39

BODY CONSTRUCTION -  Rear floor

TB-550

<Cross-Sectional Views>

1. REAR FLOOR

SECTION B-B'

SECTION A-A'

550-1

550-3

550-2

SECTION C-C'

Rear floor panel

Rear floor extension

Rear under floor
member

Rear floor side
member

Rear floor panel

Wheel house inner
panel

Spare tire mounting bracket

A

A'

C'

B'

C

B

Rear floor panel

Rear towing hook bracket

Ó

Ó

Ó

Ó

Ó

Ó

40

SECTION B-B'

BODY CONSTRUCTION - Rear floor side member

2. REAR FLOOR SIDE MEMBER

600-2

SECTION D-D'

SECTION C-C'

TB-600

SECTION A-A'

600-1

600-4

Side sill inner
extension

Rear floor front cross member

Rear floor side
member

Rear floor side
front member

Trailing arm mounting
reinforcement

Rear floor side
member

Side sill inner
rear extension

Trailing arm bracket

Rear floor side member
reinforcement

Rear floor side member

Rear suspension
spring reinforcement

600-3

Rear floor panel

Rear floor side
member extension

Rear floor side member

Trim & net mounting
rear bracket

B'

B

A'

A

Ó

Ó

C'

C

Ó

Ó

D'

D

Ó

Ó

Ó

Ó

41

BODY CONSTRUCTION -  Rear body < Back panel>

REAR  BODY

BACK PANEL

No

PART NAME

Tail gate striker reinforcement assembly
Rear transverse member
Back panel
Rear bumper cover lower mounting bracket

1
2
3
4

TB-650

1

2

3

4

42

SECTION  B-B'

SECTION A-A'

BODY CONSTRUCTION -  Rear body <Back panel>

660-1

660-2

TB-0660

Tail gate striker reinforcement

Rear transverse member

Back panel

Child restraint anchor
reinforcement

Rear transverse member

<Cross-sectional Views>

A'

A

B'

B

Í

Í

Í

Í

Back panel
