgate open/close button for 1

second to close the liftgate.
While the liftgate is opening, press the

button to stop liftgate operation.

CarManuals2.com

5-81

Power liftgate open/close button

(Outside the power liftgate)

B0909KO01

When the liftgate is closed, press the

power liftgate open/close button to open

the liftgate.
If the vehicle is locked, press the power

liftgate open/close button with the smart

key in your possession.
If the liftgate is unlocked, the liftgate will

open or close with a warning sound when

the power liftgate open/close button is

pressed without carrying the smart key.

Power liftgate open/close button

(Inside the power liftgate)

B0913KO01

Press the power liftgate open/close

button. The liftgate opens or closes with a

warning sound.

Automatic reverse

During power liftgate operation if the

power liftgate senses any obstacle, the

liftgate will stop or will fully open. The

automatic reverse feature may not

operate properly, or it may operate

unexpectedly under the following

circumstances:
• The automatic reverse feature may not

detect the resistance if the detected

resistance is below a certain level, or if

the liftgate is almost fully closed near

the latched position.

• The automatic reverse feature may

operate if a strong impact is applied

with no obstructions placed.

WARNING

Never intentionally place any object or

part of your body in the path of the power

liftgate to make sure the automatic

reverse feature operates. Serious injury,

or damage to the vehicle or object may

occur.

Information

The power liftgate may stop operating if

the automatic reverse feature operates

more than two times while attempting to

open or close the liftgate. If this occurs,

carefully open or close the liftgate

manually, and then after 30 seconds try to

operate the power liftgate automatically

again.

CarManuals2.com

Convenience Features

5-82

Setting the Power Liftgate

To use each feature, you must select the

opening speed or opening height from

the settings menu. Deselect the settings

when you do not want to use the feature.

Power liftgate opening speed

To adjust the power liftgate speed, select

‘

Setup

Vehicle

Door/Liftgate

Power

Liftgate Opening Speed

Fast/Slow

’ in

the infotainment system. (Default setting

is ‘Fast’)

Power liftgate opening height

To adjust the power liftgate opening

height, select ‘

Setup

Vehicle

Door/Liftgate

Power Liftgate Opening

Height

Full Open/Level 3/Level

2/Level 1/User Height Setting

’ in the

infotainment system.

User height setting

1. Position the liftgate manually to the

height you prefer.

2. Press the power liftgate open/close

button located inside the liftgate for

more than 3 seconds.
If ‘User Height Setting’ is selected for

the power liftgate opening height, the

power liftgate will automatically open

to the height manually set by you.

Information

• If the power liftgate opening height has

not been manually set, the power

liftgate will fully open when ‘User

Height Setting’ from the infotainment

system is selected.

• If one of the height setting (Full

Open/Level 3/Level 2/Level 1) is

selected from the settings menu in the

infotainment system, and then ‘User

Height Setting’ is selected, the liftgate

will open to the height manually set by

you.

• The power liftgate opening speed and

opening height settings change

according to the linked User Profile. If

the User Profile is changed, power

liftgate opening speed and opening

height settings will change accordingly.

• The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system

and the quick reference guide.

CarManuals2.com

5-83

Resetting the Power Liftgate

In some circumstances resetting the

power liftgate operation may need to be

performed. Some instances where

resetting the power liftgate may be

required include:
• When the 12 V battery is recharged
• When the 12 V battery is reinstalled

after removal or replacement

• When the related fuse is reinstalled

after removal or replacement

B0909EU02

1. With the engine off or running, put the

gear in P (Park).

2. Press the power liftgate open/close

inner button (B) and outer button (A)

simultaneously until a chime sounds.

3. Slowly close the liftgate manually.
4. Press the power liftgate open/close

outer button. The power liftgate will

open with a chime sound.
Wait until the liftgate fully opens to

complete resetting. If the liftgate stops

before it is fully open, resetting cannot

be completed.

Information

If the power liftgate does not operate

properly after the above procedure, have

the system inspected by an authorized

HYUNDAI dealer.

Emergency Liftgate Safety

Release

B0914KO01

To unlock and open the liftgate manually

from inside the luggage compartment,

perform the following procedure:
1. Insert a long, flat object, such as a key

into the opening at the bottom of the

liftgate.

2. Slide the latch in the direction of the

arrow to unlock the liftgate.

3. Push the liftgate to open.

WARNING

• For emergencies, be fully aware of the

location of the emergency liftgate

safety release latch in the vehicle and

how to open the liftgate if you are

accidentally locked in the luggage

compartment.

• No one, including animals, should be

allowed to occupy the luggage

compartment of the vehicle at any

time. The luggage compartment is a

very dangerous location in the event of

an accident.

• Use the release latch for emergencies

only. Use extreme caution, especially

while the vehicle is in motion.

CarManuals2.com

Convenience Features

5-84

if equipped

Smart Liftgate

B0915KO01

On a vehicle equipped with a smart key,

the liftgate can be opened with

hands-free activation using the smart

liftgate system.

