Hyundai Equus (2016 year). Instruction - part 8

Convenient features of your vehicle

WINDOWS

OVI045021N

(1) Driver’s Door Power Window

(5) Window Opening and Closing

Switch

(6) Automatic Power Window

(2) Front Passenger’s Door Power

Up/Down

Window Switch

(7) Power Window Lock Switch

(3) Rear Door (left) Power Window

Switch and Curtain Switch

i

Information

(if equipped)

In a cold and wet temperature, power

(4) Rear Door (right) Power Window

windows may not properly operate

Switch and Curtain Switch

due to a possible ice formation.

(if equipped)

3-28

Convenient features of your vehicle

03

Power Windows

Window Opening and Closing

The Engine Start/Stop Button must

be ON, before raising or lowering the

windows.

Each door has a Power Window

switch to control that door's window.

The driver has a Power Window Lock

switch to block the operation of pas-

senger windows. The power windows

even operate for approximately 30

seconds after turning the Engine

Start/Stop Button to the ACC or

LOCK position. However, after open-

OVI045021N-1

ing a front door, the Power Windows

To open:

do not operate.

Press the window switch to the first

detent position

(5). Release the

WARNING

switch to stop the operation, as

desired.

To avoid serious injury or death,

do not extend your head, arms

or body outside the windows

To close:

while driving.

Pull up the window switch to the first

detent position

(5). Release the

switch to stop the operation, as

i

Information

desired.

While driving with the rear windows

down or with the sunroof (if equipped)

Auto Up/Down Window

open (or partially open), your vehicle

Momentary pressing or pulling up of

may experience noise due to the wind

the Power Window Switch to the sec-

resistance. This is normal, and the

ond detent position

(6) can com-

noise can be reduced or eliminated by

pletely raise or lower the window,

taking the following actions. When the

even when the switch is released. To

noise occurs with one or both of the

stop the window at the desired posi-

rear windows down, lower both the

tion while the window is in operation,

front windows approximately by one

slightly press or pull up the switch,

inch. When you experience the noise

and release.

with the sunroof open, slightly close

the sunroof to reduce the opening size.

3-29

Convenient features of your vehicle

To Reset the Power Windows

When the power window switch is

pulled up again within five seconds

When the power windows do not nor-

after the window is lowered by the

mally operate, the automatic power

automatic reverse function, this func-

window system must be reset as fol-

tion does not operate.

lows:

1. Press the Engine Start/Stop but-

ton twice to the ON position.

i

Information

2. Continue pulling up the power win-

The automatic reverse function for the

dow switch even after fully closing

driver’s window is only active when

the windows for one second or

the “auto up” function is used by fully

more.

pulling up the switch. The automatic

reverse function will not operate,

If the problem persists, have the sys-

when the window is half open by oper-

tem checked by an authorized

ating the Power Window switch.

EQUUS dealer.

Automatic Reverse

WARNING

Make sure heads, other body

parts or other objects are not

extended from the windows,

before closing, to avoid injury

or vehicle damage.

Objects, which are less than

0.16 in. (4 mm) in diameter and

caught between the window

and the upper window frame,

may not be detected by the

automatic reverse sensor. Thus,

OVI045604N

the window operation will not

automatically stop and be

When a window sensor detects any

reversed.

obstacle while automatically closing

the window, the window will stop the

upward movement, and then be low-

ered by approximately 12 in (30 cm)

to allow the object to be cleared.

When the window sensor detects the

resistance while pulling up the power

window switch, the window will stop

the upward movement, and then be

lowered by approximately 1 in (2.5

cm).

3-30

Convenient features of your vehicle

03

Rear Door Window Curtains

i

Information

(if equipped)

When the upward or downward

■ Driver's door

movement of a curtain is blocked by

an object or part of the body, the cur-

tain will detect the resistance, stop its

movement, and move downwards or

upwards.

NOTICE

Do not apply excessive force

while operating a window curtain.

This may damage a window cur-

tain.

OVI045146N

■ Rear door

i

Information

The rear door window curtain may

not properly operate, when a temper-

ature inside the vehicle is lower than

5°F (-15°C).

To Reset the Rear Door Window

Curtains

When a window curtain does not

OVI045147N

properly operate, it must be reset as

follows:

You can fold or unfold a rear door

1. Press the Engine Start/Stop Button

window curtain with Power Window

to the ON position.

switches on each rear door. The

switch on the driver's door also oper-

2. Close the window curtain by

ates the rear curtains.

pressing the power window switch

to the first detent position and con-

To unfold:

tinuously pull it up for 10 seconds

1. Pull up the switch to close the win-

or over.

dow.

If the problem persists, have the sys-

2. Pull up the switch again to unfold

tem checked by an authorized

the window curtain.

EQUUS dealer.

To fold:

1. Press down the switch to fold the

window curtain.

