Hyundai Equus (2016 year). Instruction - part 9

Convenient features of your vehicle

B520C05NF

To adjust the Zone setting:

4. Within about 5 seconds the com-

pass will start displaying a com-

1. Determine the desired Zone

pass heading again.

Number based upon your current

location on the Zone Map.

2. Press and hold the button for 6

seconds to display the current

Zone Number.

3. Re-press and hold the button

again to increase the Zone

Number (Note: they will repeat

…13, 14, 15, 1, 2, …). Release the

button when the desired Zone

Number appears on the display to

set up the new Zone.

3-46

Convenient features of your vehicle

03

There are some conditions that can

cause changes to the vehicle mag-

WARNING

nets, such as installing a ski rack or

Before

programming

a CB antenna. Body repair work on

HomeLink® to a garage door

the vehicle can also cause changes

opener or gate operator, make

to the vehicle's magnetic field. In

sure that people and objects are

these situations, the compass will

out of the way from the device

need to be re-calibrated to quickly

to prevent potential harm or

correct these changes. To re-cali-

damage. Do not use HomeLink®

brate the compass:

with any garage door opener

1. Press and hold the

button for

that lacks the safety stop and

more than 9 seconds. When the

reverse features required by

compass memory is deleted, a let-

U.S. federal safety standards

ter "C" will appear on the display.

(this includes any garage door

2. To calibrate the compass, drive the

opener model manufactured

vehicle in a circle twice at less

before April 1, 1982). A garage

than 5 mph (8 km/h).

door that cannot detect an

object - signaling the door to

stop and reverse

- does not

Integrated HomeLink® Wireless

meet current U.S. federal safety

Control System

standards. Using a garage door

The HomeLink® Wireless Control

opener without these features

System provides a convenient way to

increases the risk of serious

replace up to three hand-held

injury or death.

radiofrequency

(RF) transmitters

with a single built-in device. This

innovative feature will learn the radio

Retain the original transmitter of the

frequency codes of most current

RF device you programmed for use

transmitters to operate devices such

in other vehicles as well as for future

as gate operators, garage door

HomeLink® programming. It is also

openers, entry door locks, security

suggested that upon the sale of the

systems, and even home lighting.

vehicle, the programmed HomeLink®

Both standard and rolling code-

buttons be erased for security pur-

equipped transmitters can be pro-

poses.

grammed by following the outlined

procedures. Additional HomeLink®

information can be found at:

www.homelink.com or by calling 1-

800-355-3515.

3-47

Convenient features of your vehicle

Programming HomeLink®

Programming

i

Information

Flashing

• When programming a garage door

opener, it is advised to park the

vehicle outside of the garage.

• It is recommended to replace the

hand-held transmitter battery of the

device being programmed to

HomeLink® for quicker training

and accurate transmission of the

radio-frequency signal.

• Some vehicles may require the igni-

OVI045606N

tion switch to be turned to the sec-

ond (or "accessories") position for

To train most devices, follow these

programming and/or operation of

instructions:

HomeLink.

1. For first-time programming, press

• In the event that there are still pro-

and hold the two outside buttons

gramming difficulties or questions

(

,

), HomeLink® Channel

1

after following the programming

and Channel 3, until the indicator

steps

listed

below,

contact

light begins to flash (after 10 sec-

HomeLink®.homelwww.homelink.com

onds). Release both buttons. Do

or 1-800-355-3515.

not hold the buttons for longer

than 20 seconds.

Flashing

OVI045607N

2. Point the end of your hand-held

transmitter

1-3 inches

(2-8 cm)

away from the HomeLink® button

you wish to program while keeping

the indicator light in view.

3-48

Convenient features of your vehicle

03

This device complies with Part 15

Electric chromic mirror (ECM)

of the FCC Rules.

with HomeLink® system and

Operation is subject to the following

compass (Type B)

two conditions:

Your vehicle may be equipped with a

1. This device may not cause harmful

Gentex Automatic-Dimming Mirror

interference, and

with a Z-Nav™ Electronic Compass

Display

and an Integrated

2. This device must accept any inter-

HomeLink® Wireless

Control

ference received, including inter-

System. During the night-time driv-

ference that may cause undesired

ing, this feature automatically detects

operation.

and reduces rearview mirror glare

while the compass indicates the

CAUTION

direction the vehicle heads for. The

HomeLink® Universal Transceiver

The transceiver has been tested

allows you to activate your garage

and complies with FCC and

door(s), electric gate, home lighting,

Industry Canada rules. Changes

etc.

or modifications not expressly

approved by the party responsi-

ble for compliance could void

the user's authority to operate

the device.