WARNING

Make sure that there are no people or

objects in the path of the smart liftgate

prior to use. Serious injury, damage to the

vehicle or damage to surrounding objects

may result if contact with the smart

liftgate occurs.

Using Smart Liftgate

The hands-free smart liftgate system can

be opened automatically when the

following conditions are met:
• The Smart Liftgate option is enabled in

the infotainment system.

• The smart liftgate is activated and

ready 15 seconds after all the doors are

closed and locked.

• The smart liftgate will open when the

smart key is detected in the area behind

the vehicle for 3 seconds.

Information

The smart liftgate will NOT operate when:
• A door is not locked or closed.
• The smart key is detected within 15

seconds from when the doors were

closed and locked.

• The smart key is detected within 15

seconds after the doors are closed and

locked, and within 60 in. (1.5 m) from

the front door handles. (for vehicles

equipped with Welcome Light).

• The smart key is in the vehicle.

1. Settings

To use smart liftgate, it must be

enabled from the Settings menu in the

infotainment system. Select:
•

Setup

Vehicle

Door

Smart

Liftgate

CarManuals2.com

5-85

2. Detect and Alert

The smart liftgate detecting area

extends approximately 20-40 in.

(50-100 cm) behind the vehicle. If you

are positioned in the detecting area and

are carrying the smart key, the hazard

warning lights will blink and the chime

will sound to alert you that the smart

liftgate will open.

Information

• Do not approach the detecting area if

you do not want the liftgate to open.

If you have unintentionally entered

the detecting area and the hazard

warning lights and chime starts to

operate, move away from the area

behind the vehicle with the smart

key. The liftgate will remain closed.

• The infotainment system may

change after software updates. For

more information, refer to the user's

manual provided in the infotainment

system and the quick reference

guide.

3. Automatic opening

After the hazard warning lights blink

and the chime sounds 6 times, the

smart liftgate will open.

Deactivating Smart Liftgate

B0916KO01

(1) Door lock
(2) Door unlock
(3) Liftgate open/close
(4) Panic
If you press any button on the smart key

during the Detect and Alert stage, the

smart liftgate will be deactivated.
Make sure to be aware of how to

deactivate the smart liftgate for

emergency situations.
• If you press the door unlock button (2),

the smart liftgate will be deactivated

temporarily. But, if you do not open any

door for 30 seconds, the smart liftgate

will be activated again.

• If you press the liftgate open button (3)

for more than 1 second, the liftgate

opens.

• The smart liftgate will still be activated

if you press the door lock button (1) or

liftgate open/close button (3) on the

smart key as long as the smart liftgate is

not already in the Detect and Alert

stage.

• In case you have deactivated the smart

liftgate by pressing the smart key

button and opened a door, the smart

liftgate can be activated again by

closing and locking all doors.

CarManuals2.com

Convenience Features

5-86

Detecting Area

B0917KO01

• The smart liftgate detecting area

extends approximately 20-40 in.

(50-100 cm) behind the vehicle. If you

are positioned in the detecting area and

are carrying the smart key, the hazard

warning lights will blink and the chime

will sound for about 3 seconds to alert

you that the liftgate will open.

• The alert stops once the smart key is

moved outside of the detecting area

within the 3 second period.

Information

• Smart liftgate may not operate properly

if any of the following occur:
- The smart key is close to a radio

transmitter such as a radio station or

an airport which can interfere with

normal operation of the transmitter.

- The smart key is near a mobile two

way radio system or a mobile phone.

- Another vehicle’s smart key is being

operated close to your vehicle.

• Smart liftgate detecting area may

change when:
- The vehicle is parked on an incline or

slope.

- One side of the vehicle is raised or

lowered relative to the opposite side.

Fuel Filler Door

Opening the Fuel Filler Door

B0164KO01

1. Turn the engine off.
2. Ensure the driver’s door is unlocked.
3. Push the fuel filler door near the 3

o’clock position.

B0164EU01

4. Pull the fuel filler door (1) outward to

access the fuel tank cap.

5. To remove the fuel tank cap (2), turn it

counterclockwise. You may hear a

hissing noise as the pressure inside the

tank equalizes.

6. Place the cap on the fuel filler door.

CarManuals2.com

5-87

Information

If the fuel filler door does not open

because ice has formed around it, tap

lightly or push on the door to break the ice

and release the door. Do not pry on the

door. If necessary, spray around the door

with an approved deicer fluid (do not use

radiator antifreeze) or move the vehicle to

a warm place and allow the ice to melt.

Closing the Fuel Filler Door

1. To install the fuel tank cap, turn it

clockwise until it “clicks” one time.

2. Close the fuel filler door until it is

latched securely.

Information

The fuel filler door will not close if the

driver’s door is locked. If you lock the

driver’s door while fueling, unlock it

before closing the fuel filler door.

