47

BODY CONSTRUCTION -  Tail gate

NO

1
2

 PART TIME

Tail gate outer panel
Tail gate inner panel

TB-800A/B

TAIL GATE

 1

 2

REPLACEMENT
PARTS

50

REPLACEMENT PARTS - Front body

REPLACEMENT PARTS

The following section illustrates replacement parts used in the repairs described in this manual. It is important that only
Hyundai replacement parts be used in making these repairs  to ensure the repairs are made with the highest possible
standards for fit, safety and corrosion protection.

For a more complete listing of service parts, refer to an authorized Hyundai dealership.

FRONT BODY

A

B

C

D

E

RADIATOR SUPPORT COMPLETE MEMBER ASSEMBLY

FRONT SIDE MEMBER ASSEMBLY,

LH/RH

FENDER APRON PANEL ASSEMBLY,

LH/RH

DASH PANEL COMPLETE

COWL PANEL ASSEMBLY

PART NAME

TB-60

C

B

D

A

E

51

REPLACEMENT PARTS - Side body

SIDE BODY

PART NAME

FENDER MOUNTING BRACKET ASSEMBLY,

LH/RH

FRONT PILLAR OUTER PANEL,

LH/RH

CENTER PILLAR OUTER ASSEMBLY,

LH/RH

QUARTER OUTER PANEL ASSEMBLY,

LH/RH

SIDE SILL OUTER PANEL,

LH/RH

SIDE INNER PANEL ASSEMBLY,

LH/RH

QUARTER INNER PANEL ASSEMBLY,

LH/RH

REAR PILLAR PANEL ASSEMBLY,

LH/RH

QUARTER OUTER REAR LOWER EXTENSION ASSEMBLY, LH/RH

QUARTER OUTER PANEL ASSEMBLY, 3DOOR

LH/RH

(3 DOOR)

A

B

C

D

E

F

G

H

I

J

TB-800C

C

B

A

D

E

F

G

J

I

H