NVS® is a registered trademark and

Z-Nav™ is a trademark of the Gentex

Corporation, Zeeland, Michigan.

HomeLink® is a registered trademark

owned by Johnson Controls,

Incorporated, Milwaukee, Wisconsin.

OVI045625N

(1) Channel 1 button

(2) Channel 2 button

(3) Status indicator LED

(4) Channel 3 button

(5) Rear light sensor

(6) Dimming ON/OFF button

(7) Compass control button

(8) Compass display

3-51

Convenient features of your vehicle

Automatic-Dimming Night Vision

i

Information

Safety™ (NVS®) Mirror

The mirror resets to be ON whenever

The NVS® Mirror in your vehicle is

the vehicle is started.

the most advanced mirror to reduce

annoying glare in the rearview mirror

in any driving situation. For more

Z-Nav™ Compass Display

information regarding NVS® mirrors

The NVS™ Mirror in your vehicle is

and other applications, please visit

also equipped with a Z-Nav™

the Gentex website:

Compass that shows the vehicle

www.gentex.com

Compass heading on the Display

Window in the 8 cardinals headings

NOTICE

(N, NE, E, SE, etc.).

The NVS® Mirror automatically

dims glare in driving conditions

Compass function

based upon light levels detected

The Compass can be turned

in front of the vehicle and from the

ON/OFF and remember the last

rear of the vehicle. These light

heading information when the igni-

sensors are visible through open-

tion is cycled. To turn ON/OFF the

ings in the front and rear of the

display function:

mirror case. Any object that

1. Press and release the

button

obstructs either light sensor will

within 1 second to turn OFF the

degrade the automatic dimming

display function.

control function.

2. Press and release the

button

again within 1 second to turn ON

Automatic-dimming function

the display back.

Your mirror automatically dims the

Additional options can be set by

glare upon detecting it from the vehi-

pressing and holding buttons in

cles traveling behind you. The auto-

sequences, as detailed below.

matic-dimming function can be con-

trolled by the Dimming ON/OFF

There is a difference between the

Button:

magnetic north and the actual north.

The compass in the mirror can offset

1. Pressing and hold the button for

this difference by knowing the

3 seconds turns OFF the automat-

Magnetic Zone in which it is operat-

ic-dimming function, which is indi-

ing. This is set either by the dealer or

cated by the turned-OFF green

by the user. The operating Zone

light of the Status Indicator LED.

Numbers for North America are

2. Pressing and hold the button for

shown in the figure on the next page.

3 seconds again turns ON the

automatic-dimming function which

is indicated by the turned-ON

green light of the Status Indicator

LED.

3-52

Convenient features of your vehicle

03

B520C05NF

To adjust the Zone setting:

3. Re-press and hold the

button

again to increase the Zone

1. Determine the desired Zone

Number (Note: they will repeat

Number based upon your current

…13, 14, 15, 1, 2, …). Release the

location on the Zone Map.

button when the desired Zone

2. Press and hold the button for 6

Number appears on the display to

seconds to display the current

set up the new Zone.

Zone Number.

4. Within about 5 seconds the com-

pass will start displaying a com-

pass heading again.

3-53

Convenient features of your vehicle

This device complies with Part 15

Outside rearview mirror

of the FCC Rules.

Operation is subject to the following

two conditions:

1. This device may not cause harmful

interference, and

2. This device must accept any inter-

ference received, including inter-

ference that may cause undesired

operation.

CAUTION

OVI045039N

The transceiver has been tested

Your vehicle is equipped with both left-

and complies with FCC and

hand and right-hand outside rearview

Industry Canada rules. Changes

mirrors.

or modifications not expressly

approved by the party responsi-

ble for compliance could void

WARNING

the user's authority to operate

• The right outside rearview

the device.

mirror is convex. Objects seen

in the mirror are closer than

NVS® is a registered trademark and

they appear.