WARNING

Gasoline fuel is highly flammable and

explosive. Failure to follow these

guidelines may result in SERIOUS INJURY

or DEATH:
• Read and follow all warnings posted at

the gas station.

• Before refueling, note the location of

the Emergency Gasoline Fuel Shut-Off,

if available, at the gas station.

• Before touching the fuel nozzle, you

should eliminate the potential build-up

of static electricity by touching a metal

part of the vehicle, a safe distance away

from the fuel filler neck, nozzle, or other

gas source, with your bare hand.

• Do not use mobile phones while

refueling. Electric current and/or

electronic interference from cellular

phones can potentially ignite fuel

vapors and cause a fire.

• Do not get back into a vehicle once you

have begun refueling. You can generate

a buildup of static electricity by

touching, rubbing or sliding against any

item or fabric capable of producing

static electricity. Static electricity

discharge can ignite fuel vapors

causing a fire. If you must re-enter the

vehicle, you should once again

eliminate potentially dangerous static

electricity discharge by touching a

metal part of the vehicle, away from the

fuel filler neck, nozzle or other gasoline

source, with your bare hand.

• When using an approved portable fuel

container, be sure to place the

container on the ground prior to

refueling. Static electricity discharge

from the container can ignite fuel

vapors causing a fire.
Once refueling has begun, contact

between your bare hand and the

vehicle should be maintained until the

filling is complete.

• Use only approved portable plastic fuel

containers designed to carry and store

gasoline.

• When refueling, always shift the gear to

the P (Park) position, set the parking

brake, and place the ignition switch to

the LOCK/OFF position. Sparks

produced by electrical components

related to the engine can ignite fuel

vapors causing a fire.

• Do not use matches or a lighter and do

not smoke or leave a lit cigarette in your

vehicle while at a gas station, especially

during refueling.

• Do not over-fill or top-off your vehicle

tank, which can cause gasoline spillage.

• If a fire breaks out during refueling,

leave the vicinity of the vehicle, and

immediately contact the manager of

the gas station and then contact the

local fire department. Follow any safety

instructions they provide.

CarManuals2.com

Convenience Features

5-88

• If pressurized fuel sprays out, it can

cover your clothes or skin and thus

subject you to the risk of fire and burns.

Always remove the fuel cap carefully

and slowly. If the cap is venting fuel or if

you hear a hissing sound, wait until the

condition stops before completely

removing the cap.

• Always check that the fuel cap is

installed securely to prevent fuel

spillage in the event of an accident.

Information

Make sure to refuel your vehicle

according to the “Fuel Requirements”

section in suggested in chapter 1.

NOTICE

• Do not spill fuel on the exterior surfaces

of the vehicle. Any type of fuel spilled

on painted surfaces may damage the

paint.

• If the fuel filler cap requires

replacement, use only a genuine

HYUNDAI cap or the equivalent

specified for your vehicle. An incorrect

fuel filler cap can result in a serious

malfunction of the fuel system or

emission control system.

if equipped

Head-Up Display (HUD)

B0167EU03

The Head-Up Display is an optional

feature that allows the driver to view

information projected onto a transparent

screen while still keeping your eyes on the

road ahead while driving.

Head-Up Display Settings

B0167EE01

• Head-up display can be enabled from in

the infotainment system. Select:
-

Setup

Vehicle

Head-Up Display

Enable Head-Up Display

• After turning on the head-up display,

you can change the settings of ‘Display

Control’ and ‘Content Selection’ of the

Head-Up Display.

CarManuals2.com

5-89

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

Head-Up Display Information

B0167EU04

(1) Turn by Turn (TBT) navigation
(2) Traffic sign
(3) Speedometer
(4) SCC set speed
(5) SCC vehicle distance
(6) Lane Following Assist
(7) Lane Safety
(8) Blind-Spot Safety
(9) Highway Auto Speed Change
(10)Highway Driving Assist
(11) Surrounding vehicles

Precautions While Using the

Head-Up Display

• It may sometimes be difficult to read

information on the Head-Up Display in

the following situations.
- The driver is improperly positioned in

the driver’s seat

- The driver wears polarizing-filter

sunglasses

- An object is located above the

Head-Up Display cover

- The vehicle is driven on a wet road
- Any improper lighting accessory is

installed inside the vehicle, or there is

incoming light from outside of the

vehicle

- The driver wears glasses
- The driver wears contact lenses
When it is difficult to read the Head-Up

Display information, adjust the image

height or brightness level from the

Settings menu in the infotainment

system screen.

• For your safety, make sure to stop the

vehicle before adjusting the settings.

• Do not tint the front windshield glass or

add other types of metallic coating.

Otherwise, the Head-Up Display image

may be invisible.

• Do not place any accessories on the

crash pad or attach any objects on the

windshield glass.