2. Press down the switch again to

open the window.

3-31

Convenient features of your vehicle

Power Window Lock Button

WARNING

Do not allow children to play

with the power windows. Keep

the Power Window Lock Switch

on the driver's door in the

LOCK position (indicator illumi-

nating).

Serious injury or death may

result from a child's uninten-

tional operation.

OVI045022N

NOTICE

The driver can disengage the Power

Window switches of the rear doors

• To prevent possible damage to

the Power Window system, do

by pressing the Power Window Lock

Switch. The indicator will illuminate.

not simultaneously open or

close two windows or more. This

The Power Window Lock Switch indi-

will lengthen the fuse durability.

cator illuminates in one of the follow-

• Never operate the main switch

ing situations:

on the driver's door and a win-

• The driver’s master control can

dow switch of other doors in an

operate all the power windows.

opposing direction at the same

• The front passenger’s control can

time. In this case, the window

operate the front passenger’s

will stop and cannot be opened

Power Window

or closed.

• The rear control cannot operate

the Power Windows of rear doors.

3-32

Convenient features of your vehicle

03

HOOD

Opening the Hood

Closing the Hood

1. Before closing the hood, check the

followings:

• All filler caps in engine compart-

ment must be securely closed.

• Gloves, rags or any other com-

bustible material must be

removed from the engine com-

partment.

2. Lower the hood halfway and push

down to securely lock in place.

Then, double check that the hood

OVI045020N

is securely latched.

1. Pull up the vehicle and set the

parking brake.

WARNING

2. Pull the release lever under the

lower left corner of the instrument

• Before closing the hood,

cluster to open the hood. The hood

make sure that all obstacles

will slightly pop up.

are removed from the path of

the hood opening.

• Always double check that the

hood is firmly latched before

driving. If not, the hood may

swing open while driving,

causing a total loss of visibili-

ty and an accident.

• Do not drive the vehicle, when

the hood is slightly opened,

as vision is obstructed, possi-

bly resulting in an accident

and damaging the hood.

OVI045023N

3. Slightly raise the hood to the sec-

ond detent position (1) under the

hood center until it releases the

hood and lifts the hood (2). After

being raised halfway up, the hood

will automatically swing open.

3-33

Convenient features of your vehicle

FUEL FILLER LID

Opening the Fuel Filler Lid

Closing the Fuel Filler Lid

1. To close the fuel tank cap, turn it in

a clockwise direction, until it clicks.

2. Close the Fuel Filler Lid until it is

securely latched.

When the Malfunction Indicator Light

(

) illuminates, turn OFF the

engine, check or retighten the fuel

filler cap until it clicks. When the

Malfunction Indicator Light

(

)

remains illuminated, have your vehi-

OVI045024N

cle checked by your EQUUS dealer.

WARNING

Gasoline is highly flammable

and explosive. Failure to follow

these guidelines may result in

SERIOUS INJURY or DEATH:

• Read and follow all warnings

posted at the gas station.

• Before refueling, check the

OVI045025N

location of the Emergency

Gasoline Shut-Off, if available,

1. Turn OFF the engine.

at the gas station.

2. Push the fuel filler lid open button

• Before touching the fuel noz-

on the driver’s door. Then, the fuel

zle, you should eliminate the

filler lid will slowly swing open (1).

static electricity potentially

3. To open the fuel tank cap (2), turn

built up on your body by

it in a counterclockwise direction.

touching a metal part of the

You may hear a hissing noise, as

vehicle with your bare hand,

the inside pressure equalizes.

keeping a safe distance away

4. Place the cap on the fuel filler door.

from the fuel filler neck, noz-

zle, or other gas source.

• Do not use cellular phones

while refueling. Electric cur-

rent and/or electronic interfer-

ence from cellular phones

may potentially ignite fuel

vapors and cause a fire.

(Continued)

3-34

Convenient features of your vehicle

03

(Continued)

(Continued)

•

Do not get back into a vehicle

•

Do not use matches or a

while refueling. You may build

lighter and do not smoke or

up static electricity by touch-

leave a lit cigarette in your

ing, rubbing or sliding against

vehicle while at a gas station,

any item or fabric capable of

especially during refueling.

producing static electricity.

•

Do not overfill or "top-off"

Static electricity discharge

your vehicle tank, which may

may ignite fuel vapors, caus-

cause gasoline spillage.

ing a fire. When you must re-

•

When a fire breaks out during

enter the vehicle, you should

refueling, stay away from the

eliminate potentially danger-

vehicle, and immediately noti-

ous static electricity once

fy it to the gas station manag-

again by touching a metal part

er, and call the local fire

of the vehicle with your bare

department. Follow any safety

hand, keeping a safe distance

instructions they provide.

away from the fuel filler neck,

nozzle, or other gas source.

