35

BODY CONSTRUCTION -  Side body <Quarter panel-3Door>

4-1. QUARTER PANEL (3DOOR)

No

5

4

3

9

1

2

11

8

6

1

Wheel house inner front extension

LH/RH

2

Quarter inner upper reinforcement assembly

LH/RH

3

Quarter inner panel

LH/RH

4

Quarter inner rear lower extension

LH/RH

5

Quarter pillar inner reinforcement

LH/RH

6

Rear spring house cover

LH/RH

7

Wheel house inner panel

LH/RH

8

Rear pillar panel assembly

LH/RH

9

Quarter outer rear lower extension

LH/RH

10

Fuel filler housing assembly

11

Side outer panel

LH/RH

PART NAME

TB-0480B

7

10

36

SECTION A-A'

SECTION C-C'

BODY CONSTRUCTION -  Side body <Quarter panel - 3 Door>

<Cross-Sectional Views>

     SECTION B-B'

           809-3A

809-4

TB-809

 SECTION D-D'

Side outer panel

Center pillar outer lower
reinfocement

Fuel filler housing

Quarter outer rear
lower extension

809-1

Mastic sealer

Side outer
reinforcement

C'

C

Í

Í

D'

D

Í

Í

Ð

A'

A

Ð

Ð

B

B

Ð

           809-3

Side outer
reinforcement

Side outer panel

Side outer panel

Side outer
reinforcement

Front seat belt upper
reinforcement assembly

37

BODY CONSTRUCTION -  Center floor

CENTER FLOOR PANEL

No

5

4

3

9

1

2

8

6

1

Center floor panel

2

Center floor front reinforcement

3

Parking brake aperture panel

4

Front seat cross member

5

TGS lever mounting bracket

6

Front seat mounting rear inner bracket

LH/RH

7

Front seat mounting rear side bracket

LH

8

Front seat mounting rear side bracket

RH

9

Center floor side member

LH/RH

10

Center floor tunnel brace

PART NAME

TB-539

7

10

38

BODY CONSTRUCTION -  Rear floor & side member

REAR FLOOR & SIDE MEMBER

1

6

13

10

2

4

11

6

9

7

2

12

No

TB-540

Rear floor side member

LH/RH

Rear floor side front member

LH/RH

Rear floor side member extension

LH/RH

Rear floor side member reinforcement LH/RH
Trailing arm mounting reinforcement

LH/RH

Rear suspension spring reinforcement LH/RH
Trim & net mounting front bracket

LH/RH

Trim & net mounting rear bracket
Muffler hanger mounting rear hook
Side sill inner rear extension

LH/RH

Trailing arm bracket

LH/RH

Rear floor front cross member

LH/RH

Rear floor panel

No

PART NAME

Spare tire mounting bracket
Rear towing hook bracket
Rear floor gusset

LH/RH

Rear floor extension
Rear floor center cross member
Rear seat rear bracket

LH

Rear seat rear center bracket
Rear seat rear bracket

RH

Fuel tank mounting rear bracket

LH/RH

Muffler hanger hook
Brake hose mounting bracket
Rear floor support bracket

1
2
3
4
5
6
7
8
9

10
11
12
13

14
15
16
17
18
19
20
21
22
23
24
25

PART NAME

16

15

17

19

20

21

23

22

24

25

22

1

5

5

8

16

10

14

4

3

3

7

18

11