• When replacing the front windshield

glass, replace it with a windshield glass

designed for Head-Up Display

operation. Otherwise, duplicated

images may be displayed on the

windshield glass.

WARNING

The warning information of Blind-Spot

Safety on the Head-Up Display are

supplemental. Do not solely depend on

them to change lanes. Always take a look

around before changing lanes.

CarManuals2.com

Convenience Features

5-90

Information

Head-up Display includes GPL, LGPL,

MPL and other open source license

softwares. All license notices including

related source code are provided at

http://www.mobis.co.kr/opensource/list.

do.
If the driver requests on-board software

open source code via

MOBIS_OSSrequest@mobis.co.kr within

3 years after buying this product, a

CD-ROM or other storage device will be

sent with the minimum cost covering

storage device cost and delivery cost.

Exterior Lights

Lighting Control

To operate the lights, turn the knob at the

end of the control lever to one of the

following positions:

B0177KO01

(1) OFF
(2) AUTO headlight
(3) Position lamp
(4) Headlight

Daytime Running Light (DRL)

The Daytime Running Lights (DRL) can

make it easier for others to see the front

of your vehicle during the day, especially

after dawn and before sunset. The

Daytime Running Lights (DRL) should be

illuminated whenever you are driving

during daylight hours. The DRL system

will be ON when the headlight switch is in

the OFF or the AUTO position (when

daylight is detected) and the Electronic

Parking Brake (EPB) is released.
The DRL system will turn off when:
• The headlights are ON.
• The parking brake is applied.
• The vehicle is turned off.
• The parking brake is engaged.

CarManuals2.com

5-91

AUTO headlight

B0177KO02

The position lamp and headlight will be

turned ON or OFF automatically

depending on the amount of daylight as

measured by the ambient light sensor (1)

at the upper end of the windshield glass.
Even with the AUTO headlight feature in

operation, it is recommended to manually

turn ON the headlights when driving at

night or in a fog, driving in the rain, or

when you enter dark areas, such as

tunnels and parking facilities.

NOTICE

• Do not cover or spill anything on the

sensor (1) located at the upper end of

the windshield glass.

• Do not clean the sensor using a window

cleaner, the cleanser may leave a light

film which could interfere with sensor

operation.

• If your vehicle has window tint or other

types of metallic coating on the front

windshield, the AUTO headlight system

may not work properly.

Position lamp ( )

B0177KO03

The position lamp, license plate lamp and

instrument panel lamp are turned ON.

Headlight (

)

B0177KO04

The headlight, position lamp, license

plate lamp and instrument panel lamp are

turned ON.

Information

The ignition switch must be in the ON

position to turn on the headlight.

CarManuals2.com

Convenience Features

5-92

High Beam Operation

B0178EU02

To turn on the high beam headlight, push

the lever away from you. The lever will

return to its original paosition.
The high beam indicator will light when

the headlight high beams are switched

on.
To turn off the high beam headlight, pull

the lever towards you. The low beams will

turn on.

WARNING

Do not use high beam when there are

other vehicles approaching you. Using

high beam could obstruct the other

driver’s vision.

B0178EU01

To flash the high beam headlight, pull the

lever towards you, then release the lever.

The high beams will remain ON as long as

you hold the lever towards you.

Turn Signals and Lane Change

Signals

B0181KO01

To signal a turn, push down on the lever

for a left turn or up for a right turn in

position (A).
If an indicator stays on and does not flash

or if it flashes abnormally, one of the turn

signal bulbs may be burned out and will

require replacement.

One touch turn signal

To use One Touch Turn Signal push the

turn signal lever up or down to position

(B) and then release it.
The lane change signals will blink 3, 5 or 7

times.
You can enable the One Touch Turn

Signal function or choose the number of

blinking from the Settings menu in the

infotainment system. Select:
•

Setup

Vehicle

Lights

One Touch

Turn Signal

3 flashes/5 flashes/7

flashes Off

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

CarManuals2.com

5-93

Battery Saver Function

The purpose of this feature is to help

prevent the battery from being

discharged. The system automatically

turns off the position lamp when the

driver turns the vehicle off and opens the

driver-side door.
With this feature, the position lamps will

turn off automatically if the driver parks

on the side of road at night.
However, the position lamps stay ON

even when the driver-side door is opened

if the headlight switch is turned to the

position lamp OFF or AUTO (if equipped)

position after the engine is turned off.
If necessary, to keep the lamps on turn

the position lamps OFF and ON again

using the headlight switch on the steering

column after the engine is turned off.