•

When pressurized fuel sprays

out, it may cover your clothes

•

When using an approved

or skin. This puts you at risk

portable fuel container, make

of fire and burns. Always care-

sure to place the container on

fully and slowly open the fuel

the ground, before refueling.

cap. When the fuel vents out

Static electricity discharged

from the tank, or when you

from the container may ignite

hear a hissing sound, wait

fuel vapors, causing a fire.

until those stop before com-

Once refueling has begun,

pletely opening the cap.

contact between your bare

•

Always check that the fuel cap

hand and the vehicle should

is securely closed to prevent

be maintained until the filling

fuel spillage in the event of an

is complete.

accident.

•

Use only approved portable

plastic

fuel

containers

designed to carry and store

gasoline.

•

When refueling, always set the

shift lever in P (Park), set the

parking brake, and turn OFF

the Engine Start/Stop button.

Sparks produced by electrical

components related to the

engine may ignite fuel vapors,

causing a fire.

(Continued)

3-35

Convenient features of your vehicle

03

SUNROOF

Sliding the Sunroof

Automatic Reverse

OVI045028N

OVI045029N

The Engine Start/Stop Button must

When the sunroof detects any obsta-

be ON, before opening or closing the

cle while automatically closing, it will

sunroof.

moves in a reverse direction to allow

the object to be cleared.

Momentary pressing of the sunroof

control switch to the second detent

position either forwards or back-

WARNING

wards completely opens or closes

the sunroof, even when the switch is

Objects less than 0.16 in. (4 mm)

released. To stop the sunroof at the

in diameter caught between the

desired position, while the sunroof is

sunroof glass and the sunroof

in motion, re-press the sunroof con-

sunshade may not be detected

trol lever either forwards or back-

by the sensor, and the sunroof

wards. Then, release the switch.

will not move in a reverse direc-

The sunroof can open or close by

tion.

pressing the sunroof control switch

forwards and backwards to the first

detent position. However, the sunroof

opens or closes only by pressing the

sunroof control switch.

3-37

Convenient features of your vehicle

Tilting the Sunroof

i

Information

The sunroof cannot slide in the tilt

position nor can it be tilted while in an

open/slided position.

After washing the vehicle or after a

rain, make sure to wipe off the water

on the sunroof before operating it.

NOTICE

•

Periodically remove dirt accu-

mulation over the sunroof guide

OVI045030N

rails or between the sunroof and

roof panel, which may cause a

To tilt the sunroof open:

noise.

Push the sunroof control lever

•

Do not attempt to open the sun-

upwards to the second detent posi-

roof, when a temperature is

tion. To stop the sunroof tilting at the

below the freezing point, or

desired point, adjust the control

when the sunroof is covered

lever.

with snow or ice. Otherwise, the

motor may be damaged. In a

To close the sunroof:

cold and wet temperature, the

sunroof may not properly oper-

Pull the sunroof lever downwards

ate.

until the sunroof moves to the

desired position.

•

To prevent damage to the sun-

roof and the motor, do not con-

tinuously press the sunroof con-

WARNING

trol lever, after it is fully opened,

closed or tilted.

• Make sure heads, other body

parts or other objects are not

extended out of the sunroof to

avoid injury or vehicle dam-

age.

• Never operate the sunroof or

sunshade while driving. This

may cause loss of vehicle

control, resulting in an acci-

dent.

• To avoid serious injury or

death, do not extend your

head, arms or body out of the

sunroof while driving.

3-38

Convenient features of your vehicle

03

Resetting the Sunroof

Sunshade

Sunroof needs to be reset if (in the

followings)

- Battery is discharged or discon-

nected or the related fuse has been

replaced or disconnected.

- The one-touch sliding function of

the sunroof does not normally oper-

ate.

1. The Engine Start/Stop Button

must be ON.

2. Completely close the sunroof.

OVI045031N

Then, release the control lever.

The sunshade will open automatical-

3. Pull down the control lever and

ly along with the sunroof when the

hold it, until the sunroof slightly

glass panel moves. You can manual-

moves up and down. Then,

ly close the sunshade. Do not leave

release the control lever.

the sunshade closed while the sun-

4. Pull down the control lever and

roof is open.

hold it, until the sunroof operates

as follows:

TILT DOWN → SLIDE OPEN →

SLIDE CLOSE

Then, release the control lever.

If the problem persists, have the sys-

tem checked by an EQUUS dealer.

3-39

Convenient features of your vehicle

DRIVER POSITION MEMORY SYSTEM

Storing the Position Memory

1. Make sure that the shift lever is in

P (Park), and the Engine Start/

Stop Button is ON.

2. Adjust the driver’s seat, the out-

side rearview mirrors, the steering

wheel and the HUD

(Head-Up

Display) height as desired.