Z-Nav™ is a trademark of the Gentex

• Use your interior rearview

Corporation, Zeeland, Michigan.

mirror or turn your head and

HomeLink® is a registered trademark

look to determine the actual

owned by Johnson Controls,

distance of following vehicles

Incorporated, Milwaukee, Wisconsin.

when changing lanes.

WARNING

Do not adjust or fold the outside

rearview mirrors while driving.

This may cause loss of vehicle

control resulting in an accident.

3-58

Convenient features of your vehicle

03

NOTICE

Do not scrape ice off a mirror sur-

face; this may damage the mirror

surface. If ice should restrict

movement of the mirror, do not

force the mirror for adjustment. To

remove ice, use a deicer spray, a

sponge or soft cloth with warm

water.

NOTICE

OVI045040N

If the mirror is jammed with ice, do

Adjusting the rearview mirrors:

not adjust the mirror by force. Use

Press either the L (driver’s side) or R

an approved spray de-icer

(not

(passenger’s side) button

(1) to

radiator antifreeze) to release the

select the rearview mirror you would

frozen mechanism or move the

like to adjust.

vehicle to a warm place in order to

Use the mirror adjustment control (2)

melt the ice.

to move the selected mirror up,

down, left or right.

After adjustment, press the L or R

button (1) again to prevent inadver-

tent adjustment.

NOTICE

• The mirrors stop moving when

they reach the maximum adjust-

ment angles, but the motor con-

tinues to operate while the

switch is depressed. Do not

depress the switch longer than

necessary; the motor may be

damaged.

• Do not attempt to adjust the out-

side rearview mirror by hand or

the motor may be damaged.

3-59

Convenient features of your vehicle

Folding the Outside Rearview

To unfold:

Mirrors

Press the button located on the dri-

ver’s side door panel.

The Engine Start/Stop Button must

be in the ON position or within

approximately 30 seconds after the

Engine Start/Stop Button is pressed

to the ACC position or the OFF posi-

tion.

Also, the outside rearview mirrors

can be unfolded when you approach

the vehicle with the Smart Key in

your possession or unlock the doors

OVI045041N

with the Smart Key.

When you fold the outside mirror

To fold:

after locking the doors, the automat-

Press the button located on the dri-

ic unfolding function by the Smart

ver’s side door panel.

Key does not work.

The Engine Start/Stop Button must be

ON or within approximately 30 sec-

NOTICE

onds after the Engine Start/Stop

Button is pressed to the ACC position

Do not fold the automatic type of

or the OFF position.

the outside rearview mirror by

hand. This could cause failure of

Also, the outside rearview mirrors

the motor.

can be folded when you lock the

doors with the Smart Key.

3-60

Convenient features of your vehicle

03

Electric chromic mirror (ECM)

Reverse Parking Aid Function

(if equipped)

The electric chromic mirror automat-

ically controls the glare from the

headlamps of the vehicles behind

during the night time or low light driv-

ing conditions. The sensor mounted

in the mirror senses the light level

around the vehicle, and automatical-

ly controls the headlamp glare from

following vehicles.

When the engine is running, the

glare is automatically controlled by

OVI045033N

the sensor mounted in the rearview

When you set the shift lever in R

mirror.

(Reverse), the outside rearview mir-

Whenever the shift lever is in R

ror(s) will slightly rotate downwards

(Reverse), the mirror automatically

to aid the driver to drive backwards.

sets to be in the brightest mode in

The position of the outside rearview

order to improve the driver's

mirror switch (1) determines whether

rearview. When the ECM inside the

or not the mirrors will move:

rear view mirror operates, it will oper-

Left/Right: When either the L or R

ate.

switch is selected, both

outside rearview mirrors

NOTICE

will move.

When cleaning the mirror, use a

Neutral: When neither of the switch-

paper towel or clean cloth damp-

es is selected, the outside

ened with glass cleaner. Do not

rearview mirrors will not

spray glass cleaner directly on the

move.

mirror as that may cause the liq-

The outside rearview mirrors will

uid cleaner to enter the mirror

automatically reset to their default

housing.

positions, when one of the followings

occurs:

• The Engine Start/Stop Button is

pressed to either the OFF position

or the ACC position.

• The shift lever is not in

R(Reverse).

• The outside rearview mirror switch

is not selected.

3-61

Content   ..  7  8  9  10   ..