Headlight Delay Function

If the ignition switch is in the ACC position

or the LOCK/OFF position with the

headlights ON, the headlights (and/or

position lamps) remain on for about 5

minutes. However, if the driver’s door is

opened and closed, the headlights are

turned off after 15 seconds. Also, with the

vehicle off if the driver’s door is opened

and closed, the headlights (and/or

position lamps) are turned off after 15

seconds.
The headlights (and/or position lamps)

can be turned off by pressing the lock

button on the smart key twice or turning

the headlight switch to the OFF or AUTO

position.
You can enable the headlight delay

function from the Settings menu in the

infotainment system. Select:
•

Setup

Vehicle

Lights

Headlight

Delay

NOTICE

If the driver exits the vehicle through

another door besides the driver door, the

battery saver function does not operate

and the headlight delay function does not

turn OFF automatically.
This may cause the battery to discharge.

To avoid battery discharge, turn OFF the

headlights manually from the headlight

switch before exiting the vehicle.

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

CarManuals2.com

Convenience Features

5-94

High Beam Assist (HBA)

B0179KO01

High Beam Assist automatically controls

the headlights between high beam and

low beam depending on the detected

ambient light, such as an oncoming

vehicle or leading vehicle.

Detecting sensor

B0179KO02

(1) : front view camera
The front view camera is used as a

detecting sensor to detect ambient light

and brightness while driving.
Refer to the picture above for the detailed

location of the detecting sensor.

NOTICE

• Always keep the front view camera in

good condition to maintain optimal

performance of High Beam Assist.

• For more details on the precautions of

the front view camera, refer to

“Forward Collision-Avoidance Assist

(FCA)” section in chapter 7.

High Beam Assist Settings

B0179EU03

With the ignition switch or the Engine

Start/Stop button in the ON position,

select ‘

Lights

High Beam Assist

’ from

the Settings menu to turn on High Beam

Assist and deselect to turn off the

function.

WARNING

For your safety, change the Settings after

parking the vehicle at a safe location.

CarManuals2.com

5-95

High Beam Assist Operation

Display and control

• After selecting ‘High Beam Assist’ in the

Settings menu, High Beam Assist will

operate by following the procedure

below.
- Place the headlight switch in the

AUTO position and push the

headlight lever towards the

instrument cluster. The High Beam
Assist ( ) indicator light will

illuminate on the cluster and High

Beam Assist will be enabled.

- When High Beam Assist is enabled,

high beam will turn on when vehicle

speed is above 25 mph (40 km/h).

When vehicle speed is below 15 mph

(25 km/h), high beam will turn off.

- The High Beam (

) indicator light

will illuminate on the cluster when

high beam is on.

• When High Beam Assist is operating, if

the headlight lever or switch is used,

High Beam Assist operates as follow:
- If the headlight lever is pulled

towards you when the high beam is

off, the high beam will turn on

without High Beam Assist canceled.

When you let go of the headlight

lever, the lever will move to the

middle and the high beam will turn

off.

- If the headlight lever is pulled

towards you when the high beam is

on by High Beam Assist, low beam

will be on and High Beam Assist will

turn off.

- If the headlight switch is placed from

AUTO to another position

(headlight/position/off), High Beam

Assist will turn off and the

corresponding lamp will turn on.

• When High Beam Assist is operating,

high beam switches to low beam if any

of the following conditions occur:
- When the headlight of an oncoming

vehicle is detected.

- When the tail lamp of a vehicle in

front is detected.

- When the headlight or tail lamp of a

motorcycle or a bicycle is detected.

- When the surrounding ambient light

is bright enough that high beams are

not required.

- When streetlights or other lights are

detected.

Information

The images and colors in the cluster may

differ depending on the cluster type or

theme selected from the cluster.

CarManuals2.com

Convenience Features

5-96

High Beam Assist Malfunction

and Limitations

High Beam Assist malfunction

B0179EU04

When High Beam Assist is not working

properly, the ‘Check High Beam Assist

(HBA) system’ warning message will
appear and warning light will

illuminate on the cluster. Have the

function be inspected by an authorized

HYUNDAI dealer.

Limitations of High Beam Assist

• Light from an oncoming or front vehicle

is not detected because of lamp

damage, or because it is hidden from

sight, etc.

• Headlight of an oncoming or front

vehicle is covered with dust, snow or

water.

• An oncoming or front vehicle’s

headlights are off, but the fog lamps are

on, etc.

• There is a lamp that has a similar shape

as a vehicle’s lamp.

• Headlights have been damaged or not

repaired properly.

• Headlights are not aimed properly.
• Driving on a narrow-curved road,

curved road, rough road, uphill or

downhill.

• Vehicle in front is partially visible on a

crossroad or curved road.

• There is a traffic light, reflecting sign,

flashing sign or mirror ahead.

• There is a temporary reflector or flash

ahead (construction area).

• The road conditions are bad such as

being wet, iced or covered with snow.

• A vehicle suddenly appears from a

curve.

• The vehicle is tilted from a flat tire or is

being towed.

• Light from an oncoming or front vehicle

is not detected due to obstacles in the

air such as exhaust fume, smoke, fog,

snow, or water spay or blizzard on the

road, or fogging in the lamp, etc.