3. Press the SET button on the con-

trol panel. There will be a beeping

sound.

OVI045032N

4. Press one of the memory buttons

This system is to set and recall the

(1 or 2) for 5 seconds after press-

position memory about the driver’s

ing the SET button. There will be

seat, the outside rearview mirrors,

beeping sounds twice, when the

the steering wheel and the HUD

position memory is successfully

(Head-Up Display) height. When the

saved.

battery is disconnected, the position

memory will be erased and the driv-

ing position memory must be re-set

in the system. When this system

does not normally operate, have the

driver position memory system

checked by an authorized EQUUS

dealer.

WARNING

Never attempt to operate the

driver position memory system

while driving. This may cause

loss of vehicle control resulting

in an accident.

3-40

Convenient features of your vehicle

STEERING WHEEL

Electronic Hydraulic Power

Tilt Steering/Telescope Steering

Steering (EHPS)

This system uses an electromotor to

assist your steering. When the

engine is turned OFF, or when the

EHPS becomes inoperative, you

may still steer the vehicle, but it

requires more effort in steering.

When you notice such a change

while steering, have the EHPS

checked by an authorized EQUUS

dealer.

OVI045034N

NOTICE

Adjust the steering wheel angle (2)

Do not turn the steering wheel to

and position (3) with the knob (1) on

the steering column. Move the steer-

the extreme right or left for five

ing wheel, so it points toward your

seconds or over, while running the

chest, not toward your face. Make

engine. This may cause damage to

sure you can monitor the warning

the EHPS motor pump.

lights and gauges on the instrument

cluster. After adjusting, slightly push

i

Information

up and down the steering wheel to

When there is a malfunction with the

assure that it is locked in position.

EHPS motor pump, the efforts to steer

Always adjust the position of the

may greatly increase.

steering wheel before driving.

i

Information

WARNING

When the vehicle is parked outside for

an extended period of time at a cold

NEVER adjust the steering

temperature (below 14°F/-10°C), the

wheel while driving. This may

power steering may require more

cause loss of vehicle control,

efforts, after first starting the engine.

resulting in an accident.

This is due to the increased fluid vis-

cosity at a cold temperature and does

not indicate a malfunction.

When this happens, depress the accel-

erator to increase the engine RPM,

until it reaches 1,500 rpm. Then, let

the engine idle for two-to-three min-

utes to warm up the fluid.

3-42

Convenient features of your vehicle

03

Heated Steering Wheel

Horn

OVI045035N

OVI045036N

When the Engine Start/Stop Button

To sound the horn, press the horn-

is ON, press the heated steering

symbol area on the steering wheel

wheel button to warm up the steering

(see illustration). The horn will oper-

wheel. The indicator will illuminate.

ate, only by pressing this horn-sym-

To turn the heated steering wheel

bol area.

OFF, press the button again. The

indicator will be turned OFF. The

NOTICE

heated steering wheel will turn OFF

Do not strike the horn hard to

in approximately 30 minutes.

operate it, or hit it with your fist.

Do not press on the horn with a

WARNING

sharp object.

When the steering wheel gets

too hot, turn OFF the system.

The heated steering wheel may

cause burns even at a low tem-

perature, especially if used for a

long period of time.

NOTICE

Do not install any cover and grip

on the steering wheel. This may

cause damage to the heated steer-

ing wheel system.

3-43

Convenient features of your vehicle

MIRRORS

Interior rearview mirrors

Electric chromic mirror (ECM)

with HomeLink® system and

Before you start driving, adjust the

compass (Type A)

rearview mirror to focus on the cen-

ter of the rearview through the rear

Your vehicle is equipped with a

window.

Gentex Automatic-Dimming Mirror

with a Z-Nav™ Electronic Compass

Display

and an Integrated

WARNING

HomeLink® Wireless Control System.

Make sure that your sight is not

During the night-time driving, this fea-

obstructed. Do not pile up

ture automatically detects and

objects on a rear seat, in a

reduces rearview mirror glare while

trunk, or behind a head

the compass indicates the direction

restraint, which may interfere

the vehicle heads for. The HomeLink®

with your vision through the

Universal Transceiver allows you to

rear window.

activate your garage door(s), electric

gate, home lighting, etc.

WARNING

To prevent serious injury during

an accident or deployment of

the air bag, do not modify the

rearview mirror and do not

install a wide mirror.

WARNING

OVI045605N

NEVER adjust the mirror while

(1) Telematics button

driving. This may cause loss of

(2) Telematics button

vehicle control resulting in an

(3) Telematics button

accident.

(4) Compass control button &

Dimming ON/OFF button

(5) Status indicator LED

(6) Channel 1 button

(7) Channel 2 button

(8) Channel 3 button

(9) Compass display

(10) Rear light sensor

3-44

Content   ..  6  7  8  9   ..
