31

SECTION C-C'

SECTION B-B'

SECTION A-A'

BODY CONSTRUCTION - Side body <Center pillar>

2. CENTER PILLAR

TB-400

400-1

400-2

SECTION D-D'

<Cross-Sectional Views>

Side outer reinforcement

Center pillar outer upper reinforcement

Side outer reinforcement

Center pillar outer
lower reinforcement

Side outer reinforcement

400-4

Side outer reinforcement

Side outer panel

Side outer panel

Rear door lower
mounting bracket

400-3

Center pillar upper
deadening pad

A

A'

Ð

Ð

B

B'

Ð

Ð

C

C'

Ð

Ð

D

D'

Ð

Ð

32

BODY CONSTRUCTION - Side body <Side sill>

3. SIDE SILL

<Cross-Sectional Views>

SECTION B-B'

SECTION A-A'

TB-0008

450-1

Side outer panel

Side outer reinforcement

A

A'

Í

Í

33

BODY CONSTRUCTION -  Side body <Quarter panel>

4. QUARTER PANEL

No

5

4

3

11

1

2

13

14

1

Wheel house inner front extension

LH/RH

2

Quarter inner upper reinforcement assembly

LH/RH

3

Quarter inner panel

LH/RH

4

Quarter inner rear lower extension

LH/RH

5

Quarter pillar inner reinforcement assembly

LH/RH

6

Rear spring house cover

LH/RH

7

Quarter outer rear upper extension

LH/RH

8

Quarter outer rear center upper extension LH/RH

9

Quarter outer rear center extension

LH/RH

10

Rear combination lamp housing panel

LH/RH

11

Quater outer rear lower extension

LH/RH

12

Fuel filler housing

13

Side outer panel

LH/RH

14

Wheel house inner panel

LH/RH

PART NAME

TB-480A

7

12

9

10

8

6

34

SECTION C-C'

BODY CONSTRUCTION -  Side body <Quarter panel>

<Cross-Sectional Views>

SECTION A-A'

     SECTION B-B'

           490-1

490-2

TB-08

 SECTION D-D'

Side outer panel

Side outer reinforcement

Side outer panel

Rear pillar panel

Fuel filler housing

Quarter outer rear lower
extension

490-4

Side outer panel

Side outer panel

           490-3

Ó

A'

Ó

A

Ó

B'

B

C'

C

D'

D

Ó

Ó

Ó

Ó

Ó