Information

For more details on the limitations of the

Front View Camera, refer to “Forward

Collision-Avoidance Assist (FCA)” section

in chapter 7.

WARNING

• At times, High Beam Assist may not

work properly. High Beam Assist is for

your convenience only. It is the

responsibility of the driver for safe

driving practices and always check the

road conditions for your safety.

• When High Beam Assist does not

operate normally, change the headlight

position manually between high beam

and low beam.

• High Beam Assist may not operate for

15 seconds after the vehicle is started,

or the front view camera is initialized.

CarManuals2.com

5-97

Interior Lights

WARNING

Do not use the interior lights when driving

in the dark. The interior lights may

obscure your view and cause an accident.

NOTICE

Do not use the interior lights for extended

periods when the vehicle is turned off or

the battery will discharge.

Interior Lamp AUTO Off

The interior lamps will automatically go

off approximately 20 minutes after the

vehicle is turned off and the doors are

closed. If a door is opened, the lamp will

go off 25 minutes after the vehicle is

turned off. If the doors are locked by the

smart key and the vehicle enters the

armed stage of the theft alarm system,

the lamps will go off five seconds later.

Front Lamps

B0903EU03

Front map lamp (

Touch either icons to turn the map lamp

on or off. This light produces a spot beam

for convenient use as a map lamp at night

or as a personal lamp for the driver and

the front passenger.

Door lamp ( ):

The front or rear room lamps come on

when the front or rear doors are opened.

When doors are unlocked by the smart

key, the front and rear lamps come on for

approximately 30 seconds as long as any

door is not opened. The front and rear

room lamps go out gradually after

approximately 30 seconds when the door

is closed. However, if the ignition switch

or Engine Start/Stop button is in the ON

position or all doors are locked, the front

and rear lamps will turn off. If a door is

opened with the ignition switch in the

ACC position or the LOCK/OFF position,

the front and rear lamps will stay on for

about 5 minutes.

Room lamp ( )

Press the button to turn ON the room

lamp for the front and rear seats.

CarManuals2.com

Convenience Features

5-98

Rear Lamps

B0192KO01

•

Touch the icon to turn either lamp on or

off.

Vanity Mirror Lamp

B0194KO04

Opening the lid of the vanity mirror will

automatically turn on the mirror lamp.

Glove Box Lamp

B0195KO01

The glove box lamp turns on when the

glove box is opened.
If the glove box is not closed, the lamp will

turn off after 20 minutes.

NOTICE

To prevent unnecessary charging system

drain, close the glove box securely after

using the glove box.

if equipped

Door Courtesy Lamp

B0918KO01

The lamp turns on when a door is open

and turns off when the door is closed.

CarManuals2.com

5-99

Luggage Compartment Lamp

B0197KO01

• ON (

The luggage compartment lamp stays

on at all times.

• DOOR (

The luggage compartment lamp comes

on when the liftgate is opened.

• OFF (

The luggage compartment lamp is off.

Puddle Lamp

Welcome light

B0198KO01

When all doors (and liftgate) are closed

and locked, the puddle lamp will turn on

for 15 seconds if the door is unlocked by

the smart key or when you put your hand

in the outside door handle with the smart

key in possession.

Escort light

When the ignition switch is in the

LOCK/OFF position and the driver’s door

is opened, the puddle lamp will turn on for

30 seconds. If the driver’s door is closed

within the 30 second period, the puddle

lamp will turn off after 15 seconds. If the

driver’s door is closed and locked, the

puddle lamp will turn off immediately.
The Puddle Lamp Escort Light will turn on

only the first time the driver’s door is

opened after the engine is turned off.

Interior lights

The interior lights turns on or off in the

following conditions:
• The interior lights turn on for a while

when the door is unlocked and opened

after all doors were closed and locked.

• The interior lights always turns on when

the vehicle is turned on.

• The interior lights turn on for a while

when the vehicle is turned off. If the

door is opened and closed or locked,

the interior lights turn off immediately.

You can enable the interior lights by

selecting '

Setup

Vehicle

Lights

Interior Light Always On

' in the

infotainment system.

Information

The infotainment system may change

after software updates. For more

information, refer to the manual provided

in the infotainment system and the quick

reference guide.

CarManuals2.com

Convenience Features

5-100

Wipers And Washers

B0200KO01

Front Windshield Wipers

Operates as follows when the ignition

switch or Engine Start/Stop button is in

the ON position.
MIST: For a single wiping cycle, push the

lever upward and release. The wipers will

operate continuously if the lever is held in

this position.
OFF: Wiper is not in operation.
AUTO (if equipped): The rain sensor

located on the upper end of the

windshield glass senses the amount of

rainfall and controls the wiping cycle for

the proper interval. The more it rains, the

faster the wiper operates. When the rain

stops, the wiper stops. To vary the speed

setting, turn the speed control knob.
LO: The wiper runs at a lower speed.
HI: The wiper runs at a higher speed.

