Hyundai Santa Fe (2006 year). Manual - part 105
GENERAL
BD -3
TIGHTENING TORQUE
EE62FFD8
Items
N.m
Kgf.m
lbf.ft
Door hinge to body
21.6~26.5
2.2~2.7
15.9~19.5
Front and rear doors
Door hinge to door
21.6~26.5
2.2~2.7
15.9~19.5
Tail gate hing to body
21.6~26.5
2.2~2.7
15.9~19.5
Tail gate
Tail gate hing tail gate
21.6~26.5
2.2~2.7
15.9~19.5
Hood hinge to body
21.6~26.5
2.2~2.7
15.9~19.5
Hood hinge to hood
21.6~26.5
2.2~2.7
15.9~19.5
Hood
Hood latch to body
6.9~10.8
0.7~0.1
5.1~8.0
Front seat mounting bolts
43.1~64.7
4.4~6.6
31.8~47.7
Front seat mounting nut
43.1~64.7
4.4~6.6
31.8~47.7
Seat
Rear seat mounting bolts
43.1~64.7
4.4~6.6
31.8~47.7
Front seat belt height adjuster
39.2~53.9
4.0~5.5
28.9~39.8
Front seat belt buckle mounting bolt
39.2~53.9
4.0~5.5
28.9~39.8
Front seat belt anchor mounting bolt
39.2~53.9
4.0~5.5
28.9~39.8
Front seat belt lower anchor
39.2~53.9
4.0~5.5
28.9~39.8
Front seat belt upper anchor
39.2~53.9
4.0~5.5
28.9~39.8
Rear seat belt anchor attaching bolt
39.2~53.9
4.0~5.5
28.9~39.8
Seat belt
Rear seat belt retractor mounting bolt
39.2~53.9
4.0~5.5
28.9~39.8