Information

If there is heavy accumulation of snow or

ice on the windshield, defrost the

windshield for about 10 minutes, or until

the snow and/or ice is removed before

using the windshield wipers to ensure

proper operation.
If you do not remove the snow and/or ice

before using the wiper and washer, it may

damage the wiper and washer system.

if equipped

AUTO wiper control

B0200KO02

The rain sensor located on the upper end

of the windshield glass senses the

amount of rainfall and controls the wiping

cycle for the proper interval.
The wiper operation time will be

automatically controlled depends on

rainfall.
When the rain stops, the wiper stops.
To vary the sensitivity setting, turn the

sensitivity control knob.
If the wiper switch is set in AUTO mode

when the ignition switch is in the ON

position, the wiper will operate once to

perform a self-check of the system. Set

the wiper to the OFF position when the

wiper is not in use.

WARNING

To avoid personal injury from the

windshield wipers, when the engine is

running and the windshield wiper switch

is placed in the AUTO mode:
• Do not touch the upper end of the

windshield glass facing the rain sensor.

• Do not wipe the upper end of the

windshield glass with a damp or wet

cloth.

• Do not put pressure on the windshield

glass.

CarManuals2.com

5-101

NOTICE

• When washing the vehicle, set the

wiper switch in the OFF position to stop

the auto wiper operation. The wiper

may operate and be damaged if the

switch is set in the AUTO mode while

washing the vehicle.

• Do not remove the sensor cover

located on the upper end of the

passenger side windshield glass.

Damage to system components could

occur and may not be covered by your

vehicle warranty.

• Because of using a photo sensor,

temporary malfunction could occur

according to sudden ambient light

change made by stone and dust while

driving.

Front Windshield Washers

B0201KO01

In the OFF position, pull the lever gently

toward you to spray washer fluid on the

windshield and to run the wipers 1-3

cycles. The spray and wiper operation will

continue until you release the lever. If the

washer does not work, you may need to

add washer fluid to the washer fluid

reservoir.

Recirculating air when washer

fluidis used

When washer fluid is used, in order to

reduce any objectionable scent of the

washer fluid from entering the

cabin,recirculation mode and air

conditioningare automatically activated

dependingon the outside temperature.
• When the air intake control button

ispressed while fresh mode is

selected,air intake control will switch

torecirculation mode.

• When windshield lever is used

whilerecirculation mode is selected,

airintake control will switch to

freshmode

• The function may not work in

someconditions such as cold weather

orengine off.

For more details, refer to “Climate Control

Additional Features” section inthis

chapter.

CarManuals2.com

Convenience Features

5-102

WARNING

When the outside temperature is below

freezing, ALWAYS warm the windshield

using the defroster to help prevent the

washer fluid from freezing on the

windshield and obscuring your vision

which could result in an accident and

serious injury or death.

NOTICE

• To prevent possible damage to the

washer pump, do not operate the

washer when the fluid reservoir is

empty.

• To prevent possible damage to the

wipers or windshield, do not operate

the wipers when the windshield is dry.

• To prevent damage to the wiper arms

and other components, do not attempt

to move the wipers manually.

• To prevent possible damage to the

wipers and washer system, use

anti-freezing washer fluids in the winter

season or cold weather.

Rear Window Wiper and

Washer

B0200KO03

The rear window wiper and washer switch

is located at the end of the wiper and

washer switch lever. Turn the switch to

the desired position to operate the rear

wiper and washer.

HI: High wiper speed
LO: Low wiper speed
OFF: Off

B0201KO02

Push the lever away from you to spray

rear washer fluid and to run the rear

wipers 1-3 cycles. The spray and wiper

operation will continue until you release

the lever.

Auto rear wiper

The rear wiper will operate while the

vehicle is in reverse with the front wiper

ON by selecting the function from the

Settings menu in the infotainment system

screen. Select:
•

Setup

Vehicle

Convenience

Auto

Rear Wiper (in R)

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

CarManuals2.com

Convenience Features

5-104

Heating and Air Conditioning

1. Start the engine.
2. Set the mode to the desired position.

To improve the effectiveness of heating

and cooling, select the mode according

to the following:
• Heating:

• Cooling:

3. Set the temperature control to the

desired position.

4. Set the air intake control to Fresh mode

or Recirculation mode position.

5. Set the fan speed control to the desired

speed.

6. If air conditioning is desired, turn the air

conditioning system on.

When starting the vehicle in cold weather

a more efficient way to heat the

passenger compartment is to do the

following.
• Turn off or lower the blower, right after

starting the engine.

• Engine temperature is still low and the

air flow from the heater is still cold.

• After a few minutes of engine warm up,

turn on or set the fan to a higher level

and adjust the temperature setting to

hot.

Mode selection

A0204KO02

The mode selection button controls the direction of the air flow through the ventilation

system. Air can be directed to the floor, dashboard outlets, or windshield. Five symbols

are used to represent Face, Bi-Level, Floor, Floor-Defrost and Defrost air position.

CarManuals2.com

5-105

B9024EU01

Face-Level (B, D)

W7-65

Air flow is directed toward the upper body

and face. Additionally, each outlet can be

controlled to direct the air discharged

from the outlet.

Bi-Level (B, D)

W7-66

Air flow is directed towards the face and

the floor.

Floor-Level (A, C, D, E)

W7-67_1

Most of the air flow is directed to the

floor, with a small amount of the air being

directed to the windshield and side

window defrosters.

Floor & Defrost (A, C, D, E)

W7-68

Most of the air flow is directed to the floor

and the windshield with a small amount

directed to the side window defrosters.

B9024EU08

Defrost-Level (A, D)

C9024EU01

Most of the air flow is directed to the

windshield with a small amount of air

directed to the side window defrosters.

B9024EU02

MAX A/C-Level (B, D)

The MAX A/C mode is used to cool the

inside of the vehicle faster. Air flow is

directed toward the upper body and face.
In this mode, the A/C button and the

Recirculation mode button will be

automatically selected. Turn the fan

speed mode to adjust.
After the interior cabin has cooled

sufficiently, move the temperature knob

away from the MAX A/C setting and

adjust the knob to the desired position.
If you wish to continue using A/C ON,

make sure the A/C button indicator is

illuminated.

CarManuals2.com

Convenience Features

5-106

Instrument panel vents

B0204KO04

The instrument panel vent air flow can be

directed up/down or left/right using the

vent adjustment lever.
The outlet vents can be opened or closed

separately using the vent control lever. If

you move the vent control lever away

from the passenger, the outlet vents can

be closed.

Temperature control

B9024EU03

The temperature will increase by turning

the knob to the right.
The temperature will decrease by turning

the knob tao the left.

Air intake control

B9024EU09

The air intake control button is used to

select either Fresh mode (outside air) or

Recirculation mode (cabin air).

CarManuals2.com

5-107

Recirculation mode

C0204KO08

When Recirculation mode is selected, air

from the passenger compartment will be

recirculated through the system and

heated or cooled according to the

function selected.

Fresh mode

C0204KO09

When Fresh mode is selected, air enters

the vehicle from outside and is heated or

cooled according to the function

selected.

Information

Operating the system primarily in Fresh

mode is recommended. Use

Recirculation mode temporarily only

when needed.
Prolonged operation of the heater in

Recirculation mode and without the A/C

ON can cause fogging of the windshield.
In addition, prolonged use of the A/C ON

in Recirculation mode may result in

excessively dry, dehumidified air in the

cabin and may promote formation of

musty vent odor due to stagnant air.

WARNING

• Continued use of the climate control

system operation in Recirculation

mode for a prolonged period of time

may cause drowsiness to the

occupants in the cabin. This may lead to

loss of vehicle control which may lead

to an accident.

• Continued use of the climate control

system operation in Recirculation

mode with the A/C OFF may allow

humidity to increase inside the cabin.

This may cause condensation to

accumulate on the windshield and

obscure visibility.

• Do not sleep in your vehicle or remain

parked in your vehicle with the

windows up and either the heater or the

air conditioning ON for prolonged

periods of time. Doing so may increase

the levels of carbon dioxide in the cabin

which may lead to serious injury or

death.

CarManuals2.com

Convenience Features

5-108

Fan speed control

B9024EU04

Turn the knob to the right to increase the

fan speed and airflow. Turn the knob to

the left to decrease fan speed and airflow.
Setting the fan speed control knob to the

“0” position turns off the fan.

NOTICE

Operating the fan speed when the

ignition switch is in the ON position could

cause the battery to discharge. Operate

the fan speed when the engine is running.

Air conditioning

B9024EU05

Press the A/C button to turn the system

on (indicator light will illuminate) and off.

Rear climate control button

B9024EU06

If you press the rear climate control

button, rear passengers can control the

rear climate system.

B9024EU07

Press the rear fan speed control button to

increase or decrease the fan speed and air

flow.

CarManuals2.com

Convenience Features

5-110

(1) OFF button
(2) Mode selection button
(3) Temperature control button
(4) Fan speed control button
If you press the rear climate control

button of the front climate control

system, rear passengers can control the

rear climate system by using the rear

climate control system.

Fan speed control

B9024EU06

1. Press the rear climate control button of

the front climate control system.

B9025EU01

2. The fan speed can be set to the desired

speed by pushing the fan speed control

button. The higher the fan speed is, the

more air is delivered.
Pressing the OFF button turns off the

fan.

Temperature control

1. Press the rear climate control button of

the front climate control system.

B9025EU02

2. The temperature of delivered air can be

set to the desired temperature by

pushing the temperature control

button. Pressing the off button turns off

the fan.

CarManuals2.com

Hyundai Palisade (2024 year). Manual in english - page 8
